Tangent Pillar 1600i User manual

Exceptional Price/Performance in a 1U Rackmount Server
A density-optimized server, supporting dual Intel® Xeon™
processors with 64-bit extensions, up to 3.60GHz at 800MHz
FSB, Intel® E7520 chipset, and up to 16GB ECC registered
DDR333 memory.
Operating Systems Supported
Microsoft® Windows® Server 2003 family
Processor
Dual Intel® Xeon™ processors with 64-bit
Extensions, up to 3.60GHz, 1MB/800MHz
System Memory
Up to 16GB ECC registered DDR333, or up to
32GB ECC registered DDR266 memory in eight
DIMM slots
Supports only registered ECC memory
Non-ECC or unbuffered memories are not
Supported. Two-way interleaved memory banks
(must use a pair of DIMMs)
Integrated
Intel E7520 chipset
Intel 82546GB dual port Gbit Ethernet
8MB ATI Rage XL PCI graphic controller
Expansion Slots
Two SXB-E slots supporting two PCIe (x8), or one
PCI-X (64bit/133MHz) + one PCI-X (64bit/100MHz)
On riser card
I/O Ports / Interfaces
Four SATA (Marvell controller) RAID 0 or 1
Two Ultra DMA/IDE channels support four devices
One ZCR socket for Adaptec zero-channel RAID
One Fast UART 16550 serial port
One floppy controller
One VGA port
Two RJ-45 Gbit LAN ports
Four USB ports (2xrear, 2xinternal)
One VGA port
Two PS/2 ports (keyboard/mouse)
System BIOS
8MB Flash EEPROM with AwardBIOS
USB keyboard support, Plug and Play, SMBIOS 2.3,
BIOS rescue hot keys, DMI 2.1, Hardware BIOS virus
Protection, PCI 2.2, ACPI 1.0, fan speed control
Cooling
Two 10 cm blower fans
Power Supply
500W cold-swap power supply, Auto-switching 100/240
AC power
Dimensions
17.2” W x 25.6” D x 1.7” H
Weight: 30 lb net, 40 lb gross
Chassis
1U Rackmount
Drive Bays
Four 1” SATA hot-swap drive bays
Front Panel
Chassis and CPU overheat alarm, LED indication and
control
Server Management Instrumentation
Four CPU voltage monitors, four fan status,
Environmental temperature monitor and control,
System resource alert, Supermicro System management
utility, FUCI (Frontside USB Control Interface),
DMI support
Optional: IPMI v. 2.0, SuperO Doctor software
Other Features
ACPI/APM power management
Internal / external modem ring-on
Control of power-on mode for recovery from AC
power loss
One WOL (Wake-On-LAN) connector
One chassis intrusion header
S
p
ecifications
