Teufel System 5 THX Select2 User manual

THX Select2-certied home theatre speaker
5.2 Cinema Set · 5.2 Concert Set
Technical Specifications and Operating Manual
System 5 THX®Select2TM

2· System 5 THX Select2
About this document
The information in this document is subject to
change without warning. Lautsprecher Teufel
GmbH is in no way bound by the information pro-
vided herein.
No section of this document may be reproduced
or copied by any electronic or mechanical means,
including photocopying and recording, without
prior written consent from Lautsprecher Teufel
GmbH.
© Lautsprecher Teufel GmbH
Version 1.1
February 2010
The THX logo is a registered trademark of THX
Ltd in the US and other countries. All rights
reserved.
Trademarks
® All trademarks remain the property of their
respective owners.
Original packaging
We recommend that you hold on to the packag-
ing of all your new Teufel products, as we only
accept loudspeakers back within the initial eight-
week return period if they are shipped in their
ORIGINAL PACKAGING. We do not provide packag-
ing boxes separately.
Contact
If you have any questions, suggestions or criti-
cisms, please contact our support team:
Lautsprecher Teufel GmbH
Gewerbehof Buelowbogen · Buelowstrasse 66
10783 Berlin (Germany)
Ph.: 00800 200 300 40
Fax:+49(30) - 30 09 30 30
www.teufel.eu
Terms of warranty
Lautsprecher Teufel GmbH provides a twelve-year
warranty for loudspeakers and a two-year war-
ranty for ampliers and electrical components,
starting at the purchase date. The warranty cov-
ers all materials and time needed. It does not
cover devices damaged as a result of improper
use or electrical/mechanical overloading. The
original Teufel invoice is your proof of warranty.
This warranty applies exclusively to loudspeakers,
ampliers and electronic components purchased
from Teufel for private use. The warranty does not
apply to loudspeakers, ampliers and electronic
components sold to consumers through third-
party dealers. For third-party products supplied
together with the Teufel system, the terms of
warranty of the manufacturer in question apply.
When Teufel products are resold privately, the
warranty may be transferred to the new owner.
For this, the new owner requires the original
Teufel invoice.
Returns policy
Teufel provides an eight-week right of return with
a money-back guarantee.
You may only return individual components from
a set if Lautsprecher Teufel offers these com-
ponents for sale separately. If you return one or
more individual components from a set, this voids
the discount that Lautsprecher Teufel provides
on the sale of components as a set. This means
that for individually returned components from a
set, you will be refunded the difference between
the set price and the total purchase price of the
individual components you decide to keep, i.e.,
we will deduct the discount that applies to set
purchases.
For more information on returns, please refer to
the returns form provided with your shipment (or
online at www.teufel.eu in the support section).
If you decide to return any or all of the purchased
goods, please contact us rst.
Note that we can only process and accept
returned goods if you have telephoned us in
advance and discussed the required returns
procedure.
Technical specifications
For technical data, refer to the product descrip-
tion at our website www.teufel.eu

3
· System 5 THX Select2
Contents · Introduction
Tableofcontents·Introduction.................................................Page 3
Unpacking·Includedcomponents...............................................Page 4
Accessories(optional)..........................................................Page 5
5.2 speaker placement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Page 6
7.2speakerplacement.........................................................Page 8
Connecting...................................................................Page 9
Settings......................................................................Page 10
Subwoofercontrols............................................................Page 11
Problems and solutions · Cleaning · Technical specifications . . . . . . . . . . . . . . . . . . . . . . . . .Page 12
Manual version 1.1
Dear Lautsprecher Teufel customer,
Thank you for purchasing speakers from
Lautsprecher Teufel.
You are now the owner of a powerful and
sophisticated speaker system. All Teufel products
are meticulously manufactured and tted only
with top-quality components. Before using the
speaker system for the rst time, carefully read
this operating manual. Keep the manual in a safe
place for later reference.
If you have any questions, feel free to contact our
technicians at 00800 200 300 40, or send us an
e-mail using the form provided on our website
(www.teufel.eu). Please provide your invoice
number so that we can identify your purchase
and provide the best possible support.
BEFORE you contact us with any questions,
make sure to read the “Problems and solutions”
section on page 12 of this operating manual.
Further answers are provided on the “FAQ/
Support” pages of our website: www.teufel.eu.
Please take careful note of the safety guidelines
included in this shipment. Read this page before
beginning to use the loudspeakers.
Please write down the loudspeaker set's serial
number (shown on a sticker on the packaging) and
the invoice number here:
My INVOICE NUMBER is:
....................................................................................
My SERIAL NUMBER is:
....................................................................................
Should you ever require any customer support,
please provide us with these numbers so that we
can process your request promptly.
System 5 THX Select2 Concert Set 5.2

4· System 5 THX Select2
Unpacking · Included components
Please check rst that the
system is complete.
Remember
Hold on to the cardboard boxes
for at least eight weeks (duration
of the right-of-return period).
Lautsprecher Teufel will ONLY
refund the full purchase price if
the speakers are shipped back in
their
ORIGINAL PACKAGING !
*Manufactured under licence
from THX Ltd. U.S. patent number
5,043,970. Registered patent in
other countries. The THX logo is a
registered trademark of THX Ltd.
in the US and other countries.
All rights reserved.
3S 5000 SW THX Select2
Unpacking
Open the top aps of the cardboard box, remove
the packaging foam and carefully lift the speaker
out of the box. Place the included frame carefully
onto the front of the speaker.
We recommend that you keep the original pack-
aging in case you ever have to send the speakers
back to us for servicing.
System 5 THX Select2 ships as a complete
surround loudspeaker system. Two different
congurations are available:
5.2 Concert Set ·5.2 Cinema Set
Each set is a different combination of up to three
different loudspeaker types:
Included components
5.2 Concert Set:
4 2 x S 5000 SW THX Select2 Subwoofer
4 5 x S 500 FCR THX Select2 speaker
4 2 x power supply cable
4 8 x rubber feet for subwoofer
5.2 Cinema Set:
4 2 x S 5000 SW THX Select2 Subwoofer
4 3 x S 500 FCR THX Select2 speaker
4 2 x S 500 D THX Select2 speaker*
4 2 x power supply cable
4 8 x rubber feet for subwoofer
Accessories
As our customers' setup requirements tend to
vary considerably, the system does not ship with
any audio cables, wall mounts or speaker stands.
You can also order suitable cables for the speak-
ers and subwoofers directly from us, as well as
mounts or stands.
All the optional accessories for System 5 THX
Select2 are described in the next section of this
manual.
3S 500 FCR THX Select2
3S 500 D THX Select2

5
· System 5 THX Select2
Accessories(optional)
Optional accessories for the
System 5 THX Select2
For upgrading to 6.2/7.2
You can purchase addi-
tional speakers for your
System 5 THX Select2 at
our web shop. To upgrade
to a 6.2 conguration, you
must purchase a separate
S 500 FCR. To upgrade to a
7.2 conguration, you require two S 500 FCR sat-
ellites or two S 500 D dipole speakers (only avail-
able as pairs).
Teufel 2 x 2.5 mm2speaker cable
The highly exible, unilat-
erally marked OFC cable
has sufcient diameter to
ensure unhindered bridg-
ing up to 15 meters. The
white casing is inconspicu-
ous, and is offered as a cable roll in two lengths:
15 or 30 meters.
Teufel 2 x 4 mm2speaker cable
The OFC copper cable with
2 x 4 cross sections gives
an extremely stable con-
nection and is, at the same
time, practically created.
Inconspicuous colours
(white casing) and high exibility through indi-
vidual 0.08 qmm single wires guarantee an un-
complicated installation. This cable is offered as a
roll in two lengths: 15 or 30 meters.
Teufel Subwoofer Cable
Special RCA cable - developed for use with the sub-
woofer. The best connection
between an active sub-
woofer and an AV Receiver.
Protected via high-quality
shielding against interfer-
ence from other sources, with stable gold-plated
connectors to provide secure contact. The cable
is available in three different lengths, so your sub-
woofer can truly stand whereever you’d like it.
Y adapter
1 x socket to 2 x connector.
A Y adapter lets you feed
a mono sub signal to both
of the subwoofer’s stereo
inputs; this increases the
subwoofer’s overall volume.
Teufel stand AC 4002 SP
Newly developed speaker
stand that can be ideally
combined with System 5
THX Select2.* The speaker
is securely fastened us-
ing the tried-and-tested
Teufel design (speaker
base fastened with a
packing screw) and the
speaker cable is hidden
away inside the stand.
This stand is suitable
for the S 500 FCR model (but not
S 500 D!) Dipole speakers should always be wall-
mounted.
Teufel banana plugs
These high-quality, multi-pur-
pose speaker connectors from
Teufel ensure faultless con-
nections between your speak-
ers and amplier/receiver.
The rugged banana-design
screw connector securely
holds cable diameters of
up to 6 mm. Banana plugs are sold in pairs only,
marked red and black respectively. You require
10 plugs for System 5 THX Select2.
Teufel L-Lock wall bracket
A versatile wall bracket for
mounting speaker cabinets
– designed by Teufel. Can
be combined with the S
500 D so that the box can
also be swivelled horizon-
tally.
If you require any optional
accessories, you can easily
order these directly from the
Accessories section of our
online store:
www.teufel.eu
Note:
* Please note that S 500 FCR has
only been licensed for
THX Select2 when installed on
a wall. However, they can also
be operated on speaker stands
without signicantly affecting
the sound quality.

Technical Specifications and Operating Manual
6· System 5 THX Select2
5.2 speaker placement
Hint:
*Practice has shown that
the best bass imaging can be
achieved placing the subwoofer
at a position one-thirds or
two-thirds between the other
two speakers, i.e., not directly
in the centre of the front or
side wall, but symmetrically
to the right and left of the TV
and ideally separated by the
same distance as towards the
side walls.
For more tips and information
on alternative placements for
the two subwoofers, refer to
our website www.teufel.eu
under “Support”.
Note:
** The FCR satellites can also be
installed on stands. However, we
recommend fastening the
S 500 FCR speakers to a wall or
placing them on shelving since
the THX Select2 license has only
been awarded for wall-mounted
installations.
General notes on speaker placement
With their stylish and modern design, Teufel
System 5 THX Select2 blends nicely with liv-
ing room environments. In order to achieve the
best possible audio quality from your Teufel
loudspeaker set, however, there are a number of
speaker placement rules to consider. These apply
particularly to home theatre use.
As a general rule, any home theatre system
should be concentrated around the viewing area,
i.e., that part of the room that contains the TV/
screen and the main seating spots. If at all pos-
sible, the TV/screen should be placed at a central
position relative to the viewing/listening spots.
Our speaker placement suggestions, as illustrat-
ed on the next few pages, are designed for the
best possible multi-channel sound reproduction
in your home. Of course, in the reality of your liv-
ing room there may be other factors that do not
allow the suggested placements. You should at-
tempt to comply with these guidelines as best as
possible. However, state-of-the-art AV receivers
also offer many options to electronically compen-
sate for poor speaker placements. In general, the
following applies:
Start with our recommendations and experiment
with the placements until you nd what works in
your room from a visual and acoustic standpoint.
Trust your ears (and eyes)!
Centre
The centre speaker reproduces virtually all spo-
ken sound, including most dialogue. In relation to
the main listening spot, place it centrally under
or above the TV/screen. If your S 500 FCR** is
placed lower than 40 cm or higher than 1.20 m,
angle it slightly upwards or downwards towards
the listening spot.
Front
The front speakers should be positioned the same
as with conventional stereo speakers – forming an
equilateral triangle with the listener. In a home
theatre setup, the left and right front speakers
should be set up equidistant to the TV/screen or
mounted to the wall using the brackets on the
rear. For this purpose, the S 500 FCR satellites
from Teufel are tted with integrated M6 pack-
ing screws on the base of the cabinet. The pack-
ing screws are used to lock the speaker stands in
place.** Our universal stand AC 4002 SP is suitable
for this purpose. Speaker stands ensure that the
satellite speakers are placed at the best possible
height. If you mount the speakers on the wall or
on a bookshelf, make sure the speaker height is
between 40 cm and 1.20 m. If these recommended
values are not practical in your listening envi-
ronment and you need to position the speakers
higher or lower, you should angle them towards
the listening spot. Teufel's L-Lock wall mounts are
designed for just this purpose.
Make sure that the centre speaker and the two
front speakers are positioned in a straight line, or
on a slight arc with the TV/screen. If the distance
between the listening position and the speakers
varies signicantly, the spatial imaging will suffer.
Make sure to align your speakers properly to ex-
ploit their full potential.
Subwoofer
By using the recommended crossover frequency
of 80 Hz, you can position the subwoofer any-
where in the room without affecting the output
from the other loudspeakers. The ideal position is
somewhere along the axis between the two front
speakers.* However, feel free to experiment with
placing it anywhere you like. So that the down-
ring subwoofer functions properly, attach the
rubber feet to the subwoofers! Before fastening
the feet, lay the subwoofer on its side on soft
material (such as a blanket) to prevent damage
or scratches to the subwoofer and/or the sur-
face below. Using a suitable Phillips screwdriver,
tighten the included screws until the rubber feet
are at the height of the pre-drilled holes on the
bottom of the subwoofer.
Rear(Cinema Set)
The following applies to System 5 THX Select2:
Make sure to use S 500 D dipole speakers for the
rear channels. The S 500 FCR can be used for the
front and centre speakers. The dipoles are marked
as“Right” and “Left”. To guarantee the best listen-
ing conditions, they should be installed at the
proper locations.***
*** Other placement options
for the rear speakers are
described on page 10.
Page 7
Note:
According to the THX
specications, the speakers
have been conceived to achieve
optimum performance when
used WITH covers.
WITHOUT the covers, the
frequency response may become
uneven with increased highs. For
this reason, we do not
recommend using
them this way.
Centre
FrontFront
1/3 2/3
SW SW

Technical Specifications and Operating Manual
7
· System 5 THX Select2
5.2 speaker placement
We recommend
placing the rear speakers
somewhere in the
rear grey area.
Rear/side speaker placement option A
Cinema Set
Ideally, the S 500 D dipole speakers should be
mounted to the sides of the listening spot at a
height of 1.40 - 2.10 m. The Teufel dipole speakers
ship with a simple integrated wall mount. In this
placement option, the rear dipole speakers radi-
ate forwards (towards the TV/screen) and back-
wards (towards the rear wall of the room). This
way, listeners only hear reections from the wall
and not the direct sound. The rear-radiating side
of the dipole speaker should be at least 10 cm
away from the rear wall of the room.
Rear/side placement option B Cinema Set
You can also wall-mount the dipole speakers be-
hind the listening spot, at a height of 1.40 - 2.10 m.
We recommend using our L-Lock wall bracket to
mount the S 500 D speaker cabinets so that they
can be set to a 45 degree angle and radiate from
the front towards the side wall and from the back
towards the rear wall. Thus, the dipoles reect
out the rear and side walls and produce the de-
sired spatial diffusion. The front side of the dipole
speakers should be at least 10 cm away from the
side walls of the room.
Rear placement option C Concert Set
To set up the concert set with ve direct-radiat-
ing S 500 FCR satellites, place the rear boxes at
the left and right of the listening position. Ideally,
they should be at the same height, e.g., on a shelf
or, even better, on a wall. If you need to mount the
speakers signicantly higher or lower, experiment
with angling them towards the listening spot. The
S 500 FCR rear speakers should be positioned at
least 1.00 m away from the listener. If they are
any closer to the listening spot, make sure that
the front of the speakers is not directly pointed
at the listener but into the room, angled towards
the TV/screen.
SW Centre
Front
Front
Rear
Rear
Rear
Rear
Rear
Rear
SW Centre
Front
Front
SW Centre
Front
Front
SW
SW
SW

Technical Specifications and Operating Manual
8· System 5 THX Select2
7.2 speaker placement
If you have augmented your System 5 THX Select2
5.2 set with two additional compatible satellite
speakers (see page 5 of this manual), you can
make full use of your 7.1 AV receiver and upgrade
to a 7.2 home theatre system.
Front · Centre · Subwoofer · Rear(Side)
Set the speakers up in the same pattern as with
a 5.2 system. Please refer to “Speaker Positions
in 5.2 Conguration” on the previous two pages.
Rear centre
Ideally in a 7.2 system, the rear effects speakers
(rear sides) are positioned on the side walls next
to the listening spot and the rear centre speak-
ers are positioned on the rear wall at a height
between 1.40 and 2.10 metres.
If the distance between the rear speakers and
your listening spot is less than 1.00 m, we rec-
ommend using S 500 D dipole speakers instead
of the direct-radiating S 500 FCR as a rear cen-
tre speaker. In this case, simply expand your “5.2
Cinema Set” with two additional S 500 D dipole
speakers.
Viewed from above, the imaginary lines between
the four rear speakers used in your 7.2 setup
should ideally form an isosceles trapezium. Each
side of the trapezium should be at least 1.00 m
long. If the various side lengths differ or if the
four rear speakers are mounted at different
heights, you can compensate for these asym-
metries by entering the distances between the
individual speakers into the “Speaker Setup” util-
ity of your AV receiver/amplier.
Example of a System 5 THX
Select2 5.2 Cinema set with
two additional S 500 FCR
speakers for a 7.2 upgrade.
We recommend placing the
rear speakers somewhere in
the grey rear area (also if
the S 500 D dipole speaker
is used).
SW
Centre
FrontFront
RearRear
SW

Technical Specifications and Operating Manual
9
· System 5 THX Select2
Connecting
System 5 THX Select2 can be connected to any
current Dolby Digital/DTS 5.1/6.1/7.1 AV receiver/
amplier for a 5.2 conguration with an active
subwoofer. If your AV receiver is 6.1/7.1, do not
connect the Rear Centre Out(s). To take full ad-
vantage of a 7.1 receiver, you require additional
speakers (see page 5). Use either an additional S
500 FCR for a 6.2 conguration or two of these
speakers for a 7.2 setup. Another option is to use
two S 500 D dipole speakers (also for 7.2 mode).
If your receiver is 5.1, connect the front, centre
and rear speakers as shown in the diagram.
1. Connect the “Line In” input of the rst sub-
woofer to the “Sub Out” (or similarly named)
output of your AV receivers using a mono RCA
cable. Connect the “Line Out” output of the rst
subwoofer to the “Line In” input of the second S
5000 SW of your AV receiver (see 2a & 2b) using a
mono RCA cable.
In this case, the bass signal is transmitted from
one subwoofer to the other (“interconnected”).
Important!
For a 7.2 setup, connect the
additional two L/R rear centre
speakers to the L/R Rear Centre
Outs of the 7.1 AV receiver.
AV receiver
Speaker output
Teufel
connection panel
Front, centre and rear speakers
AV receiver Subwoofer 1
Sub Out
In
Subwoofer 2
In
Y splitter
In
Sub Out
Out
Line In
AV receiver Subwoofer 1 Subwoofer 2
Fig. 1: Connecting a S 500 FCR / S 500 D speaker
Fig. 2a: Connecting the speakers to an AV surround receiver
(example: 5.2 Cinema Set with interconnected
subwoofers).
Fig. 3a: Connecting the speakers to an AV surround receiver
(example: 5.2 Cinema Set with optional Y-splitter).
Fig. 2b: Connecting the S 5000 SW with interconnected
subwoofer signals.
Fig. 3b: Connecting the S 5000 SW with optional Y-splitter.
2. Connect a separately available Y-splitter to the
“Sub Out” (or similarly named) output of your AV
receivers. Next, use mono RCA cables to connect
the two jacks of the Y-splitter to the “Line In” in-
puts of the subwoofers (see 3a & 3b).
Here, the Y cable splits the bass signal and trans-
mits it to the two subwoofers.
There are two methods of connecting the two subwoofers with the AV receiver.
Speaker loads
Note that these speaker load
values are given under the as-
sumption that the
AV receiver lters out any
potentially damaging bass
content before transmitting
the audio signals to the
satellite speakers.

Technical Specifications and Operating Manual
10 · System 5 THX Select2
Settings
Speaker loads
Note that these speaker load
values are given under the as-
sumption that the
AV receiver lters out any
potentially damaging bass
content before transmitting the
audio signals to the
satellite speakers.
Setting up the AV receiver/amplifier
To take full advantage of your System 5 THX
Select2 with the S 5000 SW active subwoofer, use
the “Speaker Setup” utility of your AV receiver
to set the satellites to “small” or “normal” (not
“large”). This ensures that the speakers will re-
ceive the proper amount of signal and that the
volumes of the subwoofers and front speakers will
be matched.
Set the subwoofer to “On” using the “Speaker
Setup” utility (bass management and/or speaker
management) of your receiver. Set the crossover
frequency for the System 5 THX Select2 to 80 Hz.
100 Hz is another possible setting.
Setting up the subwoofer
Many current AV receivers are able to automati-
cally set the correct phase and level for the sub-
woofer using the “Speaker Setup” utility by en-
tering the distance between the subwoofers and
the listening spot. For this to work correctly, the
phase switch of the subwoofer must be set to
“0°” and the volume to “THX”.
If you are using an older AV receiver or another
type of amplier that does not allow you to set
the subwoofer distance:
You can use the phase switch of the subwoof-
er to manually adjust the phase to the other
speakers. The goal here is to ensure that all
speaker membranes move in the same direc-
tion in the vicinity of the crossover frequency.
If the phase is not set correctly, this can lead to
reduced bass response or even cancellation of
bass frequencies. If the subwoofer is positioned
between the two front speakers, we recommend
setting the phase to “0°
”. If the subwoofer is po-
sitioned closer to the listening spot, a phase of
“180° ” may be more appropriate. If the subwoof-
er is placed elsewhere, the “180° ” setting can be
used to compensate for reduced bass response.
Always set the phase control to the position
where the bass response is strongest.
Compared to the home theatre settings, the
volume setting of the subwoofer may need to
be readjusted accordingly for playing different
types of music. Whereas an action-packed DVD
typically contains massive amounts of sub-bass,
much music content may not. This will be espe-
cially noticeable if you calibrate your system for
optimum DVD playback. To nd the best compro-
mise between differing sound sources, use your
own subjective judgement.

Technical Specifications and Operating Manual
11
· System 5 THX Select2
E
W
R
Q
T
Y
Subwoofer controls
T Phase
This switch determines the phase relationship be-
tween the subwoofer and the front/centre speak-
ers. If the subwoofer is positioned as shown on
page 6, set the phase to 0°. Otherwise, set it to 180°.
Y Voltage selector
This switch adapts the internal amplier to the
local mains voltage. NEVER change this from the
standard local voltage. In Europe, the correct set-
ting is 220 - 240 V.
U Mains power connector
Connect the included mains power cable that
complies with your local mains power require-
ments.
I Fuse
The mains power fuse is located here. Using a
suitable screwdriver, replace this fuse with a suit-
able one (see gure on page 12). Only replace the
fuse when the subwoofer is completely discon-
nected from the mains power supply! Failure
to do so can be fatal!
O Power
In the OFF setting, the subwoofer is switched off;
ON means that it is switched on.
Q Line In
Connect the mono RCA cable here:
1. Signal arrives from Sub Out of receiver.
or
2. Signal arrives from Y-splitter (see page 9).
or
3. Signal arrives from Line Out of other subwoofer
(see W).
W Line Out
If you do not want to use a Y-splitter, you can
connect the second subwoofer here. This can be
useful when, for instance, the two subwoofers are
installed directly next to each other.
E Automatic starting
When set to “On”, the subwoofer will remain
permanently on. With the “Auto” setting, the
subwoofer will switch on automatically when it
receives an audio signal. But after approx. 20
minutes without receiving an audio signal, it will
switch off.
R Volume
Use the “Volume” controller to set the volume of
the subwoofer. We recommend setting the con-
troller to the position marked “THX”.
Symbols
The lightning symbol with
arrowhead inside an equilateral
triangle informs the user about
the danger of non-isolated
electrical voltage within the
enclosure with the inherent risk
of electrical shock.
The exclamation mark within
an equilateral triangle, as can
be seen on the back of the unit,
indicates that there are impor-
tant operating and maintenance
instructions for the user to read.
This product complies with the
following EU directives:
2004/108/EC and 2006/95/EC.
The “waste bin” symbol printed
on the type plates and amplier
labels of our products indicates
that Lautsprecher Teufel will
ensure the proper disposal of
its speakers and subwoofers in
accordance with
Germany's Electrical and
Electronic Equipment Act.
This product complies with DIN
EN 61140 (VDE 0140-1) and IEC
60417 standards for protection
class II. It only requires a two-pin
round plug (included) and not
an earthed plug. The plug has
a reinforced or double-shielded
casing to prevent
electrical shock.
Attention:
The separating equipment of
this equipment is the mains
plug, this separating equipment
must be usable without
difculties.
U
I
O

Technical Specifications and Operating Manual
12 · System 5 THX Select2
The subwoofer is not responding
If the Power LED on the rear
panel does not light up, re-
place the fuse (see page 11,
point I).
If the power LED on the
front side is lit, set the sub-
woofer volume level (page 11,
point R) to “Min”, unplug the subwoofer's RCA
cable from the amplier, turn up the volume
slightly and touch the tip (“hot” signal line) of the
RCA connector with your nger. If this produces a
hum or crackle, the fault is with the amplier or
the amplier settings. If the subwoofer remains
completely silent, please contact our support
team.
The subwoofer hums
Hum may be caused by connected audio equip-
ment as well as by problems with the mains power.
In most cases, excessive hum is caused by one of
the following:
1. The subwoofer is connected to a different elec-
trical circuit than the other components. Make
sure that all connected devices (including any
computers) are powered from the same elec-
trical circuit, i.e., the same mains socket.
2. The antenna connected to the audio system or
TV has a different earth potential than the an-
tenna socket. To test this, simply disconnect all
of the antenna cables from the wall socket. If
this makes the hum disappear, you will require
a ferrite bead (available at most electronics
stores). Simply insert the ferrite bead between
the antenna socket and the TV/receiver.
3. A line lter (to be purchased separately) can
also be useful for hum removal. Note that you
will need to connect all your electrical devices
to the line lter. Make sure you can return the
line lter for a refund if it does not produce
the desired results.
4. Certain powerstrips can also cause hum. Try
removing your powerstrip and plug the mains
cable of the subwoofer directly into the mains
socket.
5. Unplug the mains cable, rotate the connector
plug by 180°, and plug it back into the mains
socket.
6. If you have trouble locating the source of the
hum, check whether the subwoofer is less noisy
when you plug it into the mains connection in
another room (e.g., using an extension cable).
Also, try disconnecting the subwoofer's RCA ca-
ble from the receiver to see whether the hum is
caused by one of the other connected devices.
Problems and solutions · Cleaning · Technical specifications
Cleaning
Please take note of the following guidelines to
protect your Teufel speakers:
Avoid placing the speaker cabinets in direct sun-
light. Avoid extreme temperature uctuations
and protect your loudspeakers against humid-
ity. When cleaning the speaker cabinets, only
use dry or moist cloths. Never use alcohol-based
or abrasive cleaning products. If you need to
clean a speaker membrane, do this very carefully
using a dry cloth.
Technical specifications
For technical data, refer to the product descrip-
tion at our website www.teufel.eu.
