Target TG-350 User manual
TG-350
INSTRUCTIONS AND CARE
Congratulations, you have just purchased one of the finest spot cleaning guns available today. It is
manufactured to TEKMAR’s high quality standards from the best available materials and parts.
When used as directed it should provide years of trouble free service.
For safe operation it is important to understand that this is not a toy. It is a high powered airless
spray gun which has the potential, when not used as directed, to cause a serious puncture wound.
SAFE OPERATING INSTRUCTIONS
Never point the gun at any part of your body or at any other person.
Always check electric cord for damage before using. If damaged do not attempt any
temporary repairs.
Only use with adequate ventilation and always wear eye protection.
Use only approved cleaning solvents. Never spray flammable solutions into the air.
INSTRUCTION FOR USE
1. Fill fluid bottle 4/5 full and replace on gun. Squeeze trigger until gun primes and fluid comes out
of the nozzle.
2. Place garment to be cleaned on a clean absorbent cloth or exhaust surface. Direct a jet of
cleaning solvent through stain in a circular motion, until soil is flushed through.
3. To avoid ringing adjust nozzle to wide spray pattern and spray around wet edge to feather out
giving a smooth transition from wet to dry.
4. Always test fabric in an inconspicuous area to ensure color fastness.
AIR DRYER
1. Connect the supplied air hose to the gun using the knurled nut at the base of the handle.
Connect the other end of the hose to your compressor or central air. Air pressure must not
exceed 80psi or damage to the gun may occur and is not covered by the factory warranty. If the
line pressure is higher than 80psi, install a regulator to lower the pressure.
2. The air is actuated by pressing on the black air valve handle with your thumb. Use the air to
speed up the drying process and help eliminate rings
CARE OF GUN
No routine maintenance of the gun is required, however to ensure it’s long life never use with a
corrosive or water based cleaner (this will also void warranty).
For more information please contact
TECHNICAL MARKETING LTD.
P.O. BOX 4700
SANTA BARBARA, CA. 93140
TEL (805) 965 0704 FAX (805) 963 7794
CUSTOMER LINE (800) 564 1096
Website www.tekmarltd.com
T
TT
T
E
EE
E
K
KK
K
M
M M
M
A
A A
A
R
R R
R
TECHNICAL MARKETING , LTD.
TECHNICAL MARKETING , LTD.TECHNICAL MARKETING , LTD.
TECHNICAL MARKETING , LTD.
PRODUCT INFORMATION
SHIPPING
927 Indio Muerto St.
Santa Barbara, CA 93103
MAILING
P.O. Box 4700
Santa Barbara, CA 93140
ATLANTA SHIPPING
879 Davis Drive
Conyers, GA 30207
CUSTOMER LINE: 800/564-1096 •
••
•PHONE: 805/965-0704 •
••
•FAX: 805/963-7794
Item
No.
Part
No.
Description Item
No.
Part
No.
Description
1 350-01 Gun Housing 20 TG1 Nozzle
1-1 350-1-1 Hanging Hook 21 350-21 Container
2 350-02 Cover 22 350-22 Suction Tube
3 350-03 Coil Motor 23 350-23 Pump Screw
3 350-03B Coil Motor 220v 24 350-24 Terminal Block
4 350-04 Switch 25 350-25 Cable Locking Strip
5 350-05 Armature 26 350-26 90˚ Air Connector
6 350-06 Power Lead 27 350-27 Air Connection Hose
7 350-07 Armature Spring 28 350-28 Air Feed Tube
8 350-08 Volume Control 29 350-29 “O” Ring
9 350-09 Volume Spring 30 350-30 Air Trigger
10 350-10 Bolt A Set 31 350-31 Air Trigger Pin
11 350-11 Bolt B Set 32 350-32 Front Body
12 350-12 Case Screw Set 33 350-33 Locking Screw
13 350-13 Pump Assembly 34 350-34 Air Nozzle Nut
16 350-16 Motor Mount 35 350-35 Air Nozzle
17 350-17 Valve
TG350 PARTS
20
