Tamila D1 User manual

[email protected]
TEL: [phone]
Taiwan Puritic Corp.
www.tamila-cosmedics.com
3 in 1 Desktop Ultrasonic Mist Sprayer
User Manual

• Essential oil aromatherapy (The mist isn't generated
by heating, it won’t destroy the essential oil
components).
• Auto relative humidity level sensor, with 3 level of
humidification mode.
• 4-level mist spray volume adjustment mode, and the
mist spray duration can be set from 1 hour to 15
hours.
• Air Ionizer and purifier.
• Ozone disinfection.
The copyright of this English User Manual belongs to Taiwan Puritic
Corp. Without our company's written permission, it's prohibited for
any person (or organization) to reproduce or transfer the contents of
this manual in whole or in part, in pictures or words, for the use of
others or sale .
Product SpecicationsProduct Features
3 in 1 Desktop Ultrasonic Mist SprayerProduct Name
tamila-D1Model No.
15cm (L) X 15cm (W) X 17 cm (H)Product Size
Approx.1.3 kgNet Weight
CE, FCC, RoHSCertifications
PC+ABS, PP, EPProduct Material
From 1 hour to 15 hoursMist Time Setup
Generate over 20,000,000 ions/cm3
Air Ionizer
Average of ozone concentration is
below 0.05 ppm/8 hours
Ozone Disinfection
4-level
Mist Volume
Adjustment Mode
50%~70% RH
Smart Auto
Humidity Adjustment
Total 600 ml
Water Tank
Capacity
6 W Max.
Power
Consumption
Input: 100 V~240 V-1.0A Max. 50~60 Hz
Output: +12 V 1 A, 12 W Max.
Power Source
1 2

Water tank cover
Control panel
Mist spray hole
Device body
Package Contents
Large water tank 500ml
Water pump outlet
Rubber spacers
Product specications
Humidity detection hole
Power plug
Mesh module
Power connector &
Power cord xed slot
Small water tank 100ml
Float switch
(water level
detector)
3 4

1hr
2hr
4hr
8hr
60
RH 70
50
Add water up to 80% full
1. Plug in the power adapter into the
socket, the cable can be xed in the
power cord xed slot.
3. Add Drinking Water into The Large And Small Water Tank:
Large water tank: Add water up to MAX.
Small water tank: Add water up to 80% full.
Note: Add essential oil into the small water tank.
2. Open the water tank cover.
Drinking water can be used for this product, or to add few drops of personal
preference essential oils for increasing the scent of indoor. Please follow Steps 1~12
for operating instructions.
Power/mist time setup switch
Humidity adjustment switch
e-Air Ionizer / Ozone switch
Note:
There is a layer of protective lm on the surface of
the control panel, which will be reserved on the
product when delivery. It is up to the personal
preference to keep or tear it.
Operating InstructionsControl Panel Instructions
Low-water warning light
e-Air Ionizer / Ozone display LED
e-Air Ionizer / Ozone outlet
Add water up
to MAX
Mist spray volume adjustment switch
Add essential oil into the small
water tank
5 6

4. Engage the water tank cover with the latch, and press it tightly.
5. Turn On The Power:
Continuous spray mode:
Press the power/mist time setup switch for 3 seconds, release when hearing the
"beep", power will be turned on completely after LED is lighted. When power is
turned on, both of mist spray and air ionizer/ozone function are activated at the
same time.
Intermittent spray mode (in the cycle of 15 minutes spray and pause for 5
minutes):
Press the power/mist time setup switch for 3 seconds, release when hearing the
"beep" and LED is blinking, then the intermittent spray mode is activated.
Note: When placing this product in a room without air circulation for a long period of time, and
the mist is spraying at the same direction, then the water mist will fall slowly and
accumulate into water drops.
6. Mist Time Setup:
The default mist time is one hour (after one hour the device will shut down
automatically). To change dierent mist time modes by pressing the
power/time setup switch gently (please refer to the gures below). The mist
time can be set up from 1 hour to 15 hours.
1hr
2hr
4hr
8hr
11-hrs mode
1hr
2hr
4hr
8hr
12-hrs mode
1hr
2hr
4hr
8hr
13-hrs mode
1hr
2hr
4hr
8hr
14-hrs mode
1-hr mode
1hr
2hr
4hr
8hr
2-hrs mode
1hr
2hr
4hr
8hr
3-hrs mode
1hr
2hr
4hr
8hr
4-hrs mode
1hr
2hr
4hr
8hr
5-hrs mode
1hr
2hr
4hr
8hr
6-hrs mode
1hr
2hr
4hr
8hr
7-hrs mode
1hr
2hr
4hr
8hr
8-hrs mode
1hr
2hr
4hr
8hr
9-hrs mode
1hr
2hr
4hr
8hr
10-hrs mode
1hr
2hr
4hr
8hr
1hr
2hr
4hr
8hr
15-hrs mode
7. Mist Spray Volume Adjustment:
There are 4-level of mist spray volume adjustment mode, which is indicated
from the 4 dierent size of dots. The smallest dot indicates the smallest mist
spray volume, the biggest dot indicates the largest mist spray volume.
8. RH% Adjustment:
There are 3-level of humidity adjustment (50%, 60%, 70%). Press the humidity
level adjustment switch to set up the humidity level. When the humidity level
reaches to the setup level, the mist spray will stop automatically. When all the
3-level of humidity (50%, 60%, 70%) LED lights are o, it indicates that auto
RH% is deactivated.
9. Turn O The Air Ionizer / Ozone Function:
When the device's power is turned on, the air ionizer/ozone is turned on at the
same time. To turn o the air ionizer/ozone by pressing the air ionizer/ozone
switch for 3 seconds, release after hearing the "beep", then the air ionizer/o-
zone function is turned o.
Smallest Medium General Largest
50% RH 60% RH 70% RH
RH% is deactivated
60
RH 7050
60
RH 7050
60
RH 7050
60
RH 7050
Press it tightly
60
RH 7050
Press
3 seconds
Beep～～～
7 8

10. Turn On the Air Ionizer / Ozone Function And Deactivate The Mist Spray
Function:
When the power of the device is turned o, press the air ionizer / ozone
switch for 3 seconds, release after hearing the "beep", then the air ionizer /
ozone function is activated.
11. Low-water Level Warning Light:
When the water level is too low, the low-water level warning light will be
lighted and the device will be shut down automatically. Please follow Step 3
to add some water, and then turn on the power again.
12. Turn O The Power:
Under the continuous spray mode:
Press the power/time setup swtich for 3 seconds, release after hearing the
"beep", then the spray mode swifts to intermittent spray mode. Press again
the power/time setup swtich for 3 seconds, release after hearing the "beep",
then the power is turned o.
Under the intermittent spray mode:
Press the power/time setup swtich for 3 seconds, release after hearing the
"beep", then the power is turned o.
Please follow Steps 1~14 for regular cleaning. If there is no essential oil to be
added into the water tank, please skip Steps 10 & 11.
If the device is not in use for a long period of time or the mesh module is blocked,
please add drinking water, turn on the power to activate mist spray function, and
follow the cleaning Steps 1~14. If the mist still cannot be sprayed out of the
device, please contact the dealer for assistance.
1. Please refer to the Operating Instructions Steps 1 & 2.
2. Pour out the remained drinking water inside of the large & small water
tanks.
3. Add medicinal alcohol into the small water tank until it's 80% full.
4. Engage the water tank cover with the latch, and press it tightly.
5. Press the power/mist time setup switch to activate the mist spray function,
and adjust the mist spray volume to the largest.
6. The mesh module and its residue will be cleaned throught the mist spray
function (Keep away from re and other ignition sources during spraying).
7. When the low-water warning light is lighted, it indicates that the cleaning is
done (Approx. 20 minutes).
Cleaning Instructions
Largest
1hr
2hr
4hr
8hr
Press
3 seconds
Beep～～～
60
RH 7050
60
RH 7050
Press
3 seconds
Beep～～～
Note:
(1) If the switch doesn't beep or the LED light is not lighted when pressing the switch, please
contact the dealer for repair.
(2) Do not place the device on the surface where it is dangerous, ammable, or slopy, in
order to avoid any danger.
(3) Keep the sharp object away from the mist spray hole, in order to avoid causing any
scratch or damage to the mist spray module.
910

8. After cleaning is done, turn o the power, and remove the water tank from the
device.
Note: In order to avoid water mist permeating into the bottom of the device, the water tank
and the device body are designed to be xed together tightly. Therefore, when
removing the water tank, it is kind of tight.
9. Pour out the remained medicinal alcohol from the water tank, wipe the water
tank and the bottom of the device with tissue paper.
Note:
(1) Please do not soak the water tank in water directly, due to there are motor and
connector at the bottom of water tank.
(2) The water tank and the device body are designed to be seperated, after the mist is
being spraying for a long period of time, some of the mist may accumulate into water
drop inside of the device, this will not aect the internal circuit. Please use tissue paper
to wipe the interal part of the device.
10 . Please dip the tissue paper with alcohol to clean the surface of the oat
switch (water level detector).
Note: When using the essential oil for a long period of time, some essential oil will stain the
surface of the oat switch, it may cause some dirt and stickiness, as well as the
abnormity of oat switch for not being able to oat after water is added up to the
maximum.
11. Please dip the tissue paper with alcohol to clean the surface of the small
water tank.
Note: Some essential oils may content additivies, and the additivies may have dierent
colors; therefore, after using those essential oils with the device for a long period of
time, the small tank will be dyed with colors. It will not aect the quality of the
small water tank.
12. Please dip the cotton bud with alcohol and wipe
along the edge of mesh module gently.
13. After cleaning is done, please plug in the water tank into the device body.
14. Engage the water tank cover with the latch, and press it tightly, then all cleaning
steps are completed.
Note: The device is not waterproof, do not rinse it with water directly when cleaning.
Clean with cotton bud and alcohol
Push down
Plug in
Pull up Pull out
Press it tightly
Engage the cover at
a 45° angle
11 12

Product name
Model no.
Date of purchase
Dealer’s address and phone number(company stamp)
3 in 1 Desktop Ultrasonic Mist Sprayer
tamila-D1
Warranty Coverage
Each of our company's product has one year warranty in its materials and
workmanship from date of purchase. If product fails under proper use, and after
judgment it is the problem of the product itself, our company will bear the
responsibilities of repair within the warranty period.
Warranty Period
Warranty period for the main device is one year.
Warranty period for the mesh module is 6 months.
Warranty Acknowledgement
1. Warranty card or proof of purchase
To ensure customer's rights, please ask the dealers to ll in the product model,
serial number, and date of purchase on the warranty card, as well as to stamp
the dealer's stamp on it. Please keep the warranty card or the relevant proof of
purchase (such as invoice or sales slip).
2. Direct identication
If consumers are unable to present with warranty card or proof of purchase, the
eective date of warranty will be added 2 months from the date of manufac-
ture which shows on the serial number of product lable.
Note: If the date of manufacture is Jan. 2017, then the warranty period is good until end of
Mar. 2018.
Product Warranty
Example:
Date of
manufacture
13 14
