Tepex MDS Series User manual

1
Doc. No.: TEPEx.RS.118
Ver: 1
Date: 01. 2020.
Kućište MDS-.
Housing MDS-.
Upute za uporabu
User manual
U P O Z O R E N J E !
Upute za uporabu sadrže osnovne informacije o proizvodu.
Montaža, instaliranje, uporaba i održavanje trebaju biti
izvedeni prema ovoj Uputi kako bi bio osiguran siguran rad
unutar nazivnih karakteristika. Ovu Uputu nadopunjuju
nacionalni Pravilnici i norme. Odgovorna osoba korisnika je
dužna osigurati njihovo provođenje. Neprovođenje može
umanjiti protueksplozijsku zaštitu uređaja i dovesti u
opasnost ljude, imovinu i okoliš. Svako neispravno i
nedozvoljeno postupanje kao i nepoštivanje odredbi ove
Upute isključuje svaku odgovornost proizvođača.
Prije ugradnje/puštanja u pogon:
- Pažljivo pročitati cijelu Uputu za uporabu,
- Izvršiti odgovarajuću obuku odgovornog osoblja,
- Provjeriti da je sadržaj ove Upute u potpunosti razumljiv
odgovornim osobama,
- Uvjeriti se da su primijenjeni svi zahtjevi nacionalnih Pravilnika i
posebne sigurnosne mjere ukoliko postoje.
U slučaju nejasnoća:
- Kontaktirati proizvođača.
Tijekom pogona:
- Osigurati da ove Upute za uporabu i druge radne upute korisnika
budu vidljivo istaknute i dostupne odgovornom osoblju cijelo
vrijeme,
W A R N I N G !
The user manual contains basic information about the
product. Mounting, installation, usage and maintenance
should be carried out under this user manual to provide and
ensure safe operation within the nominal characteristics.
This user manual complement national Regulation and
Standards. The responsible person shall ensure their
implementation. Failure off implement this user manual can
reduce explosion protection and endanger people, property
and the environment. Any improper and illegal actions as
well as non-compliance with the provisions of this user
manual excludes all responsibility by manufacturer side.
Before installation/commissioning:
- Carefully read all instructions,
- Execute proper training of responsible personnel,
- Check that the contents of these instructions is fully
understandable by the responsible personnel,
- Make sure that all the requirements and national Regulations
as well as all special security measures are applied.
In lack of understanding:
-Contact the manufacturer.
During operation:
- Ensure that this user manual and other work instructions are
available to the responsible staff at all times,
- Check the implementation of these instructions and all other
safety user’s instructions
Medarska 69, Zagreb, Croatia
XMade in Croatia
tel. [phone]
fax. [phone]
e-mail: [email protected]
web: www.tepex.hr
0722

2
- Provjeravati provođenje ove Upute i svih drugih sigurnosnih
uputa korisnika.
SADRŽAJ:
1. Namjena………………………………….……………………….
2. Stupanj zaštite………..……………………....………………
3. Tehnički podaci……………………….……………….………
4. Dimenzije………..……….……………………………………..
5. Tipna oznaka.………………….……………………………….
6. Pregled, održavanje, popravak i obnavljanje……
7. Odgovornosti i ovlaštenja……….………………………..
8. Skladištenje i transport….…………………………………
9. Jamstvo proizvođača………….…………………………….
10. Označavanje…………………………………………………….
2
2
2
3
3
4
4
4
4
5
CONTENTS:
1. Purpose……………………………………………………………….
2. Type of protection...……………………………….……………
3. Technical data.………………………………………………….…
4. Dimension....………………………………………………………..
5. Type………..…………………………………………………………..
6. Inspection, maintenance, repair and overhaul..……
7. Responsibility and authorization.………………………..
8. Storage and transport…………………………………………
9. Manufacturer's warranty.…………………………………….
10. Marking……..…………………………………………………………
2
2
2
3
3
4
4
4
4
5
1. NAMJENA
Protueksplozijski zaštićeno kućište tip MDS-. je prazno Ex db kućište
za fiksnu montažu u koje se ugrađuju niskonaponski sklopni aparati
i električni uređaji standardne industrijske izvedbe.
Kao cjelina čine protueksplozijski zaštićeni električni uređaj
namijenjen za uporabu u prostorima ugroženim eksplozivnim
atmosferama plinova, para i prašina u zonama opasnosti 1, 2, 21,
22 sukladno normama EN 60079-10-1 i EN 60079-10-2.
2. STUPANJ ZAŠTITE
Proizvod je sukladan Pravilniku o opremi i zaštitnim sustavima
namijenjen za uporabu u potencijalno eksplozivnim atmosferama,
NN br. 33/16.
Proizvod je razvijen, proizveden i ispitan prema postojećem
stanju tehnike, sukladno normama EN ISO 9001, EN ISO 80079-34
i EN ISO 14001.Proizvod je sukladan ATEX Direktivi 2014/34/EU i
normama:
-EN IEC 60079-0:2018,
-EN IEC 60079-7:2015/A1:2018,
-EN 60079-31:2014.
Proizvod je sukladan LVD Direktivi 2014/35/EU.
Proizvod je sukladan RoHS Direktivi 2011/65/EU.
Proizvod je sukladan EMC Direktivi 2014/30/EU.
Certifikat: FIDI 19 ATEX 0032
3. TEHNIČKI PODACI
Oznaka kategorije i
protueksplozijske
zaštite:
II 2G Ex db eb IIC T6 Gb
II 2D Ex tb IIIC T80°C Db
Mehanička zaštita:
IP 66
Otpornost na udar:
IK 10
Otpornost na udar:
I (PE - protective earthing)
Maksimalna struja:
16A
Maksimalna
instalirana snaga:
5W
Stezaljka za
unutarnje
uzemljenje:
Vijak M4x10 sa podložnom pločicom 4
Učvršćenje
ugradbene
komponente
u kućištu:
Vijčanim priborom na temeljnu ploču unutar
kućišta
Uvodi:
ISO 20 sukladno EN 62444 i NPT 1/2“ sukladno
ANSI/ASME B1.20.1
1. PURPOSE
Explosion protected housing MDS-. is an empty Ex db housing
intended for fixed mounting in which switchgear and electrical
apparatus of standard industrial usage are installed.
As a whole, they are an explosion-proof electrical device intended
for use in potentially explosive atmospheres of gases, vapors and
dusts in hazardous areas 1, 2, 21, 22 in accordance with EN 60079-
10-1 and EN 60079-10-2.
2. TYPE OF PROTECTION
The product has been developed, manufactured and tested
according to the existing state of technique, in accordance with
EN ISO 9001, EN ISO 80079-34 and EN ISO 14001. The product
complies with ATEX Directive 2014/34 / EU and with the
following standards:
- EN IEC 60079-0: 2018,
- EN IEC 60079-7: 2015 / A1: 2018,
- EN 60079-31: 2014.
The product complies with LVD Directive 2014/35 / EU.
The product complies with RoHS Directive 2011/65 / EU.
The product complies with EMC Directive 2014/30 / EU.
Certificate: FIDI 19 ATEX 0032
3. TECHNICAL DATA
Category and
explosion
protection:
II 2G Ex db eb IIC T6 Gb
II 2D Ex tb IIIC T80°C Db
Mechanical protection:
IP 66
Resistance to impact:
IK 10
Class of protection:
I (PE - protective earthing)
Maximal current:
16A
Maximal installed
power:
5W
Terminal for
internal grounding:
Screw M4x10 with washer plate 4
Mounting of the
components inside
housing:
With screw assembly on the base plate inside the
housing
Entry’s:
ISO 20 according to EN 62444 and NPT 1/2“
according to ANSI/ASME B1.20.1
Cable gland for
armored cables:
(Tamb ≥ -40°C)
ATEX certificated cable gland
II 2G Ex db IIC II 2D Ex tb IIIC
For armored cables Øv 7-20 mm and non-armored
cables Øv 7-16 mm
0722
0722

3
Uvodnica za
armirane kabele:
(Tamb ≥ -40°C)
ATEX certificirana uvodnica
II 2G Ex db IIC II 2D Ex tb IIIC
za armirane kabele Øv 7-20 mm i nearmirane kabele
Øv 7-16 mm
Moment pritezanja pritisne matice i tijela
uvodnice 12Nm
Čep
(Tamb ≥ -40°C):
ATEX certificirana čepa
II 2G Ex db IIC Gb
II 2D Ex tb IIIC Db
Moment pritezanja pritisne matice 2,5 Nm
Navoji:
M 120x 1,5 - 6H/6g, srednja tolerancija prema ISO
965-1/98, navoj DIN 13 T.24/83,
minimalno 10 punih navoja
M 20 x 1,5 - 6H/6g, srednja tolerancija prema ISO
965-1/98, navoj ISO 965-3/98 ,
minimalno 8 punih navoja
Boja:
siva, RAL 7001
Montaža na
podlogu:
preko nosača za fiksnu montažu
Masa praznog
kućišta bez
uvodnica:
cca 2,1 kg (bez adaptera i/ili uvodnica)
Tightening torque of the pressure nut and the
body of the cable gland is 12Nm
Plug
(Tamb ≥ -40°C):
ATEX certificated plug
II 2G Ex db IIC Gb
II 2D Ex tb IIIC Db
Tightening torque of the pressure nut is 2,5 Nm
Color:
gray, RAL 7001
Mounting:
using lamp carrier for fixed mounting
Mass of empty
housing without
cable glands or
adapter
cca 2,1 kg (without adapter and/or cable gland)
4. DIMENZIJE
4. DIMENSIONS
5. TIPNA OZNAKA
5. TYPE
MDS-.
-osnovna tipna oznaka
-tip uvoda
-1 –ADP 21/1 [Ex db eb]
-2 –ISO20x1,5 [Ex db]
-3 –NPT 1/2" [Ex db]
6. PREGLED, ODRŽAVANJE, POPRAVAK, OBNAVLJANJE
6. INSPECTION, MAINTENANCE, REPAIR AND OVERHAUL
Potrebno je obavljati preglede i održavati sve dijelove uređaja o
kojima ovisi protueksplozijska zaštita sukladno EN 60079-17,
općim i posebnim uputama proizvođača i Pravilnicima korisnika,
a naročito:
-da su kućište, poklopac, okvir stakla i brtve poklopca te okvira
stakla bez puknuća i oštećenja,
-da su uvodnice, adapter i čepovi pritegnuti s nazivnim
momentom.
Popravak, obnavljanje ili pregradnju kućišta obavlja proizvođač ili
od proizvođača ovlaštena pravna osoba, originalnim dijelovima
prema proizvodnoj dokumentaciji, a sve sukladno normi
EN 60079-19.
Inspections are carried out in accordance with EN 60079-17, general
and special conditions of manufacturer and users Regulations and
includes supervision of parts on which the explosion protection
depends, especially:
-that the housing, cover, glass frame and gasket of cover and glass
frame are without rupture and damage,
-that the cable glands, adapters and plugs are fastened with
nominal torque.
All the repairs are performed by the manufacturer or the
manufacturer's authorized personal and the original parts must be
provided according to the product documentation, all in accordance
with EN 60079-19.
Ø218±2
105±2

4
Ukoliko popravak i/ili obnavljanje i/ili pregradnju vrši treća osoba,
prestaje svaka odgovornost proizvođača za proizvod, a izjava
sukladnosti proizvođača postaje nevažeća.
If repair or any other procedure are performed on the product by
unauthorized person, all producer responsibility for the product and
the warranty and the manufacturer's declaration of conformity
becomes invalid.
7. ODGOVORNOSTI I OVLAŠTENJA
Ova Uputa predstavlja najvažniju informaciju o proizvodu.
Nadopunjuju ju odgovarajući nacionalni zakoni i propisi.
Proizvodnja, uporaba, certifikacija i nadzor određene su na
nacionalnoj razini:
a) Pravilnikom o opremi i zaštitnim sustavima namijenjenim
za uporabu u prostorima ugroženim eksplozivnom
atmosferom (NN br. 33/16, odnosno EU Direktiva
ATEX 2014/34/EU) i
b) Pravilnikom o najmanjim zahtjevima sigurnosti i zaštite
zdravlja radnika te tehničkom nadgledanju postrojenja,
opreme, instalacija i uređaja u prostorima ugroženim
eksplozivnom atmosferom (NN br. 39/06, 106/07.),
odnosno EU Direktivi 1999/92/EC (ATEX 137).
Odgovorna osoba dužna je osigurati njihovo provođenje u
pogonu.
8. RESPONSIBILITY AND AUTHORIZATION
This instruction is the basic information about the product. It is
completed by the corresponding national laws and regulations.
Production, use, certification and supervision are determined at
the national level:
a) Regulations concerning equipment and protective systems
intended for use in potentially explosive atmospheres EU
directive 2014/34/EU and
b) Regulations on minimum requirements for safety and health
protection of workers and technical inspection of facilities,
equipment, installations and equipment in hazardous areas EU
directive 1999/92/EC (ATEX 137).
The responsible person shall ensure their implementation at the
working facility.
8. SKLADIŠTENJE I TRANSPORT
Transport i skladištenje treba vršiti samo u originalnoj ambalaži, na
način istaknut na kartonskoj kutiji.
8. STORAGE AND TRANSPORT
Transportation and warehousing of the lamps is only allowed in the
original packaging, as outlined in a cardboard box.
9. JAMSTVO PROIZVOĐAČA
Proizvođač daje jamstvo na proizvod u trajanju od godine dana
prema odredbama Zakona o obveznim odnosima. Ova izjava ima
snagu Jamstvenog lista.
9. MANUFACTURER'S WARRANTY
The manufacturer provides a warranty on the product for a period
of one year under the provisions of this user manual and the law on
obligations. This statement has the force of Warranty sheet.
10. OZNAČAVANJE
MDS … označena je natpisnom pločicom na poklopcu te natpisnom
naljepnicom unutar kučišta.
10. MARKING
MDS is marked with a marking plate on the cover of the housing
and a marking label inside the housing.
Natpisna pločica i pločica upozorenja / Marking plate and warning plate
Natpisna naljepnica sa tehničkim podacima/ Marking label with technical data
FIDI 20 ATEX 0032 P - DAT -
II 2D Ex tb IIIC T80°C Db
MDS-. 16A max. 5W max.
-40°C/-20°C<Ta<+40°C IP66
II 2G Ex db eb IIC T6 Gb
xMedarska 69, Zagreb, Croatia
Made in Croatia
0722
WARNING
DO NOT OPEN WHEN
ENERGIZED
SEE INSTALLATION INSTRUCTION
DOCUMENT
FIDI 20 ATEX 0032 P - DAT -
II 2D Ex tb IIIC T80°C Db
MDS-. 16A max. 5W max.
-40°C/-20°C<Ta<+40°C IP66
II 2G Ex db eb IIC T6 Gb
xMedarska 69, Zagreb, Croatia
Made in Croatia
0722
