Teknion Sanna Lightbar Operating and maintenance instructions

E
A
NOTE 1: For further information on
optimizing the Cerebro assets, please refer
to the Teknion Navigate User Guide .
B
C
D
D
NOTE 2: Do NOT remove Bumper Strip
from Light Head util AFTER the Light is
fully assembled
A -Lightbar x1
B - Stem x1
C - Cable Clips x1
Top Clamp
D - Desk Edge Clamp x1
Bottom Clamp
E - Bumper Strip x1
Sanna Lightbar Desk Edge Mount (YLSC) Part and Product Identification
A - Part name
part number + quantity
Section:
Description: Page No:
Date:
Rev. No: 01
Sanna Lightbar - Desk Edge Mount for IC (YLSC)
Cerebro
Sep 2019 1 of 5
COM_603b
complements Installation Guides

D
D
D
STEP 2: Place the Desk Edge Clamp at desired location of the Worksurface.STEP 1: Slide the Bottom Edge Clamp onto the Top Edge Clamp. Undo the Clamping Knob
to make room for desk edge.
Section:
Description: Page No:
Date:
SSEMBLE DESK EDGE CLAMP MOUNTING ON DESK EDGE
DIS_603b
2 of 5
Sep 2019
Electrics for IC
Cerebro
complements Installation Guides

D
D
NOTE: Avoid over tightening
as it could damage the table.
B
B
C
D
C
DNOTE: Ensure Orange
Ring is Fully Covered
by Stem.
Orange ring
STEP 4: Install Stem onto the Desk Edge Clamp by turning it clock-wise. Slide Cable Clip into
the Stem.
STEP 3: Secure Desk Edge Clamp by turning the Clamping Knob. It is recommended to turn
the knob maximum one and a half turn after the clamp feels secure.
NOTE: Avoid over tightening as it could damage the table.
Section:
Description: Page No:
Date:
SECURE DESK EDGE LAMP INSTALL STEM
DIS_603b
3 of 5
Sep 2019
Electrics for IC
Cerebro
complements Installation Guides

ENOTE: Open Lightbar
as shown
A
NOTE: Press GENTLY
onto the Lightbar.
Remove Bumper
Strip[E] after Lightbar is
installed.
C
C
STEP 6: Insert the Cable into the Cable Clips.STEP 5: Open the Lightbar to the side. Install Lightbar to the Stem by pressing GENTLY as
shown above.
NOTE: Remove Bumper Strip[E] after Lightbar is installed.
Section:
Description: Page No:
Date:
INSTALL LIGHTBAR CABLE MANAGEMENT
DIS_603b
4 of 5
Sep 2019
Electrics for IC
Cerebro
complements Installation Guides

A
A - US and Canada
1. Slide Plug into Power Supply
2. Align Connector/Power Supply
locking features
3. Insert Connector
Power
Lock
Supply
4. Turn Connector 90 degrees to
lock
5. To remove plug, slide plug out
Connector Lock
Section:
Description: Page No:
Date:
POWER SUPPLY INFORMATION
Sep 2019 5 of 5
DIS_603b
Electrics for IC
Cerebro
complements Installation Guides
STEP 7: Insert Connector Lock into the Power Lock Supply then turn it counter clock wise to lock it in place.
