Terra Bound Solutions 581-706 User manual

581-706 5” OD Arch Post Swing 8’ 6 Seat
IMPORTANT
PLEASE READ THESE INSTRUCTIONS BEFORE COMMENCING ASSEMBLY. All equipment
must be installed in accordance with these instructions. Check your shipment
against Bill of Lading and Parts list. Any missing or broken parts must be
reported to your distributor within 10 days of receipt of your order. When
properly installed and maintained, equipment will give many years of Safe,
Trouble-Free use. Periodically check for loose or broken parts. Loose bolts
must be tightened and broken parts must be replaced as they can possibly
create dangerous situations leading to unnecessary accidents. Resilient
Surfacing should be used under all playground equipment. Appropriate
publications, available at no charge, from the Consumer Product Safety
Commission, include “A Handbook for Public Playground Safety”. You can
receive your free copy by calling 1-301-504-7908.
PACKING LIST HARDWARE BAG
1 CTN Hardware Bag 12 585-521 3 ½” Swing Hanger
3 PIPE 583-211 3 ½” Top Rail 6 585-955 Cut Proof Belt Seat
2 WF 583-573 Center Arch Posts 12 317-140 4/0 Chain 5’6”
2 WF 583-572 End Arch Posts 24 585-901 S Hook
12 196-802 ½” x ½” Socket Set Screw
1 416-400 ¼” Socket Key
1 805-532 Warning Label
1 805-534 SportsPlay Label
1 Maintenance Checklist
1 CTN 3 PIPE 4 WF TOTAL PCS= 1 SKID 1019 # WT Class 70

581-706 5” OD Arch Post Swing 8’ 6 Seat
GENERAL FOOTING RECOMMENDATIONS
Diameter and depth of footings illustrated are satisfactory in most
applications for pipe sizes up to 2 3/8” diameter. Varying soil & climatic
conditions may require deeper and heavier footings in some areas. Check
local building codes.
Detail: Detail:
Permanent Installation Suggested Bracing Method
IF RESILIENT SURFACING IS TO BE LESS THAN 12”, THEN ADDITIONAL PIPE SHOULD BE
PUT IN CONCRETE TO MAINTAIN PROPER FINISH GRADE FOR EQUIPMENT.
USE AREA AND FOOTING LAYOUT:

581-706 5” OD Arch Post Swing 8’ 6 Seat
Single Axis Swings:
The Use/Fall Zone should extend to the front & rear, a minimum distance of
twice the height of the Top Rail above the resilient surfacing material. The
Use/Fall Zone to the sides should follow the general recommendations of six
feet minimum. This six-foot zone may overlap that of an adjacent swing
structure.
Rotating Swings:
The Use/Fall Zone should extend in all directions the length of the swing
plus six feet. The six-foot minimum fall zone from the supporting structure
also applies, and may overlap the six-foot zone of an adjacent swing
structure.
GENERAL MAINTENANCE INSTRUCTIONS:
Check MONTHLY for loose bolts, damaged or broken parts. Tighten and/or
replace immediately. On swings and any equipment that uses S-hooks and/or
Swing Hangers check the bearing surfaces for wear. Replace any parts that
show a reduction of 25% from the original size.
ASSEMBLY AND INSTALLATION:
NOTE: All threaded ends of bolts protruding beyond nuts must be cut off
and/or peened to eliminate sharp edges. No more than two threads
should extend beyond face of nut. All tubing must be hammered down to
conform to the curved underlying surface to eliminate catch points. DO
NOT tighten nuts more than hand-tight until entire assembly is
completed.
STEP #1: Assemble swing frame on side, on ground. If more than one section,
assemble section by section. Layout parts so that when frame is
erected, legs will be in approximately correct position.

581-706 5” OD Arch Post Swing 8’ 6 Seat
STEP #2: Remove swing hanger pendulums from the swing hanger assemblies. Using
S-hooks, attach seats to chain and chain to swing hanger pendulums.
Close the S-hooks to within .034” (1/32”) using S-hook pliers.
STEP #3: Assemble top portion of swing hangers on top rail following spacing on
page 1 diagram.
STEP #4:
Footing holes may be marked out and dug from footing layout, however,
it is easier to position swing in proper location, mark holes, move
swing aside, and dig holes.
STEP #5: Stand swing upright onto legs and brace in footing holes so that 2’ –
3’ of pipe will be under intended level of resilient surfacing and top
rail is at desired height.
STEP #6: Plumb and level entire unit. Tighten set screws by using short length
of pipe on end of socket key to add leverage. Pour concrete. Crown
surface. Wait 48 hours before removing braces and using equipment.
STEP #7: Attach assembled seats to swing hangers by reattaching the pendulums to
the swing hangers. Do not over tighten bolt on pendulum. Hangers must
move freely.
STEP #8: Attach warning label and Manufacturer’s Identification label to a clean
surface. The labels should be attached in a location where they are
clearly visible and legible and away from normal hand and foot
placement areas. The labels must be replaced if they become illegible,
destroyed or removed. Contact your SportsPlay distributor for
replacements.
