T-VIPS CP525 cMux User manual

CP525 cMux
User’s Manual
Revision: 5.20.12 (3944)
2012-12-17
Valid for SW version 5.20.12 and newer

Contents
1History 11
2Introduction 13
2.1 Scope 13
2.2 Warnings, cautions and notes 13
2.3 Heed warnings 14
2.4 Contact information 14
3Short Product Description 15
3.1 Summary of Features 15
3.2 Software options 17
4Installing the Equipment 19
4.1 Inspect the package content 19
4.2 Installation Environment 19
4.3 Equipment installation 20
4.4 Ventilation 20
4.5 Power supply 21
4.5.1 AC power supply 21
4.5.2 Dual AC power supplies 21
4.5.2.1 AC power cable 21
4.5.2.2 Protective Earth/technical Earth 22
4.5.2.3 Connecting to the AC power supply 22
4.5.3 DC power supply 23
4.5.3.1 DC power cable 23
4.5.4 Powering up/down 23
5Functional Description 25
5.1 Introduction 25
5.2 TS inputs 25
5.3 TS output 26
5.4 Input switching 26
5.5 Optional SFN adapter 26
5.6 Video over IP 26
5.6.1 Input and output 26
5.6.2 Protocol mapping 27
5.7 Management sub-system 27
5.7.1 Graphical user interface 28
5.7.2 Configuration database 28
5.7.3 Alarm manager 28

5.8 Time synchronisation 29
5.9 TSP Module 29
5.9.1 PID Router 30
5.9.2 PSI/SI/PSIP section filter 31
5.9.3 PSI/SI/PSIP playout module 31
5.9.4 Output Priority Queue 32
5.9.5 Output Priority Queue Advanced 35
5.9.6 Bitrate shaping algorithm 36
5.9.7 TS Builder - Service and PID routing 37
5.10 PSI/SI/PSIP playout 39
5.10.1 Main configuration 39
5.10.2 Carousel priorities 39
5.10.3 Carousel bitrate 40
5.10.4 Bitrate saturation handling 41
5.10.5 Configurable back-log time 41
5.11 Handling of expired EIT schedule events 42
5.11.1 Grouping of sections - configuration 43
5.11.2 “Sliding window” and expired events 43
5.11.3 Notes about the playout sequence 44
5.12 Programming Metadata Communication Protocol (PMCP) 44
5.13 Scrambling 45
5.13.1 General 45
5.13.2 Simulcrypt setup 45
5.13.2.1 ECMG <=>SCS 46
5.13.2.2 EMMG <=>MUX 46
5.13.3 BISS mode 1 46
5.13.4 Scramble service 46
5.14 Service fallback 47
5.14.1 General 47
5.14.2 Details on confirm timeout handling 49
5.14.3 Manual switching on GPI 50
5.15 Hitless switching 51
5.16 Output Mute Controller 52
5.17 The SFP module 53
6Physical Description 55
6.1 Connecting the CP525 55
6.1.1 Physical description overview 55
6.1.2 ASI ports 56
6.1.3 ASI input ports 57
6.1.4 ASI output ports 58
6.1.5 1 PPS Input 58
6.1.6 Electrical Ethernet Data Ports 58
6.1.7 SFP port 58
6.1.8 Power Supply 59
6.1.9 Ethernet Management Port 59

6.1.10 Technical Earth 59
6.1.11 Alarm/Reset 59
6.1.12 Serial USB interface 60
7Operating the Equipment 61
7.1 Accessing the graphical user interface 61
7.2 Password protection 61
7.2.1 Resetting the password list 62
7.3 Changing the IP address of the unit 62
7.3.1 Changing IP address via the Web GUI 62
7.3.2 Changing the management port IP address via terminal interface 63
7.3.3 Detecting the management port IP address 64
7.3.3.1 USB Interface 64
7.3.3.2 T-VIPS Detect 65
8WEB Interface 67
8.1 Login 67
8.2 Status header 68
8.3 Status 69
8.3.1 Current Status 69
8.3.2 Alarm log 72
8.4 Device Info 73
8.4.1 Product info 73
8.4.2 Alarms 76
8.4.2.1 Device alarms 76
8.4.2.2 Global configuration 77
8.4.2.3 Relays and LED 78
8.4.2.4 Alarm log settings 80
8.4.3 Port Mappings 81
8.4.4 Time Settings 82
8.4.5 Network 84
8.4.5.1 Interfaces 85
8.4.5.1.1 Main 85
8.4.5.1.2 Alarms 86
8.4.5.1.3 Advanced 87
8.4.5.1.4 Status 87
8.4.5.1.5 VLAN 89
8.4.5.1.6 SFP 90
8.4.5.2 IP Routing 99
8.4.5.3 TXP Settings 100
8.4.5.4 SNMP Settings 101
8.4.5.5 Tools 102
8.4.6 SI/PSIP Download 104
8.4.6.1 Triveni Digital GuideBuilder 104
8.4.6.2 Divitech SiGul SI Manager 105
8.4.7 Clock Regulator 105

8.4.7.1 Main 105
8.4.7.2 Alarms 106
8.4.8 Save/Load Config 107
8.4.8.1 Save/Load Configs 107
8.4.8.1.1 Save Configuration 108
8.4.8.1.2 Load Configuration From file 108
8.4.8.1.3 Load Configuration from Remote Device 109
8.4.8.2 Boot Log 109
8.4.8.3 Stored Configs 109
8.4.8.4 Emergency Switch 111
8.4.9 Maintenance 113
8.4.9.1 General 113
8.4.9.2 Software Upgrade 116
8.4.9.3 Feature Upgrade 117
8.4.10 Users 118
8.4.11 GUI Preferences 119
8.5 Scrambling 119
8.5.1 BISS1 120
8.5.2 Conditional Access 120
8.5.2.1 ECM 120
8.5.2.2 EMM 124
8.5.2.3 Alarms 126
8.6 Inputs 126
8.6.1 Inputs Overview 126
8.6.1.1 IP Inputs 128
8.6.1.2 Switch Inputs 129
8.6.1.3 Copy Inputs 130
8.6.2 Input 131
8.6.2.1 Main 132
8.6.2.2 Alarms 134
8.6.2.3 IP 139
8.6.2.3.1 RTP/IP Diversity Reception 141
8.6.2.4 Copy 148
8.6.2.5 Services 149
8.6.2.6 PIDs 152
8.6.2.7 Tables 155
8.6.3 Switch 159
8.6.3.1 Main 159
8.6.3.2 Alarms 161
8.7 Outputs 161
8.7.1 Outputs Overview 161
8.7.2 Output 162
8.7.2.1 Main 163
8.7.2.1.1 Configuration Wizard 166
8.7.2.2 Alarms 168
8.7.2.3 IP 169
8.7.2.4 MIP 169

8.7.2.4.1 MIP Configuration 170
8.7.2.4.2 SFN Sync 171
8.7.2.4.3 Configuration 172
8.7.2.4.4 Sync status 172
8.7.2.4.5 Selected TimeSource status 173
8.7.2.4.6 Current transmitted MIP packet 173
8.7.2.5 Services 173
8.7.2.6 Service edit dialogue 176
8.7.2.6.1 Service Edit – General 176
8.7.2.6.2 Service Edit - Service Descriptors 180
8.7.2.6.3 Service Edit - Components 182
8.7.2.6.4 Service Edit – Scrambling 189
8.7.2.6.5 Service Edit – Fallback 191
8.7.2.7 PIDs 194
8.7.2.8 Tables 197
8.7.2.8.1 Main 197
8.7.2.8.2 EIT Sch 200
8.7.2.8.3 EIT/ETT Sch 201
8.7.2.8.4 EIT sources 202
8.7.2.8.5 Dynamic PSIP 203
8.7.2.8.6 Static SI 205
8.7.2.8.7 PSI/SI/PSIP editor 206
8.7.2.8.8 PSI/SI Editor 207
8.7.2.8.9 PSIP Editor 213
8.7.2.9 Pri Queue 218
8.7.2.9.1 Priority Queues 218
8.7.2.9.2 Default Priority Queues 220
8.7.2.10 Advanced 221
8.7.2.10.1 Automatic PID Remapping 221
8.7.2.10.2 Automatic Service Remapping 223
8.7.2.10.3 Mute 225
8.7.2.10.4 Edit Expression dialogue 227
8.7.2.11 Outgoing 228
8.7.2.11.1 Services 228
8.7.2.11.2 Service Routing 229
8.7.2.11.3 PIDs 230
8.7.2.11.4 Tables 231
8.7.3 Output copies 232
8.7.4 TS-OUT ->IP Destination 232
8.7.4.1 Main 232
8.7.4.2 FEC 235
8.7.4.3 Ping 236
9SNMP 239
9.1 SNMP agent characteristics 239
9.2 MIB naming conventions 239
9.3 MIB overview 239

9.3.1 Supported standard MIBs 239
9.3.2 Custom MIBs 239
9.4 SNMP related configuration settings 241
9.4.1 Community strings 241
9.4.2 Trap destination table 242
9.4.3 Trap configuration 242
9.5 Alarm/status related SNMP TRAPs 243
9.5.1 The main trap messages 243
9.5.2 Severity indications 243
9.5.3 Alarm event fields 244
9.5.4 Matching of on/off traps 245
9.5.5 Legacy trap messages 245
9.6 Using net-snmp to access MIB information 246
9.6.1 Reading a parameter with snmpget 246
9.6.2 Writing a parameter with snmpset 246
10 Examples of Use 249
10.1 Intro 249
10.2 Installation in a system 249
10.3 Raw PID multiplexing 249
10.4 Simple local insertion of a progam 250
10.5 Sharing of service component 250
10.6 SFN operation 251
10.7 Seamless SFN 251
10.8 Adding an unsignalled component (Ghost PID) 252
10.9 Scrambling a service using BISS1 key 253
10.9.1 Verify scrambling setup 254
10.10 Conditional Access 254
10.10.1 Scrambling 254
10.10.1.1 Setting up an ECM connection 255
10.10.1.2 Scramble service 255
10.10.2 EMM Insertion 256
11 Preventive Maintenance and Fault-finding 257
11.1 Preventive maintenance 257
11.1.1 Routine inspection 257
11.1.2 Cleaning 257
11.1.3 Servicing 257
11.1.4 Warranty 258
11.2 Fault-finding 258
11.2.1 Preliminary checks 258
11.2.2 PSU LED not lit / power supply problem 259
11.2.3 Fan(s) not working / unit overheating 260
11.3 Disposing of this equipment 260

11.4 Returning the unit 260
ATechnical Specification 261
A.1 Physical details 261
A.1.1 Half-width version 261
A.1.2 Full-width (dual power) version 261
A.2 Environmental conditions 261
A.3 Power 262
A.3.1 AC Mains supply 262
A.3.2 DC supply 262
A.4 Input/output ports 263
A.4.1 DVB ASI port 263
A.4.2 SMPTE 310M port 263
A.4.3 Ethernet management port 263
A.4.4 Ethernet data port 263
A.4.5 Serial USB interface 264
A.5 Alarm ports 264
A.5.1 Alarm relay/reset port specification 264
A.6 External reference 265
A.6.1 10MHz/1 PPS input 265
A.7 Compliance 265
A.7.1 Safety 265
A.7.2 Electromagnetic compatibility - EMC 265
A.7.3 CE marking 266
A.7.4 Interface to “public telecommunication system” 266
BForward Error Correction in IP Networks 267
B.1 IP stream distortion 267
B.2 Standardisation 268
B.3 FEC matrix 268
B.4 Transmission aspects 271
B.5 Quality of service and packet loss in IP networks 272
B.6 Error improvement 273
B.7 Latency and overhead 274
CAlarms 277
DReferences 289
EQuality of Service, Setting Packet Priority 291
E.1 MPLS 291
E.2 Layer 3 routing 291
E.2.1 CP525 configuration 292
E.3 Layer 2 priority 292
E.3.1 CP525 configuration 292

History 11
ID: um_tsmux CP525 cMux User’s Manual Rev. 5.20.12 (3944)
1 History
Revision Date Comments
5.20.10 2012-12-17 – Added description of Copy Inputs.
– Added SFN synchronization for Seamless SFN operation.
5.18.0 2012-08-30 – Updates to Auto Remap functionality.
– Default priority queues description.
– Other minor changes.
5.16.0 2012-08-30 – IP/RTP diversity feature added.
– PSI/SI/PSIP editor feature added.
– Auto remapping of PIDs feature added.
5.2.0 2011-07-08 – Scrambling pages moved
– Added BISS description
5.0.0 2011-05-11 – Description of Forward Error Correction GUI pages included
– Correction of Inputs section
4.8.0 2010-11-25 – Updated with descriptor adding/removing/replacing of components.
4.6.0 2010-08-13 – Port switching feature added.
– Format selection for output ports in Section 8.4.3 in
ATSC+DVB mode to select between ASI or SMPTE 310M per output copy.
– New 10 port ASI card HW option.
– Number of resyncs on IP input status page Section 8.6.2.3.
– Override source IP option field on IP TX parameters.
– Added service details and playout content view on output outgoing views in Section
8.7.2.11.
4.2.40 2010-06-21 – Updated with support for SFP slot.
– Some syntactical updates and general maintenance.
4.2.18 2010-04-21 – Updated for Ethernet data functionallity and Scrambling
1.4 2010-01-04 – Minor changes related to PSIP handling
1.2 2009-07-13 – ATSC version
– Added ATSC/SMPTE 310M information.
– Updated GUI images and fixed some typos.
1.0 2009-01-21 – First version
– This manual is based on manual for CP515

12
CP525 cMux User’s Manual Rev. 5.20.12 (3944) ID: um_tsmux

Introduction 13
ID: um_tsmux CP525 cMux User’s Manual Rev. 5.20.12 (3944)
2 Introduction
2.1 Scope
This manual is written for operators and users of the CP525 cMux and provides necessary
information for installation, operation and day-to-day maintenance of the unit. The manual
covers the functionality of the software version 5.20.12 or later, and continues to be relevant to
subsequent software versions where the functionality of the equipment has not been changed.
When a new software version changes the functionality of the product, an updated version of
this manual will be provided.
The manual covers the following topics:
•Getting started
•Equipment installation
•Operating instructions
•WEB interface description
•Preventive maintenance and fault finding
•Alarm listing
•Technical specifications
2.2 Warnings, cautions and notes
Throughout this manual warnings, cautions and notes are highlighted as shown below:
Warning: This is a warning. Warnings give information, which if strictly
observed, will prevent personal injury and death, or damage to personal
property or the environment.
Caution: This is a caution. Cautions give information, which if strictly
followed, will prevent damage to equipment or other goods.
Note: Notes provide supplementary information. They are highlighted for
emphasis, as in this example, and are placed immediately after the relevant
text.

14 Introduction
CP525 cMux User’s Manual Rev. 5.20.12 (3944) ID: um_tsmux
2.3 Heed warnings
•All warnings marked on the product and in this manual should be adhered to. The
manufacturer cannot be held responsible for injury or damage resulting from negli-
gence of warnings and cautions given.
•All the safety and operating instructions should be read before this product is in-
stalled and operated.
•All operating and usage instructions should be followed.
•The safety and operating instructions should be retained for future reference.
2.4 Contact information
Our primary goal is to provide first class customer care tailored to your specific business and
operational requirements.
Please contact us at:
Telephone [phone]
Fax [phone]
E-mail [email protected]
WEB www.t-vips.com
Mail and visiting address T-VIPS AS
Nils Hansens vei 2
NO-0667 Oslo
Norway

Short Product Description 15
ID: um_tsmux CP525 cMux User’s Manual Rev. 5.20.12 (3944)
3 Short Product Description
The CP525 is part of the T-VIPS cProcessor product family for processing and handling of
MPEG transport streams. The cProcessor family represents a line of compact and powerful, yet
cost-effective, products designed for advanced modification of MPEG Transport Streams.
The CP525 is a Transport Stream Re-multiplexer for regional multiplexing of MPEG transport
streams.
The CP525 supports SFN operation with MIP insertion (software licence key is required).
The CP525 supports DVB Simulcrypt scrambling with ECM and EMM insertion (software licence
key is required).
The CP525 supports insertion of unsignaled PIDs on the input (Ghost PIDs) into outgoing
services.
3.1 Summary of Features
Features of the CP525 include:
•Flexible transport stream processing
−PID and program filtering
−Service component filtering by PID value or by component tag
−Program re-multiplexing
−TS rate adaptation
−Minimum null-packet rate feature
•Powerful PSI/SI/PSIP handling
−PSI/SI regeneration
−PSI/SI/PSIP download and playout
−Flexible EIT handling
−Zero or configurable minimum null-packet rate by filling up with EIT
•PSI/SI/PSIP editor
−Generate and create custom static PSI/SI/PSIP signalling.
•Transport stream monitoring
−TR 101 290 Priority 1 monitoring: Sync loss, CC error
−Monitoring of min/max bitrate for individual PIDs
−Output PID monitoring (CC errors)

16 Short Product Description
CP525 cMux User’s Manual Rev. 5.20.12 (3944) ID: um_tsmux
•Flexible alarm configuration options
−Alarm levels freely configurable individually for each channel
−Individual setting of alarm levels based on PID values
•Compact, cost-effective solution
•User-friendly configuration and control
−WEB/XML based remote control
−Easy access to unit from any WEB browser
−Easy integration to NMS systems with SNMP Trap support
−SNMPv2c agent
−Equipment monitoring from T-VIPS Connect
•SFN adaptation (Option)
−MIP insertion
−1 PPS timing reference input
•Seamless SFN compatible
−Connected to a T-VIPS TNS541 TS Seamless Switch, two CP525’s may operate in a
Seamless SFN network.
−Support for deterministic DVB Megaframe alignment.
•Transmission of transport stream over Gigabit Ethernet (Option)
−Forward Error Correction
•Reception of transport stream over Gigabit Ethernet (Option)
−Forward Error Correction
•Scrambling of services and components (Option)
−BISS mode 1
−DVB Simulcrypt (ECM and EMM)
•RTP/IP diversity reception
−Seamless switching between two IP streams from the same source.
•Automatic PID and service re-mapping
−Rule based processing of muxing operation.

Short Product Description 17
ID: um_tsmux CP525 cMux User’s Manual Rev. 5.20.12 (3944)
3.2 Software options
The CP525 functionality depends on the sofware licences installed. The following table describes
the features available as software options. Please refer to Section 8.4.9.3 for more information
how to obtain and enable feature upgrades.
Table 3.1 Functionality enabled through software licences
Functionality Max value Description
SFP module - Enables operation of the Small form-factor pluggable (SFP) tranceiver slot.
SFP configuration - Enables configuration interface and parameter storage for some specifically
supported SFP modules.
SFN adapter support - Controls whether MIP insertion is made available on output.
Number of input
ports activated
24 Controls the number of simultaneously activated transport stream inputs.
Input switching - Enables creation of input switching groups.
Forward Error Correction - Controls availability of the FEC feature for IP outputs and IP inputs.
RTP/IP diversity reception - Enables configuration of IP diversity reception input pairs.
Ethernet data interface - Controls whether carriage of MPEG transport streams on Ethernet is made
available.
Emergency switch
support
- Enables support for external switch panel to switch between pre-loaded
configurations.
Service fallback - The feature makes it possible to configure pairs of services where one is
back-up for the other. Switching decision is made based on alarm levels on
each service.
SI download - This key is needed to use an external SI system towards the unit.
Enhanced SI playout - This option controls the availability of a few advanced DVB-EIT schedule
playout parameters: ’Use constant section interval’, ’Use sliding window’ and
’Use expired events’. These parameters are explained in Section 5.11.2 and
Section 8.7.2.8.2. Also, this option affects the availability of ’EIT packing’.
This option is explained in Section 8.7.2.8.1. All together, this option offers
a more advanced control of playout out EIT for economisation on bandwith.
PSI/SI/PSIP editor - Controls availability of built-in PSI/SI/PSIP Editor function in GUI, to edit
tables for static playout.
Allow ASI inputs - Enables use of ASI input ports. Without this key the device can be used with
IP input only.
Conditional Access - Control whether device can be used as a DVB Scrambler.
BISS - Control whether device can be used as a BISS mode 1 scrambler.
Advanced traffic
shaping
- Expands the number of queue levels for routed MPEG data on the output
prioritisation queue from 4 to 15. This makes it possible to configure more
advanced prioritization on a PID level to control which data is discarded first
in the event of over-booking the output.
Connect control - Enables supervision of the unit through the Connect Software.

18
CP525 cMux User’s Manual Rev. 5.20.12 (3944) ID: um_tsmux

Installing the Equipment 19
ID: um_tsmux CP525 cMux User’s Manual Rev. 5.20.12 (3944)
4 Installing the Equipment
Caution: The CP525 must be handled carefully to prevent safety hazards
and equipment damage. Ensure that the personnel designated to install
the unit have the required skill and knowledge. Follow the instructions
for installation and use only installation accessories recommended by the
manufacturers.
4.1 Inspect the package content
•Inspect the shipping container for damage. Keep the shipping container and cushioning
material until you have inspected the contents of the shipment for completeness and
have checked that the CP525 is mechanically and electrically in order.
•Verify that you received the following items:
−CP525 with correct power supply option
−Power cord(s)
−CD-ROM containing documentation and Flash Player installation files
−Any optional accessories you have ordered
Note: 48 VDC versions do not ship with a power cord; instead a Power
D-SUB male connector for soldering to the supply leads is supplied.
4.2 Installation Environment
As with any electronic device, the CP525 should be placed where it will not be subjected to
extreme temperatures, humidity, or electromagnetic interference. Specifically, the selected site
should meet the following requirements:
•The ambient temperature should be between 0 and 50 ◦C (32 and 122 ◦F).
•The relative humidity should be less than 95 %, non-condensing. Do not install the
unit in areas of high humidity or where there is danger of water ingress.
•Surrounding electric devices should comply with the electromagnetic field (EMC) stan-
dard IEC 801-3, Level 2 (less than 3 V/m field strength).
•The AC power outlet (when applicable) should be within 1.8 meters (6 feet) of the
CP525.

20 Installing the Equipment
CP525 cMux User’s Manual Rev. 5.20.12 (3944) ID: um_tsmux
•Where appropriate, ensure that this product has an adequate level of lightning protec-
tion. Alternatively, during a lightning storm or if it is left unused and unattended for
long periods of time, unplug it from the power supply and disconnect signal cables.
This prevents damage to the product due to lightning and power-line surges.
Warning: If the CP525 has been subject to a lightning strike or a power
surge which has stopped it working, disconnect the power immediately.
Do not re-apply power until it has been checked for safety. If in doubt
contact T-VIPS.
4.3 Equipment installation
The CP525 is designed for stationary use in a standard 19" rack. When installing please observe
the following points:
•Route cables safely to avoid them being pinched, crushed or otherwise interfered with.
Do not run AC power cables and signal cables in the same duct or conduit.
•The CP525 has all connectors at the rear. When mounting the unit, ensure that the
installation allows easy access to the rear of the unit.
•The fans contained in this unit are not fitted with dust/insect filters. Pay particular
attention to this when considering the environment in which it shall be used.
•Make sure that the equipment is adequately ventilated. Do not block the ventilation
holes on each side of the CP525.
4.4 Ventilation
Openings in the cabinet are provided for ventilation to protect it from overheating and ensure
reliable operation. The openings must not be blocked or covered. Allow at least 50 mm free
air-space each side of the unit.
Warning: Never insert objects of any kind into this equipment through
openings as they may touch dangerous voltage points or create shorts that
could result in a fire or electric shock. Never spill liquid of any kind on or
into the product.
•This product should never be placed near or over a radiator or heat register. Do not
place in a built-in installation (e.g. a rack) unless proper ventilation is provided in
accordance with the device airflow design as depicted in Figure 4.1.
•The CP525 may be vertically stacked in 19" racks without intermediate ventilation pan-
els. In systems with stacked units forced-air cooling may be required to reduce the
operating ambient temperature.
Figure 4.1 shows the air path through the unit, where cool air is taken from the left
hand side, seen from the front.
