Teufel KB 22 CR Manual

Technical Description and Operating Instructions
CD receiver for Kombo 22
KB 22 CR
KB 22 RC

2 • KB 22 CR
Contents
General notes and information . . . . . . . . . . . . . . . . . . .3
For your information . . . . . . . . . . . . . . . . . . . . . . 3
Original packaging.......................3
Complaints.............................3
Contact...............................3
Proper use .............................3
Safety notes.................................4
Overview...................................6
Control elements and connections . . . . . . . . . . . . . . . . . 7
Setup and connection..........................9
Location tips............................9
Connecting the speakers . . . . . . . . . . . . . . . . . . . 9
Antenna...............................9
Audio input ............................9
Connecting to a power supply . . . . . . . . . . . . . . . 9
Remote control..............................10
Changing the battery . . . . . . . . . . . . . . . . . . . . 10
Functionality...........................10
Basic functions ..............................11
Activating and deactivating . . . . . . . . . . . . . . . . 11
Activating ......................... 11
Switching to Standby . . . . . . . . . . . . . . . . . . 11
EcoPower mode ........................ 11
Activating EcoPower mode . . . . . . . . . . . . . . 11
Deactivating EcoPower mode . . . . . . . . . . . . 11
Dimmer .............................. 11
Selecting a source....................... 12
Adjusting the volume 12
Mute 12
Adjusting the sound. . . . . . . . . . . . . . . . . . . . . . 12
Equalizer .......................... 12
Aurally compensated volume. . . . . . . . . . . . . 12
Bass boost .........................12
Clock.....................................13
Setting the time......................... 13
Automatically with RDS. . . . . . . . . . . . . . . . . 13
Manually .......................... 13
Displaying the time . . . . . . . . . . . . . . . . . . . 13
Radio playback .............................14
Setting the radio stations . . . . . . . . . . . . . . . . . . 14
Manually .......................... 14
Station scanning . . . . . . . . . . . . . . . . . . . . . 14
Mono/stereo ..........................14
Station memory ........................14
Saving stations ...................... 14
Selecting stations from the memory 14
CD operation ...............................15
Suitable CDs ..........................15
About handling CDs . . . . . . . . . . . . . . . . . . . . . 15
Inserting a CD ......................... 15
Ejecting a CD..........................15
USB mode .................................16
Inserting a USB stick and playback . . . . . . . . . . . 16
Removing a USB stick . . . . . . . . . . . . . . . . . . . . 16
AUX operation..............................17
Analogue source device . . . . . . . . . . . . . . . . . . 17
Bluetooth source device . . . . . . . . . . . . . . . . . . . 17
Playback functions (CD, MP3/WMA, USB) . . . . . . . . . . 18
Search by track number. . . . . . . . . . . . . . . . . . . 18
Repeat function / Shuffle . . . . . . . . . . . . . . . . . . 19
Repeating a section . . . . . . . . . . . . . . . . . . . 19
Program playback ...................... 19
Creating a program . . . . . . . . . . . . . . . . . . . 19
Playing a program . . . . . . . . . . . . . . . . . . . . 20
Deleting a program . . . . . . . . . . . . . . . . . . . 20
Timer functions..............................20
Sleep................................20
Activating Sleep . . . . . . . . . . . . . . . . . . . . . 20
Deactivating Sleep. . . . . . . . . . . . . . . . . . . . 20
Displaying the Sleep time remaining . . . . . . . 20
Timer / alarm function. . . . . . . . . . . . . . . . . . . . 21
Switching the timer /alarm function on and off 21
Troubleshooting .............................22
Care and cleaning ...........................22
Protecting the environment . . . . . . . . . . . . . . . . . . . . . 23
Technical data ..............................23

• KB 22 CR 3
Notice
The information in this document may change without
prior notice and in no way constitutes any liability on the
part of Lautsprecher Teufel GmbH.
No part of these instructions may be reproduced in any
form or be broadcasted in any way electronically, me-
chanically, by photocopy or recording without the written
permission of Lautsprecher Teufel GmbH.
© Lautsprecher Teufel GmbH
Version 1.0
July 2013
Original packaging
If you wish to exercise your eight-week right of return, we
ask that you be absolutely sure to hold onto the packag-
ing. We can only accept the return of the speakers WITH
THE ORIGINAL PACKAGING.
Empty boxes are not available!
Complaints
In case of complaint we will need the following informa-
tion to process your enquiry:
1. Invoice number
Can be found on the sales slip (enclosed with the
product) or on the order confirmation received as a PDF
document, e.g. 4322543
2. Serial number or batch number
Located on the back of the unit,
e.g. serial number: KB20240129A-123.
Many thanks for your support!
Contact
For questions, suggestions or any other issues please
contact our customer service department:
Lautsprecher Teufel GmbH
Gewerbehof Buelowbogen · Buelowstraße 66
10783 Berlin (Germany)
Phone: 00800 - 200 300 40 (toll-free)
Fax: +49 (0)30 / 300 930 930
E-mail: [e-mail]
www.teufelaudio.com
Proper use
Only use the unit as described in these operating instruc-
tions. Any other use will be deemed as not in accordance
with the instructions and may lead to damage of property
or even persons.
The manufacturer accepts no liability for damage caused
by use not in accordance with the instructions.
The unit is intended for private use.
Before operating the speakers please read the
safety notes and operating instructions carefully.
This is the only way to use all functions safely
and reliably.
Keep the operating instructions safe and pass them on to
anyone who may own the unit after you.
General notes and information

4 • KB 22 CR
Safety notes
Caution icons
You will find the following caution icons in these instruc-
tions:
Danger High risk!
Failure to observe the warning may result in
severe personal injury or death.
Attention Moderate risk!
Failure to observe the warning may result in
property damage.
Minor risk!
Points which should be observed when han-
dling the unit.
Safety notes
Danger Risk of electric shock!
Faulty installation of electrical equipment or
mains voltage which is too high can cause
electric shocks.
• Only operate the unit with the mains adapter supplied
or with a mains adapter of identical construction.
• Disconnect the mains adapter immediately and do not
use the unit if its case or the mains adapter are defec-
tive or if there is other visible damage.
• If the unit emits smoke or smells of burning or other
unusual odours, disconnect it immediately from the
power supply and do not operate it.
• The standby button does not disconnect the unit from
the power supply. Therefore, place the unit so that the
mains adapter is easily accessible.
• Never open the case of the mains adapter or the unit.
Repairs may only be carried out by an authorised
specialist workshop. Only parts which conform with
the original unit specifications may be used in this
case. There are electrical and mechanical parts in this
unit which are necessary in order to avoid exposure to
sources of danger.
• Do not insert any objects through the vent slots in the
housing.
• Only use the unit in indoor areas.
• Do not operate the unit in damp areas and protect it
from drops of water or splash water.
Also take care not to stand vases or other containers
filled with liquid on or near the speaker in order to
avoid liquid getting into the case. If water or other
foreign objects should enter the unit, immediately
disconnect the mains plug. Then send the unit to our
service address.
• Never touch the mains adapter with wet hands.
• Check the unit regularly for damage.
Danger Danger to children!
Children can become trapped in the packing
film when playing and suffocate.
• Do not allow children to play with the unit or the pack-
ing film. Danger of suffocation.
• Ensure that children do not remove small parts from
the unit or take them off of the unit (e.g. control knobs
or plug adapters). They could swallow the parts and
choke.
• Never allow children to operate electrical units unsu-
pervised.
Danger to hearing!
Extended listening at high volumes may lead to
hearing loss.
Very high acoustic pressure can suddenly be created, es-
pecially if the unit is switched on when set at full volume.
This may have psychological consequences and also
cause physical injury. Children and pets are particularly
at risk.
• Set the volume control on your unit to a low level.
• When the volume is set to a high level, never place
your ear directly on the speaker.
• To avoid damage to health, avoid extended listening at
high volumes.
Danger Health hazard!
If the battery belonging to the product is swal-
lowed, this may result in severe internal injuries
and even death.
• Keep both new and used button cell batteries so that
they are not accessible for children.
• If the battery compartment can no longer be closed
securely, do not use the product further and keep it so
that it is not accessible for children.
• If you suspect that a button cell battery has been swal-
lowed or ingested in any other way, seek the immedi-
ate attention of a physician.
Danger Danger of chemical burns!
Leaking battery acid may lead to chemical
burns.
• Do not allow battery acid to come into contact with
skin, eyes or mucus membranes. In case of contact with
acid rinse the affected part immediately with plenty of
plain water and if necessary see a doctor.

• KB 22 CR 5
Danger Danger of explosion!
Batteries (particularly lithium batteries) can
explode if used improperly.
• Never attempt to recharge batteries.
• Only use batteries of the same or equivalent type.
• Do not heat or short circuit batteries or rechargeable
batteries and do not dispose them in fire.
• Do not expose batteries and storage batteries to direct
sunlight.
Danger Danger of injury/damage!
Setting the unit up in an unsuitable location
may result in injury to persons and/or damage
to property.
• Never use the unit unmounted in vehicles, in unstable
locations, on wobbly tripods or furniture, on insuffi-
ciently dimensioned brackets etc. The unit could tip or
fall down and cause injury to persons or be damaged
itself.
• Set up the unit in such a way that you cannot acciden-
tally knock it over and that the cables do not pose any
trip hazard.
• Do not place the unit near sources of heat (e.g. heat-
ers, ovens, other heat generating equipment such as
amplifiers etc.).
Danger Danger to eyes and skin!
Opening the disc compartment with the lock
deactivated will cause an invisible or visible
laser beam to be emitted.
• Do not look into the beam, even if you are using opti-
cal instruments.
Attention Fire hazard!
Improper use may lead to damage or fire.
• Do not place open flames such as burning
candles or similar on the unit.
• Do not place the unit in direct sunlight.
• Ensure sufficient ventilation.
• Do not cover the vents with curtains, blankets, news-
papers or similar. Heat build-up inside the unit can
shorten its lifetime.
Attention Risk of damage!
External influences may damage or destroy the
device.
• If the unit is to be left unsupervised for a long period
(e.g. during a holiday), or if a thunderstorm is forecast,
disconnect the power plug from the mains power sup-
ply. Otherwise, a sudden overvoltage may cause a
defect.
• Leaked batteries may damage the remote control.
In case of prolonged absence, remove any batteries
from the remote control.
• If the device is subjected to warm temperatures after
being cold (e.g. after transport), condensation may
occur inside of it.
In this case, wait at least 2 hours before you connect
and activate it.
Explanation of symbols
Safety category II
Dual insulation
May only be used indoors.
Polarity on the round connector:
outside (–), inside (+)

6 • KB 22 CR
Product contents
a 1 x CD receiver KB 22 CR
b 1 x remote control
c 1 x mains adapter
d 1 x throw-out aerial for VHF (FM)
e 2 x speaker cable
The speakers for this system are supplied in a separate
packaging. Please take note of the instructions supplied
with the speakers.
Checking the product contents
• Check that all items have been delivered and that noth-
ing is damaged.
• If the delivery is incomplete or you find damage sus-
tained in transit, do not operate the unit but contact our
service department (see page 3).
Overview
a
b
c
d
e
KB 22 RC

• KB 22 CR 7
Control elements and connections
Back side
Item Name Description
1 — Control LED
2 — Infrared receiver for remote
control
3 — CD drawer
4Opening / closing the CD drawer
5Playback/pause
6Stop button
7 MODE Radio operation: Switch between
stereo/mono
USB and CD: Adjust repeat
8Radio operation: Select stored
station (up)
USB and CD: Next track
Item Name Description
9Radio operation: Select stored
station (down)
USB and CD: Previous track
10 VOLUME Volume control
11 — DISPLAY
12 USB connection
13 LOUDNESS Switch aurally compensated
volume on / off
14 FUNCTION Switch signal source
15 Switch unit on or to Standby /
EcoPower mode
SPEAKER POWER AUX IN ANTENNA
CLASS 1 LASER
PRODUCT
15V/3A
DC
Item Name Description
16
SPEAKERS Speaker connections
17
— Mains adapter connection
18
AUX IN External signal source connection
19 FM FM / VHF antenna connection
Front side
9
8
6
5
7
4
32
1011
12
13
14
15
1
16 17 18 19

8 • KB 22 CR
Remote control
Item Name Description
20 Open / close the CD drawer
21 AUX Select external source device
(AUX / BT)
22 USB USB input selection
23
DIM Change the brightness of the
display
24
A–B CD and USB only: Repeat a sec-
tion
25
SLEEP Switch-off function
26
S-BASS Switch Super-Bass on / off
27
TIMER Switch-on function
28 Radio operation: Select stored
programme (upwards)
CD and USB: Next track
29 Radio operation: Frequency up
CD and USB: Fast forward
30 Radio operation: Select stored
programme (downwards)
USB and CD: Previous track
31
/ PAIRING Stop button / disconnect blue-
tooth connection
32
Vol +/– Volume adjust
33
MUTE Mute speaker
34
1 ... 0 Number buttons
35
PROG Radio operation: Store station
USB and CD: Set program play-
back
36
10+ Select track or stored station >10
37
ALB +/– Radio operation: Next/previous
stored station
CD and USB operation: Select
next/previous album
38 Playback/pause
39 Radio operation: Frequency down
CD and USB: Rewind
40
DISPLAY Radio operation: Show RDS info
USB and CD: Show track info
41
CLOCK Show time
42
LOUDNESS Switch aurally compensated
volume on/off
43
P-EQ Adjust the sound
44 MODE Radio operation: Switch between
stereo/mono
CD and USB: Set repeat /shuffle
mode
45
INTRO CD and USB: Play track sample
46
CD CD operation
47
FM Radio operation
48 Switch unit on or to Standby /
EcoPower mode
KB 22 RC
2444
2246
2642
2345
2147
2048
27
41
31
32
33
3536
34
37
38
2939
40
28
30
2543

• KB 22 CR 9
Setup and connection
Location tips
• Select a stable, level base.
• Make sure that the environment is clean and free from
dust.
• Avoid placing the unit close to sources of heat or in
direct sunlight.
• Arrange the connector cables so that they do not pose
a trip hazard.
• Do not place heavy objects on the cables or unit.
Connecting the speakers
Use the speaker cables supplied to connect the speakers.
If you need longer cables you can order them from the
“Accessories” section of our online shop (www.teufel.de).
On the back side of the CD receiver are the “SPEAKER”
connecting terminals 16 for the right (“R”) and left (“L”)
speakers.
The terminals are each marked red (+) and black (–).
Make sure the polarity is correct!
Connect the like coloured terminals. Otherwise
the sound quality will suffer. The strands of the
speaker cables are marked with different colours or
shapes.
1. Split the wire down by
approx. 30 mm on both ends
and remove approx. 10 mm
of insulation each. Twist the
wire so that no strands are
protruding. Tin coating is not
necessary.
2. Flip the lever on the connecting
terminal up or down to open the
terminal.
3. Guide the exposed end of the
cable into the opening in the
terminal and close the lever
again. The cable has now been
clamped in place.
Antenna
Danger Risk associated with lightning strike!
If you are using outdoor or roof antennas, be
absolutely sure that the antenna has lightning
protection.
To receive FM/VHF stations, connect the antenna to
the jack 19 “FM”. This may be a roof/outside antenna,
but also a cable television connection. You will need a
coaxial connector cable for this.
If there is no antenna connection available where the unit
is located you can use the throw-out
aerial d supplied. Push the aerial
plug into the jack 19 “FM” and adjust
the position of the throw-out aerial for
best reception. Now fixed the
antenna in place with tape.
Audio input
You can connect almost any audio source to the “AUX
IN” cinch jacks 18 on the back of the unit, i.e. computer,
Smartphone, MP3 player (with/without dock), games
console, television etc. The source device must have an
output with line level. This kind of output is either a stereo
cinch jack or a 3.5 mm jack plug. Connect these units to
the “AUX IN” connections 18 using appropriate cables.
Cables are available from our online shop (www.teufel.
de) in the “Accessories” section.
Connecting to a power supply
Connect the round plug on the mains adapter supplied to
connection 17 on the back of the unit. Connect the mains
adapter to a mains power socket.
SPEAKER POWER AUX IN ANTENNA
CLASS 1 LASER
PRODUCT
15V/3A
DC
16 17 18 19

10 • KB 22 CR
Remote control
A 3 Volt button battery CR2025 is required to operate
the remote control.
The battery is already installed in the remote control unit
on shipping and is protected by a strip of plastic. You will
see this plastic strip on the back of the remote control.
Simply remove it with care. The remote control is now
ready for use.
Danger Health hazard!
If the battery belonging to the product is swal-
lowed, this may result in severe internal injuries
and even death.
• Keep both new and used button cell batteries so that
they are not accessible for children.
• If the battery compartment can no longer be closed
securely, do not use the product further and keep it so
that it is not accessible for children.
• If you suspect that a button cell battery has been swal-
lowed or ingested in any other way, seek the immedi-
ate attention of a physician.
Danger Danger of chemical burns!
Leaking battery acid may lead to chemical
burns.
• Do not allow battery acid to come into contact with
skin, eyes or mucus membranes. In case of contact with
acid rinse the affected part immediately with plenty of
plain water and if necessary see a doctor.
Danger Danger of explosion!
Batteries (particularly lithium batteries) can
explode if used improperly.
• Never attempt to recharge batteries.
• Only use batteries of the same or equivalent type.
• Do not heat or short circuit batteries or rechargeable
batteries and do not dispose them in fire.
• Do not expose batteries and storage batteries to direct
sunlight.
Changing the battery
1. Hold the remote control face down.
2. Unscrew the cross-headed screw using a screwdriver.
3. Pull the battery compartment out of the remote control.
4. Take out the old battery (see „Batteries and recharge-
able batteries“ on page 23).
5. Place the new battery into the holder, making sure
that the “+” symbol is visible on the battery and on the
holder.
6. Replace holder and push the compartment back in until
it clicks.
7. Screw-tighten the cross-headed screw.
Functionality
The remote control relays the control signals by means of
infrared light. It is therefore important that you point the
remote control in the direction of the unit. Make sure that
the infrared light is not obstructed by objects.
Fluorescent or energy-saving light bulbs installed in the
facility of the unit may impair the function of the remote
control or even make it impossible.
