TEMEISHENG A6-4B User manual
Mobile Speaker
A6-4B
Operating Instructions
Please carefully read the operating instruction before using our product
Common simple faults and guidance for operation and repair
The power switch is turned on
The speaker is out of battery
Audio input is not correctly selected.
The audio cable is not connected properly
to the line input.
Main volume is switched to minimum.
No sound when playing U-disk.
No sound when playing by line input
Poor contact or damage of external audio
cable
Change the audio input by pressing the
mode button.
Reconnect the audio cable.
Properly adjust the volume knob.
Check the U-disk or the mode switch button.
Change the audio source of line input.
Readjust or change audio cable.
External microphone is not fully inserted
in the jack
The external microphone switch is not
turned on
The volume knob of microphone is off
Totally insert the microphone to the jack
Turn on the switch of wireless microphone
Properly adjust the volume knob of
microphone
The switch of wireless microphone is not
turned on
The wireless microphone is not Installed
with batteries
The sound of wireless microphone is in
distortion
External
microphone has
no sound
Turn on the power switch
Use power adaptor to charge the battery
Turn on the switch of wireless microphone
Install the batteries in the wireless
microphone
Change the battery of wireless microphone
Problems with
wireless
microphone
Speaker not power on
No sound
Fault description Possible causes Troubleshooting
If the above solution did not solve the issue, please contact the nearest local maintenance department. The
product technology of our company is upgraded continuously, the product descriptions in this manual are
subject to change without notice.
Panel/rear plate/MP3 function and operation
LINE IN
MIC IN
ECHOMIC.VOL
TF CARD
USB
17 1
16
2
15
3
14
4
13
5
12
6
11
7
10
8
9
.- Connection port of TF memory cards.
15.- LINE IN: Line level auxiliary input.
17.- POWER: On/Off switch of the portable amplifier.
14.- Connection port of USB storage devices.
16.- DC INPUT: Connection terminals for DC 12V.
10.- CHAR: The indicator will glow when the speaker is charging.
11.- VOLUME: General volume control.
3.- : Set the loop mode of the songs to repeat one or repeat all.
12.- ECHO: Decrease or enhance the echo effect.
8.- DC IN 9 V: Power input for the supplied power adapter.
13.- MIC VOL: Volume control for the handheld wireless microphone and MIC IN micro input.
2.- : Long press to start recording; short press playback the recording files. Recording function
only works when the U-disk is inserted.
4.- : Play the previous song.
6.- : Play the next song.
5.- : Start and pause in playback.
7.- Information screen
9.- MIC IN: Micro level input, 6.3 mm jack connector.
1.- : Allows you to select between different audio sources: USB storage device, SD
memory card, Line input or Bluetooth receiver.
- FULL: This indicator will glow when the battery is fully charged.
To customers:
Respectable users,
Thank you for your support and trust on purchasing the products of our company. To fully exert the function of the
product, we suggest you to read the operating instruction carefully before using it, for the convenience of grasping the
connection method and using points. Please take care of the operating instruction after reading it for the purpose of
further reference.
Product features
●Ultra-low distortion amplifying circuit
●Digital karaoke, treble and bass
independent adjustment
●Built-in MP3 encoding supporting
U disk
●Unique acoustic appearance design
●Professional treble and bass gain
controlling circuit
●Built-in battery for outdoor activities
●Built-in professional wireless
microphone system
●Professional high-effective
loud-speaking unit
●Compatible to DVD/VCD/PC
and other sound sources
●Suitable for adaptor and charging
●Intelligent power switch charging
circuit
Attention
The product has been installed with battery, making it applicable to the outdoor singing, advertisement, recreation and
other activities. Please charge the battery before using it outdoors, so as to guarantee that the machine can be used
for a longer time outdoors. The machine has been set with power switch circuit. When you connect the adaptor to the
power and insert the plug to the charging interface, the machine will switch to the power supplied by the adaptor
automatically and charge the built-in battery. When the adaptor interrupts the power, the machine will intelligently
switch to the built-in battery for work continuously. When adaptor is used to charge the battery, the integrated
intelligent charging circuit within the machine will give hints about charging and the charging indicator lamp will light.
After charging is finished, the intelligent charging circuit will give hint to that that the charge has been fully charged and
light the charging indicator lamp. At this moment you can close the AC power of the adaptor. If you still use adaptor in
the machine to work, the charging circuit will automatically cut off the charging circuit and it is unnecessary for you to
worry about the charging breaking. You shall notice that the battery has certain service life and it is beyond the
warranty scope of the company. Under general circumstances, the built-in battery needs charging 8-10 hours. With
more charging times, the battery volume will change and full charging time will reduce accordingly. When the battery is
out of charge after being used for a short time, please change the built-in battery. The user shall also notice that if the
electricity quantity of the battery is reduced when using the machine outdoors, please close the power switch on the
rear plate and charge the built-in battery within 24hours. If the electricity quantity of battery is totally consumed, the
situation that the battery can not be charged and the service life is expired will happen. When you don't use the
machine for a long time and leave it alone, please charge the battery every six months, so as to avoid the invalidity of
battery.
Instruction of U disk MP3 encoding playing
When you need to use the built-in MP3 encoding function, please format your USD disk (U disk for short below) as FA-
T32 format in computer first and then copy the file in MP3 format in U disk. When reading U disk, the encoding system
will engage in encoding playing according to the generation sequence of MP3 songs file. Therefore, the song which is
copied to U disk first will be played in priority or vice versa. When the user needs to play according to the specific
sequence, they can arrange the copying sequence. If the files copied to U disk can not be played, please inspect
whether the file format is in MP3 format. If not, please switch to MP3 format in computer and then copy to U disk in
order to play normally. When copying MP3 file, you shall copy to the catalogue of U disk. It is suggested to delete all
the unnecessary files and file catalogues in order to reduce the occurrence of reading error when the encoding is
played. When the user buys U disk, please select the ones with better quality and internal encoding supporting
64MB/128MB/256MB/512MB/1GB/2GB/4GB/8GB and other volumes. During the playing process, please make it far
away from the places with high temperature, high magnetic field and high frequency interference. In case of crash,
please close the power and restart for recovery!
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or more of
the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved
by manufacturer could void your authority to operate this equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
The device has been evaluated to meet general RF exposure requirement. The device
can be used in portable exposure condition without restriction.
