Technika MC 507 Instruction Manual

User Handbook
CD/TUNER Hi-Fi SYSTEM WITH MP3 AND USB FLASH DRIVE SUPPORT
MC 507

apparatus has been exposed to rain or moisture, - Reorient or relocate the receiving antenna.
does not operate normally, or has been dropped. - Increase the separation between the equipment
Warning: To reduce the risk of fire or electrical and receiver.
shock, do not expose this product to rain or - Connect the equipment into an outlet on a circuit
moisture. The product must not be exposed to different from that to which the receiver is
dripping and splashing and no object filled with connected.
liquids such as a vase of flowers should be placed - Consult the dealer or an experienced radio/TV
on the product. technician for help.
No naked flame sources such as candles should ELECTRICAL INFORMATION
be placed on the product. Mains Supply: The mains operating voltage of this
Caution: Changes or modifications not expressly unit is on the rating plate on the rear.
approved by the manufacturer could void the user's The means of disconnecting the unit from the mains
authority to operate this device. supply is the mains plug. This must be unobstructed
Caution: Usage of controls or adjustments or and freely operable at all times.
performance of procedures other than those
Read these instructions. Class II construction double insulated. This
specified herein may result in hazardous exposure.
Keep these instructions. product must not be connected to earth.
These labels tell you that the unit contains a Laser
Heed all warnings. component. Do not stare at the laser lens.
Follow all instructions.
Do not use this apparatus near water.
Clean only with a slightly damp cloth.
Do not block any ventilation openings.
Install in accordance with the manufacturer's IMPORTANT
instructions.
This equipment generates, uses and can radiate
Do not install or operate near any heat sources such radio frequency energy and, if not installed and
as radiators, stoves, or other apparatus that used in accordance with the instructions, may cause
produce heat. harmful interference to radio ommunication.
Unplug this apparatus during lightning storms or However, this is no guarantee that interference will
when unused for long periods of time. not occur in a particular installation. If this
Refer all servicing to qualified service personnel. equipment does cause harmful interference to radio
Servicing is required when the apparatus has been or television reception, which can be determined by
damaged in any way, such as the power-supply turning the equipment off and on, the user is
cord or plug is damaged, liquid has been spilled or encouraged to try to correct the interference by one
objects have fallen into the apparatus, the of the following measures:
CAUTION!
RISK OF ELECTRIC SHOCK
DO NOT OPEN
TO REDUCE THE RISK OF ELECTRIC SHOCK DO
NOT REMOVE COVER (OR BACK)
This symbol indicates that there are important
operating and maintenance instructions in the
literature accompanying this unit.
This symbol indicates that dangerous voltage
constituting a risk of electric shock is present within
this unit.
IMPORTANT SAFETY INFORMATION
2

Dirty, scratched or warped discs may cause
UNPACKING FITTING HANDSET BATTERIES
skipping or noise.
Slide the battery compartment cover down to
The carton contains: Handle the disc only by the edges. To keep discs
remove it. Unwrap the batteries and insert them into
$The MC507 AM/FM/CD receiver: clean, do not touch the surface.
the battery compartment as shown. Replace the
$Table stand: cover. Discs should be stored in their cases after use to
$Remote Handset: avoid scratches.
$ Wall mounting template and hardware. Do not expose discs to direct sunlight, high humidity,
Unpack all the components carefully being high temperature, dust, etc. Prolonged exposure to
especially careful not to damage the panels of the extreme temperatures can warp the disc.
loudspeakers. Do not stick or write anything on the disc. Sharp
Inspect the components carefully. If any item is writing instruments or the inks used in some felt tip
damaged or missing, contact the Tesco store from pens may damage its surface.
where you purchased this product, or if that is not
When loading a CD into the player:
possible, your nearest Tesco store. Please have your
receipt ready when you call. Position the disc over the centre spindle
Retain the packaging. If you dispose of it, do so in Make sure the printed side faces out
accordance with recycling regulations in your area. Press the CD gently into place
Retain the User Handbook. If you pass the unit on to Always use AAA batteries and replace them in pairs. NEVER use force
a third party make sure you pass on the handbook. Do not mix old and new batteries. If you are not
using the system for an extended period, remove
the batteries to avoid leakage and corrosion.
Never short circuit batteries or leave them lying When removing a CD from the player:
around. When disposing of used batteries do not Press lightly on the centre spindle
throw them into a fire, the general rubbish or water.
Gently ease the CD off by holding it at the edges.
Dispose of batteries having regard to the recycling
regulations in force in your area. Do not touch the playing surface
NEVER use force
PRELIMINARIES
CD TOPICS
3

Preliminaries
!Check that the mains voltage on the rating
plate which is located at the rear of the unit
matches the mains voltage in your area.
!Unwrap the power cord
!Uncoil the FM antenna and extend it fully.
The system can be used freestanding or wall
mounted
Ensure there is a suitable power point within easy
reach. The mains plug must not be obstructed
and must be freely operable at all times.
Make sure there is a least 150 mm (6”) of free
space above the unit so that the CD door can
open to its full height.
If you are free standing the system, site the system
on a stable surface (ideally a stout shelf) where it
is unlikely to fall or get knocked over.
Make sure that you position the unit where the
remote handset can easily be operated in direct
line of sight and no more than 15 metres away.
The radio performance of the system depends on
the aerial. If you plan to wall mount the unit make
sure that there is adequate signal strength in your
proposed location before drilling the wall.
The FM aerial should be moved around to get the ENSURE THE WALL IS STABLE AND CAN SUPPORT THE WEIGHT OF THE UNIT. It is for the user to
optimum results. Do not extend or cut the FM determine whether the supplied hardware is suitable for the wall and to provide proper alternative
antenna lead. fixings if not. If you are unsure of how to proceed consult a qualified building expert.
The MW aerial is internal to the system, so if you Apply the supplied template to the wall and mark the position of the holes. Ensure the template is
need good medium wave reception, try the horizontal so that the unit sits level. This is most important. Drill two 6mm holes in the wall. Push the
system in different locations before making a final wall plugs in and screw the two screws in leaving 7mm protruding. Align the keyhole slots in the unit
choice. over the screws and pull gently down to hang the unit.
SITING AND PLACEMENT ATTACHING THE TABLE STAND
4
1: Place the unit face
down on a table. Place a
soft cloth under the unit
to avoid damaging it.
2: Align the tabs on the
stand over the slots in
the unit
3: Slide the stand
forward and push the
tabs into place in the
unit.
4: When the tabs click into
place the stand is attached
5: Stand the assembly upright
and check that the stand firmly
supports the unit.
CLICK
WALLMOUNTING THE SYSTEM

CONTROLS AND FUNCTIONS - OVERVIEW
LOADING A CD
PRINT SIDE
FACING OUT
1: Select the CD input
2: Press OPEN/CLOSE to open the CD Door
3: Insert a CD as shown
4: Press OPEN/CLOSE to close the CD Door
Subwoofer Output Auxiliary Input
CD Door Control Panel
Right
Loudspeaker
Left
Loudspeaker
Table
Stand
Battery
Compartment
BACKUP BATTERIES
The backup batteries store all
your system settings so if there
is an extended power failure or
you disconnect the unit from
the mains you do not have to
re-enter the settings.
Lift off the battery compartment cover. Insert two AA batteries
(not supplied) as shown. Replace the cover.
EXTERNAL CONNECTIONS
AUXILIARY INPUT: Connect any line source such as a DVD or MP3 player. You will need to purchase a suitable RCA phono interconnect.
SUBWOOFER: This is a single RCA connector for connection to a powered subwoofer. Refer to your subwoofer user manual for guidance.
Make external connections before the unit is stand or wall mounted, or you will need to dismount the unit to access the connectors!!
Power
Cord FM Antenna
Wall mounting
keyhole slots
RIGHT
LEFT
1
CD
5

CONTROLS AND FUNCTIONS - FRONT PANEL
6
1. EQ KEY: Choose from Pass (no Eq.); Classic;rock; Pop; Jazz
2. SLEEP KEY: Choose a time period after which the set switches off.
3. TIMER KEY: Program the unit to switch ON/OFF
4. PROGRAM KEY: Set p a program of tracks. Set the clock (in Standby).
5. PREVIOUS KEY:
6. CD STOP KEY: Stop a CD playing
7. MULTIFUNCTION DISPLAY
8. PLAY/PAUSE KEY: Press to Pause a CD: Press again to play
9. NEXT KEY
10. FIND/ESP DISPLAY KEY:
11. TUNER/BAND KEY: Select the radio - Select AM/FM
12. CD REPEAT KEY: Repeat a track or a whole CD
13. MEM (+) KEY: Choose the next memorised Radio station up
14. FUNCTION KEY: Press to select AUX/USB CARD/TUNER/CD
15. MEM ( - ) KEY: Choose the next memorised Radio station down
16. VOLUME ( - ) KEY
17. VOLUME (+) KEY
18. ON/OFF KEY: Switch the unit ON or to Standby.
19. HEADPHONE SOCKET
20. USB SOCKET: Connect a USB flash card.
21. REMOTE CONTROL SENSOR
22. OPEN/CLOSE KEY: Open/Close the CD door.
0
TIMER
PROGRAM
FIND/ESP
DISPLAY
TUNER
BAND
REPEAT
MEM+
MEM–
SLEEP FUNCTION
+
EQ – VOLUME
ON/OFFOPEN/CLOSE
VOLUME
PHONESIR SENSOR
USB
Alter the Volume up or down
In CD mode, search a CD or skip a track
In Radio Mode, tune up or down the band
In CD mode, search a CD or skip
In Radio Mode, tune up or down the band
a track
c
b
d
e
f
g
h
i
j
1)
1!
1@
1#
1$
1%
1^
1&
1*
1(
2)
2!
2@
Find a named MP3 track
Switch the ESP function ON/OFF
09 64:57
ESP

COMPARISON OF CONTROL PANEL
AND HANDSET FUNCTIONS
The figure below compares the Control Panel keys
with their direct handset equivalents. Most functions
are common to the Handset and Control Panel.
INTRO (2), MUTE (13) and NUMBER(7) keys are
available only on the handset.
The CD DOOR can only be operated from the
Control Panel.
FM Stereo/Mono reception can only be selected
via the FIND/MS key (18) on the handset.
CONTROLS AND FUNCTIONS - REMOTE HANDSET
7
c
b
d
e
f
g
h
i
j
1)
1!
1@
1#
1$
1%
1^
1&
1* FIND
MS BAND
TIMER
EQ
SLEEP
MEM
DOWN
MEM
UP
PLAY/PAUSE
BACK
TUNE
DOWN
VOLUME
TUNE
UP
INTRO
FUNC.
REPEAT
PROG
STOP
1 2 3
456
7 8 9
0
1. ON/OFF KEY: Switch the unit ON or to Standby.
2. BAND KEY: Select the radio - Select AM/FM
3. INTRO KEY: Sample the first 10 secs of every track on a CD
4. FUNCTION KEY: Press to select AUX/USB CARD/TUNER/CD
5. REPEAT KEY: Repeat a track or a whole CD
6. MEM UP KEY: Choose the next memorised Radio station up
7. NUMBER KEYPAD: Directly enter CD/MP3 track/album numbers
8. PROGRAM KEY: Set p a program of tracks. Set the clock .
9. PLAY/PAUSE KEY : Press to Pause a CD: Press again to play
10. PREVIOUS/NEXT KEYS:
11. CD STOP KEY: Stop a CD playing
12. VOLUME UP/DOWN KEYS: Alter the Volume up or down
13. MUTE KEY. Press to cancel/restore the sound.
14. MEM DOWN KEY: Choose the next memorised Radio station down
15. SLEEP KEY: Choose a time period after which the set switches off.
16. EQ KEY: Choose from Pass (no Eq.); Classic;rock; Pop; Jazz
17. TIMER KEY: Program the unit to switch ON/OFF
18. FIND/MS KEY:
0
CD mode, find a named Mp3 track/album
CD mode: set/cancel the ESP function
Radio Mode, set a FM station to Mono/Stereo
Search a CD or skip
Tune up or down a Radio band
a track
TIMER
PROGRAM
SLEEP
EQ
OPEN/CLOSE
VOLUME
IR SENSOR
FIND/ESP
DISPLAY
TUNER
BAND
REPEAT
MEM+
MEM–
FUNCTION
+
–VOLUME
ON/OFF
PHONES USB
09 64:57
ESP
1
2
4
5
6
8
9
10
11
12
14
15
16
17
18
10

GETTING STARTED
Plug in the mains plug and switch the system on at the
mains point.
The system will respond and go into Standby. In
standby mode the display is off so it may appear as if
the unit is not working - it is!
Setting the Clock
When the system is in Standby the screen displays the
clock time. The clock can be set to display 24 or 12
hour (AM/PM mode)
1. Press and hold the PROGRAM key for 3 seconds
2.Press the or keys to toggle 12/24 hr mode.
3. Press the PROGRAM key to confirm
Setting the time 20:25 (24 Hour Mode)
4. Press to set the hour.
3. Press the PROGRAM key to confirm
The hour stops flashing and the minutes flash.
4. Press to set the minutes.
5. Press the PROGRAM key to confirm
The minutes stop flashing and the clock is set.
To set the clock to 12 hour format:
Select ‘12 HOUR ‘ and proceed as above.
• The clock can only be set when the unit is in Standby
The procedure may be carried out from the control
panel or the handset.
SWITCHING ON
Press the POWER switch on the handset or the
ON/OFF switch on the front panel. The unit switches
on. In normal use the system will revert to the mode and
volume it was in when last used.
SELECTING AN INPUT
Repeatedly press the FUNCTION key to select an
input - AUX/ USB CARD/ TUNER/ CD
PLAYING A CD
1. Select CD via the FUNCTION key : OR
Press the PLAY/PAUSE key.
If no disc is in the player you will see:
2. Press OPEN/CLOSE to open the CD door
3. Place a CD into the tray with the label facing
outwards.
4. Press OPEN/CLOSE to close the CD door.
5.The player will read the disc Table of Contents (TOC)
The display will register the disc information and stop.
(A very few CDs may begin playing from Track 1.)
If the disc is a standard audio CD the display will show
“CD”. Other formats will display the format type.
These behave differently and will be covered later.
ANTI SHOCK PROTECTION (ESP): The player uses
a memory buffer. The buffer memorises up to 40
seconds of information and reads from this memory to
prevent skipping when the unit is subjected to minor
shocks and vibration. If you the unit is in a location
where there is no likelihood of shock and where it will
not be moved during play, you may switch ESP off.
Press the FIND/ESP key to toggle ESP ON and OFF.
OPERATION PLAYING A CD
8
24 hour
20:00
12 hour
24 hour
20:25
20:25
Hello
O D SC
CLOSE
CD READ
VOLUME
VOLUME
VOLUME
VOLUME
09 64:57
ESP
VOLUME
09 64:57
ESP
VOLUME
09 64:57
ESP
ESP ON
ESP OFF
OPE
VOLUME

REPEAT MODE
Press the REPEAT button to cycle the repeat mode of
the player as follows:
NORMAL PLAY: (NO ICON)
REPEAT: Repeat one track continuously.
REPEAT ALL: Repeat the entire CD continuously
INTRO SKIP
Press INTRO on the handset
The player samples the first ten seconds of each
successive track on the disc. After sampling all the
tracks on the disc the player will stop.
When you want to play a track: Press INTRO again
INTRO mode can be selected when the CD is stopped
or playing.
The INTRO function cannot be combined with the
REPEAT function.
PROGRAM PLAY
PROGRAM PLAY allows selected tracks on the disc
to be played in any desired order.
1. Load a CD; Press STOP
2. Press the PROGRAM key
“PROGRAM” P-01 appears and the display prompts
you to enter a track
3. Press to locate the desired track OR.
Select the track number from the handset
4. Press PROG to confirm.
“00 P-02" appears
5. Repeat steps 3 and 4 to program more tracks. Up to
64 tracks may programmed.
6. Press to play the program.
To cancel a program before it plays:
Press STOP
To cancel a program during Program Play:
Press STOP . The disc will stop and display the tracks
on the disc but the program is retained in the memory.
Press to play the disc normally from the start.
To replay the program:
Press PROGRAM followed by the PLAY/PAUSE key
To erase the program completely:
Press PROGRAM and then press STOP twice.
Editing a Program
From STOP mode during program play:
1. Press PROG repeatedly until you reach the track you
want to replace.
2. Press to locate the desired new track.
3. Press PROG again to confirm.
4. Press to play the program.
The full program will now play but when it reaches P-
03, instead of track 8, track 4 will play.
CD MODE AND PROGRAM PLAY
9
03 o5:21
VOLUME
ESP
REPEAT ALL
03 o5:21
VOLUME
ESP
03 o5:21
VOLUME
ESP
REPEAT ALL
REPEAT
03 o0:01
VOLUME
ESP
INTRO
0 0 P - 0 1
VOLUME
VOLUME
09 64:57
ESP
0 5 P - 0 1
VOLUME
0 0 P - 0 2
VOLUME
VOLUME
09 64:57
ESP
VOLUME
01 01:01
ESP
0 5 P - 0 1
VOLUME
0 8 P - 0 3
VOLUME
0 4 P - 0 3
VOLUME
MEMORY
MEMORY
MEMORY
MEMORY
MEMORY

Press PLAY/PAUSE to commence play
To change tracks:
Press repeatedly
The disc will go forward/back one track at a time
To repeat a track:
Press once.
The disc will replay the track from the beginning
To search at speed back or forward:
Press and hold .
The disc will search at speed and the sound will mute.
Release the button to revert to normal play.
To pause a disc:
Press .
The disc will pause. In pause mode the sound mutes
and the track number and time flash.
Press to resume normal play.
To stop the disc:
Press
The disc will stop and display the total tracks
To start a disc from a particular track
Press repeatedly to select the track no. OR
Enter the track number from the Number Keypad
Then press .
The disc will play from the start of the chosen track
You can also change tracks during play by selecting the
track from the number keypad and then pressing the
PLAY/PAUSE key.
ALTERING THE VOLUME
To increase /decrease the volume
Press VOLUME
The max. volume level is 30, the minimum is 0. The
volume level is indicated by the length of the bar
display at the bottom of the screen.
The volume level appears on the screen before
reverting to the track display.
Muting the sound
Press MUTE.
The Volume bar display flashes and the sound will
mute: In mute mode you can operate the player but the
sound remains muted
To cancel mute:
Press MUTE or VOLUME
Note: If you switch the player into Standby mode when
the Volume is set to maximum level (30) when you next
switch the player on the volume level will be reduced to
25.
If you set the volume to a level below 23 the player will
come on at the lower volume.
Sound Modes
Pressing EQ cycles the player through
PASS(No Eq), CLASSIC, ROCK, POP, JAZZ
The display indicates briefly the new mode.
To check the current mode: press EQ once.
CAUTION
Do not play the system at very high levels of
volume as you may damage your hearing.
PLAYING A CD CONTROLLING THE SOUND
10
03 o0:01
VOLUME
01 01:01
ESP
VOLUME
ESP
03 o5:21
VOLUME
ESP
03 o5:24
VOLUME
ESP
03 o5:25
VOLUME
09 64:57
ESP
VOLUME
07 64:57
ESP
VOLUME
07 00:01
ESP
OLUME 14
VOLUME
03 o5:21
VOLUME
ESP
03 o5:21
VOLUME
ESP
03 o5:21
VOLUME
ESP
Jazz
VOLUME
