Task Force Tips Extend-A-Gun XG12 Programming manual

©Copyright Task Force Tips LLC 2002-2020 LIX-512 August 17, 2020 Rev09
Manually Operated Extend-A-Gun
Model XG12
Telescoping Waterway for Deck Mounted Monitors
INSTRUCTIONS FOR INSTALLATION, SAFE OPERATION, AND MAINTENANCE
DANGER
Understand manual before use. Operation of this device without understanding the manual and
receiving proper training is a misuse of this equipment. Obtain safety information at tft.com/
serial-number
This equipment is intended for use by trained and qualied emergency services personnel for
reghting. All personnel using this equipment shall have completed a course of education
approved by the Authority Having Jurisdiction (AHJ).
This instruction manual is intended to familiarize reghters and maintenance personnel with
the operation, servicing, and safety procedures associated with this product. This manual
should be kept available to all operating and maintenance personnel.
TASK FORCE TIPS LLC
MADE IN USA • TFT.com
3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 • 219-462-6161 • Fax [phone]
3" NPT
EXTENDED
SHOWN WITH TFT MASTER NOZZLE
AND CROSSFIRE DECK GUN
RETRACTED
INTEGRAL
CROSSFIRE
OUTLET
** 3” NPT
MALE OUTLET
TRUCK SURFACE
TUBE BRACKET
TFT PART XGB-13
SADDLE BRACKET
3” NPT MALE 3” VICTAULIC MALE
FROM PUMP
ALTERNATE:
1) MOUNTING PLATE, 9” SQ.
TFT PART XGB-23
2) SADDLE BRACKET
TFT PART XGB-33
To make the Extend-A-Gun as versatile as
possible, three mounting bracket kits are offered.
Each kit has a different upper bracket. The lower
bracket is the same for all three.
XGB-13 TUBE/SADDLE
BRACKET SET
XGB-23 PLATE/SADDLE
BRACKET SET
XGB-33 SADDLE/SADDLE
BRACKET SET

©Copyright Task Force Tips LLC 2002-2020 LIX-512 August 17, 2020 Rev09
2
DANGER
PERSONAL RESPONSIBILITY CODE
The member companies of FEMSA that provide emergency response
equipment and services want responders to know and understand the
following:
1. Fireghting and Emergency Response are inherently dangerous activities
requiring proper training in their hazards and the use of extreme caution
at all times.
2. It is your responsibility to read and understand any user’s instructions,
including purpose and limitations, provided with any piece of equipment
you may be called upon to use.
3. It is your responsibility to know that you have been properly trained in
Fireghting and /or Emergency Response and in the use, precautions, and
care of any equipment you may be called upon to use.
4. It is your responsibility to be in proper physical condition and to maintain
the personal skill level required to operate any equipment you may be
called upon to use.
5. It is your responsibility to know that your equipment is in operable
condition and has been maintained in accordance with the manufacturer’s
instructions.
6. Failure to follow these guidelines may result in death, burns or other
severe injury.
FEMSA
Fire and Emergency Manufactures and Service Association
P.O. Box 147, Lynneld, MA 01940 • www.FEMSA.org

©Copyright Task Force Tips LLC 2002-2020 LIX-512 August 17, 2020 Rev09
3
1.0 MEANING OF SAFETY SIGNAL WORDS
2.0 SAFETY
3.0 GENERAL INFORMATION
3.1 SPECIFICATIONS
3.2 USE WITH SALT WATER
3.3 VARIOUS MODELS AND TERMS
3.4 XG12 SERIES DIMENSIONS
4.0 BRACKET SETS
4.1 SELECTION OF STRUCTURAL SUPPORT ON FIRE TRUCKS
4.2 BRACKET INSTALLATION
4.2.1 TUBE BRACKET INSTALLATION (EXTEND-A-GUN RC3 ONLY)
4.2.1.1 TUBE BRACKET WELDING
4.2.2 SADDLE BRACKET INSTALLATION
4.2.2.1 SADDLE BRACKET WELDING
4.2.3 PLATE BRACKET INSTALLATION
5.0 MANUAL EXTEND-A-GUN SIDE LOADS AT MOUNTING POINTS WORKSHEET
5.1 EXTEND-A-GUN LOAD CHARTS
5.2 INDICATOR LIGHT
5.2.1 INDICATOR SWITCH WIRING
6.0 MOUNTING MONITORS
7.0 USE OF DRAIN
8.0 OPERATING INSTRUCTIONS
8.1 EXTEND
8.2 RETRACT
9.0 WARRANTY
10.0 MAINTENANCE
10.1 LUBRICATION
10.2 REPAIR
11.0 EXPLODED VIEW AND PARTS LIST
12.0 OPERATION AND INSPECTION CHECKLIST
Table Of Contents

©Copyright Task Force Tips LLC 2002-2020 LIX-512 August 17, 2020 Rev09
4
1.0 MEANING OF SAFETY SIGNAL WORDS
A safety related message is identied by a safety alert symbol and a signal word to indicate the level of risk involved with a particular
hazard. Per ANSI Z535.6, the denitions of the four signal words are as follows:
DANGER
DANGER indicates a hazardous situation which, if not avoided, will result in death or serious
injury.
WARNING
WARNING indicates a hazardous situation which, if not avoided, could result in death or serious
injury.
CAUTION
CAUTION indicates a potentially hazardous situation which, if not avoided, could result in minor
or moderate injury.
NOTICE
NOTICE is used to address practices not related to physical injury.
2.0 SAFETY
DANGER
Working from an elevated position increases the risk of falling. Wet or slippery surfaces add to
this risk. Serious injury or death could occur. Watch footing when working on top of apparatus.
WARNING
The stream exiting a nozzle is very powerful and capable of causing injury and property damage.
Make sure the nozzle is securely attached and pointing in a safe direction before water is turned
on. Do not direct water stream to cause injury or damage to persons or property.
WARNING
The Extend-A-Gun may be used only in either the fully raised or fully lowered position. The unit
may become damaged if the water is turned on in any position other than fully extended or
retracted.
CAUTION Damage may occur if the truck drives under a low hanging object while the Extend-A-Gun RC
is extended. Shutting o󰀨 the water downstream of an Extend-A-Gun in the raised position traps
water preventing retraction. Drain water from the piping and retract the Extend-A-Gun RC before
moving the apparatus.
Pressurizing a retracted waterway with closed shuto󰀨s or caps on the monitor discharge disables
waterway extension. Relieving pressure trapped in the waterway will restore the lift function.
3.0 GENERAL INFORMATION
The Extend-A-Gun is a telescoping waterway designed to maximize reghter safety while expanding the capabilities of deck
mounted Master Stream devices. Its function is to elevate a mounted Master Stream device above other equipment on the apparatus,
providing greater clearance and freedom of movement to the device. Operators control elevation both to and from the storage
position by manually lifting and lowering the monitor. The Extend-A-Gun features a hard coat anodized aluminum nish and built in
sensor for connection to “monitor raised” light. The Extend-A-Gun features a 3” diameter waterway.
3.1 SPECIFICATIONS
EXTEND-A-GUN XG12
Waterway Size 3.0” (76mm)
Maximum Flow 1250 gpm (4800 l/min)
Maximum Pressure 200 psi (13.8 bar)
Lifting Capability 100 lbs (46 kg)
Operating Temperature Range -30°F to +120°F (-34°C to +49°C)
Table 3.1
3.2 USE WITH SALT WATER
Use with salt water is permissible provided the equipment is thoroughly cleaned with fresh water after each use. The service life of
the equipment may be shortened due to the e󰀨ects of corrosion, and is not covered under warranty

©Copyright Task Force Tips LLC 2002-2020 LIX-512 August 17, 2020 Rev09
5
3.3 VARIOUS MODELS AND TERMS
TUBE/SADDLE BRACKET
PLATE/SADDLE BRACKET
SADDLE/SADDLE BRACKET
INLET
(NPTM, BSPM, VICTAULIC)
OUTER TUBE
INNER TUBE
SLIDE BAR
PAWLS
(LOCK/UNLOCK
INDICATOR)
Figure 3.3

©Copyright Task Force Tips LLC 2002-2020 LIX-512 August 17, 2020 Rev09
6
3.4 XG12 SERIES DIMENSIONS
SHOWN WITH
TFT MASTER NOZZLE
AND CROSSFIRE DECK GUN
ALTERNATE:
1) MOUNTING PLATE, 9” SQ.
TFT PART XGB-23
2) SADDLE BRACKET
TFT PART XGB-33
3" NPT
**- OUTLETS SHOWN ARE
FOR MODELS XG12PL-XL & XG12VL-XL
FOR MODELS WITH 3” NPT OUTLET, ADD 1”
Figure 3.4

©Copyright Task Force Tips LLC 2002-2020 LIX-512 August 17, 2020 Rev09
7
4.0 BRACKET SETS
For safe dependable service, the Extend-A-Gun MUST be securely mounted. To make the Extend-A-Gun as versatile as possible,
three mounting bracket kits are o󰀨ered. Each kit has a di󰀨erent upper bracket. The lower bracket is the same in all three.
TUBE/SADDLE BRACKET SET
XGB-13 (3” Extend-A-Gun)
PLATE/SADDLE BRACKET SET
XGB-23 (3” Extend-A-Gun)
SADDLE/SADDLE BRACKET SET
XGB-33 (3” Extend-A-Gun)
Figure 4.0A Figure 4.0B Figure 4.0C
Task Force Tips strongly recommends that Extend-A-Gun be installed using the bracket sets sold by Task Force Tips that are
designed for this purpose. The Task Force Tips bracket sets are designed to t the Extend-A-Gun outer tube very closely to prevent
distortion of the outer tube and to give it adequate support.
4.1 SELECTION OF STRUCTURAL SUPPORT ON FIRE TRUCKS
When the Extend-A-Gun is in the extended position, the nozzle reaction force can exceed 3000 lbs. These loads are transferred
directly to the mounting brackets and the structural members to which they are attached. It is crucial that the structural members
selected can withstand these forces.
4.2 BRACKET INSTALLATION
4.2.1 TUBE BRACKET INSTALLATION (EXTEND-A-GUN RC3 ONLY)
This kit contains a six inch square steel tube with two U-bolts to be used as the upper bracket, and a saddle bracket similar to a heavy
duty mu󰀪er clamp for the lower bracket. Both brackets must be used. This kit is designed for factory installation on new equipment.
The tube bracket is welded onto the truck tubular framework as shown on the Tube Bracket Welding Diagram. (see section 4.3.1.1)
The lower bracket, as shown in the Saddle Bracket Welding Diagram (see section 4.3.2.1), is welded to an additional support and
clamped as low at possible on the bottom of the Extend-A-Gun tube. Make sure the welds are capable of withstanding the forces
shown on the SIDE LOADS AT MOUNTING POINTS worksheet. (see section 5.0) The Extend-A-Gun may be installed in the brackets
after the truck is painted. Use thread locker supplied in the kit on U-bolt threads. Torque the nuts on the U-bolts used in the tube
(upper) to 15-17 lbf·ft. Torque the nuts on the U-bolts used in the saddle (lower) to 36-40 lbf·ft.
4.2.1.1 TUBE BRACKET WELDING
TORQUE NUTS
to 15-17 lbf·ft
FILLET WELD 8 PLACES
EACH SIDE TYP.
TRUCK CROSS
MEMBERS
6.0” SQUARE
4.0” HIGH
TRUCK CROSS
MEMBERS
FILLET WELD
8 PLACES TYP.
TORQUE NUTS
to15-17 lbf·ft
Figure 4.2.1.1A Figure 4.2.1.1B

©Copyright Task Force Tips LLC 2002-2020 LIX-512 August 17, 2020 Rev09
8
4.2.2 SADDLE BRACKET INSTALLATION
This kit contains two steel saddle brackets and U-bolts, and is designed for factory installation on new equipment. Both brackets
must be used. To minimize stress, the brackets should be as far apart as possible when clamped to the Extend-A-Gun tube. The
welds must be able to withstand the forces shown on the SIDE LOADS AT MOUNTING POINTS worksheet. (see section 5.0) The
Extend-A-Gun may be installed in the brackets after the truck is painted. Use Loctite supplied in the kit on U-bolt threads. Torque the
nuts used on the U-bolts to 36-40 lbf·ft.
4.2.2.1 SADDLE BRACKET WELDING
WELD 8 PLACES
TYP
1
2
3
TORQUE NUTS
to 36-40 lbf·ft
WELD 4 PLACES
TYP
1
2
3
TORQUE NUTS
to 36-40 lbf·ft 1/4" MAXIMUM
THICKNESS
A
C
B
D
E
TORQUE NUTS
to 36-40 lbf·ft
Figure 4.2.2.1A Figure 4.2.2.1B Figure 4.2.2.1C
4.2.3 PLATE BRACKET INSTALLATION
This kit may be used in either new or retro-t installations. The top
plate with its bracket may be bolted above or below an existing
deck.
The lower saddle bracket is installed as shown in the Saddle
Bracket Welding Diagram. (see section 4.3.2.1) Both brackets
must be used. To minimize stress, the brackets should be as far
apart as possible when clamped to the Extend-A-Gun tube.
Refer to the SIDE LOADS AT MOUNTING POINTS worksheet
(see section 5.0) to ensure the mounting points can withstand
these forces. Use Loctite® supplied in the kit on U-bolt threads.
Torque the nuts used on the U-bolts to 36-40 lbf·ft.
F
G
H
4
5
6
7
DECK
BOTTOM
VIEW
SQUARE
B.H.C.
SQUARE
Figure 4.2.3
Part Identication US Standard Units Metric Units
TORQUE U-BOLTS 30-40 lbf·ft (49-54 N·m)
A = Center Distance 5.0” (127mm)
B = Height 1.5” (38mm)
C = Width 3.0” (76mm)
D = U-Bolt Size 1/2-13 UNC
E = Length 6.0” (152mm)
F = Square Pattern on Plate 7.5” (191mm)
G = Plate Length and Width 9.0” x 9.0” (288mm x 288mm)
H = Hole Diameter 4-5/8” (117mm)
1 = Hex Nut (2 rqd) VT50-13NT
2 = Saddle Bracket XG486
3 = U-Bolt XG476
4 = Deck Bolt 1/2-13 Hex Bolt
5 = Washer 1/2” I.D.
6 = Plate Bracket XG485
7 = Deck Nut 1/2-13 Hex Nut
Table 4.2.3

©Copyright Task Force Tips LLC 2002-2020 LIX-512 August 17, 2020 Rev09
9
5.0 MANUAL EXTEND-A-GUN SIDE LOADS AT MOUNTING POINTS WORKSHEET
An interactive version of this worksheet is available at tft.com/Library/Instructions for Installation, Safe Operation and Maintenance.
WARNING
Reaction forces generated by master stream ows are capable of causing injury and property
damage if not properly supported. The Extend-A-Gun must be securely mounted to rigid truck
structural members.
Before installing the Extend-A-Gun, qualied persons MUST determine the forces that will be
exerted and select suitable structural members and bracket mounting locations.
• Nozzle reaction force which can be as high as 900 lbf (400 kg) for 3” models and 1500 lbf (680
kg) for 4” models.
• The forces acting on the mounting brackets when the Extend-A-Gun is in the extended
position are higher than the forces in a normal deck gun installation. Use SIDE LOADS AT
MOUNTING POINTS worksheets for calculations
• Install the upper and lower brackets as far apart as possible to minimize the amount of stress
on the brackets.
Qualied individuals should install mounting brackets, Extend-A-Guns and monitors.
• The Extend-A-Gun must be securely mounted to rigid truck support members.
• Do not use anges or pipe made from plastic for monitor mounting.
• Inferior welding or poor plate installation could result in serious injury or equipment damage.
• Torque all fasteners to specied values.
I certify that I have accurately and completely worked through the Extend-A-Gun XG12 Side Load Worksheet prior to Extend-A-Gun installation.
NAME:_____________________________________________ DATE:__________________
1) Determine the distance, D1, in inches,
from the center of the monitor elevation joint
to the bottom of the threads in the monitor inlet.
Task Force Tips CROSSFIRE
Elkhart Stinger Mod. 8297-98 w/companion flange
Akron Apollo Mod. 3422 w/companion flange
Akron Apollo Mod. 3422 threaded on
D1 FOR MOST COMMON INSTALLATIONS
D1 = 1”
D1 = 4”
D1 = 5”
D1 = 6”
D1= inches
2) Locate the value of D1 in the charts on the following
page. Find the desired HEIGHT (from the center of
the upper bracket to the center of the stream) in the
HEIGHT column.
3) Locate D2 (the distance from the bottom of the latch
casting to the center of the upper mounting bracket)
for the chosen HEIGHT in inches.
D2= inches
4) Determine the distance, D3 in inches (from the center
of the upper mounting bracket to the center of the
lower mounting bracket) for the proposed installation.
D3 MUST be between D3 min abd D3 max.
D3= inches
WHEN D2 IS LARGE AND D3 IS SMALL
THE REACTION FORCES, F1 & F2, ON
THE BRACKETS ARE LARGER.
WHEN D2 IS SMALL AND D3 IS LARGE
THE REACTION FORCES, F1 & F2, ON
THE BRACKETS ARE SMALLER.
ALWAYS MAKE D3 AS LARGE AS POSSIBLE.
D1
F1
F2
D2
D3 15.7"
C Clamp
5) Calculate forces on brackets:
D1 + D2
+ D3 + 15.7 = L inches
6) Multiply L by 900:
L X 900 = M inches · pounds
7) Divide M by D3:
M /D3 = F1 pounds
8) Subtract 900 from F1:
- 900 = F2 pounds
F1
NOTE:
F1 MUST be less than 3100 lbf. F2 MUST be less than 2200 lbf.
The proposed installation MUST be capable of withstanding forces of this magnitude.

©Copyright Task Force Tips LLC 2002-2020 LIX-512 August 17, 2020 Rev09
10
5.1 EXTEND-A-GUN LOAD CHARTS
This load chart is for the 12” manual Extend-A-Gun (model XG12) only.
Crossre
D1 D2 HEIGHT D3 min D3 max
1
1 18 7 14
2 19 8 13
3 20 8 12
4 21 8 11
5 22 9 10
6 23 9 9
D1 D2 HEIGHT D3 min D3 max
2
1 19 8 14
2 20 8 13
3 21 8 12
4 22 9 11
5 23 9 10
D1 D2 HEIGHT D3 min D3 max
3
1 20 8 14
2 21 8 13
3 22 9 12
4 23 9 11
5 24 10 10
Apollo Intergral Threads
D1 D2 HEIGHT D3 min D3 max
4
1 21 8 14
2 22 9 13
3 23 9 12
4 24 10 11
5 25 10 10
Apollo Flange
D1 D2 HEIGHT D3 min D3 max
5
1 22 9 14
2 23 9 13
3 24 10 12
4 25 10 11
Stinger
D1 D2 HEIGHT D3 min D3 max
6
1 23 9 14
2 24 10 13
3 25 10 12
4 26 11 11
D1 D2 HEIGHT D3 min D3 max
7
1 24 10 14
2 25 10 13
3 26 11 12
4 27 11 11
D1 D2 HEIGHT D3 min D3 max
8
1 25 10 14
2 26 11 13
3 27 11 12
4 28 11 11
D1 D2 HEIGHT D3 min D3 max
9
1 26 11 14
2 27 11 13
3 28 11 12
D1 D2 HEIGHT D3 min D3 max
10
1 27 11 14
2 28 11 13
3 29 12 12

©Copyright Task Force Tips LLC 2002-2020 LIX-512 August 17, 2020 Rev09
11
5.2 INDICATOR LIGHT
The Extend-A-Gun has a built in switch to control an indicator light on the truck dash board showing that the Extend-A-Gun is in the
extended position. This is to help prevent damage that would occur if the deck gun hits a low overhanging object. Do not move the
truck with the Extend-A-Gun in the extended position.
5.2.1 INDICATOR SWITCH WIRING
The Extend-A-Gun latch mechanism contains a magnetic switch. This switch is intended to be used with a MONITOR EXTENDED
warning light. The magnetic switch in the Extend-A-Gun is a normally open switch, and the switch is closed when the Extend-A-Gun
is in the down position. The enclosed relay MUST BE USED to limit the current through the switch.
V4155 Relay 12VDC
15VDC Max
10 Watt Coil Max
EXTEND-A-GUN
SWITCH
MOUNT RELAY ON
ELECTRICAL PANEL
BATTERY
SPARE
CIRCUIT
BREAKERS
87
86 85
30
87a
SWITCH IS CLOSED WHEN
EXTEND-A-GUN IS IN THE DOWN POSITION
MOUNT PANEL
LIGHT IN DASH
Figure 5.2.1A
1. After the Extend-A-Gun is permanently installed, screw the threaded switch body into the tapped hole in the Extend-A-Gun latch
casting. Be careful not to twist or break the wires.
2. Mount the relay on the electrical panel with the terminals accessible.
3. Drill a 1/2” diameter hole in the dash board for the panel light. Leave enough room for a 1-13/16” diameter label around the light
or a 2” wide x 1-1/2” high label next to the light. Apply one of the two warning labels and push the panel light through the hole in
the dash.
4. Connect the labeled wires on the switch to terminal #85 on the relay and ground respectively.
5. Connect the terminals on the panel light to terminal #87A on the relay and ground respectively.
6. Connect a wire from a “spare” position on the trucks circuit breaker panel to terminals #30 and #86. The circuit from the “spare”
position in the fuse block should only be energized when the ignition switch is in the ON position.
INSTRUCTIONSINSTRUCTIONS
Support weight of monitor.
Lift slide bar to disengage latch.
Raise or lower monitor, with slide bar released,
until latch engages.
Check that slide bar is fully down and latches
are flush with housing.
1)
2)
3)
4)
TASK FORCE TIPS, 3701 Innovation Way, Valparaiso, IN 46383-9327
[phone] • 800 348-2686 • www.tft.com • MADE IN U.S.A.
XXGL010
Read manual before use.
WARNING
When Light is ON,
Deck Monitor is
Lower Before
Moving Vehicle.
EXTENDED.
XGL020XGL020
WARNING
XGL02 5XGL 025
WARNING
When Light is ON,
Deck Monitor is
EXTENDED.
Lower Before
Moving Vehicle.
Attach the instruction label (XGL010) to a smooth
Surface where it can be seen be the person operating
The Extend-A-Gun and monitor.
Attach the warning label (XGL020) next to the indicator light
or warning label (XGL025) around the indicator light
on the truck dashboard.
Figure 5.2.1B

©Copyright Task Force Tips LLC 2002-2020 LIX-512 August 17, 2020 Rev09
12
6.0 MOUNTING MONITORS
A Task Force Tips Crossre® monitor may be mounted in one of two ways. We recommend that it be mounted directly on Extend-
A-Gun models XG18PL-XL, or XG18VL-XL, which have integral Crossre bases built in. Alternatively, it can be mounted on Extend-
A-Gun models XG18PL-PL, or XG18VL-PL using Task Force Tips part XFF-APL Truck Mount Base, which ts only the Task Force
Tips Crossre.
Monitors with an –RL inlet may be mounted directly to Extend-a-Guns with –RL outlets.
Monitors with a 3” NPTF inlet may be mounted directly to Extend-A-Guns with a –PL outlet.
Monitors with 3” 4-Bolt ANSI ange inlet may be mounted to Extend-A-Guns with a –PL outlet with the addition of an XFF-CPL
Companion Flange Kit.
7.0 USE OF DRAIN
The Extend-A-Gun comes with a ¾” NPT hole in the inlet. This
is designed to be used as a drain or plugged if a drain is used
elsewhere. A drain must be employed to remove excess water
from the system. This prevents freezing and allows the unit to be
parked.
Figure 7.0
WARNING
Equipment may be damaged if frozen while containing signicant amounts of water. Such damage
may be di󰀩cult to detect visually. Subsequent pressurization can lead to injury or death. Any time
the equipment is subject to possible damage due to freezing, it must be tested and approved for
use by qualied personnel before being considered safe for use.

©Copyright Task Force Tips LLC 2002-2020 LIX-512 August 17, 2020 Rev09
13
8.0 OPERATING INSTRUCTIONS
WARNING
The Extend-A-Gun must be lowered in the park position before the truck is driven or moved.
Damage or injury may occur if the truck drives under a low hanging object, while the Extend-
A-Gun is extended.
WARNING
The Extend-A-Gun may be used only in either the fully raised or fully lowered position. The
unit may become damaged if the water is turned on in any position other than fully extended or
retracted.
Indicators that the Extend-A-Gun is fully raised or lowered are:
• The Slide Bar is down
• The Pawls are ush with the housing
• The word “UNLOCKED” on the top of the Pawls is NOT VISIBLE
CAUTION Lifting the slide bar to lower the deck gun with out supporting the weight of the deck gun can
cause the deck gun to fall. This can cause injury. Always support the weight of the deck gun when
lifting the slide bar.
NOTICE Do not lift the slide bar while owing water. The mechanism will not unlatch, but the mechanism
can be damaged.
8.1 EXTEND
TO LOCK - SLIDE BAR DOWN
PAWLS
FLUSH
WITH
CASTING
TO UNLOCK - LIFT SLIDE BAR
PAWLS
PULLED
AWAY FROM
THE CASTING
“UNLOCKED”
VISIBLE
1. Make sure the valve to the deck gun is closed.
2. Lift the slide bar on the Extend-A-Gun latch mechanism
with one hand and lift the deck gun straight up with
your other hand. The slide bar should be released
after the deck gun has moved out of the retracted
position. Notice the word “UNLOCKED” appear on
the top surface of the pawls.
3. When the deck gun is in the extended position it will
not be possible to lift it any higher. The pawls will
retract, the slide bar will move down ush with the
housing and the word “UNLOCKED” is no longer
visible.
4. Make certain that the pawls are ush with the sides
of the housing and that the word “UNLOCKED” is not
visible before operating the valve to the deck gun.
8.2 RETRACT
1. Make sure the valve to the deck gun is closed.
2. Lift the deck gun slightly with one hand to take the
weight o󰀨 the latch mechanism and lift the slide bar
with your other hand. Notice the word “UNLOCKED”
appears on the top surface of the pawls.
3. Lower the deck gun to the retracted position. The
slide bar should be released after the deck gun leaves
the extended position.
4. Make certain that both pawls are ush with the sides
of the housing and that the word “UNLOCKED” is not
visible before opening the valve to the deck gun.
Figure 8.1

©Copyright Task Force Tips LLC 2002-2020 LIX-512 August 17, 2020 Rev09
9.0 WARRANTY
Task Force Tips LLC, 3701 Innovation Way, Valparaiso, Indiana 46383-9327 USA (“TFT”) warrants to the original purchaser of
its products (“equipment”), and to anyone to whom it is transferred, that the equipment shall be free from defects in material and
workmanship during the ve (5) year period from the date of purchase. TFT’s obligation under this warranty is specically limited to
replacing or repairing the equipment (or its parts) which are shown by TFT’s examination to be in a defective condition attributable to
TFT. To qualify for this limited warranty, the claimant must return the equipment to TFT, at 3701 Innovation Way, Valparaiso, Indiana
46383-9327 USA, within a reasonable time after discovery of the defect. TFT will examine the equipment. If TFT determines that
there is a defect attributable to it, TFT will correct the problem within a reasonable time. If the equipment is covered by this limited
warranty, TFT will assume the expenses of repair.
If any defect attributable to TFT under this limited warranty cannot be reasonably cured by repair or replacement, TFT may elect to
refund the purchase price of the equipment, less reasonable depreciation, in complete discharge of its obligations under this limited
warranty. If TFT makes this election, claimant shall return the equipment to TFT free and clear of any liens and encumbrances.
This is a limited warranty. The original purchaser of the equipment, any person to whom it is transferred, and any person who is
an intended or unintended beneciary of the equipment, shall not be entitled to recover from TFT any consequential or incidental
damages for injury to person and/or property resulting from any defective equipment manufactured or assembled by TFT.
It is agreed and understood that the price stated for the equipment is in part consideration for limiting TFT’s liability. Some states do
not allow the exclusion or limitation of incidental or consequential damages, so the above may not apply to you.
TFT shall have no obligation under this limited warranty if the equipment is, or has been, misused or neglected (including failure to
provide reasonable maintenance) or if there have been accidents to the equipment or if it has been repaired or altered by someone
else.
THIS IS A LIMITED EXPRESS WARRANTY ONLY. TFT EXPRESSLY DISCLAIMS WITH RESPECT TO THE EQUIPMENT ALL
IMPLIED WARRANTIES OF MERCHANTABILITY AND ALL IMPLIED WARRANTIES OF FITNESS FORA PARTICULAR PURPOSE.
THERE IS NO WARRANTY OF ANY NATURE MADE BY TFT BEYOND THAT STATED IN THIS DOCUMENT.
This limited warranty gives you specic legal rights, and you may also have other rights which vary from state to state.

©Copyright Task Force Tips LLC 2002-2020 LIX-512 August 17, 2020 Rev09
10.0 MAINTENANCE
The Extend-A-Gun requires little maintenance. The Extend-A-Gun should be kept clean and free of dirt. All controls should be
checked for freedom of movement and proper operation before each use. Any inoperable or damaged parts should be repaired or
replaced immediately. Consult factory for recommended service procedure.
10.1 LUBRICATION
The Extend-A-Gun is permanently lubricated on the cup seal. If lubricant has been removed during service, apply a thin lm of White
Lithium Grease on seal surfaces.
10.2 REPAIR
Factory service is available with repair time seldom exceeding one day in our facility. Factory serviced equipment is repaired by
experienced technicians, wet tested to original specications, and promptly returned. Repair charges for non-warranty items are
minimal. Any returns should include a note as to the nature of the problem and whom to reach in case of questions.
Repair parts and service procedures are available for those wishing to perform their own repairs. Task Force Tips assumes no liability
for damage to equipment or injury to personnel that is a result of user service. Contact the factory or visit the web site at tft.com for
parts lists, exploded views, test procedures and troubleshooting guides.
Performance tests shall be conducted on the equipment after a repair, or anytime a problem is reported to verify operation in
accordance with TFT test procedures. Consult factory for the procedure that corresponds to the model and serial number of the
equipment. Any equipment which fails the related test criteria should be removed from service immediately. Troubleshooting guides
are available with each test procedure or equipment can be returned to the factory for service and testing.
CAUTION Any alterations to the product or its markings could diminish safety and constitutes a misuse of
this product.
NOTICE
All replacement parts must be obtained from the manufacturer to assure proper operation of the
device.
11.0 EXPLODED VIEW AND PARTS LIST
Exploded views and part lists are available at tft.com/serial-number.

©Copyright Task Force Tips LLC 2002-2020 LIX-512 August 17, 2020 Rev09
TASK FORCE TIPS LLC
MADE IN USA • TFT.com
3701 Innovation Way, Valparaiso, IN 46383-9327 USA
800-348-2686 • 219-462-6161 • Fax [phone]
12.0 OPERATION AND INSPECTION CHECKLIST
BEFORE EACH USE, appliances must be inspected to this checklist:
1. There is no obvious damage such as missing, broken or loose parts, damaged labels, etc.
2. All controls move freely and operate properly.
3. The Extend-A-Gun operates freely without binding throughout its range of travel.
4. There are no leaks when the Extend-A-Gun is owing water.
BEFORE BEING PLACED BACK IN SERVICE, appliances must be inspected to this list:
1. All controls and adjustments are operational.
2. There are no broken or missing parts.
3. There is no damage to the Extend-A-Gun or attached monitor that could impair safe operation (e.g. detents, cracks,
corrosion, or other defects).
4. The waterway is clear of obstructions.
5. The Extend-A-Gun is clean and markings are legible.
WARNING
Equipment failing any part of the checklist is unsafe for use and must have the problem corrected
before use or being placed back into service. Operating equipment that has failed the checklist is
a misuse of this equipment.
