Technika BRSS10 User guide

BRSS10
Owner’s
Handbook
Blu-ray disc player

1
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
Do not use this apparatus near water.
Clean only with a slightly damp cloth.
Do not block any ventilation openings.
Install in accordance with the manufacturer’s instructions.
Do not install or operate near any heat sources such as
radiators, stoves, or other apparatus that produce heat.
Unplug this apparatus during lightning storms or when
unused for long periods of time.
Refer all servicing to qualied service personnel. Servicing
is required when the apparatus has been damaged
in any way, such as the power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been
dropped.
Warning: To reduce the risk of re or electrical shock, do
not expose this product to rain or moisture. The product
must not be exposed to dripping and splashing and no
object lled with liquids such as a vase of owers should
be placed on the product.
No naked ame sources such as candles should be placed
on the product.
Caution: Changes or modications not expressly approved
by the manufacturer could void the user’s authority to
operate this device.
Caution: Usage of controls or adjustments or performance
of procedures other than those specied herein may result
in hazardous exposure.
IMPORTANT
This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communication. However, this is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment o and on, the user
is encouraged to try to correct the interference by one of
the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit
dierent from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV
technician for help.
This symbol indicates that there are
important operating and maintenance
instructions in the literature accompanying
this unit.
This symbol indicates that dangerous
voltage constituting a risk of electric shock
is present within this unit.
CAUTION!
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TO REDUCE THE RISK OF ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
IMPORTANT SAFETY INFORMATION
WARNING: DANGER OF RADIATION
These labels tell you that the unit contains a laser
component. Opening the CD compartment lid and
defeating the safety interlocks will expose the user to
radiation from the laser beam. Do not stare into the laser
while it is operating.
ELECTRICAL INFORMATION
Mains Supply: The mains operating voltage of this unit is
marked on a rating plate on the underside of the unit.
The means of disconnecting this appliance from the mains
supply is the mains plug. This should be unobstructed and
readily operable at all times.

2
INDEX INTRODUCTION
Read this manual before using your player.
The Player is set to play Region B Blu ray or Region 2 DVD
Video discs.
The player will accept the following disc types (among
others): Blu-Ray, DVD Video, DVD-RAM, DVD-R, DVD+R,
DVD-RW, DVD+RW, CD, CD-R, CD-RW, WMA, JPEG,
MPEG4.
The following formats are not acceptable:
Discs with other region codes.
Improperly formatted recordable discs, including
recordable discs which are not nalised.
IMPORTANT NOTE
Blu-ray and DVD Video discs contain various features.
Many features are determined by the program or software
content on the disc itself. Some procedures in this manual
cannot be performed if the disc does not support the
feature. Also, some discs may need special settings which
are unsupported by the player.
CAUTION: during playback, the disc spins at high speed,
do not lift or move the player, doing so may damage the
disc.
Full, high-denition video playback at up to 1080p•
resolution.
Up-conversion of standard DVD Video discs for•
enhanced picture quality at up to 1080p resolution.
HDMI AV Connection.•
Stereo analogue and digital audio outputs.•
PIP (picture in picture) functionality.*•
Pop-up menu display during playback.*•
Wired ethernet connection to enable access to BD-•
Live features.*
*Where available on Blu-ray discs.
Menu navigation assistance:
Your Blu-ray player includes menus to enable you to
navigate the content of your discs and to change settings.
To help you navigate the menus, a selection box is placed
over the currently selected menu item.
In the two menu examples below, the pointers on the
box indicate which directions you can navigate with the
cursor buttons on the remote control.
PLAYER FEATURES
Important safety information ..................................................1
Introduction ...................................................................................2
Player features ...............................................................................2
Disc region codes.........................................................................3
Film ratings .....................................................................................3
Controls and connections.........................................................4
Remote control .............................................................................5
HDMI connection .........................................................................6
Composite video (CVBS) and SCART connection .............7
Digital audio connection...........................................................8
Network connection ...................................................................9
Connecting power, loading a disc....................................... 10
Playing Blu-ray or DVD-Video discs .................................... 11
Blu-ray disc special features ..................................................14
BD-Live .......................................................................................... 15
Playing CD audio discs ............................................................ 16
Viewing JPEG digital photos ................................................. 17
Playing WMA music les......................................................... 19
Playing MPEG video les.........................................................21
System settings - overview.................................................... 23
System settings - System category ..................................... 24
System settings - Network category .................................. 25
System settings - Display category..................................... 27
System settings - Audio category........................................ 28
System settings - Language category................................ 29
System settings - Parental category ................................... 30
Troubleshooting ........................................................................ 31
Care and cleaning ..................................................................... 32
Specications.............................................................................. 32
Warranty ....................................................................................... 32

3
Blu-ray and DVD discs and players are covered by a
worldwide agreement which limits playback of discs
to specic regions as determined by the software
manufacturer. Most discs come marked with a region
coding. A disc specied as playable in one region may not
play on a player designed for a dierent region. A disc
specied as universal or with no region coding may be
played in any region.
The regions are:
Blu Ray discs:
Region A: The Americas and their dependancies, East Asia
(except China and Mongolia) and Southeast Asia.
Region B: Africa, Southwest Asia, Europe (except
Belarus, Russia and the Ukraine), Oceania and their
dependancies.
RegionC:CentralAsia,EastAsia(ChinaandMongoliaonly),
South Asia, Eastern Europe and their dependancies.
DVD Video discs:
Region 1: Canada, USA
Region 2: Europe, Japan, Mid-East, South Africa.
Region 3: South-East Asia.
Region 4: Australia, Caribbean, Central & South America,
New Zealand.
Region 5: Africa, Former Soviet Union, India, North Korea,
Pakistan.
Region 6: China.
THIS PLAYER PLAYS REGION B BLU-RAY AND REGION
2 DVD VIDEO DISCS, ALSO REGION FREE, UNIVERSAL
DISCS.
An international agreement limits playback of discs to
certain age groups as below:
I KID SAFE•
2 G•
3 PG•
4 PG 13•
5 PGR•
6 R•
7 NC17•
8 ADULT•
From the factory, this player is set to play all disc ratings.
Each disc and packaging has information about the
classication of the disc.
If there are children in your house you can restrict viewing
to particular age groups by following the instructions in
the Parental settings Menu on page 30. Once restrictions
are set, access to higher rated content will require a
password.
This player incorporates copyright protection technology
that is protected by method claims of certain U.S.
patents and other intellectual property rights owned by
Macrovision Corporation and other rights owners. Use of
this copyright protection technology must be authorized
by Macrovision Corporation. and is intended for home
and other limited viewing uses only unless otherwise
authorized by Macrovision Corporation. Reverse
engineering or disassembly is prohibited.
The HDMI output of the player has High Denition
Copyright Protection (HDCP) technology. Connecting the
HDMIoutputoftheplayertoavideoscreennotsupporting
HDCP technology will downgrade the picture.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trade marks of Dolby
Laboratories.
Manufactured under license under U.S. Patent #’s:
5,451,942; 5,956,674;5,974,380; 5,978,762; 6,487,535 &
other U.S. and worldwide patents issued & pending. DTS
is a registered trademark and the DTS logos, symbol and
DTS-HD Advanced Digital Out are trademarks of DTS, Inc.
1996-2008 DTS, Inc. All rights reserved.
FILM RATINGSDISC REGION CODES NOTICES

4
CONTROLS AND CONNECTIONS
FRONT VIEW
Disc loading tray1.
Open/close button2.
Play/pause button3.
Stop button4.
Standby/On button5.
USB dock (under cover)6.
BACK VIEW
Power cord1.
Analogue stereo audio out2.
Analogue composite video out3.
Digital audio out4.
HDMI Digital A/V out5.
RJ45 ethernet connector6.

5
REMOTE CONTROL
Open/close button1.
Numeric keypad2.
Return button3.
Previous button4.
Next button5.
Play/pause button6.
Step button7.
Repeat A-B button8.
Subtitle button9.
Angle button10.
Popup/Title menu button11.
Up cursor button12.
Right cursor button13.
Down cursor button14.
Volume down button15.
Volume up button16.
Yellow (C) button17.
Blue (D) button18.
Mute button19.
Secondary audio button20.
Picture in picture button21.
Resolution button22.
Red (A) button23.
Green (B) button24.
Setup menu button25.
Audio select button26.
Left cursor button27.
Enter button28.
Disc menu button29.
OSD button30.
Repeat button31.
Zoom button32.
Stop button33.
Fast reverse button34.
Fast forward button35.
Search button36.
Standby/On button37.
When replacing the batteries in the remote control, refer
to the diagram above.
FITTING BATTERIES
1. Press the catch on the battery cover.
2. Lift o the battery cover.
4. Re-t the battery door and clip it in place.
DISPOSAL OF BATTERIES
Dispose of used batteries with regard to the recycling
regulations in your area. Do NOT short circuit batteries or
throw them into water, the general rubbish or in a re.
Weak batteries can leak and damage the remote control.
Replace them in good time!
3. Fit two AAA batteries observing polarity as shown.
When replacing the batteries, use only the same AAA
type specied.

6
CONNECTING HDMI DIGITAL VIDEO AND AUDIO TO A TV AND (OPTIONAL) SURROUND-SOUND DECODER
HDMI CONNECTION TO A TV
Your Blu-ray player includes dierent connection options.
Digital HDMI connection is recommended for the highest
quality video and audio performance.
If your TV includes HDMI digital connections, connect
an HDMI cable (not supplied) as shown for the highest
quality of picture and sound from your TV.
HDMI CONNECTION TO A SURROUND-
SOUND DECODER
If your audio-visual system includes a separate surround-
sound decoder with HDMI connections, you can use two
HDMI cables (not supplied) to connect your player to the
decoder and then to the TV.
NOTE: It is advisable to check that the settings for HDMI
digital audio are correct for your AV surround decoder.
These can be found in the section‘System settings - audio
category’. Connect to an HDMI input
of the decoder.
ConnectfromtheHDMIoutput
of the decoder to the TV
SURROUND-SOUND
DECODER
CAUTION: Always
disconnect the player,
TV, and any other AV
system components
from the mains before
making or changing
any connections.

7
CONNECTING ANALOGUE VIDEO, AUDIO AND SCART
SCART CONNECTION TO A TV
If your TV doesn’t have separate audio and video
connections, it may have a SCART audio/visual connector.
To connect to a SCART input you will need a 3-way AV
phono cable and a SCART adaptor (not supplied).
Connect the AV phono cable to the player as shown, then
connect the cable to the adaptor as shown. If the SCART
adaptor includes a switch, set this to ‘IN’. Connect the
SCART adaptor to a free SCART input of the TV.
ANALOGUE AUDIO AND VIDEO
If your TV doesn’t include a digital HDMI connection, it
may have separate composite video (CVBS) and stereo
audio connection.
The input jacks for these connections are normally
coloured yellow (composite video), white (left audio)
and red (right audio). To connect to composite video and
stereo audio you will need a 3-way AV phono cable (not
supplied).
Connect the AV phono cable to the player as shown, then
connect the other end to the TV, matching the coloured
plugs to the coloured sockets on the TV.
White plug
Red plug
Yellow plug
SCART adaptor
3-way AV cable
Connect to a free
SCART input
White plug
Red plug
Yellow plug
3-way AV cable
CAUTION: Always
disconnect the player,
TV, and any other AV
system components
from the mains before
making or changing
any connections.

8
DIGITAL AUDIO OUTPUT
USING THE DIGITAL AUDIO OUTPUT
Your player also includes a co-axial digital audio
output. You can use this jack to connect digital audio
to a surround-sound decoder that doesn’t have HDMI
connections.
Connect a single digital audio phono interconnect
between the digital audio output of the player and a free
digital audio input of the decoder.
NOTE: Video may be connected to the TV via HDMI or
CVBS (Composite) analogue video out. In the system
illustrated, video and audio are connected to the TV via
the HDMI connection.
NOTE: It is advisable to check that the settings for the
digital audio output are correct for your AV surround
decoder. These can be found in the section ‘System
settings - audio category’.
To a digital
audio input
CAUTION: Always
disconnect the player,
TV, and any other AV
system components
from the mains before
making or changing
any connections.

9
CONNECTING TO THE INTERNET
NETWORK CONNECTION
An RJ45 socket is provided on the rear panel of the player
for optional connection to the Internet via your home
network.
This connection is not essential, but if you connect your
player to the Internet you can retrieve additional bonus
information when you are playing a Blu-ray disc that
features‘BD-Live’. You can also check through the settings
menu if there are any updates for your player.
To make this connection your home network will require
an ‘always on’connection to the Internet so you will need
access to a spare port on the network modem/router.
The illustration shows the connection arrangements
found on a typical modem/router.
Modem/router
CAUTION: Always
disconnect the player,
TV, and any other AV
system components
from the mains before
making or changing
any connections.

10
GETTING STARTED
PLACEMENT
Place the player on a level surface where it is unlikely to
be knocked over or fall and where the connecting leads
do not constitute a cause of danger.
The means of disconnection from the mains supply is
via the mains plug on the power cord. This must not be
obstructed and be readily operable at all times.
CONNECTING POWER
Before connecting power, connect the player to your TV
and any other components in your system (see pages
6-9).
When you have completed all signal connections,•
plug the player, TV and other system components
into the mains.
The Standby/On button will glow red.
SWITCHING THE PLAYER ON AND OFF
CAUTION: Discs spin at high speed. To avoid damage to
your discs or player, never lift or move the player when
the power is switched on.
To switch the player on:
Press the• STANDBY/ON button.
The Standby/On button will glow blue and ‘HELLO’ will
be displayed. The player will check for the presence of an
Internet connection, then check if a disc is loaded. If a disc is
found it will read automatically.
To switch the player o:
Press the• STANDBY/ON button.
The Standby/On button will glow red and ‘OFF’ will be
displayed.
SWITCHING ON FOR THE FIRST TIME
After switching on the player, and before loading a•
disc, select the AV input on your TV that corresponds
to the connections you have made. For example, this
may be HDMI, SCART or CVBS.
The TV should display the player Settings Menu screen.
In the unlikely event that no picture or a distorted picture
is visible, refer to the Troubleshooting section on page
31.
If you can see an Internet notice as in the above example,
your player is not connected to the Internet. This may be
because there is no connection cable in place or because
the Internet connection is not working.
If you are not planning to use BD-Live features on Blu-
ray discs, then this notice can be ignored. If you do
plan to use BD-Live, then you may want to refer to the
sections ‘Connecting to the Internet’and‘System settings
- network category’ to check your Internet connections
and settings.
LOADING A DISC
Press the• button to open the disc tray.
Place the disc label side up on the disc tray.•
Press the• button to close the disc tray.
The disc will read.
NOTE: The disc tray will open again after a short delay
if the disc loaded does not include compatible material
(non-supported music/movie les etc).
Blu-ray or DVD-Video discs
If the disc is a Blu-ray or DVD-Video movie disc, the TV
display will show the initial ‘root’ menu of the disc. Refer
now to page 11 for full instructions for playing a movie
disc.
CD audio discs
If the disc is a music CD, the disc will begin to play, the track
and elapsed time will be displayed on the front panel and
the TV will show the CD playback status display. Refer to
page 16 for full instructions for playing an audio CD.
CD-ROM or DVD-ROM discs
If the disc is a CD-ROM or DVD-ROM containing WMA
music and/or JPEG photo or compatible MPEG movie les,
the TV will show a folder/le display. Refer now to page
17 (JPEG), 19 (WMA) or 21 (MPEG) for full instructions for
playing a CD-ROM/DVD-ROM.
UNLOADING A DISC
If the disc is playing, stop play and wait for a few•
seconds for the disc to stop spinning.
Press the• button.
After a delay while the disc is stopped fully, the disc tray will
open.
Carefully lift the disc o the disc tray and place it back•
in its case immediately.
If you have nished using your player, press the•
button to close the disc tray.
Internet
notice

11
PLAYING A BLU-RAY OR DVD-VIDEO DISC
The instructions for playing Blu-ray and DVD-Video
discs are the same. Blu-ray discs do include some more
advanced features. These are listed in a later section ‘Blu-
ray disc special features’.
Load the disc.•
After a short delay while the disc reads, the initial disc ‘root’
menu will be displayed on the TV screen. This menu resides
on the disc so the features of the menu are dependant
entirely on the disc content. Most Disc Menus will allow you
to begin playing the movie, jump to scenes and change disc-
related settings.
Press the• O,P,M,Nbuttons to navigate the menu
options.
Press the• ENTER button to choose an option.
One of the options will be ‘play’ or ‘play movie’. Choose this
option to play the movie.
Discs may also include menu options to activate extra
features within the movies.
PLAYBACK CONTROL
When a movie is playing.
Play/pause/still frame:
Press the• /, button to pause the movie.
A still frame will be displayed.
Press the• /, button to resume play.
Stepping frame by frame:
Press the• ,/ button to step forward frame by frame.
Press the• /, button to resume play.
Navigating chapters:
Blu-ray and DVD-Video discs are organised so that you
can jump back or forward and resume watching the
movie from a particular scene (chapter).
Press the• }or {button to jump forward or backward
through the chapters on the disc.
NOTE: Pressing the {button for the rst time will return
play to the start of the current chapter.
Fast search
Press the• ]or [button to fast-search forward or
backward through a movie. Pressing the button
repeatedly will increase search speed in the range -
2X "4X "8X "16X "32X "64X "128X " Normal
The search speed is displayed on the TV screen
Press the• /, button to return to normal speed play.
Stopping the disc
Press the• .button (also available on the front panel)
to stop the disc.
Play will stop.
If the disc you are playing features play resume, you can later
press the /, button to resume the movie from the point at
which play stopped.
To fully stop a disc (clearing play resume), press the• .
button twice.
Jumping to a particular scene:
The Disc Menu will often include an index of chapters.•
To jump to a chapter, press the DISC MENU button.
The disc will stop playing and the Disc Menu appears.
Select the ‘scenes’ or ‘chapters’ menu (not all discs will•
have this menu).
Press the• O,P,M,Nbuttons to navigate to the
chapter you want using the on-screen disc menu.
Press• ENTER to re-start play from this chapter.
Jumping to a title, chapter or time on the disc:
If you want to jump to a particular title, chapter or•
elapsed time on the disc, press the SEARCH button
repeatedly to display the search item you want.
The Title, Chapter or Time search box opens.
Enter the title number, chapter number or elapsed•
time using the numbers on the NUMERIC KEYPAD. If
you are entering a time, use the Oor Pbutton to
change between hours and minutes and seconds.
When you have nished entering the digits required,•
press the ENTER button to conrm.
The player will jump to the point you selected.

12
Repeat play:
NOTE: Repeat features may not be available on some Blu-
ray discs.
There are two repeat modes.
Press the• REPEAT button repeatedly to step through
the two repeat modes.
The repeat mode selected will be displayed on the TV
screen.
PLAYING A BLU-RAY OR DVD-VIDEO DISC
Repeat Title: The player will repeat the current title
continuously.
Repeat Chapter:The player will repeat the current chapter
continuously.
Repeat A-B:
You can also set the player to repeat a particular passage
from the disc. This can include one or more chapters.
Press the• A-B button to mark the start of the section
you want to repeat.
The indication ‘A-’ will appear under the repeat symbol on
the status display.
When you reach the end of the section you want to•
repeat, press the A-B button again.
The indication ‘A-B’ will appear under the repeat symbol on
the status display.
The player will now continuously repeat the section
between the start and end markers.
Press the• A-B button again to clear an A-B repeat
section.
Title
playing
Chapter
playing
Title
Elapsed
time
Title
total
time
Repeat
status
Play
status
Elapsed time
bargraph
Total
chapters
On-Screen status display:
When a Blu-ray or DVD-Video disc is playing you can open
the On-Screen status display to show information about
the disc that is currently playing.
Press the• OSD button.
The On-Screen status display will open.
Press the• OSD button again to switch o the On-
Screen status display.
Subtitles:
Most discs will include at least one subtitle option.
To switch on and select subtitles -
Press the• SUBTITLE button.
The Subtitle yout menu will open and show the subtitle
option currently selected.
Press the Pbutton if you want to change the subtitle.
Press the• Mor Nbutton to scroll through the options
available.
Press the• ENTER button to choose an option.
If you have chosen a subtitle, it will now display on the TV
screen. After a short delay, the yout will close.
Camera angle:
Some discs will include the option to view from a choice
of camera angles.
To change camera angle -
Press the• ANGLE button.
The Angle yout menu will open.
Press the• Mor Nbutton to scroll through the options
available.
Press the• ENTER button to choose an option.
If you have changed the camera angle, the lming angle will
now change on the TV screen. After a short delay, the yout
will close.

13
PLAYING A BLU-RAY OR DVD-VIDEO DISC
Audio selection:
Some discs will include multiple soundtracks in dierent
languages or using dierent encoding methods.
To change the audio soundtrack -
Press the• AUDIO button.
The Audio yout menu will open.
Press the• Mor Nbutton to scroll through the options
available.
Press the• ENTER button to choose an option.
Play will now resume with your choice of audio soundtrack.
After a short delay, the yout will close.
Zoom and pan (DVD Video discs only):
Press the• ZOOM button repeatedly to select the zoom
level you want from the options of Zoom o, Zoom x
2, Zoom x 4.
The view will zoom to the centre of the picture.
Press the• O,P,M,Nbuttons to pan the zoomed area
around the photo.
The zoom icon will show where the zoomed area is on the
photo.
Press the• ZOOM button repeatedly to return to normal
view.
Zoom O is indicated on the TV screen.
Volume and mute:
The volume setting for the sound of your system should
normally be set on the TV or AV surround decoder (if
you have one in your AV system). If required, you can
independantly adjust the player volume from the remote
control.
Press the• VOL+ button to increase the volume
setting.
Press the• VOL- button to decrease the volume
setting.
The volume level will be shown on-screen as a number in the
range 0-100 and also as a bargraph display.
To mute the sound completely, press the• MUTE
button.
To un-mute the sound, press the• MUTE button again.
The mute status will be displayed briey.
Resolution (HDMI only):
CAUTION: If you change to display resolution
settings that are incompatible with your TV, you
may lose the TV picture completely. If your TV is
connected via HDMI, the ‘Auto’ setting (factory
setting) is strongly recommended as the TV will
automatically set the resolution of the player for
optimum results.
NOTE: Although resolution settings will display on a TV
connected to the composite video (CVBS) video output,
the resolution of this video output is xed at 576i (PAL
operation) or 480i (NTSC operation).
To change the resolution -
Press the• RESOLUTION button once to display the
resolution setting currently in use.
Press the• RESOLUTION button repeatedly to switch
between the available resolutions.
Wait after each press for the picture to stabilise (this•
may take around 7 seconds) before pressing again to
step to the next resolution setting.
The resolution settings available are -
Auto•
1080p•
1080i•
720p•
576p•
576i•
NOTE: Changing the resolution setting from HDMI Auto
may result in the loss of a stable picture. If this happens
refer to the Troubleshooting section for instructions to
recover the picture.

14
BLU-RAY DISC SPECIAL FEATURES
The special features in this section apply to Blu-ray
discs only.
NOTE: Not all Blu-ray discs will support these features.
Blu-ray disc Popup Menu
Some Blu-ray discs feature a Pop-up Menu. This enables
you to view the Disc Menu to change settings or jump to
scenes (chapters) without stopping playback.
Press the• POPUP MENU button.
The Popup Menu will be displayed.
Blu-ray picture in picture (bonus view):
Some Blu-ray discs may include secondary video. This is
displayed as a second picture within the main picture.
Press the PIP button.•
The PIP yout menu appears, showing the current PIP
status.
If you want to change a setting from the Popup Menu,•
navigate the menu with the Oor Pbutton to select
the setting you want to change.
Press the• ENTER button to select the setting.
NOTE: Pressing the POPUP MENU button during DVD-
Video playback will return to the Disc Menu.
Press the• Pbutton to open the PIP setting screen.
The PIP options will be displayed.
Press the• Mor Nbutton to scroll through the
options.
In the example above, scroll down to select the rst•
(01) option of the two (02) PIP options avaiable.
Press the• ENTER button to select an option.
If you have selected one of the picture in picture options, a
secondary picture will be displayed on the TV screen.
To close the picture in picture display, select the ‘O’•
option from the PIP setting screen.
The secondary PIP display will close.
Secondary audio:
When secondary (picture in picture) video is displayed,
it is possible to switch the soundtrack to the secondary
video picture. The Secondary Audio menus are similar in
style to the PIP menus.
Press the• SECONDARY AUDIO button to open the
secondary audio yout menu.
Press the• Pbutton to open the Secondary Audio
setting screen.
The Secondary Audio options will be displayed.
Press the• Mor Nbutton to scroll through the
options.
Press the• ENTER button to select an option.
Colour buttons:
The red, green, yellow and blue colour buttons are used
with interactive menus when operating a Blu-ray disc
that includes Java applications.
Operating instructions will be included with the disc.
Main picture
Secondary picture

15
BD-Live content via the Internet:
Some Blu-ray discs include access to BD-Live content.
BD-Live content is provided via the Internet by the disc
producer.
To access BD-Live content -
Check that your player is connected to the Internet.•
Load a blank USB drive to the USB port on the front•
panel. The drive capacity should be between 2GB and
16GB.
NOTE: The USB memory is not optional. BD-Live will only
function when a USB drive memory is installed. If USB
memory is not installed you may see a warning message
stating that your player is incompatible with BD-Live.
Load the disc with BD-Live feature.•
Select the BD-Live menu option from the disc menu.•
You may now be required to follow the screen prompts to
register with the disc producer. Once registration is complete
you can browse the BD-Live content available by following
the screen prompts.
NOTE: You may experience delays as BD-Live content is
retrieved from the Internet.
BD-LIVE

16
PLAYING A CD AUDIO DISC
Load the disc•
After a short delay while the disc reads, the disc will start
to play from track 1. The track and elapsed time will be
displayed on the front panel and the TV will show the CD
playback status display.
PLAYBACK CONTROL
When a CD is playing.
Play/pause:
Press the• /, button.
PAUSE will be displayed on the TV screen status display.
Press the• /, button to resume play.
Navigating tracks:
Press the• }or {button to jump forward or backward
through the tracks.
NOTE: Pressing the {button for the rst time will return
play to the start of the current track.
Jumping to a particular track:
Press one of the number keys on the• NUMERIC
KEYPAD to jump directly to a track number.
To enter a two digit track number, press the two•
number buttons (for example 1 then 2 to select track
12).
The player will jump directly to the track you selected.
Fast search
Press the• ]or [button to fast-search forward
or backward through a disc. Pressing the button
repeatedly will increase search speed in the range -
2X "4X "8X "16X "32X "64X "128X " Normal
The search speed is displayed on the TV screen
Press the• /, button to return to normal speed play.
Stopping the disc
Press the• .button (also available on the front panel)
to stop the disc.
NOTE: In systems where the player is used for audio
playback of CDs through an audio Surround Decoder
or amplier, a basic CD playback display is available on
the unit (the TV display is not required for track/time
navigation). To set advanced play modes such as Repeat,
it will be necessary to use the TV display to determine the
status of the player.
Repeat/random play:
There are three repeat/random modes.
Press the• REPEAT button repeatedly to step through
the three repeat modes.
The repeat mode selected will be displayed on the TV
screen.
Repeat All: The player will repeat all tracks on the disc
continuously.
Repeat All + Random: The player will repeat all tracks on
the disc continuously, but in a random sequence.
Repeat track: The player will repeat the track currently
playing.
Repeat A-B:
You can also set the player to repeat a particular passage
from the disc. This can include one or more tracks.
Press the• A-B button to mark the start of the section
you want to repeat.
The indication ‘A-’ will appear under the repeat symbol on
the status display.
When you reach the end of the section you want to•
repeat, press the A-B button again.
The indication ‘A-B’ will appear under the repeat symbol on
the status display.
The player will now continuously repeat the section
between the start and end markers.
Press the• A-B button again to clear an A-B repeat
section.
Track
playing
Total
tracks
Elapsed
time
Track
time
Repeat
status
Shue
status
Play
status
Elapsed time
bargraph

17
VIEWING JPEG PHOTO FILES
Playing photos from a CD-ROM or DVD-ROM:
Load the disc.•
Playing photos from a USB Flash drive:
Dock the USB drive into the USB port located under•
the protective cover on the front panel.
You will now see the Main Menu selection options. The
options available will depend on the content of your disc/
drive. In the example below, the drive contains music, photos
and videos.
From the thumbnail view -
To display a single photo:
Use the• O,P,M,Nbuttons to highlight the thumbnail
you want to display.
Press the• ENTER button to display this photo.
To view other photos:
Press the• }or {button to step through the photos
in the folder.
To return to the thumbnail view:
Press the• .button.
The thumbnail view will be displayed.
Menu
pane
Thumbnail
pane
Press to start
slideshow
Selected
Disc/drive
contents
Press the• Mor Nbutton to highlight the Pictures
option.
Press the• ENTER button to select this option.
If your photos are not stored in folders you will now see a
thumbnail view of your photos.
If your photos are stored in folders, the folders will•
be displayed in the thumbnail pane. Use the P, M,
Nbuttons to navigate to the folder containing your
photos.
The thumbnail view will appear. To run a slideshow of the photos:
From the thumbnail view, press the• Obutton to
navigate to the left pane.
Press the• Mor Nbutton to select the ‘Start Slide
Show’ option from the menu.
The slideshow will start. When all the photos have been
displayed, the slideshow will stop.
To continually play a slideshow:
Press the• REPEAT button to switch slideshow repeat
mode on or o.
To pause a slideshow:
Press the• /, button to pause a slideshow display.
Press the• /, button to re-start the slideshow.
Changing Slideshow Settings:
Press the• POPUP MENU button to open the slideshow
settings yout menu.
The slideshow settings yout will open.
Press the• Mor Nbutton to choose the option of Slide
Show Eects or Slide Show Delay.
Press the• Pbutton to change a setting for the option
you selected.
Press the• Mor Nbutton to select the setting you
want.
Press the• ENTER button to conrm the setting.
The setting will change and the yout will close after a short
delay.

18
VIEWING JPEG PHOTO FILES
Zoom and pan (during a slideshow):
Press the• /, button.
The slideshow will pause at the picture displayed.
Press the• ZOOM button repeatedly to select the zoom
level you want from the options of Zoom o, zoom x
2, zoom x 4.
The view will zoom to the top left corner of the picture and a
zoom icon is shown on the screen.
Press the• OSD button again to close the photo
information banner.
Photo information banner:
Press the• OSD button while a photo is displayed to
open the photo information banner.
The photo information banner will open.
Zoom is currently displaying
this area of the screen
File
number
Total les
File name
Slideshow repeat
Play
status
Slideshow display time
Press the• O,P,M,Nbuttons to pan the zoomed area
around the photo.
The zoom icon will show where the zoomed area is on the
photo.
Press the• /, button to return to the slideshow.
Zoom and pan (single picture display):
Press the• ZOOM button repeatedly to select the zoom
level you want from the options of Zoom o, zoom x
2, zoom x 4.
The view will zoom to the top left corner of the picture and a
zoom icon is shown on the screen.
Background music:
While viewing your photos you can also play background
music.
Check that you have loaded the background music•
WMA les that you want to play onto the disc or drive
containing your photo les.
Load the disc or drive.•
Select the ‘Pictures’ option.•
The thumbnail view will appear. If music les are included
on your disc/drive, the ‘Browse Music’ option will appear on
this menu.
Select the ‘Browse Music’ option before displaying•
your pictures.
You can now browse for the music that you want to play.
Once the music is playing, press the• ENTER button.
Choose the ‘Browse pictures’ option from this menu.•
You can now navigate to a picture to display or start•
a slideshow.
Browse
music
Zoom is currently displaying
this area of the screen
Press the• O,P,M,Nbuttons to pan the zoomed area
around the photo.
The zoom icon will show where the zoomed area is on the
photo.
