SERVICE MANUAL
DATA
CSD-TD26
CSD-TD27
CSD-TD28
U
U
U
SIMPLE
S/M Code No. 09-011-443-0T1
• Replace this Service manual with “Revision Publishing” when it is issued.
COMPACT DISC STEREO
RADIO CASSETTE RECORDER BASIC TAPE MECHANISM : ZZM-1 AR5NC BASIC CD MECHANISM : DA11T3C

 2 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
! O ACCESSORY 87-A80-109-010 1C AC CORD,HK7281 BLK U USC CSD-TD26
O APPEARANCE 8B-CDA-005-010 -- CHAS,CD USC CSD-TD26
O APPEARANCE 8B-CDA-007-010 -- HANDL,ARM USC CSD-TD26
O APPEARANCE 8B-CDA-009-010 -- WINDOW,CASS USC CSD-TD26
APPEARANCE 8B-CDA-027-010 -- GRILLE,SPKR L USC CSD-TD26
APPEARANCE 8B-CDA-028-010 -- GRILLE,SPKR R USC CSD-TD26
O APPEARANCE 8B-CDL-008-010 -- PANEL,TOP USC CSD-TD26
APPEARANCE 8B-CHA-013-010 -- CABI,FRONT U USC CSD-TD26
O APPEARANCE 8B-CHA-014-010 -- CABI ASSY,FRONT U USC CSD-TD26
O APPEARANCE 8B-CHA-015-010 -- WINDOW,DISP U USC CSD-TD26
O APPEARANCE * 8B-CDA-003-010 -- LID,CASS USC CSD-TD26
O APPEARANCE * 8B-CDA-004-010 -- LID,BATT USC CSD-TD26
O APPEARANCE * 8B-CDA-006-010 -- LID,CD USC CSD-TD26
O APPEARANCE * 8B-CDA-010-010 -- LID,HANDL USC CSD-TD26
O APPEARANCE * 8B-CHA-003-010 -- CABI,REAR USC CSD-TD26
! O CD M8-ZZK-E90-070 2Y DA11T3C USC CSD-TD26
O CD C 0401 87-010-403-080 0E CAP,E 3.3-50 M 11L SME USC CSD-TD26
O CD C 0402 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O CD C 0403 87-010-263-080 0E CAP,E 100-10 M 11L SME USC CSD-TD26
O CD C 0404 87-010-248-080 0E CAP,E 220-10 M 11L SME USC CSD-TD26
O CD C 0405 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O CD C 0406 87-010-374-080 0E CAP,E 47-10 M 11L SME USC CSD-TD26
O CD C 0407 87-018-131-080 0E CAP,TC U 1000P-50 K B UP050 USC CSD-TD26
O CD C 0408 87-010-198-080 0E C-CAP,S 0.022-25 K B C2012 USC CSD-TD26
O CD C 0409 87-010-248-080 0E CAP,E 220-10 M 11L SME USC CSD-TD26
O CD C 0410 87-010-263-080 0E CAP,E 100-10 M 11L SME USC CSD-TD26
O CD C 0411 87-A11-177-080 0E C-CAP,S 0.15-16 K B USC CSD-TD26
O CD C 0412 87-010-401-080 0E CAP,E 1-50 M 11L SME USC CSD-TD26
O CD C 0413 87-016-369-080 0E C-CAP,S 0.033-25 K B GRM USC CSD-TD26
O CD C 0414 87-010-405-080 0E CAP,E 10-50 M 11L SME USC CSD-TD26
O CD C 0416 87-010-545-080 0E CAP,E 0.22-50 M 11L SME USC CSD-TD26
O CD C 0417 87-012-157-080 0E C-CAP,S 330P-50 J CH GRM USC CSD-TD26
O CD C 0418 87-010-213-080 0E C-CAP,S 0.015-25 K B GRM USC CSD-TD26
O CD C 0419 87-A11-608-080 0E C-CAP,S 0.33-25 K B USC CSD-TD26
O CD C 0420 87-016-369-080 0E C-CAP,S 0.033-25 K B GRM USC CSD-TD26
O CD C 0421 87-A11-177-080 0E C-CAP,S 0.15-16 K B USC CSD-TD26
O CD C 0422 87-010-184-080 0E C-CAP,S 3300P-50 K B C2012 USC CSD-TD26
O CD C 0423 87-010-992-080 0E C-CAP,S 0.047-25 K B MK212 USC CSD-TD26
O CD C 0424 87-A11-606-080 0E C-CAP,S 0.22-25 K B USC CSD-TD26
O CD C 0425 87-018-129-080 0E CAP,TC U 680P-50 K B UP050 USC CSD-TD26
O CD C 0426 87-A11-608-080 0E C-CAP,S 0.33-25 K B USC CSD-TD26
O CD C 0428 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O CD C 0429 87-010-186-080 0E C-CAP,S 4700P-50 K B C2012 USC CSD-TD26
O CD C 0430 87-012-156-080 0E C-CAP,S 220P-50 J CH GRM USC CSD-TD26
O CD C 0431 87-010-545-080 0E CAP,E 0.22-50 M 11L SME USC CSD-TD26
O CD C 0432 87-010-374-080 0E CAP,E 47-10 M 11L SME USC CSD-TD26
O CD C 0433 87-010-401-080 0E CAP,E 1-50 M 11L SME USC CSD-TD26
O CD C 0434 87-010-184-080 0E C-CAP,S 3300P-50 K B C2012 USC CSD-TD26
O CD C 0435 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O CD C 0436 87-010-374-080 0E CAP,E 47-10 M 11L SME USC CSD-TD26
O CD C 0437 87-010-404-080 0E CAP,E 4.7-50 M 11L SME USC CSD-TD26
O CD C 0438 87-016-669-080 0E C-CAP,S 0.1-25 K B USC CSD-TD26
O CD C 0439 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USC CSD-TD26
O CD C 0440 87-018-139-080 0E CAP,TC U 1P-50 M CH UP050 USC CSD-TD26
O CD C 0441 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O CD C 0442 87-018-109-080 0E CAP,TC U 22P-50 J SL UP050 USC CSD-TD26
O CD C 0445 87-012-368-080 0E C-CAP,S 0.1-50 Z F USC CSD-TD26
O CD C 0446 87-012-368-080 0E C-CAP,S 0.1-50 Z F USC CSD-TD26
O CD C 0447 87-012-368-080 0E C-CAP,S 0.1-50 Z F USC CSD-TD26
O CD C 0448 87-010-315-080 0E C-CAP,S 27P-50 J CH GRM USC CSD-TD26
O CD C 0451 87-012-156-080 0E C-CAP,S 220P-50 J CH GRM USC CSD-TD26
O CD C 0455 87-010-247-080 0E CAP,E 100-50 M SME USC CSD-TD26
O CD C 0457 87-010-312-080 0E C-CAP,S 15P-50 J CH GRM USC CSD-TD26
O CD C 0458 87-010-312-080 0E C-CAP,S 15P-50 J CH GRM USC CSD-TD26
O CD C 0459 87-010-263-080 0E CAP,E 100-10 M 11L SME USC CSD-TD26
O CD C 0460 87-015-819-080 0E C-CAP, 0.01-50 K B C3216 USC CSD-TD26
O CD C 0461 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O CD C 0462 87-010-248-080 0E CAP,E 220-10 M 11L SME USC CSD-TD26
O CD C 0463 87-A11-132-080 0E CAP,TC U 0.01-50 K B USC CSD-TD26
O CD C 0465 87-010-404-080 0E CAP,E 4.7-50 M 11L SME USC CSD-TD26

 3 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O CD C 0466 87-012-368-080 0E C-CAP,S 0.1-50 Z F USC CSD-TD26
O CD C 0467 87-010-263-080 0E CAP,E 100-10 M 11L SME USC CSD-TD26
O CD C 0469 87-012-154-080 0E C-CAP,S 150P-50 J CH GRM USC CSD-TD26
O CD C 0471 87-018-209-080 0E CAP,TC U 0.1-50 Z F UP050 USC CSD-TD26
O CD C 0472 87-015-785-080 0E C-CAP, 0.1-25 Z F C3216 USC CSD-TD26
O CD C 0473 87-015-785-080 0E C-CAP, 0.1-25 Z F C3216 USC CSD-TD26
O CD C 0474 87-015-785-080 0E C-CAP, 0.1-25 Z F C3216 USC CSD-TD26
O CD C 0475 87-A11-132-080 0E CAP,TC U 0.01-50 K B USC CSD-TD26
O CD C 0476 87-010-236-080 0E CAP,E 1000-10 M SME USC CSD-TD26
O CD C 0477 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O CD C 0478 87-010-263-080 0E CAP,E 100-10 M 11L SME USC CSD-TD26
O CD C 0479 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O CD C 0480 87-010-221-080 0E CAP,E 470-10 M SME USC CSD-TD26
O CD C 0481 87-010-405-080 0E CAP,E 10-50 M 11L SME USC CSD-TD26
O CD C 0482 87-010-405-080 0E CAP,E 10-50 M 11L SME USC CSD-TD26
O CD C 0489 87-012-368-080 0E C-CAP,S 0.1-50 Z F USC CSD-TD26
O CD C 0490 87-012-368-080 0E C-CAP,S 0.1-50 Z F USC CSD-TD26
O CD C 0493 87-010-180-080 0E C-CAP,S 1500P-50 K B C2012 USC CSD-TD26
O CD C 0501 87-012-368-080 0E C-CAP,S 0.1-50 Z F USC CSD-TD26
O CD C 0502 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM USC CSD-TD26
O CD C 0503 87-018-119-080 0E CAP,TC U 100P-50 K B UP050 USC CSD-TD26
O CD C 0504 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM USC CSD-TD26
O CD C 0505 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM USC CSD-TD26
O CD C 0506 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM USC CSD-TD26
O CD C 0510 87-016-669-080 0E C-CAP,S 0.1-25 K B USC CSD-TD26
! O CD CN 0205 87-A60-109-010 0E CONN,2P V S2M-2W USC CSD-TD26
! O CD CN 0401 87-A60-424-010 0E CONN,16P V TOC-B USC CSD-TD26
! O CD CN 0403 87-099-201-010 0E CONN,8P H BLK 6216 USC CSD-TD26
O CD CNA0402 8B-CDA-625-010 -- CONN ASSY,6P CD-ME USC CSD-TD26
S CD D 0401 87-070-345-080 0E DIODE,1N4148 USC CSD-TD26
S CD D 0402 87-070-345-080 0E DIODE,1N4148 USC CSD-TD26
S CD D 0403 87-070-345-080 0E DIODE,1N4148 USC CSD-TD26
S CD IC 0401 87-A20-446-010 1E C-IC,LA9241ML USC CSD-TD26
S CD IC 0402 87-A21-319-010 2A C-IC,LC78622NE USC CSD-TD26
S CD IC 0404 87-A21-891-010 1C C-IC,MM1469 H USC CSD-TD26
O CD L 0401 87-003-102-080 0E COIL,10UH J LAL02 USC CSD-TD26
CD L 0402 88-100-000-010 0E PLATING-JW, 0.58 SN95 USC CSD-TD26
O CD L 0404 87-003-152-080 0E COIL,100UH J LAL02 USC CSD-TD26
CD L 0405 88-100-000-010 0E PLATING-JW, 0.58 SN95 USC CSD-TD26
S CD Q 0401 89-109-332-380 0E TR,2SA933RS USC CSD-TD26
S CD Q 0402 87-A30-515-080 0E TR,2SA1979O/Y USC CSD-TD26
S CD Q 0403 87-A30-287-040 0E C-TR,DTC114TKA USC CSD-TD26
S CD Q 0406 87-A30-287-040 0E C-TR,DTC114TKA USC CSD-TD26
S CD Q 0407 87-A30-288-040 0E C-TR,DTC114YKA USC CSD-TD26
S CD Q 0408 87-A30-288-040 0E C-TR,DTC114YKA USC CSD-TD26
CD R 0401 88-118-101-080 0E C-RES,S 100-1/10W J USC CSD-TD26
CD R 0402 88-118-100-080 0E C-RES,S 10-1/10W J USC CSD-TD26
CD R 0403 88-118-123-080 0E C-RES,S 12K-1/10W J USC CSD-TD26
CD R 0405 88-118-104-080 0E C-RES,S 100K-1/10W J USC CSD-TD26
CD R 0406 88-118-332-080 0E C-RES,S 3.3K-1/10W J USC CSD-TD26
CD R 0407 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
CD R 0408 88-118-683-080 0E C-RES,S 68K-1/10W J USC CSD-TD26
CD R 0409 88-118-222-080 0E C-RES,S 2.2K-1/10W J USC CSD-TD26
CD R 0410 88-118-273-080 0E C-RES,S 27K-1/10W J USC CSD-TD26
CD R 0411 88-118-561-080 0E C-RES,S 560-1/10W J USC CSD-TD26
CD R 0412 88-118-224-080 0E C-RES,S 220K-1/10W J USC CSD-TD26
CD R 0413 88-118-153-080 0E C-RES,S 15K-1/10W J USC CSD-TD26
CD R 0414 88-118-332-080 0E C-RES,S 3.3K-1/10W J USC CSD-TD26
CD R 0415 88-118-223-080 0E C-RES,S 22K-1/10W J USC CSD-TD26
CD R 0417 88-118-123-080 0E C-RES,S 12K-1/10W J USC CSD-TD26
CD R 0418 88-118-473-080 0E C-RES,S 47K-1/10W J USC CSD-TD26
CD R 0419 88-118-152-080 0E C-RES,S 1.5K-1/10W J USC CSD-TD26
CD R 0420 88-118-332-080 0E C-RES,S 3.3K-1/10W J USC CSD-TD26
CD R 0421 88-121-184-080 0E RES,180K-1/8W J USC CSD-TD26
CD R 0423 88-118-104-080 0E C-RES,S 100K-1/10W J USC CSD-TD26
CD R 0424 88-118-122-080 0E C-RES,S 1.2K-1/10W J USC CSD-TD26
CD R 0425 88-118-563-080 0E C-RES,S 56K-1/10W J USC CSD-TD26
CD R 0426 88-118-123-080 0E C-RES,S 12K-1/10W J USC CSD-TD26
CD R 0427 88-118-682-080 0E C-RES,S 6.8K-1/10W J USC CSD-TD26
CD R 0428 88-118-101-080 0E C-RES,S 100-1/10W J USC CSD-TD26

 4 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
CD R 0429 88-118-152-080 0E C-RES,S 1.5K-1/10W J USC CSD-TD26
CD R 0430 88-121-682-080 0E RES,6.8K-1/8W J USC CSD-TD26
CD R 0431 88-121-274-080 0E RES,270K-1/8W J USC CSD-TD26
CD R 0432 88-121-274-080 0E RES,270K-1/8W J USC CSD-TD26
CD R 0433 88-118-472-080 0E C-RES,S 4.7K-1/10W J USC CSD-TD26
CD R 0434 88-118-473-080 0E C-RES,S 47K-1/10W J USC CSD-TD26
CD R 0435 88-118-223-080 0E C-RES,S 22K-1/10W J USC CSD-TD26
CD R 0436 88-121-822-080 0E RES,8.2K-1/8W J USC CSD-TD26
CD R 0437 88-121-103-080 0E RES,10K-1/8W J USC CSD-TD26
CD R 0438 88-118-681-080 0E C-RES,S 680-1/10W J USC CSD-TD26
CD R 0439 88-118-153-080 0E C-RES,S 15K-1/10W J USC CSD-TD26
CD R 0440 88-118-331-080 0E C-RES,S 330-1/10W J USC CSD-TD26
CD R 0441 88-118-681-080 0E C-RES,S 680-1/10W J USC CSD-TD26
CD R 0442 88-118-273-080 0E C-RES,S 27K-1/10W J USC CSD-TD26
CD R 0443 88-118-122-080 0E C-RES,S 1.2K-1/10W J USC CSD-TD26
CD R 0444 88-118-333-080 0E C-RES,S 33K-1/10W J USC CSD-TD26
CD R 0445 88-118-153-080 0E C-RES,S 15K-1/10W J USC CSD-TD26
CD R 0446 88-118-183-080 0E C-RES,S 18K-1/10W J USC CSD-TD26
CD R 0447 88-118-123-080 0E C-RES,S 12K-1/10W J USC CSD-TD26
CD R 0449 88-100-000-010 0E PLATING-JW, 0.58 SN95 USC CSD-TD26
CD R 0451 88-118-272-080 0E C-RES,S 2.7K-1/10W J USC CSD-TD26
CD R 0452 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
CD R 0453 88-118-332-080 0E C-RES,S 3.3K-1/10W J USC CSD-TD26
CD R 0455 88-118-101-080 0E C-RES,S 100-1/10W J USC CSD-TD26
CD R 0456 88-118-821-080 0E C-RES,S 820-1/10W J USC CSD-TD26
CD R 0457 88-118-153-080 0E C-RES,S 15K-1/10W J USC CSD-TD26
CD R 0459 88-121-392-080 0E RES,3.9K-1/8W J USC CSD-TD26
CD R 0460 88-121-392-080 0E RES,3.9K-1/8W J USC CSD-TD26
CD R 0465 88-118-680-080 0E C-RES,S 68-1/10W J USC CSD-TD26
CD R 0466 88-121-101-080 0E RES,100-1/8W J USC CSD-TD26
CD R 0467 88-121-333-080 0E RES,33K-1/8W J USC CSD-TD26
CD R 0469 88-118-473-080 0E C-RES,S 47K-1/10W J USC CSD-TD26
CD R 0471 88-100-000-010 0E PLATING-JW, 0.58 SN95 USC CSD-TD26
CD R 0472 88-128-000-080 0E C-JUMPER,3216 USC CSD-TD26
CD R 0473 88-128-000-080 0E C-JUMPER,3216 USC CSD-TD26
CD R 0474 88-128-000-080 0E C-JUMPER,3216 USC CSD-TD26
CD R 0475 88-121-101-080 0E RES,100-1/8W J USC CSD-TD26
CD R 0476 88-118-229-080 0E C-RES,S 2.2-1/10W J USC CSD-TD26
CD R 0478 88-118-154-080 0E C-RES,S 150K-1/10W J USC CSD-TD26
CD R 0479 88-118-153-080 0E C-RES,S 15K-1/10W J USC CSD-TD26
CD R 0480 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
CD R 0485 88-118-153-080 0E C-RES,S 15K-1/10W J USC CSD-TD26
CD R 0486 88-118-153-080 0E C-RES,S 15K-1/10W J USC CSD-TD26
CD R 0487 88-118-153-080 0E C-RES,S 15K-1/10W J USC CSD-TD26
CD R 0488 88-118-154-080 0E C-RES,S 150K-1/10W J USC CSD-TD26
CD R 0489 88-118-101-080 0E C-RES,S 100-1/10W J USC CSD-TD26
CD R 0493 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
CD R 0495 88-118-122-080 0E C-RES,S 1.2K-1/10W J USC CSD-TD26
CD R 0496 88-118-122-080 0E C-RES,S 1.2K-1/10W J USC CSD-TD26
CD R 0497 88-118-682-080 0E C-RES,S 6.8K-1/10W J USC CSD-TD26
CD R 0498 88-118-682-080 0E C-RES,S 6.8K-1/10W J USC CSD-TD26
CD R 0499 88-121-823-080 0E RES,82K-1/8W J USC CSD-TD26
CD R 0501 88-121-101-080 0E RES,100-1/8W J USC CSD-TD26
CD R 0502 88-121-101-080 0E RES,100-1/8W J USC CSD-TD26
CD R 0503 88-121-101-080 0E RES,100-1/8W J USC CSD-TD26
CD R 0504 88-121-101-080 0E RES,100-1/8W J USC CSD-TD26
CD R 0505 88-121-101-080 0E RES,100-1/8W J USC CSD-TD26
CD R 0506 88-121-101-080 0E RES,100-1/8W J USC CSD-TD26
CD R 0530 88-121-104-080 0E RES,100K-1/8W J USC CSD-TD26
CD R 0531 88-118-104-080 0E C-RES,S 100K-1/10W J USC CSD-TD26
CD R 0532 88-121-104-080 0E RES,100K-1/8W J USC CSD-TD26
O CD SFR0430 87-024-437-080 0E SFR,100K H RH063MC USC CSD-TD26
O CD 0401 8Z-CD5-633-010 1B VIB, CER16.93MHZ FCR16.93M2 USC CSD-TD26
O ELECTRICAL 87-A91-857-010 1B ANT,ROD 5SEC709 USC CSD-TD26
ELECTRICAL 89-920-050-110 0E WIRE,UD0-5-3 USC CSD-TD26
ELECTRICAL 8B-CDA-207-010 -- SH,FIBER USC CSD-TD26
O ELECTRICAL 8B-CDA-615-010 -- SPKR,10 7OHM USC CSD-TD26
O ELECTRICAL * 87-036-389-010 1B SW,PUSH 1-1-1 R8120125 USC CSD-TD26
! O ELECTRICAL * 87-A60-177-010 1A JACK,AC U BLK W/SW USC CSD-TD26
ELECTRICAL * 8A-CH4-602-010 -- HT-SINK,REG USC CSD-TD26

 5 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
ELECTRICAL * 8A-CH4-603-010 -- HT-SINK,MAIN 2.5W USC CSD-TD26
O ELECTRICAL * 8Z-CD5-634-010 1C COVER,AC SOCKET USC CSD-TD26
O ELECTRICAL CNA 8B-CDA-626-010 -- CONN ASSY,2P DOOR USC CSD-TD26
O ELECTRICAL CNA 8B-CDA-630-010 -- CONN ASSY,4P RPH USC CSD-TD26
O ELECTRICAL CNA 8B-CDA-631-010 -- CONN ASSY,4P TA-ME USC CSD-TD26
O ELECTRICAL CNA 8B-CDA-633-010 -- CONN ASSY,4P SP USC CSD-TD26
! O ELECTRICAL PT 0901 8A-CDA-611-010 1H PT,U 2.5W USC CSD-TD26
O ELECTRICAL W 8B-CDA-622-010 -- FF-CABLE,8P CD-FR USC CSD-TD26
ELECTRICAL W 8B-CDA-634-010 -- WIRE, RED AC JACK USC CSD-TD26
ELECTRICAL W 8B-CDA-635-010 -- WIRE, YEL AC JACK USC CSD-TD26
ELECTRICAL W 8B-CDA-636-010 -- WIRE, ORG AC JACK USC CSD-TD26
ELECTRICAL W 8B-CDA-637-010 -- WIRE, FASTON ASSY ANT USC CSD-TD26
O ELECTRICAL W 0901 8B-CDA-620-010 -- FF-CABLE,16P FR-MAIN USC CSD-TD26
O ELECTRICAL W 0901 8B-CDA-621-010 -- FF-CABLE,16P CD-RF USC CSD-TD26
O FUNC/BUFF C 0211 87-A11-603-080 0E C-CAP,S 0.15-16 K B USC CSD-TD26
O FUNC/BUFF C 0212 87-A11-603-080 0E C-CAP,S 0.15-16 K B USC CSD-TD26
O FUNC/BUFF C 0215 87-016-460-080 0E C-CAP,S 0.22-16 K B USC CSD-TD26
O FUNC/BUFF C 0216 87-016-460-080 0E C-CAP,S 0.22-16 K B USC CSD-TD26
O FUNC/BUFF C 0231 87-010-213-080 0E C-CAP,S 0.015-25 K B GRM USC CSD-TD26
O FUNC/BUFF C 0232 87-010-213-080 0E C-CAP,S 0.015-25 K B GRM USC CSD-TD26
O FUNC/BUFF C 0233 87-A10-201-080 0E C-CAP,S 0.33-16 K B USC CSD-TD26
O FUNC/BUFF C 0234 87-A10-201-080 0E C-CAP,S 0.33-16 K B USC CSD-TD26
O FUNC/BUFF C 0235 87-016-669-080 0E C-CAP,S 0.1-25 K B USC CSD-TD26
O FUNC/BUFF C 0236 87-016-669-080 0E C-CAP,S 0.1-25 K B USC CSD-TD26
O FUNC/BUFF C 0237 87-010-371-080 0E CAP,E 470-6.3 M SME USC CSD-TD26
O FUNC/BUFF C 0239 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O FUNC/BUFF C 0240 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O FUNC/BUFF C 0247 87-010-401-080 0E CAP,E 1-50 M 11L SME USC CSD-TD26
O FUNC/BUFF C 0248 87-010-401-080 0E CAP,E 1-50 M 11L SME USC CSD-TD26
O FUNC/BUFF C 0310 87-010-248-080 0E CAP,E 220-10 M 11L SME USC CSD-TD26
O FUNC/BUFF C 0316 87-010-263-080 0E CAP,E 100-10 M 11L SME USC CSD-TD26
O FUNC/BUFF C 0317 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
S FUNC/BUFF D 0307 87-A40-234-080 0E ZENER,MTZJ5.6A USC CSD-TD26
S FUNC/BUFF IC 0203 87-A21-520-040 1E C-IC,M61509FP USC CSD-TD26
S FUNC/BUFF Q 0306 89-318-154-080 0E TR,2SC1815Y USC CSD-TD26
FUNC/BUFF R 0203 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
FUNC/BUFF R 0204 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
FUNC/BUFF R 0215 88-118-472-080 0E C-RES,S 4.7K-1/10W J USC CSD-TD26
FUNC/BUFF R 0216 88-118-472-080 0E C-RES,S 4.7K-1/10W J USC CSD-TD26
FUNC/BUFF R 0217 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
FUNC/BUFF R 0218 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
FUNC/BUFF R 0227 88-118-472-080 0E C-RES,S 4.7K-1/10W J USC CSD-TD26
FUNC/BUFF R 0228 88-118-472-080 0E C-RES,S 4.7K-1/10W J USC CSD-TD26
FUNC/BUFF R 0231 88-118-222-080 0E C-RES,S 2.2K-1/10W J USC CSD-TD26
FUNC/BUFF R 0232 88-118-222-080 0E C-RES,S 2.2K-1/10W J USC CSD-TD26
FUNC/BUFF R 0233 88-121-102-080 0E RES,1K-1/8W J USC CSD-TD26
FUNC/BUFF R 0234 88-118-103-080 0E C-RES,S 10K-1/10W J USC CSD-TD26
FUNC/BUFF R 0235 88-118-392-080 0E C-RES,S 3.9K-1/10W J USC CSD-TD26
FUNC/BUFF R 0236 88-118-472-080 0E C-RES,S 4.7K-1/10W J USC CSD-TD26
FUNC/BUFF R 0237 88-121-102-080 0E RES,1K-1/8W J USC CSD-TD26
FUNC/BUFF R 0241 88-121-473-080 0E RES,47K-1/8W J USC CSD-TD26
FUNC/BUFF R 0242 88-118-473-080 0E C-RES,S 47K-1/10W J USC CSD-TD26
FUNC/BUFF R 0243 88-121-183-080 0E RES,18K-1/8W J USC CSD-TD26
FUNC/BUFF R 0244 88-118-183-080 0E C-RES,S 18K-1/10W J USC CSD-TD26
FUNC/BUFF R 0245 88-121-223-080 0E RES,22K-1/8W J USC CSD-TD26
FUNC/BUFF R 0246 88-118-223-080 0E C-RES,S 22K-1/10W J USC CSD-TD26
FUNC/BUFF R 0310 88-121-331-080 0E RES,330-1/8W J USC CSD-TD26
FUNC/BUFF R 0481 88-121-334-080 0E RES,330K-1/8W J USC CSD-TD26
FUNC/BUFF R 0482 88-118-334-080 0E C-RES,S 330K-1/10W J USC CSD-TD26
FUNC/BUFF R 0815 88-121-223-080 0E RES,22K-1/8W J USC CSD-TD26
FUNC/BUFF R 0816 88-121-223-080 0E RES,22K-1/8W J USC CSD-TD26
FUNC/BUFF R 0925 88-118-563-080 0E C-RES,S 56K-1/10W J USC CSD-TD26
FUNC/BUFF R 0926 88-118-563-080 0E C-RES,S 56K-1/10W J USC CSD-TD26
O KNOB 8B-CDA-014-010 -- KEY,CD USC CSD-TD26
O KNOB 8B-CDA-016-010 -- KEY,FUNC B USC CSD-TD26
O KNOB 8B-CDA-019-010 -- KEY,PAUSE USC CSD-TD26
O KNOB 8B-CDA-020-010 -- KEY,STOP USC CSD-TD26
O KNOB 8B-CDA-021-010 -- KEY,FF USC CSD-TD26
O KNOB 8B-CDA-022-010 -- KEY,REW USC CSD-TD26
O KNOB 8B-CDA-023-010 -- KEY,PLAY USC CSD-TD26

 6 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O KNOB 8B-CDA-024-010 -- KEY,REC USC CSD-TD26
O KNOB 8B-CHA-029-010 -- KEY,FUNC E USC CSD-TD26
LBL,POP 8B-CHA-970-010 -- LBL,POP U USC CSD-TD26
O MICON C 0601 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USC CSD-TD26
O MICON C 0602 87-010-555-040 0E CAP,E 100-10 M 5L SRE USC CSD-TD26
O MICON C 0603 87-A10-189-040 0E CAP,E 220-10 M 5L USC CSD-TD26
O MICON C 0604 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USC CSD-TD26
O MICON C 0605 87-018-150-080 0E CAP,TC U 18P-50 J CH UP050 USC CSD-TD26
O MICON C 0606 87-018-111-080 0E CAP,TC U 27P-50 J SL UP050 USC CSD-TD26
O MICON C 0607 87-018-116-080 0E CAP,TC U 56P-50 J SL UP050 USC CSD-TD26
O MICON C 0608 87-018-114-080 0E CAP,TC U 39P-50 J SL UP050 USC CSD-TD26
O MICON C 0609 87-018-149-080 0E CAP,TC U 15P-50 J CH UP050 USC CSD-TD26
O MICON C 0610 87-015-785-080 0E C-CAP, 0.1-25 Z F C3216 USC CSD-TD26
O MICON C 0611 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O MICON C 0612 87-018-131-080 0E CAP,TC U 1000P-50 K B UP050 USC CSD-TD26
O MICON C 0613 87-A10-826-080 0E C-CAP,S 1-10 K B USC CSD-TD26
O MICON C 0614 87-010-494-040 0E CAP,E 1-50 M 5L SRE USC CSD-TD26
O MICON C 0615 87-010-493-040 0E CAP,E 0.47-50 M 5L SRE USC CSD-TD26
O MICON C 0616 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 USC CSD-TD26
O MICON C 0617 87-010-495-040 0E CAP,E 2.2-50 M 5L SRE USC CSD-TD26
O MICON C 0618 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O MICON C 0619 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O MICON C 0625 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O MICON C 0626 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O MICON C 0627 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O MICON CN 0601 87-099-757-010 0E CONN,16P H 9604 USC CSD-TD26
! O MICON CN 0602 87-A60-079-010 0E CONN,08P H 9604S-08F USC CSD-TD26
O MICON CNA0603 8B-CHA-610-010 -- CONN ASSY,4P TU-FR USC CSD-TD26
S MICON D 0601 87-020-465-080 0E DIODE,1SS133 USC CSD-TD26
S MICON D 0602 87-020-465-080 0E DIODE,1SS133 USC CSD-TD26
S MICON D 0603 87-020-465-080 0E DIODE,1SS133 USC CSD-TD26
S MICON D 0604 87-020-465-080 0E DIODE,1SS133 USC CSD-TD26
S MICON D 0607 87-020-465-080 0E DIODE,1SS133 USC CSD-TD26
S MICON IC 0601 8B-CHA-600-010 1H C-IC,LC867132V-5T67 USC CSD-TD26
MICON JR 0601 88-129-000-080 0E C-JUMPER,3216 USC CSD-TD26
MICON JR 0602 88-129-000-080 0E C-JUMPER,3216 USC CSD-TD26
MICON JR 0603 88-129-000-080 0E C-JUMPER,3216 USC CSD-TD26
MICON JR 0604 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
MICON JR 0605 88-129-000-080 0E C-JUMPER,3216 USC CSD-TD26
MICON JR 0606 88-129-000-080 0E C-JUMPER,3216 USC CSD-TD26
O MICON L 0601 87-003-102-080 0E COIL,10UH J LAL02 USC CSD-TD26
O MICON L 0602 87-003-102-080 0E COIL,10UH J LAL02 USC CSD-TD26
MICON L 0605 88-100-000-010 0E PLATING-JW, 0.58 SN95 USC CSD-TD26
MICON L 0606 88-100-000-010 0E PLATING-JW, 0.58 SN95 USC CSD-TD26
MICON L 0607 88-100-000-010 0E PLATING-JW, 0.58 SN95 USC CSD-TD26
O MICON LCD0601 8B-CHA-620-010 -- LCD,AIW4239-32PIN USC CSD-TD26
O MICON LED0601 8A-CDA-646-010 0E LED,6224-10GD GRN USC CSD-TD26
MICON LED0602 8A-CDA-645-010 0E LED,6224-10ID RED USC CSD-TD26
MICON LED0603 8A-CDA-645-010 0E LED,6224-10ID RED USC CSD-TD26
S MICON Q 0601 87-026-237-080 0E C-TR,DTC124 K USC CSD-TD26
S MICON Q 0602 87-026-463-080 0E TR,2SA933SRS USC CSD-TD26
S MICON Q 0603 87-026-237-080 0E C-TR,DTC124 K USC CSD-TD26
S MICON Q 0604 87-026-239-080 0E C-TR,DTC114TK USC CSD-TD26
S MICON Q 0605 87-026-239-080 0E C-TR,DTC114TK USC CSD-TD26
MICON R 0601 88-118-334-080 0E C-RES,S 330K-1/10W J USC CSD-TD26
MICON R 0602 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
MICON R 0603 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
MICON R 0604 88-121-102-080 0E RES,1K-1/8W J USC CSD-TD26
MICON R 0605 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
MICON R 0606 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
MICON R 0607 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
MICON R 0608 88-121-102-080 0E RES,1K-1/8W J USC CSD-TD26
MICON R 0609 88-121-103-080 0E RES,10K-1/8W J USC CSD-TD26
MICON R 0610 88-121-103-080 0E RES,10K-1/8W J USC CSD-TD26
MICON R 0611 88-121-474-080 0E RES,470K-1/8W J USC CSD-TD26
MICON R 0612 88-118-103-080 0E C-RES,S 10K-1/10W J USC CSD-TD26
MICON R 0613 88-118-103-080 0E C-RES,S 10K-1/10W J USC CSD-TD26
MICON R 0614 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
MICON R 0615 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
MICON R 0616 88-118-000-080 0E C-JUMPER,S USC CSD-TD26

 7 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
MICON R 0617 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
MICON R 0618 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
MICON R 0619 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
MICON R 0620 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
MICON R 0621 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
MICON R 0622 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
MICON R 0623 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
MICON R 0624 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
MICON R 0625 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
MICON R 0626 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
MICON R 0627 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
MICON R 0631 88-118-334-080 0E C-RES,S 330K-1/10W J USC CSD-TD26
MICON R 0632 88-118-473-080 0E C-RES,S 47K-1/10W J USC CSD-TD26
MICON R 0633 88-118-103-080 0E C-RES,S 10K-1/10W J USC CSD-TD26
MICON R 0634 88-118-104-080 0E C-RES,S 100K-1/10W J USC CSD-TD26
MICON R 0636 88-118-152-080 0E C-RES,S 1.5K-1/10W J USC CSD-TD26
MICON R 0637 88-118-152-080 0E C-RES,S 1.5K-1/10W J USC CSD-TD26
MICON R 0639 88-118-104-080 0E C-RES,S 100K-1/10W J USC CSD-TD26
MICON R 0641 88-118-821-080 0E C-RES,S 820-1/10W J USC CSD-TD26
MICON R 0642 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
MICON R 0643 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
MICON R 0644 88-118-122-080 0E C-RES,S 1.2K-1/10W J USC CSD-TD26
MICON R 0645 88-118-122-080 0E C-RES,S 1.2K-1/10W J USC CSD-TD26
MICON R 0646 88-118-152-080 0E C-RES,S 1.5K-1/10W J USC CSD-TD26
MICON R 0647 88-118-182-080 0E C-RES,S 1.8K-1/10W J USC CSD-TD26
MICON R 0651 88-118-821-080 0E C-RES,S 820-1/10W J USC CSD-TD26
MICON R 0652 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
MICON R 0653 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
MICON R 0654 88-118-122-080 0E C-RES,S 1.2K-1/10W J USC CSD-TD26
O MICON S 0601 87-A92-170-080 -- SW,TACT EVQPAD05R USC CSD-TD26
O MICON S 0602 87-A92-170-080 -- SW,TACT EVQPAD05R USC CSD-TD26
O MICON S 0603 87-A92-170-080 -- SW,TACT EVQPAD05R USC CSD-TD26
O MICON S 0604 87-A92-170-080 -- SW,TACT EVQPAD05R USC CSD-TD26
O MICON S 0605 87-A92-170-080 -- SW,TACT EVQPAD05R USC CSD-TD26
O MICON S 0606 87-A92-170-080 -- SW,TACT EVQPAD05R USC CSD-TD26
O MICON S 0607 87-A92-170-080 -- SW,TACT EVQPAD05R USC CSD-TD26
O MICON S 0607 8Z-CT6-636-010 0E SW,TACT EVQJAC04M USC CSD-TD26
O MICON S 0608 87-A92-170-080 -- SW,TACT EVQPAD05R USC CSD-TD26
O MICON S 0608 8Z-CT6-636-010 0E SW,TACT EVQJAC04M USC CSD-TD26
O MICON S 0611 87-A92-170-080 -- SW,TACT EVQPAD05R USC CSD-TD26
O MICON S 0612 87-A92-170-080 -- SW,TACT EVQPAD05R USC CSD-TD26
O MICON S 0613 87-A92-170-080 -- SW,TACT EVQPAD05R USC CSD-TD26
O MICON S 0614 87-A92-170-080 -- SW,TACT EVQPAD05R USC CSD-TD26
O MICON S 0615 87-A92-170-080 -- SW,TACT EVQPAD05R USC CSD-TD26
O MICON 0601 87-030-273-010 1A VIB, TAL 32.768KHZ DT-38 5PPM USC CSD-TD26
O MICON 0602 87-030-376-080 1A VIB,CER 5.760MHZ CSA MG200 USC CSD-TD26
O OTHERS 86-CT9-217-110 0E HLDR,CHUCK A(S) USC CSD-TD26
O OTHERS 86-CT9-222-010 0E PLATE,MAGNET USC CSD-TD26
O OTHERS 87-036-368-010 0E MAGNET, USC CSD-TD26
! O OTHERS 87-063-165-010 0E OIL-DMPR,150 USC CSD-TD26
O OTHERS 87-064-185-010 0E HLDR,WIRE PVC 0.5 USC CSD-TD26
O OTHERS 88-CH6-220-010 0E CUSHION,CD A USC CSD-TD26
O OTHERS 8A-CDA-221-010 1A SPR-P,REC USC CSD-TD26
O OTHERS 8B-CDA-206-010 -- SPR-T,CD USC CSD-TD26
O OTHERS 8B-CDA-208-010 -- SPR-T,CASS USC CSD-TD26
! O OTHERS 8Z-CDB-169-010 1D PANEL,CD SANYO USC CSD-TD26
O OTHERS 8Z-CT6-213-110 0E BASE,CHUCK USC CSD-TD26
O OTHERS 8Z-CT6-214-110 0E RING,CHUCK USC CSD-TD26
O OTHERS * 8A-CDA-220-010 0E PLATE,REC USC CSD-TD26
OTHERS * 8A-CDA-224-010 -- CUSH, 9.3-6.2-0.6 USC CSD-TD26
O OTHERS * 8B-CDA-202-010 -- HLDR,TU USC CSD-TD26
OTHERS * 8B-CDA-204-010 -- PLATE,ANT USC CSD-TD26
O OTHERS * 8B-CHA-201-010 -- HLDR,LCD USC CSD-TD26
O OTHERS C 0321 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O OTHERS C 0322 87-010-263-080 0E CAP,E 100-10 M 11L SME USC CSD-TD26
O OTHERS CN 0201 87-099-018-010 0E CONN,16P V BLK 6216 USC CSD-TD26
O OTHERS CNA0302 8B-CDA-629-010 -- CONN ASSY,6P MA-TU USC CSD-TD26
S OTHERS D 0032 87-A40-509-080 0E ZENER,MTZJ6.8C USC CSD-TD26
OTHERS JR 0101 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
OTHERS JR 0102 88-118-000-080 0E C-JUMPER,S USC CSD-TD26

 8 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
OTHERS JR 0204 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
OTHERS JR 0350 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
OTHERS JR 0351 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
OTHERS JR 0402 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
OTHERS JR 0406 88-129-000-080 0E C-JUMPER,3216 USC CSD-TD26
OTHERS JR 0416 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
OTHERS JR 0425 88-129-000-080 0E C-JUMPER,3216 USC CSD-TD26
OTHERS JR 0426 88-129-000-080 0E C-JUMPER,3216 USC CSD-TD26
OTHERS JR 0428 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
O OTHERS L 0108 87-003-097-080 0E COIL,1.0UH K LAL02 USC CSD-TD26
S OTHERS Q 0321 89-318-154-080 0E TR,2SC1815Y USC CSD-TD26
S OTHERS Q 0841 87-026-291-080 1A TR,DTC124 S USC CSD-TD26
OTHERS R 0322 88-118-222-080 0E C-RES,S 2.2K-1/10W J USC CSD-TD26
OTHERS R 0327 88-118-822-080 0E C-RES,S 8.2K-1/10W J USC CSD-TD26
OTHERS R 0838 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
OTHERS R 0839 88-118-103-080 0E C-RES,S 10K-1/10W J USC CSD-TD26
OTHERS R 0927 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
OTHERS TM 0001 87-A60-884-010 0E PIN,DIA1 COATING-SHS USC CSD-TD26
PACKING 87-051-183-010 0E BAG,PV 0.03-120-280 USC CSD-TD26
PACKING 8A-CDA-897-010 -- SH,FOAMED-MAT 0.31-880-710 USC CSD-TD26
PACKING 8B-CDA-852-010 -- CUSHION,LEFT C USC CSD-TD26
PACKING 8B-CDA-853-010 -- CUSHION,RIGHT C USC CSD-TD26
PACKING 8B-CHA-851-010 -- CTN,PRINTED USC USC CSD-TD26
PACKING 8B-CHA-852-010 -- CTN,OUTER USC USC CSD-TD26
PLATE 84-711-909-010 1A LBL DATE CODE USC CSD-TD26
PLATE 87-B40-154-010 0E LBL,BAR-CODE CU USC CSD-TD26
PLATE 87-B40-282-010 0E LBL,BAR-CODE AU 35 8 USC CSD-TD26
PLATE 8A-CH4-040-010 0E LBL,CAUTION RW E USC CSD-TD26
PLATE 8B-CHA-007-010 -- LBL,SPEC U USC CSD-TD26
O POWER C 0491 87-A11-132-080 0E CAP,TC U 0.01-50 K B USC CSD-TD26
O POWER C 0492 87-010-221-080 0E CAP,E 470-10 M SME USC CSD-TD26
O POWER C 0901 87-010-192-080 0E C-CAP,S 0.022-50 Z F C2012 USC CSD-TD26
O POWER C 0902 87-010-192-080 0E C-CAP,S 0.022-50 Z F C2012 USC CSD-TD26
O POWER C 0903 87-010-192-080 0E C-CAP,S 0.022-50 Z F C2012 USC CSD-TD26
O POWER C 0904 87-010-192-080 0E C-CAP,S 0.022-50 Z F C2012 USC CSD-TD26
O POWER CNA0901 8B-CDA-627-010 -- CONN ASSY,3P PWR USC CSD-TD26
S POWER D 0494 87-070-345-080 0E DIODE,1N4148 USC CSD-TD26
S POWER D 0901 87-A40-465-010 0E DIODE,FR202 USC CSD-TD26
S POWER D 0902 87-A40-465-010 0E DIODE,FR202 USC CSD-TD26
S POWER D 0903 87-A40-465-010 0E DIODE,FR202 USC CSD-TD26
S POWER D 0904 87-A40-465-010 0E DIODE,FR202 USC CSD-TD26
S POWER D 0905 87-A40-465-010 0E DIODE,FR202 USC CSD-TD26
O POWER PR 0901 87-A91-940-080 0E PROTECTOR,2.5A 20P 60V USC CSD-TD26
S POWER Q 0491 89-112-965-080 0E TR,2SA1296GR USC CSD-TD26
S POWER Q 0492 87-026-291-080 1A TR,DTC124 S USC CSD-TD26
POWER R 0470 88-100-000-010 0E PLATING-JW, 0.58 SN95 USC CSD-TD26
POWER R 0490 88-121-102-080 0E RES,1K-1/8W J USC CSD-TD26
POWER R 0491 88-118-473-080 0E C-RES,S 47K-1/10W J USC CSD-TD26
POWER R 0492 88-118-331-080 0E C-RES,S 330-1/10W J USC CSD-TD26
O POWER SP 0901 8A-CDA-214-010 0E SPR-C,BATT USC CSD-TD26
O POWER SP 0902 8A-CDA-214-010 0E SPR-C,BATT USC CSD-TD26
O POWER SP 0903 8A-CDA-214-010 0E SPR-C,BATT USC CSD-TD26
O POWER SP 0904 8A-CDA-214-010 0E SPR-C,BATT USC CSD-TD26
O POWER AMP C 0251 87-010-405-080 0E CAP,E 10-50 M 11L SME USC CSD-TD26
O POWER AMP C 0263 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USC CSD-TD26
O POWER AMP C 0264 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USC CSD-TD26
O POWER AMP C 0265 87-010-263-080 0E CAP,E 100-10 M 11L SME USC CSD-TD26
O POWER AMP C 0266 87-010-263-080 0E CAP,E 100-10 M 11L SME USC CSD-TD26
O POWER AMP C 0267 87-010-385-080 0E CAP,E 220-25 M SME USC CSD-TD26
O POWER AMP C 0268 87-010-385-080 0E CAP,E 220-25 M SME USC CSD-TD26
O POWER AMP C 0271 87-010-221-080 0E CAP,E 470-10 M SME USC CSD-TD26
O POWER AMP C 0272 87-010-221-080 0E CAP,E 470-10 M SME USC CSD-TD26
POWER AMP C 0273 88-700-920-810 0E CAP,M 0.15-50 J LDS USC CSD-TD26
POWER AMP C 0274 88-700-920-810 0E CAP,M 0.15-50 J LDS USC CSD-TD26
O POWER AMP C 0278 87-010-385-080 0E CAP,E 220-25 M SME USC CSD-TD26
O POWER AMP C 0279 87-010-235-080 0E CAP,E 470-16 M SME USC CSD-TD26
O POWER AMP CN 0202 8A-CH4-687-010 0E CONN,4P V 2.5 USC CSD-TD26
S POWER AMP IC 0202 87-A21-193-010 1B IC,TA8227P USC CSD-TD26
O POWER AMP J 0201 87-A60-420-010 1A JACK,3.5 ST (MSC) USC CSD-TD26
S POWER AMP Q 0243 89-318-154-080 0E TR,2SC1815Y USC CSD-TD26

 9 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
S POWER AMP Q 0244 89-318-154-080 0E TR,2SC1815Y USC CSD-TD26
POWER AMP R 0251 88-121-152-080 0E RES,1.5K-1/8W J USC CSD-TD26
POWER AMP R 0252 88-121-152-080 0E RES,1.5K-1/8W J USC CSD-TD26
POWER AMP R 0253 88-121-222-080 0E RES,2.2K-1/8W J USC CSD-TD26
POWER AMP R 0254 88-121-222-080 0E RES,2.2K-1/8W J USC CSD-TD26
POWER AMP R 0255 88-118-332-080 0E C-RES,S 3.3K-1/10W J USC CSD-TD26
POWER AMP R 0269 88-100-000-010 0E PLATING-JW, 0.58 SN95 USC CSD-TD26
POWER AMP R 0270 88-118-104-080 0E C-RES,S 100K-1/10W J USC CSD-TD26
POWER AMP R 0271 88-121-682-080 0E RES,6.8K-1/8W J USC CSD-TD26
POWER AMP R 0272 88-121-682-080 0E RES,6.8K-1/8W J USC CSD-TD26
POWER AMP R 0274 88-118-151-080 0E C-RES,S 150-1/10W J USC CSD-TD26
POWER AMP R 0275 88-121-151-080 0E RES,150-1/8W J USC CSD-TD26
POWER AMP R 0277 88-130-229-080 0E RES,2.2-1/4W J USC CSD-TD26
POWER AMP R 0278 88-130-229-080 0E RES,2.2-1/4W J USC CSD-TD26
POWER AMP R 0279 88-121-181-080 0E RES,180-1/8W J USC CSD-TD26
POWER AMP R 0280 88-121-181-080 0E RES,180-1/8W J USC CSD-TD26
O POWER SUPPLY C 0301 87-016-495-000 1B CAP,E 3300-25 M SMG USC CSD-TD26
O POWER SUPPLY C 0306 87-010-404-080 0E CAP,E 4.7-50 M 11L SME USC CSD-TD26
O POWER SUPPLY C 0307 87-010-401-080 0E CAP,E 1-50 M 11L SME USC CSD-TD26
O POWER SUPPLY C 0308 87-010-221-080 0E CAP,E 470-10 M SME USC CSD-TD26
O POWER SUPPLY C 0311 87-010-265-080 0E CAP,E 33-16 M 11L SME USC CSD-TD26
O POWER SUPPLY C 0312 87-010-385-080 0E CAP,E 220-25 M SME USC CSD-TD26
O POWER SUPPLY C 0325 87-010-405-080 0E CAP,E 10-50 M 11L SME USC CSD-TD26
O POWER SUPPLY CN 0301 8A-CH4-689-010 0E CONN,3P V 2.5 USC CSD-TD26
S POWER SUPPLY D 0303 87-070-345-080 0E DIODE,1N4148 USC CSD-TD26
S POWER SUPPLY D 0304 87-A40-648-080 0E ZENER,MTZJ8.2A USC CSD-TD26
S POWER SUPPLY D 0305 87-070-345-080 0E DIODE,1N4148 USC CSD-TD26
S POWER SUPPLY D 0306 87-070-345-080 0E DIODE,1N4148 USC CSD-TD26
S POWER SUPPLY D 0311 87-017-932-080 0E ZENER,MTZJ6.2B USC CSD-TD26
S POWER SUPPLY Q 0301 89-112-965-080 0E TR,2SA1296GR USC CSD-TD26
S POWER SUPPLY Q 0302 87-026-463-080 0E TR,2SA933SRS USC CSD-TD26
S POWER SUPPLY Q 0303 87-026-291-080 1A TR,DTC124 S USC CSD-TD26
S POWER SUPPLY Q 0304 87-A30-476-010 1A TR,KTA1046Y USC CSD-TD26
S POWER SUPPLY Q 0305 87-026-462-080 0E TR,2SC1740SRS USC CSD-TD26
S POWER SUPPLY Q 0310 89-318-154-080 0E TR,2SC1815Y USC CSD-TD26
POWER SUPPLY R 0301 88-118-470-080 0E C-RES,S 47-1/10W J USC CSD-TD26
POWER SUPPLY R 0302 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
POWER SUPPLY R 0303 88-118-101-080 0E C-RES,S 100-1/10W J USC CSD-TD26
POWER SUPPLY R 0304 88-118-474-080 0E C-RES,S 470K-1/10W J USC CSD-TD26
POWER SUPPLY R 0305 88-118-471-080 0E C-RES,S 470-1/10W J USC CSD-TD26
POWER SUPPLY R 0306 88-121-103-080 0E RES,10K-1/8W J USC CSD-TD26
POWER SUPPLY R 0307 88-121-152-080 0E RES,1.5K-1/8W J USC CSD-TD26
POWER SUPPLY R 0308 88-121-103-080 0E RES,10K-1/8W J USC CSD-TD26
POWER SUPPLY R 0309 88-121-471-080 0E RES,470-1/8W J USC CSD-TD26
POWER SUPPLY R 0311 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
POWER SUPPLY R 0313 88-130-101-080 0E RES,100-1/4W J USC CSD-TD26
POWER SUPPLY R 0316 88-118-682-080 0E C-RES,S 6.8K-1/10W J USC CSD-TD26
POWER SUPPLY R 0317 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
POWER SUPPLY R 0318 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
POWER SUPPLY R 0321 88-121-152-080 0E RES,1.5K-1/8W J USC CSD-TD26
POWER SUPPLY R 0325 88-121-102-080 0E RES,1K-1/8W J USC CSD-TD26
POWER SUPPLY R 0328 88-121-102-080 0E RES,1K-1/8W J USC CSD-TD26
! PRINTED DU 87-056-144-010 0E SH,AUDIO-N SAFETY USC CSD-TD26
PRINTED DU 87-B40-085-010 0E BAG,PV 0.04-200-350 PL USC CSD-TD26
PRINTED DU 87-B50-054-010 1D WARR-CARD,USA CUST/PORTABLE USC CSD-TD26
O PRINTED DU 8B-CHA-903-010 -- IB,U(ESF)FM USC CSD-TD26
PWB 8B-CDA-641-010 -- PWB,MAIN 2M -2.5W USC CSD-TD26
PWB 8B-CHA-666-010 -- PWB,TU BCH 4M USC CSD-TD26
PWB * 8B-CHA-601-010 -- PWB,COMB FR 5 2 USC CSD-TD26
PWB * 8B-CHA-602-010 -- PWB,FR USC CSD-TD26
PWB * 8B-CHA-602-010 -- PWB,FR USC CSD-TD26
PWB * 8B-CHA-603-010 -- PWB,BATT USC CSD-TD26
PWB * 8B-CHA-603-010 -- PWB,BATT USC CSD-TD26
PWB * 8B-CHA-604-010 -- PWB,BATT COVER USC CSD-TD26
PWB * 8B-CHA-604-010 -- PWB,BATT COVER USC CSD-TD26
PWB * 8B-CHA-604-010 -- PWB,BATT COVER USC CSD-TD26
PWB * 8B-CHA-604-010 -- PWB,BATT COVER USC CSD-TD26
PWB * 8B-CHA-605-010 -- PWB,VOLTAGE SEL. USC CSD-TD26
PWB * 8B-CHA-605-010 -- PWB,VOLTAGE SEL. USC CSD-TD26
PWB * 8B-CHA-606-010 -- PWB,BATT INF USC CSD-TD26

 10 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
PWB * 8B-CHA-606-010 -- PWB,BATT INF USC CSD-TD26
O SCREW 87-721-096-410 0E QT2+3-10 W/O SLOT USC CSD-TD26
O SCREW 87-751-104-410 0E VT2+3-30 W/O SLOT USC CSD-TD26
O SCREW 87-B10-183-010 0E VT2+3-20 W/O SOLT USC CSD-TD26
O SCREW * 87-254-097-410 0E U+3-12 CR USC CSD-TD26
O SCREW * 87-751-076-410 0E VT2+2.6-12 USC CSD-TD26
O SCREW * 87-751-076-410 0E VT2+2.6-12 USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 87-751-096-410 0E VT2+3-10 W/O SLOT USC CSD-TD26
O SCREW * 8A-CDA-222-010 0E S-SCREW,CASS+2.6-4 USC CSD-TD26
O SCREW * 8A-CK4-223-010 0E S-SCREW,CD USC CSD-TD26
O SCREW * 8A-CK4-223-010 0E S-SCREW,CD USC CSD-TD26
O SCREW * 8A-CK4-223-010 0E S-SCREW,CD USC CSD-TD26
O SCREW * 8A-CK4-223-010 0E S-SCREW,CD USC CSD-TD26
TAPE M8-ZZM-196-070 2A ZZM-1 AR5NC USC CSD-TD26
O TAPE C 0030 87-010-260-080 0E CAP,E 47-25 M 11L SME USC CSD-TD26
O TAPE C 0324 87-010-260-080 0E CAP,E 47-25 M 11L SME USC CSD-TD26
O TAPE C 0801 87-010-248-080 0E CAP,E 220-10 M 11L SME USC CSD-TD26
O TAPE C 0805 87-012-365-080 0E C-CAP,S 0.027-25 K B USC CSD-TD26
O TAPE C 0806 87-012-365-080 0E C-CAP,S 0.027-25 K B USC CSD-TD26
O TAPE C 0807 87-010-406-080 0E CAP,E 22-50 M 11L SME USC CSD-TD26
O TAPE C 0808 87-010-406-080 0E CAP,E 22-50 M 11L SME USC CSD-TD26
O TAPE C 0809 87-010-401-080 0E CAP,E 1-50 M 11L SME USC CSD-TD26
O TAPE C 0810 87-010-401-080 0E CAP,E 1-50 M 11L SME USC CSD-TD26
O TAPE C 0811 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USC CSD-TD26
O TAPE C 0812 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USC CSD-TD26
O TAPE C 0816 87-010-180-080 0E C-CAP,S 1500P-50 K B C2012 USC CSD-TD26
O TAPE C 0817 87-010-180-080 0E C-CAP,S 1500P-50 K B C2012 USC CSD-TD26
O TAPE C 0821 87-010-401-080 0E CAP,E 1-50 M 11L SME USC CSD-TD26
O TAPE C 0822 87-010-401-080 0E CAP,E 1-50 M 11L SME USC CSD-TD26
O TAPE C 0823 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USC CSD-TD26
O TAPE C 0824 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USC CSD-TD26
O TAPE C 0829 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USC CSD-TD26
O TAPE C 0830 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USC CSD-TD26
O TAPE C 0831 87-010-198-080 0E C-CAP,S 0.022-25 K B C2012 USC CSD-TD26
TAPE C 0833 88-700-620-810 0E CAP,M 1200P-50 J USC CSD-TD26
O TAPE C 0834 87-010-248-080 0E CAP,E 220-10 M 11L SME USC CSD-TD26
O TAPE C 0843 87-A11-132-080 0E CAP,TC U 0.01-50 K B USC CSD-TD26
O TAPE C 0844 87-018-124-080 0E CAP,TC U 270P-50 K B UP050 USC CSD-TD26
O TAPE C 0845 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USC CSD-TD26
O TAPE C 0846 87-010-263-080 0E CAP,E 100-10 M 11L SME USC CSD-TD26
O TAPE C 0851 87-A11-128-080 0E CAP,TC U 4700P-50 K B USC CSD-TD26
O TAPE C 0852 87-018-131-080 0E CAP,TC U 1000P-50 K B UP050 USC CSD-TD26

 11 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O TAPE C 0853 87-A11-132-080 0E CAP,TC U 0.01-50 K B USC CSD-TD26
! O TAPE CN 0801 87-A60-110-010 0E CONN,4P V S2M-4W USC CSD-TD26
O TAPE CN 0802 8A-CH4-687-010 0E CONN,4P V 2.5 USC CSD-TD26
S TAPE D 0308 87-017-978-080 0E DIODE,1N4003 USC CSD-TD26
S TAPE D 0309 87-070-345-080 0E DIODE,1N4148 USC CSD-TD26
TAPE D 0803 88-100-000-010 0E PLATING-JW, 0.58 SN95 USC CSD-TD26
S TAPE D 0807 87-070-345-080 0E DIODE,1N4148 USC CSD-TD26
S TAPE D 0808 87-070-345-080 0E DIODE,1N4148 USC CSD-TD26
S TAPE IC 0801 87-A21-607-010 0E IC,NJM14558LD USC CSD-TD26
O TAPE L 0801 87-007-342-010 0E COIL,OSC 85KHZ BIAS USC CSD-TD26
S TAPE Q 0801 89-318-154-080 0E TR,2SC1815Y USC CSD-TD26
S TAPE Q 0810 87-026-464-080 0E TR,DTC114TS USC CSD-TD26
TAPE R 0801 88-118-820-080 0E C-RES,S 82-1/10W J USC CSD-TD26
TAPE R 0802 88-118-820-080 0E C-RES,S 82-1/10W J USC CSD-TD26
TAPE R 0803 88-121-472-080 0E RES,4.7K-1/8W J USC CSD-TD26
TAPE R 0804 88-121-472-080 0E RES,4.7K-1/8W J USC CSD-TD26
TAPE R 0805 88-121-184-080 0E RES,180K-1/8W J USC CSD-TD26
TAPE R 0806 88-121-184-080 0E RES,180K-1/8W J USC CSD-TD26
TAPE R 0808 88-130-221-080 0E RES,220-1/4W J USC CSD-TD26
TAPE R 0809 88-118-334-080 0E C-RES,S 330K-1/10W J USC CSD-TD26
TAPE R 0810 88-121-334-080 0E RES,330K-1/8W J USC CSD-TD26
TAPE R 0812 88-118-153-080 0E C-RES,S 15K-1/10W J USC CSD-TD26
TAPE R 0813 88-118-153-080 0E C-RES,S 15K-1/10W J USC CSD-TD26
TAPE R 0819 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
TAPE R 0820 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
TAPE R 0821 88-118-223-080 0E C-RES,S 22K-1/10W J USC CSD-TD26
TAPE R 0822 88-118-223-080 0E C-RES,S 22K-1/10W J USC CSD-TD26
TAPE R 0833 88-121-222-080 0E RES,2.2K-1/8W J USC CSD-TD26
TAPE R 0834 88-121-222-080 0E RES,2.2K-1/8W J USC CSD-TD26
O TAPE R 0840 87-029-124-010 0E RES,FUSE 2.2-1/4W J USC CSD-TD26
TAPE R 0842 88-118-471-080 0E C-RES,S 470-1/10W J USC CSD-TD26
TAPE R 0843 88-118-104-080 0E C-RES,S 100K-1/10W J USC CSD-TD26
TAPE R 0844 88-118-104-080 0E C-RES,S 100K-1/10W J USC CSD-TD26
TAPE R 0850 88-121-103-080 0E RES,10K-1/8W J USC CSD-TD26
TAPE R 0851 88-121-121-080 0E RES,120-1/8W J USC CSD-TD26
TAPE R 0863 88-130-151-080 0E RES,150-1/4W J USC CSD-TD26
O TAPE SW 0801 8Z-CD9-609-010 1A SW,SL 1-6-2 PS62D01 USC CSD-TD26
O TUNER C 0001 87-010-312-080 0E C-CAP,S 15P-50 J CH GRM USC CSD-TD26
O TUNER C 0002 87-010-316-080 0E C-CAP,S 33P-50 J CH GRM USC CSD-TD26
O TUNER C 0003 87-010-312-080 0E C-CAP,S 15P-50 J CH GRM USC CSD-TD26
O TUNER C 0005 87-012-360-080 0E C-CAP,S 1-10 Z F CM/CB USC CSD-TD26
O TUNER C 0007 87-014-049-080 0E CAP,PP 470P-100 J PL USC CSD-TD26
O TUNER C 0008 87-012-349-080 0E C-CAP,S 1000P-50 J CH GRM USC CSD-TD26
O TUNER C 0010 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O TUNER C 0011 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O TUNER C 0012 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O TUNER C 0013 87-010-150-080 0E C-CAP,S 6P-50 D CH USC CSD-TD26
O TUNER C 0014 87-010-303-080 0E C-CAP,330P-50 J CH USC CSD-TD26
O TUNER C 0015 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USC CSD-TD26
O TUNER C 0016 87-010-374-080 0E CAP,E 47-10 M 11L SME USC CSD-TD26
O TUNER C 0017 87-010-198-080 0E C-CAP,S 0.022-25 K B C2012 USC CSD-TD26
O TUNER C 0018 87-015-835-080 0E C-CAP,0.047-50 K B USC CSD-TD26
O TUNER C 0019 87-010-263-080 0E CAP,E 100-10 M 11L SME USC CSD-TD26
O TUNER C 0020 87-010-404-080 0E CAP,E 4.7-50 M 11L SME USC CSD-TD26
O TUNER C 0021 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O TUNER C 0022 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O TUNER C 0023 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O TUNER C 0024 87-010-303-080 0E C-CAP,330P-50 J CH USC CSD-TD26
O TUNER C 0025 87-016-460-080 0E C-CAP,S 0.22-16 K B USC CSD-TD26
O TUNER C 0027 87-A11-067-080 0E C-CAP,S 1-10 K B USC CSD-TD26
O TUNER C 0028 87-016-669-080 0E C-CAP,S 0.1-25 K B USC CSD-TD26
O TUNER C 0029 87-016-669-080 0E C-CAP,S 0.1-25 K B USC CSD-TD26
O TUNER C 0030 87-010-220-080 0E C-CAP,S 0.018-25 K B USC CSD-TD26
O TUNER C 0031 87-010-220-080 0E C-CAP,S 0.018-25 K B USC CSD-TD26
O TUNER C 0033 87-012-358-080 0E C-CAP,S 0.47-10 Z F CM/CB USC CSD-TD26
O TUNER C 0034 87-012-358-080 0E C-CAP,S 0.47-10 Z F CM/CB USC CSD-TD26
O TUNER C 0035 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O TUNER C 0036 87-010-263-080 0E CAP,E 100-10 M 11L SME USC CSD-TD26
O TUNER C 0037 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O TUNER C 0038 87-010-263-080 0E CAP,E 100-10 M 11L SME USC CSD-TD26

 12 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O TUNER C 0039 87-010-404-080 0E CAP,E 4.7-50 M 11L SME USC CSD-TD26
O TUNER C 0040 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O TUNER C 0041 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USC CSD-TD26
O TUNER C 0042 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USC CSD-TD26
O TUNER C 0043 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 USC CSD-TD26
O TUNER C 0044 87-010-311-080 0E C-CAP,S 12P-50 J CH GRM USC CSD-TD26
O TUNER C 0045 87-010-312-080 0E C-CAP,S 15P-50 J CH GRM USC CSD-TD26
O TUNER C 0046 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O TUNER C 0047 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O TUNER C 0048 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O TUNER C 0049 87-012-140-080 0E C-CAP,S 470P-50 J CH USC CSD-TD26
O TUNER C 0050 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O TUNER C 0051 87-010-316-080 0E C-CAP,S 33P-50 J CH GRM USC CSD-TD26
O TUNER C 0054 87-014-055-080 0E CAP,PP 820P-100 J PL USC CSD-TD26
O TUNER C 0056 87-010-312-080 0E C-CAP,S 15P-50 J CH GRM USC CSD-TD26
O TUNER C 0071 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O TUNER C 0072 87-010-263-080 0E CAP,E 100-10 M 11L SME USC CSD-TD26
O TUNER C 0073 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O TUNER C 0075 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O TUNER C 0091 87-012-140-080 0E C-CAP,S 470P-50 J CH USC CSD-TD26
O TUNER C 0092 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O TUNER C 0093 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 USC CSD-TD26
O TUNER CF 0001 87-A91-094-010 1A FLTR,CDA10.7 MG80A USC CSD-TD26
O TUNER CF 0002 87-008-261-010 1A FLTR,CF SFE10.7MA5 USC CSD-TD26
O TUNER CF 0003 87-008-261-010 1A FLTR,CF SFE10.7MA5 USC CSD-TD26
TUNER CN 0001 8Z-CT4-623-010 0E PIN,TESTDIA0.9-10 USC CSD-TD26
! O TUNER CN 0002 87-099-854-010 0E CONN,6P V S2M-6W USC CSD-TD26
! O TUNER CN 0003 87-A60-110-010 0E CONN,4P V S2M-4W USC CSD-TD26
TUNER CN 0004 8Z-CT4-623-010 0E PIN,TESTDIA0.9-10 USC CSD-TD26
TUNER CN 0005 8Z-CT4-623-010 0E PIN,TESTDIA0.9-10 USC CSD-TD26
TUNER CN 0006 8Z-CT4-623-010 0E PIN,TESTDIA0.9-10 USC CSD-TD26
TUNER CN 0007 8Z-CT4-623-010 0E PIN,TESTDIA0.9-10 USC CSD-TD26
S TUNER D 0001 87-070-345-080 0E DIODE,1N4148 USC CSD-TD26
S TUNER D 0002 87-070-345-080 0E DIODE,1N4148 USC CSD-TD26
O TUNER D 0003 87-A40-616-070 1B VARI-CAP,SVC384(S/T) USC CSD-TD26
O TUNER D 0004 87-A40-916-040 0E C-VARI-CAP,HVC202A USC CSD-TD26
O TUNER D 0005 87-A40-916-040 0E C-VARI-CAP,HVC202A USC CSD-TD26
S TUNER D 0006 87-017-090-080 0E ZENER,HZS5B3 USC CSD-TD26
O TUNER HD 0001 88-CD6-661-010 -- HLDR,BAR ANT. USC CSD-TD26
O TUNER HD 0002 88-CD6-661-010 -- HLDR,BAR ANT. USC CSD-TD26
S TUNER IC 0001 87-A21-550-010 1C IC,TA2149N USC CSD-TD26
S TUNER IC 0002 87-A21-928-010 1C IC,LC72131D-N USC CSD-TD26
TUNER JR 0001 88-129-000-080 0E C-JUMPER,3216 USC CSD-TD26
TUNER JR 0002 88-129-000-080 0E C-JUMPER,3216 USC CSD-TD26
TUNER JR 0003 88-129-000-080 0E C-JUMPER,3216 USC CSD-TD26
TUNER JR 0021 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
TUNER JR 0023 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
TUNER JR 0024 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
TUNER JR 0026 88-129-000-080 0E C-JUMPER,3216 USC CSD-TD26
TUNER JR 0027 88-129-000-080 0E C-JUMPER,3216 USC CSD-TD26
TUNER JR 0028 88-129-000-080 0E C-JUMPER,3216 USC CSD-TD26
TUNER JR 0029 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
TUNER JR 0030 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
TUNER JR 0031 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
TUNER JR 0032 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
TUNER JR 0033 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
TUNER JR 0034 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
TUNER JR 0035 88-129-000-080 0E C-JUMPER,3216 USC CSD-TD26
TUNER JR 0036 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
TUNER JR 0051 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
TUNER JR 0052 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
TUNER JR 0053 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
TUNER JR 0054 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
TUNER L 0001 88-100-000-080 0E PLATING-JW, 0.58 SN95 USC CSD-TD26
O TUNER L 0002 87-A50-560-010 0E COIL,FM BPF(ACD) USC CSD-TD26
O TUNER L 0003 8A-CH4-670-010 1A BAR-ANT,MW 2B-ACH(COI) USC CSD-TD26
O TUNER L 0004 87-A50-420-010 1E COIL,MW OSC(SYN) USC CSD-TD26
O TUNER L 0005 87-A50-566-010 0E COIL,FM RF E (ACH) USC CSD-TD26
O TUNER L 0006 87-A50-567-010 0E COIL,FM OSC(ACH) USC CSD-TD26
O TUNER L 0007 87-A91-308-010 0E FLTR,PCFAZH- 450T (TOK) USC CSD-TD26

 13 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O TUNER L 0008 87-005-849-080 0E COIL,10UH K CECS USC CSD-TD26
S TUNER Q 0001 89-327-143-080 0E C-TR,2SC2714O USC CSD-TD26
S TUNER Q 0002 87-026-447-080 0E TR,2SC1740SR USC CSD-TD26
S TUNER Q 0003 89-111-624-080 0E C-TR,2SA1162Y USC CSD-TD26
S TUNER Q 0004 87-A30-288-040 0E C-TR,DTC114YKA USC CSD-TD26
S TUNER Q 0051 89-503-025-010 1A C-FET,2SK302GR USC CSD-TD26
S TUNER Q 0052 87-026-447-080 0E TR,2SC1740SR USC CSD-TD26
S TUNER Q 0054 87-A30-283-040 0E C-TR,DTA114YKA USC CSD-TD26
S TUNER Q 0071 89-327-125-080 0E C-TR,2SC2712GR USC CSD-TD26
TUNER R 0001 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
TUNER R 0002 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
TUNER R 0003 88-118-104-080 0E C-RES,S 100K-1/10W J USC CSD-TD26
TUNER R 0004 88-118-473-080 0E C-RES,S 47K-1/10W J USC CSD-TD26
TUNER R 0006 88-118-472-080 0E C-RES,S 4.7K-1/10W J USC CSD-TD26
TUNER R 0008 88-118-470-080 0E C-RES,S 47-1/10W J USC CSD-TD26
TUNER R 0009 88-118-331-080 0E C-RES,S 330-1/10W J USC CSD-TD26
TUNER R 0010 88-118-152-080 0E C-RES,S 1.5K-1/10W J USC CSD-TD26
TUNER R 0011 88-118-473-080 0E C-RES,S 47K-1/10W J USC CSD-TD26
TUNER R 0012 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
TUNER R 0013 88-118-331-080 0E C-RES,S 330-1/10W J USC CSD-TD26
TUNER R 0014 88-118-332-080 0E C-RES,S 3.3K-1/10W J USC CSD-TD26
TUNER R 0015 88-121-472-080 0E RES,4.7K-1/8W J USC CSD-TD26
TUNER R 0016 88-118-472-080 0E C-RES,S 4.7K-1/10W J USC CSD-TD26
TUNER R 0017 88-118-472-080 0E C-RES,S 4.7K-1/10W J USC CSD-TD26
TUNER R 0020 88-118-471-080 0E C-RES,S 470-1/10W J USC CSD-TD26
TUNER R 0021 88-118-271-080 0E C-RES,S 270-1/10W J USC CSD-TD26
TUNER R 0022 88-118-562-080 0E C-RES,S 5.6K-1/10W J USC CSD-TD26
TUNER R 0023 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
TUNER R 0024 88-118-681-080 0E C-RES,S 680-1/10W J USC CSD-TD26
TUNER R 0025 88-118-222-080 0E C-RES,S 2.2K-1/10W J USC CSD-TD26
TUNER R 0027 88-118-472-080 0E C-RES,S 4.7K-1/10W J USC CSD-TD26
TUNER R 0028 88-118-472-080 0E C-RES,S 4.7K-1/10W J USC CSD-TD26
TUNER R 0029 88-118-472-080 0E C-RES,S 4.7K-1/10W J USC CSD-TD26
TUNER R 0030 88-118-472-080 0E C-RES,S 4.7K-1/10W J USC CSD-TD26
TUNER R 0031 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
TUNER R 0033 88-118-100-080 0E C-RES,S 10-1/10W J USC CSD-TD26
TUNER R 0034 88-118-273-080 0E C-RES,S 27K-1/10W J USC CSD-TD26
TUNER R 0035 88-118-100-080 0E C-RES,S 10-1/10W J USC CSD-TD26
TUNER R 0035 88-118-222-080 0E C-RES,S 2.2K-1/10W J USC CSD-TD26
TUNER R 0036 88-118-472-080 0E C-RES,S 4.7K-1/10W J USC CSD-TD26
TUNER R 0037 88-118-104-080 0E C-RES,S 100K-1/10W J USC CSD-TD26
TUNER R 0039 88-118-104-080 0E C-RES,S 100K-1/10W J USC CSD-TD26
TUNER R 0041 88-118-330-080 0E C-RES,S 33-1/10W J USC CSD-TD26
TUNER R 0051 88-118-471-080 0E C-RES,S 470-1/10W J USC CSD-TD26
TUNER R 0053 88-118-101-080 0E C-RES,S 100-1/10W J USC CSD-TD26
TUNER R 0054 88-118-103-080 0E C-RES,S 10K-1/10W J USC CSD-TD26
TUNER R 0055 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
TUNER R 0056 88-118-472-080 0E C-RES,S 4.7K-1/10W J USC CSD-TD26
TUNER R 0057 88-118-102-080 0E C-RES,S 1K-1/10W J USC CSD-TD26
TUNER R 0072 88-118-222-080 0E C-RES,S 2.2K-1/10W J USC CSD-TD26
TUNER R 0073 88-118-103-080 0E C-RES,S 10K-1/10W J USC CSD-TD26
TUNER R 0074 88-118-000-080 0E C-JUMPER,S USC CSD-TD26
TUNER R 0075 88-118-472-080 0E C-RES,S 4.7K-1/10W J USC CSD-TD26
TUNER R 0099 88-118-334-080 0E C-RES,S 330K-1/10W J USC CSD-TD26
TUNER SH 0001 88-ZA1-605-010 -- SHLD-CASE,IFT CAP-CASE USC CSD-TD26
O TUNER TC 0001 87-011-254-080 0E TRIMMER,CER 20P 4.0 4.5 ECR USC CSD-TD26
O TUNER TC 0051 87-A91-659-010 0E TRIMMER,50P 4.0 4.5 ECRL USC CSD-TD26
O TUNER 0001 87-A70-061-010 1A VIB, TAL 4.500MHZ CSA-309 USC CSD-TD26

 14 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
! O ACCESSORY 87-A80-109-010 1C AC CORD,HK7281 BLK U UWC CSD-TD27
O APPEARANCE 8B-CDA-009-010 -- WINDOW,CASS UWC CSD-TD27
O APPEARANCE 8B-CDA-063-010 -- CHAS,CD (W) UWC CSD-TD27
APPEARANCE 8B-CDA-064-010 -- GRILLE,SPKR L (W) UWC CSD-TD27
APPEARANCE 8B-CDA-065-010 -- GRILLE,SPKR R (W) UWC CSD-TD27
O APPEARANCE 8B-CDL-008-010 -- PANEL,TOP UWC CSD-TD27
O APPEARANCE 8B-CHA-015-010 -- WINDOW,DISP U UWC CSD-TD27
O APPEARANCE 8B-CHA-016-010 -- CABI ASSY,FRONT U W UWC CSD-TD27
O APPEARANCE 8B-CHA-020-010 -- LID,BATT W UWC CSD-TD27
O APPEARANCE 8B-CHA-021-010 -- HANDL,ARM W UWC CSD-TD27
O APPEARANCE 8B-CHA-022-010 -- LID,HANDL W UWC CSD-TD27
O APPEARANCE * 8B-CDA-006-010 -- LID,CD UWC CSD-TD27
O APPEARANCE * 8B-CDA-132-010 -- LID,CASS U (W) UWC CSD-TD27
APPEARANCE * 8B-CHA-017-010 -- CABI,FRONT U W UWC CSD-TD27
O APPEARANCE * 8B-CHA-018-010 -- CABI,REAR U W UWC CSD-TD27
! O CD M8-ZZK-E90-070 2Y DA11T3C UWC CSD-TD27
O CD C 0401 87-010-403-080 0E CAP,E 3.3-50 M 11L SME UWC CSD-TD27
O CD C 0402 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 UWC CSD-TD27
O CD C 0403 87-010-263-080 0E CAP,E 100-10 M 11L SME UWC CSD-TD27
O CD C 0404 87-010-248-080 0E CAP,E 220-10 M 11L SME UWC CSD-TD27
O CD C 0405 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 UWC CSD-TD27
O CD C 0406 87-010-374-080 0E CAP,E 47-10 M 11L SME UWC CSD-TD27
O CD C 0407 87-018-131-080 0E CAP,TC U 1000P-50 K B UP050 UWC CSD-TD27
O CD C 0408 87-010-198-080 0E C-CAP,S 0.022-25 K B C2012 UWC CSD-TD27
O CD C 0409 87-010-248-080 0E CAP,E 220-10 M 11L SME UWC CSD-TD27
O CD C 0410 87-010-263-080 0E CAP,E 100-10 M 11L SME UWC CSD-TD27
O CD C 0411 87-A11-177-080 0E C-CAP,S 0.15-16 K B UWC CSD-TD27
O CD C 0412 87-010-401-080 0E CAP,E 1-50 M 11L SME UWC CSD-TD27
O CD C 0413 87-016-369-080 0E C-CAP,S 0.033-25 K B GRM UWC CSD-TD27
O CD C 0414 87-010-405-080 0E CAP,E 10-50 M 11L SME UWC CSD-TD27
O CD C 0416 87-010-545-080 0E CAP,E 0.22-50 M 11L SME UWC CSD-TD27
O CD C 0417 87-012-157-080 0E C-CAP,S 330P-50 J CH GRM UWC CSD-TD27
O CD C 0418 87-010-213-080 0E C-CAP,S 0.015-25 K B GRM UWC CSD-TD27
O CD C 0419 87-A11-608-080 0E C-CAP,S 0.33-25 K B UWC CSD-TD27
O CD C 0420 87-016-369-080 0E C-CAP,S 0.033-25 K B GRM UWC CSD-TD27
O CD C 0421 87-A11-177-080 0E C-CAP,S 0.15-16 K B UWC CSD-TD27
O CD C 0422 87-010-184-080 0E C-CAP,S 3300P-50 K B C2012 UWC CSD-TD27
O CD C 0423 87-010-992-080 0E C-CAP,S 0.047-25 K B MK212 UWC CSD-TD27
O CD C 0424 87-A11-606-080 0E C-CAP,S 0.22-25 K B UWC CSD-TD27
O CD C 0425 87-018-129-080 0E CAP,TC U 680P-50 K B UP050 UWC CSD-TD27
O CD C 0426 87-A11-608-080 0E C-CAP,S 0.33-25 K B UWC CSD-TD27
O CD C 0428 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 UWC CSD-TD27
O CD C 0429 87-010-186-080 0E C-CAP,S 4700P-50 K B C2012 UWC CSD-TD27
O CD C 0430 87-012-156-080 0E C-CAP,S 220P-50 J CH GRM UWC CSD-TD27
O CD C 0431 87-010-545-080 0E CAP,E 0.22-50 M 11L SME UWC CSD-TD27
O CD C 0432 87-010-374-080 0E CAP,E 47-10 M 11L SME UWC CSD-TD27
O CD C 0433 87-010-401-080 0E CAP,E 1-50 M 11L SME UWC CSD-TD27
O CD C 0434 87-010-184-080 0E C-CAP,S 3300P-50 K B C2012 UWC CSD-TD27
O CD C 0435 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 UWC CSD-TD27
O CD C 0436 87-010-374-080 0E CAP,E 47-10 M 11L SME UWC CSD-TD27
O CD C 0437 87-010-404-080 0E CAP,E 4.7-50 M 11L SME UWC CSD-TD27
O CD C 0438 87-016-669-080 0E C-CAP,S 0.1-25 K B UWC CSD-TD27
O CD C 0439 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 UWC CSD-TD27
O CD C 0440 87-018-139-080 0E CAP,TC U 1P-50 M CH UP050 UWC CSD-TD27
O CD C 0441 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 UWC CSD-TD27
O CD C 0442 87-018-109-080 0E CAP,TC U 22P-50 J SL UP050 UWC CSD-TD27
O CD C 0445 87-012-368-080 0E C-CAP,S 0.1-50 Z F UWC CSD-TD27
O CD C 0446 87-012-368-080 0E C-CAP,S 0.1-50 Z F UWC CSD-TD27
O CD C 0447 87-012-368-080 0E C-CAP,S 0.1-50 Z F UWC CSD-TD27
O CD C 0448 87-010-315-080 0E C-CAP,S 27P-50 J CH GRM UWC CSD-TD27
O CD C 0451 87-012-156-080 0E C-CAP,S 220P-50 J CH GRM UWC CSD-TD27
O CD C 0455 87-010-247-080 0E CAP,E 100-50 M SME UWC CSD-TD27
O CD C 0457 87-010-312-080 0E C-CAP,S 15P-50 J CH GRM UWC CSD-TD27
O CD C 0458 87-010-312-080 0E C-CAP,S 15P-50 J CH GRM UWC CSD-TD27
O CD C 0459 87-010-263-080 0E CAP,E 100-10 M 11L SME UWC CSD-TD27
O CD C 0460 87-015-819-080 0E C-CAP, 0.01-50 K B C3216 UWC CSD-TD27
O CD C 0461 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 UWC CSD-TD27
O CD C 0462 87-010-248-080 0E CAP,E 220-10 M 11L SME UWC CSD-TD27
O CD C 0463 87-A11-132-080 0E CAP,TC U 0.01-50 K B UWC CSD-TD27
O CD C 0465 87-010-404-080 0E CAP,E 4.7-50 M 11L SME UWC CSD-TD27

 15 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O CD C 0466 87-012-368-080 0E C-CAP,S 0.1-50 Z F UWC CSD-TD27
O CD C 0467 87-010-263-080 0E CAP,E 100-10 M 11L SME UWC CSD-TD27
O CD C 0469 87-012-154-080 0E C-CAP,S 150P-50 J CH GRM UWC CSD-TD27
O CD C 0471 87-018-209-080 0E CAP,TC U 0.1-50 Z F UP050 UWC CSD-TD27
O CD C 0472 87-015-785-080 0E C-CAP, 0.1-25 Z F C3216 UWC CSD-TD27
O CD C 0473 87-015-785-080 0E C-CAP, 0.1-25 Z F C3216 UWC CSD-TD27
O CD C 0474 87-015-785-080 0E C-CAP, 0.1-25 Z F C3216 UWC CSD-TD27
O CD C 0475 87-A11-132-080 0E CAP,TC U 0.01-50 K B UWC CSD-TD27
O CD C 0476 87-010-236-080 0E CAP,E 1000-10 M SME UWC CSD-TD27
O CD C 0477 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 UWC CSD-TD27
O CD C 0478 87-010-263-080 0E CAP,E 100-10 M 11L SME UWC CSD-TD27
O CD C 0479 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 UWC CSD-TD27
O CD C 0480 87-010-221-080 0E CAP,E 470-10 M SME UWC CSD-TD27
O CD C 0481 87-010-405-080 0E CAP,E 10-50 M 11L SME UWC CSD-TD27
O CD C 0482 87-010-405-080 0E CAP,E 10-50 M 11L SME UWC CSD-TD27
O CD C 0489 87-012-368-080 0E C-CAP,S 0.1-50 Z F UWC CSD-TD27
O CD C 0490 87-012-368-080 0E C-CAP,S 0.1-50 Z F UWC CSD-TD27
O CD C 0493 87-010-180-080 0E C-CAP,S 1500P-50 K B C2012 UWC CSD-TD27
O CD C 0501 87-012-368-080 0E C-CAP,S 0.1-50 Z F UWC CSD-TD27
O CD C 0502 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM UWC CSD-TD27
O CD C 0503 87-018-119-080 0E CAP,TC U 100P-50 K B UP050 UWC CSD-TD27
O CD C 0504 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM UWC CSD-TD27
O CD C 0505 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM UWC CSD-TD27
O CD C 0506 87-010-322-080 0E C-CAP,S 100P-50 J CH GRM UWC CSD-TD27
O CD C 0510 87-016-669-080 0E C-CAP,S 0.1-25 K B UWC CSD-TD27
! O CD CN 0205 87-A60-109-010 0E CONN,2P V S2M-2W UWC CSD-TD27
! O CD CN 0401 87-A60-424-010 0E CONN,16P V TOC-B UWC CSD-TD27
! O CD CN 0403 87-099-201-010 0E CONN,8P H BLK 6216 UWC CSD-TD27
O CD CNA0402 8B-CDA-625-010 -- CONN ASSY,6P CD-ME UWC CSD-TD27
S CD D 0401 87-070-345-080 0E DIODE,1N4148 UWC CSD-TD27
S CD D 0402 87-070-345-080 0E DIODE,1N4148 UWC CSD-TD27
S CD D 0403 87-070-345-080 0E DIODE,1N4148 UWC CSD-TD27
S CD IC 0401 87-A20-446-010 1E C-IC,LA9241ML UWC CSD-TD27
S CD IC 0402 87-A21-319-010 2A C-IC,LC78622NE UWC CSD-TD27
S CD IC 0404 87-A21-891-010 1C C-IC,MM1469 H UWC CSD-TD27
O CD L 0401 87-003-102-080 0E COIL,10UH J LAL02 UWC CSD-TD27
CD L 0402 88-100-000-010 0E PLATING-JW, 0.58 SN95 UWC CSD-TD27
O CD L 0404 87-003-152-080 0E COIL,100UH J LAL02 UWC CSD-TD27
CD L 0405 88-100-000-010 0E PLATING-JW, 0.58 SN95 UWC CSD-TD27
S CD Q 0401 89-109-332-380 0E TR,2SA933RS UWC CSD-TD27
S CD Q 0402 87-A30-515-080 0E TR,2SA1979O/Y UWC CSD-TD27
S CD Q 0403 87-A30-287-040 0E C-TR,DTC114TKA UWC CSD-TD27
S CD Q 0406 87-A30-287-040 0E C-TR,DTC114TKA UWC CSD-TD27
S CD Q 0407 87-A30-288-040 0E C-TR,DTC114YKA UWC CSD-TD27
S CD Q 0408 87-A30-288-040 0E C-TR,DTC114YKA UWC CSD-TD27
CD R 0401 88-118-101-080 0E C-RES,S 100-1/10W J UWC CSD-TD27
CD R 0402 88-118-100-080 0E C-RES,S 10-1/10W J UWC CSD-TD27
CD R 0403 88-118-123-080 0E C-RES,S 12K-1/10W J UWC CSD-TD27
CD R 0405 88-118-104-080 0E C-RES,S 100K-1/10W J UWC CSD-TD27
CD R 0406 88-118-332-080 0E C-RES,S 3.3K-1/10W J UWC CSD-TD27
CD R 0407 88-118-000-080 0E C-JUMPER,S UWC CSD-TD27
CD R 0408 88-118-683-080 0E C-RES,S 68K-1/10W J UWC CSD-TD27
CD R 0409 88-118-222-080 0E C-RES,S 2.2K-1/10W J UWC CSD-TD27
CD R 0410 88-118-273-080 0E C-RES,S 27K-1/10W J UWC CSD-TD27
CD R 0411 88-118-561-080 0E C-RES,S 560-1/10W J UWC CSD-TD27
CD R 0412 88-118-224-080 0E C-RES,S 220K-1/10W J UWC CSD-TD27
CD R 0413 88-118-153-080 0E C-RES,S 15K-1/10W J UWC CSD-TD27
CD R 0414 88-118-332-080 0E C-RES,S 3.3K-1/10W J UWC CSD-TD27
CD R 0415 88-118-223-080 0E C-RES,S 22K-1/10W J UWC CSD-TD27
CD R 0417 88-118-123-080 0E C-RES,S 12K-1/10W J UWC CSD-TD27
CD R 0418 88-118-473-080 0E C-RES,S 47K-1/10W J UWC CSD-TD27
CD R 0419 88-118-152-080 0E C-RES,S 1.5K-1/10W J UWC CSD-TD27
CD R 0420 88-118-332-080 0E C-RES,S 3.3K-1/10W J UWC CSD-TD27
CD R 0421 88-121-184-080 0E RES,180K-1/8W J UWC CSD-TD27
CD R 0423 88-118-104-080 0E C-RES,S 100K-1/10W J UWC CSD-TD27
CD R 0424 88-118-122-080 0E C-RES,S 1.2K-1/10W J UWC CSD-TD27
CD R 0425 88-118-563-080 0E C-RES,S 56K-1/10W J UWC CSD-TD27
CD R 0426 88-118-123-080 0E C-RES,S 12K-1/10W J UWC CSD-TD27
CD R 0427 88-118-682-080 0E C-RES,S 6.8K-1/10W J UWC CSD-TD27
CD R 0428 88-118-101-080 0E C-RES,S 100-1/10W J UWC CSD-TD27

 16 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
CD R 0429 88-118-152-080 0E C-RES,S 1.5K-1/10W J UWC CSD-TD27
CD R 0430 88-121-682-080 0E RES,6.8K-1/8W J UWC CSD-TD27
CD R 0431 88-121-274-080 0E RES,270K-1/8W J UWC CSD-TD27
CD R 0432 88-121-274-080 0E RES,270K-1/8W J UWC CSD-TD27
CD R 0433 88-118-472-080 0E C-RES,S 4.7K-1/10W J UWC CSD-TD27
CD R 0434 88-118-473-080 0E C-RES,S 47K-1/10W J UWC CSD-TD27
CD R 0435 88-118-223-080 0E C-RES,S 22K-1/10W J UWC CSD-TD27
CD R 0436 88-121-822-080 0E RES,8.2K-1/8W J UWC CSD-TD27
CD R 0437 88-121-103-080 0E RES,10K-1/8W J UWC CSD-TD27
CD R 0438 88-118-681-080 0E C-RES,S 680-1/10W J UWC CSD-TD27
CD R 0439 88-118-153-080 0E C-RES,S 15K-1/10W J UWC CSD-TD27
CD R 0440 88-118-331-080 0E C-RES,S 330-1/10W J UWC CSD-TD27
CD R 0441 88-118-681-080 0E C-RES,S 680-1/10W J UWC CSD-TD27
CD R 0442 88-118-273-080 0E C-RES,S 27K-1/10W J UWC CSD-TD27
CD R 0443 88-118-122-080 0E C-RES,S 1.2K-1/10W J UWC CSD-TD27
CD R 0444 88-118-333-080 0E C-RES,S 33K-1/10W J UWC CSD-TD27
CD R 0445 88-118-153-080 0E C-RES,S 15K-1/10W J UWC CSD-TD27
CD R 0446 88-118-183-080 0E C-RES,S 18K-1/10W J UWC CSD-TD27
CD R 0447 88-118-123-080 0E C-RES,S 12K-1/10W J UWC CSD-TD27
CD R 0449 88-100-000-010 0E PLATING-JW, 0.58 SN95 UWC CSD-TD27
CD R 0451 88-118-272-080 0E C-RES,S 2.7K-1/10W J UWC CSD-TD27
CD R 0452 88-118-102-080 0E C-RES,S 1K-1/10W J UWC CSD-TD27
CD R 0453 88-118-332-080 0E C-RES,S 3.3K-1/10W J UWC CSD-TD27
CD R 0455 88-118-101-080 0E C-RES,S 100-1/10W J UWC CSD-TD27
CD R 0456 88-118-821-080 0E C-RES,S 820-1/10W J UWC CSD-TD27
CD R 0457 88-118-153-080 0E C-RES,S 15K-1/10W J UWC CSD-TD27
CD R 0459 88-121-392-080 0E RES,3.9K-1/8W J UWC CSD-TD27
CD R 0460 88-121-392-080 0E RES,3.9K-1/8W J UWC CSD-TD27
CD R 0465 88-118-680-080 0E C-RES,S 68-1/10W J UWC CSD-TD27
CD R 0466 88-121-101-080 0E RES,100-1/8W J UWC CSD-TD27
CD R 0467 88-121-333-080 0E RES,33K-1/8W J UWC CSD-TD27
CD R 0469 88-118-473-080 0E C-RES,S 47K-1/10W J UWC CSD-TD27
CD R 0471 88-100-000-010 0E PLATING-JW, 0.58 SN95 UWC CSD-TD27
CD R 0472 88-128-000-080 0E C-JUMPER,3216 UWC CSD-TD27
CD R 0473 88-128-000-080 0E C-JUMPER,3216 UWC CSD-TD27
CD R 0474 88-128-000-080 0E C-JUMPER,3216 UWC CSD-TD27
CD R 0475 88-121-101-080 0E RES,100-1/8W J UWC CSD-TD27
CD R 0476 88-118-229-080 0E C-RES,S 2.2-1/10W J UWC CSD-TD27
CD R 0478 88-118-154-080 0E C-RES,S 150K-1/10W J UWC CSD-TD27
CD R 0479 88-118-153-080 0E C-RES,S 15K-1/10W J UWC CSD-TD27
CD R 0480 88-118-102-080 0E C-RES,S 1K-1/10W J UWC CSD-TD27
CD R 0485 88-118-153-080 0E C-RES,S 15K-1/10W J UWC CSD-TD27
CD R 0486 88-118-153-080 0E C-RES,S 15K-1/10W J UWC CSD-TD27
CD R 0487 88-118-153-080 0E C-RES,S 15K-1/10W J UWC CSD-TD27
CD R 0488 88-118-154-080 0E C-RES,S 150K-1/10W J UWC CSD-TD27
CD R 0489 88-118-101-080 0E C-RES,S 100-1/10W J UWC CSD-TD27
CD R 0493 88-118-000-080 0E C-JUMPER,S UWC CSD-TD27
CD R 0495 88-118-122-080 0E C-RES,S 1.2K-1/10W J UWC CSD-TD27
CD R 0496 88-118-122-080 0E C-RES,S 1.2K-1/10W J UWC CSD-TD27
CD R 0497 88-118-682-080 0E C-RES,S 6.8K-1/10W J UWC CSD-TD27
CD R 0498 88-118-682-080 0E C-RES,S 6.8K-1/10W J UWC CSD-TD27
CD R 0499 88-121-823-080 0E RES,82K-1/8W J UWC CSD-TD27
CD R 0501 88-121-101-080 0E RES,100-1/8W J UWC CSD-TD27
CD R 0502 88-121-101-080 0E RES,100-1/8W J UWC CSD-TD27
CD R 0503 88-121-101-080 0E RES,100-1/8W J UWC CSD-TD27
CD R 0504 88-121-101-080 0E RES,100-1/8W J UWC CSD-TD27
CD R 0505 88-121-101-080 0E RES,100-1/8W J UWC CSD-TD27
CD R 0506 88-121-101-080 0E RES,100-1/8W J UWC CSD-TD27
CD R 0530 88-121-104-080 0E RES,100K-1/8W J UWC CSD-TD27
CD R 0531 88-118-104-080 0E C-RES,S 100K-1/10W J UWC CSD-TD27
CD R 0532 88-121-104-080 0E RES,100K-1/8W J UWC CSD-TD27
O CD SFR0430 87-024-437-080 0E SFR,100K H RH063MC UWC CSD-TD27
O CD 0401 8Z-CD5-633-010 1B VIB, CER16.93MHZ FCR16.93M2 UWC CSD-TD27
O ELECTRICAL 87-A91-857-010 1B ANT,ROD 5SEC709 UWC CSD-TD27
ELECTRICAL 89-920-050-110 0E WIRE,UD0-5-3 UWC CSD-TD27
ELECTRICAL 8B-CDA-207-010 -- SH,FIBER UWC CSD-TD27
O ELECTRICAL 8B-CDA-615-010 -- SPKR,10 7OHM UWC CSD-TD27
O ELECTRICAL * 87-036-389-010 1B SW,PUSH 1-1-1 R8120125 UWC CSD-TD27
! O ELECTRICAL * 87-A60-177-010 1A JACK,AC U BLK W/SW UWC CSD-TD27
ELECTRICAL * 8A-CH4-602-010 -- HT-SINK,REG UWC CSD-TD27

 17 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
ELECTRICAL * 8A-CH4-603-010 -- HT-SINK,MAIN 2.5W UWC CSD-TD27
O ELECTRICAL * 8Z-CD5-634-010 1C COVER,AC SOCKET UWC CSD-TD27
O ELECTRICAL CNA 8B-CDA-626-010 -- CONN ASSY,2P DOOR UWC CSD-TD27
O ELECTRICAL CNA 8B-CDA-630-010 -- CONN ASSY,4P RPH UWC CSD-TD27
O ELECTRICAL CNA 8B-CDA-631-010 -- CONN ASSY,4P TA-ME UWC CSD-TD27
O ELECTRICAL CNA 8B-CDA-633-010 -- CONN ASSY,4P SP UWC CSD-TD27
! O ELECTRICAL PT 0901 8A-CDA-611-010 1H PT,U 2.5W UWC CSD-TD27
O ELECTRICAL W 8B-CDA-622-010 -- FF-CABLE,8P CD-FR UWC CSD-TD27
ELECTRICAL W 8B-CDA-634-010 -- WIRE, RED AC JACK UWC CSD-TD27
ELECTRICAL W 8B-CDA-635-010 -- WIRE, YEL AC JACK UWC CSD-TD27
ELECTRICAL W 8B-CDA-636-010 -- WIRE, ORG AC JACK UWC CSD-TD27
ELECTRICAL W 8B-CDA-637-010 -- WIRE, FASTON ASSY ANT UWC CSD-TD27
O ELECTRICAL W 0901 8B-CDA-620-010 -- FF-CABLE,16P FR-MAIN UWC CSD-TD27
O ELECTRICAL W 0901 8B-CDA-621-010 -- FF-CABLE,16P CD-RF UWC CSD-TD27
O FUNC/BUFF C 0211 87-A11-603-080 0E C-CAP,S 0.15-16 K B UWC CSD-TD27
O FUNC/BUFF C 0212 87-A11-603-080 0E C-CAP,S 0.15-16 K B UWC CSD-TD27
O FUNC/BUFF C 0215 87-016-460-080 0E C-CAP,S 0.22-16 K B UWC CSD-TD27
O FUNC/BUFF C 0216 87-016-460-080 0E C-CAP,S 0.22-16 K B UWC CSD-TD27
O FUNC/BUFF C 0231 87-010-213-080 0E C-CAP,S 0.015-25 K B GRM UWC CSD-TD27
O FUNC/BUFF C 0232 87-010-213-080 0E C-CAP,S 0.015-25 K B GRM UWC CSD-TD27
O FUNC/BUFF C 0233 87-A10-201-080 0E C-CAP,S 0.33-16 K B UWC CSD-TD27
O FUNC/BUFF C 0234 87-A10-201-080 0E C-CAP,S 0.33-16 K B UWC CSD-TD27
O FUNC/BUFF C 0235 87-016-669-080 0E C-CAP,S 0.1-25 K B UWC CSD-TD27
O FUNC/BUFF C 0236 87-016-669-080 0E C-CAP,S 0.1-25 K B UWC CSD-TD27
O FUNC/BUFF C 0237 87-010-371-080 0E CAP,E 470-6.3 M SME UWC CSD-TD27
O FUNC/BUFF C 0239 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 UWC CSD-TD27
O FUNC/BUFF C 0240 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 UWC CSD-TD27
O FUNC/BUFF C 0247 87-010-401-080 0E CAP,E 1-50 M 11L SME UWC CSD-TD27
O FUNC/BUFF C 0248 87-010-401-080 0E CAP,E 1-50 M 11L SME UWC CSD-TD27
O FUNC/BUFF C 0310 87-010-248-080 0E CAP,E 220-10 M 11L SME UWC CSD-TD27
O FUNC/BUFF C 0316 87-010-263-080 0E CAP,E 100-10 M 11L SME UWC CSD-TD27
O FUNC/BUFF C 0317 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 UWC CSD-TD27
S FUNC/BUFF D 0307 87-A40-234-080 0E ZENER,MTZJ5.6A UWC CSD-TD27
S FUNC/BUFF IC 0203 87-A21-520-040 1E C-IC,M61509FP UWC CSD-TD27
S FUNC/BUFF Q 0306 89-318-154-080 0E TR,2SC1815Y UWC CSD-TD27
FUNC/BUFF R 0203 88-118-000-080 0E C-JUMPER,S UWC CSD-TD27
FUNC/BUFF R 0204 88-118-000-080 0E C-JUMPER,S UWC CSD-TD27
FUNC/BUFF R 0215 88-118-472-080 0E C-RES,S 4.7K-1/10W J UWC CSD-TD27
FUNC/BUFF R 0216 88-118-472-080 0E C-RES,S 4.7K-1/10W J UWC CSD-TD27
FUNC/BUFF R 0217 88-118-000-080 0E C-JUMPER,S UWC CSD-TD27
FUNC/BUFF R 0218 88-118-000-080 0E C-JUMPER,S UWC CSD-TD27
FUNC/BUFF R 0227 88-118-472-080 0E C-RES,S 4.7K-1/10W J UWC CSD-TD27
FUNC/BUFF R 0228 88-118-472-080 0E C-RES,S 4.7K-1/10W J UWC CSD-TD27
FUNC/BUFF R 0231 88-118-222-080 0E C-RES,S 2.2K-1/10W J UWC CSD-TD27
FUNC/BUFF R 0232 88-118-222-080 0E C-RES,S 2.2K-1/10W J UWC CSD-TD27
FUNC/BUFF R 0233 88-121-102-080 0E RES,1K-1/8W J UWC CSD-TD27
FUNC/BUFF R 0234 88-118-103-080 0E C-RES,S 10K-1/10W J UWC CSD-TD27
FUNC/BUFF R 0235 88-118-392-080 0E C-RES,S 3.9K-1/10W J UWC CSD-TD27
FUNC/BUFF R 0236 88-118-472-080 0E C-RES,S 4.7K-1/10W J UWC CSD-TD27
FUNC/BUFF R 0237 88-121-102-080 0E RES,1K-1/8W J UWC CSD-TD27
FUNC/BUFF R 0241 88-121-473-080 0E RES,47K-1/8W J UWC CSD-TD27
FUNC/BUFF R 0242 88-118-473-080 0E C-RES,S 47K-1/10W J UWC CSD-TD27
FUNC/BUFF R 0243 88-121-183-080 0E RES,18K-1/8W J UWC CSD-TD27
FUNC/BUFF R 0244 88-118-183-080 0E C-RES,S 18K-1/10W J UWC CSD-TD27
FUNC/BUFF R 0245 88-121-223-080 0E RES,22K-1/8W J UWC CSD-TD27
FUNC/BUFF R 0246 88-118-223-080 0E C-RES,S 22K-1/10W J UWC CSD-TD27
FUNC/BUFF R 0310 88-121-331-080 0E RES,330-1/8W J UWC CSD-TD27
FUNC/BUFF R 0481 88-121-334-080 0E RES,330K-1/8W J UWC CSD-TD27
FUNC/BUFF R 0482 88-118-334-080 0E C-RES,S 330K-1/10W J UWC CSD-TD27
FUNC/BUFF R 0815 88-121-223-080 0E RES,22K-1/8W J UWC CSD-TD27
FUNC/BUFF R 0816 88-121-223-080 0E RES,22K-1/8W J UWC CSD-TD27
FUNC/BUFF R 0925 88-118-563-080 0E C-RES,S 56K-1/10W J UWC CSD-TD27
FUNC/BUFF R 0926 88-118-563-080 0E C-RES,S 56K-1/10W J UWC CSD-TD27
O KNOB 8B-CDA-014-010 -- KEY,CD UWC CSD-TD27
O KNOB 8B-CDA-016-010 -- KEY,FUNC B UWC CSD-TD27
O KNOB 8B-CDA-019-010 -- KEY,PAUSE UWC CSD-TD27
O KNOB 8B-CDA-020-010 -- KEY,STOP UWC CSD-TD27
O KNOB 8B-CDA-021-010 -- KEY,FF UWC CSD-TD27
O KNOB 8B-CDA-022-010 -- KEY,REW UWC CSD-TD27
O KNOB 8B-CDA-023-010 -- KEY,PLAY UWC CSD-TD27

 18 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
O KNOB 8B-CDA-024-010 -- KEY,REC UWC CSD-TD27
O KNOB 8B-CHA-029-010 -- KEY,FUNC E UWC CSD-TD27
LBL,POP 8B-CHA-970-010 -- LBL,POP U UWC CSD-TD27
O MICON C 0601 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 UWC CSD-TD27
O MICON C 0602 87-010-555-040 0E CAP,E 100-10 M 5L SRE UWC CSD-TD27
O MICON C 0603 87-A10-189-040 0E CAP,E 220-10 M 5L UWC CSD-TD27
O MICON C 0604 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 UWC CSD-TD27
O MICON C 0605 87-018-150-080 0E CAP,TC U 18P-50 J CH UP050 UWC CSD-TD27
O MICON C 0606 87-018-111-080 0E CAP,TC U 27P-50 J SL UP050 UWC CSD-TD27
O MICON C 0607 87-018-116-080 0E CAP,TC U 56P-50 J SL UP050 UWC CSD-TD27
O MICON C 0608 87-018-114-080 0E CAP,TC U 39P-50 J SL UP050 UWC CSD-TD27
O MICON C 0609 87-018-149-080 0E CAP,TC U 15P-50 J CH UP050 UWC CSD-TD27
O MICON C 0610 87-015-785-080 0E C-CAP, 0.1-25 Z F C3216 UWC CSD-TD27
O MICON C 0611 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 UWC CSD-TD27
O MICON C 0612 87-018-131-080 0E CAP,TC U 1000P-50 K B UP050 UWC CSD-TD27
O MICON C 0613 87-A10-826-080 0E C-CAP,S 1-10 K B UWC CSD-TD27
O MICON C 0614 87-010-494-040 0E CAP,E 1-50 M 5L SRE UWC CSD-TD27
O MICON C 0615 87-010-493-040 0E CAP,E 0.47-50 M 5L SRE UWC CSD-TD27
O MICON C 0616 87-010-196-080 0E C-CAP,S 0.1-25 Z F C2012 UWC CSD-TD27
O MICON C 0617 87-010-495-040 0E CAP,E 2.2-50 M 5L SRE UWC CSD-TD27
O MICON C 0618 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 UWC CSD-TD27
O MICON C 0619 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 UWC CSD-TD27
O MICON C 0625 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 UWC CSD-TD27
O MICON C 0626 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 UWC CSD-TD27
O MICON C 0627 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 UWC CSD-TD27
O MICON CN 0601 87-099-757-010 0E CONN,16P H 9604 UWC CSD-TD27
! O MICON CN 0602 87-A60-079-010 0E CONN,08P H 9604S-08F UWC CSD-TD27
O MICON CNA0603 8B-CHA-610-010 -- CONN ASSY,4P TU-FR UWC CSD-TD27
S MICON D 0601 87-020-465-080 0E DIODE,1SS133 UWC CSD-TD27
S MICON D 0602 87-020-465-080 0E DIODE,1SS133 UWC CSD-TD27
S MICON D 0603 87-020-465-080 0E DIODE,1SS133 UWC CSD-TD27
S MICON D 0604 87-020-465-080 0E DIODE,1SS133 UWC CSD-TD27
S MICON D 0607 87-020-465-080 0E DIODE,1SS133 UWC CSD-TD27
S MICON IC 0601 8B-CHA-600-010 1H C-IC,LC867132V-5T67 UWC CSD-TD27
MICON JR 0601 88-129-000-080 0E C-JUMPER,3216 UWC CSD-TD27
MICON JR 0602 88-129-000-080 0E C-JUMPER,3216 UWC CSD-TD27
MICON JR 0603 88-129-000-080 0E C-JUMPER,3216 UWC CSD-TD27
MICON JR 0604 88-118-000-080 0E C-JUMPER,S UWC CSD-TD27
MICON JR 0605 88-129-000-080 0E C-JUMPER,3216 UWC CSD-TD27
MICON JR 0606 88-129-000-080 0E C-JUMPER,3216 UWC CSD-TD27
O MICON L 0601 87-003-102-080 0E COIL,10UH J LAL02 UWC CSD-TD27
O MICON L 0602 87-003-102-080 0E COIL,10UH J LAL02 UWC CSD-TD27
MICON L 0605 88-100-000-010 0E PLATING-JW, 0.58 SN95 UWC CSD-TD27
MICON L 0606 88-100-000-010 0E PLATING-JW, 0.58 SN95 UWC CSD-TD27
MICON L 0607 88-100-000-010 0E PLATING-JW, 0.58 SN95 UWC CSD-TD27
O MICON LCD0601 8B-CHA-620-010 -- LCD,AIW4239-32PIN UWC CSD-TD27
O MICON LED0601 8A-CDA-646-010 0E LED,6224-10GD GRN UWC CSD-TD27
MICON LED0602 8A-CDA-645-010 0E LED,6224-10ID RED UWC CSD-TD27
MICON LED0603 8A-CDA-645-010 0E LED,6224-10ID RED UWC CSD-TD27
S MICON Q 0601 87-026-237-080 0E C-TR,DTC124 K UWC CSD-TD27
S MICON Q 0602 87-026-463-080 0E TR,2SA933SRS UWC CSD-TD27
S MICON Q 0603 87-026-237-080 0E C-TR,DTC124 K UWC CSD-TD27
S MICON Q 0604 87-026-239-080 0E C-TR,DTC114TK UWC CSD-TD27
S MICON Q 0605 87-026-239-080 0E C-TR,DTC114TK UWC CSD-TD27
MICON R 0601 88-118-334-080 0E C-RES,S 330K-1/10W J UWC CSD-TD27
MICON R 0602 88-118-102-080 0E C-RES,S 1K-1/10W J UWC CSD-TD27
MICON R 0603 88-118-102-080 0E C-RES,S 1K-1/10W J UWC CSD-TD27
MICON R 0604 88-121-102-080 0E RES,1K-1/8W J UWC CSD-TD27
MICON R 0605 88-118-102-080 0E C-RES,S 1K-1/10W J UWC CSD-TD27
MICON R 0606 88-118-102-080 0E C-RES,S 1K-1/10W J UWC CSD-TD27
MICON R 0607 88-118-102-080 0E C-RES,S 1K-1/10W J UWC CSD-TD27
MICON R 0608 88-121-102-080 0E RES,1K-1/8W J UWC CSD-TD27
MICON R 0609 88-121-103-080 0E RES,10K-1/8W J UWC CSD-TD27
MICON R 0610 88-121-103-080 0E RES,10K-1/8W J UWC CSD-TD27
MICON R 0611 88-121-474-080 0E RES,470K-1/8W J UWC CSD-TD27
MICON R 0612 88-118-103-080 0E C-RES,S 10K-1/10W J UWC CSD-TD27
MICON R 0613 88-118-103-080 0E C-RES,S 10K-1/10W J UWC CSD-TD27
MICON R 0614 88-118-102-080 0E C-RES,S 1K-1/10W J UWC CSD-TD27
MICON R 0615 88-118-000-080 0E C-JUMPER,S UWC CSD-TD27
MICON R 0616 88-118-000-080 0E C-JUMPER,S UWC CSD-TD27

 19 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
MICON R 0617 88-118-102-080 0E C-RES,S 1K-1/10W J UWC CSD-TD27
MICON R 0618 88-118-102-080 0E C-RES,S 1K-1/10W J UWC CSD-TD27
MICON R 0619 88-118-102-080 0E C-RES,S 1K-1/10W J UWC CSD-TD27
MICON R 0620 88-118-102-080 0E C-RES,S 1K-1/10W J UWC CSD-TD27
MICON R 0621 88-118-102-080 0E C-RES,S 1K-1/10W J UWC CSD-TD27
MICON R 0622 88-118-102-080 0E C-RES,S 1K-1/10W J UWC CSD-TD27
MICON R 0623 88-118-102-080 0E C-RES,S 1K-1/10W J UWC CSD-TD27
MICON R 0624 88-118-102-080 0E C-RES,S 1K-1/10W J UWC CSD-TD27
MICON R 0625 88-118-102-080 0E C-RES,S 1K-1/10W J UWC CSD-TD27
MICON R 0626 88-118-102-080 0E C-RES,S 1K-1/10W J UWC CSD-TD27
MICON R 0627 88-118-102-080 0E C-RES,S 1K-1/10W J UWC CSD-TD27
MICON R 0631 88-118-334-080 0E C-RES,S 330K-1/10W J UWC CSD-TD27
MICON R 0632 88-118-473-080 0E C-RES,S 47K-1/10W J UWC CSD-TD27
MICON R 0633 88-118-103-080 0E C-RES,S 10K-1/10W J UWC CSD-TD27
MICON R 0634 88-118-104-080 0E C-RES,S 100K-1/10W J UWC CSD-TD27
MICON R 0636 88-118-152-080 0E C-RES,S 1.5K-1/10W J UWC CSD-TD27
MICON R 0637 88-118-152-080 0E C-RES,S 1.5K-1/10W J UWC CSD-TD27
MICON R 0639 88-118-104-080 0E C-RES,S 100K-1/10W J UWC CSD-TD27
MICON R 0641 88-118-821-080 0E C-RES,S 820-1/10W J UWC CSD-TD27
MICON R 0642 88-118-102-080 0E C-RES,S 1K-1/10W J UWC CSD-TD27
MICON R 0643 88-118-102-080 0E C-RES,S 1K-1/10W J UWC CSD-TD27
MICON R 0644 88-118-122-080 0E C-RES,S 1.2K-1/10W J UWC CSD-TD27
MICON R 0645 88-118-122-080 0E C-RES,S 1.2K-1/10W J UWC CSD-TD27
MICON R 0646 88-118-152-080 0E C-RES,S 1.5K-1/10W J UWC CSD-TD27
MICON R 0647 88-118-182-080 0E C-RES,S 1.8K-1/10W J UWC CSD-TD27
MICON R 0651 88-118-821-080 0E C-RES,S 820-1/10W J UWC CSD-TD27
MICON R 0652 88-118-102-080 0E C-RES,S 1K-1/10W J UWC CSD-TD27
MICON R 0653 88-118-102-080 0E C-RES,S 1K-1/10W J UWC CSD-TD27
MICON R 0654 88-118-122-080 0E C-RES,S 1.2K-1/10W J UWC CSD-TD27
O MICON S 0601 87-A92-170-080 -- SW,TACT EVQPAD05R UWC CSD-TD27
O MICON S 0602 87-A92-170-080 -- SW,TACT EVQPAD05R UWC CSD-TD27
O MICON S 0603 87-A92-170-080 -- SW,TACT EVQPAD05R UWC CSD-TD27
O MICON S 0604 87-A92-170-080 -- SW,TACT EVQPAD05R UWC CSD-TD27
O MICON S 0605 87-A92-170-080 -- SW,TACT EVQPAD05R UWC CSD-TD27
O MICON S 0606 87-A92-170-080 -- SW,TACT EVQPAD05R UWC CSD-TD27
O MICON S 0607 87-A92-170-080 -- SW,TACT EVQPAD05R UWC CSD-TD27
O MICON S 0607 8Z-CT6-636-010 0E SW,TACT EVQJAC04M UWC CSD-TD27
O MICON S 0608 87-A92-170-080 -- SW,TACT EVQPAD05R UWC CSD-TD27
O MICON S 0608 8Z-CT6-636-010 0E SW,TACT EVQJAC04M UWC CSD-TD27
O MICON S 0611 87-A92-170-080 -- SW,TACT EVQPAD05R UWC CSD-TD27
O MICON S 0612 87-A92-170-080 -- SW,TACT EVQPAD05R UWC CSD-TD27
O MICON S 0613 87-A92-170-080 -- SW,TACT EVQPAD05R UWC CSD-TD27
O MICON S 0614 87-A92-170-080 -- SW,TACT EVQPAD05R UWC CSD-TD27
O MICON S 0615 87-A92-170-080 -- SW,TACT EVQPAD05R UWC CSD-TD27
O MICON 0601 87-030-273-010 1A VIB, TAL 32.768KHZ DT-38 5PPM UWC CSD-TD27
O MICON 0602 87-030-376-080 1A VIB,CER 5.760MHZ CSA MG200 UWC CSD-TD27
O OTHERS 86-CT9-217-110 0E HLDR,CHUCK A(S) UWC CSD-TD27
O OTHERS 86-CT9-222-010 0E PLATE,MAGNET UWC CSD-TD27
O OTHERS 87-036-368-010 0E MAGNET, UWC CSD-TD27
! O OTHERS 87-063-165-010 0E OIL-DMPR,150 UWC CSD-TD27
O OTHERS 87-064-185-010 0E HLDR,WIRE PVC 0.5 UWC CSD-TD27
O OTHERS 88-CH6-220-010 0E CUSHION,CD A UWC CSD-TD27
O OTHERS 8A-CDA-221-010 1A SPR-P,REC UWC CSD-TD27
O OTHERS 8B-CDA-206-010 -- SPR-T,CD UWC CSD-TD27
O OTHERS 8B-CDA-208-010 -- SPR-T,CASS UWC CSD-TD27
! O OTHERS 8Z-CDB-169-010 1D PANEL,CD SANYO UWC CSD-TD27
O OTHERS 8Z-CT6-213-110 0E BASE,CHUCK UWC CSD-TD27
O OTHERS 8Z-CT6-214-110 0E RING,CHUCK UWC CSD-TD27
O OTHERS * 8A-CDA-220-010 0E PLATE,REC UWC CSD-TD27
OTHERS * 8A-CDA-224-010 -- CUSH, 9.3-6.2-0.6 UWC CSD-TD27
O OTHERS * 8B-CDA-202-010 -- HLDR,TU UWC CSD-TD27
OTHERS * 8B-CDA-204-010 -- PLATE,ANT UWC CSD-TD27
O OTHERS * 8B-CHA-201-010 -- HLDR,LCD UWC CSD-TD27
O OTHERS C 0321 87-010-197-080 0E C-CAP,S 0.01-25 K B C2012 UWC CSD-TD27
O OTHERS C 0322 87-010-263-080 0E CAP,E 100-10 M 11L SME UWC CSD-TD27
O OTHERS CN 0201 87-099-018-010 0E CONN,16P V BLK 6216 UWC CSD-TD27
O OTHERS CNA0302 8B-CDA-629-010 -- CONN ASSY,6P MA-TU UWC CSD-TD27
S OTHERS D 0032 87-A40-509-080 0E ZENER,MTZJ6.8C UWC CSD-TD27
OTHERS JR 0101 88-118-000-080 0E C-JUMPER,S UWC CSD-TD27
OTHERS JR 0102 88-118-000-080 0E C-JUMPER,S UWC CSD-TD27

 20 
! = ! SAFTY PARTS
C = Components marked
All components used on this model at the production line are shown in this service manual.
However please note that not all components will be available as spare parts for after-sales service.
Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
Components marked X and R are not designated as spare parts for after sales service and will not be stocked at the spare parts centers.
K NO. = Only use japanese.
C UNIT NAME REF NO. MODEL NAME!DESCRIPTIONK NO.PARTS CODE SUFFIX
PARTS LIST
OTHERS JR 0204 88-118-000-080 0E C-JUMPER,S UWC CSD-TD27
OTHERS JR 0350 88-118-000-080 0E C-JUMPER,S UWC CSD-TD27
OTHERS JR 0351 88-118-000-080 0E C-JUMPER,S UWC CSD-TD27
OTHERS JR 0402 88-118-000-080 0E C-JUMPER,S UWC CSD-TD27
OTHERS JR 0406 88-129-000-080 0E C-JUMPER,3216 UWC CSD-TD27
OTHERS JR 0416 88-118-000-080 0E C-JUMPER,S UWC CSD-TD27
OTHERS JR 0425 88-129-000-080 0E C-JUMPER,3216 UWC CSD-TD27
OTHERS JR 0426 88-129-000-080 0E C-JUMPER,3216 UWC CSD-TD27
OTHERS JR 0428 88-118-000-080 0E C-JUMPER,S UWC CSD-TD27
O OTHERS L 0108 87-003-097-080 0E COIL,1.0UH K LAL02 UWC CSD-TD27
S OTHERS Q 0321 89-318-154-080 0E TR,2SC1815Y UWC CSD-TD27
S OTHERS Q 0841 87-026-291-080 1A TR,DTC124 S UWC CSD-TD27
OTHERS R 0322 88-118-222-080 0E C-RES,S 2.2K-1/10W J UWC CSD-TD27
OTHERS R 0327 88-118-822-080 0E C-RES,S 8.2K-1/10W J UWC CSD-TD27
OTHERS R 0838 88-118-000-080 0E C-JUMPER,S UWC CSD-TD27
OTHERS R 0839 88-118-103-080 0E C-RES,S 10K-1/10W J UWC CSD-TD27
OTHERS R 0927 88-118-102-080 0E C-RES,S 1K-1/10W J UWC CSD-TD27
OTHERS TM 0001 87-A60-884-010 0E PIN,DIA1 COATING-SHS UWC CSD-TD27
PACKING 87-051-183-010 0E BAG,PV 0.03-120-280 UWC CSD-TD27
PACKING 8A-CDA-897-010 -- SH,FOAMED-MAT 0.31-880-710 UWC CSD-TD27
PACKING 8B-CDA-852-010 -- CUSHION,LEFT C UWC CSD-TD27
PACKING 8B-CDA-853-010 -- CUSHION,RIGHT C UWC CSD-TD27
PACKING 8B-CHA-856-010 -- CTN,PRINTED UWC UWC CSD-TD27
PACKING 8B-CHA-857-010 -- CTN,OUTER UWC UWC CSD-TD27
PLATE 84-711-909-010 1A LBL DATE CODE UWC CSD-TD27
PLATE 87-B40-154-010 0E LBL,BAR-CODE CU UWC CSD-TD27
PLATE 87-B40-282-010 0E LBL,BAR-CODE AU 35 8 UWC CSD-TD27
PLATE 8A-CH4-040-010 0E LBL,CAUTION RW E UWC CSD-TD27
PLATE 8B-CHA-007-010 -- LBL,SPEC U UWC CSD-TD27
O POWER C 0491 87-A11-132-080 0E CAP,TC U 0.01-50 K B UWC CSD-TD27
O POWER C 0492 87-010-221-080 0E CAP,E 470-10 M SME UWC CSD-TD27
O POWER C 0901 87-010-192-080 0E C-CAP,S 0.022-50 Z F C2012 UWC CSD-TD27
O POWER C 0902 87-010-192-080 0E C-CAP,S 0.022-50 Z F C2012 UWC CSD-TD27
O POWER C 0903 87-010-192-080 0E C-CAP,S 0.022-50 Z F C2012 UWC CSD-TD27
O POWER C 0904 87-010-192-080 0E C-CAP,S 0.022-50 Z F C2012 UWC CSD-TD27
O POWER CNA0901 8B-CDA-627-010 -- CONN ASSY,3P PWR UWC CSD-TD27
S POWER D 0494 87-070-345-080 0E DIODE,1N4148 UWC CSD-TD27
S POWER D 0901 87-A40-465-010 0E DIODE,FR202 UWC CSD-TD27
S POWER D 0902 87-A40-465-010 0E DIODE,FR202 UWC CSD-TD27
S POWER D 0903 87-A40-465-010 0E DIODE,FR202 UWC CSD-TD27
S POWER D 0904 87-A40-465-010 0E DIODE,FR202 UWC CSD-TD27
S POWER D 0905 87-A40-465-010 0E DIODE,FR202 UWC CSD-TD27
O POWER PR 0901 87-A91-940-080 0E PROTECTOR,2.5A 20P 60V UWC CSD-TD27
S POWER Q 0491 89-112-965-080 0E TR,2SA1296GR UWC CSD-TD27
S POWER Q 0492 87-026-291-080 1A TR,DTC124 S UWC CSD-TD27
POWER R 0470 88-100-000-010 0E PLATING-JW, 0.58 SN95 UWC CSD-TD27
POWER R 0490 88-121-102-080 0E RES,1K-1/8W J UWC CSD-TD27
POWER R 0491 88-118-473-080 0E C-RES,S 47K-1/10W J UWC CSD-TD27
POWER R 0492 88-118-331-080 0E C-RES,S 330-1/10W J UWC CSD-TD27
O POWER SP 0901 8A-CDA-214-010 0E SPR-C,BATT UWC CSD-TD27
O POWER SP 0902 8A-CDA-214-010 0E SPR-C,BATT UWC CSD-TD27
O POWER SP 0903 8A-CDA-214-010 0E SPR-C,BATT UWC CSD-TD27
O POWER SP 0904 8A-CDA-214-010 0E SPR-C,BATT UWC CSD-TD27
O POWER AMP C 0251 87-010-405-080 0E CAP,E 10-50 M 11L SME UWC CSD-TD27
O POWER AMP C 0263 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 UWC CSD-TD27
O POWER AMP C 0264 87-010-178-080 0E C-CAP,S 1000P-50 K B C2012 UWC CSD-TD27
O POWER AMP C 0265 87-010-263-080 0E CAP,E 100-10 M 11L SME UWC CSD-TD27
O POWER AMP C 0266 87-010-263-080 0E CAP,E 100-10 M 11L SME UWC CSD-TD27
O POWER AMP C 0267 87-010-385-080 0E CAP,E 220-25 M SME UWC CSD-TD27
O POWER AMP C 0268 87-010-385-080 0E CAP,E 220-25 M SME UWC CSD-TD27
O POWER AMP C 0271 87-010-221-080 0E CAP,E 470-10 M SME UWC CSD-TD27
O POWER AMP C 0272 87-010-221-080 0E CAP,E 470-10 M SME UWC CSD-TD27
POWER AMP C 0273 88-700-920-810 0E CAP,M 0.15-50 J LDS UWC CSD-TD27
POWER AMP C 0274 88-700-920-810 0E CAP,M 0.15-50 J LDS UWC CSD-TD27
O POWER AMP C 0278 87-010-385-080 0E CAP,E 220-25 M SME UWC CSD-TD27
O POWER AMP C 0279 87-010-235-080 0E CAP,E 470-16 M SME UWC CSD-TD27
O POWER AMP CN 0202 8A-CH4-687-010 0E CONN,4P V 2.5 UWC CSD-TD27
S POWER AMP IC 0202 87-A21-193-010 1B IC,TA8227P UWC CSD-TD27
O POWER AMP J 0201 87-A60-420-010 1A JACK,3.5 ST (MSC) UWC CSD-TD27
S POWER AMP Q 0243 89-318-154-080 0E TR,2SC1815Y UWC CSD-TD27
