Tandy CCR-83 User manual

Cat. No.
26-1384
Computer Cassette Recorder
CCR-83
TANDY'

The FCC Wants You to Know
This equipment generates and uses radio frequency energy. If not installed and used properly,
that is in strict accordance with the manufacturer's instructions, it may cause interference to
radio and television reception.
It has been type tested and found to comply with the limits for a Class B computing device
in accordance with the specifications in Subpart J of Part 1501 FCC Rules, which are designed
to provide reasonable protection against such interference in a residential installation.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the in-
terference by one or more of the following measures:
•
Reorient the receiving antenna
•
Relocate the computer with respect to the receiver
•
Move the computer away from the receiver
•
Plug the computer into a different outlet so that computer and receiver are on different
branch circuits.
Warning
This equipment has been certified to comply with the limits for a Class B computing device,
pursuant to Subpart J of Part 15 of FCC Rules. Only peripherals (computer inputiouput
devices, terminals, printers, etc.) certified to comply with the Class B limits may be attached to
this computer. Operation with non-certified peripherals is likely to result in interference to
radio and TV reception.
Notice: You
must use a
shielded cable when connecting this device

2/86
Computer Cassette Recorder CCR-83 Operation Manual:
@ 1988 Tandy Corporation, Fort Worth, Texas 76102 U.S.A.
All Rights Reserved.
Reproduction or use of any portion of this manual, without express written
permission from Tandy Corporation, is prohibited. While reasonable efforts have
been made in the preparation of this manual to assure its accuracy, Tandy
Corporation assumes no liability resulting from any errors in or omissions from
this manual, or from the use of the information contained herein.
10987654321
TERMS AND CONDITIONS OF SALE AND LICENSE OF TANDY COMPUTER EQUIPMENT AND
SOFTWARE PURCHASED FROM RADIO SHACK COMPANY-OWNED COMPUTER CENTERS, RETAIL
STORES AND RADIO SHACK FRANCHISEES OR
DEALERS AT THEIR AUTHORIZED LOCATIONS
USA LIMITED WARRANTY
I. CUSTOMER OBLIGATIONS
A


CUSTOMER assumes full responsibility that this computer hardware purchased (the "Equipment), and any
copies of software included with the Equipment or licensed separately (the "Software") meets the specifications,
capacity, capabilities, versatility, and other requirements of CUSTOMER.
B. CUSTOMER assumes full responsibility for the condition and effectiveness of the operating environment in which
the Equipment and Software are to function. and for its installation.
If.
 LIMITED WARRANTIES AND CONDITIONS OF SALE
A.
For a period of ninety (90) calendar days from the date of
the Radio Shack sales document received upon
purchase of the Equipment. RADIO SHACK warrants to the original CUSTOMER that the Equipment and the
medium upon which the Software is stored is free from manufacturing detects
This warranty Is only applicable
Ii purchases of Tandy Equipment by the original customer from Radio Shock company-owned computer
centers, retail stores, and Radio Shack franchisees and dealers If their authorized locations.
The warranty is
void if the Equipment or Software has been subjected to improper or abnormal use. If a
manufacturing detect is
discovered during the stated warranty period, the detective Equipment must be returned to a Radio Shack
Computer Center, a Radio Shack retail store, a participating Radio Shack franchisee or a participating Radio Shack
dealer for repair, along with a copy of the sales document or lease agreement. The original CUSTOMER'S sole and
exclusive remedy in the event of a detect is limited to the correction of the defect by repair, replacement, or
refund of the
purchase
price, at RADIO SHACK'S election and sole expense.
RADIO SHACK has no obligation to
replace or repair expendable items.
B.
RADIO SHACK makes no warranty as to the design, capability, capacity, or suitability for use of the Software,
except as provided in this paragraph. Software is licensed on an "AS IS" basis, without warranty. The original
CUSTOMER'S exclusive remedy, in the event of a Software manufacturing defect, is its repair or replacement
within thirty (30) caiendar days of the date of the Radio Shack sales document received upon license of the
Software. The defective Software shall be returned to a Radio Shack Computer Center, a Radio Shack retail store.
a participating Radio Shack franchisee or Radio Shack dealer along with the sales document.
C.
Except as provided herein no employee, agent, franchisee, dealer or other person is authorized to give any
warranties of any nature on behalf of RADIO SHACK.
D. EXCEPT AS PROVIDED HEREIN, RADIO SHACK MAKES NO EXPRESS WARRANTIES, AND ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE IS LIMITED IN ITS DURATION
TO THE DURATION OF THE WRITTEN LIMITED WARRANTIES SET FORTH HEREIN,
E.
Some states do not allow limitations on how long an implied warranty lasts, so the above limitation(s) may not
apply to CUSTOMER.
III. LIMITATION OF LIABILITY
A
EXCEPT AS PROVIDED HEREIN, RADIO SHACK SHALL HAVE NO LIABILITY OR RESPONSIBILITY TO CUSTOMER
OR ANY OTHER PERSON OR ENTITY WITH RESPECT TO ANY LIABILITY, LOSS OR DAMAGE CAUSED OR
ALLEGED TO BE CAUSED DIRECTLY OR INDIRECTLY BY "EQUIPMENT" OR "SOFTWARE" SOLD, LEASED,
LICENSED OR FURNISHED BY RADIO SHACK, INCLUDING. BUT NOT LIMITED TO, ANY INTERRUPTION OE
SERVICE, LOSS OF BUSINESS OR ANTICIPATORY PROFITS OR CONSEQUENTIAL DAMAGES RESULTING FROM
THE USE OR OPERATION OF THE "EQUIPMENT" OR "SOFTWARE. - IN NO EVENT SHALL RADIO SHACK BE
LIABLE FOR LOSS OF PROFITS, OR ANY INDIRECT, SPECIAL, OR CONSEQUENTIAL DAMAGES ARISING OUT OF
ANY BREACH OF THIS WARRANTY OR IN ANY MANNER ARISING OUT OF OR CONNECTED WITH THE SALE,
LEASE, LICENSE, USE OR ANTICIPATED USE OF THE "EQUIPMENT" OR
- SOFTWARE."
NOTWITHSTANDING THE ABOVE LIMITATIONS AND WARRANTIES, RADIO SHACK'S LIABILITY HEREUNDER FOR
DAMAGES INCURRED BY CUSTOMER OR OTHERS SHALL NOT EXCEED THE AMOUNT PAID BY CUSTOMER FOR
THE PARTICULAR "EQUIPMENT" OR "SOFTWARE" INVOLVED.
B.
RADIO SHACK shall not be liable for any damages caused by delay in delivering or furnishing Equipment andur
Software.
C.
No action arising out of any claimed breach of this Warranty or transactions under this Warranty may be brought
more than two (2) years after the cause of action has accrued or more than four (4) years after the date of the
Radio Shack sales document for the Equipment or Software, whichever first occurs.
D.
Some states do not allow the limitation or exclusion of incidental or consequential damages. so
the above
limitation(s) or exclusion(s) may not apply to CUSTOMER.
IV. SOFTWARE LICENSE
RADIO SHACK grants to CUSTOMER a non-exclusive, paid-up license to use the TANDY Software on
one computer.
subject to the following provisions:
A.
Except as otherwise provided in this Software License, applicable copyright laws shall apply to the Software.
B.
Title to the medium on which the Software is recorded (cassette and/or diskette) or stored (ROM) is transferred to
CUSTOMER, but not title to the Software.
C.
CUSTOMER may use Software on a multiuser or network system only if either, the Software is expressly labeled
to be for use on a multiuser or network system, or one copy of this software is purchased for each node or
terminal on which Software is to be used simultaneously.
D.
CUSTOMER shall not use, make, manufacture, or reproduce copies of Software except for use on one
computer
and as is specifically provided in this Software License. Customer is expressly
prohibited from disassembling the
Software.
E.
CUSTOMER is permitted to make additional copies of the Software
only for backup or archival
purposes or if
additional copies are required in the operation of
one
computer with the Software, but only to the extent the
Software allows a backup copy to be made. However. for TRSDOS Software, CUSTOMER is permitted to make a
limited number of additional copies for CUSTOMER'S own use.
F.
CUSTOMER may resell or distribute unmodified copies of the Software provided CUSTOMER has
purchased one
copy of the Software for each one sold or distributed. The provisions of this
Software License shall also be
applicable to third parties receiving copies of the Software from CUSTOMER.
G.
All copyright notices shall be retained on all copies of the Software.
V. APPLICABILITY OF WARRANTY
A.
The terms and conditions of this Warranty are applicable as between RADIO SHACK and CUSTOMER to either a
sale of the Equipment and/or Software License to CUSTOMER or to a transaction whereby Radio Shack sells or
conveys such Equipment to a third party for lease to CUSTOMER.
B.
The limitations of liability and Warranty provisions herein shall inure to the benefit cd
RADIO SHACK, the author,
owner and or licensor of the Software and any manufacturer of the Equipment sold by Radio Shack.
VI. STATE LAW RIGHTS
The warranties granted herein give the original CUSTOMER specific legal rights, and the
original CUSTOMER may
have other rights which vary from state to state. 
4/87

CAUTION
RISE OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR
BACK). NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
WARNING: To reduce the risk of fire or electric
shock, do not expose this appliance to rain or
moisture.
The lightning flash with arrowhead
symbol within an equilateral trian-
gle is intended to alert the user to
the presence of uninsulated "dan-
gerous voltage" within the product's
enclosure that may be of sufficient
magnitude to constitute a risk of
electric shock to persons.
The exclamation point within an equi-
lateral triangle is intended to alert
the user to the presence of impor-
tant operating and maintenance
(servicing) instructions in the litera-
ture accompanying the appliance.
FEATURES
Computer Controlled
—Allows the computer to start or stop the tape to load or
save programs and data.
CUE and REVIEW Functions—
Enable instant fast forward or rewind while in
either Record or Play mode independent of the computer. Let you quickly locate
desired portion of the tape.
Automatic Shut-Off Mechanism —
Automatically shuts off the recorder when
the end of the tape is reached while in the Play or Record mode and/or while
loading or saving programs and data files. This saves wear and strain on the unit,
the tape, and the batteries.
Built-in A.L.C. (Automatic Level Control) Circuit —
Lets you automatically
obtain a perfect recording level for both recording music and saving programs/
data — no need to adjust the volume.
Tape Counter —
Helps you find a specific section of the tape quickly.
Mechanical Pause—
Lets you stop the tape instantly while in Record or Play
mode.
Convenient 3-Way Power—Can be used with AC, batteries, or an external
source of 6 volts DC.
RECORD/BATTERY Indicator — Flickers when the recorder is at peak record-
ing levels, and lights up when the batteries need to be replaced.
Note: The RECORD/BATTERY indicator flashes briefly as you press function
buttons. This is normal and does not mean the batteries are weak. If the indicator
stays on, the batteries need to be replaced.

CONTROLS AND CONNECTIONS
PREPARATION
1. Cassette Compartment
2.
AC Line Cord Receptacle
3.
DC 6V Jack
4.
EAR (earphone) Jack
5. AUX (auxiliary) Input Jack
6.
REM/MIC (remote/microphone) Jack
7. VOLUME Control
8.
RECORD /CSAVE Button
9. PLAY/CLOAD Button
10.
REWIND/REVIEW Button
11.
FAST-F (fast forward)/CUE Button
12.
STOP/EJECT Button
13.
PAUSE Button
14. Tape Counter
15.
RECORD/BATTERY Indicator
A. Tape output plug (to EAR Jack)
B. Tape input plug (to AUX Input Jack)
C. Tape control plug (to REM Jack)
D. Computer cassette plug (to TAPE output on computer)
2
CHOOSING A POWER SUPPLY
You can operate the recorder using any of these power sources:
•
Household AC (with supplied AC power cord)
•
Four C batteries
•
12V automotive battery (with an optional DC adapter)
Note:
We recommend that you always use AC power when using the CCR-83
with a computer.
Operating on AC Power
Connect one end of the AC power cord to the recorder's AC POWER jack, and
plug the other end into a standard AC outlet. Connecting the cord to the unit
automatically disconnects the internal battery circuit. Never leave the cord
plugged into an AC outlet when it is not connected to the recorder.
Installing Batteries
Your recorder requires four Size C batteries. We recommend Radio Shack Cat.
No. 23-581 or 23-551. To load the batteries, turn the recorder over and open the
battery compartment cover. Insert the batteries as indicated in the compartment;
then, close the cover.
Caution:
Weak batteries, even "leak-proof" types, may swell and leak. To avoid
damage to the recorder, replace weak batteries. If you are going to store the
recorder for a month or longer, remove the batteries.
3

Full Reel
On This Side
Using an Automotive Battery
If your vehicle has a 12-volt, negative ground electrical system, you can power
your recorder from your vehicle battery. Use our DC auto adapter (Cat. No.
14-844D). Set the switch on the adapter to the 6V position and connect one end
to the recorder's DC 6V jack. Connect the other end of the adapter to your
vehicle's lighter socket. When the adapter is connected, the internal battery
circuit is automatically disconnected.
Caution:
If you use another adapter, you must be sure that the voltage is correct
(6V DC only) and that the center terminal of the connector is negative. Failure to
observe these two vital points might result in damage to your recorder and/or
adapter.
INSERTING THE TAPE
CONNECTING TO THE COMPUTER
A computer connection cable is supplied with your recorder. However, some
computers require their own connection cables. Refer to your computer owner's
manual.
Note:
Some connecting cables have plugs that are too long to fit into the jacks on
the recorder. When using a connection cable other than the one supplied with
your recorder, insert the plug until you feel a slight catch. Do not try to force the
plug all the way in.
1.
Connect the output plug (black) to the recorder's EAR jack.
EAR
2. Connect the input plug (larger gray) to the recorder's AUX or MIC. See your
computer owner's manual.
Before inserting or removing the cassette tape, be sure to press the STOP/EJECT
button to cancel any functions that may have been previously selected. Open the
cassette lid by pressing the STOP/EJECT button again. Hold the cassette with
the open side toward you and insert it into the opening so that the full reel is on
your left; then, close the lid. After you have finished recording or playing one side
of the cassette, open the lid, turn the cassette over and reinsert it. You are now
ready to record or play the second side.
AUX
0
3.
If your computer has a remote control function, connect the control plug
(smaller gray) to the recorder's REM.
REM
4.
Connect the computer cassette plug (opposite the three plugs) to the cassette
tape output on the computer.
MC
or

OPERATION WITH THE COMPUTER
LOADING A PROGRAM OR DATA FILE FROM TAPE
1.
Set the VOLUME control to the correct level for your computer. See the
computer owner's manual for details. If you have trouble loading programs or
inputting data, try adjusting the volume.
VOLUME
MIN - MAX
,
IIIISSION1111111.,
2. Be sure the tape is positioned to the point just before the beginning of
recorded programs or data. Use the tape counter or CUE or REVIEW functions
to locate the correct position.
3.
If your computer does not have a remote control function, press PAUSE before
the computer is ready to load the program or input the data. If your computer
does have a remote control function, proceed to Step 4.
4.
Press PLAY/CLOAD. On the computer keyboard, type CLOAD and press
ENTER (or equivalent command on your computer). If you pressed PAUSE in
Step 3, press it again to release it. The tape will begin moving and programs
or data will be transferred to the computer.
C LOAD
(ENTER)
5.
If your computer has a remote control function, the tape will stop
automatically when operation is complete. If your computer does not have a
remote control function, listen to the sound of the data on the moving tape.
(Some computers have a command that enables you to hear the data sounds
through the monitor speaker. Color Computers use the AUDIO ON
command.) When the sound stops, press STOP/EJECT.
Caution:
Do not leave the RECORD and/or PLAY buttons engaged for a long
period of time. Doing so can cause a flat spot on the drive wheel, resulting in
sound distortion.
SAVING A PROGRAM OR DATA FILE ON TAPE
1. Insert a blank (new or bulk-erased) tape, and press REWIND/REVIEW to
rewind the tape to the beginning. If you use a tape with a leader, be sure to
press PLAY for a few seconds to advance the tape past the leader.
For maximum protection of digital computer data, use cassettes that are
specially certified for computer use (eg., Cat. No. 26-301, 26-302 or 26-308).
2. If your computer does not have a remote control function, press PAUSE before
the computer is ready to save the program or the data.
3.
Press RECORD. (When RECORD/CSAVE is pressed, the PLAY button is
pressed automatically.) If you pressed PAUSE in step 2, press it again to
release the pause mode. Then, type CSAVE on the computer keyboard and
press ENTER (or the equivalent key on your computer). The tape will begin
moving and the programs or data will be saved onto the tape.
CSAVE (ENTER)
While the recorder is receiving data, the RECORD/BATTERY indicator will
flicker. There is no need to adjust the VOLUME; the recorder does that
automatically during the save operation.
0 0 0 0 0 0 0 0 0 0 0 0 0
I /
••=11. 0
RECORD/BATTERY
 / \ 
4.
When the save operation is complete, a computer with a remote control
function stops the tape automatically. If your computer does not have a remote
control function, press STOP/EJECT at the end of the save operation.

Notes:
•
When you are saving data on a cassette tape with a computer that does not
have a remote control function, we recommend that you write a program that
displays the end of data transfer on the screen. Then, you can manually stop
the recorder without much loss of the tape.
•
It is possible to record two or more programs or data files on one side of a tape.
However, this takes a little extra care and attention on your part. First, rewind
the tape and reset the tape counter. Then keep a written record of the counter
reading where each program or data file starts.
•
Keep the recorder as far as possible from your monitor or television. This
prevents interference that could cause I/O errors.
•
When you are ready to load in a particular program or date file, rewind the tape,
reset the counter, and then fast-forward or rewind to position the tape just
ahead of the desired tape section. Remember, you can fast-forward or rewind
manually without disconnecting the remote jack.
OTHER USES FOR THE RECORDER
PLAYING PRERECORDED TAPES
1.
Insert the prerecorded cassette tape.
2.
Rewind the tape by pressing REWIND/REVIEW.
3.
Press STOP/EJECT when you reach the section of the tape you wish to play.
4.
Press PLAY/CLOAD. Adjust the VOLUME control to a comfortable setting.
5.
To stop playback, press STOP/EJECT. When the tape reaches the end, the unit
automatically shuts off.
6.
When you want to listen privately, plug an earphone into the EAR jack. Or, for
greater fidelity, you can use an external speaker which has an impedance of
8-16 ohms. Connect the speaker via a patch cord plugged into the EAR jack.
(Visit your local Radio Shack store for all accessories.)
To advance the tape rapidly, press FAST-F/CUE. When you reach the approximate
point you want, press STOP/EJECT and then press PLAY/CLOAD.
To rewind the tape rapidly, press REWIND/REVIEW. When you reach the
approximate point you want, press STOP/EJECT and then press PLAY.
In each case, always press STOP/EJECT before pressing PLAY/CLOAD. Abrupt
change in tape speed or direction can damage the tape. When you press and hold
FAST-F/CUE or REWIND/REVIEW while the PLAY button is engaged, either in
the Play or Record mode, the tape will move rapidly and, at the same time, you
can hear the recorded sound in a high-pitched tone. (The RECORD/CSAVE
button is released if the unit is in the Record mode.) This helps you to locate the
end or beginning of a particular section of the tape. Release FAST-F/CUE or
REWIND/REVIEW, and normal playback is resumed.
REWIND
ERMA.
FAST-F

 C.
TAPE TIPS
PAUSE provides a convenient method of starting and stopping the recorder
whenever it is playing or recording. It does not function in Fast-forward or
Rewind mode. To stop tape movement, press PAUSE; press PAUSE once more to
restart tape motion.
PAUSE
RECORDING WITH AN EXTERNAL MICROPHONE
Connect an optional external microphone to the MIC jack. To begin recording,
press RECORD /CSAVE. To stop recording, press STOP/EJECT. If the
microphone you are using has an ON/OFF switch for remote control, connect its
smaller remote operation plug to the REM jack. Then, you can turn the recorder
on and off electrically with the switch on your mic. However, when the recording
session is finished, be sure to press STOP/EJECT to disengage the mechanism.
RECORDING FROM A RADIO OR PHONOGRAPH
1. Connect the external sound source to the recorder's AUX jack using a
suitable patch cord with the proper plug.
2. Set the sound source's volume control to a normal listening level. The
recorder sets its recording level automatically. The recorder's VOLUME control
will have no effect on the sound.
3. Press RECORD/CSAVE .
4. To stop recording, press STOP/EJECT.
Note: When both the MIC and AUX jacks are connected, only MIC is functional.
ERASING TAPES
Each time you make a recording, any previous recording on the tape is
automatically erased; thus, the tape may be used for new recordings as many
times as you wish. For best results, we recommend that computer tapes be bulk
erased before reusing them. Use our Magnetic Bulk Tape Eraser (Cat. No. 44-
232). This will assure that all traces of previously recorded data are removed and
will not interfere with the new data.
Caution:
The bulk tape eraser erases both sides of a cassette. If you want to
erase only one side, disconnect the plugs from the MIC and/or AUX jacks and
press RECORD.
ACCIDENTAL ERASURE PREVENTION
Cassettes have small plastic tabs on one edge. To prevent erasure of a previous
recording, break off the plastic tab with a screwdriver. There is a tab for each
side; be sure you break off the correct tab. (See Figure A.)
If you decide you want to record on the cassette after you have broken off the
tabs, put a piece of tape over the hole where you broke off each tab, as shown in
Figure B.
Figure A

Figure B
Caution:
If you have a cassette without tabs, do not try to force the RECORD
button down. Doing so can damage part of the mechanism.

RE.... PEAT
— 03MERD — CIMED
5 T.T .
o fTENOTJO fOOT-S EJECT PouST
CARE AND MAINTENANCE
Open the cassette lid, press the PLAY/CLOAD button, exposing the erase and
record heads and the rubber drive wheel. Clean these points, using a cotton swab
moistened with denatured alcohol (not rubbing alcohol) or with a special head
cleaning fluid. (Your local Radio Shack store has these items.) To insure good
recording and playback results, clean after the first 6 hours of operation (and
every 6-8 hours of operation after that). After cleaning, be sure to press the
STOP/EJECT button, so that these parts may return to their normal operating
position. For easy cleaning, we recommend our cassette Head Cleaner Tape (Cat.
No. 44-1160).
It is a good idea to periodically demagnetize the tape heads, too. Use one of our
tape head demagnetizers. If you use the longer, thinner tapes (C-90 or C-120), it
is absolutely vital that you keep your recorder clean. Failure to do so can result in
poor tape handling, malfunction auto-stop or serious tape wrap-ups. Clean the
tape handling parts well and often.
Use the tape recorder and cassettes in normal temperature and humidity
environments.
Your CCR-83 is an example of superior design and craftsmanship. The following
suggestions will help you care for your new cassette recorder so that you can
enjoy it for years.
Keep the cassette recorder dry. If it does get wet, wipe it dry
immediately. Liquids might contain minerals that can corrode
the electronic circuits.
Use and store the cassette recorder only in normal temperature
environments. High temperatures can shorten the life of
electronic devices, damage batteries, and distort or melt plastic
parts.
Handle the cassette recorder gently and carefully. Dropping it
can damage circuit boards and cases and can cause the cassette
recorder to work improperly.
Keep the cassette recorder away from dust and dirt which can
cause premature wear of parts.
Wipe the cassette recorder with a dampened cloth occasionally
to keep it looking new. Do not use harsh chemicals, cleaning
solvents, or strong detergents to clean the unit.
Keep screwdrivers, other metal objects, and magnets away from the tape heads.
Use only fresh batteries of the recommended size and type.
Always remove old or weak batteries. They can leak chemicals
that destroy electronic circuits.
Modifying or tampering with the cassette recorder's internal components can
cause a malfunction and might invalidate the product's warranty. If your cassette
recorder is not performing as it should, take it to your local Radio Shack store.
Our personnel can assist you and arrange for service if needed.
12
13

0 3 L
14 0
 g
--X14
-Vht
r
0
11 8
.
r
01,001.
010
—NSA+
-
2
N rol-
•
12x9 c• — •
>
0.
1•141Y0
1 ...0.0.0.0,
01.130
;0.
^
14 • 0
4Z:
14.-1
0-
:31
L Z 0 0
003
•
n
•
SPECIFICATIONS
SCHEMATIC DIAGRAM
Tape System:
Tape Speed:
Wow and Flutter (VVRMS):
Signal-to-Noise Ratio:
Erase System:
Recording System:
ALC delay time at Recording:
Turn on time at Play:
Power Requirement:
Dimensions (H x W x D):
Weight:
Accessories:
2-track monaural
1 
inch/sec. (4.75 cm/sec.)
0.2%
45dB (DC)/40 dB (AC)
DC bias Erasing
AC bias
0.1 sec.
0.1 sec.
AC 120V60 Hz, DC 6V
(four 1.5V "C" batteries or via optional
DC adapter)
9i3x5 - 1 - x14 - inch
(250 x 146 x 49 mm)
2.6 lbs. (1.2 kg)
AC power cord, computer cable
1TA NI
=
.a  *
o
n"P
4zi
d
15
1 4

SERVICE POLICY
Radio Shack's nationwide network
of service facilities provides quick,
convenient, and reliable repair
services for all of its computer
products, in most instances.
Warranty service will be performed
in accordance with Radio Shack's
Limited Warranty. Non-warranty
service will be provided at
reasonable parts and labor costs.
6 86
RADIO SHACK
A Division of Tandy Corporation
Fort Worth, Texas 76102
8A8 
Printed in Hong Kong
811022030A
