TOSHIBA SYNC KIT
INSTALLATION MANUAL
480/480 V 100/160/225 kVA
Document No: 201090-000
Document Ref: 4GBH0096 Rev. B
March 2020

G9000 N Series TOSHIBA SYNC KIT 80-225kVA Installation Manual - 201090-000i
UNINTERRUPTIBLE POWER SYSTEM
If additional information or technical assistance is required call TOSHIBA Customer Support Center at 877-867-8773, or
write to: Toshiba International Corporation, 13131 West Little York Road, Houston, TX 77041-9990 Attn: UPS Product
Manager.
Please complete the following information for your records.
Keep this manual with the UPS equipment.
Job Number:
Model Number:
Serial Number:
Application:
Shipping Date:
Date of Installation:
Inspected By:
IMPORTANT NOTICE
Never attempt to install, operate, maintain or dispose of this equipment until you have first read and understood all
of the relevant product warnings and user directions that are contained in this Installation manual.
The installation of this equipment must only be performed by qualified personnel.
The Instructions contained in this manual are not intended to cover all of the details or variations in equipment or to
provide for every possible contingency to be met in connection with installation, operation, or maintenance. Should
further information be required or should particular problems arise which are not covered sufficiently the matter
should be referred to the local TOSHIBA sales office.
Nothing in this manual shall alter Toshiba International Corporation’s standard terms and conditions or the
conditions of any written sales contract.
Any Electrical or mechanical modifications to this equipment without prior written consent of
TOSHIBA will void all warranties and may void UL/CUL listing. Unauthorized modifications may
also result in personal injury, death, or equipment damage.

ii G9000 N Series TOSHIBA SYNC KIT 80-225kVA Installation Manual - 201090-000
Purpose and Scope of Manual
This manual provides information on how to safely install, operate, and maintain your TOSHIBA power electronics product.
This manual includes a section on General Safety Instructions that describes the warning labels and symbols that are used
throughout the manual. Read the manual completely before installing, operating, or performing maintenance on this
equipment.
This manual and the accompanying drawings should be considered a permanent part of the equipment and should be
readily available for reference and review. Dimensions shown in the manual are in metric and/or the English equivalent.
TOSHIBA reserves the right, without prior notice, to update information, make product changes, or to discontinue any
product or service identified in this publication.
TOSHIBA is a registered trademark of TOSHIBA INTERNATIONAL CORPORATION. All other product or trade references
appearing in this manual are registered trademarks of their respective owners.
TOSHIBA shall not be liable for technical or editorial omissions or mistakes in this manual. Nor shall it be liable for
incidental or consequential damages resulting from the use of information contained in this manual.
This manual is copyrighted. No part of this manual may be photocopied or reproduced in any form without the prior written
consent of TOSHIBA INTERNATIONAL CORPORATION.
© Copyright 2020 TOSHIBA INTERNATIONAL CORPORATION.
All rights reserved.
Printed in Japan
Contacting TOSHIBA Customer Support Center
The TOSHIBA Customer Support Center can be contacted to obtain help in resolving any Uninterruptible Power System
problem that you may experience or to provide after sales service support.
Toshiba Customer Support Center
8 a.m. to 5 p.m. (CST) –Monday through Friday
Tel [phone]
Fax [phone]
E-mail –[email protected]
You may contact TOSHIBA by writing to:
TOSHIBA INTERNATIONAL CORPORATION.
SOCIAL INFRASTRUCTURE SYSTEMS GROUP
POWER ELECTRONICS DIVISION
13131 West Little York Rd.
Houston, TX 77041-9990
Attn: UPS Product Manager
For further information on Toshiba products and services, please visit our website at:
http://www.toshibaups.com

G9000 N Series TOSHIBA SYNC KIT 80-225kVA Installation Manual - 201090-000iii
Table of Contents
Table of Contents....................................................................................................................................................................iii
List of Figures..........................................................................................................................................................................iii
List of Tables...........................................................................................................................................................................iii
1How to use this Manual....................................................................................................................................................1
1.1 Notice Icons.............................................................................................................................................................1
1.2 Qualified Personnel.................................................................................................................................................2
2OVERVIEW......................................................................................................................................................................3
3TOSHIBA SYNC KIT parts list.........................................................................................................................................4
4TOSHIBA SYNC KIT Parts Location ...............................................................................................................................6
5MASTER UPS Installation Procedure..............................................................................................................................8
6SLAVE UPS Installation Procedure.................................................................................................................................9
7SLAVE UPS Setting Procedure.....................................................................................................................................12
8Verify Proper Setup........................................................................................................................................................14
List of Figures
Figure 2-1 Synchronous operation configuration .................................................................................................................3
Figure 3-1 TOSHIBA SYNC KIT parts appearance..............................................................................................................5
Figure 4-1 TOSHIBA SYNC main parts location (MASTER UPS).......................................................................................6
Figure 4-2 TOSHIBA SYNC main parts location (SLAVE UPS) ..........................................................................................7
Figure 5-1 Installation Procedure for Master UPS................................................................................................................8
Figure 6-1 Installation procedure for SLAVE UPS (1)........................................................................................................10
Figure 6-2 Installation procedure for SLAVE UPS (2)........................................................................................................10
Figure 6-3 Installation procedure for SLAVE UPS (3)........................................................................................................11
Figure 7-1 SLAVE UPS setting procedure.........................................................................................................................13
List of Tables
Table 3-1 Parts list of TOSHIBA SYNC KIT.........................................................................................................................4

iv G9000 N Series TOSHIBA SYNC KIT 80-225kVA Installation Manual - 201090-000
This Page Left Intentionally Blank

G9000 N Series TOSHIBA SYNC KIT 80-225kVA Installation Manual - 201090-0001
1 How to use this Manual
This manual is designed for ease of use, giving the user easy and quick reference to information.
This manual uses notice icons to draw attention to the user important information regarding the safe operation and
installation of the UPS.
1.1 Notice Icons
The notice icons used in this manual are explained below, and should be taken into account and adhered to whenever they
appear in the text of this manual.
Warning: A warning symbol shows potentially hazardous situation or condition which could result in
personal injury or death, if not avoided.
Caution: A caution symbol shows potentially hazardous situation or condition which could result in
personal injury or equipment damage, if not avoided.
Note: A Note symbol shows the information the user or the service personnel should observe during
the UPS operation or service work.
Prohibit: A prohibit symbol shows the act the user or the service personnel should NEVER perform
during the UPS installation, operation or service work.
Safety Recommendations: If any problems are encountered while following this manual, contact the Toshiba Customer
Support Center.
WARNING
CAUTION
!
NOTE
PROHIBIT

2 G9000 N Series TOSHIBA SYNC KIT 80-225kVA Installation Manual - 201090-000
1.2 Qualified Personnel
Only qualified persons are to install, operate or service this equipment according to all applicable codes and established safety
practices.
A qualified person must:
1) Read this entire instruction manual carefully.
2) Be skilled in the installation, construction or operation of the equipment and aware of the hazards involved.
3) Be trained and authorized to safely energize, de-energize, clear, ground, lockout and tag circuits in accordance with
established safety practices
4) Be trained and authorized to perform the service, maintenance or repair of this equipment
5) Be trained in the proper care and use of protective equipment such as rubber gloves, hard hat, safety glasses, face shield,
flash clothing, etc. in accordance with established practices
6) Be trained in rendering first aid.

G9000 N Series TOSHIBA SYNC KIT 80-225kVA Installation Manual - 201090-0003
2 OVERVIEW
TOSHIBA G9000 Uninterruptible Power Supply Systems (UPS) need a TOSHIBA SYNC KIT whenever two SMS UPSs are
installed in a synchronous operation configuration.
Each TOSHIBA SYNC KIT contains all hardware necessary for one pair of master and slave UPS to operate in a
synchronous configuration. Each additional UPS unit will require another sync kit, if applicable. This manual contains kit
installation and startup information specifically for 80-225kVA capacity models of the G9000 Enhanced Series UPS.
The UPSs must be de-energized when the TOSHIBA SYNC KITs are installed and the
synchronous operation configuration is established between the UPSs.
Figure 2-1 Synchronous operation configuration
CAUTION
BYPASS Input
AC Input
UPS #A: MASTER
INV
CONV
INV
CONV
UPS #B: SLAVE
BYPASS Input
TOSHIBA Sync circuit
Master
TOSHIBA Sync circuit
Slave
STS
PDU
VSAU-16
To Load
AC Input
IOAU-09*
TN1
13 14
Jumper
External Input Contact
UPS #A: MASTER
UPS #B: SLAVE
, TOSHIBA G9000 series UPS or competitor’s three phase UPS
, TOSHIBA G9000 series UPS
Qty. 3 #16AWG, 600V insulation,
multi-strand, twisted trio wire, with ring lugs
for #12 screws.
Field installed by Others

4 G9000 N Series TOSHIBA SYNC KIT 80-225kVA Installation Manual - 201090-000
3 TOSHIBA SYNC KIT parts list
Table 3-1 Parts list of TOSHIBA SYNC KIT
#
Part name
Qty
Remarks
Master
Slave
1
VS1 PCB: Sensor Board (VSAU-16*)
-
1
2
Mounting Bracket
1
1
3
Flat Cable (UPGR-M*/UPJR-C* - VSAU-16*)
-
1
L=3800mm
4
Wire (VSAU-16* - Fuses) 3-twisted
-
1
L= 200mm
5
Wire (Terminal Jumper for VSAU-16*)
-
3
L= 150mm
6
Wire (GNDC - FG)
-
1
L= 40mm
7
Wire (OUTPUT Busbars - Fuse holder) 3-twisted
1
-
L=1000mm
8
Wire (Terminal Jumper for IOAU-09*)
-
1
L= 40mm
9
Fuses holder
1
1
10
Fuses
3
3
11
Spacer
-
4
12
Screws (M3) with spring washer and flat washer
-
5
For Spacer: 4
For Grounding: 1
13
Screws (M4) with spring washer and flat washer
6
6
For Fuses holder: 2x2
For Bracket 4x2
14
Fuse label
1
1
[Note] Part number followed by “ * ” denotes any letter A to Z.

G9000 N Series TOSHIBA SYNC KIT 80-225kVA Installation Manual - 201090-0005
#1: VSAU-16*: Sensor Board
#2: Mounting Bracket
#3: Flat Cable (UPGR-M*/UPJR-C* - VSAU-16*)
#4: Wire (VSAU-16* - Fuses) 3-twisted
#5: Wire (Terminal Jumper for VSAU-16*)
#6: Wire (GNDC - FG)
#7: Wire (OUTPUT Busbars - Fuse holder)
3-twisted
#8: Wire (Terminal Jumper for IOAU-09*)
#9: Fuses holder
#10: Fuses
#11: Spacer
#12: Screws (M3)
#13: Screws (M4)
#14: Fuse label
[Note] Part number followed by “ * ” denotes any letter A to Z.
Figure 3-1 TOSHIBA SYNC KIT parts appearance

6 G9000 N Series TOSHIBA SYNC KIT 80-225kVA Installation Manual - 201090-000
4 TOSHIBA SYNC KIT Parts Location
Figure 4-1 TOSHIBA SYNC main parts location (MASTER UPS)
#2: Mounting
Bracket
#9: Fuses holder
#10: Fuses
#7: Wires
(OUTPUT Busbars –Fuses)
To SLAVE UPS
Pictured: 225kVA UPS
UPGR-M*/
UPJR-C*

G9000 N Series TOSHIBA SYNC KIT 80-225kVA Installation Manual - 201090-0007
Figure 4-2 TOSHIBA SYNC main parts location (SLAVE UPS)
#3: Flat Cable
#2: Mounting
Bracket
#1: VSAU-16*
Sensor Board
#9: Fuses holder
#10: Fuses
From MASTER UPS
Pictured: 225kVA UPS
UPGR-M*/
UPJR-C*

8 G9000 N Series TOSHIBA SYNC KIT 80-225kVA Installation Manual - 201090-000
5 MASTER UPS Installation Procedure
1. Prior to the installation of the parts, confirm that the AC input breaker, AC output breaker,
Bypass input breaker and DC breaker are turned off. (De-energize the interior of the UPS.)
2. Then remove the metal cover plates from UPS.
Refer to Figure 5-1 Installation Procedure for Master UPS
Step M-1. Install the Fuse holder (#9) on the Mounting Bracket(#2) with Screws (M4, #13).
Step M-2. Insert three (3) Fuses (#10) into the Fuse holder(#9).
Step M-3. Stick the Fuse label (#14) on the Mounting Bracket(#2).
Step M-4. Install an assembly of Mounting Bracket (#2), which is mentioned above, into the UPS with screws
(M4, #13).
Step M-5. Connect the wire (#7) between the OUTPUT Busbars (A/B/C) and the Fuse holder (#9, A/B/C side).
Step M-6. Connect the field-installed wirings (connected between MASTER UPS and SLAVE UPS) to the Fuse
holder (#9, a/b/c side).
Note: wires (qty. 3) should have 600V insulation and be #16AWG, multi-strand, twisted trio with ring
lugs sized for #12 screws.
Figure 5-1 Installation Procedure for Master UPS
Step M-1
#9: Fuses holder
* Use two (2) screws (M4, #13)
to install the Fuse holder(#9)
Step M-2
#10: Three (3) Fuses
Step M-4
* Use four (4) screws (M4, #13)
to install an assembly of
Mounting Bracket(#2) into UPS.
#2: Mounting Bracket
Step M-3
#14: Fuse label
Step M-5
#7: Wire 3-twisted
(Bus bars - Fuse holder)
A
B
C
a
b
c
Step M-6
Field-installed wirings
to SLAVE UPS
From OUTPUT Busbars
To SLAVE UPS
CAUTION

G9000 N Series TOSHIBA SYNC KIT 80-225kVA Installation Manual - 201090-0009
6 SLAVE UPS Installation Procedure
1. Prior to the installation of the parts, confirm that the AC input breaker, AC output breaker,
Bypass input breaker and DC breaker are turned off. (De-energize the interior of the UPS.)
2. Then remove the metal cover plates from UPS.
Refer to Figure 6-1 Installation procedure for SLAVE UPS (1)
Step S-1. Install the Fuse holder (#9) on the Mounting Bracket (#2) with Screws (M4, #13).
Step S-2. Insert three (3) Fuses (#10) into the Fuse holder (#9).
Step S-3. Stick the Fuse label (#14) on the Mounting Bracket (#2).
Step S-4. Screw four (4) Spacers (#11) on the Mounting Bracket (#2).
Refer to Figure 6-2 Installation procedure for SLAVE UPS (2)
Step S-5. Install the VS1 PCB, Sensor Board (VSAU-16*, #1), onto the Spacers (#11) with Screws (M3, #12).
Step S-6. Connect the wire (#6) between the VS1 PCB (#1) and the Mounting Bracket (#2) for grounding.
Step S-7. Connect the wire (#4) between the Fuse holder (#9, U/V/W Side) and the VS1 PCB (#1).
Step S-8. Connect the wire (#5) between the terminals (UN and V, VN and W, WN and U) on the VS1 PCB
(#1).
Step S-9. Install an assembly of Mounting Bracket (#2), which is mentioned above, into the UPS.
Step S-10. Connect the Flat cable (#3) between the CN1 of VS1 PCB(#1) and the CN50 of UP1 PCB
(UPGR-M*/UPJR-C*).
Step S-11. Connect the field-installed wirings (from MASTER UPS) to the Fuse holder (#9, A/B/C Side).
Note: wires (qty. 3) should have 600V insulation and be #16AWG, multi-strand, twisted trio with
ring lugs sized for #12 screws.
Refer to Figure 6-3 Installation procedure for SLAVE UPS (3)
Step S-12. Connect the Jumper (#8) between the terminal 13 and 14 of TN1 on IO1 PCB (IOAU-09*).
CAUTION

10 G9000 N Series TOSHIBA SYNC KIT 80-225kVA Installation Manual - 201090-000
Figure 6-1 Installation procedure for SLAVE UPS (1)
Figure 6-2 Installation procedure for SLAVE UPS (2)
* Use four (4) screws (M4, #13)
to install an assembly of
Mounting Bracket(#2) into UPS.
* Use a screw(M3, #12)
for grounding.
* Use four (4) screws(M3, #12)
to install VS1 PCB.
Step S-11
Field-installed wirings
from MASTER UPS
From MASTER UPS
CN50
Upper right of UP1 PCB
Step S-10
#3: Flat cable
Connect between
UPGR-M*/UPJR-C* (CN50) -
VSAU-16*(CN1)
Step S-9
CN1
Step S-6
#6: Wire (GNDC - FG)
Step S-8
#5: Wire
(Terminal Jumper
for VSAU-16*)
UN - V
VN - W
WN - U
Step S-5
#1: VS1 PCB (VSAU-16*)
Step S-7
#4:Wire
(VSAU-16* - Fuses,
3-twisted)
U - U
V - V
W - W
U
A
V
B
W
C
#2: Mounting Bracket
Step S-1
#9: Fuses holder
Step S-2
#10: Three (3) Fuses
* Use two (2) screws (M4, #13)
to install the Fuse holder (#9)
Step S-4
#11: Four (4) Spacers
Step S-3
#14: Fuse label
UP1 PCB
(UPGR-M*/UPJR-C*)

G9000 N Series TOSHIBA SYNC KIT 80-225kVA Installation Manual - 201090-00011
Figure 6-3 Installation procedure for SLAVE UPS (3)
TN1
TN1
14
13
IO1 PCB
(IOAU-09*)
Step S-12
#8: Wire (Jumper)

12 G9000 N Series TOSHIBA SYNC KIT 80-225kVA Installation Manual - 201090-000
7 SLAVE UPS Setting Procedure
*The setting for MASTER UPS is unnecessary.
1. Before the UPS setting, install the metal cover plates for the UPS.
2. Keep door closed except when the "MAINT" button located on the
SW1 PCB (DPAU-81*) is pressed.
Step 1. Supply the AC input and the Bypass input voltage to the UPS.
Initialization will start. Under initializing, the UPS will automatically:
-Turn on contactor CB1;
-Initialize converter operation;
-Initialize inverter operation;
After initialization, LCD screen should appear.
(Refer to the SERVICE MANUAL, 6-1. SMS Start-up Procedure for details.)
Step 2. Press the "MAINT" button located on the SW1 PCB (DPAU-81*).
Maintenance screen will appear.
Step 3. Press the "SETUP" tab on the Maintenance screen, then press the "INPUT PORT" button.
Step 4. Press the "IN4" button, and select item "9: ANOTHER BUS. SYNC." by pressing " " key then
press "OK" button.
1. As the “IN4”default setting, it may be “POWER DEMAND”.
2. Before making a change of the “IN4”setting, make sure that the POWER DEMAND function is
defunct.
(Contact Toshiba International Corporation, if POWER DEMAND function is under service.)
Step 5. Press the "CLOSE" button, and confirm that "9: ANOTHER BUS. SYNC." is lay out.
Step 6. Press the "MAINTENANCE" tab, then press the "MAIN MENU" button for completion of SLAVE
UPS SETTING.
CAUTION
ATTENTION

G9000 N Series TOSHIBA SYNC KIT 80-225kVA Installation Manual - 201090-00013
Press the "MAINT" button Return to "MAIN" screen
Press the "SETUP" tab Return to "MAINTENANCE" screen
Press the "INPUT PORT" button Confirm "9: ANOTHER BUS. SYNC."
Press the "IN4" button Select item "9: ANOTHER BUS. SYNC."
Figure 7-1 SLAVE UPS setting procedure
MAINT
Confirm

14 G9000 N Series TOSHIBA SYNC KIT 80-225kVA Installation Manual - 201090-000
8 Verify Proper Setup
To confirm that the TOSHIBA SYNC circuit is functioning properly, during TOSHIBA SYNC operation, “Ath Bus Sync.” is
displayed at the bottom of LCD screen as shown in Figure 8-1.
Figure 8-1: Example of TOSHIBA SYNC operation display
