GENERAL WARNINGS
This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capacities, or by persons lacking
experience or knowledge, unless they have received adequate supervision
or preliminary instructions on how to use the appliance from a person in
charge of their safety.
Children should be supervised to ensure that they do not play with the
appliance.
This appliance may be used by children aged 8 or older and persons with
reduced physical, sensory or mental capacities, or lacking experience
and knowledge, if they are properly supervised or if they have received
instructions for using the appliance safely and if the risks entailed are taken
into account. Children must not play with the appliance. The appliance
must not be cleaned or serviced by children without supervision.
INSTALLATION
IMPORTANT: Heavy product: to be handled with care.
The installation and commissioning work on Aéromax Piscine may pose
hazards due to high pressures and live parts. Aéromax Piscine must be
installed, commissioned and serviced by trained and qualified personnel
only.
The pressure gauge present on the side of the product can be used to
check that the gas load is compliant. If it is less than 8 bar (0.8 MPa), please
contact the After-Sales service.
Aéromax Piscine must be installed outside, with free space around it
and close to the equipment shed. The clearance required to install the
appliance correctly is specified in the figures on pages 8 to 11.
This manual should be kept even after the product has
been installed.
EN

GENERAL WARNINGS
HYDRAULIC CONNECTION
Respect the order of the various hydraulic equipment (see page 12).
This product was designed to operate at air temperatures of between
2 °C and 35 °C inclusive, and water temperatures of above 4 °C
When winterizing your pool, you must also shut down Aéromax Piscine to
prevent any risk of failure during the winter, in particular frost-induced
damage to the exchanger.
ELECTRICAL CONNECTION
Be sure to turn off the power before removing the cover, to prevent any
risk of injury or electric shock.
The connection must comply with installation standard NFC 15-100, or the
recommendations in force in the country in which Aéromax Piscine is to be
installed (see page 13).
Upstream of the appliance, the electrical installation must have an all-pole
cut-out device (circuit-breaker, fuse) compliant with the local installation
rules in force (30 mA residual current device).
If the power cable is damaged, it must be replaced by the manufacturer,
its After-Sales service or a similarly qualified professional to prevent any
hazards.
Earthing is mandatory. A special terminal marked is provided for this
purpose.
The ventilation hole must not be obstructed.
Service operations may only be performed on the refrigerant circuit by a
skilled and authorised refrigeration engineer.
The user manual for this appliance can be obtained from the After-Sales
service.
These appliances comply with Directives 2014/30/EU on electromagnetic
compatibility, 2014/35/EU on low voltage, and 2011/65/EU on ROHS.
Environment: Do not dispose of your appliance with household
waste; take it to an official collection point for recycling.

Présentation du matériel ......................................2
Caractéristiques...............................................................................2
Les accessoires compatibles............................................................4
Installation .............................................................8
Mise en place du chauffe-eau........................................................8
Raccordement hydraulique ............................................................9
Raccordement électrique .............................................................11
Mise en service du chauffe-eau ..........................15
Remplissage du chauffe-eau........................................................15
Vérification du bon fonctionnement ..........................................15
Mise en service de la commande nomade.........16
Réglage de la molette ..................................................................16
Installation des piles sur la commande nomade.........................16
Procédure d'association avec le chauffe-eau..............................17
Réglage date et heure..................................................................18
Emplacement de la commande nomade.....................................20
Recommandations du GIFAM..............................22
Risques mécaniques......................................................................22
Risques électriques........................................................................22
Risques hydrauliques ....................................................................22
Manuel d’installation
Chauffe-eau
et commande digitale nomade
Sommaire
Manuel à conserver même après installation du produit.
Manuel installation FR.book Page 1 Mercredi, 23. décembre 2009 10:13 10
Installation and
maintenance manual
Aéromax Piscine
Contents
Product presentation ..................................................... 4
Important recommendations ................................................. 4
Packaging contents ................................................................. 4
Handling, Transport, Storage ................................................. 4
Operating principle ................................................................. 5
Technical specifications ........................................................... 6
Installation ...................................................................... 7
Tools required .......................................................................... 7
Additional equipment ............................................................ 8
Selecting the installation location ......................................... 8
Positioning the product ........................................................ 10
Opening the product ............................................................ 11
Hydraulic connection ............................................................ 12
Electrical connection ............................................................. 12
Commissioning and initial settings ...................................... 13
Use.................................................................................. 15
Remote control ...................................................................... 15
Parameter table ..................................................................... 16
Default display ...................................................................... 16
Time setting ........................................................................... 16
Operating mode setting ....................................................... 17
Setpoints and parameters...................................................... 17
Clock mode ............................................................................ 17
Informative operating values ............................................... 17
Locking the remote control keypad ..................................... 18
Winterizing - Recommissioning ................................... 18
Preparing for winter ............................................................. 18
Precautions - Start of season ................................................ 18
Servicing - Maintenance - Troubleshooting ................ 19
User advice ............................................................................. 19
Maintenance .......................................................................... 19
Fault diagnostics .................................................................... 20
Warranty........................................................................ 22
Scope of the warranty .......................................................... 22
Warranty conditions ............................................................. 22
Warranty ................................................................................ 23
3
EN

EN
4
1. Product presentation
1.1. Important recommendations
The installation and commissioning work on Aéromax Piscine may pose hazards due to high pressures
and live parts.
Aéromax Piscine must be installed, commissioned and serviced by trained and qualified personnel
only.
1.2. Packaging contents
1.3. Transport, Handling and storage
Storage and transport of the Aéromax Piscine in the horizontal position are prohibited, since it
could be damaged. Handle the appliance with care. It is formally prohibited to handle Aéromax
Piscine via the water inlets and outlets. Our liability cannot be incurred for any product defect
resulting from transport or handling of the product not in accordance with our recommendations.
When handling the unit, keep in mind the following points:
•
Fragile, handle with care.
•
Keep the box oriented so that these arrows are always pointing upward, to prevent any
damage to the compressor.
• Before picking up, make sure that the product has an unobstructed transport path.
• Move the product with its original package, mounted upright on its pallet.
• Before lifting the product, be aware off its off-centred centre of gravity.
Aéromax Piscine
Winterizing tarpaulinRemote control extension (10 m)
Manual Mounting system (x4)
Water inlet and outlet screw-in
connector (x2)
Condensate drainage connector
(x2)
Vibration isolators
(x8)
Mounting guard plate + screws
Installation manual: Product presentation
Some parts may be delivered inside Aéromax Piscine, depending on the model.
The pressure gauge present on the side of the product can be used to check that the
gas load is compliant. If it is less than 0.8 MPa, please contact the After-Sales service.

EN
5
EN
1.4. Operating principle
Aéromax Piscine uses outside air to heat the water in your pool. The refrigerant contained in
Aéromax Piscine completes a thermodynamic cycle, enabling it to transfer the energy contained
in the outside air to the pool water.
The fan generates an air flow into the evaporator. The refrigerant evaporates upon entering the
evaporator.
The compressor compresses the fluid vapour, raising its temperature. This heat
is transmitted to the pool water via the titanium exchanger.
The refrigerant then passes into an expansion capillary, where it cools and reverts to liquid form.
It is then once more ready to receive heat in the evaporator.
Installation manual: Operating principle
Accepted position Prohibited positions
on one side
inverted
laid down
  

Air aspiré
Air refoulé
DétendeurCompresseur
Sortie
eau chaude
Échangeur
Entrée
eau froide
Discharged air
Expansion valveCompressor
Hot
water outlet
Cold water
inlet
Exchanger
Air intake

EN
6
1.5. Technical specifications
Installation manual: Technical specifications
Aéromax
Piscine 8
Aéromax
piscine 10
Aéromax
piscine 12
Aéromax
piscine 14
Performance measured at: Air 15 °C / Water 26 °C
Power output (kW) 7.60 10.00 11.30 13.60
Power input (kW) 1.65 2.27 2.46 3.02
COP 4.60 4.40 4.60 4.50
Performance measured at: Air 24 °C / Water 26 °C
Power output (kW) 9.50 12.50 14.00 17.00
Power input (kW) 1.73 2.36 2.55 3.15
COP 5.50 5.30 5.50 5.40
Recommended pool
volume (m
3
)* up to 50 m
3
up to 65 m
3
up to 75 m
3
up to 90 m
3
Power supply
(Voltage / phase / frequency) 230 V~ / 1 / 50 Hz
Rated current (A) 8.8 11.5 12.9 15.6
Maximum power (W) 2100 2390 2820 3180
Water flow rate (m
3
/h) 6.0 7.0 7.0 10.0
Exchanger Titanium
Hydraulic connectors Ø 50 mm
Acoustic pressure at 1 m
(db(A)) 54 55 56 56
IP IP X4
Refrigerant R410A
Maximum pressure 3.8 MPa
GWP 2088
Fluid load (g) 1100 1250 1500 1500
T equivalent CO
2
2.30 2.61 3.13 3.13
Dimensions (l x w x h) 1057 x 347 x 620 1057 x 347 x 620 1115 x 394 x 706 1115 x 394 x 706
Packed dimensions (l x w x h) 1087 x 378 x 750 1087 x 378 x 750 1145 x 427 x 840 1145 x 427 x 840
Net weight (kg) 66 72 85 100
Gross weight (kg) 87 93 111 126
Water temperature
setting range 8 ° to 40 °C
Operating range This product was designed to operate at air temperatures
of between 2 °C and 35 °C inclusive, and water temperatures of above 4 °C
*Indicative values, depending on the specifications of each pool.

EN
7
EN
Dimensions - Aéromax Piscine 8 and Aéromax Piscine 10 models
Dimensions - Aéromax Piscine 12 and Aéromax Piscine 14 models
2. Installation
2.1. Tools required:
• Phillips screwdriver
• Drill gun
• Ø 10 mm drill bit
• Hammer
• Open-ended spanner
• Saw (cutting PVC pipes)
• Sandpaper
• Cutting pliers
• Stripping pliers
• Rule
• Spirit level
Installation manual: Fitting Aéromax Piscine
1057
1115
673
643
620.5706342 295
394 347
347
394
321

EN
8
2.2. Additional equipment:
• ¼-turn valve (X3)
• Ø50 PVC connector (depending on installation)
• High-pressure PVC pipe (rigid or flexible)
• Connector glue (blue)
• Power cable / circuit breaker (see table on p. 12)
• Acetone
• Internal Ø 16 mm pipe for condensate drainage.
2.3. Selecting the installation location
Aéromax Piscine must be installed outside,
with free space around it and close to the
equipment shed (filtration, water treatment,
circulation pump, etc.) .
Minimum clearance distances (mm):
Installation manual: Installation
min. 500
min. 500min. 500
min. 4000



discharged
air
DO DO NOT DO
Where possible, install the product
away from property boundaries.
Avoid orienting the product to face neighbouring
properties.




EN
9
EN
Installation manual: Installation
DO DO NOT DO
Install the product away from windows.
Avoid installing the product in a corner
or in a small enclosure
Aéromax Piscine must be mounted on a flat, stable
surface that is sufficiently solid to bear the weight of
Aéromax Piscine in operation.
If the support surface has a slight slope (max. 5 °),
make sure that the condensate is correctly drained.

 

 

max. 5 °

EN
10
Installation manual: Installation
DO DO NOT DO
Aéromax Piscine must be installed
at least 3.50 m from the pool
to protect it from splashes (NFC 15-100).
Aéromax Piscine must not be oriented either
to face the pool or a terrace,
to prevent disturbance caused by the fresh air flow.
Do not place anything on top of the appliance.
2.4 Positioning the product:
Anchoring the product:
Position Aéromax Piscine in its designated place, and mark the position of the drill holes.
Drill the holes and fit the mountings.
 

 

min. 3.50 m
 
Aéromax Piscine 8
and Aéromax Piscine 10
Aéromax Piscine 12
and Aéromax Piscine 14
643 673
295 342

EN
11
EN
Installation manual: Installation
Fit the rubber isolators to
limit vibrations and noise,
and then anchor Aéromax Piscine.
2.5 Opening the product:
1 - Remove the 4 mounting screws
2 - Pull on the bottom part of the front panel to unclip it
3 - Pull on the top part of the front panel to slide out the hooks
4 - Lift up the front panel
Rubber isolators
Fit the bends and condensate drainage pipes (if necessary) before anchoring
Aéromax Piscine.
Ground
Aéromax Piscine








EN
12
Installation manual: Installation
2.6. Hydraulic connection:
The Aéromax Piscine must be connected with pipes and a PVC pressure connector with Ø 50 mm.
2.7. Electrical connection:
Ensure that the electrical installation is designed to be able to connect the whole
of the installation and is compliant with the standards (NFC 15-100).
Power (kW) Rated current (A) D curve
circuit breaker (A)
Cable diameter*
(mm2)
8 8.8 16 3G 2.52
10 11.5 16 3G 2.52
12 12.9 16 3G 2.52
14 15.6 20 3G 42
* Data provided for information purposes for a heat pump power cable less than 20 m long. In case
of a longer cable, please refer to the standard.
Please adhere to the order of the various equipment:
• Circulation pump / Filter
• Aéromax Piscine
• Water treatment
All electrical installation or connection work must be carried out with the power off.
Groupe de
ltrage
Local technique
Vers la
piscine
Depuis la piscine
V2V3
V4
V1
Pompe
Bypass
Equipment shed
To pool
Filter unit
Pump
From pool

EN
13
EN
Installation manual: Installation
Aéromax Piscine must receive a constant power supply during its operating season.
Aéromax Piscine must be connected to a 230 V AC network. The connection must comply with
installation standard NFC 15-100, or the recommendations in force in the country in which
Aéromax Piscine is to be installed.
Protection required:
• An all-pole cut-out device (D curve).
• A 30 mA residual current device.
• Earthing is mandatory.
Accessing the connection terminal block:
• Unscrew the upper plastic cover.
• Unscrew the electrical compartment protective plate.
• Electrically connect the product, feeding the cable through the gland.
• Use the cable clamp to lock the cable in position.
Please note: If you want to move the remote control, you need to connect the extension before
closing the cover.
2.8. Commissioning and flow rate setting:
Filling with water:
• Fully open bypass valve 1,
and close valves 2 and 3.
• Start up the circulation pump.
• Gradually and fully open valve 3
(Aéromax Piscine outlet).
• Gradually and fully open valve 2
(Aéromax Piscine inlet).
• Check the sealing of the entire circuit.
• Fully close bypass valve 1.
The protective covers must always be reclosed before powering on.
Groupe de
ltrage
Local technique
Vers la
piscine
Depuis la piscine
V2V3
V4
V1
Pompe
Bypass
Pump

EN
14
Installation manual: Installation
Start-up:
• Power on Aéromax Piscine via
your switch board.
Aéromax Piscine will be in standby mode,
with ambient temperature displayed on the remote control.
• Press the button on the remote control.
• The fan should start up, followed moments later by the
compressor.
• Once the Aéromax Piscine compressor has run for a few
minutes, check that the air discharged by the fan is being
cooled.
Check that after the water circulation pump is switched off, Aéromax Piscine also switches off.
The message should be displayed on the remote control.
Then restart the circulation pump. The message should disappear and Aéromax Piscine should
restart. This may take a few minutes.
Flow rate setting:
• View the Aéromax Piscine inlet temperature
S E T
IN
NO.
ROOM
OUT
VALVE
TEMP
HUM
FAN
ON
OFF
and
outlet temperature
S E T
IN
NO.
ROOM
OUT
VALVE
TEMP
HUM
FAN
ON
OFF
on the remote control.
• To ensure the best possible performance, the target
temperature difference between the inlet and outlet is 2 °C.
To achieve this difference, adjust the main bypass valve (V1).
• To reduce the difference, reduce the opening of the
stepper valve (V1).
• To increase this difference, open the stepper valve (V1).
• If does not appear when the circulation
pump is running, ensure that valves V2 and V3 are open,
and that valve V1 is closed.
C
C
IN OUT
C
ROOM
Aéromax Piscine can only start if the water
is circulating inside.
Each valve position change requires you to wait a few seconds, to view the effect on
the remote control display.
Once the setting has been confirmed, mark the position of the levers on the valves,
in order to facilitate recommissioning after winterizing.
To rapidly heat up the pool, it is advisable to run the circulation pump and
Aéromax Piscine continuously (24 h a day) until the desired temperature setpoint is
reached. (This may take several days)
1
0
AUTO
1
0
AUTO
1
0
AUTO

EN
15
EN
Installation manual: Use
3. Use
3.1. Remote control:
Auto mode (heating + cooling)
Cooling mode
Heating mode
Start / standby button
Switch mode button
Set values / lock buttons
Select parameters or confirm button
Set programming button
Temperature viewing mode
Parameters setting mode
Parameter number
Outdoor temperature
Aéromax Piscine water inlet temperature
Aéromax Piscine water outlet temperature
1
2
MIN
TEMP
ON
OFF
C
C
IN
S E T
O U T
ROOM
NO.
S E T
IN
NO.
ROOM
OUT
VALVE
TEMP
HUM
FAN
ON
OFF
S E T
IN
NO.
ROOM
OUT
VALVE
TEMP
HUM
FAN
ON
OFF
S E T
IN
NO.
ROOM
OUT
VALVE
TEMP
HUM
FAN
ON
OFF
S E T
IN
NO.
ROOM
OUT
VALVE
TEMP
HUM
FAN
ON
OFF
S E T
IN
NO.
ROOM
OUT
VALVE
TEMP
HUM
FAN
ON
OFF
S E T
IN
NO.
ROOM
OUT
VALVE
TEMP
HUM
FAN
ON
OFF
S E T
IN
NO.
ROOM
OUT
VALVE
TEMP
HUM
FAN
ON
OFF
S E T
IN
NO.
ROOM
OUT
VALVE
TEMP
HUM
FAN
ON
OFF
S E T
IN
NO.
ROOM
OUT
VALVE
TEMP
HUM
FAN
ON
OFF

EN
16
Installation manual: Use
3.2. Parameter table:
Only the , and parameters may be modified.
Num Setting
range
Default
setting
00 Temperature setpoint
in cooling mode 8 28 °C 12 °C
01 Temperature setpoint
in heating mode 15 40 °C 28 °C
02 Operating time before the defrosting
cycle starts - 30 mins
03 Evaporator temperature
activating the defrosting cycle -
-7 °C
"-" is not
displayed
04 Evaporator temperature
deactivating the defrosting cycle - 13 °C
05 Defrosting time - 8 mins
06 Number of compressors in the system - 1
07 Restart after power outage - 1 (yes)
08 Operating type
• Heating and cooling: 1 - 1
09 Operating mode
• Circulation pump always running: 0 - 0
10 Temperature setpoint
in AUTO mode 8  40 °C 28 °C
11 Expansion valve management (auto: 1) - 1
12 Overheating target - 5 °C
13 Expansion valve manual setting in cooling mode - 35
14 Expansion valve manual setting in heating mode - 35
3.3. Default display:
• In standby mode: outdoor temperature and time.
• In operation: water inlet and outlet temperatures, and time.
3.4. Time setting:
• Press and hold
S E T
IN
NO.
ROOM
OUT
VALVE
TEMP
HUM
FAN
ON
OFF
for 5 seconds, until the hours start to flash.
• Set the hours using the and buttons.
• Press
S E T
IN
NO.
ROOM
OUT
VALVE
TEMP
HUM
FAN
ON
OFF
• Set the minutes using the and buttons.
• Press
S E T
IN
NO.
ROOM
OUT
VALVE
TEMP
HUM
FAN
ON
OFF
to confirm.
S E T
IN
NO.
ROOM
OUT
VALVE
TEMP
HUM
FAN
ON
OFF
S E T
IN
NO.
ROOM
OUT
VALVE
TEMP
HUM
FAN
ON
OFF
S E T
IN
NO.
ROOM
OUT
VALVE
TEMP
HUM
FAN
ON
OFF

EN
17
EN
Installation manual: Use
3.5. Operating mode setting:
• Press to select the operating mode.
3.6. Parameter settings:
For the , and parameters:
• Press
S E T
IN
NO.
ROOM
OUT
VALVE
TEMP
HUM
FAN
ON
OFF
until you reach the desired parameter, then select the value using the and
keys.
• The appliance will exit
S E T
IN
NO.
ROOM
OUT
VALVE
TEMP
HUM
FAN
ON
OFF
mode after 5 seconds without any activity on the remote control.
The to parameters are provided for information purposes only.
3.7. Clock mode:
It is possible to program up to 2 operating time frames for your Aéromax Piscine on your remote
control.
• Press and hold for 5 seconds until flashes.
• Set the hours and minutes for the start of the first time frame using and .
• Press until flashes
• Set the hours and minutes for the end of the first time frame using and .
• Press .
You have the option of:
• Setting the 2nd time frame following the same procedure.
• Confirming by leaving the hours and minutes at zero on the 2nd time frame.
3.8. Informative operating values:
If Aéromax Piscine is running, pressing and enables you to view
4 operating temperature data.
• the exchanger's inlet temperature
S E T
IN
NO.
ROOM
OUT
VALVE
TEMP
HUM
FAN
ON
OFF
and outlet temperature
S E T
IN
NO.
ROOM
OUT
VALVE
TEMP
HUM
FAN
ON
OFF
.
• the evaporator temperature P1.
• temperature P2 (not used).
• the outdoor temperature
S E T
IN
NO.
ROOM
OUT
VALVE
TEMP
HUM
FAN
ON
OFF
.
S E T
IN
NO.
ROOM
OUT
VALVE
TEMP
HUM
FAN
ON
OFF
S E T
IN
NO.
ROOM
OUT
VALVE
TEMP
HUM
FAN
ON
OFF
S E T
IN
NO.
ROOM
OUT
VALVE
TEMP
HUM
FAN
ON
OFF
AUTO mode
S E T
IN
NO .
ROOM
OUT
VALVE
TE M P
HUM
FAN
ON
OFF
enabling automatic heating and cooling of the water.
This operating mode may be useful in case of a high outdoor temperature,
to keep the pool water at the desired temperature.

EN
18
Installation manual: Use
3.9. Locking the remote control keypad:
Hold and simultaneously for 5 seconds
to lock the remote control keypad.
Follow the same procedure to unlock.
4. Winterizing - Recommissioning
4.1. Preparing for winter:
To do so, you need to:
• Cut the power supply to the circuit breaker.
• Close the inlet valve (2) and outlet valve (3) on Aéromax Piscine.
• Empty the entire Aéromax Piscine water circuit by unscrewing the water inlet and outlet
connectors on the rear of the product, or opening the drainage circuit valve (if any).
• After making sure that there is no water left in the circuit, screw these connectors back in,
to prevent any foreign bodies from getting into the circuit.
• Place the winterizing tarpaulin over the product.
We cannot be held liable for any fault in a product if the winterizing rules have not been complied
with.
4.2. Precautions - Start of season:
When reactivating your pool and Aéromax Piscine, you need to:
• Remove the winterizing tarpaulin.
• Clean the fan to remove any objects that might impede start-up, and also the evaporator
(rear grille), using a soft-bristled brush and taking care not to bend the blades.
• Check the tightness of the connectors.
• Follow the start-up procedure described on page 13 of the manual, and reset the bypass
valves if necessary.
C
C
IN OUT
When winterizing your pool, you must also shut down Aéromax Piscine to prevent
any risk of failure during the winter, in particular frost-induced damage to the
exchanger.
