ACU-RITE 01022 User manual

Instruction Manual
CONTENTS
Unpacking Instructions ............... 2
Package Contents ...................... 2
Product Registration ................... 2
Features & Benets: Lightning Sensor .. 3
Features & Benets: 5-in1 ........... 4
Features & Benets: Display........ 5
Setup ........................................ 9
Lightning Sensor Setup ............... 9
5-in-1 Sensor Setup ...................10
Display Setup ...........................11
Set the Time, Date & Units .........12
Backlight Settings......................12
Placement Guidelines ................13
5-in-1 Sensor Installation............15
Using the Weather Center .........16
Rainfall Tracking .......................18
Weather Ticker .........................19
Programmable Alarms.............. 20
Troubleshooting ....................... 22
Care & Maintenance................ 24
Calibration .............................. 24
Specications........................... 26
FCC Information ...................... 26
Customer Support .................... 27
Warranty................................. 27
Weather Station with Lightning Detector
models 01022, 02080, 06046
SAVE THIS MANUAL FOR FUTURE REFERENCE.
Questions? Contact Customer Support at
[phone] or visit www.AcuRite.com.

2
Congratulations on your new AcuRite product. To ensure the best
possible product performance, please read this manual in its entirety
and retain it for future reference.
Unpacking Instructions
Remove the protective lm that is applied to the LCD screen prior to using this
product. Locate the tab and peel off to remove.
Package Contents
1. Display with Tabletop Stand
2. 5-in-1 Sensor
3. Lightning Sensor
4. Sensor Mounting Bracket
5. Mounting Hardware
6. Power Adapter
7. Instruction Manual
PRODUCT REGISTRATION
Register online to receive 1 year warranty protection
www.AcuRite.com
IMPORTANT PRODUCT MUST BE REGISTERED
TO RECEIVE WARRANTY SERVICE

3
2
4
3
5
7
6
1
NOTE: Under no circumstances shall the Lightning Detector, Chaney Instrument
Co. or the Primex Family of Companies be held responsible for any damages
whatsoever that may result from the use of or inability to use this product, including
without limitation any indirect, incidental, special, exemplary or consequential
damages, which are expressly disclaimed. This disclaimer of liability applies to
any damages or injury caused by any failure of performance, error, omission,
inaccuracy, interruption, deletion, defect, delay in operation or transmission
software virus, communication failure, theft or destruction or unauthorized access
to, alteration of, or use of the product, whether for breach of contract, tortuous
behavior (including, without limitation, strict liability), negligence, or under any
other cause of action, to the fullest extent permissible by law. This does not affect
any statutory rights which may not be disclaimed. The contents of this product,
including all lightning and weather data are provided “as is” and without warranty
or condition of any kind, express or implied, including, without limitation, any
warranty of merchantability or tness for a particular purpose. Chaney Instrument
Co. & the Primex Family of Companies do not warrant that this product or the
data that it provides will be free of errors, interruptions, viruses or other harmful
components. Chaney Instrument Co. & the Primex Family of Companies do not
warrant the accuracy or reliability of any lightning strike alerts, weather data or
other information provided by the product. Chaney Instrument Co. & the Primex
Family of Companies reserve the right to alter the product or withdraw it from the
market at its sole discretion.
Features & Benets
1. Integrated Hanger
For easy placement.
2. Wireless Signal Indicator
Flashes when data is being
sent to the companion unit.
3. Interference Indicator
Flashes when interference is
detected (see page 14).
4. A-B-C Switch
ID code that must match
display’s A-B-C switch to ensure
units synchronize.
5. Battery Compartment
6. Lightning Strike Indicator
Indicates a lightning strike has
occurred within 25 miles (40 km).
7. Battery Compartment Cover
LIGHTNING SENSOR

4
Features & Benets
9
10
11
7
2
1
8
5
6
4
3
5-in-1 SENSOR
1. Rainfall Collector Funnel
2. Solar Cell Panel
Converts sunlight into power to run
internal aspirating fan.
Internal Aspirating Fan
(not shown)
Draws ambient air into
sensor to reduce solar radiation
heating, resulting in more accurate
temperature measurement.
3. A-B-C Switch
ID code that must match display’s
A-B-C switch to ensure units
synchronize.
4. Battery Compartment
5. Temperature & Humidity Sensors
(internal)
6. Mounting Point
7. Wind Speed Anemometer
8. Wind Direction Vane
9. Mounting Bracket
10. Mounting Hardware
Includes 5 anchors & the following
screws:
Qty Diameter Length
5 #4 3/4”
1 #4 1/2”
1 #6 1/2”
11. Debris Filter
Pre-installed to prevent debris from
entering the rain gauge.

5
1
2 3 4 65 7 3 8
FRONT OF DISPLAY
1. Button
Press to view rainfall records (see page 18).
2. select Button
Press to cycle through available
readings and access options, alarms
and records menu.
3. and Buttons
For setup preferences and manually
cycling through Weather Ticker messages
(when display is not connected to
additional sensors). For manually cycling
add-on sensor data (when display is
connected to additional sensors).
4. options Button
For calibration and setup preferences.
5. SET
enter Button
For setup preferences.
6. alarms Button
For alarm setup preferences.
7. records Button
Press to view historical records for
reading selected.
8. clear Button
Press to clear selected record.
Features & Benets

6
1
2
3
4
5
6
7
8
9
10
16
11
12
13
14
15
28
29
30
31
32
33
34
35
34 363738394041
24
25
26
27
23
8
17 1814 19 222120
Features & Benets
FRONT OF DISPLAY

7
1. Current Outdoor Temperature
Arrow indicates direction temperature
is trending.
2. Outdoor Low Temperature Record
Lowest temperature recorded since
midnight.
3. Outdoor High Temperature Record
Highest temperature recorded since
midnight.
4. Current Outdoor Humidity
Arrow indicates direction humidity
is trending.
5. Outdoor Low Humidity Record
Lowest humidity recorded since midnight.
6. Outdoor High Humidity Record
Highest humidity recorded since midnight.
7. Weather Select
Heat Index calculation displays when
temperature is 80°F (27°C) or higher.
Dew Point calculation displays when
temperature is 79°F (26°C) or below.
Wind chill calculation displays when
temperature is 40°F (4°C) or lower.
8. Alarm ON Indicator
Indicates alarm is activated to emit an
audible alert when conditions exceed
your presets (see page 20).
9. Rainfall
Displays most recent rainfall total
(today, yesterday or this week).
10. Rainfall History
Displays historical rainfall totals
(see page 18).
11. 5-in-1 Sensor Signal Strength
12. 5-in-1 Sensor Low Battery Indicator
13. Lightning Sensor Signal Strength
14. Interference Indicator
Flashes when interference is detected
(see page 14).
15. Lightning Sensor Low Battery Indicator
16. Weather Ticker
Streams real-time data (see page 19).
17. Strike Counter
Displays most recent total of lightning
strikes that has been detected (today,
this week, this month).
18. Clock
Automatically updates for Daylight
Saving Time.
19. Lightning Strike Indicator
Indicates a lightning strike has
occurred within 25 miles.
20. Estimated Distance to Storm Front
Updates with latest lightning strike
detected today.
21. Icon
Indicates display is in auto-dimming
brightness mode (see page 12).
22. Display Low Battery Indicator
23. Date
24. Add-on Sensor Low Battery Indicator
If applicable (see page 17).
25. Add-On Sensor Signal Strength
If applicable (see page 17).
26. Auto-Cycle Indicator
Indicates auto-cycle mode is enabled.
If applicable (see page 17).
27. Add-On Sensor Indicator
If applicable (see page 17).
28. Current Humidity for #27 or #30
Arrow icon indicates direction humidity
is trending.
29. Humidity Level Indicator
Indicates a high, low, or ideal humidity
comfort level.
30. Indoor Indicator
Indicates indoor (display) conditions are
being shown.
31. Current Temperature for #27 or #30
Arrow icon indicates direction temperature
is trending.
32. Peak Wind Speed
Highest speed from the last 60 minutes.
33. Average Wind Speed
Average wind speed over the past 2 minutes.
34. Current Wind Direction
35. Current Wind Speed
36. Wind Speed Alert Indicator
Activates when wind speed is over 32 mph.
37. Learning Mode Icon
Disappears after weather forecast
self-calibration is complete (see page 16).
38. Previous 2 Wind Directions
39. 12 to 24 Hour Weather Forecast
Self-Calibrating Forecasting pulls data from
your 5-in-1 sensor to generate your
personal forecast.
40. Barometric Pressure
Arrow icon indicates direction pressure
is trending.
41. Freeze Alert Indicator
Indicates temperature is below freezing
(32°F; 0°C).

8
6
7
BACK OF DISPLAY
1. Integrated Hang Hole
For easy wall mounting.
2. A-B-C Switch
ID code that must match the
5-in-1 sensor and lightning sensor’s
A-B-C switches to ensure units
synchronize.
3. RESET Button
Press and release for full reset to
factory defaults.
4. Removable Tabletop Stand
5. Power Adapter
6. Battery Compartment Cover
(not shown)
7. Plug-in for Power Adapter
8. LIGHT Button
Dimmer control while using power
adapter. Activates momentary
backlight while on battery power.
5
4
1
2
3
8

9
SETUP
Lightning Sensor Setup
Set the A-B-C Switch
Locate the A-B-C switch inside the
battery compartment. It can be set
to A, B or C. However, you must
select the same letter choices for the
display, 5-in-1 sensor and lightning
sensor in order for the units to
synchronize.
Install or Replace Batteries
AcuRite recommends high quality
alkaline or lithium batteries in
the wireless sensor for the best
product performance. Heavy duty
or rechargeable batteries are not
recommended.
The sensor requires lithium batteries
in low temperature conditions. Cold
temperatures can cause alkaline
batteries to function improperly. Use
lithium batteries in the sensor for
temperatures below -4ºF / -20ºC.
1. Slide off the battery compartment
cover.
2. Insert 4 x AA batteries into the
battery compartment, as shown.
Follow the polarity (+/-) diagram
in the battery compartment.
3. Replace the battery cover.
2Install Batteries
4 AA batteries
1A-B-C Switch
Set to match display & 5-in-1 sensor
A B C
1
2
PLEASE DISPOSE OF OLD OR DEFECTIVE BATTERIES IN AN ENVIRONMENTALLY SAFE
WAY AND IN ACCORDANCE WITH YOUR LOCAL LAWS AND REGULATIONS.
BATTERY SAFETY: Clean the battery contacts and also those of the device prior to battery installation. Remove batteries from equipment that will not be
used for an extended period of time. Follow the polarity (+/-) diagram in the battery compartment. Promptly remove dead batteries from the device. Dispose of used
batteries properly. Only batteries of the same or equivalent type as recommended are to be used. DO NOT incinerate used batteries. DO NOT dispose of batteries in fire,
as batteries may explode or leak. DO NOT mix old and new batteries or types of batteries (alkaline/standard). DO NOT use rechargeable batteries. DO NOT recharge
non-rechargeable batteries. DO NOT short-circuit the supply terminals.

10
5-in-1 Sensor Setup
Set the A-B-C Switch
Locate the A-B-C switch inside the
battery compartment. It can be
set to A, B or C. However, you
must select the same letter choices
for the display, 5-in-1 sensor and
lightning sensor in order for the
units to synchronize.
Install or Replace Batteries
Batteries MUST be installed for
this product to operate. AcuRite
recommends high quality alkaline
or lithium batteries for the best
product performance. Heavy duty
or rechargeable batteries are not
recommended.
The 5-in-1 sensor requires lithium
batteries in low temperature
conditions. Cold temperatures can
cause alkaline batteries to function
improperly. Use lithium batteries in
the 5-in-1 sensor for temperatures
below -4ºF/-20ºC.
1. Slide off the battery
compartment cover.
2. Insert 4 x AA batteries into the
battery compartment, as
shown. Follow the polarity
(+/-) diagram in the battery
compartment.
3. Replace the battery cover.
Remove Rain Gauge Stabilizer
Locate and remove the rain gauge
stabilizer (plastic tab) taped into
the bottom of the sensor. The rain
gauge will not function until this is
removed.
2
3
1
A B C
1A-B-C Switch
Set to match
display &
lightning sensor
2Install Batteries
4 AA Batteries
3Rain Gauge Stabilizer
Remove and discard
NOTE: If add-on sensors are being used with the display (see page 17), set them up at this
time. If pairing more than one wireless sensor with the display, the A-B-C channel must differ
between each add-on sensor. The display will automatically begin searching for add-on sensors
during initial setup.

11
1A-B-C Switch
Set to match
5-in-1 sensor and
lightning sensor
IMPORTANT: Batteries are a backup power source to preserve records in the event of
a power outage. Power adapter is the recommended primary power source to enjoy
the full functionality of this product.
Display Setup
AcuRite recommends high quality alkaline batteries for the best product
performance. Heavy duty or rechargeable batteries are not recommended.
Set the A-B-C Switch
Locate the A-B-C switch inside the
battery compartment. It can be set
to A, B or C. However, you must
select the same letter choices for the
display, 5-in-1 sensor and lightning
sensor in order for the units to
synchronize.
1
Install or Replace
Backup Batteries (optional)
Insert 6 x AA alkaline batteries
into the battery compartment,
as shown. Follow the polarity
(+/-) diagram in the battery
compartment.
3
Plug Power Adapter into
Electrical Outlet
2
3Install Backup
Batteries
(optional)
6 AA Batteries
2Plug in Power
Adapter
A B C

12
Set the Time, Date & Units
The display will automatically enter SET MODE after the unit has powered on.
Once in set mode, the preference you are currently setting will blink on the display.
To adjust the currently selected (ashing) item, press and release the “ “ or
“ “ buttons (press and HOLD to fast adjust).
To save your adjustments, press and release the “ SET
enter” button again to adjust
the next preference. The preference set order is as follows:
LANGUAGE (English, French)
COUNTRY (USA, Canada, Australia, Other)
TIME ZONE (EST, CST, MST, PST, AKT, HAT, NST, AST)
AUTO DST CHANGE* (YES, NO)
WEATHER TICKER SPEED (SLOW, MEDIUM, FAST)
CLOCK HOUR
CLOCK MINUTE
CALENDAR MONTH
CALENDAR DATE
CALENDAR YEAR
TEMPERATURE UNITS (ºF or ºC)
WIND SPEED UNITS (mph, kph, knots)
RAINFALL UNITS (in or mm)
PRESSURE UNITS (inHg or hPa)
DISTANCE UNITS (mi or km)
*If you live in an area that observes Daylight Saving Time, DST should be set
to YES, even if it is not currently Daylight Saving Time.
You will automatically exit SET MODE if no buttons are pressed for 15 seconds.
Enter SET MODE at any time by pressing the “ SET
enter” button.
Display Backlight Settings
This weather station’s color display features three different lighting settings:
High (100%) brightness, Medium (60%) brightness and Low (15%) brightness.
Using battery power alone, the backlight is available momentarily for 10
seconds by pressing the “LIGHT ” button.
When the display is powered with the power adapter, the backlight remains
on at 100% brightness. Press the “LIGHT ” button once to dim to 60% brightness;
press again to dim to 15%, press a 3rd time to enter “AUTO DIM” mode. “LIGHT ”
will appear next to the clock.
NOTE: Pressing and holding the “LIGHT ” button for 5 seconds will disable the backlight.
Once any button is pressed, the backlight will return to your selected setting.
AUTO DIM MODE: Automatically adjusts display brightness based on time of day.
6:00 a.m. - 9:00 p.m. = 100% brightness
9:01 p.m. - 5:59 a.m.= 15% brightness

13
Placement for Maximum Accuracy
AcuRite sensors are sensitive to surrounding environmental conditions. Proper
placement of the display, 5-in-1 sensor and lightning sensor is critical to the
accuracy and performance of this product.
Display Placement
Place the display in a dry area free of dirt and dust. To ensure
accurate temperature measurement, place out of direct sunlight
and away from heat sources or vents. Display stands upright for
tabletop use or is wall-mountable.
5-in-1 Sensor Placement
The 5-in-1 sensor is designed to remain outdoors all year long.
Choose an open location with no obstructions above or around
the sensor for the most accurate measurements.
Lightning Sensor Placement
The Lightning Sensor is water-resistant and is designed for
general outdoor use, however, to extend its life place the sensor
in an area protected from direct weather elements.
Hang the sensor using the integrated hanger, or by using string
(not included) to hang it from a suitable location, like a well
covered tree branch. The best location is 4 to 8 feet above the
ground with permanent shade and plenty of fresh air to circulate
around the sensor.
Important Placement Guidelines
Display must be within 330 feet (100 meters) of 5-in-1 sensor and lightning sensor.
MAXIMIZE WIRELESS RANGE
Place units away from large metallic items, thick walls, metal surfaces, or other
objects that may limit wireless communication.
PREVENT WIRELESS INTERFERENCE
Place units at least 3 feet (.9 m) away from electronic devices (TV, computer,
microwave, radio, etc.).
LOCATE AWAY FROM HEAT SOURCES
Position sensor away from heaters, air conditioners, chimneys, exhaust vents,
asphalt and concrete (surfaces that radiate heat).
LOCATE AWAY FROM HUMIDITY SOURCES
Avoid installing the sensor near pools, spas, or other bodies of water. Water
sources may impact humidity accuracy.

14
LOCATE AWAY FROM SPRINKLER HEADS
DO NOT install the sensor where it will be sprayed by a sprinkler system. This
may force water inside the sensor.
LOCATE AWAY FROM WIND & RAIN OBSTRUCTIONS
DO NOT mount the sensor with obstructions around it.
Consider a location that is a wide open area, with few
structures around to ensure accurate wind measurement.
View Video
Visit us online to view installation photos and
video, or learn more about AcuRite technology:
www.AcuRite.com/5in1
False Detection
This sensor features advanced technology to distinguish between lightning
strikes and interference, however in rare cases the sensor may "false detect"
lightning activity due to interference. In these situations, verify there is no
lightning in the area and then relocate the sensor. If the false detections persist,
identify and relocate the source of interference or relocate the sensor.
Interference
The sensor features enhanced interference rejection capabilities to prevent
false lightning detection. When the detector cannot detect lightning due to
interference from nearby equipment, the sensor's interference indicator will ash.
• Electric motors (windshield wiper motor or fan motors in cars, hard drive and
optical drive motors on your PC and AV equipment, well pumps, sump pumps)
• CRT monitors (PC monitors, TV's)
• Fluorescent light xtures (turned off or on)
• Microwave ovens (while in use)
• PC's and mobile phones
WARNING: Take shelter IMMEDIATELY when lightning is present, whether or
not it has been detected by the Lightning Detector. If you are concerned about
lightning strikes, follow all safety precautions to keep yourself and others safe.
DO NOT rely on this Lightning Detector as your only source for warnings
about potentially deadly lightning strikes or other severe weather conditions.
Lightning Sensor Installation Guidelines

15
5-in-1 Sensor Installation Guidelines
INSTALLATION HEIGHT Mount the sensor at a minimum height of 5 feet
(1.5 meters) off the ground, in an open area. Higher is better for wind
measurements - the National Weather Service recommends 33 feet
(10 meters) high!
MOUNTING OPTIONS The included mounting bracket is designed to screw
directly onto wooden posts or surfaces that are 2”x 4” or larger. The sensor
can also be mounted directly to 3/4” steel pipe (available at hardware stores
and home centers).
SOLAR CELL INSTALLATION Install the sensor
with the solar cell facing SOUTH. This ensures
the cell receives as much sun as possible and
orients wind direction.
5-in-1 Sensor Installation
1. Fasten mounting base (included) to a post
or pole (not included) using the 4 longer
screws included in the hardware bag.
2. Insert the mounting base into the hole on
the bottom of the sensor.
3. Make sure the arrows on the top of the
sensor are pointed in the proper direction
and the bubble level is centered. The solar
cell should be facing south to properly
orient the wind direction.
4. Fasten the sensor into the mounting base
using the 2 shorter screws included in the
hardware bag.
The 5-in-1 sensor is now ready to use.
Basic Setup is Complete
The 5-in-1 sensor will now synchronize with the display. It may take a few
minutes for synchronization to complete. If both or one of the units appear to
be functioning improperly, please refer to the troubleshooting section.
SOUTH
(1.5 meters)
NO OBSTRUCTIONS
ABOVE OR AROUND

16
Using the Professional Weather Center
Learning Mode
Self-Calibrating Forecasting use a unique algorithm to analyze changes in pressure over
a time period (called Learning Mode) to determine your altitude. After 14 days, the
icon disappears from the display screen. At this point, the self-calibrated pressure is
tuned in to your location and the unit is ready for superior weather prediction.
Weather Forecast
AcuRite’s patented Self-Calibrating Forecasting provides your personal forecast of weather
conditions for the next 12 to 24 hours by collecting data from the sensor in your backyard.
It generates a forecast with pinpoint accuracy - personalized for your exact location.
View the complete list of icons at www.AcuRite.com/acurite-icons
SNOW / RAIN
MIX LIKELY
RAIN
LIKELY
SNOW
LIKELY
STORMY
& WINDY
CLOUDY
(flashing=stormy)
OPERATION
Wind Speed
This weather center displays the current, average and peak wind speeds. By
default, average wind speed is calculated in 2-minute intervals. To adjust the time
interval for average wind speed calculations:
1. Press and release the “select” button until “WIND SPEED AVERAGE” is shown
on the Weather Ticker.
2. Press and release the “options” button.
3. Press and release the “ SET
enter” button.
4. Press and release the “ ” or “ ” buttons until the desired interval is shown
on the display.
5. Press and release the “ SET
enter” button to save your selection.
After 5 seconds of inactivity, you will exit set mode.
Weather Select
Weather Select displays data including wind chill, dew point and heat index based
on current outdoor conditions. To manually change the Weather Select reading
being displayed:
1. Press and release the “select” button until “WEATHER SELECT” is shown on the
Weather Ticker.
2. Press and release the “options” button.
3. Press and release the “ ” or “ ” buttons until the desired reading is shown on
the display.
4. Press and release the “ SET
enter” button to save your selection.
After 5 seconds of inactivity, you will exit set mode.

17
Compatible Sensors Perfect for:
Temperature & Humidity Sensor
Model 06002
• Indoor and outdoor applications
Temperature & Humidity Sensor
Model 06044
• Integrated digital display for conditions
at a glance
• Measures temperature and humidity
• For indoor applications
View Indoor/Add-On Sensor Readings
The weather station displays the current indoor temperature and humidity readings,
by default.
If the weather station is being used with additional sensors (see Expand the
System), toggle between indoor readings and each sensor’s readings by pressing
and releasing the “ “ or “ “ buttons.
In auto-cycle mode, the display will automatically cycle through indoor and each
sensor’s data. Auto-cycle mode can be activated by pressing and releasing the
““ or “ “ buttons until the “ “ indicator appears.
Expand the System
The display features built-in sensors for measuring temperature and humidity
at its location. The display can be expanded to track additional areas by using
compatible Temperature & Humidity Sensors (optional; sold separately). Add up
to 3 indoor/outdoor sensors to observe conditions in additional locations within
330 ft (100 m). Compatible Sensors are available at: www.AcuRite.com
Barometric Pressure
Subtle variations in barometric pressure greatly affect the weather. This weather
center displays the current pressure with an arrow icon to indicate the direction the
pressure is trending (FALLING, STEADY, or RISING).
Lightning Detection
The lightning sensor detects cloud-to-cloud, cloud-to-ground and intra-cloud
lightning. When lightning is detected, the sensor will beep and the strike indicator
will ash for each of the rst 10 strikes. After 10 strikes, the sensor will enter silent
mode but will continue to ash. The sensor will stay in silent mode for 2 hours after
the last lightning detection.
The display will automatically show the most recent lightning event (TODAY, WEEK,
MONTH). The icon appears on the display when lightning is detected and
keeps a running count of lightning strikes detected. The display shows an estimate
of the distance to the front of today’s lightning-producing storm.

18
Rainfall Data
Rainfall History
ALL-TIME TOTAL RAINFALLTOTAL RAINFALL
FOR MONTH SHOWN
CURRENT YEAR
TOTAL RAINFALL
(default)
If there hasn’t been any
rainfall today, the current
week’s rainfall (Sunday to
Saturday) is displayed, if
applicable.
WEEK
Displays rainfall
recorded TODAY
since 12:00am,
if applicable.
TODAY
If there hasn’t been any
rainfall this week, the
current month’s rainfall is
displayed.
YESTERDAY
Weather Ticker™
The Weather Ticker automatically ashes your real-time weather information
and alerts as text in the lower part of the display screen.
The possible WEATHER TICKER messages are as follows:
HEAT INDEX-XX
WINDCHILL-XX
DEW POINT-XX
Rainfall Tracking
This weather station features enhanced tracking of historical rainfall data.
Rain accumulation data is displayed for the current day, yesterday, or week
(most recent rainfall total). Press the “ ” button to review historical rainfall
records.
Records are shown in the following order:
CURRENT YEAR TOTAL (default)
PREVIOUS MONTHLY TOTALS WITH RAIN (up to 12 months prior)
CURRENT YEAR TOTAL
PREVIOUS YEAR TOTAL
ALL-TIME TOTAL
The Sensor Indicator is used to determine which add-on sensor readings you
are viewing. For example, if the Sensor Indicator is displaying “A”, the readings
are being transmitted from the sensor with the A-B-C switch set to “A”.

19
IT FEELS LIKE XX OUTSIDE
TODAY’S HIGH HUMIDITY...OUTDOOR XX/INDOOR XX
TODAY’S LOW HUMIDITY...OUTDOOR XX/INDOOR XX
TODAY’S HIGH TEMP...OUTDOOR XXX/INDOOR XXX
TODAY’S LOW TEMP...OUTDOOR XXX/INDOOR XXX
7 DAY HIGH TEMP. XX–MM/DD
7 DAY LOW TEMP. XX–MM/DD
30 DAY HIGH TEMP. XX–MM/DD
30 DAY LOW TEMP. XX–MM/DD
ALL TIME HIGH TEMP. XXX…RECORDED MM/DD/YY
ALL TIME LOW TEMP. XXX…RECORDED MM/DD/YY
24 HOUR TEMP. CHANGE +XX
ALL TIME HIGH WIND XX MPH…RECORDED MM/DD/YY
7 DAY AVERAGE WIND XX MPH
TODAY’S AVERAGE WIND XX MPH
MOON- NEW
MOON- WAXING CRESCENT
MOON- FIRST QUARTER
MOON-WAXING GIBBOUS
MOON- FULL
MOON- WANING GIBBOUS
MOON- LAST QUARTER
MOON- WANING CRESCENT
INDOOR HUMIDITY OK
INDOOR HUMIDITY HIGH
INDOOR HUMIDITY LOW
NEW LOW TEMP. RECORD XX
NEW HIGH TEMP. RECORD XX
NEW WIND RECORD TODAY XX
CURRENT RAINFALL RATE X.XX /HR.
RAIN EVENT STARTED XX HRS. AGO
5-IN-1 SENSOR BATTERIES LOW
DISPLAY BATTERIES LOW
5-IN-1 SENSOR SIGNAL LOST…CHECK BATTERIES AND PLACEMENT
CAUTION– HEAT INDEX IS XXX
CAUTION– WIND CHILL IS XXX
LIGHTNING DETECTED...XX MILES AWAY...STRIKES CLOSER
LIGHTNING DETECTED...XX MILES AWAY...STRIKES FARTHER AWAY
LIGHTNING STRIKES...LAST 48 HOURS - XXXX
LIGHTNING STRIKES...LAST MONTH - XXXX
LIGHTNING STRIKES...THIS YEAR - XXXX
LIGHTNING STRIKES...LAST YEAR - XXXX
LIGHTNING STRIKES...ALL TIME - XXXX
MOST LIGHTNING...IN ONE DAY - XXXX...MM/DD/YY
CAN’T DETECT LIGHTNING...RELOCATE SENSOR
LIGHTNING SENSOR...BATTERIES LOW
LIGHTNING SENSOR...SIGNAL LOST...CHECK BATTERIES... AND PLACEMENT

20
Programmable Weather Alarms
Each selectable weather category features an alarm option. When an alarm
sounds, the display emits audible beeping and ashes the affected category, its
alarm settings, and any other relevant data.
Alarms can be customized to alert you when your programmed value is
reached. Alarms include:
OUTDOOR TEMPERATURE
OUTDOOR HUMIDITY
BAROMETRIC PRESSURE
WIND SPEED
WEATHER SELECT
RAINFALL
INDOOR TEMPERATURE
INDOOR HUMIDITY
LIGHTNING STRIKES (ON/OFF only; ON by default)
High and Low Records
Today’s high and low records are displayed for outdoor temperature and
humidity. Today’s records automatically clear at 12:00am midnight every day.
Historical records (daily, weekly, monthly) can also be viewed by accessing the
records menu. Records include:
OUTDOOR TEMPERATURE
OUTDOOR HUMIDITY
BAROMETRIC PRESSURE
WIND SPEED
RAINFALL
INDOOR TEMPERATURE
INDOOR HUMIDITY
LIGHTNING STRIKES
View Records
1. Press and release the “select” button until the reading for which you wish to
view is shown on the Weather Ticker screen.
2. Press and release the “records” button to enter RECORDS MODE.
3. Press and release the “ ” or “ ” buttons to cycle through available record
values for that reading.
4. Repeat steps 1-3, as needed.
NOTE: To clear a record, press and release the “clear” button while viewing the
record you wish to clear. Dashes display to conrm you have cleared the record.
