Technaxx®* User Manual
VIP Pen FullHD 8GB TX-112
Ballpoint pen usable as Video Interview Pen
with camera & microphone
The Declaration of Conformity for this device is under the Internet link:
www.technaxx.de/ (in bottom bar “Konformitätserklärung”). Before using the
device the first time, please read the user manual carefully.
This device has a rechargeable battery. It must be fully charged before
first use. NOTE: Charge the battery of the device every 2–3 month if it is
not used!
Service phone No. for technical support: 01805 012643 (14 cent/minute from
German fixed-line and 42 cent/minute from mobile networks).
Free Email: [e-mail]
Keep this user manual for future reference or product sharing carefully. Do
the same with the original accessories for this product. In case of warranty,
please contact the dealer or the store where you bought this product.
Warranty 2 years
Enjoy your product * Share your experience and opinion on one of the
well-known internet portals such as Amazon or idealo.de
Features
Built-in 2MP FullHD camera for video recordings
FullHD video recording 1920x1080 with 30fps
Built-in microphone for audio/voice recordings
Perfect for covert recordings & portable surveillance camera
(designed as full ballpoint pen function with retractable tip)
160mAh battery for approx. 50–60 minutes non-stop recording
Built-in 8GB storage (FAT32)
Charging and data transfer via USB
Plug & Play, connection via USB (driver-free)

Technical specifications
Video resolution
FullHD 1920x1080 with 30fps
Camera angle
75° horizontal
File size
160–170MB min. (8GB = 45 min.)
Internal storage
8GB (FAT32)
Formats
Video AVI / Audio WAV
Recording time
Video ~60–70 min. / Audio ~70–80 min.
Power supply
Built-in rechargeable lithium polymer
battery 160mAh 3.7V
Charging time
~3–4 hours
Playback software
VLC Player /Windows Media player /
KM Player
Operating systems
Windows 7 / 8 / 10 & Mac OS
Working temperature
0°C up to +40°C
Material
Metal & ABS
Weight / Dimensions
41g / (L) 14.3x (W) 1.9cm with clip
Package contents
VIP Pen FullHD 8GB TX-112, 1x USB
cable, User Manual
Product view
1
Camera
2
Power On/Off &
Start key
3
Indicator LED
4
Reset hole
5
Video & voice
mode switch

Use of the device
Charging
Before first use, connect the USB port of the charging cable to the
TX-112. Then connect the USB port of the charging cable to the
USB port of an AC adapter (*not included) or to the USB port of a
computer. During charging the yellow LED is flashing. When it is
fully charged, yellow LED will steady on.
Internal storage
Since the TX-112 uses a built-in memory card (MicroSD), it is not
recommended to remove or replace other memory cards.
Voice recording
Set operation switch to position 1, long press power key, blue LED
will turn on and TX-112 is in standby mode. Short press power key,
the blue LED turns off and yellow LED flashing 3 times. Camera
enters into voice recording mode. Short press power key again, the
voice will be saved and TX-112 will go into standby mode.
Video recording
Set operation switch to position 2, long press power key, yellow
LED will turn on and TX-112 is in standby mode. Short press power
key, the yellow LED turns off and blue LED flashing 3 times.
Camera enters into video recording mode. Short press power key
again, the video will be saved and TX-112 will go into standby mode.
Note: Maximum file length of video recording is 10minutes, after
that a new file is created. After 1 minute without any operation
(standby) the camera will automatically power off.
Recording while charging
5 seconds after connecting to the adapter or a computer USB,
same operation like normal using.

Turn off camera
Under standby mode, long press power key, LED flashes 3x and
turns off. The camera turns off.
Connecting with PC
Power off the device then connect it with PC using USB cable. Do
not have any operation on the device during this connection. If the
device is not read by PC, please re-connect and make sure the
USB driver/cable is alright.
Reset
To reset camera, insert a pin into the reset hole and hold for about
2 seconds. After 1 minute, the camera is reset.
Set Date and Time stamp
The date and time will be revised for video in next recording.
Plug in the USB cable to the camera and to the computer.
 Go to <My Computer> or Computer or Explorer.
 The camera will be recognized as removable Disk Drive.
 Double left click on removable Disk Drive and it will bring
up the Video folder. DO NOT OPEN IT!
Edit the text document named “time” by double left click
on the “time.txt” document.
 Fill in the current Year-Month-Day
hour:minute:seconds [eg: 2018-01-01 12:00:00 ] ,Go to File and
Save, then close file.
Power off the TX-112 and restart. The device now has the current
date and the current time.

FAQs
Q1: What happens to my recordings when the battery goes out
of charge? A1: Before the TX-112 pen goes off, all recordings are
saved automatically.
Q2: What can I do when the VIP pen shows no reaction, e.g.
when buttons are pressed? A2: Press the RESET button; then turn
ON the VIP pen again.
Q3: How can I delete files from the internal memory of the VIP
pen? A3: Delete single files on your PC/Notebook or format
(FAT32) the whole internal memory of the VIP pen.
Important Hints
(1) Do NOT press the RESET button while recording; this stops the
recording and recorded data is deleted.
(2) Always charge the battery after usage.
Warnings
Do not attempt to disassemble the device, it may result in short-
circuit or even damage. Do not drop or shake the device, it may
break internal circuit boards or mechanics. Use it under normal
temperature and normal humidity. Do not put it in a moist working
environment since it is not waterproof. Do not use it directly
against strong light, to avoid damage optical device. Do not use
under high dust density environment, to avoid the lens and other
components stain dust and affect the camera quality. Do not
make its strong shock, vibration, do not use under high magnetic
field. Keep the device away from little children.
Hints for Environment Protection: Packages
materials are raw materials and can be recycled. Do
not disposal old devices or batteries into the domestic
waste. Cleaning: Protect the device from
contamination and pollution (use a clean drapery).
Avoid using rough, coarse-grained materials or
solvents/aggressive cleaner. Wipe the cleaned device
accurately. Distributor: Technaxx Deutschland
GmbH & Co.KG, Kruppstr. 105, 60388 Frankfurt a.M.,
Germany
