Telio obihai User manual
Quick Start
Guide
Box content
Telio-adapter
Power Adapter
Ethernet Cable
Telephone Cable
LED icons and behaviour
Icon Light behaviour What it means
Off The adapter is not receiving power.
Solid green The adapter is operational.
Flashing green The adapter is looking for an IP address.
Flashing orange The adapter is upgrading. Do not unplug power!
Solid red The adapter is non-operational.
Flashing green Light flashes when there is data activity on the
Internet Ethernet port.
Flashing green Light flashes when there is data activity on the
LAN Ethernet port.
Off The port is not enabled.
Solid green The phone is ready to be used.
Flashing green The phone is in use.
Rapidly flashing green The phone is ringing.
Connection ports on the Telio Adapter
Phone 1 – Telephone port (for main line)
Phone 2 – Telephone port (for secondary
line or fax machine)
USB – Port for wireless network via USB
dongle or external storage devices
Internet – Port for Internet
modem or router
Power – Power jack
LAN – Computer port
How to connect
A: If your Internet setup looks like this…
...please follow these instructions:
1. Find the cable that connects your PC and your modem. Unplug the cable from the
modem and connect it to the yellow LAN port on your adapter.
2. Connect one end of the Ethernet cable (included in the box) to the blue Internet
port on the adapter, and the other end to an Ethernet port your modem (the same port
that you unplugged in step 1).
3. Unplug the telephone cable currently connected to your telephone. Pick up the
telephone cable included in the box, and use this to connect your phone to the green
Phone-1 port on the adapter.
4. Connect the Power adapter to the black Power jack on the adapter, and plug it into
a power outlet.
1
2
3
4
1
B: If your Internet setup looks like this…
...please follow these instructions:
1. Connect one end of Ethernet cable included in the box to the blue Internet port on
the adapter, and the other end to an available Ethernet port on your router.
2. Unplug the telephone cable currently connected to your telephone. Pick up the
telephone cable included in the box, and use this to connect your phone to the green
Phone-1 port on the adapter.
3. Connect the Power adapter to the black Power jack on the adapter, and plug it into
a power outlet.
3
1
2
C: If your Internet setup looks like this…
...please follow these instructions:
1. Connect one end of the Ethernet cable included in the box to the blue Internet
port on the adapter, and the other end to an available Ethernet port on your router.
2. Unplug the telephone cable currently connected to your telephone. Pick up the
telephone cable included in the box, and use this to connect your phone to the green
Phone-1 port on the adapter.
3. Connect the Power adapter to the black Power jack on the adapter, and plug it into
a power outlet.
3
1
2
What to do if it does not work:
Please note: Once you have connected, it may take up to
ten minutes before your phone is ready to be used. The
phone is ready when the LED icon for the Phone-1 port is
solid green. If you are using both lines, both the Phone LED
icons should be solid green.
• Make sure all cables are properly connected
• Turn modem, router, and Telio adapter o and then on again.
• Check the light behaviour of the LED icons on the Telio adapter.
If you are still unable to make it work,
please visit www.telio.ch, or contact Customer Services.
Telio Customer Service
NO: 02101
DK: 70807025
NO: kundeservice@telio.no
DK: kundeservice@tellio.dk
www.telio.no
www.tellio.dk
