TERSO TS074 User manual

EDOC00052 –Large ULT RFID Refrigerator User Manual, rev 0 1
Large UHF
RFID
Refrigerator
Terso Solutions, Inc.
5540 Research Park Drive
Madison, WI 53711
USA

EDOC00052 –Large ULT RFID Refrigerator User Manual, rev 0 2
Table of Contents
Introduction ........................................................................................... 3
Precautions for Safe Operation.................................................................. 3
Cautions for Usage .................................................................................. 7
Environmental Conditions......................................................................... 7
Components ........................................................................................... 8
Installation ............................................................................................. 9
Operating Instructions ........................................................................... 12
Maintenance ......................................................................................... 14
Troubleshooting .................................................................................... 14
Disposal ............................................................................................... 14
Specifications ....................................................................................... 15
Model Specifics ..................................................................................... 15
Safety Check List .................................................................................. 16

EDOC00052 –Large ULT RFID Refrigerator User Manual, rev 0 3
Introduction
Read this manual carefully before using the refrigerator and follow the
instructions for safe operation.
Terso Solutions does not guarantee safe operation if the refrigerator is
not used as intended as outlined in this manual.
Keep this manual in an easily accessible place to refer to as necessary.
The contents of this manual are subject to change without notice due to
improvement in performance or functions.
Contact Terso Technical Support if a page of the manual is lost or page order is
incorrect.
Contact Terso Technical Support if any point in this manual is unclear or if
there are any inaccuracies.
Precautions for Safe Operation
It is imperative that the user complies with this manual as it contains important
safety advice.
Items and procedures are described so that you can use this refrigerator
correctly and safely. If the precautions advised are followed, this will prevent
possible injury to the user and any other person.
Precautions are illustrated in the following way:
WARNING
Failure to observe WARNING signs could result in a hazard to
personnel possibly resulting in serious injury or death
CAUTION
Failure to observe CAUTION signs could result in injury to
personnel and damage to the refrigerator and associated property

EDOC00052 –Large ULT RFID Refrigerator User Manual, rev 0 4
Symbol shows:
This symbol means an action is prohibited.
●This symbol means an instruction must be followed.
Be sure to keep this manual in a place accessible to users of this
refrigerator.
Caution, read all accompanying documents before operating the
device.
This mark is labeled on the cover in which the electrical components
of high voltage are enclosed to prevent electrical shock.
The cover should be removed by qualified engineers or service
personnel only.
This mark indicates the location of the protective earth conductor.
Do not disconnect. Disconnection of the protective earth conductor
may impair the protection provided by the device.
WARNING
●
Risk of shock is present inside the device. The cover should be
removed by qualified engineers or service personnel only.
Do not use the refrigerator outdoors. Current leakage or electric
shock may result if refrigerator is exposed to rain water.
●
Be sure to install the refrigerator on a sturdy floor. If the floor is
not strong enough or the installation site is not adequate, injury may
result from the refrigerator falling or tipping over.
Never install the refrigerator in a flammable or volatile location.
This may cause explosion or fire.
Never install the refrigerator where acid or corrosive gases are
present as current leakage or electrical shock may result due to
corrosion.
●
Make sure a dedicated power source is used as indicated on the
rating label attached to the refrigerator.
●
Make sure to remove dust from the power supply plug before
inserting in a power source. A dusty plug or improper insertion may
pose a hazard.

EDOC00052 –Large ULT RFID Refrigerator User Manual, rev 0 5
WARNING
●
Use a power supply outlet with ground (earth) to prevent electric
shock. If the power supply outlet is not grounded, it will be necessary
to have qualified engineers install a ground.
●
When removing the plug from the power supply outlet, grip the
power supply plug, not the cord. Pulling the cord may result in
electric shock or fire by short circuit.
Never damage or break the power supply plug or cord. Do not
use the supply plug if its cord is loose. This may cause fire or
electric shock.
Do not touch any electrical parts such as power supply plug or
any switches with a wet hand. This may cause electric shock.
Never ground the refrigerator through a gas pipe, water main,
telephone line or lightening rod. Such grounding may cause electric
shock in the case of an incomplete circuit.
Do not insert metal objects such as a pin or wire into any
outlet, vent or gap for inner air circulation. This may cause electric
shock.
●
If this refrigerator is to be used for storing poisons, radioactive
material or other harmful products, ensure that it is in a safe
area. Failure to do so may lead to an adverse effect on the health of
personnel in the area and local environment. In this case, a request for
repair or maintenance will necessitate a safety check sheet for
maintenance personnel and that the unit is clearly labeled to show
such materials.
Never splash water directly onto the refrigerator as this may
cause electric shock or short circuit.
Never disassemble, repair, or modify this refrigerator yourself.
Any such work carried out by an unauthorized person may result in fire
or injury due to a malfunction.
●
Disconnect the power supply plug if there is something wrong
with the refrigerator. Continued abnormal operation may cause
electric shock or fire.
●
If the refrigerator is to be stored unused in an unsupervised area for an
extended period of time, ensure that children do not have access
and that doors cannot be closed completely.

EDOC00052 –Large ULT RFID Refrigerator User Manual, rev 0 6
WARNING
●
Make sure to prepare a safety check sheet when you request any
repair or maintenance for the safety of service personnel.
●
Select a level and sturdy floor for installation. This precaution will
prevent the refrigerator from tipping. Improper installation may result
in injury from the refrigerator tipping over.
CAUTION
Do not disconnect the protective earth conductor. Disconnection
may impair the protection provided by the device.
Do not place any switches or disconnect devices in the earth
conductor.
Do not touch any stock, especially metal objects, in the
refrigerator with a bare hand. This may cause frostbite.
Do not climb onto the refrigerator. This may cause injury by tipping
or damage to the refrigerator.
●
Always hold the handle when closing the door. This will reduce the
likelihood of a trapped finger.
Do not lean on the door. This may cause injury if the refrigerator tips
over.
●
Always disconnect the power supply plug before moving the
refrigerator. Take care not to damage the power cord. A damaged
cord may cause electric shock or fire.
●
Be careful not to tip over the refrigerator during movement to
prevent damage or injury.
●
Always disconnect the power plug when the refrigerator is not used
for long periods of time.
●
Always disconnect the power supply to the refrigerator prior to
any repair or maintenance of the refrigerator in order to prevent
electric shock or injury.

EDOC00052 –Large ULT RFID Refrigerator User Manual, rev 0 7
Cautions for Usage
1. Always use gloves when handling items within the refrigerator.
2. Never store corrosive materials such as acid or alkali unless the
container is completely sealed up. Corrosion may lead to failure of the
refrigerator in time.
3. Always close the door firmly. The door open buzzer will sound after the
door is open for five minutes unless configured otherwise. The buzzer
can be canceled automatically when the door is closed.
4. Always open and close the door gently. Rough operation may lead to
stored items falling down, incomplete closing, or damage of the door
and/or locking mechanism.
5. Items should be added to the refrigerator in small batches to minimize
temperature increase.
6. If condensation forms on the door or frame surface, wipe it off with a
dry soft cloth.
Environmental Conditions
This equipment is designed to be safe at least under the following conditions:
1. Indoor use
2. 2000m / 6550ft altitude
3. 5° C to 40° C / 41° F to 104° F, ≤80% relative humidity
4. Over Voltage Category II
5. Pollution Degree 2 (normal office conditions)
6. Peak operating noise level of 60 dB

EDOC00052 –Large ULT RFID Refrigerator User Manual, rev 0 8
Components
Back Panel
1. AC On/Off Switch
2. WAN Ethernet Jack
3. Reset Button
4. Bypass Button
5. Buzzer Mute Switch
6. Alarm Contacts
Refrigerator Front
1. LCD Screen
2. Proximity Badge
Reader
3. USB Interface
4. Unit Control Panel:
Temp Settings +
Control, Light Switch
(refer to refrigerator
manual)
1
4
2
3
2
5
4
3
1
6

EDOC00052 –Large ULT RFID Refrigerator User Manual, rev 0 9
Installation
Site
To operate this refrigerator properly and to obtain maximum performance,
install the refrigerator in a location with the following conditions:
A location with correct power outlets
The refrigerator requires a dedicated grounded 120V 20A NEMA 5-20
outlet.
A location with a sturdy and level floor
Install the refrigerator on a sturdy floor to ensure proper door alignment
WARNING
Be sure to install the refrigerator on a sturdy floor. If the floor is
not strong enough or the installation site is not adequate, this may
result in injury from the refrigerator falling or tipping over.
CAUTION
Select a level and sturdy floor for installation. This precaution will
prevent the refrigerator from tipping.
A location not prone to high humidity
WARNING
Do not use the refrigerator outdoors. Current leakage or electric
shock may result if the refrigerator is exposed to rain water.
Never install the refrigerator in a humid place or a place where it
is likely to be splashed by water. This may result in current leakage
or electric shock.
Do not install the refrigerator under water pipes or steam pipes.
This may result in current leakage or electric shock.
A location without a flammable or corrosive gas
WARNING
Never install the refrigerator in a flammable or volatile location.
This may cause explosion or fire.
Never install the refrigerator where acid or corrosive gases are
present as current leakage or electric shock may result due to
corrosion.

EDOC00052 –Large ULT RFID Refrigerator User Manual, rev 0 10
Installation
Inspection
With packaging in place, inspect the refrigerator for any damage that may have
occurred during transit. If any damage is present, please contact Terso
Technical Support at [phone] in the US or [phone] in
Europe.
Unpacking
Remove the straps and remove all packaging. Gently position the
refrigerator in place on the ground.
Remove accessories from inside the refrigerator. Items included
are a Power Cable and Ethernet Cable. Other items may also be
included such as an Ethernet Hub or other refrigerator specific items.
Proper Handling
Move the refrigerator to the installation site. There are wheels on the
refrigerator to aid in positioning. Roll the refrigerator by firmly pushing on the
middle section of the body. Always move the refrigerator with the door facing
you. Carefully roll the refrigerator into position leaving at least a 6”gap
between the refrigerator and the wall.
Connecting AC Power
Plug the refrigerator into a grounded wall outlet with a minimum of a 8A rating.
The power outlet must be within 3m / 6ft of the refrigerator and must be easily
accessible unobstructed outlet. Ensure that the on/off switch is easily
accessible.
In an emergency, the cord can act as an off switch.
Connecting Communications
Plug the Ethernet cable into the back panel and then into the appropriate wall
data jack or cellular router.
Access Verification
Present a pass below the LCD screen on the front panel. The LCD text should
indicate that the door is now unlocked. The door can be closed at any time and
will be locked upon doing so. This can be verified by gently pulling on the door
handle.

EDOC00052 –Large ULT RFID Refrigerator User Manual, rev 0 11
Remote Alarm Contacts
Alarm contacts on the back of the refrigerator are available to wire the
refrigerator into an alarm system. These contacts can alarm on high/low
temperature, power outages, and control probe or microboard failures.
Reference the Refrigerator Manual for further details.

EDOC00052 –Large ULT RFID Refrigerator User Manual, rev 0 12
Operating Instructions
Basic Access Process
An end user will present an access badge to the proximity badge reader on the
refrigerator. The badge needs to be presented close to the proximity reader to
be read. The LCD screen will indicate granted access when a valid badge has
been presented.
The end user now can open the door for a predetermined time period, normally
about five seconds. Otherwise the user will need to present the pass again.
Desired products may now be taken out. The refrigerator will give an audible
alarm if the door is left open for, typically, more than five minutes.
Close the refrigerator door once products have been retrieved. The refrigerator
will automatically lock the door and begin its inventory process. The updated
inventory will then be sent to Terso Solutions for processing. The refrigerator
will not be accessible during the inventory process. Typically, the inventory
process will take about a minute to complete. Access will then be restored and
the process can be repeated.
Alarms
All refrigerator alarms are automatically sent to Terso Solutions. Terso
Solutions staff may contact on site staff to assist in correcting a potential
problem.
Alarm Types
Door Ajar
When the refrigerator door is left open for longer than five minutes, an audible
alarm will sound until the door is closed. If the door appears to be closed,
verify nothing is obstructing the door and attempt to re-close.
Power Outage
In the event of a power outage, an audible alarm will sound. The alarm will
continue until AC power has been restored or the onboard UPS system runs out
of power. Once power has been restored, the refrigerator will perform an
inventory scan and be ready for normal use.
Temperature
The refrigerator continuously monitors its internal temperature where inventory
items are kept. If the temperature becomes too hot or cold, Terso Solutions
staff will contact on site staff to attempt to troubleshoot and/or move
temperature sensitive products to a safe location. The refrigerator may also
prevent access if the inventory items have become compromised.

EDOC00052 –Large ULT RFID Refrigerator User Manual, rev 0 13
Hardware Failure
The refrigerator will automatically attempt to correct any hardware errors
preventing the refrigerator from functioning correctly. However, in the event
that a hardware component fails, the refrigerator may lock itself down to
prevent access. Terso Solutions staff will be in contact with on site staff if this
is the case.
Door Breach
If the refrigerator door is forced open, a notification indicating a forced entry
occurred will be sent to Terso Solutions. Any products taken will be reported.
This is a rare occurrence but may result in damage to the refrigerator.

EDOC00052 –Large ULT RFID Refrigerator User Manual, rev 0 14
Maintenance
There are no serviceable parts in the refrigerator. Please contact Terso
Solutions for any service related inquiries.
WARNING
Always disconnect the power supply to the refrigerator prior to
any repair or maintenance in order to prevent shock or injury.
Exterior Cleaning
Use a dry cloth to wipe off small amounts of dirt on the outside and inside of
the refrigerator and all accessories. If the outside panels are dirty, clean them
with a diluted neutral dishwashing detergent. (Undiluted detergent can damage
the plastic components. For the dilution refer to the instruction of the
detergent.) After cleaning with diluted detergent, always wipe off the same
areas with a wet cloth. Then wipe off the refrigerator or accessories with a dry
cloth.
Never pour water onto or into the refrigerator. Doing so can cause electric
shock or a short circuit.
Do not clean the refrigerator with scrubbing brushes, acid, thinner, solvents,
powdered soap, cleanser or hot water. These agents can scratch the paint or
cause it to peel. Plastic and rubber parts can be easily damaged by these
materials. Especially never use any volatile solvent to clean the plastic or
rubber parts. When a neutral dishwashing detergent is used to clean the
refrigerator, wipe it up thoroughly with a cloth soaked in clean water.
Interior Cleaning
If the interior of the unit requires cleaning, refer to in house safety procedures
to ensure any harmful materials are handled and cleaned correctly.
Troubleshooting
If the refrigerator appears to not be operating correctly, check to ensure that it
is plugged into a wall outlet and powered on. If further support is needed,
contact Terso Technical Support at [phone] in the US or +49 621
8501 233 in Europe. Support can also be contacted by visiting
http://support.tersosolutions.com.
Disposal
Terso Solutions will handle the disposal of the refrigerator and its components.
Please contact Terso Solutions at [phone] in the US or +49 621
8501 233 in Europe to arrange for refrigerator disposal.

EDOC00052 –Large ULT RFID Refrigerator User Manual, rev 0 15
Specifications
Attribute
Specification (Imperial)
Specification (Metric)
External Dimension
79.5H x 29.5W x 29.5D in
2020H x 750W x 750D mm
Internal Dimension
58.25H x 24.75W x 24.25D in
1480H x 629W x 615D mm
External Space
64.25H x 27.75W x 27.25D in
1680H x 675W x 680D mm
Volume
20.2 ft3
572 L
Unit Weight
473 lbs.
215 kg
Control Range
2° F to 10° F
-16° C to -12° C
Maximum Drawer Weight
Capacity
30 lbs.
14 kg
Electrical Input Rating
120VAC, 60Hz, 8A
Power Consumption
920W max
Battery
12VDC, 1.3A, Sealed lead acid, qty 2
Security Device
Electromagnet
Access Control
EM4102/EM4200 Proximity Reader
Environmental Protection
IPXO
Refrigerant
R-134A non-CFC
Cooling Method
Forced Air Cooled
Communications
Ethernet based LAN
DSL optional
Cellular optional
Model Specifics
Model
Country
RFID Frequency
Plug Style
Door Style
TS074
US
902-928 MHz
NEMA 5-15
Glass
Note: Design or specifications are subject to change without prior notice

EDOC00052 –Large ULT RFID Refrigerator User Manual, rev 0 16
Safety Check List
CAUTION
Please fill out this form before servicing and ensure that the unit is properly
marked with any applicable markings to denote any hazards inside.
Provide this form to the service engineer to keep for safety purposes.
Safety Check List
Refrigerator Contents:
Risk of infection .....................................................................
Yes
No
Risk of toxicity .......................................................................
Yes
No
Risk of radioactive sources ......................................................
Yes
No
Please list any potentially hazardous materials that
have been stored in this refrigerator:
Contamination of the Refrigerator
No contamination ...................................................................
Yes
No
Decontaminated.....................................................................
Yes
No
Contaminated ........................................................................
Yes
No
