Teknoline TQ-7000 User manual
TQ-7000 HD DVB-T/C QAM
RECEIVER
USER'S MANUAL
IMPORTANT SAFETY PRECAUTIONS
READ THE FOLLOWING WARNINGS BEFORE USING YOUR DEVICE
WARNING
The following safety precautions must be observed.
Avoid fire or electric shock hazard. Security measures include, but are not limited to.
Power supply / Mains cable
•Operate the unit only within the voltage range properly defined by the device.
•Occasionally check the power connector and remove any dirt or dust.
•Use only the mains cable that came with your unit.
•Do not use a split or damaged power cord, unit orplug.
•Do not place the mains cable near heatingappliances.
•Make sure the device is plugged into a properly grounded outlet. Inadequate grounding may
result in electric shock.
•Always carefully remove all plugs by pulling on the plug, not thecord.
•Make sure the unit's power switch is off before unplugging thecord.
•Unplug the mains cable when the unit is not used for a long time.
•Do not connect the unit to a multi-plug to prevent the plug fromoverheating.
Installation / Storage
•This unit contains high precision electronics. To ensure optimum performance and prevent
damage, do not store in any place where dirt, ducts, lint can collect, etc. Do not expose to
extreme heat or cold (eg in direct sunlight, near a heater or in a car during the day). Place
the unit in a safe place to prevent falls.
•Before moving the unit, always disconnect all cables first.
•When installing the unit, make sure that the outlet is easily accessible. In case of
malfunction, turn off the unit and unplug the power cord. Make sure the mains cable is
disconnected for a long time to use when not in the unit.
•Always turn off and unplug all devices before connecting the unit to other electronicdevices.
•Do not spill liquid on the unit. Do not use any diluents or volatile liquids forcleaning.
•Do not insert your finger into the openings in yourunit..
•Never put paper, metal pieces or other objects into the openings of your unit. If you suspect
there are foreign parts in your unit, turn it off and unplug the mains. Contact the
manufacturer's technical support department.
Login
•You now have a high-quality, professional receiver broadcast centre. Please read carefully to
get the most out of your purchase.
Description
•Receive video signal from ANTENNA sources and broadcast from VGA or HDMIoutput.
GENERAL FEATURES
•Fully compatible with DVB-T/C digital standard.
•HEVC / H.264 / MPEG-4 / AVS High Definition Digital TV
•MPEG-2 High Definition and Standard Resolution Output
•MPEG-1/2 Layer I / II / III
•DVB-T/C Signal input
•On-screen Electronic Program Guide (EPG)
•Supports Auto search and Manual search
•Parental control for channels
•Plug and Play setup with easy to use Menu System
•Supports 480p, 576p, 720p, 1080i/p Video Resolution
•Supports 4:3 and 16:9 Aspect Ratio
•DVB or EBU subtitle selected by the system according to network
availability
•Various channel editing function (Favorites, Move, Lock, Delete)
•Software update via USB2.0 interface
•USB 2.0 interface PVR and media player
•Record digital television program to an external USB portable hard disk and
play it via USB2.0
GENERAL SETTINGS
By pressing the MENU button on the remote control, the settings section is accessed.
1. CHANNEL LIST
2. Language
3. AV SETTINGS
4.TIME
5.SYSTEM
6.MEDIA CENTER
7. NETWORK
“RALINK RT-5370” wifi antenna is required for Wi-Fi connection
.
8.CHANNELS SEARCH
9.CHANNEL SEARCH SETTING
The device receives DVB-T/C broadcasts.
DVB/T
Manual Decode The frequencies in the device memory are being searched.
Broadcast search frequency in the range of 177500 KHz -860000 KHz
DVB/C
It automatically decodes calls between 114-858 MHz.
MANUEL SEARCH
Manual decode is for searching the desired frequency individually.
FULL DECODE
You can automatically search for the frequency range you have specified.
decode the frequency range.
11.CHANNEL EDITING
Editing is done according to the color options on the channel editing screen.
12. ADDING DEVICES TO THE SMART CONTROLLER
First, press the SET button.
Release the button when the red LED light intensity changes.
Press the button you want to add (Shutdown, AV/TV, Vol-, Vol+).
Then press the button of the remote you want to add (Shutdown, AV/TV, Vol-, Vol+).
Finally, it is memorized by pressing the SET button again.
The same operations are repeated for the other keys.
