TATA Motors Connectnext User manual

1
CONNECTNEXT® INFOTAINMENT SYSTEM USER’S MANUAL
Dear Customer,
Welcome to the CONNECTNEXT® Infotainment System User's Manual. The infotainment system in your vehicle provides you with
state of the art in-car entertainment to enhance your driving experience.
Before using the infotainment system for the first time, please ensure that all users read this manual carefully. The manual will
familiarize you with the infotainment system of your car and its functionalities. It also contains instructions on how to use the
infotainment system in a safe and effective manner.
We insist that all service and maintenance of the infotainment system of your car must be done only at authorized TATA service
centers. Incorrect installation or servicing can cause permanent damage to the system.If you have any further questions about the
infotainment system, please get in touch with the nearest Tata Dealership. We will be happy to answer your queries and value your
feedback.
We wish you a safe and connected drive!

2
CONTENTS
CONTENTS
1ABOUT THIS MANUAL 2INTRODUCTION 3GETTING STARTED
Conventions .................................. 4
Safety Guidelines......................... 5
Trademarks .................................... 7
Warranty Clauses ......................... 8
Control Elements Overview .....10
Other Modes of Control.............16
System Usage ................................21
System ON/OFF............................ 26
Manage General Settings ......... 28
Change Audio Settings.............. 30
Change Volume Settings .......... 33
Reset to Factory Default............ 36
Software Details........................... 38
4RADIO 5MEDIA 6PHONE
Overview ........................................ 39
Radio Operations......................... 41
Overview.........................................46
Playing a Media Source..............48
Music Related Functions ...........52
Pair Devices.................................... 58
Manage Paired Devices ............. 62
Phone Functions.......................... 64

3
CONTENTS
7CONNECTNEXT® APPS 8VEHICLE 9FREQUENTLY ASKED QUES-
TIONS
General Information................... 72
Install CONNECTNEXT® App .... 74
Config CONNECTNEXT® App... 75
Apps DISCLAIMER ....................... 76
Display Vehicle Setup Screen ..78
Set Lock/Unlock Options...........79
Manage Park Assist......................81
Manage Exterior Lights..............85
Overview of Climate Control ...86
Frequently Asked Questions ... 88
10 ABBREVIATIONS 11 INDEX
Abbreviations ............................... 90 Index.................................................91

4
ABOUT THIS MANUAL CONVENTIONS
ABOUT THIS MANUAL
This guide introduces you to the CONNECTNEXT®
Infotainment system and details its controls, options and
operations.
In addition, the guide contains:
 Illustrations to provide orientations or identification of
various options like buttons and menus.
 Cautions related to a topic such as Danger alerts,
Security alerts, Warning statements, Caution notices and
General notes.
 A list of abbreviations used in this guide with their
explanation.
 An alphabetical index for quick identification of required
topics.
CONVENTIONS
!DANGER :
Text that indicates to actions that might
cause harm to personnel.
!SECURITY ALERT:
Text that indicates to actions which
increases the potential for unauthorized
access.
!WARNING
:
Text that indicates to actions that might
cause harm to the equipment.
!CAUTION
:
Text that call for attention.
NOTE:
Text that provides some additional
important information, which when
ignored can cause inconvenience or tips
that will help you in using the equipment.
01

5
ABOUT THIS MANUALSAFETY GUIDELINES
SAFETY GUIDELINES
!DANGER :
The infotainment system must be used in
a way that allows you to drive the vehicle
safely at all times. Failure to do so may
result in an accident involving serious
injury or death.
Keep this manual in the vehicle, so it will be handy for you to
refer, when needed. If you sell or lend the vehicle, make sure
this manual is available in the vehicle along with other
standard booklets.
Please read and follow the safety guidelines listed in this
section to avoid injury or property damage.
GENERAL SAFETY GUIDELINES
!WARNING
:
The infotainment system is a
sophisticated electronic device. Do not
allow improper access of the infotainment
system.
!DANGER :
Permanent hearing loss may occur if you
play your music at loud volumes for
prolonged duration. Exercise caution
when setting the volume of your
infotainment system.
!DANGER :
Exposure of the infotainment system to
water or excessive moisture can cause
electric shocks, fire, or other damages.
01

6
ABOUT THIS MANUAL SAFETY GUIDELINES
SAFETY GUIDELINES WHILE DRIVING
!DANGER :
Glance at the screen of the infotainment
system only when necessary and safe to
do so. If prolonged viewing of the screen
is necessary, park in a safe location and
engage the hand brake.
!DANGER :
Make certain that the volume level of the
infotainment system is set to a level that
allows you to hear outside traffic and
other warnings.
SYSTEM CARE AND MAINTENANCE
Exert at most care while handling the infotainment system as
partial or complete loss of the infotainment system functions
due to intentional misuse is not covered under warranty.
Some guidance for using or maintaining the system are listed
below:
!WARNING
:
Parking under direct sunlight for
prolonged duration can result in high
temperatures inside your car, which can
damage your infotainment system, if
used. So, before using the system let the
car interior to cool down.
!WARNING
:
Do not open the infotainment system as
incorrect handling can damage the
system. Further, warranty is void, if seal is
broken.
!WARNING
:
Do not replace the vehicle speakers or fit
additional speakers with aftermarket
speakers. It may lead to the
malfunctioning or even damage of the
infotainment system.
01

7
ABOUT THIS MANUALTRADEMARKS
!WARNING
:
Do not apply sticky or strong alcohol
based spray, lotion or liquid on the
infotainment system while cleaning the
vehicle dashboard. This may cause
permanent damage to the system button
functions, knob operations or the display
screen. It may also lead to the
deterioration of the system paint.
!WARNING
:
Avoid addition of any accessories such as
external amplifiers, which will lead to the
modification of the standard factory
wiring connections. As such unauthorized
interconnections, can result in the
malfunctioning of the infotainment
system. Always contact the Tata dealer for
the changes to the vehicle or system.
!WARNING
:
Usage of paint or color on the
infotainment system can make the
moving parts sticky and stop them from
functioning correctly.
!WARNING
:
Ensure that any liquid does not enter the
infotainment system, as it will lead to the
failure of radio. The warranty of the
system will be void, if liquid ingress marks
are observed inside the system.
!WARNING
:
Do not use excessive force while handling
the infotainment system, USB slot, AUX-In
slot and so on. It might cause damage to
the system or component.
TRADEMARKS
Apple, Apple CarPlay, Siri, iPod and iPhone are trademarks of
Apple Inc., registered in the U.S. and Other countries.
Android and Android Auto are trademarks of Google Inc.
01

8
ABOUT THIS MANUAL WARRANTY CLAUSES
WARRANTY CLAUSES
The warranty clauses applicable to the infotainment system
are listed below:
1. Warranty is applicable in India only.
2. Warranty for the product is against defective materials
and manufacturing faults for 36 months / 36,000 km
(whichever comes earlier) from the date of the first
sale of vehicle.
3. LCD Display is covered for 12 months / 36,000km
(whichever comes earlier) from the date of the first
sale of vehicle.
4. Warranty is expressly not applicable under the
following conditions:
Where the product has been dismantled,
repaired, altered, modified or damaged due
to user negligence and misuse
The serial number of the product been
removed, defaced or altered.
Warranty void sticker is removed or tampered
Improper usage such as wrong electrical sup-
ply / voltage setting causing damage to the
equipment.
Tampered or serviced or repaired by any
agency not authorized by Tata Motors Lim-
ited.
01

9
INTRODUCTIONWARRANTY CLAUSES
INTRODUCTION
The CONNECTNEXT® infotainment system provides you with
a bundle of high-end functionalities to:
 Manage in-vehicle entertainment capabilities
 Handle certain vehicle feature controls
 View information about some vehicle features
Key features of the infotainment system include:
 3.5” inch ASTN Display
 4 Channel Audio
 AM and FM Tuner Bands with 20 station memories on
each band
 Speed Dependent Volume Control
 Display OFF feature for distraction free night drive
 USB, Aux and Bluetooth Audio media support
 Pairing with multiple Phone handsets (up to 10 devices)
through Bluetooth for Phone and Music supports like
Audio streaming
 Integrated with vehicle components like FATC and Park
Assist System and displays related information
 Vehicle feature control support like handling vehicle
door locking and Approach lights
 Infotainment system control through Steering Wheel
Controls.
NOTE:
Some of the vehicle features like park
assist system, Steering Wheel Controls
(SWC), park assist system, FATC, locking,
and lighting are not standard in every
vehicle variant. Features that are
unavailable in the vehicle cannot be
controlled using the infotainment system.
Please refer to the Owner’s Manual of your
vehicle or check with your vehicle dealer
to confirm the list of features available in
your vehicle.
02

10
INTRODUCTION CONTROL ELEMENTS OVERVIEW
CONTROL ELEMENTS OVERVIEW
The control elements, buttons and knobs, that are available
on the infotainment system allows you to control the
infotainment system. It provides you with quick and easy
access to the commonly used functions and options of the
infotainment system.
678
Figure 1: CONNECTNEXT® Infotainment System Control Elements
345
2
3
02

11
INTRODUCTIONCONTROL ELEMENTS OVERVIEW
Table 1: Infotainment System Control Elements
Sl
No
Control
Elements Description
1
Volume Rotary
Knob
 Clock Wise:
Increases the volume.
 Anti-Clock Wise:
Decreases the volume.
 Single Press:
System Switch Off Mode: System On
Media On: Play/Pause or Mute/Unmute Media
Radio/AUX: Mute/Unmute
 Long Press:
System Switch Off Mode: System On
Media On/Off: Turns Media Off/Media On
2
Home button
 Single Press & Long Press:
Displays home screen with current media/audio source playing in the background.
NOTE:
During high priority activities like Park Assist and Active Phone Call, if the Home
button is pressed, no action will be performed.
02

12
INTRODUCTION CONTROL ELEMENTS OVERVIEW
3
Favorite
button
This is a configurable button, which can be set as the shortcut for any of the below listed
functionalities:
1. Source (Toggle)
2. Audio Setup
3. Setup
 Single Press
Opens the currently configured shortcut. If no shortcut is configured, lists the configu-
rable functionalities.
 Long Press
Displays the list of configurable functionalities or allows to set a different functionality as
the shortcut.
Table 1: Infotainment System Control Elements
Sl
No
Control
Elements Description
Figure 2: Favorite Screen
02

13
INTRODUCTIONCONTROL ELEMENTS OVERVIEW
4
Seek Down
button
 Single Press:
USB & Bluetooth Audio: Plays the previous track.
Radio: Plays previous preset.
 Long Press:
USB & Bluetooth Audio: Fast rewinds the current track.
Radio: Enables auto seek down.
5
Seek Up
button
 Single Press:
USB & Bluetooth Audio: Plays the next track.
Radio: Plays next preset.
 Long Press:
USB & Bluetooth Audio: Fast forwards the current track.
Radio: Enables auto seek up.
Table 1: Infotainment System Control Elements
Sl
No
Control
Elements Description
02

14
INTRODUCTION CONTROL ELEMENTS OVERVIEW
6
Phone button
 Single Press & Long Press:
If a phone is connected, displays the Phone menu.
If phone is not connected, displays the Bluetooth Setup screen.
NOTE:
If no further action is taken, returns to the menu/screen from which the Phone
button was pressed.
Incoming Phone Call: Accepts (Connects) the Phone call.
Active Phone Call: Displays the Options screen with Hold and Mute Microphone options.
7
Back button
 Single Press & Long Press:
Back to the previous menu or screen, if applicable.
NOTE:
During high priority activities like Park Assist and Active Phone Call, if the Back
button is pressed, no action will be performed.
Table 1: Infotainment System Control Elements
Sl
No
Control
Elements Description
02

15
INTRODUCTIONCONTROL ELEMENTS OVERVIEW
8
Menu Rotary
Knob
 Clock Wise:
USB: Previews next track. On knob press, plays the track.
Radio: Enables manual tune up of FM/AM stations.
Setup, Home Screen, Incoming and Active Phone Calls: Scrolls down or right through a
menu/list like call logs, setup options, media list, home screen tiles or radio presets.
 Anti-Clock Wise:
USB: Previews previous track. On knob press, plays the track.
Setup, Home screen, Incoming and Active Phone Calls: Scrolls up or left through a menu/
list like call logs, setup options, media list, home screen tiles or radio presets.
 Single Press & Long Press:
Selects the selection i.e. a track, a menu, an option, or a FM/AM station/preset.
Incoming Phone Calls: Receives/Rejects the incoming phone call.
Outgoing Phone Call: Ends the outgoing phone call.
Table 1: Infotainment System Control Elements
Sl
No
Control
Elements Description
02

16
INTRODUCTION OTHER MODES OF CONTROL
OTHER MODES OF CONTROL
In addition to the control elements on the infotainment
system, the system can also be controlled from the:
 Steering Wheel controls
Steering wheel control elements provide you the flexibility of
controlling your infotainment system even while you are
driving without distracting your attention.
NOTE:
Voice recognition feature is unavailable
for this variant of the vehicle.
02

17
INTRODUCTIONOTHER MODES OF CONTROL
STEERING WHEEL CONTROL ELEMENTS
Figure 3: Steering wheel control elements
2
7
3
6
1
4
5
02

18
INTRODUCTION OTHER MODES OF CONTROL
Table 2: Steering Wheel Control Elements
Sl
No
Control
Element Description
1
Media Source
 SP/LP:
Toggles between the available Media Sources
2
Increase
Volume
 SP:
Increases volume/ring tone volume by 1 unit.
 LP:
Continues to increase volume/ring tone volume till the maximum value is reached or if
the button is released.
3
Accept Phone
Call / Phone
Screen
Press To Talk (if
available)
 SP:
Displays Call Log screen.
Incoming Phone Call: Accept call.
 LP:
Calls the last dialled number.
02

19
INTRODUCTIONOTHER MODES OF CONTROL
4
Scroll Next
 SP:
Media Types (except AUX-IN): Plays the next track.
Radio: Plays next preset radio station.
 LP:
Media Types (except AUX-IN & Bluetooth Devices): Plays the next track.
Radio: Starts Auto Seek by increasing radio frequency until the button is pressed.
5a
And
5b Mute
Reject Phone
Call
 SP/ LP:
Plays/Pauses or Mutes/Unmutes the Media audio.
Incoming Phone Call: Reject call.
Outgoing Phone Call: Cancel call.
Active Phone Call: End call.
6
Decrease
Volume
 SP:
Decreases volume/ring tone volume by 1 unit.
 LP:
Continues to decrease volume/ring tone volume till the value reaches 0 or if the button is
released.
Table 2: Steering Wheel Control Elements
Sl
No
Control
Element Description
02

20
INTRODUCTION OTHER MODES OF CONTROL
7
Scroll Previous
 SP:
Media Types (except AUX-IN): Plays the previous track.
Radio: Plays previous preset radio station.
 LP:
Media Types (except AUX-IN & Bluetooth Devices): Plays the previous track.
Radio: Starts Auto Seek by decreasing radio frequency until the button is released.
Table 2: Steering Wheel Control Elements
Sl
No
Control
Element Description
02
