Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail: [email protected]
Model #: SUPT20KX
3-Breaker Parallel Tie Cabinet (for SU20KX 3-Phase UPS)
Highlights
3 breaker parallel tie cabinet accessory for two Tripp Lite 3 phase UPS
systems
Enables dual-UPS redundancy or links the output of two UPS systems
for double-capacity
3 built-in circuit breakers, heavy duty copper buswork
Compatible with Tripp Lite SU20KX 3 phase UPS systems
Description
Tripp Lite's parallel tie cabinet provides a means for safely paralleling two UPS systems for either redundancy or additional capacity. Redundant
configuration provides fault-tolerance to maintain network operations during failure of one UPS. Non-redundant configuration combines the output of
two UPS systems to support twice the output current. Two input breakers receive incoming pwoer from the UPS and are connected to heavy duty
copper buswork and an output breaker rated for the total UPS capacity of the two UPS systems combined. See downloads section for Tripp Lite
3-Breaker Parallel Tie Cabinet detailed specifications, dimensional drawings, operational flow charts and technical description of each included
component.
Compatible with two Tripp Lite SU20KX UPS systems.
Specifications
OVERVIEW
Model Type Tie Cabinets
INPUT
Voltage compatibility (VAC) 380; 400; 415
PHYSICAL
Shipping weight (lbs) 95
Shipping weight (kg) 43.1
Unit Dimensions (HWD/in) 24.6 x 24.1 x 9
Unit Dimensions (HWD/cm) 62.5 x 61.2 x 22.9
Shipping Dimensions
(HWD/in)
24.87 x 9.75 x 25.35
Shipping Dimensions
(HWD/cm)
63.2 x 24.8 x 64.4
Unit weight (lbs) 90
Unit weight (kg) 40.9
Form factors supported Wallmount
WARRANTY
Product Warranty Period
(Worldwide)
2-year limited warranty
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=4158.
Copyright © 2012 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous
improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
