Tellur TLL331111 User manual

WiFi Smart Solar Camera
User guide

Product description
Indicator Light
Infrared Light
Lens
PIR Detection
Light Sensor
Solar Panels
Name Description
Solar Panels
Infrared Light
Light Sensor
Pickup Device
PIR Detection
Lens
When the sun is strong, that can charge the device
battery.
When the ambient light is not enough, enable the
infrared light to increase the brightness of the
environment.
Used to collect ambient brightness values, when the
illumination is lower than 2Lux, enable the infrared
light.
Collect ambient sounds and implement voice intercom.
When the human body moves in front of the device,
it can generate a trigger signal to the mobile phone.
Capture image video.
Red light flashes slowly: the system waits in the WiFi
configuration.
The blue light is slow: the system is in normal working
condition.
Red and blue flashing alternately: system WiFi
connection failed
TF Card
USB Interface
Battery Switch
Reset Key
Speaker
Bracket
mounting
Name Description
Reset Key The device in the working status, then press and hold
for 5 seconds to restore the factory settings.
Micro SD slot Install Micro SD card to support local recording
Battery Switch Turn off and turn on the device battery by turning on
the key
USB Interface Charge the device battery through the USB interface
Bracket mounting Mounting on the wall using the accessory bracket
Speaker Issue system prompts and implement voice intercom
Note: You need to detach the bottom silicone to see the function
interface as shown.

Installation
Operate as shown, using mounting
screwsInstall the bracket and
adjust the angle to make the
PIR Enough to detect people .
Installation Notes
Installation: 1. The human body induction effective distance is 3 5-
meters, so please adjust the monitoring angle
according to the actual situation.
2. Please avoid the installation position where the
temperature changes too much, such as heat
source, airoutlet, etc. it will cause false alarm of
equipment.
Alarm adjustment: The device default setting triggers the alarm
immediately. If you need to adjust the sensitivity,
please go to the device settings page.
Solar panels: Please ensure that the sun is fully exposed.
Connect
Download the Tellur Smart App for both iOS and Android OS.
Scan the QR code to download Tellur Smart App
Android
IOS
·Support
Download App(IOS&android)

• Once App is installed on your device and you have added your smart
device to your app you will be able to control it.
Adding a New Device
• Turn on power of device being paired and make
sure light is flashing quickly.
• Open App and Click “+” to add appropriatedevice.
• Select WiFi network and input password of WiFi
then.
• Once connected the App will prompt the
connection, then you can rename the device or
just click “done”.
QR Code Configuration
Getting started
1. Please follow the instructions and make sure the passwords
are inputed correctly.
2. One device can only be added with one App account, if the device
has been added with another account already, then it can
' t be
added to any another account again.
3.The device will be unbind from previous account after been deleted
from App. Further ,the device will be resetted automattically once
from blue light to red light

20 30cm
Process
Step 1.
Open the Tellur Smart App,
click "+" or "Add Device".
Step 2.
Select "Smart Camera".
Power the device on and make
sure the indicator is flashing
quickly or a prompt tone is heard.
Step 3. Input WiFi passwords and click "Confirm", scan the QR Code
with a device. (You can change the network connection)

Technical Specification
Sensor type: 1/4'' CMOS
Sensor resolution:1.3 Megapixels
Lens: F:1.4 f:2.8mm
View angle 143°
Inflared sensor:Yes, up to 10 meters
Image resolution: HD 960P 1280*960
Video compresion:H.264
Bit rate: 32Kbps~2Mbps
Frame rate: 1~25/second
Internal storage: MicroSD card (up to 32GB)
Night vision: Yes
Motion detection: Yes
Audio comunication: Two-way audio
Waterproof IP65
WiFi standard: IEEE 802.11b/g/n
Supported WiFi network: 2.4GHz
Battery: 3.7V, 6400mAh Li-ion Rechargable
Dimensions: 210*75*89MM
Weight: 480g
Product description: WiFi Smart Outdoor Solar Camera
Brand: Tellur
Product code: TLL331111
RED – 2014/53/EU
Applied standards:
EMC: ETSI EN 301 489-1 V2.2.0
ETSI EN 301 489-17 V3.2.0
Radio: ETSI EN 300 328 V2.1.1 (2016-11)
ETSI EN 300 220-1 v2.4.1
ETSI EN 300 220-2 v2.4.1
Health: EN 62479:2010
Safety: EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013
RoHS – 2011/65/EU
Place and date: Bucuresti, 20-06-2019
Signature:
The product bears CE mark, applied in 2019
We, ABN SYSTEMS INTERNATIONAL S.R.L., Bucharest, Sector 1,
Marinarilor street, nr. 31, we declare on own responsibility that the
product below:
It does not endanger life, health, work safety, does not have a negative
impact on the environment and corresponds to the standards stated
in the manufacturer's declaration of conformity. The product is in
compliance with the following standards and / or other normative
documents:
Declaration of conformity
Name: George Barbu
Function: Director General
