teko Astra-Z-3245 User manual

Astra-Z-3245
Wireless Remote Control Key Fob
Operation Manual
Figure 1
This operation manual is intended for studying the operating
principles, proper use, storage, and maintenance of the
Wireless remote control key fob Astra-Z-3245 (hereinafter
referred to as key fob) (Figure 1).
The manufacturer reserves the right to make alteration
regarding refinement of the product without prior notification. All
improvements are included in new revision of the operation
manual.
List of Abbreviations:
Astra-Zitadel System: Astra-Zitadel on-site wireless intrusion /
fire detection and alarm system;
Control panel: Astra-Z-812M / Astra-8945 version A control
panel;
KF: key fob;
MSS: Astra-Z monitoring software suite.
1 Purpose
1.1 The key fob is intended for wireless
transmitting of alarm notifications and
identifiable reports for arming / disarming, etc.
to the control panel of the Astra-Zitadel
system.
1.2 Power is supplied to the key fob from a
CR2430 type battery, voltage 3,0 V (included
in delivery package).
2 Specification
Technical Parameters of Radio Channel
Operating frequency range, MHz ......................2 400 to 2 483,5
Number of operating channels at 5 MHz intervals...................16
Channel width, MHz ..................................................................2
Wireless coverage range:
Line-of-sight, m, min..............................................................100
Emission power, mWt, max.....................................................10
General Technical Parameters
Current consumption, mA, max:
- with radio module OFF.....................................................0,005
- with radio module ON............................................................45
Battery replacement
indication threshold, V............................................................2,3
Power supply voltage, V.......................................from 2,1 to 3,0
Power supply voltage lower threshold
(operability threshold), V.........................................................1,8
Overall dimensions, mm, max ...............................7432,513,5
Weight, kg, max....................................................................0,04
Battery average operating lifetime
with double pressing per day, years, min ..................................2
Operating Conditions
Temperature range, °C........................................from -20 to +50
Relative air humidity, %..................................up to 95 at +35 °C
without moisture condensation
3 Package Contents
Astra-Z-3245 .....................................................................1 pcs.
CR2430 Battery................................................................. 1 pcs.
Operation Manual............................................................. 1 copy
4 Structure
Figure 2
The keyfob consists of a cover (front side) and base (Figure 2).
Mounted in the cover are printed circuit board with radio
elements (hereinafter PCB) and buttons. The base is affixed to
the cover with a screw.
Mounted on PCB is the LED for Astra-3245 operability
supervision.
5 Information Capacity
Table 1: Notifications processed by LED and Control Panel (or
MSS interface)
Notification
Type
LED
Control
Panel
Standby
Mode start
Lights up once for 1 to 20
seconds after powering up
−
Alarm
Lights up for 1 second when
pressing the «Alarm»button
+
Arming
Lights up for 1 second when
pressing the «Arm»button
+
Disarming
Lights up for 1 second when
pressing the «Disarm»
button
+
LSA activation
Lights up for 1 second when
pressing the «Service»
button
+
Power failure
Triple blink while pressing a
button
+
Network search
Blinks with frequency of 5Hz
during 1 to 60 seconds
+
Command
delivered
Turns on one time for 0,1
second within 10 seconds
after pressing any button
upon notification handshake
from control panel
−
Command not
delivered
Double blink in a 10 seconds
after pressing any button if
wireless network is not found
or there is no handshake
from control panel
−
+: notification issued; –: notification not issued
Notes
1. If «Power failure» notification appears, change the battery within
three weeks.
2. When pressing the service button «*»on the key fob (which is registered
in the system and has user rights for arming / disarming), light and sound
alerter Astra-2345 switches ON to indicate status of partitions, which it is
assigned to, by light alerting.

Revision 3245-v2_4_en
2
6 Pre-starting Procedure
6.1 After transportation in conditions differing from those of
operation, key fob must be kept unpacked for 4 hours in the
expected operating conditions.
6.2 Registering the key fob in the Wireless Network
Key fob registration procedure is required for identification in
the wireless network in which it is supposed to operate.
6.2.1 Registering the key fob in Astra-Z-812M control panel
Step-1
Place the key fob on the
working place and
disassemble:
- Remove the screw;
- Insert a screwdriver into
the groove on the key fob
housing and separate the
base from the cover.
- Remove the base.
Step-2
Insert the battery; the
LED lights up for 1 to 20
seconds.
After the LED turns OFF,
the key fob switches to
registration mode for 60
seconds.
Step-3
During the delay time (60 seconds), initiate Wireless
component registration mode on the control panel by the
method described in the appropriate Astra-Zitadel system
Operation manual* or Quick Start Guide*, and press any
two buttons at the same time (except for «Service»
button) on the key fob.
The key fob switches to wireless network search mode for
no more than 60 seconds, the LED blinks at a frequency of
5 Hz.
Step-4
Verify registration by the control panel indication:
Once registration procedure completed successfully,
the control panel screen displays «KFxxx registered»
notification.
Assemble the detector:
- Replace the base.
- Tighten the screw.
In case registration procedure failed, the control panel
screen displays «Registration time expired» notification.
In this case, repeat the registration procedure, i.e. perform
steps 2 –4.
Step-5
If necessary, assign to the key fob user rights for arming /
disarming by the method described in the appropriate
Astra-Zitadel Quick Start Guide*.
Step-6
After successful registration of the key fob, for long term
storage before its installation, it is allowed to switch the key
fob OFF by removing the battery.
When power is supplied, there is no need to re-register the key
fob in the same wireless network if it was not intentionally
removed from the network through Astra-Z-812 control panel.
6.2.2 Registering the key fob in Astra-Z-8945 control panel
Step-1
Set Astra-Z MSS on PC according to method described in
Astra-Zitadel system based on Astra-Z-8945 ver.A control
panel Operating manual* or Quick Start Guide*. Run Setup
module. Choose Wireless network / List of wireless
devices menu item.
Step-2
Insert the battery (see p.6.2.1, steps 1, 2); the LED lights up
for 1 to 20 seconds.
After the LED turns OFF, the key fob switches to registration
mode for 60 seconds.
Step-3
During the delay time (60 seconds) in Wireless network / List
of wireless devices menu item right click any empty row and
choose Register wireless devices command from pop-up
menu and press any two buttons at the same time (except
for «Service»button) on the key fob.
The key fob switches to wireless network search mode for no
more than 60 seconds, and the LED blinks at a frequency of 5
Hz.
1 Make sure the registration procedure is completed
according to the procedure described in the Astra-Zitadel
system Operating manual* or Quick Start Guide*:
Once registration procedure completed successfully,
«KF»appears in selected row.
In case registration procedure failed repeat registration
procedure.
2 If necessary, assign to the key fob user rights for arming /
disarming by the method described in the appropriate Astra-
Zitadel Quick Start Guide*.
Step-4
After successful registration of the key fob, for long term
storage before its installation, it is allowed to switch the key fob
OFF by removing the battery.
When power is supplied, there is no need to re-register the key
fob in the same wireless network if it was not intentionally
removed from the network through Astra-Z MSS.
7 Labeling
The following information is marked on the label attached to the key
fob housing:
- abbreviated key fob designation;
- firmware version;
- month and year (last two digits) of manufacture;
- conformity mark (if certificate is available);
- bar-code that duplicates textual information.

Revision 3245-v2_4_en
3
8 EC Conformity Declarations
This product is in conformity with the provisions of:
R&TTE Directive 1999/5/EC, Article 10.5;
EN 60950: 2001 Safety of information technology equipment;
EN 50371 Generic standard to demonstrate the compliance of low-
power electronic and electrical apparatuses with the basic restrictions
related to human exposure to electromagnetic fields (10 MHz - 300
GHz) –General public;
EN 301489-17 V1.1.1 (09-2000) Electromagnetic Compatibility and
radio spectrum Matters (ERM); Electromagnetic Compatibility (EMC)
standard for radio equipment and services; Part 17: Specific condi-
tions for wideband data Hiperlan equipment;
EN 300220-1 V1.3.1 (2000-09) Electromagnetic compatibility and
Radio spectrum Matters (ERM); Short range devices; Technical char-
acteristics and test methods for radio equipment to be used in the 25
MHz to 1 000 MHz frequency range with power levels ranging up to
500 mWt; Part 1: Parameters intended for regulatory purposes.
Construction of the detector provides for protection class IP41.
9 Recycling
9.1 The key fob is not a danger to life, human health and the
environment. On expiry of its lifetime recycling is done without taking
special measures to protect the environment.
9.2 Recycling of battery cells must be done by delivering used cells to
a trading organization, service centre, manufacturer, or to another
organization accepting used batteries.
10 Warranty Terms
10.1 The manufacturer guarantees the compliance of the siren to
specifications on condition that user observes required conditions of
transportation, storage, installation and operation.
10.2 The storage warranty period is 1 year and 6 months from the
date of manufacture.
10.3 The operating warranty period is 1 year from the date of
commissioning, but not more than 1 year and 6 months from the date
of manufacture.
10.4 The manufacturer guarantees replacement or repair of the
product during the warranty period.
10.5 The warranty doesn’t come into effect in the following
cases:
- not adherence to the operating manual;
- mechanical damage to the device
- repair of the device by any third-party service apart from the
Manufacturer
10.6 The warranty applies to the key fob only. Any third-party
equipment from other manufacturers used in conjunction with the key
fob, including batteries, is subject to its own warranty terms.
The manufacturer bears no responsibility for death, injury,
property damage or other incidental or premeditated loss based
on user's statement that the device failed to implement its
functions.
* Available for free downloading from www.controlex.eu
Sales:
Controlex GmbH
Warranty service and
technical support:
ТЕКО-TD
Philosophenweg 31-33
47051 Duisburg, Germany
Phone: +49 (0) 203 / 393 91 188
Fax: +49 (0) 203 / 393 91 189
GSM: +49 (0) 178 / 218 48 22
E-mail: [e-mail]
Web: www.controlex.eu
Prospect Pobedy str. 19
420138 Kazan, Russia
Phone: [phone]
Fax: [phone]
E-mail: [e-mail]
[e-mail]
Web: www.teko.biz
Made in Russia
