TECO TVF172WMPA User manual

To ensure proper use of the appliance and your safety, please read the
following user manual completely before operating this appliance.
172L VERTICAL FREEZER
USER’S MANUAL
Model : TVF172WMPA

Thank you for purchasing our product and thank you for placing your
confidence in us.
Read this manual carefully before using. Follow instructions and
keep it for future reference.
Follow the operating instructions and safety notices in this manual.
If any trouble arise, do not fix it yourself or hand it to the after sales
service centre which have not been authorised. Please contact the
local authorised service centre.
This freezer is designed and approved for use with R134a refrigerant.
The appliance is specifically constructed for domestic
use and is therefore suitable for the refrigeration and storage
of frozen foods and the production of ice-cubes.
The appliance has not been designed or manufactured for
professional use. Teco declines all responsibility for damage
deriving from improper use of the appliance. The freezer
has undergone the necessary tests on the tightness of the
refrigeration circuit and complies with the safety regulations
for electrical appliances.
All images, illustrations and photos contained in this manual are for
illustration purposes only and may differ from your appliance.
WARNING ICON
This symbol indicates information concerning your personal
safety
CAUTION ICON
This symbol indicates information on how to avoid damaging
the appliance
FLAMMABLE ICON
R600a WARNING LABEL
CAUTION
WARNING
R600a

TABLE OF CONTENTS
Safety precautions............................................. 1
Name of parts and usage................................. 3
Packing List .................................................... 4
Transporting the appliance .............................. 5
Installation instructions..................................... 5
Reversing the Door ......................................... 6
Operating instructions ..................................... 8
Energy saving tips ........................................... 9
Maintenance ......................................... .......... 9
Disconnection of the appliance ....................... 10
Troubleshooting ............................................. 10
Repairs, service & warranty ..............................12
Specifications ................................................... 13

1
R600a Iso-butane Refrigerant
Hydrocarbon refrigerants have excellent refrigerant
properties and minimal low global warming potential and
no ozone depletion potential.
This appliance contains a small quantity of flammable, non-
synthetic R600a refrigerant:
Hydrocarbon refrigerants cannot be ‘retrofitted’ to the appliance
that has not been designed and approved to use that type of
refrigerant.
Ensure that the tubing of the refrigerant circuit is not damaged
during transportation and installation.
Leaking refrigerant may cause eye injuries or could ignite.
The room for installing the appliance must be at least 1m3per 8g
of refrigerant. The amount of refrigerant in the appliance can be
found on the rating plate attached to the appliance.
Risk of fire
If the refrigerant circuit should become damaged. Avoid
open flames and sources of ignition. Disconnect the appliance
from the mains power. Thoroughly ventilate the room in which
the appliance is situated for several minutes.
SAFETY INFORMATION
• The freezer is designed to operate on a single phase power
supply within a voltage range of 220~240V/50Hz.
• The refrigeration system contains refrigerant. Do not allow any
sharp objects to come in contact with the refrigerant system to
avoid damage to the refrigerant circuit.
• This product is for indoor use only.
• Do not place electrical items or cooking equipment nearby.
Keep away from substances which could cause ignition and ensure
good ventilation is always available.
• Do not place objects on top of the appliance which are magnetic,
heavy or filled with water.
• If the supply cord is damaged, it must be replaced by authorised
TECO service personal, service agent or similarly qualified persons
in order to avoid a hazard.
WARNING
WARNING

2
• Do not store flammable, explosive, volatile and highly corrosive
materials in the freezer. Containers with flammable gases or
liquids can leak at low temperature. There is a risk of explosion or
fire.
• Do not splash water on the appliance. It may cause
malfunction or electric shock.
• Do not place or operate any electrical appliance in the freezer.
• Always switch off and unplug the appliance before cleaning.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Safety of children
• Young children should be supervised to ensure that they do not
play with the appliance.
• Packing (e.g. wraps, polystyrene etc.) can be dangerous
for children. There is a risk of suffocation. Keep packaging
materials away from children.
• Contact your local authorities for correct method of disposal.
Dispose of all packaging in a responsible manner in accordance
with local regulations.
Dispose of old appliances in accordance with local regulations.
Remove the doors, cut off the main cable, break or remove spring
or bolt catches if fixed to prevent children trapped or involve
themselves in other dangers.
WARNING

NAME OF PARTS AND USAGE
1. Temperature Control
2. Freezer Drawer
3. Freezer Compartment Cover
4. Adjustable Foot
5. Glass Shelf
The freezer you purchased is subject to continuous improvement,
which may not be completely consistent with the manual, however the
functions and operating methods will not change.
If you use the freezer for the first time, remove any adhesive tapes.
Do not pull or push the covers, drawers and shelves forcefully during
use in case of damage.
3
1
3
2
2
2
3
5
4

PACKING LIST
Check the packing list that all items have been included.
Note: Product specifications are subject to change without prior notice.
4
Model TVF172WMPA
Freezer Drawer
Freezer
Compartment Cover
Glass Shelf
User manual
Warranty
Information
3 pieces
2 pieces
1 piece
1 Copy
1 Copy
Part No.
(see pg.3)
2
3
5

TRANSPORTING THE APPLIANCE
1.The appliance must be transported only in a vertical position. The
packing must be intact during the transportation.
2. When unpacking and re-packing the appliance, please memorise the
position of each accessory of the appliance when unpacking it. When
re-packing the appliance for transportation, ensure all accessories are
secured before transportation.
3. Do not lift or pull the door during transportation
INSTALLATION INSTRUCTIONS
1. When moving the appliance, do not tilt >45 degrees (the angle of the
vertical direction). Please avoid strong vibration and impacts that could
cause damage to the appliance.
2. The freezer should be located on a firm and flat surface. An uneven
surface may cause excess operating noise or vibration.
(a) The noise may be increased if the floor is not firm.
(b) If the appliance is to be positioned on carpet flooring and heat
emitted from the appliance is a concern, place a solid sheet
under the appliance.
3. Choose a location which is not exposed to sunlight, high
temperature or humid, as humidity may cause staining.
4. It is recommended a clearance of at least 50mm away
from objects and walls on both sides and back. Ensure the
clearance above the appliance is not less than 100mm and 160° clear for
the door to swing open.
5. If the appliance is unstable, rotating either of the
front two legs in a clockwise direction will raise the
appliance.
6. When adjusting the front legs, ensure the
appliance slopes backwards slightly for keeping the door closed.
7. Remove all internal packaging before operating.
100mm
50mm
50mm
5

6
REVERSING THE DOOR
To reverse the freezer door, ensure you have a phillips head screwdriver,
a flat blade screwdriver and an allen key that suit the screws required
to swap the hinge. Unplug the freezer and empty all contents before
proceeding.
Step 1. Remove the cover from the
hinge. Refer to Fig. 1.
Step 2. Use a phillips head screwdriver
to remove the 2 screws holding
the hinge in place. Support the
weight of the door while
removing the hinge.
Step 3. Lift the door off the bottom hinge
and place in a safe location to
prevent damage.
Step 4. Remove the hinge shaft sleeve
and door block from the bottom
and relocate it to the opposite
side of the door. Refer to Fig. 2.
Step 5. Take the hinge and undo the nut
holding the hinge pin. Relocate
to the opposite side and fix in
place. (Refer to Fig. 3).
Fig. 1
Fig. 2
Fig. 3
Hinge
cover
Hinge screws
Hinge
shaft
sleeve
Door
block

7
Step 6. Carefully tilt the freezer
back to access the bottom
hinge assembly. NOTE: Do
not tilt >45o. Using a phillips
head screwdriver, remove the
screws holding the hinge in
place. Unscrew the adjustable
foot from the opposite side.
(Refer to Fig. 4).
Step 7. Relocate the bottom hinge
to the opposite side and
secure in place using the
same screws from step 6.
NOTE: Do not tighten
screws completely until after
the door has been correctly
placed and the seal checked.
Screw the adjustable foot into the opposite side (Refer to Fig.5).
Step 8. Replace the screws that
previously held the hinge in
place from Step 1. Remove
the cover from the opposite
side and place over screws.
(Refer to Fig. 6).
Step 9. Remove the two screws now
exposed and install the top hinge (Refer to Fig. 7).
NOTE: Do not tighten the hinge screws completely until the door
has been aligned and seals
aligned.
Step 10. Place the door on the top and
bottom hinges, align making
sure the door gasket seals
correctly. Once aligned,
tighten the hinge screws.
Step 11. Replace the hinge cover.
Fig. 4
Adjustable
foot
Bottom
hinge
assembly
Fig. 5
Adjustable
foot
Bottom
hinge
assembly
Fig. 6
Top cover
Replace
screws
here
Fig. 7
Install
hinge here
Cover
installed
here

OPERATING INSTRUCTIONS
TEMPERATURE CONTROL
To adjust the temperature within the
freezer, locate the temperature control
located inside the freezer (refer to Page 3
- Item 1). The temperature of the freezer
can be controlled manually by adjusting
the thermostat dial. Observe the markings
when selecting a temperature.
MIN represents the minimum (warmest) temperature, MID represents a
medium temperature and MAX represents the maximum (coldest) setting.
The default setting is MID for normal operating conditions.
PLACEMENT OF FOOD
1. There should always be some space between
items inside for air circulation.
2. Food should be kept in sealed packaging to
avoid becoming dry or spoilt.
3. Hot food should be cooled down before placing
into the appliance. Otherwise, the interior
temperature and power consumption will increase.
4. Reduce opening the door frequently.
Keeping the door closed will increase the
appliance efficiency and reduce power consumption.
Do not use any electronic equipment inside the appliance.
Do not store objects which are costly or subject to temperature
variations. e.g. medication or chemicals.
ICE MAKING (Ice cube tray not included)
To make ice cubes, fill the ice tray with potable water
and place it in the freezer. To remove ice cubes
easily, run water on the tray before gently twisting and
inverting the tray.
WARNING
8

ENERGY SAVING TIPS
1. Adjust the temperature control to a setting that is acceptable for the
storage of the food. This will reduce the power consumption.
2. Only open the door when required. Frequently opening the door will
increase power consumption.
3. Maintain good air circulation within the freezer.
MAINTENANCE
The appliance should be maintained and cleaned frequently. For your
safety, pull the plug out of the socket before cleaning.
1.Interior and exterior maintenance
Clean the interior of the appliance with clean water and wipe it dry
with a piece of dry cloth.
Cleansers such as soap powder, abrasive cleaning powder, alkali
cleansers, chemical cloth, thinners, alcohol, acid petroleum products
and hot water should not be used to clean the freezer as they
may damage the painted cover and plastics.
2. Smearing can age the interior plastic components, so remove it as soon
as possible.
3. Wipe the door gasket clean, it is easy to damage the door gaskets if
polluted by stains, e.g. oil, sauce, etc.
4. Please check the points below after maintenance:
(1) Is there any damage or loss of the power lead?
(2) Can the power plug be inserted into the power socket correctly?
(3)Is the power plug and/or lead heating up?
Please remove the gasket from the door before disposing. The
disposed apparatus should be handled by professionals, as it
may be harmful to the environment. If disposal is necessary,
please contact your local authorities for correct method of
disposal. Dispose of all packaging in a responsible manner in
accordance with local council regulations.
9
CAUTION

DISCONNECTION OF THE APPLIANCE
If a power failure occurs, even in summer, the freezer could store food
normally for some time.
1. Power failure
During a power failure, do not put additional food in the appliance and
reduce opening the door frequently.
Place several ice cubes into each freezer drawer if power failure is
anticipated beforehand, and place it in the top of the freezer.
2. Power failure during vacation
Before departure of short vacation, remove any items that could spoil if a
power failure occurs. Ensure the door is closed firmly.
If going on a long vacation, remove all items, defrost the appliance,
clean and wipe dry the internal of the appliance, prior to disconnecting
the power and leave the door open.
3. Storage of appliance
If the freezer will be stopped for a long period of time (storage),
remove all items, defrost the appliance, clean and wipe dry the internal
of the appliance, unplug the appliance from the power outlet. The door
should be kept open in order to prevent unpleasant odours.
After unplugging the appliance from the power outlet,
please leave at least 5 minutes before reconnection.
TROUBLESHOOTING
The following cases are not malfunctions:
1. Moisture may form as condensation on the outside of the appliance
during humid conditions. To remove excess moisture, wipe clean.
2. The flow of refrigerant through the pipeline coil could cause gurgling,
similar to water boiling. This is the normal function of the appliance.
3. It is normal that the sides of the appliance will get warm as a result of
the refrigeration system operation.
4. Do not place objects on top of the appliance which are magnetic,
heavy, or filled with water.
5. The appliance operation could cause electrical interference to electrical
equipment. 10
WARNING

SYMPTOM: The freezer does not work.
SUGGESTION: It may not be connected to the power supply (plug, power
failure or blown fuse) and switched on. Check that the temperature dial is
not set to 0 position.
SYMPTOM: The freezer does not work efficiently as expected.
SUGGESTION: It may be caused by heavy frost on the ice box
compartment, by a warm temperature setting or by frequently opening the
door, or low voltage.
SYMPTOM: It makes an unusual noise.
SUGGESTION: It may be caused by an unbalanced appliance or unstable
surface, vibration from an object on top of, behind or beside the appliance.
SYMPTOM: The compressor keeps working for a long period.
SUGGESTION: The environment temperature may be too high. The doors
may be opened frequently or even left open. The temperature control knob
setting position may increase the working time of the compressor. Large
amounts of warm food recently placed in the appliance.
SYMPTOM: Unpleasant odours.
SUGGESTION: Interior may need cleaning. Some foods produce strong
odours, some containers can also cause odours. Food should be packed
tightly before being put inside the appliance. Please check whether there
is any spoilt items left in the appliance.
SYMPTOM: Freezer temperature is too cold.
SUGGESTION: Check the temperature control setting (refer to page 8).
11

REPAIRS, SERVICE & WARRANTY
It is hazardous for anyone installing, removing, altering, repairing,
servicing, testing or certifying the gas system of a gas device (i.e.
charging, discharging or breaking into the refrigeration system that uses
hydrocarbon refrigerants).
Only an Authorised Service Person can carry out servicing or repairs to
this appliance. In Queensland the authorised person must hold a Gas
Work Authorisation for hydrocarbon refrigerants, before carrying out
servicing or repairs which involve the removal of covers.
IF SERVICE IS REQUIRED
If you have a problem, and the problem persists after you have made the checks
mentioned in the Troubleshooting section of this manual, contact:
TECO Australia Service on 1300 660 037 (9am to 4pm AEST Mon to Fri)
For warranty details please visit www.teco.com.au
Complete and retain the following information:
Name of retailer: _________________________________
Date of purchase: ________________________________
Model No. : _____________________________________
Serial No. : _____________________________________
MFG code: _____________________________________
Please retain proof of purchase for warranty claims.
12

SPECIFICATIONS
13
Model TVF172WMPA
Climate class T
Classification of
installation and use Class 1 Indoor use only
Rated Total Gross
Volume (L) 172
Voltage (V) 220~240
Frequency (Hz) 50
Noise Level (dB) 42
Refrigerant type R600a
Dimensions
(mm)
Height
Width
Depth
1420
550
550
Net Weight (Kg) 44
Max. Ambient
Operating temp (oC) 43

www.teco.com.au
LBE-PV
