T-audio LX350C User manual

LX120C
12-Slots Charger Hand Bag
LX350C 35-Slots Charger Carry Case
Quick Start Guide
Visit T-audio online: www.t-audio.eu

1. lntroduction
Model
LX120C
LX350C
Product Name
12 slots charger hand bag
35 slots charger carry case
Applicable to
LX200T, LX200R, LX200S
LX200T, LX200R, LX200S
2. Operating lnstructions
2- 1 Plug the DC output of the power adaptor into the charger and the AC
plug into an AC outlet.
Step 1
Align the ARROW
marking on the
connectors and
connecting adaptor's
DC 4pin mini-din
male output to the
TC-35K DC femal
input.
Step 2
To disconnect, firmly
push off the disconnect
clip toward the adaptor
as shown - this will
release the locking
mechanism. Then pull
the two connectors
apart.
2-2 lnsert the transmitter or receiver into the compartment in
accordance with direction as shown in the picture below.
•
�
2- 3 LED Indicators
• Red solid LED indicates the transmitter or receiver is charging.
• Green solid LED indicates the transmitter or receiver is fully charged.
• LED lights off indicates system is not charging.
• LED Flashing indicates that the system is in channel synchronization.
• Additional synchronization kits, such as LX200K, are available.
Charging
compartment
LED indicator
Micro USB charging
socket
3. The charger takes approx. 6-7hr to charge trom 1 % to 100%
4. Caution
• Keep this equipment dry and secure, and away from fire.
• Do not place this equipment in direct sunlight or a humid environment.
• Do not drop or shake this equipment.
T-audio V.1
