TFA Dostmann WIRELESS 868 MHz TEMPERATURE STATION User manual

26
WIRELESS 868 MHz TEMPERATURE STATION
Instruction Manual
Cat. No. 30.3050.IT
Thank you for choosing this wireless temperature station from TFA.
BEFORE YOU USE IT
Pl as b sur to r ad th instruction manual car fully.
This information will help you to familiarise yourself with your new de ice, learn all of its functions
and parts, find out important details about its first use and how to operate it, and get ad ice in the
e ent of faults.
Following the instruction manual will pre ent damage to the de ice and loss of your statutory rights
arising from defects due to incorrect use.
W shall not b liabl for any damag occurring as a r sult of not following th s
instructions.
Lik wis , w tak no r sponsibility for any incorr ct r adings and for any
cons qu nc s which may r sult from th m.
Pl as tak particular not of th saf ty advic !
Pl as look aft r this manual for futur r f r nc .
SCOPE OF DELIVERY:
• Temperature station (basic unit)
• Outdoor transmitter
• Instruction manual

27
FIELD OF OPERATION AND ALL OF THE BENEFITS OF YOUR NEW TEMPERATURE
STATION AT A GLANCE:
• DCF Radio controlled time with manual setting option
• Time reception ON/OFF
• Daylight sa ing time (DST) function selectable (ON/OFF)
• Time zone option –2h to +5h
• Calendar display (month, date; year only in manual setting)
• Temperature display in degrees Celsius (°C)
• MIN/MAX indoor and outdoor temperature display with time and date of recordings
• Manual reset of the MIN/MAX temperature records
• Low battery indicator
• Table standing or wall mounting
FOR YOUR SAFETY:
• The product is exclusi ely intended for the field of application described abo e. The product
should only be used as described within these instructions.
• Unauthorised repairs, modifications or changes to the product are prohibited.
• The product is not to be used for medical purpose or for public information, but is intended
solely for home use.
Caution!
Risk of injury:

28
• Keep this instrument and the batteries out of reach of children.
• Batteries must not be thrown into the fire, short-circuited, taken apart or recharged. Risk of
explosion!
• Batteries contain harmful acids. Low batteries should be changed as soon as possible to
pre ent damage caused by a leaking battery. Ne er use a combination of old and new
batteries together or batteries of different types. Wear chemical-resistant protecti e glo es
and glasses when handling leaked batteries.
! Important information on product saf ty!
• Do not expose the instrument to extreme temperatures, ibration or shock.
• The outdoor transmitter is protected against splash water, but is not watertight. Choose a
shady and dry position for the transmitter.

29
ELEMENTS:
Th t mp ratur station
Foldout
stand
Battery
compartment
co er
Function
keys
LCD
display
Hanging hole

30
Th t mp ratur transmitt r
• Remote transmission of outdoor temperature to temperature station by
868 MHz signals
• Casing protected against splash water
• Wall mounting and table stand
• Suitable for connection with sensor cable for pool, freezer etc. (optional)
INSTALL AND REPLACE BATTERIES IN THE TEMPERATURE TRANSMITTER
The temperature transmitter uses 2 x AAA, IEC LR3, 1.5V batteries. To install
and replace the batteries, please follow the steps below:
1. Slide the battery co er downwards and remo e.
2. Insert the batteries, obser ing the correct polarity (see marking).
3. Replace the battery co er.

31
INSTALL AND REPLACE BATTERIES IN THE TEMPERATURE STATION
The temperature station uses 2 x AAA, IEC LR3, 1.5V batteries. To
install and replace the batteries, please follow the steps below:
1. Remo e the co er at the back of the temperature station.
2. Insert batteries obser ing the correct polarity (see marking).
3. Replace compartment co er.
Batt ry r plac m nt
• Replace the batteries when the battery symbol of the temperature station appears near the
indoor temperature display.
• When the batteries of the transmitter are used up, the low battery icon appears near the
outdoor temperature display.
Not :
In the e ent of changing batteries in any of the units, all units need to be reset by following the
setting up procedures. This is because a random security code is assigned by the transmitter at
start-up and this code must be recei ed and stored by the temperature station in the first 3
minutes of power being supplied to it.

32
SETTING UP:
1.
First, insert the batteries into the transmitter (see “Install and r plac batt ri s in th
t mp ratur transmitt r” below).
2. Within 30 seconds of powering up the transmitter, insert the batteries to the temperature
station (see “Install and r plac batt ri s in th t mp ratur station” below). Once the
batteries are in place, all segments of the LCD will light up briefly. Then the indoor
temperature and the time as 0:00 will be displayed. If they are not shown on LCD after 60
seconds, remo e the batteries and wait for at least 60 seconds before reinserting them.
Once the indoor data is displayed, user may proceed to the next step.
3. After the batteries are inserted, the temperature station will start recei ing data signal from
the transmitter.
4. In order to ensure sufficient 868 MHz transmission, the position between the temperature
station and the transmitter should not be more than 100 meters (see notes on “Positioning”
and “868 MHz R c ption”).
5. Once the remote temperature has been recei ed and displayed on the temperature station,
the DCF time code reception is automatically started. This takes typically between 3-5
minutes in good conditions.
DCF-77 RADIO CONTROLLED TIME
The time base for the radio-controlled time is a Cesium Atomic Clock operated by the Physikalisch
Technische Bundesanstalt Braunschweig which has a time de iation of less than one second in
one million years. The time is coded and transmitted from Mainflingen near Frankfurt ia frequency
signal DCF-77 (77.5 kHz) and has a transmitting range of approximately 1,500 km. Your radio-

33
controlled temperature station recei es this signal and con erts it to show the precise time in
summer or wintertime. The quality of the reception depends greatly on the geographic location. In
normal cases, there should be no reception problems within a 1500km radius of Frankfurt.
Once the outdoor temperature is displayed on the temperature station, the DCF tower icon in the
clock display will start flashing in the upper left corner. This indicates that the clock has detected
that there is a radio signal present and is trying to recei e it. When the time code is recei ed, the
DCF tower becomes permanently lit and the time will be displayed.
DCF reception is done twice daily at 02:00 and 03:00 am. If the reception is not successful at
02:00 am, then the next reception takes place the next hour and so on until 06:00am, or until the
reception is successful. If the reception is not successful at 06:00 am, then the next attempt will
take place the next day at 02:00 am.
If the tower icon flashes, but does not set the time or the DCF tower does not appear at all, then
please take note of the following:
• Recommended distance to any interfering sources like computer monitors or TV sets is a
minimum of 1.5 - 2 meters.
• Within ferro-concrete rooms (basements, superstructures), the recei ed signal is naturally
weakened. In extreme cases, please place the unit close to a window and/ or point its front
or back towards the Frankfurt transmitter.
• During nighttime, the atmospheric disturbances are usually less se ere and reception is
possible in most cases. A single daily reception is adequate to keep the accuracy de iation
below 1 second.

34
FUNCTION KEYS:
T mp ratur station:
The temperature station has four easy to use function keys.
SET k y (S tting):
• Press and hold to enter the setting mode for the following settings: time zone, time reception
(RCC ON/OFF), daylight sa ing time (DST ON/OFF), manual time and calendar settings.
+ k y
• To make adjustment for arious settings
• To display the calendar (display returns to time display automatically after 5 seconds)
IN k y
• To toggle between the MIN/MAX and current indoor temperature
• Press and hold to reset the MIN/MAX indoor temperature records
• Press to exit the manual setting mode
SET key
OUT
key
+ key
IN key

35
OUT k y
• To toggle between the MIN/MAX and current outdoor temperature
• Press and hold to reset the MIN/MAX outdoor temperature records
• Press to exit the manual setting mode
LCD SCREEN:
Low battery icon
(temperature station)
Outdoor temperature
MAX indoor
temperature
MIN i
ndoor
temp
erature
Time
reception
icon
Outdoor signal
reception icon*
MAX outdoor
temperature
MIN
outdoor
temp
erature
Ind
oor
temperature
Low battery icon
(transmitter)
Time

36
* When the signal is successfully recei ed by the temperature station, the outdoor transmission
icon will be switched on. (If not successful, the icon will not be shown on LCD). The user can then
easily see whether the last reception was successful (icon on) or not (icon off). On the other hand,
the short blinking of the icon shows that a reception is currently taking place.
MANUAL SETTINGS:
The following manual settings can be done in the setting mode:
• Time zone setting
• Time reception ON/OFF setting (RCC)
• Daylight sa ing time (DST) ON/OFF
• Manual time setting
• Calendar setting (Year, Month, Date)
Press and hold the SET key for about 3 seconds to ad ance to the setting mode:
TIME ZONE SETTING:
The time zone default of the temperature station is 0h. To change to another time zone:
1. The time zone “0” start flashing. Use the + key set the time zone. The range runs from –2h
to +5h and then runs from +5h to -2h back in 1hour inter al.
Time zone flashing

37
2. Press the SET key to confirm and enter the “Tim r c ption On/Off s tting”.
TIME RECEPTION ON/OFF SETTING
In areas where reception of the atomic time is not possible, the time reception function can be
turned OFF. The clock will then work as a normal quartz clock. (Default setting is “1” (ON)).
1. The digit “1” (ON) and the time reception icon will start flashing on the LCD. Use the + key to
turn “0” (OFF) or “1” (ON) the time reception function.
2. Confirm with the SET key and enter the “
Daylight saving tim (DST) ON/OFF ”.
Not :
If the time reception function is turned OFF manually, the clock will not attempt any reception of
the DCF time as long as the time reception OFF function is acti ated. The time reception icon will
not be displayed on the LCD.
DAYLIGHT SAVING TIME ON/OFF SETTING (DST)
The daylight sa ing time (DST) function can be set ON “1” or OFF “0”. Default setting is “1” (ON):
Flashing

38
Important:
This function is only significant if th tim r c ption s tting is turn d OFF “0”.
• Daylight saving tim s tting “1” (ON): the clock calculates DST automatically in normal
quartz mode. DST begins on the last Sunday of March and ends on the last Sunday of
October.
•
Daylight saving tim s tting “0” (OFF): DST feature is OFF and the clock will not change
time automatically.
If th tim r c ption s tting is turn d ON “1”, pl as s t th daylight saving tim “1” (ON):
the time change will be updated by the DCF-77 signal (as long as a proper reception is possible).
In case of daylight sa ing time setting “0” (OFF): the time will be transmitted by the DCF-77 signal,
but the clock calculates automatically a “no-DST time”.
1. “1” (ON) will flash on the LCD with "dSt" displayed. Use the + key to turn the daylight sa ing
time function ON or OFF.
2. Confirm with the SET key and enter the “Manual tim s tting”.
Flashing

39
MANUAL SETTING OF THE CLOCK
In case the temperature station is not able to detect the atomic time (DCF) signal (disturbances,
transmitting distance, etc.), the time can be manually set. The clock will then work as a normal
quartz clock.
To set the clock:
1. The hour digits start flashing in the time display section.
2. Use the + key to adjust the hours and then press SET key to go to the minute setting.
3. The minute will be flashing. Press the + key to adjust the minutes.
4. Confirm with the SET key and enter the “Cal ndar s tting”.
Not :
The unit will still try to recei e the signal despite it being manually set. When it does recei e the
signal, it will change the manually set time into the recei ed time. During reception attempts the
DCF tower icon will flash. If reception has been unsuccessful, then the DCF tower icon will not
appear but reception will still be attempted the following hour.
CALENDAR SETTING
The date default of the temperature station is 1. 1. of the year 2012 after initial set-up. Once the radio-
controlled time signals are recei ed, the date is automatically updated. Howe er, if the signals are not
recei ed, the date can also be set manually.
Minutes (flashing)
Hours (flashing)

40
1. The year is flashing. Using the + key, set the year required. The range runs from 2012 to
2039 (default is 2012).
2. Press the SET key to enter the month setting mode.
3. The month digit will be flashing. Press the + key to set the month and then press the SET
key to go to the day setting.
4. The day digit will be flashing. Press the + key to set the day.
5. Confirm with the SET key to exit the setting mode.
DISPLAY OF INDOOR TEMPERATURE READING:
The indoor temperature is measured and displayed on the second section of the LCD.
Indoor
temperature
Indoor
Icon
Year
Date Month

41
DISPLAY OF OUTDOOR TEMPERATURE READING:
The bottom LCD section shows the outdoor temperature.
DISPLAY OF INDOOR MIN/MAX RECORDS:
1. Continuously press the IN key se eral times to iew:
• MIN indoor temperature and time of recording
• MIN indoor temperature and date of recording
• MAX indoor temperature and time of recording
• MAX indoor temperature and date of recording
2. Press again the IN key to return to normal display.
Not : the measuring indoor MIN/MAX temperature range is: -9ºC to +39ºC with 1ºC resolution
DISPLAY OF OUTDOOR MIN/MAX RECORDS:
1. Continuously press the OUT key se eral times to iew:
• MIN outdoor temperature and time of recording
• MIN outdoor temperature and date of recording
Outdoor icon
Outdoor
temperature
Outdoor reception
signal

42
• MAX outdoor temperature and time of recording
• MAX outdoor temperature and date of recording
2. Press again the OUT key to return to normal display.
Not : the measuring outdoor MIN/MAX temperature range is: -40ºC to +60ºC with 1ºC resolution
RESETTING THE INDOOR AND OUTDOOR MIN/MAX RECORDS
1. Press and hold the IN or OUT key for about 3 seconds, this will reset the currently shown
indoor or outdoor MIN/MAX data to the current time, date and temperature respecti ely.
868 MHz RECEPTION
The temperature station should recei e the temperature data within 3 minutes after set-up. If the
temperature data is not recei ed 3 minutes after setting up (not successfully continuously, the
outdoor display shows “- - -” ), please check the following points:
1. The distance of the temperature station or transmitter should be at least 1.5 to 2 meters
away from any interfering sources such as computer monitors or TV sets.
2. A oid positioning the temperature station onto or in the immediate proximity of metal
window frames.
3. Using other electrical products such as headphones or speakers operating on the same
signal frequency (868MHz) may pre ent correct signal transmission and reception.
5. Neighbors using electrical de ices operating on the 868MHz signal frequency can also
cause interference.

43
Not :
When the 868MHz signal is recei ed correctly, do not re-open the battery co er of either the
transmitter or temperature station, as the batteries may spring free from the contacts and force a
false reset. Should this happen accidentally then reset all units (see S tting up abo e) otherwise
transmission problems may occur.
The transmission range is about 100 m from the transmitter to the temperature station (in open
space). Howe er, this depends on the surrounding en ironment and interference le els. If no
reception is possible despite the obser ation of these factors, all system units ha e to be reset
(see S tting up).
POSITIONING THE TEMPERATURE STATION:
The temperature station is designed to hang onto wall or free standing.
To wall mount
Before wall mounting, please check that the outdoor temperature alues can be
recei ed from the desired locations.
1. Fix a screw (not supplied) into the desired wall, lea ing the head
extended out the by about 5mm.
2. Hang the station onto the screw. Remember to ensure that it locks into
place before releasing.

44
Fr standing
With the foldout stand, the temperature station can be placed onto
any flat surface.
POSITIONING THE TEMPERATURE TRANSMITTER
The transmitter is supplied with a holder that may be attached to a wall with the
two screws supplied. The transmitter can also be positioned on a flat surface by
mounting the holder at the bottom of the transmitter.
Choose a sheltered place. A oid direct rain and sunshine.

45
To wall mount:
1. Secure the holder onto a desired wall using the screws and plastic
anchors.
2. Clip the transmitter onto the holder.
Not :
Before permanently fixing the transmitter wall base, place all units in the desired locations to check
that the outdoor temperature reading is recei able. In e ent that the signal is not recei ed, relocate
the transmitter or mo e it slightly as this may help the signal reception.
CARE AND MAINTENANCE
• Clean the instrument and the transmitter with a soft damp cloth. Do not use sol ents or
scouring agents. Protect from moisture.
• Remo e the batteries if you do not use the product for a lengthy period.
MALFUNCTION
Probl ms Troubl shooting
No indication on the
temperature station
• Ensure batteries polarity is correct
• Change batteries
