Texas Instruments TPA0242 User manual

TPA0242
Audio Power Amplifier
Evaluation Module
March 2000 Mixed-Signal Products
User’s Guide
SLOU074

IMPORTANT NOTICE
TexasInstruments andits subsidiaries(TI) reservethe rightto makechanges totheir productsor todiscontinue
any product or service without notice, and advise customers to obtain the latest version of relevant information
to verify, before placing orders, that information being relied on is current and complete. All products are sold
subject to the terms and conditions of sale supplied at the time of order acknowledgement, including those
pertaining to warranty, patent infringement, and limitation of liability.
TI warrants performance of its semiconductor products to the specifications applicable at the time of sale in
accordance with TI’s standard warranty. Testing and other quality control techniques are utilized to the extent
TIdeemsnecessarytosupport thiswarranty. Specifictestingofallparameters ofeachdevice isnotnecessarily
performed, except those mandated by government requirements.
CERTAIN APPLICATIONS USING SEMICONDUCTOR PRODUCTS MAY INVOLVE POTENTIAL RISKS OF
DEATH, PERSONAL INJURY, OR SEVERE PROPERTY OR ENVIRONMENTAL DAMAGE (“CRITICAL
APPLICATIONS”). TI SEMICONDUCTOR PRODUCTS ARE NOT DESIGNED, AUTHORIZED, OR
WARRANTED TO BE SUITABLE FOR USE IN LIFE-SUPPORT DEVICES OR SYSTEMS OR OTHER
CRITICALAPPLICATIONS.INCLUSIONOFTIPRODUCTSINSUCHAPPLICATIONSISUNDERSTOODTO
BE FULLY AT THE CUSTOMER’S RISK.
In order to minimize risks associated with the customer’s applications, adequate design and operating
safeguards must be provided by the customer to minimize inherent or procedural hazards.
TIassumes noliabilityforapplicationsassistance orcustomer productdesign. TIdoes notwarrantorrepresent
thatanylicense,eitherexpressorimplied,isgrantedunderanypatentright,copyright,maskworkright,orother
intellectual property right of TI covering or relating to any combination, machine, or process in which such
semiconductor products or services might be or are used. TI’s publication of information regarding any third
party’s products or services does not constitute TI’s approval, warranty or endorsement thereof.
Copyright 2000, Texas Instruments Incorporated

iii
Chapter Title—Attribute Reference
Preface
Related Documentation From Texas Instruments
J TI Plug-N-Play Audio Amplifier Evaluation Platform (literature
number SLOU011) provides detailed information on the evaluation
platform and its use with TI audio evaluation modules.
J TPA0242 Stereo 2-W Audio Power Amplifier (literature number
SLOS287) This is the data sheet for the TPA0242 audio amplifier
integrated circuit.
FCC Warning
This equipment is intended for use in a laboratory test environment only. It
generates, uses, and can radiate radio frequency energy and has not been
testedforcompliancewiththelimitsofcomputingdevicespursuanttosubpart
Jofpart 15ofFCCrules,which aredesignedtoprovidereasonableprotection
against radio frequency interference. Operation of this equipment in other
environments may cause interference with radio communications, in which
case the user at his own expense will be required to take whatever measures
may be required to correct this interference.
Trademarks
TI is a trademark of Texas Instruments Incorporated.

iv

Running Title—Attribute Reference
v
Chapter Title—Attribute Reference
Contents
1 Introduction 1-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1 Feature Highlights 1-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Description 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3 TPA0242 EVM Specifications 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2 Quick Start 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1 Precautions 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Quick Start List for Platform 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Quick Start List for Stand-Alone 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3 Details 3-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1 Precautions 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2 The TPA0242 Audio Power Amplifier Evaluation Module 3-3. . . . . . . . . . . . . . . . . . . . . . . . .
3.2.1 TPA0242 Audio Amplifier IC 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2.2 Inputs and Gain 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2.3 Differential Input 3-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2.4 Depop Circuitry 3-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2.5 BTL Operation 3-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2.6 Single-Ended Operation 3-7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3 Using The TPA0242 EVM With the Plug-N-Play Evaluation Platform 3-8. . . . . . . . . . . . . . .
3.3.1 Installing and Removing EVM Boards 3-8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.2 TPA0242 Module Jumper Settings and Switches 3-9. . . . . . . . . . . . . . . . . . . . . . . .
3.3.3 Signal Routing 3-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.4 Mute (Shutdown)/Mode 3-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.5 Power Requirements 3-14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.3.6 Inputs and Outputs 3-15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4 Using The TPA0242 EVM Stand-Alone 3-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4.1 TPA0242 EVM Connected for BTL Output 3-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4.2 TPA0242 EVM Connected for Single-Ended Output 3-17. . . . . . . . . . . . . . . . . . . . .
3.5 TPA0242 Audio Power Amplifier Evaluation Module Parts List 3-18. . . . . . . . . . . . . . . . . . .

Running Title—Attribute Reference
vi
Figures
1–1 The TI TPA0242 Audio Amplifier Evaluation Module 1-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2–1 Quick Start Platform Map 2-2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2–2 Module Preparation 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2–3 Quick Start Module Map 2-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–1 The TI Plug-N-Play Audio Amplifier Evaluation Platform 3-2. . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–2 TPA0242 EVM 3-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–3 TPA0242 EVM Schematic Diagram 3-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–4 TPA0242 Amplifier IC 3-5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–5 TPA0242 EVM Jumpers and Switches 3-9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–6 Platform Signal Routing and Outputs 3-11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–7 Mute/Mode and Polarity Control 3-12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–8 Typical Headphone Plug 3-15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–9 TPA0242 EVM Connected for Stereo BTL Output 3-16. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–10 TPA0242 EVM Connected for Stereo Single-Ended Output 3-17. . . . . . . . . . . . . . . . . . . . . . . .
Tables
2–1 Typical TI Plug-N-Play Platform Jumper and Switch Settings for the TPA0242 2-1. . . . . . . . .
2–2 Typical TPA0242 EVM Jumper Settings 2-1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2–3 Platform Jumper and Switch Settings for the TPA0242 2-3. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2–4 Typical TPA0242 EVM Jumper Settings 2-4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–1 TPA0242 EVM BTL Volume Settings 3-6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3–2 Typical TPA0242 EVM Jumper Settings for BTL Stand-Alone 3-16. . . . . . . . . . . . . . . . . . . . . .
3–3 Typical TPA0242 EVM Jumper Settings for Single-Ended Stand-Alone 3-17. . . . . . . . . . . . . .
3–4 TPA0242 EVM Parts List 3-18. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-1
Introduction
Introduction
This chapter provides an overview of the Texas Instruments (TI) TPA0242
audio amplifier evaluation module (SLOP275). It includes a list of EVM
features, a brief description of the module illustrated with a pictorial diagram,
and a list of EVM specifications.
Topic Page
1.1 Feature Highlights 1–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.2 Description 1–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.3 TPA0242 EVM Specifications 1–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 1

Feature Highlights
1-2
Introduction
1.1 Feature Highlights
The TI TPA0242 audio amplifier evaluation module and the TI plug-n-play
audio amplifier evaluation platform include the following features:
- TPA0242 stereo 2-W audio power amplifier evaluation module
J Internal depop circuitry to minimize transients in outputs
J Dual channel, bridge-tied load (BTL) or single-ended operation
J 2 W per channel output power into 3 Ωat 5 V, BTL
J Low current consumption in shutdown mode (150 µA)
J Internal input MUX selects among two sets of stereo inputs
J DCvoltagevolumecontrolfrom+20dB to –40 dB,anda–85dBmute
J Differential stereo inputs
J PC Beep input
- QuickandeasyconfigurationwiththeTIplug-n-playaudioamplifierevalu-
ation platform
J Evaluation module is designed to simply plug into the platform,
automatically making all signal, control, and power connections
J Platform provides flexible power options
J Jumpers on the platform select power and module control options
J Switches on the platform route signals
J Platformprovides quick andeasyaudioinput and outputconnections
- Platform power options
J External 5-V – 15-V DC VCC supply inputs
J External regulated VDD supply input
J Socket for on-board 5 V/3.3 V VDD voltage regulator EVM
J Onboard overvoltage and reverse polarity power protection
- Platform audio input and output connections
J Left and right RCA phono jack inputs
J Miniature stereo phone jack input
J Left and right RCA phono jack outputs
J Left and right compression speaker terminal outputs
J Miniature stereo headphone jack output

Description
1-3
Introduction
1.2 Description
The TPA0242 stereo 2-W audio power amplifier evaluation module is a
complete, 2-watt per channel stereo audio power amplifier. It consists of the
TI TPA0242 stereo 2-W audio power amplifier IC along with a small number
of other parts mounted on a circuit board that measures approximately 2 1/4
inches by 1 1/2 inches (Figure 1–1).
Figure 1–1.The TI TPA0242 Audio Amplifier Evaluation Module
GND
ROUT+
ROUT–
SE/BTL
S1
SHUTDOWN
GND
LOUT–
LOUT+
C11
C2
C13
VDD GND
L IN+
GND
L LINE–
L HP
VDD GND
R HP
R LINE–
GND
R IN+
C10
+
TPA00242 EVM Board SLOP275
U1
+
TEXAS
INSTRUMENTS
R2
R1 PCBEEP
C1
C12
C6 C5 C4
R3
S2
C7 C8 C9
C3
SHUTDOWN
R4
S3 S4
HP/LINE
Single in-line header pins extend from the underside of the module circuit
board to allow the EVM to be plugged into the TI plug-n-play audio amplifier
evaluationplatform,ortobewired directlyintoexistingcircuitsandequipment
when used stand-alone.
The platform has room for a single TPA0242 evaluation module and is a
convenient vehicle for demonstrating TI’s audio power amplifier and related
evaluation modules. The EVMs simply plug into the platform, which auto-
matically provides power to the modules, interconnects them correctly, and
connectsthemtoaversatilearrayofstandardaudioinputandoutputjacksand
connectors. Easy-to-use configuration controls allow the platform and EVMs
to quickly model many possible end-equipment configurations.
There is nothing to build, nothing to solder, and nothing but the speakers
included with the platform to
hook up .
1.3 TPA0242 EVM Specifications
Supply voltage range, VDD 4.5 V to 5.5 V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Supply current, IDD 2 A max. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Continuous output power per channel, PO: 3-ΩBTL, VDD=5 V 2 W. . . . . .
Audio input voltage, VI,: HP input 5 Vpp max. . . . . . . . . . . . . . . . . . . . . . . . . .
Line input 5 Vpp max. . . . . . . . . . . . . . . . . . . . . . . .
PC BEEP input 5 Vpp max. . . . . . . . . . . . . . . . . . . .
Minimum load impedance, RL3 Ω. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

1-4
Introduction

2-1
Quick Start
Quick Start
ThestepsinthischaptercanbefollowedtoquicklypreparetheTPA0242audio
amplifier EVM for use. Using the TPA0242 with the TI plug-n-play audio
amplifierevaluation platform is aquick and easyway to connect power, signal
and control inputs, and signal outputs to the EVM using standard connectors.
However, the audio amplifier evaluation module can be used stand-alone by
making connections directly to the module pins, and can be wired directly into
existing circuits or equipment.
Theplatformswitchand jumper settings shown inTable2–1aretypicalforthe
TPA0242 EVM and will cause the TPA0242 to switch to single-ended output
mode when a plug is inserted into platform headphone jack J10.
Table 2–1. Typical TI Plug-N-Play Platform Jumper and Switch Settings for the TPA0242
EVM JP6 JP7 JP8 S2 S3
P-N-P Platform Mode X Hi Note 2 U2–U4
Notes: 1) X = Don’t care
2) SetS2to ON when signalconditioningboardis installed in U1;setS2
to OFF when no signal conditioning board is installed.
Table 2–2. Typical TPA0242 EVM Jumper Settings
EVM S3
TPA0242 OFF
Note: ON = Shunt installed
OFF = Open
Topic Page
2.1 Precautions 2–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.2 Quick Start List for Platform 2–3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.3 Quick Start List for Stand-Alone 2–5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Chapter 2

Precautions
2-2
Quick Start
2.1 Precautions
Power Supply Input Polarity and Maximum Voltage
Always ensure that the polarity and voltage of the external power
connected to VCC power input connector J1, J2, and/or VDD power
input connector J6 are correct. Overvoltage or reverse-polarity
power applied to these terminals can open onboard soldered-in
fuses and cause other damage to the platform, installed evaluation
modules, and/or the power source.
Inserting or Removing EVM Boards
Do not insert or remove EVM boards with power applied—damage
to the EVM board, the platform, or both may result.
Figure 2–1.Quick Start Platform Map
Signal Conditioning
****CAUTION****
Do not insert or remove
EVM boards with power
applied
ICC
JP4
F1
VR1
R1
JP3
JP2 JP1 AC/DC
(J2)
VCC(J1)
D1 D2 D3
D4 J2
J3 J4 J5
AC/DC
In
VCC
In
+
J1
DC
SOURCE
LED1 VCC
LED2 VDD
R2
JP5 IDD
B1
U6
POWER
SUPPLY
U3 U4
U5
U1
U2
Audio
Power
Amps
OnOff ConditioningS2
J7 J8 Right
Out Left
Out
+– +–
JP6
Mode
Mute
Spk(U2-U4)
JP8
J9 Left
Out
JP7
S3 HP Source
U2-U4
U5
Polarity
Lo
Hi
HP(U5)
C3 C2
++
R3
R5
J10
Stereo
HP Out
TP1
GND
Plug-N-PlayAudio Amplifier
Evaluation Platform
SLOP097 Rev. C.1
Stereo
In
Right
In Left
In
J6 In/Out VDD
F2
VR2 +
DC
Power
In/Out
Speaker
Output
Headphone
Output
Audio
Input
Power
Input
Batt
C1+
Right
Out
On Off Pwr
S1
TEXAS INSTRUMENTS 1997
R4
7a
1
23 4
5
6
7b
7b
7
b7 b
910
13

Quick Start List for Platform
2-3
Quick Start
2.2 Quick Start List for Platform
FollowthesestepswhenusingtheTPA0242EVMwiththeTIplug-n-playaudio
amplifier evaluation platform (see the platform user’s guide, SLOU011, for
additional details). Numbered callouts for selected steps are shown in Figure
2–1 and Figure 2–2, and details appear in Chapter 3.
- Platform preparations
1) Ensurethatallexternalpowersourcesaresetto OFF andthattheplatform
power switch S1 is set to OFF.
2) Install a TPA0242 module in platform socket U2, taking care to align the
module pins correctly.
3) Use switch S2 to select or bypass the signal conditioning EVM (U1).
4) Set control signal Polarity jumper JP8 to Hi.
5) Set jumper JP6 to select the Mode control input (causes the TPA0242 to
switch to the single-ended output mode if a plug is inserted into platform
headphone jack J10).
6) If the headphone jack (J10) output will be used, set headphone source
switch S3 to U2–U4.
Table 2–3. Platform Jumper and Switch Settings for the TPA0242
EVM JP6 JP7 JP8 S2 S3
P-N-P Platform Mode X Hi Note 2 U2–U4
Notes: 1) X = Don’t care
2) SetS2 to
ON whensignal conditioning board is installed inU1; set S2
to
OFF when no signal conditioning board is installed.
- Power supply
7) Selectandconnectthepowersupply(ensurepowersupplyissetto OFF ):
a) Connectanexternalregulatedpowersupplysetto5VtoplatformVDD
power input connector J6 taking care to observe marked polarity,
or
b) InstallavoltageregulatorEVM(SLVP097orequiv.)inplatformsocket
U6.Connecta7V –12Vpowersourcetoaplatform VCC powerinput
J1 or J2 and jumper the appropriate power input (see platform user’s
guide).
- Inputs and outputs
8) Ensure that the audio signal source level is set to minimum.
9) Connect the audio source to left and right RCA phono jacks J3 and J5 or
stereo miniature phone jack J4.
10) Connectspeakerstoleftandright RCA jacksJ7 andJ9 ortostrippedwire
speaker connectors J8.

Quick Start List for Platform
2-4
Quick Start
- Evaluation module preparations
Figure 2–2.Module Preparation
11
12
13
14
GND
ROUT+
ROUT–
SE/BTL
S1
SHUTDOWN
GND
LOUT–
LOUT+
C11
C2
C13
VDD GND
L IN+
GND
L LINE–
L HP
VDD GND
R HP
R LINE–
GND
R IN+
C10
+
TPA00242 EVM Board SLOP275
U1
+
TEXAS
INSTRUMENTS
R2
R1 PCBEEP
C1
C12
C6 C5 C4
R3
S2
C7 C8 C9
C3
SHUTDOWN
R4
S3 S4
HP/LINE
Table 2–4. Typical TPA0242 EVM Jumper Settings
EVM S3
TPA0242 OFF
Note: ON = Shunt installed, OFF = Open
11) To allow the module SE/BTL control input to switch the amplifier IC
between single ended (SE) and bridge-tied load (BTL) output modes, set
output mode jumper S3 to
OFF . To keep the module amplifier IC in the
single-endedoutputmoderegardlessofthecontrolinputstate,setjumper
S3 to ON .
12) To allow the module HP/LINE control input to switch the amplifier IC
between using the HP pins and the LINE pins as the signal inputs, set the
input mode jumper S3 to OFF . To keep the amplifier IC in the HP input
mode regardless of the control input state, set jumper S3 to ON .
- Power Up
13) To allow the amplifier IC to switch from the LINE inputs to the HP inputs
when the output switches from BTL output mode to SE output mode and
vice versa, set jumper S4 to ON . To allow the inputs and output modes to
switch independently, set jumper S4 to OFF .
PlatformLED2shouldlightindicatingthepresenceofVDD,andtheevaluation
modules installed on the platform should begin operation.
14) Adjust the signal source level as needed.

Quick Start List for Stand-Alone
2-5
Quick Start
2.3 Quick Start List for Stand-Alone
Follow these steps to use the TPA0242 EVM stand-alone or when connecting
it into existing circuits or equipment. Connections to the TPA0242 module
header pins can be made via individual sockets, wire-wrapping, or soldering
to the pins, either on the top or the bottom of the module circuit board.
Numbered callouts for selected steps are shown in Figure 2–3 and details
appear in Chapter 3.
Figure 2–3.Quick Start Module Map
GND
ROUT+
ROUT–
SE/BTL
S1
SHUTDOWN
GND
LOUT–
LOUT+
C11
C2
C13
VDD GND
L IN+
GND
L LINE–
L HP
VDD GND
R HP
R LINE–
GND
R IN+
C10
+
TPA00242 EVM Board SLOP275
U1
+
TEXAS
INSTRUMENTS
R2
R1 PCBEEP
C1
C12
C6 C5 C4
R3
S2
C7 C8 C9
C3
SHUTDOWN
R4
S3 S4
HP/LINE
6
7
8
9
- Power supply
1) Ensure that all external power sources are set to OFF.
2) Connectanexternalregulatedpower supplysetto5Vtothemodule VDD
and GND pins taking care to observe marked polarity.
- Inputs and outputs
3) Ensure that audio signal source level adjustments are set to minimum.
4) Connect the right (left) positive lead of the audio source to the module
R LINE– (L LINE–) pins and the negative lead to the R IN+ (L IN+) pins.
If using the headphone inputs, connect the positive audio source to the
module R HP (L HP) and the negative lead to R IN+ (L IN+). The inputs
can be used with a differential or single-ended audio source, but the
headphone and line have common positive inputs.
5) Select output mode:
a) For BTL output, connect a speaker to the module OUT+ and OUT–
pins of each channel,
or
b) For single-ended output, connect a headphone or a speaker to the
module OUT+ and GND pins of each channel through a 33 µF to
1000 µF output-coupling capacitor (Figure 3–10).

Quick Start List for Stand-Alone
2-6
Quick Start
- Evaluation module preparations
6) To allow the module SE/BTL control input to switch the amplifier IC
between single ended (SE) and bridge-tied load (BTL) output modes, set
output mode jumper S3 to OFF . To keep the module amplifier IC in the
single-endedoutputmoderegardlessofthecontrolinputstate,setjumper
S3 to
ON .
7) To allow the module HP/LINE control input to switch the amplifier IC
between using the HP pins and the LINE pins as the signal inputs, set the
input mode jumper S3 to OFF . To keep the amplifier IC in the HP input
mode regardless of the control input state, set jumper S3 to ON .
- Control inputs
8) To allow the amplifier IC to switch from the LINE inputs to the HP inputs
when the output switches from BTL output mode to SE output mode and
vice versa, set jumper S4 to ON . To allow the inputs and output modes to
switch independently, set jumper S4 to OFF . Connect control lines to the
various module control input pins as needed:
a) SE/BTL: A high selects the single-ended (SE) output mode; a low or
float selects the bridge-tied load (BTL) output mode.
b) SHUTDOWN:AlowshutsdowntheamplifierIConthemodule;ahigh
or float allows normal operation.
- Power-up
9) Verify correct voltage and input polarity and setthe external powersupply
to ON.
The EVM should begin operation.
10) Adjust the signal source level as needed.

3-1
Details
Details
This chapter provides details on the TPA0242 IC, the evaluation module, and
thestepsintheQuick-StartList,additionalapplicationinformation,andaparts
list for the TPA0242 evaluation module.
Topic Page
3.1 Precautions 3–2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.2 The TPA0242 Audio Power Amplifier Evaluation Module 3–3. . . . . . . . .
3.3 Using the TPA0242 EVM With the Plug-N-Play
Evaluation Platform 3–8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.4 Using The TPA0242 EVM Stand-Alone 3–16. . . . . . . . . . . . . . . . . . . . . . . .
3.5 TPA0242 Audio Power Amplifier Evaluation Module Parts List 3–18. .
Chapter 3

Precautions
3-2
Details
3.1 Precautions
Power Supply Input Polarity and Maximum Voltage
Always ensure that the polarity and voltage of the external power
connected to VCC power input connector J1, J2, and/or VDD power
input connector J6 are correct. Overvoltage or reverse-polarity
power applied to these terminals can open onboard soldered-in
fuses and cause other damage to the platform, installed evaluation
modules, and/or the power source.
Inserting or Removing EVM Boards
Do not insert or remove EVM boards with power applied—damage
to the EVM board, the platform, or both may result.
Figure 3–1.The TI Plug-N-Play Audio Amplifier Evaluation Platform
Signal Conditioning
****CAUTION****
Do not insert or remove
EVM boards with power
applied
ICC
JP4
F1
VR1
R1
JP3
JP2 JP1 AC/DC
(J2)
VCC(J1)
D1 D2 D3
D4 J2
J3 J4 J5
AC/DC
In
VCC
In
+
J1
DC
SOURCE
LED1 VCC
LED2 VDD
R2
JP5 IDD
B1
U6
POWER
SUPPLY
U3 U4
U5
U1
U2
Audio
Power
Amps
OnOff Conditioning
S2
J7 J8 Right
Out Left
Out
+– +–
JP6
Mode
Mute
Spk(U2-U4)
JP8
J9 Left
Out
JP7
S3 HP Source
U2-U4
U5
Polarity
Lo
Hi
HP(U5)
C3 C2
++
R3
R5
J10
Stereo
HP Out
TP1
GND
Plug-N-PlayAudio Amplifier
Evaluation Platform
SLOP097 Rev. C.1
Stereo
In
Right
In Left
In
J6 In/Out VDD
F2
VR2 +
DC
Power
In/Out
Speaker
Output
Headphone
Output
Audio
Input
Power
Input
Batt
C1+
Right
Out
On Off Pwr
S1
TEXAS INSTRUMENTS 1997
R4

The TPA0242 Audio Power Amplifier Evaluation Module
3-3
Details
3.2 The TPA0242 Audio Power Amplifier Evaluation Module
The TPA0242 audio power amplifier evaluation module is powered by a
TPA0242 stereo power amplifier capable of delivering greater than 2 W of
continuouspowerperchannelinto3-Ωloads.TheamplifierICcanbeoperated
in either the BTL or single-ended output mode. The evaluation module
includes control inputs for shutdown, selection between two sets of stereo
inputs, and switching between single-ended and bridge-tied load output
modes.
The module can be used with the TI plug-n-play audio amplifier evaluation
platform (Figure 3–1) or wired directly into circuits or equipment. The module
has single in-line header connector pins mounted to the under side of the
board. These pins allow the module to be plugged into the TI platform, which
automatically makes all the signal input and output, power, and control
connections to the module.
The module connection pins are on 0.1-inch centers to allow easy use with
standard perf board and plug board-based prototyping systems. Or, the EVM
can be wired directly into existing circuits and equipment when used stand-
alone.
The module appears in Figure 3–2 and its schematic is shown in Figure 3–3.
Figure 3–2.TPA0242 EVM
GND
ROUT+
ROUT–
SE/BTL
S1
SHUTDOWN
GND
LOUT–
LOUT+
C11
C2
C13
VDD GND
L IN+
GND
L LINE–
L HP
VDD GND
R HP
R LINE–
GND
R IN+
C10
+
TPA00242 EVM Board SLOP275
U1
+
TEXAS
INSTRUMENTS
R2
R1 PCBEEP
C1
C12
C6 C5 C4
R3
S2
C7 C8 C9
C3
SHUTDOWN
R4
S3 S4
HP/LINE

The TPA0242 Audio Power Amplifier Evaluation Module
3-4
Details
Figure 3–3.TPA0242 EVM Schematic Diagram
R4
100 kΩ
C12
10 µF
GNDGND
RLINEINPCB ENABLE
SHUTDOWNVOLUME
ROUT+LOUT+
ROUT–LOUT–
SE/BTLLIN
PC–BEEPBYPASS
GNDGND
RHPINLLINEIN
VDD LHPIN
PVDD PVDD
CLKRIN
10
9
12
11
6
5
8
7
2
1
4
3
23
22
21
20
19
18
17
16
15
14
13
24
S1
L OUT –
L OUT +
L HP
VDD
C4
0.47 µFR3 0 Ω
R LINE –
R OUT +
R HP
VDD
ROUT–
SE/BTL
TPA0242
C12
0.47 µF
C9
0.47 µF
L IN +
C2
0.47 µF
R IN +
GND
C8
0.47 µF
C7
0.47 µF
L LINE –
CCW
VDD
R2
50 kΩ
VDD
R1
100 kΩ
C1
0.47 µF
SHUTDOWN
SHUTDOWN
C3
0.47 µF
C10
10 µF
GND
C5
0.1 µF
TP1
C11
0.47 µF
PCBEEP
VDD
S2
CW
C6
47 nF
S3
HP/LINE
S4
SE/BTL
3.2.1 TPA0242 Audio Amplifier IC
The TPA0242 audio amplifier IC (Figure 3–4) is a CMOS device intended
primarily for bridge-tied load (BTL) operation in battery-powered applications.
It is supplied in a very small 24-pin TSSOP thermal surface-mount package
and has been designed to operate from low supply voltages (between
approximately 4.5 V and 5.5 V). Typical applications include portable
computers and multimedia systems.
The IC includes two separate amplifier channels, each of which can operate
in either the bridged-tied load (BTL) mode or the single-ended mode as
selectedbytheSE/BTLpin. In theBTLmode,thelineinputsareautomatically
selected and the two output lines of each channel operate as mirror images
of each other for increased power. The speaker load is connected directly
across OUT+ and OUT–, and neither line is connected to ground. BTL
operation provides many benefits, including quadruple the output power of
single-ended operation and no need for bulky output coupling capacitors.
In the single-ended mode, the headphone inputs are automatically selected
and the speaker load is connected between the OUT+ terminal, through an
output coupling capacitor, to system ground. For more information, see the
TPA0242 amplifier IC data sheet, TI literature number SLOS287.
