TCS FVK2200 User manual

TCS TürControlSysteme AG Geschwister-Scholl-Str. 7 39307 Genthin Subject to technical changes.
Fon.: [phone] Fax: [phone] www.tcsag.de PI FVK220x UK 2A
Product information
Built-in camera module color
FVK2200 and FVK2201

2 11/2014
TCS TürControlSysteme AG Geschwister-Scholl-Str. 7 39307 Genthin Subject to technical changes.
Fon.: [phone] Fax: [phone] www.tcsag.de PI FVK220x UK 2A
Safety notices
!
Assembly, installation and commissioning must only be carried out by a qualified elec-
trician!
For work on systems with 230 V AC mains voltage the safety requirements of DIN VDE
0100 must be observed.
When installing TCS:BUS systems the general safety rules for telecommunication systems
in accordance with VDE 0800 must be observed:
separate cabling for high and low voltage lines,
minimum distance of 10 cm for joint cabling arrangements,
use of separators between high and low voltage lines in joint cable ducts,
use of standard telecommunication cables, e. g. J-Y (St) Y with 0.8 mm diameter,
existing cables (modernisation) with different cross sections may be used whilst taking
account of the loop resistance.
!
Suitable lightning protection must ensure that a voltage of 32 V DC will not be exceed-
ed at the TCS:BUS wires a and b.
Scope of delivery
1 x built-in color camera FVK2200 (horizontal), FVK2201 (vertical)
1 x Product information

3 11/2014
TCS TürControlSysteme AG Geschwister-Scholl-Str. 7 39307 Genthin Subject to technical changes.
Fon.: [phone] Fax: [phone] www.tcsag.de PI FVK220x UK 2A
Device overview
Technical data
supply voltage: 18 ... 28 V DC, smoothed
housing: plastics, black
dimensions (in mm): H 80 x W 109 x D 35
(see dimensional drawing, page 5)
weight 100 g
operating temperature: -20°C to 50°C
input current: 80 mA (26 V)
output impedance: 1 Vss FBAS, symmetrical
color camera CCD sensor: 8,5 mm 1/3”, Sony Super HAD
resolution: 420 lines (TVL)
photo sensitivity: 0,2 Lux / 5 Lux color
lens: F 2.0, Board Lens
focal length f=3.6 mm, 67 ° horizontal, 50 ° vertical,
around 90 ° diagonal
Based on the TCS video system with 6 wire technique.
camera
tabs with
mounting holes
connection TCS:BUS
connection for Service Device
orientation arrow
for mounting posi-
tion

4 11/2014
TCS TürControlSysteme AG Geschwister-Scholl-Str. 7 39307 Genthin Subject to technical changes.
Fon.: [phone] Fax: [phone] www.tcsag.de PI FVK220x UK 2A
Application
FVK2200 and FVK2201 are built-in camera modules for the connection to the TCS:BUS.
The built in color camera FVK220x is suitable for installing into letterbox systems or other
front panels provided by customer on site.
Brief description
can be swiveled manually ± 7° H / V (in combination with assembly frame VKR)
Auto Electronic Shutter (AES), Auto Gain Control (AGC), Auto White Balance(AWB).
image recording is activated permanently
automatic changeover between bw/color
Connection for Service Device
Assembly
Notes on mounting
!
The built-in camera modules have
to be installed behind safety glass.
Use the assembly frame VKR10 (see
Accessory, page 8).
Alternatively you can use a disc with
a minimum diameter of 25 mm (when
the disc is 2 mm thick, the distance to
the objective is 1 mm, see illustra-
tion).
distance in cm
diameter in cm

5 11/2014
TCS TürControlSysteme AG Geschwister-Scholl-Str. 7 39307 Genthin Subject to technical changes.
Fon.: [phone] Fax: [phone] www.tcsag.de PI FVK220x UK 2A
Installation location
To achieve a good video quality the camera do
not point directly at:
sunlight,
strong sources of light,
bright or strongly reflecting walls.
Installation height
The installation height for the video front-door
station must be selected under consideration
of the field of capture of the camera (see fig-
ure). Persons with average body height are
best captured with an installation height of 160
cm above floor level.
Installation dimensions

6 11/2014
TCS TürControlSysteme AG Geschwister-Scholl-Str. 7 39307 Genthin Subject to technical changes.
Fon.: [phone] Fax: [phone] www.tcsag.de PI FVK220x UK 2A
Positioning the device
The built-in camera can be mounted behind any front panel (e. g. bell button extensions or
letterbox systems).
!
The device has to be installed that way, that run off condensation or rain water cannot
enter the device.
Position of installation
!
Please note the installation position! The arrow on the type label must face upwards.
Cable connection
Connection
Connect the lines in accordance with in-
scription.
connection terminals
connection for Service Device
Connection plan

7 11/2014
TCS TürControlSysteme AG Geschwister-Scholl-Str. 7 39307 Genthin Subject to technical changes.
Fon.: [phone] Fax: [phone] www.tcsag.de PI FVK220x UK 2A
Wiring example
Commissioning
!
First install the system completely, then connect it to the power!
Install the devices of the system completely.
Observe that V1 and V2 must not be connected to the a-, b- or P-wire.
When connecting the video wires V1 (+) and V2 (-) the polarity must be observed.
Check the a-, b- and P-wire against each other on short-circuites.
Switch in the main powerl.
floor
push
button
floor
push
button
Set matching resistor when
the device is installed at the
end of a TCS:BUS video
strand.

8 11/2014
TCS TürControlSysteme AG Geschwister-Scholl-Str. 7 39307 Genthin Subject to technical changes.
Fon.: [phone] Fax: [phone] www.tcsag.de PI FVK220x UK 2A
Conformity
The declarations of conformity are available under www.tcsag.de, Downloads, trade
information.
Information on disposal
The adjoiing symbol shows, that the device has to be disposed separateley from
domestic waste. The materials used are recyclable. Please do help protecting our
environment and dispose the device via a collection point for electronic scrap.
Dispose the parts of the packaging in collecting tanks for cardboard and paper
resp. plastics.
Warranty
We offer a simplified processing in case of warranty for electricians.
Please note our conditions of sale and delivery download from www.tcsag.de, Down-
loads, trade information and included in our current catalogue.
Please contact the TCS HOTLINE.
Accessory
Short text
Article number
assembly frame, anodised nature
VKR10-EN
assembly frame, white
VKR10-ES
assembly frame, stainless steel
VKR10-WS
Service
Please send your questions and inquiries to
[email protected]
Headquarters
TCS TürControlSysteme AG, Geschwister-Scholl-Str. 7, 39307 Genthin
Tel.: [phone], FAX: [phone], www.tcsag.de
