English fiCONS 05/00
Components of the appliance (differ, depending on model /type)
4
5
6
7
8
11
12
12
12
1
2
3
9
10
13
All drawings are for illustration only. The equipment of your appliance can
differ from that in the above and following drawings.
Lamp: E14/ 240V~, 50Hz, Max. 15W
On some models the lamp cover is open
at the front, enabling the lamp to be changed
without removing the cover.
51
1
2
Remove lamp by unscrewing
(counterclockwise)
Press bulb cover in the direction
indicated by the arrows 1
Pull out sideways
1
2
To remove bulb cover
*Ventilation grille
*Worktop/Cover
Butter/Cheese Compartment
Interior light
* and thermostat knob
Shelf
Defrost drainage channel
* Glass / plexiglass shelf
Salad drawer/s
Door tray
Bottle rack
Ice cube- / Freeze drawer for fruts
Freezer/Storage Compartment
Door seal
