Technogamma SineUPS Series User manual

SineUPS
Models S100a, S100a+, S100 and S200
User manual

Introduction
SineUPS is an uninterruptible power supply, guaranteeing constant powering to the
electric loads connected. In case of ains failure (power cut or instability) SineUPS
generates pure sine wave and can work continuously until the battery runs out. The output
voltage has the sa e for as the ains voltage eaning that the connected loads will
work just as efficiently as being powered fro the ains network.
When the device is powered by regular ains voltage, it keeps the battery fully charged so
it can provide its axi u capacity when needed.
Installation
Warning!
SineUPS works at high voltage and requires special attention when its being
connected!
The device is designed for home use only! Please make sure there is enough
space around it to vent properly, do not install it in a place e ceeding the operating
temperature and humidity!
Mounting
The device can be ounted on a horizontal surface or vertically on a wall. In order to
ount it vertically, install 4 screws on the wall (3.5 x 35 ), so the unit can be hanged as
depicted on the drawing below.
2

Connection
1. Connect the load's power plug to the OUTPUT socket of the UPS.
2. For odels S100 and S200 an external battery has to be connected ( odels S100a
and S100a+ have integrated battery, so skip this step, as S100a+ has an option for
connecting external battery so the step is not andatory). Connect the battery to the
BATTERY ter inal, paying attention to the polarity – the + cable goes to the + ter inal of
the battery. Depending on the particular type of installed battery, there is possibility that
so e har ful gases can be released and in that case it is reco ended to install the
device in a proper location.
3. Verify that the load and battery are properly connected. Plug the power plug of the
UPS (INPUT ter inal) to ains socket. If ains is present, the device will start charging the
battery. If in the electrical installation a co on neutral is used instead of protective
earth (PE), it is reco ended to cut off the plug and power the device using hard wiring –
brown wire to phase and blue to neutral.
4. Turn on the device to power the load connected by pressing the power on button
(see next chapter Operation).
3

Operation
Symbol Function Description
Power On / Off button Press and hold the button for 0.5 sec to turn
the device on or off.
On Device is turned on.
Battery 4 levels of battery charge, each LED stands
for 25% charge.
Mains power Stable ains. The LED blinks if the ains
voltage is not within the li its.
Error An error occurred: overload, overheat or
internal error.
Press and hold the power button for 0.5 sec to power the device and load connected.
The button LED lights on and a beeping sound is ade.
4

Stable mains
Whenever stable ains is present, the device charges the battery and displays the current
charge on the panel.
If the device is turned on and the ains is off or unstable, it auto atically switches to
battery powered ode.
If the ains is not available, the indicator goes off, if the ains voltage is not within the
specified li its the indicator blinks.
Battery power
Switching to battery powered ode a continuous sound is ade in the ti e of transition
and then a short one every 30 sec.
The ti e to operate on battery power depends on the capacity, charge and condition of
the connected battery, as well as the power of the load connected. When the battery
charge goes below 10%, the device beeps every 2 sec until the battery voltage goes below
10.2 V, then the device auto atically shuts down. When the ains is restored, the device
auto atically turns on and starts charging the battery.
In case of connecting a load that is ore powerful than the device rated output power or
short-circuit of the output, the LED lights up and the power to the load is cut off. The
UPS will atte pt 10 retries in 10 sec to restore the power to the load and if the overload
condition is re oved will go back to nor al battery power operation.
5

Troubleshooting
Problem Solution
The device is connected to
ains, but pressing the
button does not turn it
on.
The device does not function without a connected
battery!
If you are using a car battery, please check the
ounted ter inals – so e of the are painted on the
inner side and do not ensure proper electrical contact to
the battery contacts.
The battery should be in good condition. If the voltage
of the connected battery is under 10.5V, then the device
will not turn on /low voltage battery protection/.
The LED does not
indicate the presence of
ains.
Check the device connections and ains voltage.
Check the device fuse and replace it if necessary.
The device akes long
beep and turns itself of
during power up.
Device internal error. Please contact the authorized
service center.
The LED is on and beeps
every 30 sec.
Nor al work in battery powered ode, the device is
turned on and the ains is issing.
Inadequate work ti e in
battery ode.
Check that the battery is fully charged (at least 10 hours).
With ti e the battery capacity decreases. Contact the
authorized service for internal battery replace ent
( odel S100a) or replace the external battery with a new
one ( odels S100 and S200).
6

Technical parameters
Parameter S100a S100a+ S100 S200
Input Voltage 220 VAC
Frequency 50 Hz
Voltage to switch to
battery powered
ode
below 180 VAC
over 260 VAC
Protection Fuse, ounted on the housing
Output Voltage 220 VAC ± 4%
Frequency 50 Hz ± 1 Hz
Power 100 W 200 W
Voltage for Pure sine wave
Switching ti e < 5 s
Protection
Auto atic resettable protection fro overload and short
circuit
Battery Type 12V, lead-acid
Capacity
Internal 7.2
Ah
Internal
7.2 Ah
External1
20 – 70 Ah
External1
20 – 70 Ah
External1
20 – 100 Ah
Protection – Reverse polarity connection protection
Weight 4.1 kg 4.1 kg 2.1 kg 2.9 kg
Di ensions 200 x 200 x 70
A bient te perature 0 – 35 C
Relative hu idity 0 – 95 %
1. External battery is not part of the product.
7

Limited warranty
The warranty is valid for 24 onths fro the sale date. The warranty for the internal
battery for odels S100a and S100a+ is 12 onths.
Warranty is void if:
Incorrect installation
Alteration of the product and/or atte pts to repair or odify
Visible da age of the housing and/or the inside of the device
Da age caused by lightning stor s
Usage in inappropriate conditions (te perature and hu idity)
Broken warranty stickers
Warranty Card
Sold (client/date):___________________________________________________
__________________________________________________________________
Invoice (Receipt):____________________________________________________
Signature:_________________________________________________________
Technogamma TD
4004 Plovdiv, Bulgaria
9N Kuklensko Shose str. fl. 3, office 6
Phone: +359 32 699-240
E- ail: info@technoga a.bg
www.technoga a.bg
8
Rev 2.5
01/16
