The Handy THCGS Installation and maintenance instructions

Page 1
OPERATOR’S MANUAL AND PARTS LIST
CORDLESS GARDEN SPRAYER - THCGS
Spares & Support:01793 333212
www.thehandy.co.uk
Before use please read & understand this manual, paying particular
attention to the safety instructions.
07/06/2012

Page 2
CONTENTS
SAFETY INSTRUCTIONS 3
MAJOR PARTS 4
LIST OF PARTS SUPPLIED 5
SPECIFICATION 5
ASSEMBLY 6-7
MAINTENANCE AND STORAGE 7
PARTS DIAGRAM AND LIST 8
EC DECLARATION OF CONFORMITY 9

Page 3
SAFETY INSTRUCTIONS
Read and understand the owner’s manual and labels afxed to the
garden sprayer. Learn its application and limitations as well as the
specic potential hazards. Retain these instructions for reference.
• Use only with chemicals that are approved and recommended for use
with a battery operated sprayer.
• Neveruseammablesolvents,combustibles,extremelycaustic
solutions or oils.
• The sprayer should only be used by competent adults who have read
this manual. Keep away from children and keep bystanders at a safe
distance.
• Always wear eye protection, rubber gloves and a mask to protect
against the inhalation of chemicals.
• Do not operatethegardensprayerifyouaretired,illorundertheinu-
ence of alcohol or drugs.
• Do notspraytowardsyourself,otherpeople,pets,electricaloutletsor
ames.
• Only use the battery charger indoors.
• Use the sprayer in good visibility - do not use when raining.
• Do not modify the unit in any way as this may be dangerous and
invalidate your warranty.
Additional Warnings relating to Battery/Charger:
• Toreducetheriskofelectricshock,protectthebatterychargerfrom rain
and moisture.
• Recharge the battery only with the charger provided.
• Beforeeachusecheckforsignsofdamageorwornpartsand,iffound,
do not use.
• Toreducetheriskofexplosionsprotectthe battery from heat, such as
continuoussunlightorre and donot short circuit it.

Page 4
MAJOR PARTS
1 Handle 2 Telescopic Tube
3 Spray Gun 4 Fill Cap
5 Tank 6 Bracket
7 Holster 8 Wheel
9Connector 10 Nozzle
11 Trigger 12 Safety Lock
13 Cap 14 Pick-up Tube
15 Spring Tube 16 ExtensionWandNozzle
17 Battery Charger 18 Charge Control Indicator
19 Charging Inlet 20 Plug Connector for Charger
21 Clip 22 Filter

Page5
LISTOFPA RT S SUPPLIED
Carefully remove the sprayer from the packaging and check that all the contents
shown below are included:
1. Tank assembled with bracket, filling cap.
2. Spray Gun assembled with tubes.
3. Telescopic Tube.
4. Handle.
5. Extension Misting Wand.
6. Battery Charger.
7. Instruction Manual.
Please recycle the cardboard packaging in a responsible way.
Contact your local recycling centre for details.
SPECIFICATIONS
Model THCGS
Battery Pack Voltage DC3.6V
Battery Pack Capacity 1300 mAH
Battery Type Lithium-ion
Tank Capacity 11 litres
Charger (adapter) Input AC230V 50Hz
Battery Charging Time 3-5 hours
Sound Pressure Level 67 dB(A) K=3 dB(A)
Sound Power Level 78 dB(A) K=3dB(A)
Vibration 2.1 m/s² K1.5 m/s²

Page 6
ASSEMBLY
Before using for the rst time, the battery must be fully charged.
• Insert the charger cable into the charging inlet on the sprayer.
• Plug the battery charger plug into the ains power supply.
• The ref LED indicator lights up to tell you that the battery pack is on charge.
• The battery is fully charged when the red LED light indicator is no longer lit.
Duringthechargingprocess,thebodyofthesprayerwillwarmup-thisisnormal.
Whennotchargingthesprayer,disconnectthechargerplugfromthemains.
Only charge the battery between temperatures of 10o- 45oC.
To Assemble:
Insertthetelescopictubeintotheholeonthesprayerbodyandxwith anutandscrew.
(Fig 1)
Fit thehandletothetelescopictube,makingsurethatthetwoholesonthehandlelineup
with thetwoholesonthetelescopictube.Fixwithtwoscrewsandnuts.(Fig2and3)
To attach the extension misting wand:
Unscrewtheexistingnozzleandreplacewith theextensionwandnozzle.
To t the Spray Gun Set to the Machine:
• Attachtheguntotheholsterandtightenthexingtape. (Fig6)
Fig 1 Fig 2 Fig 3
Fig 4 Fig 5 Fig 6

Page 7
ASSEMBLY cont’d
Two different nozzles are supplied with the machine. We suggest that the nozzle which is
notinuse,isscrewedontothetelescopictube,asshownbelow(Fig7&8).
• Keep the safety switch in the lock position when not in use.
• Donotswitchbetweendifferentchemicalswithoutrstcleaning the sprayer head
thoroughly.
• Do not store liquids in the tank - always follow the chemical manufacturer’s instructions
for storage and disposal.
• Ensurethatthellercapistightatalltimes.
• Cleanthelterperiodicallytoensuregoodperformance.
• After use rinse out the sprayer and tank with clean water. Run water through the sprayer
for 30 seconds whilepressing the trigger.
• Charge the battery for 3.5 hours before storing.
• Charge the battery at least once every three months to protect it from damage.
• Store the sprayer in a dry place out of the reach of children.
• Do not store where there is static electricity.
This machine contains a Lithium-ion battery and must be disposed of in an environmentally
friendly way. Please refer to your local recycling centre for details.
Fig 7 Fig 8
MAINTENANCE AND STORAGE


PA RTS DIAGRAM
Page8


PA RTS LIST
No. PartNo. Description QTY No PartNo. Description QTY
1 TH154‐1 ScrewsST4.2x13 4 45 TH154‐49 Leftcover 1
2 TH154‐2 BoltM4 2 46 TH154‐51 Smallpole 1
3 TH154‐3 Handlelowercover 1 47 TH154‐52 Motor 1
4 TH154‐4 Innertube 1 48 TH154‐53 Gearbox 1
5 TH154‐6 Knob 1 49 TH154‐54 Gearboxcover 1
6 TH154‐7 Guidesleeve 1 50 TH154‐55 ScrewM2.5x7 2
7 TH154‐8 Outertube 1 51 TH154‐56 Gearshaft3 1
8 TH154‐9 Knob 1 52 TH154‐57 Drivengear 1
9 TH154‐10 ScrewsST3.5x15 6 53 TH154‐58 Biggear 1
10 TH154‐11 Rightcover 1 54 TH154‐59 Gearshaft1 1
11 TH154‐12 Wheelcover 2 55 TH154‐60 Gearboxlowercover 1
12 TH154‐13 Rclip2.5x20 2 56 TH154‐61 Shaftseal 1
13 TH154‐14 Wheel 2 57 TH154‐62 ScrewST2.9x13 4
14 TH154‐15 Axle 1 58 TH154‐63 Seal 1
15 TH154‐16 Watercontainer 1 59 TH154‐64 HexnutM2 4
16 TH154‐17 Support 1 60 TH154‐65 Separationboard 1
17 TH154‐19 Leftcover 1 61 TH154‐66 Oring21.4x13.3x1.5 1
18 TH154‐20 HexnutM5 1 62 TH154‐67 Pumpgear1 1
19 TH154‐21 Boltconnector 5 63 TH154‐68 Gearshaft2 1
20 TH154‐22 Cap 1 64 TH154‐69 Pumpgear2 1
21 TH154‐24 Pipe 1 65 TH154‐70 Inletpipe 1
22 TH154‐25 Connector 1 66 TH154‐72 ScrewST2.9x13 4
23 TH154‐29 Pipe 1 67 TH154‐75 Pipe 1
24 TH154‐30 Connector 1 68 TH154‐77 Pipe 1
25 TH154‐31 Cap 1 69 TH154‐78 Oring 1
26 TH154‐32 Wireclip 1 70 TH154‐79 Spraynozzle 1
27 TH154‐33 Sleeve 1 71 TH154‐80 Block 1
28 TH154‐34 ScrewST2.9x6.5 1 72 TH154‐81 Rotatingcap 1
29 TH154‐35 Band 1 73 TH154‐82 Bigrotatingcap 1
30 TH154‐36 Rivet3x5 1 74 TH154‐83 Tube 1
31 TH154‐37 Pipe 1 75 TH154‐84 Capsleeve 1
32 TH154‐38 ScrewST2.9x13 5 76 TH154‐85 Oring 1
33 TH154‐39 Rightcover 1 77 TH154‐86 Smallrotatingcap 1
34 TH154‐40 Pushbutton 1 78 TH154‐5 Protectorsleeve 1
35 TH154‐41 Button 1 79 TH154‐87 InletFilter 1
36 TH154‐42 Transparentcover 1 80 TH154‐44 Coverforchargingconnectorhole 1
37 TH154‐26 Drainagepluglower 1 81 TH154‐71 Wireclip 1
38 TH154‐28 Drainageplusupper 1 82 TH154‐18 Charger 1
39 TH154‐27 Drainageplug 1 83 TH154‐88 Spring 1
40 TH154‐43 Lightcover 1 84 TH154‐89 Redvulcanizedfibrepaper75*19.5*1 1
41 TH154‐45 PCBboard 1 85 TH154‐90 CrossscrewM2*8HardenAnti‐Rust 4
42 TH154‐46 3.6vBattery 1 86 TH154‐76 Spring 1
43 TH154‐48 Upperhandlecover 1 87 TH154‐23 Filter 1
44 TH154‐47 Screw4x32 2    
Page9

Page 10
EC DECLARATION OF CONFORMITY
Declaration of Conformity
Pursuant to the regulations of the following EC Directives:
- Electromagnetic Compatibility Directive 2004/108/EC
- Machinery Directive 2006/42/EC
Handy Distribution Ltd hereby declares that the product:
Machine Type: Cordless Garden Sprayer
Machine Model: THCGS
Rating: 3.6V dc. 1300mAH
Tank capacity: 11 litres
Spray Distance: 4m
Conforms to the main safety requirements of the EC Directives listed above.
This conformity is based on the following standards and normative documents:
EN60745-1:2009
EN50144-2-7:2000
EN55014-1:2006
EN55014-2/A1:2001
EN61000-6-3:2007
Theresponsibleperson,basedwithintheEC,isidentiedbelow:
Name: Mr Simon Belcher
Title: Managing Director
Company: Handy Distribution Ltd
Address:HobleyDrive,StrattonStMargaret,SWINDON,Wiltshire,SN34NS
Signature:      Date:28thJuly,2010

To order spare parts and see the complete range of garden
machinery and garden equipment from Handy, visit:
www.thehandy.co.uk
Spares & Support: 01793 333212
