The Moorings 4800 User manual

Designed in collaboration between The Moorings Sailing
holidays, architects Simonis-Voogd and catamaran builder
Robertson and Caine, the Moorings 4800 follows in the
footsteps of the popular Moorings 4600, the best-selling
Moorings model to-date. What sets the Moorings 4800
apart is, not only its space, but the introduction of a large
forward cockpit accessible from the saloon; the first ever
on a Moorings yacht.
This forward cockpit previously
made its debut on the award-winning Leopard 44 (Boat
of the Year 2012) and adds additional relaxation space to
an already comfortable and spacious yacht.
The Moorings 4800 features a raised helm station offer ing
excellent visibility and ease of manoeuvres, and here all
sheets and halyards lead in to. Below, the aft cockpit
fea
tures a cockpit table with wrap-around seating and
stools.
Inside a fully fitted modern galley and U-shaped
set
tee in saloon provide ample space for entertaining and
360 degree views allowing plenty of natural
light. Down
below are four air-conditioned private state
rooms with
en suite heads and showers, plus a separate forepeak
berth with head to starboard and a single forepeak berth
to port.
THE MOORINGS
Built by Robertson & Caine to Moorings Specifications
4800
4 cabins - 4 heads

SPECIFICATIONS & EQUIPMENT
GENERAL
The hulls are of GRP construction with
balsa core for strength, stiffness and
insulation, using high quality materials
The hulls are painted with EPA approved
environmentally friendly anti-fouling
Both deck and hull are finished in white
gel coat with the trademark Moorings
striping and M4800 graphics
The deck has a moulded-in nonskid
pattern providing excellent traction
DECK FITTINGS
Guardwires with stanchions, bases, port
& stb side gates
Guardwires across bow and stern
Quick - Aleph 1000 w vertical windlass 10
mm gypsy c/w hand-held remote
Anchor bow roller fitting
Anchor chain stopper
Liferaft locker with convertible fore/aft
seat bolster
Sliding companionway door - 2 leaf
Hardtop over cockpit complete with LED
lighting
Hardtop bimini over helm c/w s/s supports
and LED light
Swimming ladder c/w teak steps
Cockpit table
Furler jammer on deck
Bridle mainsheet system (3:1 purchase)
Trampoline (white Aquabatten Supertramp)
Helmseat
Lifering holder
Acrylic smoke grey tinted windows
Hardtop s/s supports
Side window brows
Helmsman enclosure - includes shade
cloth sides and back
Cockpit side & back shade curtains only
Coach roof side window removable shade
covers
2 x s/s cockpit table stools
Twin fold-away tables in forward cockpit
Davit system with s/s hoop and 12 v reel
winch
Hatches - Bomar:
4 x Size 10 Flush Hatch over heads
4 x Size 44 Flush Hatch over cabins
2 x Size 60 Flush Hatch on foredeck
1 x Size 70 Flush Hatch over cockpit
Portlights - Bomar:
2 x Size 5 in windscreen
10 x Size 1 in hull side and transom
1x Anchor/windlass locker
2 x Foredeck lockers
Forward lounging cockpit with hardtop
c/w watertight saloon access door and
sliding hatch for foredeck access
2 x Seats c/w stowage locker under in
fwd cockpit
2 x Pulpits with seat
2 x Pushpits
2 x Coachroof s/s handrails
7 x 330 mm mooring cleats
2 x Lewmar winch handles
1 x Halyard / sheet electric winch - Lewmar
55EST (alloy)
1 x Halyard / sheet winch - Lewmar 55ST
(alloy)
1 x Main sheet winch - Lewmar 55ST
(alloy)
2 x Lewmar genoa cars with pin stop
2 x Lewmar genoa tracks
1 x Winch handle pocket at helm
2 x Spinlock halyard clutch at helm (Main
& Gennaker)
2 x Spinlock genoa clutch at helm
2 x Spinlock mainsheet clutch at helm
2 x Spinlock reef clutch at helm
4 x Padeyes to allow for gennaker tackle
2 x Drinking can holders
55 lb (25 kg) Delta anchor c/w 165 ft (50
m) chain
35 lb (16 kg) Britany anchor c/w 26 ft (8
m) chain & 200 ft (61 m) warp
Anchor bridle, shackles and hook
Fenders (6 off), moorings lines (4 off 18 mm
x 10 m), spring lines (2 off 18 mm x 15 m)
MAST, RIGGING & SAILS
Sparcraft natural anodized mast
Sparcraft natural anodized crossbeam
c/w mooring cleats
Windex wind indicator
Profurl genoa furler
Mainsail full battened c/w 2 rows reefs
(Quantum)
Boom Cover (Quantum stackpack)
120% Furling genoa
2 x Additional spare 12 v wires in mast
Additional spare conduit with messenger
in mast
RUNNING RIGGING
2 x Main sheets (3:1 purchase)
2 x Genoa sheets
3 x Halyards (main, genoa & spare)
2 x Single line reefs lead aft
Main boom topping lift
RUDDER & STEERING SYSTEM
Balanced spade rudders
Rudder stock in 17-4ph stainless steel
JP3 Self aligning bearings
Edson chain and wire steering system
c/w bulkhead steering unit and brake
Destroyer-type steering wheel
Emergency tiller (s/s)
ENGINE & CONTROLS
Morse double lever throttle / gearshift
control
Sound deadening panels in engine room
2 x Engine room ventilation fans and
ducting
2 x Yanmar 4JH4c 54 hp diesel engines
with SD50 sail drives
2 x Propellers - 3-blade fixed
2 x Fuel deck fillers
2 x Racor fuel filter / water separators
2 x Fuel tanks aluminium 185 US gal. /
700 l total capacity
2 x Exhaust skin fittings (s/s)
2 x Exhaust water locks
2 x Cooling water inlet strainers
2 x Exhaust cooling water temperature
sensors with audible alarms at helm
PLUMBING INSTALLATION
Hot and cold pressurized fresh water
system consisting of:
2 x Water tanks, 206 US gal. / 780 l total
capacity
1 x Additional 58 US gal. / 220 l water
tank
1 x Jabsco Par Max 3.5 GPM fresh water
pressure pump with 1 l Jabsco accumulator
tank
2 x Hot water cylinders 6 US gal. / 23 l
total capacity
1 x Hot/Cold transom shower
4 x Shower drain pumps with filters
2 x Holding tanks, 26 US gal. / 100 l
2 x Electric bilge pumps (keel sump) with
float switches and alarm at switch panel
2 x Manual bilge pumps with strum boxes
(keel sump)
2 x High water bilge float switches with
alarm at switch panel
2 x Electric bilge pumps (engine room)
with alarm at switch panel
ELECTRICAL INSTALLATION
110 v hard wired shore power pack:
includes 2 heavy duty 50 ft 30 a shore
power lines, AC switch panel, AC double
outlets in cabins, galley and at freezer and
switchpanel
LED Courtesy lights at stairways
LED Bi-colour & stern navlights
12 v DC switch panel
2 x 12 v outlet sockets at switch panel and
at helmstation
2 x Fuel tank gauges at helm position
2 x Ammeters at helm position
3 x AGM House batteries 210 ah

2 x AGM Engine starter batteries
1 x House battery isolator switch
1 x Quick battery charger 40 a
2 x Engine starter battery isolator
switches
2 x Alternators, standard with engines
1 x Electrical spares kit: fuses, relays, fuse
holders
1 x Electric fog horn with control at helm
station
Genset:
Northern Lights 9 kw - Fuel supplied by
aft port tank, fuel transfer ability from
stb to port tank
Airconditioning System:
Cruisair: 40,000 BTU Total (2 x 12,000
BTU, 1 x 16,000 BTU) 110 v
23” Flat Screen TV and DVD installed in
saloon area 110 v
2 x Solar panels 70 w each fitted to hard top
Sony CD player with two Polyplanar
speakers in saloon and two Bose marine
speakers in cockpit c/w auxiliary jack
input
External Bose forward cockpit speakers,
inc. fader & amplifier
NAVIGATION EQUIPMENT
Plastimo Contest 130 compass at helm
position
RAY55 VHF radio at helm
ST6002 autopilot, rotary drive, C95W
color chartplotter, ST60 wind instrument,
ST60+ Tridata c/w depth transducer
NAVIGATION CONSOLE
Chart table surface with overhead LED
light
Instrument and switch panel
Chart table bench seat c/w stowage
under cushion
SALOON
Cherry laminate finishes with solid wood
trims
Single saloon table
Settee - U-shape
Wear resistant simulated Austrian Walnut
flooring
LED overhead lighting
Ample ventilation through fwd facing
portlights
Stowage space under settee cushions
2 x Vetus Magnus 5151 LS escape
hatches under stairways to hulls
Front doorway access to forward cockpit
GALLEY
Corian galley worktop surfaces
Single lever mixer faucet
Double s/s sink
Dish and cutlery drying recess with
drainage
Cover for drying recess
Vitrifrigo 2 drawer front opening fridge/
freezer, 56 US gal. / 212 l 12 v refrigeration
Microwave oven (110 v)
Force 10 gas cooker 3-burner c/w oven
& broiler
Gas solenoid shut-off valve with control
at switch panel & warning light at cooker
Gas cylinder regulator in dedicated
cockpit LPG locker
Separate garbage bin locker with side &
top access
Stowage space in shelf & drawer lockers
Corian galley shelf with spice rack
CABINS x 4
Cherry laminate finishes with solid wood
trims
Double berths:
- Fwd Bunks (60 in. / 1.52 m x 80 in. / 2.05 m)
- Aft Bunks (60 in. / 1.52 m x 80 in. / 2.05 m)
Hanging locker
Storage locker with shelving
LED overhead lighting
LED reading lamps
Overhead roller blinds for privacy
Large open shelves
Stowage space under bunk
Large hull window incorporating portlight
and pleated blind
HEADS COMPARTMENTS x 4
Washbasins with basin mixer and Corian
worktop
Vanity locker with mirror
Towel hook, rail and ring
Separate shower compartment with
Perspex door
c/w lever mixer and adjustable shower
rose
Shower sump with push-button drainage
LED Overhead lighting
Overhead roller blinds for privacy
Electric Jabsco quiet flush large bowl toilet
FOREPEAKS x 2
STBD incl. light, fan, Jabsco large bowl
manual toilet, hand basin c/w combination
faucet/shower mixer
PORT incl. light & fan
GENERAL EQUIPMENT
4 x Fire extinguishers
Owner’s Operating Manual
CE Certification
NMMA Certification
Illustrations, equipment and specifications are subject to change without prior notice, as the company and builder reserve the right to modify or improve this model. Last edited, April 2013

Technical Information
Length Overall 48 ft 5 in. / 14.75 m
Hull Length 45 ft 5 in / 13.85 m
Beam 25 ft / 7.64 m
Draft 4 ft 7 in / 1.40 m
Sail Area 1,555 sq ft / 144.5 sq m
Engines 2 x 54 hp
Fuel Capacity 185 gal. / 700 l
Water Capacity 211 gal. / 800 l
Berths 8 + 2 in fore peaks
Displacement 31,956 lb / 14,460 kg
Heads 4 + 1 in fore peak
Showers 5
