Texim Europe RTC-900B User manual

Rugged Tablet Computer RTC-900B
RTC-900B
Intel®AtomTM E3825
1.33GHz Dual Core Processor
10.1” WXGA Color LCD
1 Micro-USB3.0, 1 Micro-HDMI
RTC-900B Manual 1st Ed
March 2, 2015
DISTRIBUTED BY TEXIM EUROPE

Rugged Tablet Computer RTC-900B
Copyright Notice
This document is copyrighted, 2015. All rights are reserved. The
original manufacturer reserves the right to make improvements to
the products described in this manual at any time without notice.
No part of this manual may be reproduced, copied, translated, or
transmitted in any form or by any means without the prior written
permission of the original manufacturer. Information provided in
this manual is intended to be accurate and reliable. However, the
original manufacturer assumes no responsibility for its use, or for
any infringements upon the rights of third parties that may result
from its use.
The material in this document is for product information only and is
subject to change without notice. While reasonable efforts have
been made in the preparation of this document to assure its
accuracy, AAEON assumes no liabilities resulting from errors or
omissions in this document, or from the use of the information
contained herein.
AAEON reserves the right to make changes in the product design
without notice to its users.
i
DISTRIBUTED BY TEXIM EUROPE

Rugged Tablet Computer RTC-900B
Acknowledgments
All other products’ name or trademarks are properties of their
respective owners.
•Intel®and AtomTM are trademarks of Intel®Corporation.
•Atom™is a registered trademark of Intel.
•Adobe®Flash®Player Support
All other product names or trademarks are properties of their
respective owners.
ii
DISTRIBUTED BY TEXIM EUROPE

Rugged Tablet Computer RTC-900B
Packing List
Before you begin operating your tablet computer, please make sure
that the following materials are enclosed:
•1 RTC-900B Rugged Tablet with Windows® Embedded
8.1 Industrial Pro
•1 AC Adapter
•1 DVD-ROM for USB driver & manual
(in PDF format)
If any of these items could be missing or damaged, please contact
your distributor or sales representative immediately.
iii
DISTRIBUTED BY TEXIM EUROPE

Rugged Tablet Computer RTC-900B
Options
The following items are normally optional, but some vendors may
include them in the standard package. Some items may not be
available in some countries, or some vendors may choose not to carry
all the times.
•3G Modem module
Caution:Purchase accessories that are approved for use with your
Rugged Tablet Computer only. The above accessories are proprietary
items. Our system vendor can obtain these approved accessories. If
you use items that are not approved for use with this Rugged Tablet
Computer, you may cause it to malfunction, emit or receive
electro-magnetic radiation in excess of local regulations. For
non-proprietary accessories such as PC cards or printers, ensure that
the accessory functions properly with your Rugged Tablet Computer
before making the purchase. Your system vendor may be able to
recommend reliable brands and models.
iv
DISTRIBUTED BY TEXIM EUROPE

Rugged Tablet Computer RTC-900B
Safety & Maintenance
You can use your Rugged Tablet Computer under a wide range of
environmental conditions. However, to ensure long use and continued
high performance, consider the following factors when setting up your
Rugged Tablet Computer (RTC):
Follow all warnings and instructions noted in this documentation
and in the Windows Help program.
The input voltage range between the wall outlet and this adapter is
AC 100V–240V, and the output voltage of this adapter is DC 12V,
4A.
The first time you use your RTC, we recommend that you carefully
read the Making Connections section of this manual and initialize
the battery to ensure optimum battery performance.
Unplug the RTC from the power outlet before cleaning. Use a damp
cloth for cleaning. Do not use aerosols, solvents, or strong
detergents.
Slots and openings on the enclosure are for cooling purposes. Do
not block or cover these openings or the system could overheat. Do
not use or store the RTC near a source of heat or dust.
On the base or rear panel of this RTC, there is a label with
information on the power requirements of this system. These
requirements must be followed. If you are unsure of your local
power supply, consult your dealer or local Power Company.
Do not step on or place anything on the power cord.
v
DISTRIBUTED BY TEXIM EUROPE

Rugged Tablet Computer RTC-900B
If you use the RTC with an extension cord, ensure that the total
ampere ratings of all the devices sharing the extension do not
exceed the rating of the extension cord or the rating of the wall
outlet.
Never push foreign objects into the RTC through any of the slots
or openings. Dangerous voltages are present, which could
cause electric shock or fire, or damage sensitive components.
vi
DISTRIBUTED BY TEXIM EUROPE

Rugged Tablet Computer RTC-900B
FCC
This device complies with Part 15 FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received including interference that may cause
undesired operation.
Caution:
There is a danger of explosion if the battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer. Dispose of used batteries according to the
manufacturer’s instructions and your local government’s recycling or
disposal directives.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to operate
the equipment.
Attention:
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte.
Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le
constructeur. Recycler les batteries usées en accord avec les instructions du
fabricant et les directives gouvernementales de recyclage.
Les modifications non approuvées de façon explicite par l’organisme
responsable de la conformité pourraient annuler le droit de l’utilisateur à
opérer l’équipement.
vii
DISTRIBUTED BY TEXIM EUROPE

Rugged Tablet Computer RTC-900B
China RoHS Requirements
产品中有毒有害物质或元素名称及含量
AAEON Panel PC/ Workstation
部件名称
有毒有害物质或元素
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr(VI))
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印刷电路板
及其电子组件
×
○
○
○
○
○
外部信号
连接器及线材
×
○
○
○
○
○
外壳
×
○
○
○
○
○
中央处理器
与内存
×
○
○
○
○
○
硬盘
×
○
○
○
○
○
液晶模块
×
○
○
○
○
○
光驱
×
○
○
○
○
○
触控模块
×
○
○
○
○
○
电源
×
○
○
○
○
○
O：表示该有毒有害物质在该部件所有均质材料中的含量均在
SJ/T 11363-2006
标准规定的限量要求以下。
X
：表示该有毒有害物质至少在该部件的某一均质材料中的含量超出
SJ/T 11363-2006
标准规定的限量要求。
备注：
一、此产品所标示之环保使用期限，系指在一般正常使用状况下。
二、上述部件物质中央处理器、内存、硬盘、光驱、触控模块为选购品。
viii
DISTRIBUTED BY TEXIM EUROPE

Rugged Tablet Computer RTC-900B
Contents
Chapter 1 Settings
1.1 Introduction................................................................ 1-2
1.2 Features .................................................................... 1-3
1.3 More Information.......................................................1-4
1.4 Quick Start.................................................................1-5
1.5 Loading Windows......................................................1-6
Chapter 2 Getting Started
2.1 Introduction................................................................ 2-2
2.2 Product Overview......................................................2-3
2.3 Power Indicator ......................................................... 2-6
2.4 Touch Panel Control..................................................2-7
2.5 Touchscreen Calibration ........................................... 2-9
Chapter 3 Setting Up
3.1 Settings Screen.........................................................3-2
3.2 Setting the Power Button ..........................................3-10
Chapter 4 Driver Installation
4.1 Installation ................................................................. 4-3
Chapter 5 Power Management
5.1 Power Management.................................................. 5-2
5.2 Heat Considerations..................................................5-3
Appendix A Statements
ix
DISTRIBUTED BY TEXIM EUROPE

Rugged Tablet Computer RTC-900B
A.1 Statements.............................................................A-2
A.2 Canadian Notice ....................................................A-5
A.3 CE Mark Notice......................................................A-7
A.4 Safety Caution .......................................................A-8
A.5 Battery Disposal...................................................A-10
A.6 Battery Caution....................................................A-12
A.7 Adapter Caution...................................................A-13
x
DISTRIBUTED BY TEXIM EUROPE

Rugged Tablet Computer RTC-900B
Introduction
Chapter
1
Chapter 1 Introduction 1- 1
DISTRIBUTED BY TEXIM EUROPE

Rugged Tablet Computer RTC-900B
1.1 Introduction
This Rugged Tablet Computer (RTC) is a fully functional PC with
built-in wireless connectivity, Bluetooth®and an optional 3G modem
module. With your RTC you will be able to organize and access
important business and personal information, send and receive
e-mails, and access the Internet.
This User Manual contains setup information and describes the key
elements and features of the RTC. New users can find a simple
step-by-step guide in each chapter.
Chapter 1 Introduction 1- 2
DISTRIBUTED BY TEXIM EUROPE

Rugged Tablet Computer RTC-900B
1.2 Features
Operating System
Windows®Embedded 8.1 Industrial Pro
Processor
Intel® Atom E3825 1.33GHz Dual Core Processor
System Memory
DDR3L 4GB (up to 8GB by OEM order)
Storage
32GB Mini Card SSD (upgradable to 256 GB)
eMMC (available upon request)
Connectivity
Built-in 802.11b/g/n band wireless LAN
Bluetooth®
3G modem (optional)
Chapter 1 Introduction 1-3
DISTRIBUTED BY TEXIM EUROPE

Rugged Tablet Computer RTC-900B
1.3 More Information
About Your RTC
Users can find more descriptions about the key elements of the
RTC-900B in this user manual. Please visit aaeon.com for the most
updated version.
About Windows®Embedded Operating System
Windows developers may refer to Mircosoft.com for more on the
Windows® Embedded 8.1 Industry Pro Operating System.
Chapter 1 Introduction 1- 4
DISTRIBUTED BY TEXIM EUROPE

Rugged Tablet Computer RTC-900B
1.4 Quick Start
Turning on the Rugged Tablet Computer for the First Time
1. Connect the AC adapter power cord to the AC adapter.
2. Connect the AC adapter to the DC power port on the bottom
side of your RTC.
3. Connect the AC adapter power cord to an AC outlet.
4. Press the power button to turn on the power.
Note:Calibrate the battery and allow it to be fully charged before use (i.e.
before disconnecting AC power). It is recommended that the battery is
charged at least once per month to prevent battery deterioration. For more
information, please refer to Power Management chapter of this manual.
4
3
4
1
2
Chapter 1 Introduction 1-5
DISTRIBUTED BY TEXIM EUROPE

Rugged Tablet Computer RTC-900B
1.5 Loading Windows
Your RTC will begin loading Windows once you turn on the power.
Wait for a few seconds for Windows setup to load.
The “Welcome to Windows” screen will appear. You may disable
this feature by clearing the check box labeled show this screen
each time Windows starts.
Some software comes preloaded with Windows. New users can
familiarize themselves by selecting them from the start screen.
Chapter 1 Introduction 1- 6
DISTRIBUTED BY TEXIM EUROPE

Rugged Tablet Computer RTC-900B
Getting Started
Chapter
2
Chapter 2 Getting Started 2-1
DISTRIBUTED BY TEXIM EUROPE

Rugged Tablet Computer RTC-900B
2.1 Introduction
This chapter introduces the different components and controls of
your RTC, including the hardware components, software, and audio
and video systems.
Before you begin using your RTC, read this chapter to familiarize
yourself with the main components installed in the system.
Chapter 2 Getting Started 2 - 2
DISTRIBUTED BY TEXIM EUROPE

Rugged Tablet Computer RTC-900B
2.2 Product Overview
Front view
Mute
Volume Up
Volume Down
Home
Light Sensor
Chapter 2 Getting Started 2 - 3
DISTRIBUTED BY TEXIM EUROPE
