TBK vision TBK-H3211 User manual

Specification
Model Name TBK-H3211
Image Sensor 1/3” Sony Super HAD CCDⅡCCD (960H)
CCD Solution Enhanced Effio-E ( ICX811AKA+ CXD4140GG)
Effective Pixels PAL976(H)X582(V) NTSC:976(H)X494(V)
Scanning System PAL/NTSC
Horizontal Resolution 700TVL
Minimum Illumination 0.01LUX/F1.2
AGC ON/OFF
BackLight Compensation HLC/BLC/OFF
Electronic Shutter AUTO(1/50(1/60)--1/100,000(s)/FIXED/MANUAL
White Balance MANUAL/USER1/USER2/PUSH LOCK/CRR/ATW
WDR OFF/ON(level adjustable)
Day &Night Auto/B/W/Color
NR(2D ) Y/C,Y,C,OFF
Image adjustment Lightness/Contrast/Sharpness/Tone/Saturation
Privacy zones Off/On(4 areas)
Motion detection Off/On(4 areas)
Mirror function Horizontal mirror/OFF
Gamma 0.45(Default)
OSD menu 8 kinds of language
(English/Japanese/French/Spanish/German etc.)
Lens 3.7mm pinhole
Gamma Correction 0,45
S/N Ratio ≥50db (AGC OFF)
Sync.system Internal
Video Output 1.0Vp-p,75Ω（BNC）
Power Requirement DC12V/500mA
Operation Temperature -20℃～+50℃
Cautions In Installation
Do use the camera under conditions where temperatures are
whthin -20-+50℃
b)Do not install the camera under unstable lighting conditions.
Severe lighting change of flicker can cause the camera to
work improperly
humidity is high.It can result in poor-quality image.
d)Do not diassemble the camera.There are no user
serviceable parts inside it.Opening or removing the camera's
cover may expose you to dangerous voltage or other hazards.
Refer all servicing to qualigied personnel only
e)Do not touch the imaging surface of sensor.Use a soft cloth
with alcohol to clean the surface if it is touched accidentally.
f)Ensure the supply voltage is correct before operation!
g)Do not focus the camera on the sun directly.
www.tbkvision.com
a) Do not install the camera in extreme temperature conditions.
c)Do not install or use the camera in an environment where the
Before using the product,please read this manual
carefully

4.BACKLIGHT COMPENSATION
OSD MENUAL (V1.0)
Warning：Please read this manual carefully before installation and use!
OSD CONTROL BY FIVE SWITCH OSD CONTROL BY ONE SWITCH
SET：push [ SET ] into Main Memu
UP/DOWN：[ UP ] or [ DOWN ] for move up and down.
LEFT/RIGHT：[ LEFT ] or [ RIGHT ] for modifying the menu parameters.
1
23
1.LENS
Manual: Please choose‘manual’when use
manual iris lens for the camera
Auto: Please choose‘Auto’when use manual
iris lens for the camera
2.SHUTTER/AGC
AUTO: Auto control of the shutter is enabled.
The shutter speed is controlled automatically
according to the brightness of the scene.
MANUAL: The shutter speed can be controlled manually
3.WHITE BAL(white balance)
ATW: The camera can adjust the white balance au
tomatically according to the color temperature range.
SETUP MENU
NEXT
EXIT
LENS MANUAL
SHUTTER/AGC AUTO
WHITE BAL ATW
BACKLIGHT OFF
PICT ADJUST OFF
MOTION DET ON
SETUP MENU
LENS
SHUTTER/AGC
WHITE BAL
BACKLIGHT
PICT ADJUST
MOTION DET
NEXT
EXIT SAVE ALL
ON
OFF
OFF
ATW
AUTO
MANUAL
ATW
SPEED
DELAY CNT
ATW FRAME
ENVIRONMENT
RETURN
X1.00
INDOOR
Single press: use for the fixed environment
User 1:User can adjust white balance as he need.
USER1 WB
B-GAIN
R-GAIN
RETURN
USER2 WB
B-GAIN
R-GAIN
RETURN
User 2: User can adjust white balance as he need
Color rolling suppression: Restrain color rolling
when the frequency of the camera and the testing
temperature are not the same.
Manual: This mode is used for advanced setti ngs,
User can adjust white balance manually from 015
to 056.
MANUAL WB
LEVEL
RETERN
Backlight Compensation: when there is strong
back lighting at the back of the monitored object,
you can use this function to get clear images both
for the object and the background
Strong light BLC: by processing light signal or
exposure compensation to achieve backlight
compensation and brightness compensation
OFF: close ‘BLC’ function
5.PICT ADJUST
Mirror: This function is used to achieve picture
horizontal reverse.
Brightness: It can adjust the brightness of the
picture (0-255)
Contrast: It can adjust the contrast of the picture
(0-255)
Sharpness: It can adjust the Sharpness of the
picture (0-255)
HUE: It can adjust the HUE of the picture (0-255)
Gain: It can adjust the gain of the picture (0-255)
PICT ADJUST
MIRROR
BRIGHTNESS
CONTRAST
SHARPNESS
HUE
GAIN
RETERN
6.ATR
ON: bright/dark compensate open
Sharpness OFF:ATR CLOSE
SETUP MENU
LENS
SHUTTER/AGC
WHITE BAL
BACKLIGHT
MANUAL
AUTO
OFF
OFF
ON
ATR
MOTION DET
NEXT
EXIT SAVE ALL
PICT ADJUST
OFF
SETUP MENU
LENS
SHUTTER/AGC
WHITE BAL
BACKLIGHT
PICT ADJUST
MOTION DET
NEXT
EXIT SAVE ALL
7.MOTION DET
ON: MOTION DET open, one checking area
OFF: MOTION DET close
8.NEXT: NEXT PAGE
9.EXIT: EXIT MENU
10.SAVE ALL
11, Privacy Zone
On: turn on the function, it contains 4 privacy
zones.
Off: turn off the function.
MANUAL
AUTO
ATW
OFF
OFFATR
ON
MOTION DET
DETECT SENSE
BLOCK DISP
MONITOR AREA
AREA SEL
TOP
BOTTON
LEFT
RIGHT
RETURN
OFF
ON
PRIVACY
TOP
BOTTON
LEFT
RIGHT
COLOR
RETURN
OFF
TRANSP
MOSAIC
AREA SEL 1/4
1
1.00
SETUP MENU
PRIVACY
DAY/ NIGHT
NR
CAMERA ID
SYNC
LANGUAGE
CAMERA RESET
BACK
EXIT SAVE ALL
OFF
OFF
OFF
INT
CHINESE
12.Day/ Night Mode
Auto: Select this, the camera will show color
image in high lux and will auto change
into black/white image in low lux.
Color: select this menu to show color image.
Black/White select this menu to show black/white
image.
13.Noise reducing
NR model: choose NR mode.
Y Level: brightness signal
C Level: color signal Return
14.Camera ID
On: turn on the camera ID function
OFF: turn off the function.
DAY/NIGHT
BURST
DELAY CNT
DAY NIGHT
NIGHT DAY
RETURN
OFF
NR
NR MODE
Y LEVEL
C LEVEL
RETURN
Y/C
CAMERA ID
RETURN
15.Synchronous Mode: Int Sync
SETUP MENU
PRIVACY OFF
DAY/NIGHT AUTO
NR
CAMERA ID OFF
SYNC INT
LANGUAGE CHINESE
CAMERA RESET
BACK
EXIT SAVE ALL
17.CAMERA RESET: Menu restore to
factory default.
16.LANGUAGE: Including Chinese, English,
Japanese, Germany, French, Russian,
ortuguese, Spanish
SETUP MENU
PRIVACY
NR
CAMERA RESET
BACK
EXIT SAVE ALL
OFF
DAY/NIGHT AUTO
CAMERA ID OFF
SYNC INT
LANGUAGE CHINESE
18.BACK: Previous
19.EXIT: Exit Menu.
SETUP MENU
NR
CAMERA RESET
BACK
EXIT SAVE ALL
PRIVACY OFF
DAY/NIGHT AUTO
CAMERA ID OFF
SYNC INT
LANGUAGE CHINESE
SETUP MENU
NR
CAMERA RESET
BACK
EXIT SAVE ALL
PRIVACY OFF
DAY/NIGHT AUTO
CAMERA ID OFF
SYNC INT
LANGUAGE CHINESE
SETUP MENU
PRIVACY
DAY/NIGHT
NR
CAMERA ID
SYNC
LANGUAGE
CAMERA RESET
BACK
EXIT SAVE ALL
OFF
AUTO
OFF
INT
CHINESE
20.SAVE ALL: Save
SETUP MENU
NR
CAMERA RESET
BACK
EXIT
PRIVACY
DAY/NIGHT
CAMERA ID
SYNC
LANGUAGE
SAVE ALL
OFF
AUTO
OFF
INT
CHINESE
1.Press Set key to show the OSD Main Menu,
2.Select different memu content by UP and DOWN button
3.Through the left (LEFT) or right (RIGHT) button to change the selection of different modes.
4.Chose EXIT and press SET key to end the setting.
