Tesla RC3800FMX User manual

Product images are for illustrative purposes only and may differ from the actual product.
COMBI FRIDGE
FREEZER
NO-FROST
RC3800FMX
User Manual
ENG SRB

3
ENG
• THIS appliance is intended to be used in household
and similar applications such as staff kitchen areas
in shops, offices and other working environments;
farm houses and by clients in hotels, motels and
other residential type environments; bed and
breakfast type environments; catering and similar
nonretail applications.
• THIS appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.)
• CHILDREN should be supervised to ensure that
they do not play with the appliance. If the supply
cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
• DO not store explosive substances such as aerosol
cans with a flammable propellant in this appliance.
• THE appliance has to be unplugged after use
and before carrying out user maintenance on the
appliance.
• Keep ventilation openings, in the appliance
enclosure or in the built-in structure, clear of
obstruction.
• Do not use mechanical devices or other means to
accelerate the defrosting process, other than those
recommended by the manufacturer.
• Do not damage the refrigerant circuit.
• Do not use electrical appliances inside the food
storage compartments of the appliance, unless
they are of the type recommended by the
manufacturer.
• Please abandon the refrigerator according to local
regulators for it use flammable blowing gas and
refrigerant.
• When positioning the appliance, ensure the supply
cord is not trapped or damaged.
• Do not locate multiple portable socket-outlets
or portable power supplies at the rear of the
appliance.
• DO not use extension cords or ungrounded (two
prong) adapters.
• Risk of child entrapment. Before you throw away
your old refrigerator or freezer:
- Take off the doors.
- Leave the shelves in place so that children may not
easily climb inside.
• THE refrigerator must be disconnected from the
source of electrical supply before attempting the
installation of accessory.
• REFRIGERANT and cyclopentane foaming
material used for the appliance are flammable.
Therefore, when the appliance is scrapped, it
shall be kept away from any fire source and be
recovered by a special recovering company
with corresponding qualification other than
be disposed by combustion, so as to prevent
damage to the environment or any other harm.
• This appliance can be used by children aged
from 8 years and above and persons with reduce
physical sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use
of the appliance in a safe way and understand
the hazards involved. Children shall not play with
the appliance. Cleaning and user maintenance
shall not be made by children without
supervision. Children aged from 3 to 8 years
are allowed to load and unload refrigerating
appliances.
• THE necessity that, for doors or lids fitted with
locks and keys, the keys be kept out of the
reach of children and not in the vicinity of the
refrigerating appliance, in order to prevent
children from being locked inside .
• TO avoid contamination of food, please respect
the following instructions:
– Opening the door for long periods can cause
a significant increase of the temperature in the
compartments of the appliance.
– Clean regularly surfaces that can come in
contact with food and accessible drainage
systems.
– Clean water tanks if they have not been used
for 48 h; flush the water system connected to a
water supply if water has not been drawn for 5
days. (note 1)
– Store raw meat and fish in suitable containers in
the refrigerator, so that it is not in contact with or
drip onto other food.
– Two-star frozen-food compartments are suitable
for storing pre-frozen food, storing or making
ice-cream and making ice cubes. (note 2)
– One-, two- and three-star compartments are not
suitable for the freezing of fresh food. (note 3)
– For appliances without a 4-star compartment:
this refrigerating appliance is not suitable for
freezing foodstuffs.(note 4)
– If the refrigerating appliance is left empty
for long periods, switch off, defrost, clean, dry,
and leave the door open to prevent mould
developing within the appliance.
Note 1,2,3,4:Please confirm whether it
is applicable according to your product
compartment type.
• FOR a freestanding appliance: this refrigerating
appliance is not intended to be used as a built-in
appliance.
• ANY replacement or maintenance of the
LED lamps is intended to be made by the
manufacturer, its service agent or similar qualified
person.
• This product contains a light source of energy
efficiency class (F ).
SAFETY WARNINGS

4
ENG
Meaning of safety warning symbols
This is a prohibition symbol.
Any incompliance with
instructions marked with this
symbol may result in damage
to the product or endanger the
personal safety of the user.
This manual contains lots of important safety information which shall be observed by the users.
This is a warning symbol.
It is required to operate in strict
observance of instructions marked
with this symbol; or otherwise
damage to the product or personal
injury may be caused.
This is a cautioning symbol.
Instructions marked with this
symbwol require special caution
Insufficient caution may result
in slight or moderate injury, or
damage to the product.
Electricity related warnings
Warnings for using
• Do not pull the power cord when pulling the power plug of the refrigerator. Please firmly grasp the
plug and pull out it from the socket directly.
• To ensure safe use, do not damage the power cord or use the power cord when it is damaged or worn.
• Please use a dedicated power socket and the power socket shall not be shared with other electrical
appliances.
The power plug should be firmly contacted with the socket or else fires might be caused.
• Please ensure that the grounding electrode of the power socket is equipped with a reliable grounding
line.
• Please turn off the valve of the leaking gas and then open the doors and windows in case of leakage
of gas and other flammable gases. Do not unplug the refrigerator and other electrical appliances
considering that spark may cause a fire.
• Do not use electrical appliances on the top of the appliance, unless they are of the type recommended
by the manufacturer.
• Do not arbitrarily disassemble or reconstruct the refrigerator, nor damage the refrigerant circuit;
maintenance of the appliance must be conducted by a specialist.
• Damaged power cord must be replaced by the manufacturer, its maintenance department or related
professionals in order to avoid danger.
• The gaps between refrigerator doors and between doors and refrigerator body are small, be noted not
to put your hand in these areas to prevent from squeezing the finger. Please be gentle when open the
refrigerator door to avoid falling articles.
• Do not pick foods or containers with wet hands in the freezing chamber when the refrigerator is
running, especially metal containers in order to avoid frostbite.
• Do not allow any child to get into or climb the refrigerator; otherwise suffocation or falling injury of the
child may be caused.
• Do not place heavy objects on the top of the refrigerator considering that objectives may fall when
close or open the door, and accidental injuries might be caused.
• Please pull out the plug in case of power failure or cleaning. Do not connect the freezer to power
supply within five minutes to prevent damages to the compressor due to successive starts.
Warnings for placement
• Do not put flammable, explosive, volatile and highly corrosive items in the refrigerator to prevent
damages to the product or fire accidents.
• Do not place flammable items near the refrigerator to avoid fires.
• The refrigerator is intended for household use, such as storage of foods; it shall not be used for other
purposes, such as storage of blood, drugs or biological products, etc.
• Do not store beer, beverage or other fluid contained in bottles or enclosed containers in the freezing
chamber of the refrigerator; otherwise the bottles or enclosed containers may crack due to freezing to
cause damages.

5
ENG
1. Refrigerating appliances might not operate consistently (possibility of defrosting of contents or
temperature becoming too warm in the frozen food compartment) when sited for an extended
period of time below the cold end of the range of temperatures for which the refrigerating appliance
is designed.
2. The fact that effervescent drinks should not be stored in food freezer compartments or cabinets or in
low-temperature compartments or cabinets, and that some products such as water ices should not be
consumed too cold;
3. The need to not exceed the storage time(s) recommended by the food manufacturers for any kind
of food and particularly for commercially quick-frozen food in food-freezer and frozen-food storage
compartments or cabinets;
4. The precautions necessary to prevent an undue rise in the temperature of the frozen food while
defrosting the refrigerating appliance, such as wrapping the frozen food in several layers of
newspaper.
5. The fact that a rise in temperature of the frozen food during manual defrosting, maintenance or
cleaning could shorten the storage life.
Warnings for energy
PROPER USE OF REFRIGERATORS
Placement
• Before use, remove all packing materials, including bottom cushions, foam pads and tapes inside of the
refrigerator; tear off the protective film on the doors and the refrigerator body.
• Keep away from heat and avoid direct sunlight. Do not place the freezer in moist or watery places to
prevent rust or reduction of insulating effect.
• Do not spray or wash the refrigerator; do not put the refrigerator in moist places easy to be splashed
with water so as not to affect the electrical insulation properties of the refrigerator.
• The refrigerator is placed in a well-ventilated indoor place; the ground shall be flat, and sturdy (rotate
left or right to adjust the wheel for leveling if unstable).
• The top space of the refrigerator shall be greater than 30cm, and The refrigerator should be placed
against a wall with a free distance more than 10cm to facilitate heat dissipation.
• Spare enough space for convenient
opening of the doors and drawers.
The picture above is only for reference. The actual configuration will depend on
the physical product or statement by the distributor.

6
ENG
Levelling feet
LH
The picture above is only for reference. The actual configuration will depend on the physical product or
statement by the distributor.
Adjusting procedures:
a. Turn the feet clockwise to raise the refrigerator;
b. Turn the feet counterclockwise to lower the refrigerator;
c. Adjust the right and left feet based on the procedures above to a horizontal level.
Door right-left change
List of lools to be provided by the user
Cross screwdriver Putty knife
thin-blade screwdriver
5/16’’
socket and ralchet Masking tape
Parts to be used for door reverse
SN Part Quantity Notes
1Upper hinge 1Pre-installed on refrigerator, removed and retained it when changing
the door
2Upper hinge cover 1Pre-installed on refrigerator, removed and retained it when changing
the door
3Decorative cover 1Pre-installed on refrigerator, removed and retained it when changing
the door
4Door self-locking 2Pre-installed on refrigerator, removed and retained it when changing
the door
5Middle hinge 1Pre-installed on the refrigerator and to be used when changing the door
6Decorative cover 1Pre-installed on the refrigerator and to be used when changing the door
7Lower hinge 1Pre-installed on the refrigerator and to be used when changing the door
8Levelling feet 1Pre-installed on the refrigerator and to be used when changing the door
9Left upper hinge 1In the attached plastic bag, take them out for use when door is reversed
10 Left upper hinge cover 1In the attached plastic bag, take them out for use when door is reversed
11 Left door self-locking 2In the attached plastic bag, take them out for use when door is reversed
12 Right plastic cover 1In the attached plastic bag, take them out for use when door is reversed

7
ENG
1.Remove all food from the inner door liner.
2. Remove the upper left hinge cover decorative cover, upper right hinge cover and upper right hinge,
and disconnect the right signal line terminal 1 and signal line terminal 2 at the top of the box body.
3. Remove the refrigerated door body (be careful not to lose small parts such as the shaft sleeve and stop
on the door);
Remove the middle hinge and remove the decorative cover of hinge hole on the other side.
4. Remove the freezing door body (be careful not to lose small parts such as the shaft sleeve and stop on
the door);
Remove the hinge and adjust the angle. Remove and install the lower hinge shaft to the other side of
the hinge, and install the modified lower hinge to the other side of the box.
upper hinge cover upper hinge
decorative cover
decorative
cover
middle hinge

8
ENG
5. Change the refrigerator door:
1) Remove the cover plate of the upper end cover of the refrigeration door and the left decorative cover.
Install the upper shaft sleeve and the signal line terminal 1 of the door body to the other side and cover
the upper end cover plate. Take out the right decorative cover from the accessory bag and install it to
the other side of the upper end cover.
2) Remove the door self-locking, door stop and shaft sleeve of the refrigeration door, take out the
left door self-locking from the accessory bag, install it on the left side of the lower end cover of the
refrigeration door, change the door stop and shaft sleeve to the left side of the lower end cover of the
refrigeration door.
6. Change the freezing door:
1) Remove the shaft sleeve and cap of the upper end cover of the freezing door and install them at the
left and right swap positions.
2) Remove the door self-locking, door stop and shaft sleeve of the freezing door, take out the left door
self-locking from the accessory bag, install it on the left side of the lower end cover of the freezing door,
change the door stop and shaft sleeve to the left side of the lower end cover of the freezing door.
7. Install the replaced freezing door on the lower hinge, then install the middle hinge and cover the hinge
hole decorative cover.
middle hinge
decorative cover

9
ENG
upper hinge cover
upper hinge
decorative cover
inserts
Changing the Light
Starting
Energy saving tips
Any replacement or maintenance of the LED lamps is intended to be made by the manufacturer,its service
agent or similar qualified person.
• After transportation, please let the product stay for more than 2 hours before turning on the power,
otherwise it will lead to a decrease in cooling capacity or a damage to the product.
• Before putting any fresh or frozen foods, the refrigerator shall have run for 2-3 hours, or for above 4
hours in summer when the ambient temperature is high.
• Please pull out the plug in case of power failure or cleaning. Do not connect the freezer to power
supply within five minutes to prevent damages to the compressor due to successive starts.
• The appliance should be located in the coolest area of the room, away from heat producing appliances
or heating ducts, and out of the direct sunlight.
• Let hot foods cool to room temperature before placing in the appliance. Overloading the appliance
forces the compressor to run longer. Foods that freeze too slowly may lose quality, or spoil.
• Be sure to wrap foods properly, and wipe containers dry before placing them in the appliance. This cuts
down on frost build-up inside the appliance.
• Appliance storage bin should not be lined with aluminum foil, wax paper, or paper toweling. Liners
interfere with cold air circulation, making the appliance less efficient.
• Organize and label food to reduce door openings and extended searches. Remove as many items as
needed at one time, and close the door as soon as possible.
Light source in this product is replaceable only by qualified engineers.
8. Remove the upper left hinge cover and upper left hinge from the accessory bag.
Place the refrigerated door body on the middle hinge and install the upper left hinge.
Connect the refrigerator top signal line 4 to the door body signal line 1, and connect the signal line 2 to
the signal line 3.Finally, replace the hinge decorative cover to the right side of the box body (note: when
replacing the hinge decorative cover to the right side of the box body, the two inserts on the hinge
decorative cover (as shown in the figure) shall be cut o).
(The picture above is only for reference.The actual configuration will
depend on the physical product or statement by the distributor)
1. Please take out
the plug before
removal.
2. Remove the lampshade
with a screwdriver.
3. Take down the
lamp panel.
4. Remove the connection
terminal.

10
ENG
STRUCTURE AND FUNCTIONS
Key components
Door switch
LED light
Shelf
LED light (for some models)
Fruits & Vegetables box
Meat & Fish box
Drawer
Door tray
(The picture
above is only for
reference.The actual
configuration will
depend on the
physical product or
statement by the
distributor)
Refrigerating chamber
• The Refrigerating Chamber is suitable for storage of a variety of fruits, vegetables, beverages and other
food consumed in the short term. Suggested storage time 3 days to 5 days.
• Cooking foods shall not be put in the refrigerating chamber until cooled to room temperature.
• Foods are recommended to be sealed up before putting into the refrigerator.
• The glass shelves can be adjusted up or down for a reasonable amount of storage space and easy use.
Freezing chamber
• The low temperature freezing chamber may keep food fresh for a long time and it is mainly used to
store frozen foods and making ice.
• The freezing chamber is suitable for storage of meat, fish, rice balls and other foods not to be
consumed in short term.
• Chunks of meat are preferably to be divided into small pieces for easy access. Please be noted food
shall be consumed within the shelf time.
• Drawers, food boxes, shelves, etc. placed according to the position in the picture above are the most
energy efficient.

11
ENG
Functions
The picture above is only for reference. The actual configuration will depend on the physical product or
statement by the distributor.
Display screen
Refrigerating chamber
temperature display area
Freezing chamber
temperature display area Quick cool icon
Quick freeze icon Vacation icon Lock icon
Operation button
ATemperature setting button of
refrigerating chamber BTemperature setting button of freezing chamber
CSuper cool/super freezing button
Display
When power on the refrigerator for the 1st time, the whole display panel will shine for 3 seconds. Then
the display panel enters the normal display. The first time for using the refrigerator, the default set
temperatures of refrigerating chamber, freezing chamber is 5° C/-18 °C respectively.
When the error occurs, the display panel shows the error code (see next page); during normal running,
the display panel shows the set temperature of refrigerating chamber, freezing chamber.
Under normal running , if there is no operation or opening door action within 30s, the display panel will be
locked .the light of display panel will go out after the locked state continued for 30s.
Lock /unlock
In the non-locking state, press and hold the super-cool /super-freezer button for 3 seconds to enter the
locked state and the lock buzzer will sound.
In the locked state, press and hold the super-cool /super-freezer button for 3 seconds to enter the
unlocked state and the unlocking buzzer will sound.
After 30 seconds of no button operation, it will automatically enter the locked state, and the external
display board with a music buzzer will sound the lock buzzer at the same time.
The alarm sound release operation can be carried out in the locked state, and all other key operations
must be carried out in the unlocked state.
If the operation is in the locked state, an error buzzer will be displayed.
Temperature setting of refrigerating chamber
Click the button to change the set temperature of refrigerating chamber, each click of temperature
adjusting button of the refrigerating chamber, the set temperature will be reduced 1° C.

12
ENG
Fault
Code Fault Description
E1 Temperature sensor failure of
refrigerating chamber
E2 Temperature sensor failure of freezing
chamber
E3 Temperature sensor failure of
meat&fish zone
Error
code Error description
E5 Freezing defrost sensor detection
circuit error
E6 Communication error
E7 Ambient temperature sensor error
The temperature setting range of refrigerating chamber is 2~8 °C. When the set temperature is 2° C, click
the button again, the set temperature of refrigerating chamber will switch to 8° C.
Temperature setting of freezing chamber
Click the button to change the set temperature of freezing chamber, each click of temperature
adjusting button of the freezing chamber, the set temperature will be reduced 1 °C. The temperature
setting range for freezing chamber is -24~ -16°C. When the temperature is -24 °C, click the button again,
the set temperature of freezing chamber will switch to -16 °C.
Mode setting
Long press the refrigeration temperature adjustment button (3s) to set/cancel the holiday mode
When setting the holiday mode, the refrigeration is turned off, the refrigeration temperature display area is
extinguished, and the freezing is automatically set to -18°C;
Adjusting the refrigeration/freezing/super cool and super freezer buttons will exit the holiday mode.
When exiting the holiday mode, the refrigeration set temperature will automatically return to the set
temperature before the holiday mode; the freezing set temperature will automatically return to the set
temperature before the holiday mode; enter the normal operation mode.
Super freeze mode
Super cool and super freezer mode, press the super cool/super freezer button, the setting sequence is:
super cool -> super freezer -> cancel
When setting/cancelling the super cool mode, the corresponding super cool icon is on/off; when setting
the super cool mode, the refrigeration is automatically set to 2°C;
When exiting the super-cool mode, the set temperature of the refrigerating room will automatically return
to the set temperature before the quick-cooling mode;
When the super-freezer mode is set, the corresponding super-freezer icon is lit; when the super-freezer
mode is set, the freezing is automatically set to -24°C;
When exiting the super-freezer mode, the set temperature of the freezer compartment will automatically
return to the set temperature before the super-freezer mode;
Super cool mode automatically disabled for 6H.
Super freezer mode automatically disabled for 24H.
Recommended setting: refrigerated chamber 4 °C ,freezing chamber - 18°C.
Note: The super-freezer function is designed to maintain the nutritional value of the food in the freezer. It
can freeze the food in the shortest time. If a large amount of food is frozen at one time, it is recommended
that the user turn on the quick-freezing function and put the food in. At this time, the freezing speed of the
freezer compartment is increased, which can quickly freeze the food, effectively lock the nutrition of the
food, and facilitate storage.
Opening warning and alarm control
If the refrigerator door is open for 120 seconds without closing, the buzzer will alarm until the refrigerator
door is closed; any key will cancel the buzzer alarm.
Fault indication
The following warnings appearing on the display indicate corresponding faults of the refrigerator. Though
the refrigerator may still have cold storage function with the following faults, the user shall contact a
maintenance specialist for maintenance, so as to ensure optimized operation of the appliance.

13
ENG
MAINTENANCE AND CARE OF THE
REFRIGERATOR
Overall cleaning
• Dusts behind the refrigerator and on the ground shall be timely cleaned to improve the cooling effect
and energy saving.
• Check the door gasket regularly to make sure there are no debris. Clean the door gasket with a soft
cloth dampened with soapy water or diluted detergent.
• The interior of the refrigerator should be cleaned regularly to avoid odor.
• Please turn off the power before cleaning interior, remove all foods, drinks .shelves, drawers, etc.
• Use a soft cloth or sponge to clean the inside of the refrigerator, with two tablespoons of baking soda
and a quart of warm water. Then rinse with water and wipe clean. After cleaning, open the door and let
it dry naturally before turning on the power.
• For areas that are difficult to clean in the refrigerator (such as narrow sandwiches, gaps or corners), it is
recommended to wipe them regularly with a soft rag, soft brush, etc. and when necessary, combined
with some auxiliary tools (such as thin sticks) to ensure no contaminants or bacterials accumulation in
these areas.
• Do not use soap, detergent, scrub powder, spray cleaner, etc., as these may cause odors in the interior
of the refrigerator or contaminated food.
• Clean the bottle frame, shelves and drawers with a soft cloth dampened with soapy water or diluted
detergent. Dry with a soft cloth or dry naturally.
• Wipe the outer surface of the refrigerator with a soft cloth dampened with soapy water, detergent, etc.,
and then wipe dry.
• Do not use hard brushes, clean steel balls, wire brushes, abrasives (such as toothpastes), organic
solvents (such as alcohol, acetone, banana oil, etc.), boiling water, acid or alkaline items, which may
damage the fridge surface and interior. Boiling water and organic solvents such as benzene may
deform or damage plastic parts.
• Do not rinse directly with water or other liquids during cleaning to avoid short circuits or affect electrical
insulation after immersion.
Please unplug the refrigerator for defrost and cleaning.
Cleaning the glass shelf
• Remove the drawer on the glass shelf;
• Lift up the front of glass shelf (about 60°), and then pull out;
• Remove the glass shelf and clean as needed;
• The reverse operation is for installation of glass shelf.
Defrosting
Out of operation
• The refrigerator is made based on the air-cooling principle and thus has automatic defrosting function.
Frost formed due to change of season or temperature may also be manually removed by disconnection
of the appliance from power supply or by wiping with a dry towel.
• Power failure: In case of power failure, even if it is in summer, foods inside the appliance can be kept for
several hours; during the power failure, the times of door opening shall be reduced, and no more fresh
food shall be put into the appliance.
• Long-time nonuse: The appliance shall be unplugged and then cleaned; then the doors are left open
to prevent odor.

14
ENG
The appliance shall run continuously once it is started. Generally, the operation of the appliance
shall not be interrupted;otherwise the service life may be impaired.
• Moving: Before the refrigerator is moved, take all objects inside out, fix the glass partitions, vegetable
holder, freezing chamber drawers and etc. with tape, and tighten the levelling feet; close the doors and
fix them with tape. During moving, the appliance shall not be laid upside down or horizontally, or be
vibrated; the inclination during movement shall be no more than 45°.
TROUBLESHOOTING
You may try to solve the following simple problems by yourself.
If them cannot be solved, please contact the after-sales department.
Failed operation
Check whether the appliance is connected to power or whether the plug is
in well contact
Check whether the voltage is too low
Check whether there is a power failure or partial circuits have tripped
Odor
Odorous foods shall be tightly wrapped
Check whether there is any rotten food
Clean the inside of the refrigerator
Long-time operation of
the compressor
Long operation of the refrigerator is normal in summer when the ambient
temperature is high
It is not suggestible having too much food in the appliance at the same time
Food shall get cool before being put into the appliance
The doors are opened too frequently
Light fails to get lit Check whether the refrigerator is connected to power supply and whether
the illuminating light is damaged
Doors cannot be
properly closed
The door is stuck by food packages
The refrigerator is tilted
Loud noise Check whether the floor is level and whether the refrigerator is placed stably
Check whether accessories are placed at proper locations
Door seal fails to be
tight
Remove foreign matters on the door seal
Heat the door seal and then cool it for restoration
(or blow it with an electrical drier or use a hot towel for heating)
Water pan overflows
There is too much food in the chamber or food stored contains too much
water, resulting in heavy defrosting
The doors are not closed properly, resulting in frosting due to entry of air
and increased water due to defrosting
Hot housing
Heat dissipation of the built-in condenser via the housing, which is normal.
When housing becomes hot due to high ambient temperature and storage
of too much food, it is recommended to provide sound ventilation to
facilitate heat dissipation.
Surface condensation
Condensation on the exterior surface and door seals of the refrigerator is
normal when the ambient humidity is too high. Just wipe the condensate
with a clean towel.
Abnormal noise
Buzz: The compressor may produce buzzes during operation, and the
buzze: are loud particularly upon start or stop. This is normal.
Creak: Refrigerant flowing inside of the appliance may produce creak, which
is normal.

15
ENG
Warnings for disposal
Refrigerant and cyclopentane foaming material used for the refrigerator are flammable. Therefore,
when the refrigerator is scraped, it shall be kept away from any fire source and \ be recovered
by a special recovering company with corresponding qualification other than be disposed by
combustion, so as to prevent damage to the environment or any other harm.
When the refrigerator is scraped, disassemble the doors, and remove gasket of door and shelves;
put the doors and shelves in a proper place, so as to prevent trapping of any child.
Correct Disposal of this product:
This marking indicates that this product should not be disposed with other household
wastes throughout the EU. To prevent possible harm to the environment or human health
from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse
of material resources. To return your used device, please use the return and collection
systems or contact the retailer where the product was purchased. They can take this
product for environmental safe recycling.

16
ENG
Product Information Sheet
COMMISSION DELEGATED REGULATION (EU) 2019/2016 with regard to energy labelling of refrigerating
appliances
Supplier's name or trade mark: Tesla
Supplier's address: Tesla Electronics, Litijska 47, 1000 Ljubljana, SI
Model identifier: RC3800FMX
Type of refrigerating appliance:
Low-noise appliance: No Design type: freestanding
Wine storage appliance: No Other refrigerating appli-
ance: Yes
General product parameters:
Parameter Value Parameter Value
Height 2 010
Width 595
Overal dimensions
(millimetre) Depth 660
Total volume (dm³ or l) 378
EEI 100 Energy efficiency class E
Airborne acoustical noise emis-
sions (dB(A) re 1 pW) 40 Airborne acoustical noise emission class C
Annual energy consumption
(kWh/a) 265 Climate class:
extended temperate,
temperate, subtropi-
cal
Minimum ambient tempera-
ture (ºC), for which the refrig-
erating appliance is suitable
10
Maximum ambient tem-
perature (ºC), for which
the refrigerating appliance
is suitable
38
Winter setting No
Compartment Parameters:
Compartment parameters and values
Compartment type Compartment Vol-
ume (dm³ or l)
Recom-
mended
tempera-
ture setting
for opti-
mised food
storage (ºC)
These set-
tings shall
not con-
tradict the
storage
conditions
set out in
Annex IV,
Table 3
Freezing
capacity
(kg/24h)
Defrosting type
(auto-defrost=A,
manual defrost=M)
Page 1 / 2

17
ENG
Pantry No - - - -
Wine storage No - - - -
Cellar No - - - -
Fresh food Yes 256,0 4 - A
Chill No - - - -
0-star or ice-making No - - - -
1-star No - - - -
2-star No - - - -
3-star No - - - -
4-star Yes 122,0 -18 8,5 A
2-star section No - - - -
Variable temperature
compartment - - - - -
For 4-star compartments
Fast freeze facility Yes
Light source parameters:
Type of light source LED
Energy efficiency class -
Minimum duration of the guarantee offered by the manufacturer: 24 months
Additional information:
Weblink to the manufacturer's website, where the information in point4(a) Annex of Commission Regulation (EU)
2019/2019 is found: tesla.info
Page 2 / 2
Link to the EU EPREL database
The QR code on the energy label supplied with the appliance provides a web link to the registration
of this appliance in the EU EPREL database. Keep the energy label for reference together with the user
manual and all other documents provided with this appliance.
It is possible to find information related to the performance of the product in the EU EPREL database using
the link https://eprel.ec.europa.eu and the model name and product number that you can find on the
rating plate of the appliance.
For more detailed information about the energy label, visit www.theenergylabel.eu.

18
SRB
BEZBEDNOSNA UPOZORENJA
• Ovaj uređaj je namenjen za upotrebu u
domaćinstvu i sličnim aplikacijama kao što je npr
kuhinjski prostori za osoblje u prodavnicama,
kancelarijama i drugim radnim okruženjima;
seoske kuće i od strane klijenata u hotelima,
motelima i drugim okruženjima stambenog tipa;
okruženja tipa noćenje i doručak; ugostiteljstvo i
slične aplikacije koje nisu u maloprodaji.
• Ovaj uređaj nije namenjen za upotrebu od
strane osoba (uključujući decu) sa smanjenim
fizičkim, senzornim ili mentalnim sposobnostima
ili nedostatkom iskustva i znanja, osim ako su bili
pod nadzorom ili instrukciji u vezi sa upotrebom
uređaja od strane osobe odgovorne za njihovu
bezbednost.
• Decu treba nadzirati kako bi se osiguralo da se
ne igraju sa uređajem.Ako je kabl za napajanje
oštećen, mora ga zameniti proizvođač, njegov
serviser ili slično kvalifikovane osobe kako bi se
izbegla opasnost.
• Ne skladištite eksplozivne supstance kao što su
aerosolne limenke sa zapaljivim gorivom u ovom
uređaju.
• Aparat se mora isključiti iz utičnice nakon upotrebe
i pre obavljanja korisničkog održavanja na uređaju.
• Otvore za ventilaciju, u kućištu uređaja ili u
ugrađenoj konstrukciji, održavajte čistim od
prepreka.
• Nemojte koristiti mehaničke uređaje ili druga
sredstva za ubrzavanje procesa odmrzavanja, osim
onih koje preporučuje proizvođač.
• Nemojte oštetiti krug rashladnog sredstva.
• Ne koristite električne uređaje unutar pregrada za
odlaganje hrane u uređaju, osim ako nisu tipa koje
preporučuje proizvođač.
• Molimo napustite frižider u skladu sa lokalnim
regulatorima jer koristi zapaljivi gas i rashladno
sredstvo.
• Kada postavljate uređaj, uverite se da kabl za
napajanje nije zaglavio ili oštećen.
• Nemojte locirati više prenosivih utičnica ili
prenosivih izvora napajanja na zadnjoj strani
uređaja.
• Nemojte koristiti produžne kablove ili
neuzemljene (dvokrake) adaptere.
• Opasnost Rizik od uklještenja deteta. Pre nego što
bacite stari frižider ili zamrzivač:
- Skini vrata.
- Ostavite police na mestu kako deca ne bi mogla
lako da se popnu unutra.
• Frižider se mora isključiti iz izvora električne
energije pre nego što pokušate da instalirate
dodatnu opremu.
• Rashladno sredstvo i ciklopentan pene malarija
koja se koristi za Iha uređaj su zapaljivi. Zbog toga,
kada se Iha uređaj rashodi, on mora biti udaljen
od bilo kakvog izvora požara i biti će vraćen
od strane posebne kompanije za oporavak sa
odgovarajućom kvalifikacijom osim da se odlaže
sagorevanjem, kako bi se sprečila šteta po životnu
sredinu ili bilo koja druga šteta.
• Ovaj uređaj mogu da koriste deca uzrasta od
8 godina i više i osobe sa smanjenim fizičkim
senzornim ili mentalnim sposobnostima ili
nedostatkom iskustva i znanja ako su pod
nadzorom ili instrukcije u vezi sa korišćenjem
uređaja na bezbedan način i razumeju opasnosti
uključeni. Deca se ne smeju igrati sa uređajem.
Čišćenje i korisničko održavanje ne smeju da vrše
deca bez nadzora. Deca uzrasta od 3 do 8 godina
dozvoljeno je utovar i istovar rashladnih uređaja.
• Neophodnost da, za vrata ili poklopce opremljene
bravama i ključevima, da ključeve čuvajte van
domašaja dece i ne u blizini rashladnog uređaja,
kako biste sprečili da deca budu zaključana unutra.
• KAKO biste izbegli kontaminiranje hrane,
pridržavajte se sledećih uputstava:
- Dugo držanje vrata uređaja otvorenim može
da dovede do značajnog rasta temperature
unutar odeljaka uređaja.
- Redovno čistite površine koje mogu da dođu
u dodir sa hranom, kao i pristupačne delove
odvodnog sistema.
- Očistite posude za vodu ukoliko ih niste koristili
tokom vremenskog perioda od 48 h; ukoliko
tokom vremenskog perioda od 5 dana niste
uzimali vodu iz uređaja, isperite sistem za protok
vode povezan na dovod vode. (napomena 1)
- Sirovo meso i ribu čuvajte u odgovarajućim
posudama u frižideru, tako da ne dođe u
kontakt sa drugom hranom ili da kaplje na
drugu hranu.
- Odeljci za smrznutu hranu označeni dvema
zvezdicama pogodni su za držanje prethodno
smrznute hrane, za držanje ili pravljenje
sladoleda i za pravljenje kockica leda.
(napomena 2)
- Odeljci označeni jednom, dvema ili trima
zvezdicama nisu pogodni za zamrzavanje sveže
hrane. (napomena 3)
- Kod uređaja koji nemaju odeljak označen
četrima zvezdicama: ovaj uređaj za rashlađivanje
nije pogodan za zamrzavanje namirnica.
(napomena 4)
- Ukoliko će uređaj za rashlađivanje biti prazan
tokom dužeg vremenskog perioda, isključite ga,
odledite, očistite i osušite, a zatim ostavite vrata
uređaja otvorenim kako biste sprečili razvoj buđi
u unutrašnjosti uređaja.
Napomene 1, 2, 3, 4: Proverite da li su navedene
informacije primenjive na tipove odeljaka Vašeg
proizvoda.
• Za samostojeći aparat: ovaj rashladni uređaj nije
namenjen za upotrebu kao ugradni uređaj.
• Svaka zamena ili održavanje LED lampe su
namenjene da ih proizvodi proizvođač, njegov
serviser ili slično kvalifikovano lice.
• Ovaj proizvod sadrži izvor svetlosti klase
energetske efikasnosti (F).

19
SRB
Značenje simbola za bezbednosna upozorenja
Ovo je simbol zabrane.
Svaka neusaglašenost sa
uputstvima označenim ovim
simbolom za rezultat može
imati oštećenje proizvoda ili
opasnost po ličnu bezbednost
korisnika.
Ovo uputstvo sadrži mnoštvo važnih informacija o bezbednosti kojih korisnici moraju da se pridržavaju.
Ovo je simbol upozorenja.
Neophodno je da se uređaj
upotrebljava uz strogo poštovanje
uputstava označenih ovim simbolom;
u suprotnom, može doći do nastanka
oštećenja na proizvodu ili povreda
kod ljudi.
Ovo je simbol opreza.
Uputstva označena ovim
simbolom pozivaju na poseban
oprez. Nedovoljni stepen
opreza za rezultat može imati
nastanak manjih ili umerenih
povreda, ili oštećenje proizvoda.
Upozorenja koja se odnose na elektriku
Upozorenja u vezi sa upotrebom
• Nemojte povlačiti kabl za napajanje prilikom iskopčavanja frižidera sa napajanja. Čvrsto uhvatite utikač i
direktno ga iskopčajte iz utičnice.
• Kako biste bili sigurni da se uređaj upotrebljava na bezbedan način, nemojte oštećivati kabl za
napajanje i nemojte ga upotrebljavati ukoliko je oštećen ili pohaban.
• Upotrebljavajte namensku utičnicu na koju ne smeju da budu priključeni drugi električni uređaji.
Kabl za napajanje treba da ima čvrst kontakt sa utičnicom. U suprotnom, može doći do nastanka požara.
• Uverite se da je elektroda za uzemljenje na utičnici opremljena pouzdanom linijom za uzemljenje.
• U slučaju curenja plina ili drugih zapaljivih gasova, isključite ventil za plin koji curi, a zatim otvorite vrata
i prozore. Ne isključujte frižider ili druge električne uređaje sa napajanja, jer pojava varnica može da
izazove nastanak požara.
• Ne postavljajte druge električne uređaje na ovaj uređaj, osim ukoliko su u pitanju tipovi uređaja
preporučeni od strane proizvođača.
• Nemojte proizvoljno rasklapati ili ponovo sklapati frižider, niti oštećivati instalacije za rashladno sredstvo;
održavanje uređaja mora da obavi stručno lice
• Zamenu oštećenog kabla za napajanje mora da obavi proizvođač, njegov sektor za održavanje ili slična
stručna lica, kako bi se izbegao nastanak opasnosti.
• Otvori između vrata frižidera, kao i između vrata i tela frižidera su malih dimenzija; upozoravamo Vas da
ne postavljate ruke na pomenuta mesta, kako biste sprečili priklještenje prstiju. Vrata frižidera zatvarajte
lagano kako biste izbegli padanje predmeta.
• Tokom rada frižidera, ne uzimajte vlažnim rukama hranu ili posude, posebno one napravljene od
metala, koje se nalaze u komori za zamrzavanje, a kako biste izbegli nastanak promrzlina.
• Ne dozvoljavajte deci da ulaze u frižider, kao ni da se penju na njega. U suprotnom, može doći do
pojave gušenja ili povrede nastale usled pada kod dece.
• Ne stavljajte teške predmete na frižider, jer takvi predmeti prilikom zatvaranja ili otvaranja vrata mogu
pasti, što za rezultat može imati nehotično povređivanje.
• U slučaju nestanka struje ili prilikom čišćenja, iskopčajte utikač iz utičnice. Nemojte povezivati zamrzivač
na napajanje tokom perioda od pet minuta, kako biste sprečili oštećenje kompresora nastalo
uzastopnim pokretanjem uređaja.
Upozorenja u vezi sa držanjem sadržaja u uređaju
• Nemojte u frižider stavljati zapaljive, eksplozivne, isparljive i izuzetno korozivne supstance, kako biste
sprečili oštećenja proizvoda ili slučajni nastanak požara.
• Kako biste izbegli nastanak požara, ne stavljajte zapaljive supstance blizu frižidera.
• Ovaj frižider je namenjen za upotrebu u domaćinstvu, npr. za čuvanje hrane, i ne sme se upotrebljavati
ni u koje druge svrhe, poput čuvanja krvi, lekova ili bioloških proizvoda, itd.
• Nemojte u komori za zamrzavanje ovog frižidera držati pivo, pića ili druge tečnosti u bocama ili
zatvorenim posudama; u suprotnom, može doći do pucanja pomenutih boca ili zatvorenih posuda
usled zamrzavanja, što može dovesti do nastanka oštećenja.

20
SRB
PRAVILNA UPOTREBA FRIŽIDERA
Postavljanje
• Pre upotrebe uklonite sav materijal za pakovanje, uključujući donje jastuke, jastučiće od pene i trake
unutar frižidera; otkinuti zaštitnu foliju na vratima i kućištu frižidera.
• Čuvajte dalje od toplote i izbegavajte direktnu sunčevu svetlost. Ne postavljajte zamrzivač na vlažna ili
vodena mesta kako biste sprečili rđu ili smanjenje izolacionog efekta.
• Nemojte prskati ili prati frižider; ne stavljajte frižider na vlažna mesta koja se lako poprskaju vodom kako
ne biste uticali na električnu izolaciju frižidera.
• Frižider se postavlja u dobro provetreno zatvoreno mesto; podloga treba da bude ravna i čvrsta
(rotirajte levo ili desno da podesite točak za nivelisanje ako je nestabilno).
• Gornji prostor frižidera treba da bude veći od 30 cm, a frižider treba da bude postavljen uza zid sa
slobodnim rastojanjem većim od 10 cm kako bi se olakšalo rasipanje toplote.
• Ostavite dovoljno prostora za
udobno otvaranje vrata i fioka.
Slika iznad je samo za referencu. Stvarna konfiguracija zavisiće od fizičkog proizvoda ili izjave
distributera.
1. Uređaji za rashlađivanje možda neće raditi ujednačeno (potencijalno otapanje sadržaja ili previsoka
temperatura u odeljku za smrznutu hranu) ukoliko su tokom dužih vremenskih perioda podešeni na
vrednosti niže od temperaturnih opsega za koje je dati uređaj za rashlađivanje predviđen.
2. Gazirana pića ne treba držati u odeljku ili pregradi za zamrzavanje hrane ili u odeljcima ili pregradama
frižidera u kojim je temperatura niska, a određene proizvode, poput kockica leda, ne treba
konzumirati ukoliko su previše hladni;
3. Neophodno je povesti računa da se, prilikom držanja hrane u odeljku ili pregradi frižidera za
zamrzavanje hrane, ne prekorači rok trajanja preporučen od strane proizvođača, za bilo koju vrstu
hrane, a posebno za komercijalnu, brzo smrznutu hranu;
4. Potrebno je preduzeti neophodne mere kako bi se, prilikom otapanja uređaja za rashlađivanje,
sprečio nepotrebni rast temperature smrznute hrane, poput umotavanja smrznute hrane u nekoliko
slojeva novinske hartije.
5. Rast temperature smrznute hrane tokom ručnog otapanja, održavanja ili čišćenja može da skrati rok
trajanja proizvodima.
Upozorenja u vezi sa ekonomičnošću
