Component Playgrounds CP-PS24-8x10 User manual

Dear Customer:
Thank you for purchasing your equipment from Component Playgrounds. We are proud of our products
and we are confident that you will enjoy your equipment for many years.
NOTE! In order for bolt length guide included on the parts identification page to be correct, you may have
to remove the scaling when printing. To do this, click "print", then under "page scaling" select "none".
Then proceed to print.
Your product is being shipped to you on a common carrier truck line and will be brought directly to your
home. All shipments are delivered to curbside only. The receiver is responsible to unload the
merchandise from the truck and should make arrangements to have someone help unload upon delivery.
Included below are some guidelines that should be followed when receiving your shipment.
1. Confirm that the number of pieces being delivered matches with the number of pieces originally
shipped.
2. Your equipment may arrive on a pallet. If so, please verify with the packing list that all pieces
have arrived. If there are any pieces missing, note this directly on to the delivery receipt
before you sign. Some pieces, such as club house supports, may be shipped separate
from the pallet.
3. Pay careful attention to the condition of the product when it arrives. If there are parts that
have been damaged, note these problems on the delivery receipt before you sign and
accept delivery of the product.
4. Open packaging of slides, glider seats, etc. to inspect for concealed damage.
5. If your shipment appears to have damage and/or missing pieces, a claim must be filed with
the freight company within two business days. Component Playgrounds will assist you
with this process. Contact the Shipping Manager Toll Free @ 877-530-0222 for claims
assistance.
6. Ask your driver to sign or initial the freight slip acknowledging any damage or
discrepancies.
7. Get a copy of the delivery receipt from your delivery driver before he leaves.
All shortages and damaged items are the sole responsibility of the carrier. You are responsible to
notify Component Playgrounds of any shortages or damage relating to your shipment within 2
business days of receipt of your equipment. After this time, any claim for shortage or loss cannot be
honored.
Component Playgrounds cannot be responsible for replacement of any parts missing or damaged
that have not been properly noted on the delivery receipt. Component playgrounds cannot be
responsible for damaged or missing pieces due to the fault of, or loss by the freight company.
We appreciate your business, and look forward to serving you in the future.
Sincerely,
The entire team at Component Playgrounds

Quantity
Description
1
Box Containing Swing Set Parts
2
2 3/8” x 10’ Top rail
2
1 - 4” x 12’ Vertical Post with Socket
1 –4” x 14’ Vertical Post with Socket
1
4” x 14’ Vertical Post
with Two Sockets for
Multi-level Swing
Sets
6
TOTAL PIECES
Parts Identification
CP-PS24-8x10 Swing Set

Installation Instructions
Model CP-PS24-8x10
Upright Post Sleeve to Top Rail Assembly
3/8” x 3/8”
Set Screws
(4 per sleeve)
3/8” x 3/8”
Set Screws
(4 per sleeve)
Commercial
Play Space:
34’ x 40’
30”
20”
24”
20”
30”
30”
20”
24”
20”
30”
8’
9’
Dig holes 24” in diameter
x 36” in depth. (Approx.
7 80 lb bags of concrete
in each hole)
Dig holes 24” in diameter
x 36” in depth. (Approx. 7
80 lb bags of concrete in
each hole)
36”
36”
20’ Clearance
20’ Clearance
6’ Perimeter
6’

128”
Hole size is 24”
diameter by
36” deep.
Measure 2” from the end of
the top rail to find the center
of the post hole.
2”
2”
Marking your holes
1. Loosen and remove the top two nyloc jam nuts.
2. Reassemble on to swing top rail with the carriage
bolt on top and the nyloc nut on the bottom (Or
carriage on bottom and nut on top if it won’t fit
the other way. Tighten securely so that the hanger
is firmly attached in pace and cannot slide or
swivel along top rail.
3. Attach chain through security clevis and tighten
using provided Clevis Key.

1.c. Next have three adults stand on opposite ends and stand structure up into the holes that you have
dug.
#1
#2
#3
1.b. Assemble the 2 top rails to the post ends. Slide top rail into the sleeves on the post ends and
secure using 3/8” set screws provided. (4 set screws per end)

1.d. Place a level on the top rails and make the necessary adjustments to get set level.
LEVEL
LEVEL
LEVEL
1.e. After the top rails are level, line up the posts and level them out. Then check top rails one more
time.
LEVEL
LEVEL
LEVEL
LEVEL
LEVEL

Generally Required Tools and Supplies
Wheelbarrow
Shovel
Digging Bar or Pick
Level
Marker Pen
Ladder
Tape Measure
¾” Open end, box wrench or socket with ratchet
Cordless or Electric Drill w/clutch
*Before digging, please obey local laws by notifying your local utilities marking
organization.*
Any modifications to these dimensions will be specifically shown on the individual item
installation page.
All posts and pipe are prepared with enough length to accommodate 12" deep impact
attenuating ground cover. Component Playgrounds recommends that 12" of impact
attenuating surfacing be placed under and around the playground and any adjacent
structures. Playground equipment should not be installed over hard surfaces such
as concrete, asphalt or grass.
If the specifications on your project call for less ground cover, you may simply cut the
pipe to the desired length or you may dig the holes deeper. Please refer to the ASTM
Designation: F 1487 - 05 Standard Safety Performance Specification for Playground
Equipment for Public Use, or you may also refer to the CPSC guidelines for public and
commercial playgrounds for more information regarding surfacing requirements.

Safety and Clearance Guidelines
For more information regarding public playground safety and your responsibilities as the
purchaser, owner, manager or installer of this equipment, please contact the US Consumer
Product Safety Commission (CPSC) and obtain the newest version of the Handbook for Public
Playground Safety. This handbook is available by visiting www.cpsc.gov, or by calling
Component Playgrounds at 1-877-530-0222.
The entire area under and around the playground must be covered with some form of impact
attenuating ground cover. The surfacing selected must have a critical fall height rating value of
at least the highest designated play surface on the equipment. The critical fall height rating of
the selected material must be in accordance with
A.S.T.M. Standard F1292. You may order A.S.T.M. Standard F1292, Standard specification for
impact attenuation of surface systems under and around playground equipment, by contacting
the American Society for testing and Materials (A.S.T.M.). by calling 610-832-9585, or by
visiting their web site at www.astm.org.
• Component Playgrounds recommends that a minimum of 12" of proper impact
attenuating surfacing be installed prior to opening the playground for use by children.
• Component Playgrounds also recommends that a regular maintenance program be
implemented.
• We also recommend that the equipment be regularly and properly maintained and that
the ground cover remains at the recommended depth and the area is kept clean from
debris or other items that may present a safety hazard.
Clearance guidelines are important to help reduce the risk of congestion on the playground and
to reduce the risk of accidental impact with adjacent structures, other children or the edge of the
playground pit. Please refer to the CPSC Handbook for Public Playground Safety for more detail
of the safety guidelines.
• There should be a minimum fall zone surrounding the structure of no less than 6'.
• Slides must have a use zone from the exit of the chute equal to the deck height that the
slide is mounted from. This distance must be no less than 6' and does not need to
exceed 14'. The use zones for slides must not overlap the use zone of another
component.
• Swings have a use zone that extends to the front and rear of the top rail pivot point a
minimum distance of twice the height of the top rail. This measurement is made from the
pivot point to the level of the protective surfacing. The swings also require a minimum
distance of 6' from the sides of the structure.
• Multi-axis swings have a use zone that extends 360 degrees from the pivot point for a
minimum distance of 6' plus the length of the suspending members.
• Most other components on the structure will require a minimum 6' clearance from the
edge of the pit, edging or adjacent use zones.
• We recommend that parts or individual playground components not approved or
manufactured by Component Playgrounds, should not be attached or added to the
playground.

Supervision Guidelines
Playgrounds that are designed, installed and properly maintained in accordance with the safety
guidelines and standards can still present hazards to children in the absence of adequate adult
supervision. Component Playgrounds recommends the following guidelines for supervision of
children while the playground is in use.
• Children should not use this equipment without adult supervision.
• Children should be directed to age appropriate activities. Not all equipment is
appropriate for all children who may use the playground.
• Pre-school children require more direct supervision than older children.
• Do not permit the use of wet, icy, or snowy equipment as slips, falls or loss of grip may
occur.
• Constantly observe the children while at play. Note play patterns and possible
hazardous play or overcrowding. Take immediate steps to stop hazardous play or to
control overcrowding.
• Children should not be allowed to jump off equipment when dismounting, as it is a
dangerous practice to jump on or off playground equipment.
• Children should not wear loose clothing, hoods, bicycle or other helmets, drawstrings,
or jewelry while using the playground equipment. These and other loose items not listed
could present a strangulation or entanglement hazard.
• Children should not use playground equipment bare footed and should be required to
wear shoes and socks at all times while using the playground equipment.

Read Before Use
Congratulations! You have just purchased one of the finest pieces of playground equipment available.
Your family will enjoy many hours of fun with this fine equipment. Playground equipment can be most
enjoyable, but there are some dangers if not used properly. You should be aware of the following:
Equipment should be installed in a level area, free from obstructions, with enough space to allow for
adequate clearance in all directions when equipment is in maximum use.
Keep objects away from equipment that could interfere with persons using it or that could be hazardous.
Misuse or abuse of this playground equipment is dangerous and can cause serious injury.
This equipment should be inspected before each use and any worn, defective or missing parts should be
replaced.
Children should play on equipment only with adult supervision and should be duly warned of the
potential hazards in this type of equipment when used improperly. Children should be instructed as to
proper caution to take in its use.
Equipment should NOT be used when it is wet or icy.
Equipment should only be used in a well-lighted area.
Do NOT use equipment when tired, under stress or emotionally upset.
Do NOT overcrowd.
Do NOT use equipment when under the influence of alcohol or drugs.
Do NOT attempt somersaults or gymnastic stunts on or using this equipment.
Know your own limitations and exercise caution at all times.
Do not jump off of equipment when dismounting. It is a dangerous practice to jump on or off equipment.
Do not attempt to use equipment for something other than the use for which it was designed and intended,
or in a manner other than that for which it was designed and intended.
While every attempt is made by Component Playgrounds to ensure the highest degree of
safety in all of our equipment, we cannot guarantee freedom from injury. The user
assumes all risk of injury due to use. All merchandise is sold on this condition, which no
representative of the company can waive or change.
