Taylor PRATICA ROCKET EXPRESS/1A User manual

ROCKET EXPRESS
ITEM No.
Model options:
qROCKET EXPRESS/1A (single phase)
qROCKET EXPRESS/3A (three phase)
Standard equipment:
1x Paddle
1x Lloyd pan grill plate
1x Solid Teflon tray
1x Meterote baking stone
1x Oven guard protector spray
1x Non-caustic oven cleaner
1x USB memory stick
1x Operators manual
12 Months parts and labour warranty
ROCKET EXPRESS - Rapid Cook Oven
Rapid Cook Oven
Performance:
wThe Rocket Express rapid cook oven utilises a combination of
convection heat, high speed impinged air, bottom infra-red radiation and
precision microwave to reduce cook times by more than 80% whilst
maintaining chef-quality results.
wThe Rocket Express oven is equipped with a removable catalytic
converter which breaks down grease laden vapours allowing for
ventless operation.
Features:
wUp to 1024 recipes, each with 8 steps each, divided into 16
groups.
wUSB port to upload/download recipes.
wEasy to clean with step by step on screen cleaning instructions.
wAdjustable temperature from 30°C to 276°C.
wUser friendly touch screen Interface with icons and text.
wCool to the touch exterior.
wIndependently controlled upper impinged air heater and lower
infra-red heating element.
wVariable speed impinged airflow.
wDual magnetrons with side launched microwave.
wConstructed from AISI430 (exterior) and AISI304 (interior) Stainless
Steel.
wVentless system with easy removable catalytic filter.
wAllows the use of metal pans.
wManual cooking mode for ‘on-the-fly’ cooking.
Taylor UK (a division of HTG Trading Ltd)
106 Claydon Business Park, Gt. Blakenham,
Ipswich, Suffolk, IP6 0NL, United Kingdom
0800 838 896 - [e-mail]
www.taylor-company.co.uk
Due to continual research and development, these specifications are subject to change without notification - Feb 2020
1. Blower motor
2. Impingement heater
3. Impinged air
4. Infra-Red heater
5. Catalytic converter
6. Blower motor
Removable Catalytic converter Easily accessible air filter *Ventless cooking operation supported with the exception of food classified as ‘raw fatty
proteins’ such as, but not limited to, bone-in skin-on chicken, raw bacon, raw hamburger etc.
Ultimate ventless operation is subject to local authority regulations and landlord permissions.

ITEM No.
Rapid Cook Oven
ROCKET EXPRESS - Rapid Cook Oven
ROCKET EXPRESS SINGLE PHASE THREE PHASE
External OVEN dimensions (WxDxH) 532 x 806 x 636 mm
Crated dimensions (WxDxH) 560 x 860 x 800 mm
Net weight / crated weight 88 Kg / 110 Kg
Cook chamber volume 21.5 ltr
Cook chamber dimensions (WxDxH) 394 x 362 x 146 mm
Wall clearance (sides/rear) 0 mm / 75 mm
Voltage 230v / 50Hz / 1Ph 415v / 50Hz / 3Ph
Nominal power 6.9 kW
Circuit breaker 32 amp 16 amp
PRATICA RAPID COOK OVENS SHOULD BE INSTALLED WITH A D-TYPE CIRCUIT BREAKER
Cable size 3 x 4.0 mm² 5 x 4.0 mm²
Isolator socket 32 amp (1P+N+E) 16 amp (3P+N+E)
Section view:
ROCKET EXPRESS
Taylor UK (a division of HTG Trading Ltd)
106 Claydon Business Park, Gt. Blakenham,
Ipswich, Suffolk, IP6 0NL, United Kingdom
0800 838 896 - [e-mail]
www.taylor-company.co.uk
Due to continual research and development, these specifications are subject to change without notification - Feb 2020
Installation:
Isolator
Socket
wThe oven must be installed on a base or counter that supports the weight of the unit (approx 88 kg).
wFor proper ventilation, a minimum space of 3” (75mm) between the rear of the oven and the
wall is required. The Rocket Express is not designed for ‘built-in’ installation and requires suitable
ventilation.
wDo not block the air inlets and exhaust outlets located on the bottom and rear of the oven.
wIt is not recommended for the unit to be positioned near stoves, deep fryers, hot plates and other
equipment that releases fat, fumes and heat.
wThis unit must be properly grounded to avoid electrical shock. The Rocket Express is equipped
with a suitable plug. This plug must be connected to a properly installed and grounded outlet. In
the event of an electrical short, properly grounding the unit reduces the risk of electrical shock by
grounding the electrical current. The building electrical installation is the customer’s responsibility.
Improper installation may void the equipment warranty.
