TerraWave M35100O10006 User manual

TerraWave Solutions®3400-3600 MHz 10 dBi Omnidirectional Antenna with N-Style Jack Connector
TerraWave’s 3400-3600 MHz 10 dBi Omnidirectional antenna is designed for outdoor WiMAX network
applications. The antenna features high gain and is constructed of fiberglass for durability. The antenna is
easy to install and includes a mast mount and integrated N-Style Jack connector. All TerraWave antennas
are covered by the Company’s two-year TerraNet warranty program. For questions and to purchase product,
contact a wireless networking solutions sales engineer at 210-375-8482, 800-851-4965 or
[email protected]. Visit www.terrawave.com for additional information.
Specifications
Model M35100O10006
Frequency Range 3400 ~ 3600 MHz
Downtilt 6°
Gain 10 dBi
Vertical Beamwidth 6.5°
Horizontal Beamwidth 360°
VSWR ≤1.5
Nominal Impedance 50 Ohms
Polarization Vertical
Max Power 200 Watts
Connector N-Style Jack (F)
Dimensions 35.82” x 0.79”
Lightning Protection DC Grounded
Weight 1.15 lbs
Mounting Style Mast Mount
Operating Temperature -40° to 140° F
Mast Mount Diameter .75” to 1.43”
Rated Wind Velocity 134 mph
E-Plane H-Plane
www.terrawave.com Email: [e-mail] Phone: [phone] Fax: [phone] Gulfdale, San Antonio, TX 78216

TerraWave Solutions®3400-3600 MHz 10 dBi Omnidirectional Antenna with N-Style Jack Connector
Installation Information for M35100O10006
www.terrawave.com Email: [e-mail] Phone: [phone] Fax: [phone] Gulfdale, San Antonio, TX 78216
Antenna cap
Joint sheath
Pressure plate
Clamp
Cable
Installation Instructions:
1. Assemble the antenna by placing the antenna’s joint sheath between the pressure plate and clamp using a
wrench.
2. Install this antenna assembly vertically to the mounting pole. Please note that it is not recommended to install the
antenna on a pole with a diameter other than specified.
3. It is recommended to wrap the connector with weather-proof adhesive tape after connecting to the device or
cable assembly.
Other Recommendations:
1. Do not attempt to carry out the antenna installation during inclement weather.
2. Make sure the antenna is installed in a safe and suitable location that is clear from any power lines.
3. Do not attempt to install the antenna on a pole of a diameter other than specified.
