Texas Instruments LM5013-Q1EVM User manual

User’s Guide
LM5013-Q1EVM User's Guide
ABSTRACT
The LM5013-Q1EVM has a 100-V DC/DC buck regulator that employs asynchronous rectification and achieves
high conversion efficiency. The EVM operates over a wide input voltage range of 15-V to 100-V to provide a
regulated 12-V output at 300-kHz switching frequency. The module design uses the LM5013-Q1 asynchronous
buck converter with wide input voltage (wide VIN) range, wide duty-cycle range, integrated high-side power
MOSFET, cycle-by-cycle overcurrent protection, and precision enable. With AEC-Q100 grade 1 automotive
qualification, the LM5013-Q1 is rated to operate over a junction temperature range of –40°C to +150°C. The
LM5013-Q1 is available in an 8-pin SO PowerPAD™ package to enable high density, low component count
DC/DC solutions.
Use the LM5013-Q1 with WEBENCH® Power Designer LM5013-Q1 with WEBENCH® Power Designer to
create a custom regulator design.
Table of Contents
1 General TI High Voltage Evaluation User Safety Guidelines.............................................................................................. 2
2 Overview..................................................................................................................................................................................4
2.1 LM5013-Q1 Asynchronous Buck Converter.......................................................................................................................4
3 LM5013-Q1 Evaluation Module..............................................................................................................................................5
3.1 Quick Start Procedure........................................................................................................................................................5
3.2 Detailed Descriptions......................................................................................................................................................... 6
4 Schematic................................................................................................................................................................................8
5 PCB Layout..............................................................................................................................................................................9
6 Bill of Materials..................................................................................................................................................................... 10
7 Performance Curves.............................................................................................................................................................11
8 Revision History................................................................................................................................................................... 12
List of Figures
Figure 2-1. LM5013-Q1 Pin Configuration (8-Pin SO Package with PowerPAD, Top View)........................................................4
Figure 2-2. LM5013-Q1 Buck Regulator Simplified Schematic................................................................................................... 4
Figure 3-1. LM5013-Q1 EVM Top View....................................................................................................................................... 5
Figure 4-1. LM5013-Q1 EVM Schematic.....................................................................................................................................8
Figure 5-1. Top Layer and Silkscreen Layer................................................................................................................................ 9
Figure 5-2. Mid-Layer 1 Ground Plane........................................................................................................................................ 9
Figure 5-3. Mid-Layer 2 Routing.................................................................................................................................................. 9
Figure 5-4. Bottom Layer Routing................................................................................................................................................9
Figure 7-1. Thermal Capture of EVM: VIN = 48-V, VOUT = 12-V, IOUT= 1.5-A.............................................................................11
List of Tables
Trademarks
PowerPAD™ is a trademark of Texas Instruments.
All trademarks are the property of their respective owners.
www.ti.com Table of Contents
SNVU754A – OCTOBER 2021 – REVISED NOVEMBER 2021
Submit Document Feedback
LM5013-Q1EVM User's Guide 1
Copyright © 2021 Texas Instruments Incorporated

1 General TI High Voltage Evaluation User Safety Guidelines
WARNING
Always follow TI’s set-up and application instructions, including use of all interface components within their
recommended electrical rated voltage and power limits. Always use electrical safety precautions to help ensure
your personal safety and the safety of those working around you. Contact TI’s Product Information Center http://
support.ti.com for further information.
Save all warnings and instructions for future reference.
Failure to follow warnings and instructions may result in personal injury, property damage, or death due
to electrical shock and/or burn hazards.
The term TI HV EVM refers to an electronic device typically provided as an open framed, unenclosed printed-
circuit board assembly. It is intended strictly for use in development laboratory environments, solely for qualified
professional users having training, expertise, and knowledge of electrical safety risks in development and
application of high-voltage electrical circuits. Any other use and/or application are strictly prohibited by Texas
Instruments. If you are not suitably qualified, you should immediately stop from further use of the HV EVM.
•Work Area Safety:
– Maintain a clean and orderly work area.
– Qualified observer(s) must be present anytime circuits are energized.
– Effective barriers and signage must be present in the area where the TI HV EVM and its interface
electronics are energized, indicating operation of accessible high voltages may be present, for the
purpose of protecting inadvertent access.
– All interface circuits, power supplies, evaluation modules, instruments, meters, scopes, and other related
apparatus used in a development environment exceeding 50 VRMS/75 VDC must be electrically located
within a protected Emergency Power Off (EPO) protected power strip.
– Use a stable and non-conductive work surface.
– Use adequately insulated clamps and wires to attach measurement probes and instruments. No freehand
testing whenever possible.
•Electrical Safety:
As a precautionary measure, it is always a good engineering practice to assume that the entire EVM may
have fully accessible and active high voltages.
– De-energize the TI HV EVM and all its inputs, outputs, and electrical loads before performing any
electrical or other diagnostic measurements. Confirm that TI HV EVM power has been safely de-
energized.
– With the EVM confirmed de-energized, proceed with required electrical circuit configurations, wiring,
measurement equipment hook-ups, and other application needs, while still assuming the EVM circuit and
measuring instruments are electrically live.
– When EVM readiness is complete, energize the EVM as intended.
WARNING
While the EVM is energized, never touch the EVM or its electrical circuits as they could be
at high voltages capable of causing electrical shock hazard.
General TI High Voltage Evaluation User Safety Guidelines www.ti.com
2LM5013-Q1EVM User's Guide SNVU754A – OCTOBER 2021 – REVISED NOVEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated

•Personal Safety:
– Wear personal protective equipment, for example, latex gloves and/or safety glasses with side shields or
protect EVM in an adequate lucent plastic box with interlocks from accidental touch.
•Limitation for Safe Use:
– EVMs are not to be used as all or part of a production unit.
Safety and Precautions
The EVM is designed for professionals who have received the appropriate technical training, and is designed
to operate from an AC power supply or a high-voltage DC supply. Please read this user guide and the safety-
related documents that come with the EVM package before operating this EVM.
CAUTION
!
Do not leave the EVM powered when unattended.
WARNING
Hot surface! Contact may cause burns. Do not touch! A fan should be utilized if full-power operation
is done. The EVM was constructed to highlight the small solutize size and as a result, is not as
thermally optimized as typical application PCB.
WARNING
High Voltage! Electric shock is possible when connecting board to live wire. Board should be
handled with care by a professional.
For safety, use of isolated test equipment with overvoltage and overcurrent protection is highly
recommended.
www.ti.com General TI High Voltage Evaluation User Safety Guidelines
SNVU754A – OCTOBER 2021 – REVISED NOVEMBER 2021
Submit Document Feedback
LM5013-Q1EVM User's Guide 3
Copyright © 2021 Texas Instruments Incorporated

2 Overview
2.1 LM5013-Q1 Asynchronous Buck Converter
The LM5013-Q1 step-down switching converter features all the functions needed to implement a low-cost,
high-efficiency buck regulator capable of supplying 3.5-A load current. An adaptive constant on-time (COT)
control scheme and PFM at light loads enables low standby current. Various features incorporated for enhanced
reliability and safety include cycle-by-cycle peak current limit, thermal shutdown protection, internal output
voltage soft-start timer, precision enable , and an open-drain PGOOD indicator for sequencing and fault
reporting.
Figure 2-1 shows the pin configuration of the LM5013-Q1. Figure 2-2 presents the regulator schematic for quick
reference.
Figure 2-1. LM5013-Q1 Pin Configuration (8-Pin SO Package with PowerPAD, Top View)
Figure 2-2. LM5013-Q1 Buck Regulator Simplified Schematic
Overview www.ti.com
4LM5013-Q1EVM User's Guide SNVU754A – OCTOBER 2021 – REVISED NOVEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated

3 LM5013-Q1 Evaluation Module
The LM5013-Q1EVM is configured to deliver 12-V at up to 3.5-A at a switching frequency of 300-kHz. As
shown in LM5013-Q1EVM schematic, a type 3 ripple generation circuit is used to generate the appropriate
voltage ripple on FB. This circuit uses an RC network (consisting of "R4" and "C4") between SW and VOUT
to create a triangular ramp. This triangular ramp is then AC coupled into the feedback node with capacitor
"C16." This method is best suited for applications where low output voltage ripple is required and where ceramic
output capacitors are used (since it is not using the output voltage to generate the ripple signal). If additional
output ripple can be managed, a possibility for reduced BOM count can be achieved with type 1 or type 2
compensation. Reference the data sheet for these implementations.
3.1 Quick Start Procedure
1. Connect the voltage supply between VIN and GND connectors using short wires.
2. Connect the load of the converter between VOUT and GND connectors using short wires.
3. Set the supply voltage (VVIN) at an appropriate level between 15-V to 100-V. Set the current limit of the
supply to an appropriate level as well.
4. Turn on the power supply. The EVM powers up and provides VOUT = 12-V.
5. Monitor the output voltage while increasing the load current to max.
See Figure 3-1 for the location of the connectors.
Figure 3-1. LM5013-Q1 EVM Top View
CAUTION
Caution Hot surface.
Contact may cause burns.
Do not touch.
www.ti.com LM5013-Q1 Evaluation Module
SNVU754A – OCTOBER 2021 – REVISED NOVEMBER 2021
Submit Document Feedback
LM5013-Q1EVM User's Guide 5
Copyright © 2021 Texas Instruments Incorporated

3.2 Detailed Descriptions
This section describes the connectors and the test points on the EVM and how to properly connect, set up and
use the LM5013-Q1EVM. See Figure 3-1 for a top view of the EVM.
VOUT Output voltage of the converter.
VOUT connector and test point connected to the power inductor and the output capacitors. Connect
the loading device between VOUT and GND connectors to provide loading to the regulator. Connect
the loading device to the board with short wires to handle the DC output current.
GND Ground of the converter.
It is connected to the GND as well as the return terminals of the input and output capacitors. GND
is the current return path for both supply voltage and load. Connect to supply and load grounds with
short wires.
VIN Input voltage to the converter.
VIN connector and test point connects to the input capacitors and the VIN pin of the LM5013-Q1.
Connect the supply voltage from a power supply or a battery between the VIN and GND connectors.
The voltage range should be higher than 6 V for the device to be active. VVIN higher than 15-V
provides a regulated 12-V output voltage. To avoid damaging the device VVIN should be no greater
than 100-V. The current limit on the supply should be high enough to provide the needed supply
current when the output is fully loaded. The supply voltage should be connected to the board with
short wires. C7 is populated to avoid oscillation between the cable parasitic inductance and the
low-ESR input ceramic capacitors.
VIN-EMI Input voltage to input filter of the converter.
The supply voltage should be connected to the board with short wires.
The inductor/ferrite in series with input path have some DCR associated with them. Verifying
datasheet specification should be done by shorting these components.
GND-
EMI
Ground connection near the input filter.
This is the current return path for the supply connected to VIN-EMI. It provides a direct connection
to the input filter capacitors to filter conducted noise generated by the converter. Use VIN-EMI and
GND-EMI connections at the input filter to minimize EMI.
Input
Filter
EMI mitigation.
The input filter consists of a filter inductor, ferrite bead and ceramic capacitors. An electrolytic
capacitor is included for bulk energy storage and input parallel damping.
EN/
UVLO
Test point to monitor the EN/UVLO pin of the device.
This test point is to monitor the voltage on the device EN/UVLO pin.
EN/
UVLO
Set EN/UVLO
By default, device is hard-enabled. Device enable/disable voltage would correspond to typical
VEN-RISING and VEN-FALLING datasheet specification.
The enable/disable voltage can be varied by calculating for bottom UVLO resistor RUV2.
Calculate the lower UVLO resistor, RUV2 (R6), based on the desired turn-on voltage of 6 V and the
selected upper UVLO resistor, RUV1 (R5) , of 1 MΩ using Equation 1.
UV2 UV1
IN(on)
1.5 V 1.5 V
R R 1M 332k
V 1.5 V 6 V 1.5 V
˜ ˜ : :
 
(1)
LM5013-Q1 Evaluation Module www.ti.com
6LM5013-Q1EVM User's Guide SNVU754A – OCTOBER 2021 – REVISED NOVEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated

PGOOD PGOOD
This flag indicates whether the output voltage has reached its regulation level. LM5013-Q1 PGOOD
is an open-drain output that is tied to VOUT through pull-up resistor.
www.ti.com LM5013-Q1 Evaluation Module
SNVU754A – OCTOBER 2021 – REVISED NOVEMBER 2021
Submit Document Feedback
LM5013-Q1EVM User's Guide 7
Copyright © 2021 Texas Instruments Incorporated

4 Schematic
Figure 4-1. LM5013-Q1 EVM Schematic
Note the ripple injection circuit was designed for minimum ripple at the nominal input voltage of the design of 48 V. The circuit should be re-designed if
the nominal voltage is lower, or make sure ensure there is sufficient ripple injection for stability at lower input voltages (< 30 V).
Schematic www.ti.com
8LM5013-Q1EVM User's Guide SNVU754A – OCTOBER 2021 – REVISED NOVEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated

5 PCB Layout
Top Layer and Silkscreen Layer through Bottom Layer Routing show the board layout for the LM5013-Q1EVM.
The EVM offers resistors, capacitors, and test points to configure the output voltage, precision enable, and
switching frequency.
The 8-pin SO PowerPAD package offers an exposed thermal pad, which must be soldered to the copper landing
on the PCB for optimal thermal performance. The PCB consists of a 4-layer design. There are 2-oz copper
planes on the top and bottom and 1-oz copper mid-layer planes to dissipate heat with an array of thermal vias
under the thermal pad to connect to all four layers.
Test points have been provided for ease of use to connect the power supply, required load, and to monitor critical
signals.
Figure 5-1. Top Layer and Silkscreen Layer Figure 5-2. Mid-Layer 1 Ground Plane
Figure 5-3. Mid-Layer 2 Routing Figure 5-4. Bottom Layer Routing
www.ti.com PCB Layout
SNVU754A – OCTOBER 2021 – REVISED NOVEMBER 2021
Submit Document Feedback
LM5013-Q1EVM User's Guide 9
Copyright © 2021 Texas Instruments Incorporated

6 Bill of Materials
Designator Quantity Description PartNumber
C2, C11, C13 3 CAP, CERM, 0.1 µF, 100 V,+/- 10%, X7R, AEC-Q200 Grade
1, 0603
HMK107B7104KAHT
C3 1 Chip Capacitor, 2.2 nF, +/- 10%, 50 V, -55 to 125 degC,
0402 (1005 Metric), RoHS, Tape and Reel
GRM155R71H222KA01D
C4 1 CAP, CERM, 3300 pF, 100 V, +/- 10%, X7R, AEC-Q200
Grade 1, 0603
CEU3E2X7R2A332K080AE
C5, C6 2 CAP, CERM, 22 µF, 25 V,+/- 10%, X7R, 1210 CL32B226KAJNFNE
C7 1 CAP, AL, 33 uF, 100 V, +/- 20%, 0.7 ohm, AEC-Q200 Grade
2, SMD
EEE-FK2A330P
C8, C9 2 CAP, CERM, 4.7 uF, 100 V, +/- 10%, X7S, 1210 C3225X7S2A475K200AE
C10, C12 2 CAP, CERM, 4.7 uF, 100 V, +/- 10%, X7S, AEC-Q200 Grade
1, 1210
CGA6M3X7S2A475K200AB
C16 1 Cap Ceramic 56pF 50V C0G 5% SMD 0402 125C Paper
T/R
CL05C560JB5NNNC
D1 1 Diode Schottky 120V 8A 3-Pin(2+Tab) SMPC T/R V8P12-M3/86A
J1, J2 2 Terminal Block, 3.5mm Pitch, 2x1, TH ED555/2DS
L1 1 22µH Shielded Molded Inductor 3.5A 74mOhm Max
Nonstandard
74437368220
L2 1 Ferrite Bead, 220 ohm @ 100 MHz, 4 A, 1206 FBMH3216HM221NTV
L3 1 Shielded Power Inductors XGL4020-822MEC
R2 1 RES, 0, 0%, 0.2 W, AEC-Q200 Grade 0, 0402 CRCW04020000Z0EDHP
R4 1 RES, 453 k, 1%, 0.1 W, 0603 RC0603FR-07453KL
R5 1 RES, 1.00 M, 1%, 0.063 W, AEC-Q200 Grade 0, 0402 CRCW04021M00FKED
R6 1 RES, 330 k, 1%, 0.063 W, AEC-Q200 Grade 0, 0402 CRCW0402330KFKED
R7 1 RES, 102 k, 1%, 0.063 W, AEC-Q200 Grade 0, 0402 CRCW0402102KFKED
R8 1 RES, 453 k, 1%, 0.063 W, AEC-Q200 Grade 0, 0402 CRCW0402453KFKED
R9 1 RES, 49.9 k, 1%, 0.063 W, AEC-Q200 Grade 0, 0402 CRCW040249K9FKED
R10 1 RES, 100 k, 1%, 0.063 W, 0402 RC1005F104CS
TP1, TP2 2 Test Point, Multipurpose, White, TH 5012
U1 1 100-V Input, 3.5-A Non-Synchronous Buck DC/DC
Converter with Ultra-low IQ
LM5013QDDARQ1
C1 0 CAP, CERM, 56 pF, 100 V, +/- 5%, C0G/NP0, 0603 GRM1885C2A560JA01D
C14, C15 0 CAP, CERM, 22 uF, 25 V, +/- 10%, X7R, AEC-Q200 Grade
1, 1210
TMK325B7226KMHT
C17 0 Chip Capacitor, 100 pF, +/- 10%, 50 V, -55 to 125 degC,
0402 (1005 Metric), RoHS, Tape and Reel
C1005C0G1H101K050BA
R1, R3 0 RES, 1.00, 0.5%, 0.1 W, 0603 RT0603DRE071RL
Bill of Materials www.ti.com
10 LM5013-Q1EVM User's Guide SNVU754A – OCTOBER 2021 – REVISED NOVEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated

7 Performance Curves
For performance curves, in addition to those shown in Figure 7-1, please visit LM5013-Q1 data sheet's
application section. Applications curves would be taken on LM5013-Q1 EVM unless otherwise specified.
Figure 7-1. Thermal Capture of EVM: VIN = 48-V, VOUT = 12-V, IOUT= 1.5-A
Note the design was optimized for small size and as a result, the thermal performance of the EVM does not
reflect expected system performance with larger copper area. If continuous evaluation is to be done at higher
input voltage, load current, or both, a fan must be used to make sure the IC does not hit its thermal limit.
Ensure the hot temperature identifiers are noticed on the PCB and care is taken in the handling of the PCB.
www.ti.com Performance Curves
SNVU754A – OCTOBER 2021 – REVISED NOVEMBER 2021
Submit Document Feedback
LM5013-Q1EVM User's Guide 11
Copyright © 2021 Texas Instruments Incorporated

8 Revision History
NOTE: Page numbers for previous revisions may differ from page numbers in the current version.
Changes from Revision * (October 2021) to Revision A (November 2021) Page
• Updated Section 4 ............................................................................................................................................. 8
• Updated Section 7 ............................................................................................................................................11
Revision History www.ti.com
12 LM5013-Q1EVM User's Guide SNVU754A – OCTOBER 2021 – REVISED NOVEMBER 2021
Submit Document Feedback
Copyright © 2021 Texas Instruments Incorporated

STANDARD TERMS FOR EVALUATION MODULES
1. Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, and/or
documentation which may be provided together or separately (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance
with the terms set forth herein. User's acceptance of the EVM is expressly subject to the following terms.
1.1 EVMs are intended solely for product or software developers for use in a research and development setting to facilitate feasibility
evaluation, experimentation, or scientific analysis of TI semiconductors products. EVMs have no direct function and are not
finished products. EVMs shall not be directly or indirectly assembled as a part or subassembly in any finished product. For
clarification, any software or software tools provided with the EVM (“Software”) shall not be subject to the terms and conditions
set forth herein but rather shall be subject to the applicable terms that accompany such Software
1.2 EVMs are not intended for consumer or household use. EVMs may not be sold, sublicensed, leased, rented, loaned, assigned,
or otherwise distributed for commercial purposes by Users, in whole or in part, or used in any finished product or production
system.
2Limited Warranty and Related Remedies/Disclaimers:
2.1 These terms do not apply to Software. The warranty, if any, for Software is covered in the applicable Software License
Agreement.
2.2 TI warrants that the TI EVM will conform to TI's published specifications for ninety (90) days after the date TI delivers such EVM
to User. Notwithstanding the foregoing, TI shall not be liable for a nonconforming EVM if (a) the nonconformity was caused by
neglect, misuse or mistreatment by an entity other than TI, including improper installation or testing, or for any EVMs that have
been altered or modified in any way by an entity other than TI, (b) the nonconformity resulted from User's design, specifications
or instructions for such EVMs or improper system design, or (c) User has not paid on time. Testing and other quality control
techniques are used to the extent TI deems necessary. TI does not test all parameters of each EVM.
User's claims against TI under this Section 2 are void if User fails to notify TI of any apparent defects in the EVMs within ten (10)
business days after delivery, or of any hidden defects with ten (10) business days after the defect has been detected.
2.3 TI's sole liability shall be at its option to repair or replace EVMs that fail to conform to the warranty set forth above, or credit
User's account for such EVM. TI's liability under this warranty shall be limited to EVMs that are returned during the warranty
period to the address designated by TI and that are determined by TI not to conform to such warranty. If TI elects to repair or
replace such EVM, TI shall have a reasonable time to repair such EVM or provide replacements. Repaired EVMs shall be
warranted for the remainder of the original warranty period. Replaced EVMs shall be warranted for a new full ninety (90) day
warranty period.
WARNING
Evaluation Kits are intended solely for use by technically qualified,
professional electronics experts who are familiar with the dangers
and application risks associated with handling electrical mechanical
components, systems, and subsystems.
User shall operate the Evaluation Kit within TI’s recommended
guidelines and any applicable legal or environmental requirements
as well as reasonable and customary safeguards. Failure to set up
and/or operate the Evaluation Kit within TI’s recommended
guidelines may result in personal injury or death or property
damage. Proper set up entails following TI’s instructions for
electrical ratings of interface circuits such as input, output and
electrical loads.
NOTE:
EXPOSURE TO ELECTROSTATIC DISCHARGE (ESD) MAY CAUSE DEGREDATION OR FAILURE OF THE EVALUATION
KIT; TI RECOMMENDS STORAGE OF THE EVALUATION KIT IN A PROTECTIVE ESD BAG.

www.ti.com
2
3Regulatory Notices:
3.1 United States
3.1.1 Notice applicable to EVMs not FCC-Approved:
FCC NOTICE: This kit is designed to allow product developers to evaluate electronic components, circuitry, or software
associated with the kit to determine whether to incorporate such items in a finished product and software developers to write
software applications for use with the end product. This kit is not a finished product and when assembled may not be resold or
otherwise marketed unless all required FCC equipment authorizations are first obtained. Operation is subject to the condition
that this product not cause harmful interference to licensed radio stations and that this product accept harmful interference.
Unless the assembled kit is designed to operate under part 15, part 18 or part 95 of this chapter, the operator of the kit must
operate under the authority of an FCC license holder or must secure an experimental authorization under part 5 of this chapter.
3.1.2 For EVMs annotated as FCC – FEDERAL COMMUNICATIONS COMMISSION Part 15 Compliant:
CAUTION
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to
operate the equipment.
FCC Interference Statement for Class A EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
FCC Interference Statement for Class B EVM devices
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
3.2 Canada
3.2.1 For EVMs issued with an Industry Canada Certificate of Conformance to RSS-210 or RSS-247
Concerning EVMs Including Radio Transmitters:
This device complies with Industry Canada license-exempt RSSs. Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may
cause undesired operation of the device.
Concernant les EVMs avec appareils radio:
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence. L'exploitation
est autorisée aux deux conditions suivantes: (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de l'appareil doit
accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
Concerning EVMs Including Detachable Antennas:
Under Industry Canada regulations, this radio transmitter may only operate using an antenna of a type and maximum (or lesser)
gain approved for the transmitter by Industry Canada. To reduce potential radio interference to other users, the antenna type
and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for
successful communication. This radio transmitter has been approved by Industry Canada to operate with the antenna types
listed in the user guide with the maximum permissible gain and required antenna impedance for each antenna type indicated.
Antenna types not included in this list, having a gain greater than the maximum gain indicated for that type, are strictly prohibited
for use with this device.

www.ti.com
3
Concernant les EVMs avec antennes détachables
Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et
d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage
radioélectrique à l'intention des autres utilisateurs, il faut choisir le type d'antenne et son gain de sorte que la puissance isotrope
rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. Le
présent émetteur radio a été approuvé par Industrie Canada pour fonctionner avec les types d'antenne énumérés dans le
manuel d’usage et ayant un gain admissible maximal et l'impédance requise pour chaque type d'antenne. Les types d'antenne
non inclus dans cette liste, ou dont le gain est supérieur au gain maximal indiqué, sont strictement interdits pour l'exploitation de
l'émetteur
3.3 Japan
3.3.1 Notice for EVMs delivered in Japan: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page 日本国内に
輸入される評価用キット、ボードについては、次のところをご覧ください。
http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_01.page
3.3.2 Notice for Users of EVMs Considered “Radio Frequency Products” in Japan: EVMs entering Japan may not be certified
by TI as conforming to Technical Regulations of Radio Law of Japan.
If User uses EVMs in Japan, not certified to Technical Regulations of Radio Law of Japan, User is required to follow the
instructions set forth by Radio Law of Japan, which includes, but is not limited to, the instructions below with respect to EVMs
(which for the avoidance of doubt are stated strictly for convenience and should be verified by User):
1. Use EVMs in a shielded room or any other test facility as defined in the notification #173 issued by Ministry of Internal
Affairs and Communications on March 28, 2006, based on Sub-section 1.1 of Article 6 of the Ministry’s Rule for
Enforcement of Radio Law of Japan,
2. Use EVMs only after User obtains the license of Test Radio Station as provided in Radio Law of Japan with respect to
EVMs, or
3. Use of EVMs only after User obtains the Technical Regulations Conformity Certification as provided in Radio Law of Japan
with respect to EVMs. Also, do not transfer EVMs, unless User gives the same notice above to the transferee. Please note
that if User does not follow the instructions above, User will be subject to penalties of Radio Law of Japan.
【無線電波を送信する製品の開発キットをお使いになる際の注意事項】 開発キットの中には技術基準適合証明を受けて
いないものがあります。 技術適合証明を受けていないもののご使用に際しては、電波法遵守のため、以下のいずれかの
措置を取っていただく必要がありますのでご注意ください。
1. 電波法施行規則第6条第1項第1号に基づく平成18年3月28日総務省告示第173号で定められた電波暗室等の試験設備でご使用
いただく。
2. 実験局の免許を取得後ご使用いただく。
3. 技術基準適合証明を取得後ご使用いただく。
なお、本製品は、上記の「ご使用にあたっての注意」を譲渡先、移転先に通知しない限り、譲渡、移転できないものとします。
上記を遵守頂けない場合は、電波法の罰則が適用される可能性があることをご留意ください。 日本テキサス・イ
ンスツルメンツ株式会社
東京都新宿区西新宿６丁目２４番１号
西新宿三井ビル
3.3.3 Notice for EVMs for Power Line Communication: Please see http://www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page
電力線搬送波通信についての開発キットをお使いになる際の注意事項については、次のところをご覧ください。http:/
/www.tij.co.jp/lsds/ti_ja/general/eStore/notice_02.page
3.4 European Union
3.4.1 For EVMs subject to EU Directive 2014/30/EU (Electromagnetic Compatibility Directive):
This is a class A product intended for use in environments other than domestic environments that are connected to a
low-voltage power-supply network that supplies buildings used for domestic purposes. In a domestic environment this
product may cause radio interference in which case the user may be required to take adequate measures.

www.ti.com
4
4EVM Use Restrictions and Warnings:
4.1 EVMS ARE NOT FOR USE IN FUNCTIONAL SAFETY AND/OR SAFETY CRITICAL EVALUATIONS, INCLUDING BUT NOT
LIMITED TO EVALUATIONS OF LIFE SUPPORT APPLICATIONS.
4.2 User must read and apply the user guide and other available documentation provided by TI regarding the EVM prior to handling
or using the EVM, including without limitation any warning or restriction notices. The notices contain important safety information
related to, for example, temperatures and voltages.
4.3 Safety-Related Warnings and Restrictions:
4.3.1 User shall operate the EVM within TI’s recommended specifications and environmental considerations stated in the user
guide, other available documentation provided by TI, and any other applicable requirements and employ reasonable and
customary safeguards. Exceeding the specified performance ratings and specifications (including but not limited to input
and output voltage, current, power, and environmental ranges) for the EVM may cause personal injury or death, or
property damage. If there are questions concerning performance ratings and specifications, User should contact a TI
field representative prior to connecting interface electronics including input power and intended loads. Any loads applied
outside of the specified output range may also result in unintended and/or inaccurate operation and/or possible
permanent damage to the EVM and/or interface electronics. Please consult the EVM user guide prior to connecting any
load to the EVM output. If there is uncertainty as to the load specification, please contact a TI field representative.
During normal operation, even with the inputs and outputs kept within the specified allowable ranges, some circuit
components may have elevated case temperatures. These components include but are not limited to linear regulators,
switching transistors, pass transistors, current sense resistors, and heat sinks, which can be identified using the
information in the associated documentation. When working with the EVM, please be aware that the EVM may become
very warm.
4.3.2 EVMs are intended solely for use by technically qualified, professional electronics experts who are familiar with the
dangers and application risks associated with handling electrical mechanical components, systems, and subsystems.
User assumes all responsibility and liability for proper and safe handling and use of the EVM by User or its employees,
affiliates, contractors or designees. User assumes all responsibility and liability to ensure that any interfaces (electronic
and/or mechanical) between the EVM and any human body are designed with suitable isolation and means to safely
limit accessible leakage currents to minimize the risk of electrical shock hazard. User assumes all responsibility and
liability for any improper or unsafe handling or use of the EVM by User or its employees, affiliates, contractors or
designees.
4.4 User assumes all responsibility and liability to determine whether the EVM is subject to any applicable international, federal,
state, or local laws and regulations related to User’s handling and use of the EVM and, if applicable, User assumes all
responsibility and liability for compliance in all respects with such laws and regulations. User assumes all responsibility and
liability for proper disposal and recycling of the EVM consistent with all applicable international, federal, state, and local
requirements.
5. Accuracy of Information: To the extent TI provides information on the availability and function of EVMs, TI attempts to be as accurate
as possible. However, TI does not warrant the accuracy of EVM descriptions, EVM availability or other information on its websites as
accurate, complete, reliable, current, or error-free.
6. Disclaimers:
6.1 EXCEPT AS SET FORTH ABOVE, EVMS AND ANY MATERIALS PROVIDED WITH THE EVM (INCLUDING, BUT NOT
LIMITED TO, REFERENCE DESIGNS AND THE DESIGN OF THE EVM ITSELF) ARE PROVIDED "AS IS" AND "WITH ALL
FAULTS." TI DISCLAIMS ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, REGARDING SUCH ITEMS, INCLUDING BUT
NOT LIMITED TO ANY EPIDEMIC FAILURE WARRANTY OR IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS
FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT OF ANY THIRD PARTY PATENTS, COPYRIGHTS, TRADE
SECRETS OR OTHER INTELLECTUAL PROPERTY RIGHTS.
6.2 EXCEPT FOR THE LIMITED RIGHT TO USE THE EVM SET FORTH HEREIN, NOTHING IN THESE TERMS SHALL BE
CONSTRUED AS GRANTING OR CONFERRING ANY RIGHTS BY LICENSE, PATENT, OR ANY OTHER INDUSTRIAL OR
INTELLECTUAL PROPERTY RIGHT OF TI, ITS SUPPLIERS/LICENSORS OR ANY OTHER THIRD PARTY, TO USE THE
EVM IN ANY FINISHED END-USER OR READY-TO-USE FINAL PRODUCT, OR FOR ANY INVENTION, DISCOVERY OR
IMPROVEMENT, REGARDLESS OF WHEN MADE, CONCEIVED OR ACQUIRED.
7. USER'S INDEMNITY OBLIGATIONS AND REPRESENTATIONS. USER WILL DEFEND, INDEMNIFY AND HOLD TI, ITS
LICENSORS AND THEIR REPRESENTATIVES HARMLESS FROM AND AGAINST ANY AND ALL CLAIMS, DAMAGES, LOSSES,
EXPENSES, COSTS AND LIABILITIES (COLLECTIVELY, "CLAIMS") ARISING OUT OF OR IN CONNECTION WITH ANY
HANDLING OR USE OF THE EVM THAT IS NOT IN ACCORDANCE WITH THESE TERMS. THIS OBLIGATION SHALL APPLY
WHETHER CLAIMS ARISE UNDER STATUTE, REGULATION, OR THE LAW OF TORT, CONTRACT OR ANY OTHER LEGAL
THEORY, AND EVEN IF THE EVM FAILS TO PERFORM AS DESCRIBED OR EXPECTED.

www.ti.com
5
8. Limitations on Damages and Liability:
8.1 General Limitations. IN NO EVENT SHALL TI BE LIABLE FOR ANY SPECIAL, COLLATERAL, INDIRECT, PUNITIVE,
INCIDENTAL, CONSEQUENTIAL, OR EXEMPLARY DAMAGES IN CONNECTION WITH OR ARISING OUT OF THESE
TERMS OR THE USE OF THE EVMS , REGARDLESS OF WHETHER TI HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. EXCLUDED DAMAGES INCLUDE, BUT ARE NOT LIMITED TO, COST OF REMOVAL OR
REINSTALLATION, ANCILLARY COSTS TO THE PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES, RETESTING,
OUTSIDE COMPUTER TIME, LABOR COSTS, LOSS OF GOODWILL, LOSS OF PROFITS, LOSS OF SAVINGS, LOSS OF
USE, LOSS OF DATA, OR BUSINESS INTERRUPTION. NO CLAIM, SUIT OR ACTION SHALL BE BROUGHT AGAINST TI
MORE THAN TWELVE (12) MONTHS AFTER THE EVENT THAT GAVE RISE TO THE CAUSE OF ACTION HAS
OCCURRED.
8.2 Specific Limitations. IN NO EVENT SHALL TI'S AGGREGATE LIABILITY FROM ANY USE OF AN EVM PROVIDED
HEREUNDER, INCLUDING FROM ANY WARRANTY, INDEMITY OR OTHER OBLIGATION ARISING OUT OF OR IN
CONNECTION WITH THESE TERMS, , EXCEED THE TOTAL AMOUNT PAID TO TI BY USER FOR THE PARTICULAR
EVM(S) AT ISSUE DURING THE PRIOR TWELVE (12) MONTHS WITH RESPECT TO WHICH LOSSES OR DAMAGES ARE
CLAIMED. THE EXISTENCE OF MORE THAN ONE CLAIM SHALL NOT ENLARGE OR EXTEND THIS LIMIT.
9. Return Policy. Except as otherwise provided, TI does not offer any refunds, returns, or exchanges. Furthermore, no return of EVM(s)
will be accepted if the package has been opened and no return of the EVM(s) will be accepted if they are damaged or otherwise not in
a resalable condition. If User feels it has been incorrectly charged for the EVM(s) it ordered or that delivery violates the applicable
order, User should contact TI. All refunds will be made in full within thirty (30) working days from the return of the components(s),
excluding any postage or packaging costs.
10. Governing Law: These terms and conditions shall be governed by and interpreted in accordance with the laws of the State of Texas,
without reference to conflict-of-laws principles. User agrees that non-exclusive jurisdiction for any dispute arising out of or relating to
these terms and conditions lies within courts located in the State of Texas and consents to venue in Dallas County, Texas.
Notwithstanding the foregoing, any judgment may be enforced in any United States or foreign court, and TI may seek injunctive relief
in any United States or foreign court.
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2019, Texas Instruments Incorporated

IMPORTANT NOTICE AND DISCLAIMER
TI PROVIDES TECHNICAL AND RELIABILITY DATA (INCLUDING DATA SHEETS), DESIGN RESOURCES (INCLUDING REFERENCE
DESIGNS), APPLICATION OR OTHER DESIGN ADVICE, WEB TOOLS, SAFETY INFORMATION, AND OTHER RESOURCES “AS IS”
AND WITH ALL FAULTS, AND DISCLAIMS ALL WARRANTIES, EXPRESS AND IMPLIED, INCLUDING WITHOUT LIMITATION ANY
IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR NON-INFRINGEMENT OF THIRD
PARTY INTELLECTUAL PROPERTY RIGHTS.
These resources are intended for skilled developers designing with TI products. You are solely responsible for (1) selecting the appropriate
TI products for your application, (2) designing, validating and testing your application, and (3) ensuring your application meets applicable
standards, and any other safety, security, regulatory or other requirements.
These resources are subject to change without notice. TI grants you permission to use these resources only for development of an
application that uses the TI products described in the resource. Other reproduction and display of these resources is prohibited. No license
is granted to any other TI intellectual property right or to any third party intellectual property right. TI disclaims responsibility for, and you
will fully indemnify TI and its representatives against, any claims, damages, costs, losses, and liabilities arising out of your use of these
resources.
TI’s products are provided subject to TI’s Terms of Sale or other applicable terms available either on ti.com or provided in conjunction with
such TI products. TI’s provision of these resources does not expand or otherwise alter TI’s applicable warranties or warranty disclaimers for
TI products.
TI objects to and rejects any additional or different terms you may have proposed. IMPORTANT NOTICE
Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265
Copyright © 2021, Texas Instruments Incorporated
