tactio CONCERO-85TX1 User manual

www.tactio.net Rev.1.01
Quick Installation Guide
CONCERO-85TX1
85Mbps Powerline Ethernet Adapter
Introduction
The Wall Mount Powerline Ethernet Bridge can be used to bridge any
Ethernet device to your powerline networking with 85Mbps high speed.
No need to spend time and money professionally installing expensive
Ethernet cabling to share your high speed cable or DSL modem.
Sharing your high speed modem is as fast and simple as plugging the
devices in the wall. All with no new wires!
LEDS for Powerline Networking Status
PL Indicate powerline networking activity.
ETH Indicate Ethernet link activity.
PWR Power ready.
Ethernet Status
Ethernet Where you will connect 10/100M Ethernet network devices,
such as PCs, printer servers, and anything else you want to
put on your networks.
Installation
1. Simply plug into a power outlet and do not use a power strip or UPS
with the wall mount device.
2. Use a twisted-pair cable with RJ-45 plugs at both ends, and plug into
Ethernet device and Ethernet of Powerline Bridge 85.
Package Content
•CONCERO-85TX1 Powerline Ethernet Adapter unit
•Quick Installation Guide
•Powerline Management Utility CD
•Ethernet cable
2
1

www.tactio.net Rev.1.01
Warning
This is a class A product. In a domestic environment this product may
cause radio interference in which case the user may be required to take
adequate measures.
Important Safety Instructions
This product is intended for connection to the AC power line.
The following pre-cautions should be taken when using this product:
•Please read all instructions before installing and operating this
product.
•Please follow all warnings and instructions marked on the product.
•Do not operate this product near water.
•This product should never be place near or over radiator, or heat
register.
•This product relies on a building's electrical installation for short-
circuit (over current) protection.
•Ensure that a fuse or circuit breaker is used on the phase
conductors (all current-carrying conductors).
•Do not allow anything to reset on the product interconnect cords.
•Do not locate this product where people may walk on the cords.
•The power cord should be plugged directly into a specification AC
wall outlet.
•Only a qualified technician should service this product. Opening or
removing covers may result in exposure to dangerous voltage points
or other risk.
•Unplug this product from the wall outlet and refer the product to
qualified service personal for the following conditions:
1. When the interconnect cords are damaged or frayed.
2. If liquid has been spilled onto the product.
3. If the product has been exposed to rain or water.
4. If the product does not operate normally when the operating
instructions have followed.
5. If the product exhibits a distinct change in performance.
.
3
