Tappan Electric Built- in oven User manual

Recycled paper Printed in Canada P/N 318200907 (9808) Rev. A

2
ProductRegistration Thank you for choosing this appliance. Theinformationcontained within this
Owner'sGuidewillinstructyouonhowtoproperlyoperateandcareforyourwall
oven.Pleasereadthroughtheinformationcontainedinyourliteraturepacktolearn
more about your new appliance.
Record Your Model and Serial Numbers
Recordinthespaceprovidedbelowthemodelandserialnumbersfoundontheserial
plate located along the side of the oven door in the open position (lower door of
double oven models).
ModelNumber: _____________________________________________________
SerialNumber: _____________________________________________________
DateofPurchase: ___________________________________________________
Register Your Product
ThePRODUCTREGISTRATIONCARD
should be filled in completely, signed
and returned to Frigidaire Company.
Contents 2 ProductRegistration
2 Versión en español
3-4 ImportantSafetyInstructions
4 Setting the Clock and Minute Timer
5 BeforeSettingOvenControls
5 Air Circulation in the Oven
6 SettingOvenControls
7 Oven Baking
8 ChangingOvenLight
8 AdjustingOvenTemperature
9 Oven Cleaning
9-10 General Cleaning
11 Avoid Service Checklist
12 Warranty&ServiceInformation
This Owner's Guide contains general
operating instructions for your oven and
feature information for several models.
Yourovenmaynothaveallthedescribed
features.
Note: Theinstructions appearing in this
Owner's Guide are not meant to cover
every possible condition and situation
that may occur. Common sense and
caution must be practiced when
installing,operatingandmaintainingany
appliance.
Versión en español
Si desea obtener una copia en español
de este Manual del Usuario, sírvase
escribir la dirección que se incluye a
continuación.SolicitelaP/N318201117.
SpanishOwner'sGuides
FrigidaireCompany
P. O. Box 9061
Dublin,Ohio 43017-0961
© 1998 White Consolidated Industries
All rights reserved

3
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions before using this appliance.
Save these instructions for future reference.
This guide contains important safety symbols and instructions. Please pay special attention to these symbols and follow all
instructions given. Here is a brief explanation of the use of these symbols.
This symbol will help alert you to situations
that may cause serious bodily harm, death or property
damage.
This symbol will help alert you to
situations that may cause bodily injury or property
damage.
•Do not leave children alone—Children should not be
left alone or unattended in the area where an
appliance is in use. They should never be allowed to sit
or stand on any part of the appliance.
• DO NOT TOUCH INTERIOR OVEN ELEMENTS OR
INTERIOR SURFACES OF THE WALL OVEN UNTIL THEY
HAVE COOLED. The oven heating elements may be hot
even though the elements are dark in color. Areas near the
elements may become hot enough to cause burns. During
and after use, do not touch, or let clothing or other
flammable materials touch these areas until they have had
sufficient time to cool. Among these areas are the oven
vent openings, the surfaces near these openings, oven
door and window.
• Wear Proper Apparel—Loose-fitting or hanging
garments should never be worn while using the
appliance. Do not let clothing or other flammable
materials contact hot surfaces.
Never use your appliance for warming or
heating the room.
• Do Not Use Water or Flour on Grease Fires—Smother
the fire with a pan lid, or use baking soda, a dry
chemical or foam-type extinguisher.
•When heating fat or grease, watch it closely. Fat or
grease may catch fire if allowed to become too hot.
•Use Only Dry Potholders—Moist or damp potholders
on hot surfaces may result in burns from steam. Do
not let the potholders touch the hot heating elements. Do
not use a towel or other bulky cloth instead of a potholder.
•Do Not Heat Unopened Food Containers—Build-up
of pressure may cause the container to burst and
result in injury.
IMPORTANTINSTRUCTIONSFOR
USINGYOUROVEN
• Use Care When Opening an Oven Door—Stand to the
side of the wall oven when opening the door of a hot oven.
Let hot air or steam escape before you remove or replace
food in the oven.
• Keep Oven Vent Ducts Unobstructed. The wall oven is
vented at the upper control panel trim. Touching the
surfaces in this area when the wall oven is operating may
cause severe burns. Also, do not place plastic or heat-
sensitive items near the oven vent. These items could melt
or ignite.
•Remove all tape and packaging wrap before using
the wall oven. Destroy the carton and plastic bags
after unpacking the wall oven. Never allow children to
play with packaging material. Do not remove the wiring
label and other literature attached to the back of the wall
oven. Do not remove model/serial number plate.
•Proper Installation—Be sure your appliance is
properly installed and grounded by a qualified
electrician or installer in accordance with the
National Electrical Code ANSI/NFPA No. 70 (U.S.A.) or
CSA C22.1, PART 1 (Canada)—latest editions and local
code requirements. Install only per installation
instructions provided in the literature package for this wall
oven.
Ask your dealer to recommend a qualified installer,
technician or an authorized repair service. Know how to
disconnect the electrical power to the wall oven at the
circuit breaker or fuse box in case of an emergency.
•User Servicing—Do not repair or replace any part of
the appliance unless specifically recommended in the
manuals. All other servicing should be done only by a
qualified technician. This may reduce the risk of personal
injury and damage to the wall oven.
•Never modify or alter the construction of the wall
oven by removing panels, wire covers, or any other
part of the product.
• Remove the oven door(s) from any unused wall oven
if it is to be stored or discarded.
Stepping, leaning or sitting on the doors
of this wall oven can result in serious injuries and may
also cause damage to the wall oven. Do not allow
children to climb or play around the wall oven.
• Storage in or on Appliance—Flammable materials
should not be stored in an oven, or in the storage
drawer (if equipped). This includes paper, plastic and
cloth items, such as cookbooks, plasticware and towels, as
well as flammable liquids. Do not store explosives, such as
aerosol cans, in or near the wall oven.
Do not use the wall oven for storage.
Do not store items of interest to children
in the cabinets above a wall oven. Children climbing on
the wall oven to reach items could be seriously injured.

4
IMPORTANT SAFETY INSTRUCTIONS (continued)
SAVE THESE INSTRUCTIONS
Setting the Clock and
Minute Timer
To Set the Clock
Whentherangeisfirstpluggedin,orwhenthepowersupplytotherangehasbeen
disconnected, "12:00" will flash in the display window.
1. Press button C (CLOCK).
2. Pushinand holdbuttonA(HOUR)until thecorrecthourappearsin thedisplay.
(The numbers will only count forward.)
3. Push in and hold button B (MINUTE) until the correct minutes appear in the
display.
To Set the Minute Timer
The minute timer does not start or stop cooking. It serves as an extra timer in the
kitchenthatwillbeepwhen the set timehasrunout.Theminutetimercan be used
independently during any of the bake or broil functions.
1. Press button D (TIMER), "0:59." (59 MINUTES) and the minute timer indicator
willappearinthedisplaywindow.Thetimercanbesetfor any amount of time
from 1 minute to 1 hour and 59 minutes.
2. • Tosetatimemorethan59minutes, push in and release button A (HOUR).
The timer will jump in at the maximum 1 hour and 59 minutes. Adjust the
time by pushing in and holding button B (MINUTE) until the correct time
appears in the display.
• Tosetatimelessthan59minutes,pushinandholdbuttonB(MINUTE)until
thecorrectminutes appearinthedisplay.(The minutetimerwillautomati-
cally start when the button is released.)
3. When the set time has passed, the control will display "0:00." and beep
continuously.PressbuttonC(CLOCK)tocancelthetimerandreturntotheclock
mode.
CLOCK HOUR
TIMER MINUTE
•Placement of Oven Racks. Always place oven racks in
desired location while oven is cool. If the rack must be
moved while the oven is hot, use extreme caution. Use
potholdersandgrasp the rackwithbothhands to reposition.
Do not let potholders contact the hot oven element or
interior of the oven. Remove all utensils from the rack
before removing the rack.
•Do not use the broiler pan without its insert. The
broiler pan and grid allow dripping fat to drain and be kept
away from the high heat of the broiler.
•Do not cover the broiler grid or oven bottom with
aluminum foil. Exposed fat and grease could ignite.
•Do not touch a hot oven light bulb with a damp cloth.
Doing so could cause the bulb to break. Disconnect the
oven or shut off the power to the oven before removing and
replacing the bulb.
IMPORTANTINSTRUCTIONSFOR
CLEANINGYOUROVEN
• Clean the wall oven regularly to keep all parts free of
grease that could catch fire. Do not allow grease to
accumulate.
• Kitchen cleaners/aerosols—Always follow the
manufacturer's recommended directions for use. Be aware
that excess residue from cleaners and aerosols may ignite
causing damage and/or injury.

5
Oven Vent Location
The oven is vented at the top of the upper control panel trim. When the oven
ison,warm airisreleasedthroughthe vent.Thisventingis necessaryforproperair
circulationintheoven and goodbakingresults.DO NOT blockthe vent. Doingso
may cause cooking failures, fire or damage to the wall oven.
Arranging Oven Racks
ALWAYSARRANGEOVENRACKSWHENTHEOVENISCOOL(PRIORTOOPERATING
THE OVEN). Always use oven mitts when using the oven.
Somemodelshave2flatracks.Othermodelshaveoneflatrackandoneoffsetrack.
Therungsontheoffsetrackareslightlyraisedfromtheedgesoftherack.Thisraised
partof the rack isdesignedtoallow easy and saferemovaloffoods from the lower
racksoftheovenandpreventhandsfromcontactingthehotovendoor.Alwaysuse
the offset rack in the lower position.
Before Setting Oven
Controls
To remove an oven rack, pull the
rackforwarduntilitstops.Liftupfront
of rack and slide out. To replace an
ovenrack,fittherackontotheguides
ontheovenwalls. Tilt the front of the
rack upward and slide the rack back
into place.
Tobakeononerack,placetherack
at position 2 or 3. To bake on two
racks, place the racks at positions 1
and 3.
Air Circulation in the
Oven
Ifusingmultiplepans,staggerasshown.Ifusingonepan,placeincenterofoven.
For best air circulation and baking results, center pans as much as possible. Allow
2-4" (5-10 cm) around the utensil(s) for proper air circulation and be sure pans do
not touch each other, the door, sides or back of oven. The hot air must circulate
around the pans in the oven for even heat to reach all parts of the oven.

6
Setting Oven Controls To Bake
1. Arrange oven racks while the oven is still cool. See "Arranging Oven Racks"
underBefore Setting OvenControls.
2. Turn the Temperature Control knob to the desired temperature. The oven
indicator light will go on.
3. Preheattheovenfor10to12minutesbeforebaking.Preheatingisnotnecessary
whenroasting,cookingcasserolesorbroilingmostfoods.
4. Whencookingisfinished,turntheTemperatureControlknobtoOFF.Theoven
indicator light will go off.
To Broil
1. Arrangebroilerpanwhilebroilcompartmentisstillcool.Forraremeats,position
thebroilerpanclosertotheburner(upperposition).Forwell-donefoodssuch
aschicken,lobstertailsorthickcutsofmeat,positionthepanfurtherfromthe
burner(lowerposition).
Rack Position From Top Food
1 Rare steaks
2 - 3 Ham slices, fish, hamburgers and medium
steaks and chops
4 Well-done foods such as chicken and lobster
2. Turn the Temperature Control knob to BROIL. The oven indicator light will go
on.
3. Placethegridonthebroilerpan,thenplacethemeatonthegrid.DONOTuse
the broiler pan without the grid or cover the grid with aluminum foil. The
exposed fat could ignite.
4. Place the pan on the oven rack. Leave the door open at the broil stop
position while broiling. The door will stay in this position without closing.
5. Broilononesideuntilfoodisbrowned;turnandcookonthesecondside.Season
andserve.Note:Alwayspulltherackouttothestoppositionbeforeturningor
removingfood.
6. Whenbroilingisfinished,turntheTemperatureControlknobtoOFF.Theoven
indicator light will go off.
TemperatureControl Knob
Thebroilerpananditsgridallowdripping
grease to drain and be kept away from
thehighheatofthebroiler. DONOTuse
the pan without its grid. DO NOT cover
the grid with foil. The exposed grease
couldignite.
Shouldanovenfireoccur,
close the oven door and turn the oven
off. If the fire continues, throw baking
sodaonthefireoruseafireextinguisher.
DO NOT put water or flour on the fire.
Flour may be explosive.

7
Corrections
• Allow oven to preheat to the selected temperature before
placing food in oven.
• Choosepansizesthatwillpermit2-4"(5-10cm)ofairspace
on all sides when placed in the oven.
• Use a medium-weight aluminum baking sheet.
• Allow oven to preheat to the selected temperature before
placing food in the oven.
• Use proper rack position for baking needs.
• Setoventemperature25°F/12°Clowerthanrecommended.
• Setoventemperature25°F/12°Clowerthanrecommended.
• Use pan size suggested in recipe.
• Use proper rack position and place pan so there is 2-4" (5-
10 cm) of space on all sides of pan.
• Place a marked glass measuring cup filled with some water
on the center of the oven rack. If the water level is uneven,
refer to the installation instructions for leveling the range.
• Be sure to allow 2-4" (5-10 cm) of clearance on all sides of
each pan in the oven.
• Do not use pans that are dented or warped.
• Check oven rack for flatness and proper positioning.
• Setoventemperature25°F/12°Chigherthansuggestedand
bake for the recommended time.
• Besuretoremoveallpansfromthe ovenexceptthe onesto
be used for baking.
• Open oven door only after shortest recommended baking
time.
Oven Baking "Baking"meanstocookfoodssuchascakesorcasserolesbydryheatinacovered
oruncoveredpan.Roasting,oftenconfusedwithbaking,meanstocookmeatinan
uncovered pan. To Bake or Roast, follow the instructions in the Setting Oven
Controls section.
Product Expectations
The cooking times and temperatures needed to bake a product may vary slightly
fromyourpreviouslyownedappliance
BakingProblemsandSolutions
Chart(Below)
BakingProblems
Cookies and
biscuits burn on
the bottom.
Cakes too dark on
top or bottom.
Cakes not done in
thecenter.
Cakes not level.
Foods not done
when cooking time
is up.
Causes
• Cookies and biscuits put into the
oven before the preheating time is
completed.
• Ovenrackovercrowded.
• Dark pan absorbs heat too fast.
• Cakes put into the oven before
preheating time is completed.
• Rack position too high or low.
• Oventoohot.
• Oventoohot.
• Incorrect pan size.
• Pan not centered in oven.
• Range not level.
• Pan too close to oven wall or rack
overcrowded.
• Pan warped.
• Oven rack not level.
• Oven too cool.
• Ovenovercrowded.
• Ovendooropenedtoofrequently.

8
Changing Oven Light Besurethepowertotheovenisturned OFF and all parts are COOL
before replacing the oven light. Wear a leather-faced glove for protection against
possiblebrokenglass.
The oven light automatically turns on when the door is opened. There is a switch
locatedonthecontrolpaneltoturnonthelightwhenthedoorisclosed.Movethis
switch to the on or off position to turn the light on or off.
The oven light is located at the rear of each oven. It is covered with a glass shield
heldinplaceby awireholder.Theglassshield must be in placewheneverthe
oven is in use.
To Change the Oven Light (some models)
1. Turn electrical power off at the main source.
2. Press wire holder to one side to release the glass shield.
3. Replace bulb with a new 40 watt appliance bulb.
4. Replace glass shield in socket and snap wire holder into place.
5. Turn power back on again at the main source.
6. The clock will then need to be reset. To reset, see Setting the Clock and
Minute Timer in this Owner's Guide.
Figure 1: Back of Control Knob
Thetemperatureintheoven(s)hasbeensetatthefactory.Whenfirstusingtheoven,
be sure to follow recipe times and temperatures. Then, if you think the oven is too
hotortoocool,thetemperaturecontroloftheovencanbeadjusted.Beforeadjusting,
test a recipe by using a higher or lower temperature than the recommended
temperature. The baking results should help you to decide how much of an
adjustment is needed.
ToAdjustOvenTemperature:
1. Check to be sure the Temperature Control knob is in the OFF position.
2. PullTemperature Control knob straight offtheshaft.
3. Loosen,butdonotremove, thetwoscrewsatthebackoftheknob(Figure1).
Note: If knob does not have 2 screws, it is not adjustable. There are a series of
smallindicatorgrooves.Oneofthesegroovesispositionednexttoatinypointer.
Notethe position of thepointer.
4. To increase the temperature, move the pointer in a clockwise direction. To
decrease the temperature, move the pointer in a counterclockwise direction.
The temperature can be adjusted in increments of 10°F.
5. When the desired adjustment is reached, tighten both screws.
6. Toreplacetheknob, line up the flatsides of boththe knoband theshaft. Push
theknobintoplace.DONOT forcetheTemperatureControlknobontotheshaft
or you may damage the back of the knob.
Note: Once an adjustment is made, the OFF position will vary from the reference
mark on the backguard depending on the amount of adjustment.
Adjusting Oven
Temperature

9
PorcelainEnamelOven
Porcelain has a smooth finish and is a type of glass fused to metal. Oven cleaners
can be used on all interior oven surfaces.
GeneralCleaning
Removesoils using hot, soapywater. Do notallow foodspillswithahigh sugar or
acidcontent(suchasmilk,tomatoes,saukerkraut,fruitjuicesorpiefilling)toremain
on the surface as they may cause a dull spot even after cleaning.
ToRemoveHeavy Soil
1. Allow a dish of ammonia to sit in the oven overnight or for several hours with
theovendoorclosed. Cleansoftenedspotsusinghot,soapywater. Rinsewell
with water and a clean cloth.
2. If soil remains, use a soap-filled scouring pad or a nonabrasive cleaner. If
neccessary,useanovencleanerfollowingmanufacturer'sinstructions.DONOT
mix ammonia with other cleaners.
3. Cleananysoilfromtheovenframe,thedoorlineroutsidetheovendoorgasket,
the small area at the front center of the oven bottom and the oven vent exit
(located below the backguard). Clean with hot, soapy water. Rinse well using
clean water and a cloth.
Adhere to the following precautions when using oven cleaners:
1. DO NOT spray on the electrical controls or switches because it could cause a
short circuit and result in sparking or fire.
2. DO NOT allowa film from the cleaner to build up on the temperature sensing
bulb;itcouldcausetheoventoheatimproperly. (Thebulbislocatedintherear
of the oven.) Carefully wipe the bulb clean after each oven cleaning, being
carefulnottomovethebulb.Achangeinitspositioncouldaffecthowtheoven
bakes. Avoid bending the bulb and capillary tube.
3. DO NOT spray any cleaner on the oven door trim or gasket, handles or any
exterior surfaces of the range, wood or painted surfaces. The cleaner can
damage these surfaces.
Oven Cleaning
Adhere to the following cleaning
precautions:
• Allowtheoventocoolbeforecleaning.
• Wearrubbergloveswhencleaningthe
oven manually.
REMOVE SPILLOVERS AND HEAVY
SOILING AS SOON AS POSSIBLE.
REGULAR CLEANINGS WILL REDUCE
THENUMBEROF MAJORCLEANINGS
LATER.
Ammonia must be rinsed
before operating the oven. Provide
adequateventilation.
DO NOT line the oven
walls, bottom, racks or any other part of
the range with aluminum foil. Doing so
will destroy heat distribution, produce
poorbakingresultsandcausepermanent
damage to the oven interior (aluminum
foil will melt to the interior surface of the
oven).
General Cleaning
To Remove and Replace Oven Door
1. Open the door to the fully opened position.
2. Pull up the lock located on each hinge support and engage it in the hook of
the hinge lever. You may have to apply a little downward pressure on the
door to pull the locks fully over the hooks.
3. Grasp the door by the sides, pull the bottom of the door up and toward you
todisengagethehinge supports.
4. Keep pulling the bottom of the door toward you while rotating the top of
the door toward the appliance to completely disengage the hinge levers.
5. To reinstall the oven door, reverse steps 1 through 4. Make sure the hinge
supports are fully engaged before unlocking the hinge levers.
The door is heavy. For
safe, temporary storage, lay the door
flat with the inside of the door facing
down.
DoorRemoval

10
General Cleaning
(continued)
Cleaning Various Parts of Your Wall Oven
Before cleaning any part of the wall oven, be sure all controls are turned OFF and
the oven is COOL. REMOVE SPILLOVERS AND HEAVY SOILING AS SOON AS
POSSIBLE. REGULAR CLEANINGS WILL REDUCE THE NUMBER OF MAJOR
CLEANINGS LATER.
Beforecleaninganypart
of the oven, be sure the control knobs
areturnedoff.Waituntiltheoveniscool.
How to Clean
Usehot,soapywaterandacloth.Drywithacleancloth.DONOTscouroruseall-purpose
cleaners, ammonia, powdered cleansers or commercial oven cleaner. They can scratch
anddiscoloraluminum.
For general cleaning, use hot soapy water and a cloth. For more difficult soils and built-
upgrease,applyaliquiddetergentdirectlyontothesoil.Leaveonsoilfor30to60minutes.
Rinsewithadampclothanddry.DONOTuseabrasivecleaners,spraycleanersorscouring
padsonanyofthesematerials.Thesecleanerscanpermanentlydamagethecontrolpad
surface.
Gentlescouringwithasoapyscouringpadwillremovemostspots.Rinsewitha1:1solution
ofclear waterandammonia.Ifnecessary,coverdifficultspotswithan ammonia-soaked
papertowelfor30to40minutes.Rinsewithcleanwaterandadampcloth,andthenscrub
withasoap-filledscouringpad.Rinseandwipedrywithacleancloth.Removeallcleaners
or the porcelain may become damaged during future heating.
Clean with hot soapy water and a dishcloth. Rinse with clean water and a cloth. Cover
stubbornspotswithanammonia-soakedpapertowelfor30to40minutes.Rinse.Cleaners
made especially for stainless steel are recommended. Be sure to rinse the cleaners as
bluish stains may occur during heating and cannot be removed.
Removeracks.See"Removing and Replacing Oven Racks" under Before Setting Oven
Controls.Useamild,abrasivecleaner,followingmanufacturer'sinstructions.Rinsewith
clean water and dry. After cleaning the racks, rub the sides of the racks with wax paper
oraclothcontainingasmall amount of babyoilorsaladoil(thiswillmakethe racks glide
easier into the rack positions).
Tocleanovendoor,washwithhot,soapywaterandacleancloth.DONOTimmersethe
door in water. To remove oven door, see instructions on page 11.
Lightlyspraythecontrolpanelwithaliquidcleaner.Wipewithasoftclothorpapertowel.
DO NOT use abrasive cleaners or scouring pads. These can permanently damage the
controlpanelsurface.
Surfaces
Aluminum (Trim Pieces)
Glass, Painted and Plastic
Body Pieces and Decorative
Trim
PorcelainEnamel Broiler Pan
and Grid, Door Liner
StainlessSteel, Chrome
Decorative Trim
OvenRack(s)
OvenDoor
ControlPanel

11
Avoid Service Checklist Before you call for service, review this list. It may save you time and expense. The
listincludescommonoccurrencesthatarenottheresultofdefectiveworkmanship
or materials in this appliance.
POSSIBLE CAUSE/SOLUTION
Poor installation. Place a level on an oven rack in center of oven. Contact installing
agent if rack is not level.
Kitchen cabinet misalignment may make oven appear to be not level. Be sure
cabinets are square and level. Contact cabinet maker to correct problem.
Be sure electrical cable is securely connected to the electrical junction box.
Service wiring not complete. Contact your dealer, installing agent or authorized
servicer.
Power outage. Check house lights to be sure. Call your local electric company.
Short in electrical cable or electrical circuit. Repair as needed.
Controls are not set properly. See instructions under Setting Oven Controls or
Oven Cleaning to set the controls.
House fuse has blown or circuit breaker has tripped immediately following
installation. House fuse may not be fully engaged. Check fuse and screw or engage
circuit breaker securely.
House fuse has blown or circuit breaker has tripped after the oven has been installed
and previously operating. Call an authorized servicer.
Burned-out or loose bulb. Follow the instructions under Changing Oven Light to
replace or tighten the bulb.
Oven door is closed. Door should be open during broiling.
Meat too close to the broiler unit. Reposition the rack to provide more clearance
between the meat and the broiler. Preheat broil element for quick searing operation.
Meat not properly prepared. Remove excess fat from meat. Slash remaining fatty
edges to prevent curling, but do not cut into the lean.
Grid on broiler pan wrong side-up. Grease does not drain into broiler pan. Always
place the grid on the broiler pan with the ribs up and the slots down to allow grease
to drip into the pan.
Oven needs to be cleaned. Grease has built up on oven surfaces. Regular cleaning
is necessary when broiling frequently. Old grease or food spatters cause excessive
smoking.
Many factors affect baking results. Make sure the proper rack position is used.
Center food in the oven and space pans to allow air to circulate. Allow the oven to
preheat to the set temperature before placing food in the oven. Try adjusting the
recipe's recommended temperature or baking time. If you feel the oven is too hot
or cool, see Adjusting Oven Temperature in this Owner's Guide.
Excessive spillovers in oven. This is normal, especially for pie spillovers or for large
amounts of grease on bottom of oven. Wipe up excessive spillovers before starting
self-clean cycle.
OCCURRENCE
Oven is not level.
Entire Oven Does Not Operate.
Oven Light Does Not Work.
Oven Smokes Excessively During
Broiling.
Poor Baking Results.
Flames Inside Oven or Smoke From
Vent.

TAPPAN,THROUGHITSAUTHORIZED
SERVICERS,WILL:
Pay all costs for repairing or replacing any parts of this
appliance which prove to be defective in materials or
workmanship.
All of the provisions of the full warranty above and the
exclusions listed below apply.
THECONSUMERWILLBE
RESPONSIBLEFOR:
CostsofservicecallsthatarelistedunderNORMAL
RESPONSIBILITIESOFTHECONSUMER.*
Costsofthetechnician'straveltothehomeandany
costs for pick up and delivery of the appliance
required because of service.
FULLONE-YEAR
WARRANTY
LIMITEDWARRANTY
(Applicabletothe
StateofAlaska)
WARRANTY
PERIOD
One year from original
purchasedate.
Timeperiodlistedabove.
This warranty applies only to products in ordinary household use, and the consumer is responsible for the
items listed below:
1. Proper use of the appliance in accordance with instructions provided with the product.
2. Proper installation by an authorized servicer in accordance with instructions provided with the appliance and in
accordance with all local plumbing, electrical and/or gas codes.
3. Proper connection to a grounded power supply of sufficient voltage, replacement of blown fuses, repair of loose
connections or defects in house wiring.
4. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves, etc., which
are not a part of the appliance when it was shipped from the factory.
5. Damages to finish after installation.
6. Replacement of light bulbs and/or fluorescent tubes (on models with these features).
This warranty does not cover the following:
1. CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING
FROM ANY BREACH OF THIS WRITTEN OR ANY IMPLIED WARRANTY.
Note: Some states do not allow the exclusion or limitation of incidental or consequential damages, so this limitation
or exclusion may not apply to you.
2. Service calls which do not involve malfunction or defects in workmanship or material, or for appliances not in ordinary
household use. The consumer shall pay for such service calls.
3. Damages caused by services performed by persons other than authorized Tappan servicers; use of parts other than
Frigidaire Company Genuine Renewal Parts; obtained from persons other than such servicers; or external causes such
as abuse, misuse, inadequate power supply or acts of God.
4. Products with original serial numbers that have been removed or altered and cannot be readily determined.
Keepyour billofsale, deliveryslip,or someotherappropriate paymentrecord. The dateonthe billestablishesthe warranty
period should service be required. If service is performed, it is in your best interest to obtain and keep all receipts. This
written warranty gives you specific legal rights. You may also have other rights that vary from state to state. Service under
this warranty must be obtained by following these steps, in order:
1. Contact Frigidaire Company Consumer Services or an authorized Tappan servicer.
2. If there is a question as to where to obtain service or parts, call or write our Consumer Relations Department at:
Tappan
P.O. Box 7181
Dublin, Ohio 43017
[phone]
Product features or specifications as described or illustrated are subject to change without notice. All warranties are made
by White Consolidated Industries, Inc. This warranty applies only in the 50 states of the U.S.A. and Puerto Rico.
*NORMAL
RESPONSIBILITIES
OF THE CON-
SUMER
EXCLUSIONS
IF YOU NEED
SERVICE
TAPPAN WALL OVEN WARRANTY
Your Tappan product is protected by this warranty
Your appliance is warranted by Frigidaire Company, a division of White Consolidated Industries, Inc. We authorize no person to change or add
to any of our obligations under this warranty. Our obligations for service and parts under this warranty must be performed by Frigidaire Company
Consumer Services or an authorized Tappan servicer.
