Technomax TD40N User manual

ENG
Instr. TD40N.
2
Before placing the minibar into service, read this manual
carefully in all its parts!
Dear Customer,
We would like for this product, which is developed in modern production lines and subjected to
thorough Quality Control testing, to offer maximum performance.
We kindly ask that you:
-store this manual in such a way that it can be accessed if needed, as it may need to be
consulted in the future.
-follow all the safety instructions.
-read any other supplementary documentation attached to this manual.
CONTENTS
1- Pre-installation warnings and safety precautions
2- Technical specifications of minibar
3- Intended use of minibar
4- Instructions for correct installation in a furniture unit
5- Fixing the minibar to the furniture unit
6- Fixing the handle (without a decorative panel)
7- Fixing a decorative panel (supplied by the Hotel) and the handle
8- First use and regulation of minibar
9- Disposal
10- Cleaning the minibar
11- Instructions to follow to return the minibar
12- Recommendations for improved energy savings
13- Troubleshooting
14- Warranty
This product complies with the EU Directives and Regulations listed below:
•Regulation 2014/35/EU concerning electrical materials intended for use
within certain voltage limits (LVD).
•Regulation 2014/30/EU concerning electromagnetic compatibility (EMC).
•Regulation 643/2009/EC Directive 2009/125/EC (ERP).
•Regulation 1060/2010/EU Directive 2010/30/EC (ECO-LABEL).
IM PORTANT NOTICE:
THE MANUFACTURER RESERVES THE RIGHT TO MAKE CHANGES TO THE PRODUCT
AND MANUAL WITHOUT PRIOR NOTICE.

ENG
Instr. TD40N.
3
.
1- Pre-installation warnings and safety precautions
After removing the packaging, check that
the minibar is intact and without defects.
The minibar must be positioned on a flat
base.
Do not insert oils or foods cooked with
vegetable oils in unsealed containers in
the minibar, insofar as they may damage
the surfaces of your appliance. In case
of spillage or oil stains on the surfaces,
clean and rinse them with warm water.
The minibar must be installed far from
heat sources such as ovens, cookers,
etc. and away from direct sunlight.
The cooling unit at the back of the
minibar must be ventilated through
openings in the furniture unit of about
200 cm²each (see paragraph 5).
The ventilation openings of the minibar
must be free of any obstructions for the
correct circulation of air.
The supply voltage of the minibar is
indicated on the label inside the minibar
itself. The warranty shall lapse in the
event of problems caused by an
incorrect electrical power supply.
The electrical connections must be
checked by an expert electrician.
Use a power socket with ground
connection. Damage to the product
caused by electrical errors are not
covered by the warranty.
If the power cord is damaged, it must be
replaced only by a qualified person so as
to avoid hazardous situations.
The polyurethane expanding agent used
as an insulating material is
Cyclopentane, which is safe for the
ozone layer.
This appliance must not be used by
persons with reduced physical and
mental abilities, including children,
unless under the supervision of an adult
responsible for their safety.
Children must always be supervised to
ensure they don't play with the appliance
and its packaging.
The minibar has been designed to keep
beverages cold.
It is not suitable for the storage of
food or medical devices
Do not store products containing
explosive or flammable substances, or
pressurised containers in the minibar.
Never use petrol, benzene or similar
substances to clean the minibar.
The plug should always be disconnected
before cleaning the minibar.
The appliance must never be exposed to
rain.
230
Volts

ENG
Instr. TD40N.
4
2- Technical specifications of Minibar
Internal Light and
Temperature Regulation
MODEL TD40N
Gross capacity 40 lt.
Net capacity 38 lt.
Refrigerant type / quantity R600a / 25 g.
Product dim. without packaging H. x L. x D. mm 412 x 495 x 455
Type of Compartment Moderate Temperature Compartment (2)
Energy Efficiency Class A+
Climate Class / Ambient Temperature N / 16°C - 32 °C
Storage Temperature (°C) 8-14 °C.
Max. Input Power 65 Watts
Power 220-240V / 50-Hz
Energy Consumption (kWh/year) 115
Net Weight (Kg) 14
Gross Weight (Kg) 15
Thermostat Type Manual, inside minibar
Sound Emission (dB) 24
3. Intended use of Minibar
This minibar is intended for use in indoor environments, it is not designed for use in outdoor
environments.

ENG
Instr. TD40N.
5
4. Instructions for correct installation in a furniture unit
 Insert the minibar in a compartment having the following minimum dimensions: H 422 x L 505 x D 505 mm
Check that the minibar is placed on a horizontal surface and perfectly level. Inclinations greater
than 2 degrees are not allowed for the purposes of the warranty.
Leave a clearance between the back of the minibar and the wall of at least 5 cm.
The top and bottom ventilation openings of the minibar must not be covered.
It is necessary and essential to create an opening for the intake and output of air. Both openings
must be at least 200 cm² each.
The air passing through the duct must not be pre-heated.
If aeration grilles are used, they must include openings of at least 200 cm2each.
Regardless of how the minibar is installed, to ensure its proper operation and best cooling
performance, it is essential to ensure correct air circulation. This effect, as illustrated in the figure,
consists in allowing the intake of fresh air from the front bottom part of the appliance and the
subsequent expulsion of hot air from the top rear part.
Ensure the correct aeration of the cooling unit by implementing a ventilation duct as illustrated
in the images below.
FOR BUILT-IN INSTALLATIONS, IT IS ESSENTIAL TO CREATE PROPER AIR INTAKES SO AS
TO FACILITATE THE EXPULSION OF THE HOT AIR PRODUCED.
Aeration with 200 cm² grille, E.g.: 40 cm x 5 cm
Air Output
Min. 200 Cm3
Air Output
Min. 200 Cm
3
A i r In t ak e
Min. 200 Cm
3
A i r In t ak e
Min. 200 Cm
3
A i r In t ak e
Min. 200 Cm
3
A i r In t ak e
Min. 200 Cm
3
Air Output
5 Cm
Air Output
5 Cm

Instr. TD40N.
6
5. Fixing the minibar to the furniture unit
In order to fix the minibar to the furniture unit, the drawer needs to be completely removed.
1) Open the drawer completely;
2) Press the guide release device (1) as follows
Lower the black lever on
the right-hand side of the
drawer.
3) Pull the drawer out;
Lift the black lever on the
left-hand side of the
drawer.
4) Using the pilot holes inside the minibar (2) anchor the
minibar to the furniture unit using suitable screws.
5) Insert the drawer again, lowering and lifting the black
levers on the sides on the guides.
6. Fixing the handle (without a decorative panel)
Using the two pilot holes inside the
door, drill the door with a 3 mm bit.
Screw the handle onto the door of the
minibar with the two M4 short screws
supplied in the bag inside the minibar.
ENG

Instr. TD40N.
7
ENG
7. Fixing a decorative panel (supplied by the hotel) and the handle
To fix a decorative panel on the door of the minibar, the drawer needs to be completely
removed (see paragraph 5 points 1-3).
Using the pilot holes inside the door, fix the panel
with the supplied screws suitable for a panel of
minimum thickness 10 mm.
Using the two pilot holes inside the
door, drill the door with a 3 mm bit.
Screw the handle onto the door of the
minibar with the two M4 long screws
supplied in the bag inside the minibar.

ENG
Instr. TD40N.
8
To control the internal temperature
turn the knob, allowing the
temperature to be controlled within
a range of “0” to “3”.
8. First use and regulation of Minibar
The minibar must be connected to an AC power outlet, with suitable grounding in accordance
with legislation in force. Check that the minibar’s voltage and frequency of use correspond to
those in the country of use. In this case, connect the minibar plug and wait a few hours before
placing any beverages inside; otherwise, do not insert the minibar plug.
The minibar is equipped with a manual regulation thermostat, located inside the minibar.
For a lower internal temperature, turn the knob clockwise toward “3”;
For a higher temperature, turn the knob counter-clockwise toward “0”.
The minibar has an automatic defrost function. The fridge will start its first defrost cycle 36
hours after it is first turned on and will take about one hour to defrost. Afterwards, the fridge
will defrost every 36 hours of operation, for a duration of about one hour. The water generated by
the defrost cycle is collected in the collection tank located at the back of the minibar, and
eventually evaporates naturally.

ENG
Instr. TD40N.
9
The symbol on products or documents supplied with all
products indicates
that the minibar cannot be treated as
household waste. It must be sent to a collection point for the
disposal of electrical and electronic equipment. Dispose of in
accordance with local special waste disposal regulations. For
detailed information regarding
the treatment, recovery and
recycling of this product, contact your local municipality, urban
waste collection service or the retailer where you purchased
the product.
9. Disposal
The packaging materials may be hazardous to children, therefore keep them out of their reach. Do
not dispose of packaging materials as household waste, but in accordance with their classification.
The minibar packaging is produced using recyclable materials.
Dispose of your old minibar without harming the environment. To do so use an authorised special
waste collection centre or else return it to the retailer when purchasing a new equivalent appliance,
based on the ‘buy one return one’ principle. Before disposing of the fridge, cut the electrical power
cord and make any closures on the door unusable so as to protect children against all hazards.
This appliance bears the differentiated waste recycling symbol in compliance with European Waste
Electrical and Electronic Equipment Directive (WEEE) 2012/19/EU. Ensure that this product is
disposed of correctly to avoid potentially negative effects on the environment and human health.
ENG

ENG
Instr. TD40N.
10
10. Cleaning the Minibar
Before cleaning the minibar, turn it off and disconnect the
power.
Clean the inside and outside of the minibar with warm water
before use, then dry it carefully.
Never use soap, granular products, soda or other products
different to water for cleaning.
For the minibar door gasket, follow the cleaning procedures
described above, making sure not to use lubricating oils and
not to expose the minibar to humidity.
11. Instructions to follow to return the minibar
1) It is best to use the original packaging, otherwise pack it securely and carefully using cardboard
or bubble wrap.
2) Before packaging the appliance, take out all beverages and any other products.
3) In the case of multiple minibars, use wooden pallets wrapped in cellophane.
12. Recommendations for improved energy savings
•Install the appliance in a dry, well-ventilated environment, but not directly exposed to sunlight or
in the proximity of a heat source (for example radiators, the kitchen, etc.).
•Open and close the door in as short a time as possible.
•Every now and then, remove any dust from the back of the minibar using a vacuum cleaner or
brush, to avoid higher power consumption.

ENG
Instr. TD40N.
11
13. Troubleshooting
If the products presents a malfunction, make the following checks before contacting customer service:
PROBLEM
POSSIBLE CAUSES AND SOLUTIONS
The minibar doesn’t turn on
Check that the outlet has power.
Check that the plug is inserted properly.
The circuit may be burnt out.
The minibar doesn’t cool enough
The room temperature might be too high. The door has
been opened too often and for too long. The door isn’t
closed properly.
The temperature regulator hasn't been properly
positioned.
The door gaskets aren’t sealing properly. Check that
the air intakes are of the
correct size and that they're not covered.
The internal lighting doesn't work
Check that the outlet has power.
Check that the plug is inserted properly. The
circuit may be burnt out.
The globe may have burnt out.
The door doesn't close properly
The minibar isn’t resting on a horizontal surface.
The door handing has been changed incorrectly.
The gaskets are dirty.
The shelves or beverages aren’t positioned properly.
After making all these checks, if the problem persists, contact the retailer.
ENG

Instr. TD40N.
12
14. Warranty
The product is supplied with a warranty that covers manufacturing faults and defects for a
period of 24 months from the date of purchase, validated by a tax invoice.
•It lapses if the installation instructions are not followed;
•It lapses if the product is misused, changes are made to the appliance or non-original spare
parts are used;
•It shall not respond to any changes made to the appliance;
•It shall not respond to any damages to persons or property caused by misuse and/or incorrect
installation.
IMPORTANT: THE COMPANY RESERVES THE RIGHT TO MODIFY THE
CHARACTERISTICS OF THE PRODUCT WITHOUT ANY PRIOR NOTICE.
ENG
