Technics SL-C700E User manual

© Panasonic Corporation 2015. All rights reserved.
Unauthorized copying and distribution is a violation
of law.
ORDER NO.PSG1502003CE
Compact Disc Player
Model No. SL-C700E
Product Colour:
(S) ...... Silver Type

2
TABLE OF CONTENTS
PAGE PAGE
1 Safety Precautions -----------------------------------------------3
1.1. General guidelines-----------------------------------------3
2Warning--------------------------------------------------------------4
2.1. Prevention of Electrostatic Discharge (ESD)
to Electrostatic Sensitive (ES) Devices ---------------4
2.2. Service caution based on legal restrictions----------5
2.3. Precaution of Laser Diode -------------------------------6
2.4. Handling Precaution for CD DRIVE
UINT(Optical Pickup)--------------------------------------7
3 Specifications ------------------------------------------------------8
4 Location of Controls and Components--------------------9
5 Troubleshooting Guide---------------------------------------- 11
5.1. Check the problem is reproduced-------------------- 11
5.2. No power --------------------------------------------------- 12
5.3. LED does not illuminate -------------------------------- 17
5.4. No buzzer -------------------------------------------------- 17
5.5. Remote control does not operate -------------------- 17
5.6. No Display ------------------------------------------------- 18
5.7. No CD operation------------------------------------------ 19
5.8. Connector pin configuration --------------------------- 20
5.9. Blocks related to each function ----------------------- 21
6 Disassembly and Assembly Instructions --------------- 22
6.1. PCB layout drawing-------------------------------------- 23
6.2. Removing the disc when the disc cannot be
removed using the opening-closing button -------- 25
6.3. Disassembly flow chart --------------------------------- 26
6.4. SET LEG UNIT ------------------------------------------- 27
6.5. TOP AL PANEL------------------------------------------- 27
6.6. TOP CABINET BLOCK --------------------------------- 27
6.7. SIDE PANEL (R), SIDE PANEL (L), TOP
PANEL ------------------------------------------------------ 27
6.8. FRONT PANEL UNIT ----------------------------------- 28
6.9. TOUCH SENSOR PCB, PICT LIGHTING
WINDOW--------------------------------------------------- 28
6.10. DISPLAY PCB, OLED ASSY-------------------------- 28
6.11. IR PCB, MAIN SWITCH PCB ------------------------- 29
6.12. FRONT PANEL ASSY ---------------------------------- 29
6.13. BELT LOADING ------------------------------------------ 29
6.14. CD MECHA BLOCK, DOOR -------------------------- 29
6.15. SPRING, CD LOADING UNIT ------------------------ 30
6.16. INSULATOR, CD DRIVE UNIT ----------------------- 30
6.17. REAR PANEL --------------------------------------------- 30
6.18. MAIN PCB ------------------------------------------------- 31
6.19. SOFTWARE IN 1 PCB, SOFTWARE IN 2
PCB---------------------------------------------------------- 31
6.20. CD MECHA DRIVE PCB------------------------------- 31
6.21. PS PCB ----------------------------------------------------- 32
6.22. AC INLET PCB ------------------------------------------- 32
7 Dimensions ------------------------------------------------------- 33
8 Block Diagram --------------------------------------------------- 34
9 Wiring Connection Diagram --------------------------------- 35

3
1 Safety Precautions
1.1. General guidelines
1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or
damaged by the short circuit.
2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly
installed.
3. After servicing, make the following leakage current checks to prevent the customer from being exposed to shock hazards.
1.1.1. Leakage current cold check
1. Unplug the AC cord and connect a jumper between the
two prongs on the plug.
2. Measure the resistance value, with an ohmmeter,
between the jumpered AC plug and each exposed
metallic cabinet part on the equipment such as
screwheads, connectors, control shafts, etc. When the
exposed metallic part has a return path to the chassis, the
reading should be between 1Mand 5.2M.
When the exposed metal does not have a return path to
the chassis, the reading must be .
1.1.2. Leakage current hot check
(See Figure 1.)
1. Plug the AC cord directly into the AC outlet. Do not use
an isolation transformer for this check.
2. Connect a 1.5k, 10 watts resistor, in parallel with a
0.15F capacitors, between each exposed metallic part
on the set and a good earth ground such as a water pipe,
as shown in Figure 1.
3. Use an AC voltmeter, with 1000 ohms/volt or more
sensitivity, to measure the potential across the resistor.
4. Check each exposed metallic part, and measure the
voltage at each point.
5. Reverse the AC plug in the AC outlet and repeat each of
the above measurements.
6. The potential at any point should not exceed 0.75 volts
RMS. A leakage current tester (Simpson Model 229 or
equivalent) may be used to make the hot checks, leakage
current must not exceed 1/2 milliampere. In case a
measurement is outside of the limits specified, there is a
possibility of a shock hazard, and the equipment should
be repaired and rechecked before it is returned to the
customer.
Figure 1

4
2Warning
2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatic Sensitive
(ES) Devices
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called
Electrostatic Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistor-sand
semiconductor "chip" components. The following techniques should be used to help reduce the incidence of component damage
caused by electrostatic discharge (ESD).
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD on your
body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging ESD wrist strap,
which should be removed for potential shock reasons prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as
aluminum foil, to prevent electrostatic charge buildup or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4. Use only an anti-static solder removal device. Some solder removal devices not classified as "anti-static (ESD protected)" can
generate electrical charge sufficient to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most
replacement ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil or
comparable conductive material).
7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective material
to the chassis or circuit assembly into which the device will be installed.
Caution
Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise harmless motion such as the
brushing together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity sufficient
to damage an ES device).

5
2.2. Service caution based on legal restrictions
2.2.1. General description about Lead Free Solder (PbF)
The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for this
equipment in considering the globally environmental conservation.
The normal solder is the alloy of tin (Sn) and lead (Pb). On the other hand, the lead free solder is the alloy mainly consists of tin
(Sn), silver (Ag) and Copper (Cu), and the melting point of the lead free solder is higher approx.30 degrees C (86°F) more than that
of the normal solder.
Definition of PCB Lead Free Solder being used
Service caution for repair work using Lead Free Solder (PbF)
• The lead free solder has to be used when repairing the equipment for which the lead free solder is used.
(Definition: The letter of "PbF" is printed on the PCB using the lead free solder.)
• To put lead free solder, it should be well molten and mixed with the original lead free solder.
• Remove the remaining lead free solder on the PCB cleanly for soldering of the new IC.
• Since the melting point of the lead free solder is higher than that of the normal lead solder, it takes the longer time to melt the
lead free solder.
• Use the soldering iron (more than 70W) equipped with the temperature control after setting the temperature at 350±30 degrees
C (662±86°F).
Recommended Lead Free Solder (Service Parts Route.)
• The following 3 types of lead free solder are available through the service parts route.
SVKZ000001-----------(0.3mm 100g Reel)
SVKZ000002-----------(0.6mm 100g Reel)
SVKZ000003-----------(1.0mm 100g Reel)
Note:
* Ingredient: Tin (Sn) 96.5%, Silver (Ag) 3.0%, Copper (Cu) 0.5%. (Flex cored)
The letter of "PbF" is printed either foil side or components side on the PCB using the lead free solder.
(See right figure)

6
2.3. Precaution of Laser Diode
Caution:
This product utilizes a laser diode with the unit turned "on", invisible laser radiation is emitted from the pickup lens.
Wavelength: 790 nm (CD)
Maximum output radiation power from pickup: 100 μW/VDE
Laser radiation from the pickup unit is safety level, but be sure the followings:
1. Do not disassemble the pickup unit, since radiation from exposed laser diode is dangerous.
2. Do not adjust the variable resistor on the pickup unit. It was already adjusted.
3. Do not look at the focus lens using optical instruments.
4. Recommend not to look at pickup lens for a long time.
ACHTUNG:
Dieses Produkt enthält eine Laserdiode. Im eingeschalteten Zustand wird unsichtbare Laserstrahlung von der
Lasereinheitadgestrahit.
Wellenlänge : 790nm (CD)
Maximale Strahlungsleistung der Lasereinheit :100 μW/VDE
Die Strahlung an der Lasereinheit ist ungefährlich, wenn folgende Punkte beachtet werden:
1. Die Lasereinheit nicht zerlegen, da die Strahlung an der freigelegten Laserdiode gefährlich ist.
2. Den werkseitig justierten Einstellregler der Lasereinhit nicht verstellen.
3. Nicht mit optischen Instrumenten in die Fokussierlinse blicken.
4. Nicht über längere Zeit in die Fokussierlinse blicken.
CAUTION!
THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE
SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.

7
2.4. Handling Precaution for CD DRIVE UINT(Optical Pickup)
The laser diode in the CD DRIVE UINT(Optical Pickup) may break down due to static electricity of clothes or human body. Special
care must be taken avoid caution to electrostatic breakdown when servicing and handling the laser diode in the Traverse Unit.
2.4.1. Cautions to Be Taken in Handling the CD DRIVE UINT(Optical Pickup)
The laser diode in the CD DRIVE UINT(Optical Pickup) may be damaged due to electrostatic discharge generating from clothes or
human body.
Special care must be taken avoid caution to electrostatic discharge damage when servicing the laser diode.
1. Do not give a considerable shock to the CD DRIVE UINT(Optical Pickup) as it has an extremely high-precise structure.
2. To prevent the laser diode from the electrostatic discharge damage, the flexible cable of the CD DRIVE UINT(Optical Pickup)
removed should be short-circuited with a short pin or a clip.
3. The flexible cable may be cut off if an excessive force is applied to it. Use caution when handling the flexible cable.
4. The antistatic FFC is connected to the new CD DRIVE UINT(Optical Pickup). After replacing the CD DRIVE UINT(Optical
Pickup) and connecting the flexible cable, cut off the antistatic FFC.
2.4.2. Grounding for electrostatic breakdown prevention
Some devices such as the CD player use the optical pickup (laser diode) and the optical pickup will be damaged by static electricity
in the working environment. Proceed servicing works under the working environment where grounding works is completed.
2.4.2.1. Worktable grounding
1. Put a conductive material (sheet) or iron sheet on the area where the CD DRIVE UINT(Optical Pickup) is placed, and ground
the sheet.
2.4.2.2. Human body grounding
1. Use the anti-static wrist strap to discharge the static electricity form your body.

8
3 Specifications

9
4 Location of Controls and Components

10

11
5 Troubleshooting Guide
5.1. Check the problem is reproduced

5.2 No power
12

13

14

15

16

17
5.3. LED does not illuminate
5.4. No buzzer
5.5. Remote control does not operate

18
5.6. No Display

19
5.7. No CD operation

20
5.8. Connector pin configuration
