TAIFOND GFL400 User manual

Basic Version
Upgraded Version
Plus Version

1.Packing List
Open the package, then make sure the floodlight
cam(device) is intact, and with all the below
accessories.
Mounting Bracket
Use this bracket to attach to your
Floodlight Cam.
Installation Manual
Please refer to the installation pictures
in the App, and read this manual and
keep it handy during installation.
Smart Floodlight Cam
Hook
Hang your Floodlight Cam while
connecting the wires.
01

WARNING
This manual is for information
purpose only. Working with electricity can be dangerous
unless proper safety precautions are taken.
If you are not comfortable or are inexperienced with the
processes and tools described in this manual, we
recommend that you hire a licensed electrician.
Plastic Expansion Nails Plug (4)
Knock the plastic expansion nails plug into the
hole.
Wire Nuts (3)
Use these to connect Floodlight Cam wires
to your existing wires.
Waterproof rubber cap (2)
Use the waterproof cap on the screw
hole of the device.
Philips big flathead self-drilling screw (4)
Use 2 of these to attach the supplied bracket
to your on the wall.
02
Waterproof rubber gasket
Use the waterproof rubber gasket between
the base and the floodlight cam

03
2.How it all fits together
4*28
Plastic
expansion
Bracket screws
Mounting
bracket
Wire
Nuts

04
Light
Adjustment
Knob
Rubber
cover
Camera
Lock
Collar
Motion
Detector
（for lights）

3.The proper installation height to optimize
the motion sensor performance
26 feet (8 Meters)
WARNING
In order to prolong service life of the equipment,
please try to install the equipment in a place
without rain and high temperature and humidity.
Parallel to groud
3.How installation height to
optimize the motion sensor
05

When mounted at 3 meters off the ground, with the
motion detector about 30 degree to the ground,
the detect human-sized objects distance
up to 8 meters.
9 feet
(3 Meters)
06

Step 1 - Shut power off at the fusebox
If you don’t know where your breaker is or how to turn
off power to the floodlight circuit, consult with a licensed
electrician.
WARNING WARNING: Risk of electrical shock
Properly ground fixture.
Always follow code standards when installing wired connections.
Installation and wiring must be performed by a licensed electrician.
Do not install near combustible or flammable surfaces.
Do not connect this light fixture to a dimmer switch or timer.
Disconnect power at the circuit breaker before installing.
Verify that the supply voltage is correct.
Connect fixture to a 110VAC ~ 240VAC 50/60 Hz power
source.
CAUTION: Risk of fire
NOTICE
OFF
OFF
Please switch it from [ON] to [OFF]
07

Step 2 - Remove the mounting bracket
Use a screwdriver handle to unscrew the nut.
1
Remove the mounting bracket.
2
2
1
08

Step 3- Install the bracket waterproof
rubber gasket
Attach the waterproof rubber gasket into the mounting
bracket, press the 6 holes to fix it.
09

Step 4- To determine the location
First, determine the height of the chassis, and then use
the pen to draw the position of the screw hole, make a
mark.
1 2
4
3
10

1
1
2
2
Before drilling, ensure that the hole does not
impinge on pipe work, cables or other
building services.
Knock the plastic expansion nail plug into
the hole.
Step 5 - Choose a proper place for drilling
11

Step 6 - Fix base
Tighten the screw and fix the base. Pay attention to the
horizontal position on the top.
12
Carefully push all the wires through the large opening in
the bracket.

Connect power wire to terminals Black(Hot) and White(
Neutral)
Align the mounting posts with the holes on Floodlight
Cam and press together, securing the screw cap nuts
with the screwdriver.
Step 7- Connect the power wire
White(Neutral)
13
If you don’t know which is neutral or hot wire coming out
of the junction box, consult with a licensed electrician.
Ternimals(G)
Brown(Live)

Put the waterproof rubber cap on the screw hole.
Tighten the screws with philips bit.
Step 8 - Mounting bracket
14

Step 9 - Adjust the Angle of the light and
camera
Loosen or tighten the screw to adjust the light angle
Do not remove your led light part or camera part from
the ball socket on the base.
Loosen or tighten the screw to adjust the camera angle
15

Step 10 - Restore power at the breaker
After restoring power, the lights will turn on and your
Floodlight Cam will begin speaking to you to let you
know it is in setup mode.
Step 11 - App setup
Open the App, follow the user manual to connect
Floodlight Cam to your WiFi network.
OFF
ON
ON
Please switch it from [OFF] to [ON]
Customize...
AT&T 11:57 AM
Device Name
Front Door
BackYard
What would you like to name
the device?
Side
16

Connect Floodlight Cam to Your APP

1.Preparation
Please prepare the below stuff before you use it.
One smartphone or tablet PC(Mac or Windows PC is not
acceptable) with IOS 10.0 or Android 4.4 system(higher
version system is acceptable)
Wi-Fi Router
Device can only connect to 2.4Ghz Wi-Fi router.
Make sure turn on the DHCP of router, and MAC address should be off.
Distance between the router and the device should be within 3
meters during configuration.
Please don't use special character such as Chinese,
symbol to name the WiFi.
Please don't use special character such as Chinese,
symbol as the password，the WiFi and Wi-Fi
password can not be blank.
2.4G Wi-Fi
iPad iPhoneAndroid phone
Wi-Fi Router
