THERMOROSSI LAMBDA S29 EVO5 Installation and operating instructions

LAMBDA S29 –S35 –S46 EVO5
ITA - MANUALE DI INSTALLAZIONE, USO E MANUTENZIONE.
FRA - MANUEL D’INSTALLATION, D’UTILISATION ET D’ENTRETIEN.
ENG - INSTALLATION, USE AND MAINTENANCE GUIDE.
DEU - INSTALLATIONS-, BETRIEBS- UND WARTUNGSANLEITUNG.
ESP - MANUAL DE INSTALACIÓN, USO Y MANTENIMIENTO.
ITA - Informazioni importanti per la sicurezza ed il corretto funzionamento.
FRA - À lire impérativement ! Informations importantes pour la sécurité et le bon fonctionnement.
ENG - Must read! Important information for safety and correct operation.
DEU - Unbedingt lesen! Wichtige Informationen zur Sicherheit und zum sicheren Betrieb.
ESP - ¡Leer! Informaciones importantes para la seguridad y el correcto funcionamiento.

Installation, use and maintenance guide
LAMBDA S29 –S35 –S46 EVO5
Page 1
ENG

Installation, use and maintenance guide
LAMBDA S29 –S35 –S46 EVO5
Page 2
ENG
INDEX
1 –INTRODUCTION.................................................................................................................................. 4
2 –TECHNICAL CHARACTERISTICS...................................................................................................... 6
3 –GENERAL DESCRIPTION.................................................................................................................. 8
4 –INSTALLATION..................................................................................................................................10
5 –MOUNTING THE MOTOR-OPERATED ANTICONDENSATION UNIT ..............................................23
6 –USE OF THE GENERATOR...............................................................................................................26
7 –CLEANING AND MAINTENANCE .....................................................................................................31
8 –ALARMS ............................................................................................................................................34
9 –SMOKE DISCHARGE TUBE..............................................................................................................35
10 –ROOM VENTILATION......................................................................................................................37
11 –ELECTRICAL WIRING.....................................................................................................................38
12 –TROUBLESHOOTING CAUSE - SOLUTION...................................................................................39

Installation, use and maintenance guide
LAMBDA S29 –S35 –S46 EVO5
Page 3
ENG
EU Declaration of Conformity (DoC) / Dichiarazione di Conformità UE (DoC)
Company name:
Azienda:
THERMOROSSI S.P.A.
Postal address:
Indirizzo:
VIA GRUMOLO, N° 4
Postcode and city:
Codice postale e città:
36011 ARSIERO (VI)
Telephone number:
Numero di telefono:
0445/741310
E-mail address:
Indirizzo e-mail:
[email protected]
declare that the DoC is issued under our sole responsibility and belongs to the following product:
dichiara che la dichiarazione viene rilasciata sotto la propria responsabilità e si riferisce al seguente prodotto:
Apparatus model / Product:
Descrizione prodotto:
Wood logs boiler
Caldaia a legna
Trademark:
Marchio:
THERMOROSSI S.P.A.
Models:
Modelli:
LAMBDA S29 EVO5
LAMBDA S35 EVO5
LAMBDA S46 EVO5
The object of the declaration described above is in conformity with the relevant Union harmonisation legislation:
L'oggetto della dichiarazione di cui sopra è conforme alla pertinente normativa di armonizzazione dell'Unione:
•Direttiva 2014/30/UE, EMCD
•Direttiva 2014/35/UE, LVD
•Direttiva 2011/65/UE, RoHS
•2014/30/EU Directive, EMCD
•2014/35/EU Directive, LVD
•2011/65/EU Directive, RoHS
Sono state applicate le seguenti norme armonizzate e/o specifiche tecniche:
The following harmonised standards and/or technical specifications have been applied:
EN 55014-1
EN 55014-2
EN 61000-3-2
EN 61000-3-3
EN 60335-1
EN 60335-2-102
EN 62233
EN 50581
EN 303-5 tests carried out by the notified laboratory Kiwa Cermet Italia S.p.a (N.B. 0476) Viale Venezia, 45 31020 San
Vendemiano (TV).
Arsiero, 10/04/2023
Firma/Sign.
IT –SCHEDA PRODOTTO (UE 2015/1187)
EN –PRODUCT FICHE (EU 2015/1187)
FR –FICHE PRODUIT (UE 2015/1187)
NL –PRODUCTGEGEVENSBLAD (EU 2015/1187)
DE –PRODUKTDATENBLATT (EU 2015/1187)
ES –FICHA DE PRODUCTO (UE 2015/1187)
IT –MARCHIO
EN –BRAND
FR –MARQUE
NL –MERK
DE –MARKE
ES –MARCA
THERMOROSSI S.P.A.
IT –MODELLO
EN –MODEL
FR –MODÈLE
NL –MODEL
DE –MODELL
ES –MODELO
LAMBDA S29
EVO5
LAMBDA S35
EVO5
LAMBDA S46
EVO5
IT –CLASSE DI EFFICIENZA ENERGETICA
EN –ENERGY EFFICIENCY CLASS
FR –CLASSE D'EFFICACITÉ ÉNERGÉTIQUE
NL –ENERGIE EFFICIENTIEKLASSE
DE –ENERGIEEFFIZIENZKLASSE
ES –CLASE DE EFICIENCIA ENERGÉTICA
A +
A +
A +
IT –POTENZA TERMICA NOMINALE
EN –RATED HEAT OUTPUT
FR –PUISSANCE THERMIQUE NOMINALE
NL –NOMINALE WARMTEAFGIFTE
DE –NENNWÄRMELEISTUNG
ES –POTENCIA CALORÍFICA NOMINAL
30 kW
31 kW
40 kW
IT –INDICE DI EFFICIENZA ENERGETICA
EN –ENERGY EFFICIENCY INDEX
FR –INDICE D'EFFICACITÉ ÉNERGÉTIQUE
NL –ENERGIE-EFFICIENTIE-INDEX
DE –ENERGIEEFFIZIENZINDEX
ES –ÍNDICE DE EFICIENCIA ENERGÉTICA
116
117
123
IT –EFFICIENZA ENERGETICA STAGIONALE DI RISCALDAMENTO DI AMBIENTE
EN –SEASONAL SPACE HEATING ENERGY EFFICIENCY
FR –EFFICACITÉ ÉNERGÉTIQUE SAISONNIÈRE POUR LE CHAUFFAGE DES LOCAUX
NL - SEIZOENSGEBONDEN ENERGIE-EFFICIËNTIE VOOR RUIMTEVERWARMING
DE –RAUMHEIZUNGS-JAHRESNUTZUNGSGRAD
ES –EFICIENCIA ENERGÉTICA ESTACIONAL DE CALEFACCIÓN DE ESPACIOS
79%
80%
84%
IT –RISPETTARE TUTTE LE ISTRUZIONI RIPORTATE SUL MANUALE DI INSTALLAZIONE USO E MANUTENZIONE
EN –ALWAYS FOLLOW THE INSTRUCTIONS PROVIDED IN THE OPERATING AND MAINTENANCE MANUAL
FR –RESPECTER TOUTES LES INSTRUCTIONS CITÉES DANS LA NOTICE D’INSTALLATION, UTILISATION ET ENTRETIEN
NL –VOLG ALTIJD DE INSTRUCTIES VAN DE INSTALLATIE-, GERUIKERSHANDLEIDING EN DE ONDERHOUDSVOORSCHRIFTEN
DE –ERFÜLLEN DIE ANWEISUNGEN DER INSTALLATION, NUTZUNG UND WARTUNG, DIE IN DEM ANLEITUNGSBUCH SIND
ES –RESPECTAR LAS INSTRUCCIONES REPORTADAS EN EL MANUAL DE UTILIZACIÓN Y MANTENIMIENTO

Installation, use and maintenance guide
LAMBDA S29 –S35 –S46 EVO5
Page 4
ENG
1 –INTRODUCTION
1.1 SAFETY GUIDELINES
This installation, use and maintenance manual is an integral and essential part of the product and must be kept by the user. Before
commencing with the installation, use and maintenance of the product, carefully read this guide. All local, national and European
regulations regarding the installation and use of the appliance must be met. The Manufacturer recommends carrying out all the
maintenance operations described in this manual.
This appliance must only be used as intended by the manufacturer. Any other use is considered incorrect and therefore hazardous;
consequently, the user shall be totally liable for the product if used improperly. Installation, maintenance and repairs must be carried
out by professionally qualified personnel, certified according to Decree no. 37 of 22 January 2008 and in compliance with current
regulations. In case of repairs only original spare parts supplied by the manufacturer must be used. Incorrect installation or poor
maintenance can injure or damage people, animals or things; in this case the manufacturer shall be relieved of all responsibility.
Before beginning any cleaning or maintenance operation switch off the appliance by means of the 0/I main switch and disconnect
the plug from the electrical power socket. The product must be installed in locations suitable for fire-fighting and furnished with all
the services (power and outlets) which the appliance requires for a correct and safe operation. Any repairs or actions carried out on
any systems, components or internal parts of the appliance, or on any of the accessories supplied with it, that are not specifically
authorised by Thermorossi S.p.A, will automatically void the warranty and the manufacturer's responsibility, pursuant to Italian
Decree no. 224 of the President of the Republic of 24/05/1988, art. 6/b.
It is recommended to keep this manual in a safe place that is easily accessible to all users; if the manual is lost or deteriorated
contact the manufacturer for a replacement copy. If the appliance is sold or transferred to another user ensure that the manual is
handed over with it. The images and figures featured in this manual are purely illustrative and may differ from the actual product.
Furthermore, Thermorossi reserves the right to apply changes to the content of this manual anytime and without notice.
Thermorossi S.p.A. retains copyright on this manual. These instructions may not be reproduced or communicated to third parties or
used in any other way without the necessary authorisation.
1.2 SAFETY STANDARDS
PERSONAL INJURY
This safety symbol identifies important messages throughout the manual. Read the information marked by this symbol
carefully as non-observance of this message can cause serious injury to persons using the appliance.
DAMAGE TO PROPERTY
This safety symbol identifies messages or instructions that are fundamental for the generator to function well. To avoid
serious damage to the appliance, adhere strictly to these instructions.
INFORMATION
This symbol indicates important instructions for good functioning of the generator. If this information is not correctly
observed, the performance of the appliance will not be satisfactory.
1.3 RECOMMENDATIONS
ATTENTION: It is mandatory for the appliance to be inspected by an Authorised Technical Service
Centre within 30 days from its installation. Once this time has elapsed the manufacturer’s
warranty will be immediately voided, as specified in the warranty certificate.
Before using the appliance, carefully read every section of this installation, use and maintenance guide as knowledge
of the information and the regulations contained in it are essential for a correct use of the appliance.
The entire operation concerning the connection of the electric panel must be carried out by expert personnel; no
responsibility will be accepted for damages, even to third parties, if the instructions for installation, use and
maintenance of the appliance are not followed scrupulously. Modifications made to the appliance by the user or on
his behalf, must be considered to be under his complete responsibility. The user is responsible for all the operations
required for the maintenance of the appliance before and during its use.

Installation, use and maintenance guide
LAMBDA S29 –S35 –S46 EVO5
Page 5
ENG
1.4 GENERAL GUIDELINES
Attention: the appliance must be connected to a system provided with a PE conductor (in compliance with the
specifications concerning low-voltage equipment). Before installing the appliance check the efficiency of the earth
circuit of the power supply system.
Attention: the power supply line must have a section which is suitable for the power of the equipment. The cable section must in any
case be no less than 1.5 mm². The appliance requires powering with a voltage of 230V and 50 Hz. Voltage variations greater than
10% of the nominal value can cause irregular operation or damage the electrical device. Position the appliance so that the electric
power outlet in the room is easily accessible. Ensure that a suitable differential switch is installed upstream from the equipment.
Position the power supply cable in order to prevent any contact of the latter with the smoke exhaust pipe or hot parts of the
appliance. If the power cord is damaged it must be replaced by the manufacturer or by an authorised technical assistance service in
order to avoid risks.
The product must not be used by children under the age of 8 years, by persons with physical, mental or sensorial impairments, or
by persons who are not familiar with the instructions for use and maintenance of the product (the instructions are found in this
booklet). Children must not play with the appliance.
ATTENTION: before every use make sure that the burner and the ash pan are clean, and check that the firebox door is firmly
closed and air tight.
ATTENTION: the door must always remain shut tight when the appliance is operating. it is strictly forbidden to open the door while
the flame is still burning. During operation, the smoke exhaust pipes, door, handles and some parts of the appliance may reach
extremely high temperatures: be careful not to touch them and also educate children to be aware of said risks. Do not expose your
body to hot air for long, do not overheat the room in which the appliance is installed, as these actions could cause health problems.
Do not expose plants or animals directly to the hot air flow as this could have noxious effects on them. It is prohibited to use any
liquids or gases such as alcohol, petrol, etc. to light or rekindle the fire, use only thin wood. Do not place non-heat resistant or
inflammable or combustible objects in the vicinity of the appliance: keep them at a suitable distance. Do not place wet clothing to
dry on the appliance. When using a clothes horse, keep at a suitable distance. It is strictly prohibited to disconnect the appliance
from the electrical power mains while it is in operation.
Caution: do not wet the appliance and do not touch the electrical parts with wet hands. Never vacuum hot ash: this
could damage the vacuum device. All the cleaning operations described in this manual must be carried out when the
appliance is cold and shut off.
Attention! Warning for Swiss users
Refer to the local cantonal regulations imposed by the Fire Department (Mandatory signalling and safety distances)
and the Note concerning installation of heaters issued by the Association of Cantonal Fire Agencies (VKF - AEAI).
ATTENTION: it is mandatory to earth the appliance. If this instruction is not observed serious damage, which is not
covered by warranty, will result to the body of the appliance. Have an electrician check the earthing. There must be
no electric potential (Volt) between the earth of the generator and the actual earth of the system.
1.5 TRANSPORTATION AND STORAGE
TRANSPORTATION AND HANDLING
The appliance body must always be in a vertical position when handled and exclusively by means of trolleys. Take special care to
protect the electric panel and all the fragile parts from mechanical impact which could damage them and their correct functioning.
We recommend handling the generator with the casing removed so as to avoid any damage.
STORAGE
The appliance must be stored in a humid-free environment and sheltered from the weather; avoid placing the appliance directly on
the ground. The Company denies all responsibility for damage caused to wood floors or floors made from any other material.
It is inadvisable to store the product for long periods of time.
1.6 GUIDELINES FOR CORRECT DISPOSAL OF THE PRODUCT
At the end of the product’s useful life it must be disposed of in compliance with applicable regulations and in respect
of the environment, not with urban waste. The product must be consigned to designated sorted waste collection
centres for the disposal of electronic waste authorised by the local municipal councils. Correct disposal not only helps
safeguard the environment but it also promotes recovery and recycling of the materials.

Installation, use and maintenance guide
LAMBDA S29 –S35 –S46 EVO5
Page 6
ENG
2 –TECHNICAL CHARACTERISTICS
The spiral tube scraper lever can be installed both on the right-hand and left-hand sides of the generator.
Legenda
Key
Pozzetto ½’’
Pocket ½’’
Tappo ½’’
Plug ½’’
Scambiatore
sicurezza ½’’
(optional)
Safety heat
exchanger ½’’
(optional)
Revisione Autore Data
Descrizione
LAMIERA
Il fornitore è responsabile della corretta
realizzazione del particolarecome
indicano le viste di progetto; lo sviluppo
piano deve essere verificato ed
eventualmente modificato dal fornitore
in funzione delle macchine di piegatura
che andranno a realizzare il particolare.
STAMPI E FUSIONI
É obbligo da parte del fornitore,
prima di realizzare qualsiasi
attrezzatura, fornire a
THERMOROSSI S.p.A. i file
tridimensionali dei particolari
definitivi
Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione a terzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore.
Scala
Locazione file
Data
Firma
FoglioNote
Materiale
Prodotto
Sviluppo
2/52
TEL. [phone]- FAX [phone]
Via Grumolo, 4 - 36011 ARSIERO (Vicenza) - ITALY
S.p.A.
Spessore x
Approv. Data approv.
Formato
Cod.
Disegnatore
Volume
Peso
Colore
Revisione
Descrizione
#
148 134
Tappo 1/2"
45412
145
Scambiatore sicurezza 1/2"
(optional)
40 542
133
Pozzetto 1/2"
1326
538
1032
340
362
1543
724
636
1277
1277
1068
1419
318118
148
912
1192
O180
178
636
723
lambda_2 caratteristiche tecniche

Installation, use and maintenance guide
LAMBDA S29 –S35 –S46 EVO5
Page 7
ENG
M.U.
LAMBDA S29
EVO5
LAMBDA S35
EVO5
LAMBDA S46
EVO5
Height
mm
1,543
1,543
1,543
Depth
mm
1,277
1,277
1,277
Width
mm
724
724
724
Empty weight
Kg
567
567
572
Firebox power *
kW
33.4
34.9
45.3
Output to water *
kW
29.6
30.9
39.9
Appliance class
5
5
5
Consumption *
Kg/h
7.89
8.16
10.06
Operating autonomy *
h
3.2
3.2
3.1
Max log length
mm
500
500
500
Ø smoke exhaust pipe
mm
180
180
180
Max delivery water temperature
°C
80
80
80
Min water return temperature
°C
55
55
55
Draft
Pa / mbar
12 / 0.12
12 / 0.12
12 / 0.12
Average smoke temperature *
°C
117
122
152
Maximum smoke temperature *
°C
250
250
250
Smoke flow rate *
kg/s
0.017
0.018
0.023
Combustion chamber volume
Litres
108
108
108
Water content
Litres
105
105
105
Maximum operating pressure
bar
2.5
2.5
2.5
Maximum working pressure
bar
1.5
1.5
1.5
Min puffer tank capacity ****
Litres
1,500
1,500
1,500
Efficiency *
%
88.6
88.5
88.1
CO concentration with 10% 02 *
mg/m3
40
38
26
Power supply voltage and frequency
V / Hz
230 / 50
230 / 50
230 / 50
Max electrical consumption
W
88
88
88
Electrical consumption in standby
W
6.5
6.5
6.5
Loss of load - water side at 10K
mbar
63.6
63.6
63.6
Loss of load - water side at 20K
mbar
15.9
15.9
15.9
Heatable volume **
m3
790
830
1,050
Noise level ***
dB
55
55
55
* All the figures were recorded using 450 mm long logs, with a thermal value below 15,247 kJ/kg and a moisture content of
10.6%
** Important: It is important to take into consideration the fact that the heatable volume is greatly influenced by the
insulation of the house (energy class of the building) and by the position of the appliance in the planimetry of the house,
therefore the indicated values may vary, even significantly.
*** Test carried out with sound level meter at a distance of 3m.
**** The sizing of the puffer tank must be calculated by a qualified professional according to applicable regulations.

Installation, use and maintenance guide
LAMBDA S29 –S35 –S46 EVO5
Page 8
ENG
3 –GENERAL DESCRIPTION
3.1 OPERATING TECHNOLOGY
Your generator has been built to fully satisfy all your heating and practical requirements. Top-grade components and functions
managed with microprocessor technology guarantee high reliability and optimal performance.
LAMBDA EVO5 uses reverse flame technology. The flame is drawn to the lower part of the boiler through the action of a suction
device. The flame develops in the cast iron burner and the particular shape of the flame determines low emissions and an optimal
smooth running.
3.2 WOOD FUEL
The only fuel permissible for use in this appliance is wood logs having a maximum length of 500 mm and moisture content below
20%.
Pay special attention to the characteristics of the wood: like all biomass generators good performance of the generator depends on
the type of wood used and on its degree of seasoning.
Wood after one year of drying: still contains 40% moisture and generates an average 2000/2200 Kcal per Kg.
Wood after two years of drying: still contains an average of 25% moisture and generates approx. 3000 Kcal per Kg.
Wood after three years of drying: still contains an average of 15% moisture and generates approx. 3500 Kcal per Kg.
Store firewood correctly, preferably raised from the ground and protected from sources of moisture or humidity and the weather.
Excellent quality: ash, beech, maple, hornbeam, oak. Average quality: birch, alder and acacia.
Satisfactory quality: lime, poplar, willow, chestnut (only with a minimum seasoning of two years to reduce the tannin content), fir,
larch. Other types of resinous woods are not suitable.
The wood should be cut as close as possible to the length of the combustion chamber in such a way as to completely cover the
burner base and also to obtain a heavier load for a longer duration.
The logs must be placed parallel, next to each other, in order to leave the fewer gaps possible. To achieve the rated power the fuel
load must sit on a bed of embers that does not exceed a thickness of 5 cm. Using larger logs could reduce the generator power.
The maximum thermal value is achieved by using fuel having a diameter of 5/7 cm.
Use of fuel other than all-wood logs is forbidden. The use of fuel other than all-wood logs immediately voids
the appliance warranty. Do not use the appliance as an incinerator, at the risk of voiding the warranty.

Installation, use and maintenance guide
LAMBDA S29 –S35 –S46 EVO5
Page 9
ENG
3.3 MAIN COMPONENTS
A
Control panel
B
Sensor pockets
C
Safety heat exchanger fixing plate
D
Delivery tube 1’’ ¼
E
Smoke suction unit
F
Smoke analysis cover
G
Smoke temperature sensor
H
Lambda sensor
I
Return tube 1’’ ¼
L
Return sensor
M
Pocket
N
Combustion chamber
O
Feed door
P
Actuators for primary and secondary air
Q
Ash pan door
R
Ash pan
S
Spiral tube scraper lever
T
Safety heat exchanger (optional)
U
Tube bundle inspection cover
V
Electronic board
W
Ash cleaning tool
X
Riddling tool
Y
Brush holder
Z
Cleaning brush
Revisione Autore Data
Descrizione
LAMIERA
Il fornitore è responsabile della corretta
realizzazione del particolare come
indicano le viste di progetto; lo sviluppo
piano deve essere verificato ed
eventualmente modificato dal fornitore
in funzione delle macchine di piegatura
che andranno a realizzare il particolare.
STAMPI E FUSIONI
É obbligo da parte del fornitore,
prima di realizzare qualsiasi
attrezzatura, fornire a
THERMOROSSI S.p.A. i file
tridimensionali dei particolari
definitivi
Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione aterzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore.
Scala
Locazione file
Data
Firma
FoglioNote
Materiale
Prodotto
Sviluppo
4/60
TEL. [phone] - FAX [phone]
Via Grumolo, 4 - 36011 ARSIERO (Vicenza) - ITALY
S.p.A.
Spessorex
Approv. Data approv.
Formato
Cod.
Disegnatore
Volume
Peso
Colore
Revisione
Descrizione
#
BCDE
F
G
H
I
M
N
O
P
Q
R
U
AV
T
S
A - Pannello comandi
B - Pozzetti alloggiamento sonde
C - Piastra alloggiamento scambiatore di sicurezza
D - Tubo mandata 1" 1/4
E - Aspiratore fumi
F - Tappo per analisi fumi
G - Sonda temperatura fumi
H - Sonda Lambda
I - Tubo ritorno 1" 1/4
L - Sonda ritorno
M - Pozzetto
L
Y
X
N - Camera di combustione
O - Porta caricamento
P - Attuatori per aria primaria e aria secondaria
Q - Porta vano cenere
R - Vano cenere
S - Leva scuotiturbolatori
T - Scambiatore di sicurezza (optional)
U - Tappo ispezione fascio tubiero
V - Scheda elettronica.
W - Paletta pulizia ceneri
X- Attizzatoio
Y - Asta portascovolo
Z- Scovolo
W
Z

Installation, use and maintenance guide
LAMBDA S29 –S35 –S46 EVO5
Page 10
ENG
A = 200 mm
L = 200 mm
P = 200 mm
4 –INSTALLATION
4.1 APPLIANCE LOCATION
Follow the general guidelines set out in paragraph 1.1 to the letter. Keep in mind that the flooring of the room in which
the appliance is to be installed must withstand the combined weight of the appliance, the fuel, and the water
contained in the appliance.
ATTENTION: The room where the appliance is installed must be well-ventilated and
free from humidity and salty air. A high level of humidity or saltiness in the room can
lead to the onset of rust or corrosion which will not be covered by warranty.
If inflammable materials are located in the vicinity of the appliance (e.g.: match-
boarding, furniture, curtains, pictures and paintings, sofas) it is mandatory to comply
with the minimum distances illustrated (see figure at right)
Installation in the vicinity of heat-sensitive materials is only permitted if suitable
insulating and fireproof protection is placed between the object and the appliance
(ref. Uni 10683). If the flooring is made of wood or any other combustible material, it
is mandatory to install a fireproof floor protector plate between the appliance and the
floor. Installation in the vicinity of heat-sensitive materials is only permitted if suitable
insulating and fireproof protection is placed between the object and the appliance
(ref. Uni 10683). Failure to observe this instruction will immediately invalidate the
warranty.
The installer must issue a certificate of conformity for the installation which includes the design plans and the
following documents:
a) Report containing the type of materials utilised.
b) Project as defined in Article 5 of Ministerial Decree n° 37 22 January 2008.
d) References to existing partial or previous declarations of conformity (e.g. electrical wiring).
e) Copy of the certificate of recognition of the professional technical qualifications.
These documents must, by law, be kept together with the use and maintenance booklet. The customer is responsible
for verifying, directly or indirectly, that the installation has been carried out to perfection in accordance with relevant
regulations in force. Do not install the appliance in unsuitable rooms such as bedrooms, bathrooms, garages and/or
lock-ups. It is forbidden to place the appliance in environments with an explosive atmosphere.
ATTENTION, the appliance is not simply a household appliance: if the instructions set out in this booklet are not
followed and/or if installation of the appliance is not executed perfectly and/or the provisions in force are not strictly
complied with, dangerous conditions could arise for both objects and persons. It is the user’s responsibility to verify
the presence, in the room, of a vent necessary for supplying oxygen to the generator.
The installer must provide the final user with verbal instructions on the correct use of the appliance when the
appliance is set at work for the first time.
Legenda
Key
ISOLANTE TERMICO
HEAT INSULATING MATERIAL
100-200-800 Minimo
100-200-800 Minimum
800 Minimo
100 Minimo
ISOLANTE TERMICO
800 Minimo 200
Minimo

Installation, use and maintenance guide
LAMBDA S29 –S35 –S46 EVO5
Page 11
ENG
4.2 INSTALLATION OF THE SAFETY HEAT EXCHANGER (OPTIONAL)
The safety heat exchanger is mandatory in closed expansion tank systems. Installation of the safety heat exchanger requires
removal of part of the casing. Follow the instructions below to perform this operation. By installing the approved thermal relief valve
the safety heat exchanger absorbs the excess heat in the boiler, due to external causes, as soon as it rises to excessively high
temperatures. This function is called fast disconnection phase.
IF THE SAFETY HEAT EXCHANGER IS INSTALLED TO PRODUCE DOMESTIC HOT WATER THE
GUARANTEE FOR THE GENERATOR IS IMMEDIATELY VOIDED.
INSTALLATION OF THE SAFETY HEAT EXCHANGER MUST BE CARRIED OUT BY A QUALIFIED
PROFESSIONAL AND IN COMPLIANCE WITH APPLICABLE REGULATIONS.
THE MAXIMUM PRESSURE OF THE HEAT EXCHANGER IS 6 bar AND THE INFLOWING WATER
TEMPERATURE MUST NOT EXCEED 20°C.
1) Pull upwards to remove the top:
2) Undo the two M10 wing nuts on the complete inspection door and remove it by pulling upwards. Next, remove the rivet
8X35 and remove the whole spiral tube scraper lever by pulling it outwards:
Revisione Autore Data
Descrizione
LAMIERA
Il fornitore è responsabile della corretta
realizzazione del particolarecome
indicano le viste di progetto; lo sviluppo
piano deve essere verificato ed
eventualmente modificato dal fornitore
in funzione delle macchine di piegatura
che andranno a realizzare il particolare.
STAMPI E FUSIONI
É obbligo da parte del fornitore,
prima di realizzare qualsiasi
attrezzatura, fornire a
THERMOROSSI S.p.A. i file
tridimensionali dei particolari
definitivi
Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione a terzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore.
Scala
Locazione file
Data
Firma
FoglioNote
Materiale
Prodotto
Sviluppo
43/52
TEL. [phone] - FAX [phone]
Via Grumolo, 4 - 36011 ARSIERO (Vicenza) - ITALY
S.p.A.
Spessorex
Approv. Data approv.
Formato
Cod.
Disegnatore
Volume
Peso
Colore
Revisione
Descrizione
#
60007785 Dado ad alette M10
60004578 Rondella D.10
60012790 Ribattino 8x35
Leva azionamento turbolatori completa
70015415 Porta ispezione completa
60004578 Rondella D.10
60007785 Dado ad alette M10
Legenda
Key
Dado ad alette M10
Wing nut M10
Rondella D10
Washer D10
Ribattino 8x35
Rivet 8x35
Porta ispezione
completa
Complete inspection
door
Leva azionamento
turbolatori completa
Complete spiral tube
scraper lever

Installation, use and maintenance guide
LAMBDA S29 –S35 –S46 EVO5
Page 12
ENG
3) Now remove the sides of the casing by pulling up the two upper tabs:
N.B. take utmost care during this process not to pull the electric wires that are located inside it.
4) Undo screw 60005227 completely and screw 60007780 only partially
Attention: Only partially undo screw 60007780 to prevent the coil fastening plate from falling inside the body of
the appliance!
Completely remove the COMPLETE COIL HOLE KIT as illustrated in the figure below.
Revisione Autore Data
Descrizione
LAMIERA
Il fornitore è responsabile della corretta
realizzazione del particolarecome
indicano le viste di progetto; lo sviluppo
piano deve essere verificato ed
eventualmente modificato dal fornitore
in funzione delle macchine di piegatura
che andranno a realizzare il particolare.
STAMPI E FUSIONI
É obbligo da parte del fornitore,
prima di realizzare qualsiasi
attrezzatura, fornire a
THERMOROSSI S.p.A. i file
tridimensionali dei particolari
definitivi
Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione a terzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore.
Scala
Locazione file
Data
Firma
FoglioNote
Materiale
Prodotto
Sviluppo
16/59
TEL. [phone] - FAX [phone]
Via Grumo lo, 4 - 36011 ARSIERO (Vicenza) - ITALY
S.p.A.
Spessorex
Approv. Data approv.
Formato
Cod.
Disegnatore
Volume
Peso
Colore
Revisione
Descrizione
#
60005227 Vite TE 8x25
60007780 Vite TE 8x45
60006097 Guarnizione nylon 8.1x4.8
60006097 Guarnizione nylon 8.1x4.8
70006221 Rondella EPDM
70006221 Rondella EPDM
60009624 Rondella 8x40
60009624 Rondella 8x40
70011814 Piatto chiusura serpentino
70011554 KIT COMPLETO FORI SERPENTINO
Legenda
Key
Vite TE 8x25 - 8x45
Hex head screw
8x25 / 8x45
Rondella 8x40
Washer 8x40
Rondella EPDM
Washer EPDM
Piatto chiusura
serpentino
Coil fastening plate
Guarnizione nylon
8.1x4.8
Nylon gasket
8.1x4.8
KIT COMPLETO
FORI SERPENTINO
COMPLETE COIL
HOLE KIT
Revisione Autore Data
Descrizione
LAMIERA
Il fornitore è responsabile della corretta
realizzazione del particolarecome
indicano le viste di progetto; lo sviluppo
piano deve essere verificato ed
eventualmente modificato dal fornitore
in funzione delle macchine di piegatura
che andranno a realizzare il particolare.
STAMPI E FUSIONI
É obbligo da parte del fornitore,
prima di realizzare qualsiasi
attrezzatura, fornire a
THERMOROSSI S.p.A. i file
tridimensionali dei particolari
definitivi
Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione a terzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore.
Scala
Locazione file
Data
Firma
FoglioNote
Materiale
Prodotto
Sviluppo
14/54
TEL. [phone] - FAX [phone]
Via Grumo lo, 4 - 36011 ARSIERO (Vicenza) - ITALY
S.p.A.
Spessorex
Approv. Data approv.
Formato
Cod.
Disegnatore
Volume
Peso
Colore
Revisione
Descrizione
#

Installation, use and maintenance guide
LAMBDA S29 –S35 –S46 EVO5
Page 13
ENG
5) Partially undo screw 60006245, it must not be unscrewed to the end of its thread.
Attention: Partially undo screw 60006245 to prevent the flange fastening crosspiece from falling inside the body
of the appliance!
Remove the COMPLETE HEAT EXCHANGER HOLE KIT as illustrated in the figure below:
6) Insert the safety heat exchanger inside the appliance as illustrated in the following figure. Then remount the COMPLETE
HEAT EXCHANGER HOLE KIT and tighten screw 60006245 all the way.
Revisione Autore Data
Descrizione
LAMIERA
Il fornitore è responsabile della corretta
realizzazione del particolarecome
indicano le viste di progetto; lo sviluppo
piano deve essere verificato ed
eventualmente modificato dal fornitore
in funzione delle macchine di piegatura
che andranno a realizzare il particolare.
STAMPI E FUSIONI
É obbligo da parte del fornitore,
prima di realizzare qualsiasi
attrezzatura, fornire a
THERMOROSSI S.p.A. i file
tridimensionali dei particolari
definitivi
Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e la divulgazione a terzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in vigore.
Scala
Locazione file
Data
Firma
FoglioNote
Materiale
Prodotto
Sviluppo
17/59
TEL. [phone] - FAX [phone]
Via Grumo lo, 4 - 36011 ARSIERO (Vicenza) - ITALY
S.p.A.
Spessorex
Approv. Data approv.
Formato
Cod.
Disegnatore
Volume
Peso
Colore
Revisione
Descrizione
#
60011557 Guarnizione serpentino
70010502 Traversino fissaggio flangia
70011812 Tappo scambiatore
60006095 Rondella 1/4" con inserto gomma
60006245 Vite TE 12X70
70013994 KIT COMPLETO FORO SCAMBIATORE
Legenda
Key
Tappo
scambiatore
Heat exchanger
cover
Guarnizione
serpentino
Coil gasket
Traversino
fissaggio flangia
Flange fastening
crosspiece
Vite TE 12X70
Hex head screw
TE 12x70
Rondella 1/4'' con
inserto gomma
1/4'' washer with
rubber insert
KIT COMPLETO
FORO
SCAMBIATORE
COMPLETE HEAT
EXCHANGER
HOLE KIT
Legenda
Key
Scambiatore termico di sicurezza
Safety heat exchanger
Kit completo foro scambiatore
Complete heat exchanger hole kit
Revisione Autore Data
Descrizione
LAMIERA
Il fornitore è responsabile della corretta
realizzazione del particolare come
indicano le viste di progetto; lo sviluppo
piano deve essere verificato ed
eventualmente modificato dal fornitore
in funzione delle macchine di piegatura
che andranno a realizzare il particolare.
STAMPI E FUSIONI
É obbligo da parte del fornitore,
prima di realizzare qualsiasi
attrezzatura, fornire a
THERMOROSSI S.p.A. i file
tridimensionali dei particolari
definitivi
Il presente disegno è di proprietà esclu siva di THERMOROSSI S.p.A.. La ri produzione totale e/o parziale e la divulgazione a t erzi, senza nostro esplicito co nsenso scritto, verrà perseguito seco ndo i termini di legge in v igore.
Scala
Locazione file
Data
Firma
Foglio
Note
Materiale
Prodotto
Sviluppo
18/59
TEL. [phone] - FAX [phone]
Via Grumolo, 4 - 36011 ARSIERO( Vicenza) - ITALY
S.p.A.
Spessorex
Approv.Data approv.
Formato
Cod.
Disegnatore
Volume
Peso
Colore
Revisione
Descrizione
#
60013727 Scambiatore termico di sicurezza
70013994 Kit completo foro scambiatore

Installation, use and maintenance guide
LAMBDA S29 –S35 –S46 EVO5
Page 14
ENG
7) Fasten the two inlets with the Kit supplied with the heat exchanger and following the order indicated in the figure below:
8) Install the certified and calibrated two-way thermal relief valve at the exchanger inlet, following the instructions provided by
the manufacturer and install a discharge pipe.
The thermal relief valve must have the following characteristics:
- Double safety sensor for solid fuel generators
- Max working pressure: 10 bar
- Temperature range: 5÷110°C
- Calibration temperature 98°C
- Discharge capacity with Δp = 1 bar and T=110°C: 3000 l/h
- Capillary tube length: 130 mm
- Certified to standard EN 14597
Lastly insert the sensitive element of the thermal relief valve by removing the pocket (M) and screwing in the pocket
supplied with the valve.
ATTENTION: before reassembling the remaining parts make sure that the gaskets are tight by bringing the system to
pressure.
9) Reassemble the parts by carrying out the above procedure in reverse order.
ATTENTION: A CONNECTION MUST BE MADE BETWEEN THE SAFETY VALVE AND THE OUTLET TO
PREVENT DAMAGING MATERIALS SURROUNDING THE BOILER WHEN THE VALVE IS ACTIVATED. IT IS
MANDATORY TO INSTALL A T UNION WITH TAP FOR DISCHARGING FROM THE BOILER.
Revisione Autore Data
Descrizione
LAMIERA
Il fornitore è responsabile della corretta
realizzazione del particolare come
indicano le viste di progetto; lo sviluppo
piano deve essere verificato ed
eventualmente modificato dal fornitore
in funzione delle macchine di piegatura
che andranno a realizzare il particolare.
STAMPI E FUSIONI
É obbligo da parte del fornitore,
prima di realizzare qualsiasi
attrezzatura, fornire a
THERMOROSSI S.p.A. i file
tridimensionali dei particolari
definitivi
Il presente disegno è di proprietà esclusiva di THERMOROSSI S.p.A.. La riproduzione totale e/o parziale e l a divulgazione a terzi, senza nostro esplicito consenso scritto, verrà perseguito secondo i termini di legge in v igore.
Scala
Locazione file
Data
Firma
Foglio
Note
Materiale
Prodotto
Sviluppo
19/59
TEL. [phone] - FAX [phone]
Via Grumolo, 4 - 36011 ARSIERO (Vicenza) - ITALY
S.p.A.
Spessorex
Approv.Data approv.
Formato
Cod.
Disegnatore
Volume
Peso
Colore
Revisione
Descrizione
#
Dado 1/2"
Dado 1/2"
Rondella ottone
Rondella ottone
Guarnizione "OR"
Guarnizione "OR"
60013727 Scambiatore termico di sicurezza
Legenda
Key
Scambiatore
termico di
sicurezza
Safety heat
exchanger
Dado 1/2''
Nut 1/2''
Rondella ottone
Brass washer
Guarnizione
"OR"
O-Ring gasket

Installation, use and maintenance guide
LAMBDA S29 –S35 –S46 EVO5
Page 15
ENG
4.3 RELOCATION OF THE SPIRAL TUBE SCRAPER LEVER
The product is supplied with the spiral tube scraper lever mounted on the right side; if needed, it can be moved to the left side of
the appliance.
This operation must be exclusively performed by qualified professional staff, as set forth by Decree no. 37 of 22nd
January 2008 and applicable laws on the subject. Before performing said task, make sure the power supply cable is
disconnected from the electrical power socket.
Follow the procedures in the previous chapter up to point 2 to carry out this operation.
4.4 GUIDELINES FOR THE HYDRAULIC SYSTEM
The hydraulic system must be installed by qualified personnel who are familiar with the standards mentioned
above and who have the appropriate professional requirements to release the declaration of conformance in
accordance with Ministerial Decree n° 37 of 22 January 2008. The system must be suitably sized in relation to the
power of the generator.
ATTENTION: it is mandatory to earth the generator. If this instruction is not observed serious damage, which is
not covered by warranty, will result to the body of the appliance. Have a skilled electrician check the earthing.
There must be no electric potential (Volt) between the generator earth and the plant’s real earth (earth plate). To
prevent electrochemical corrosion of the appliance body do not use galvanised pipes and fittings. Other materials
must be earthed with special earthing cables in order to obtain a unipotential earthing system.
4.5 INSTRUCTIONS FOR EXECUTING THE CLOSED EXPANSION TANK HYDRAULIC SYSTEM
To install the system with a closed expansion tank refer to the requirements laid down in EN 10412-2:2009 for appliances with
nominal heat output not exceeding 35 kW or in the Ministerial Decree Collection R edition 2009 for appliances with nominal heat
output exceeding 35 kW.
The hydraulic system must be installed by qualified personnel who are familiar with the standards mentioned above and who have
the appropriate professional requirements to release the declaration of conformance in accordance with Ministerial Decree n° 37 of
22 January 2008.
A closed expansion tank must be series-connected to the generator as protection for the system.
The nominal volume of the closed expansion tank must be sized in relation to the total volume of the water contained in the system.
Thermorossi prescribes the size of the closed expansion tank as equal to 10% of the volume of water contained in the entire
system. Any bulging of the boiler body caused by an incorrectly sized expansion tank will not be covered by the warranty.
The next chapter and the preceding chapters do not replace the above mentioned standards to which they refer. The qualified
installer must in any case be fully aware of the above standards and their amending versions.

Installation, use and maintenance guide
LAMBDA S29 –S35 –S46 EVO5
Page 16
ENG
4.6 TYPICAL HYDRAULIC DIAGRAMS
- BOILER WITH PUFFER TANK AND HIGH AND LOW TEMPERATURE SYSTEM
Legenda
Key
RISCALDAMENTO A PAVIMENTO
UNDERFLOOR HEATING
Sonda PUFFER BASSO JP12 pin 9 e 10
Sensor LOWER PUFFER JP12 pin 9 and 10
Sonda PUFFER ALTO JP12 pin 7 e 8
Sensor UPPER PUFFER JP12 pin 7 and 8
RADIATORI
RADIATORS
DALL'ACQUEDOTTO
FROM WATER MAINS
BULBO VST
BULB VST
CALDAIA
BOILER
SCARICO
OUTLET
THERMOPUFFER 1500
THERMOPUFFER 1500
Morsettiera JP2 pin 1 e 2
Terminal block JP2 pin 1 and 2
Morsettiera JP2 pin 5 (marrone), 6 (blu), 7 (nero)
VNR
Nonreturn valve
VST
Thermal relief valve
CC
Boiler circulating pump
S
Gate valve
VR
Pressure reducing valve
VSP
Gate valve (throttle according to pressure drop in the
system)
VEC
Closed expansion tank
VS
Overpressure safety valve
V3V
Three-way valve
SCA
Safety heat exchanger
GAM
Motor-operated anticondensation unit
V3VM
Manual three-way valve
CIB
System circulator pump, low
temperature
CIA
System circulating pump, high
temperature
PUFFER TANK 1500 l + BOILER + HIGH TEMPERATURE SYSTEM + LOW TEMPERATURE SYSTEM
ATTENTION: Before loading the system, it is mandatory to verify that the preload pressure of the expansion tank or expansion
tanks is 1.5 bar. Next load the system until it reaches a pressure of 1 bar.
ATTENTION: The following genuine Thermorossi accessories are required to control this system:
2 thermocouples (code no. 60013656) to connect to the terminal block JP12 on pins 7 - 8 (upper puffer sensor) and on pins 9 - 10
(lower puffer sensor).
CIB
V3VM
PUFFER 1500 l + CALDAIA + IMPIANTO ALTA TEMPERATURA + IMPIANTO BASSA TEMPERATURA
CIA
VNR - Valvola di non ritorno
S - Saracinesca
VEC - Vaso di espansione chiuso
V3V - Valvola 3 vie
V3VM - Valvola 3 vie manuale
CIA - Circolatore impianto alta temperatura
Sonda PUFFER BASSO JP12 pin 9 e 10
Sonda PUFFER ALTO JP12 pin 7 e 8
VNR VSP
VST
BULBO VST
VR
SCA
VS
CC
GAM
DALL'
ACQUEDOTTO
CC - Circolatore caldaia
VSP - Valvola saracinesca (da parzializzare in funzione delle
perdite di carico dell'impianto).
GAM - Gruppo anticondensa motorizzato
CALDAIA
SCARICO
VST - Valvola di scarico termico
VR - Valvola riduttrice di pressione.
VS - Valvola di sicurezza di sovrapressione.
SCA - Scambiatore termico di sicurezza
CIB - Circolatore impianto bassa temperatura
morsettiera JP2 pin 1 e 2
VNR
VNR
S
V3V
RISCALDAMENTO
A PAVIMENTO
RADIATORI
SSS
VNR
V3V
S
S
S
VEC
S
VEC
SSS
S
THERMOPUFFER 1500
morsettiera JP2 pin 5 (marrone), 6 (blu), 7 (nero)

Installation, use and maintenance guide
LAMBDA S29 –S35 –S46 EVO5
Page 17
ENG
1 motor-operated anticondensation unit 70030783
1 safety heat exchanger Code 60013727
1 thermal relief valve Code 60012922
With this type of system, you must activate the BOILER + PUFFER TANK configuration in the generator’s System Menu. (See the
paragraph dedicated to software operation).
ATTENTION: it is mandatory to earth the generator. If this instruction is not observed serious damage, which
is not covered by warranty, will result to the body of the generator. Have an electrician check the earthing.
There must be no electric potential (Volt) between the earth of the generator and the actual earth of the
system. To prevent electrochemical corrosion of the boiler body do not use galvanised pipes and fittings.
Dedicated ground wires must be used to ground all other materials.

Installation, use and maintenance guide
LAMBDA S29 –S35 –S46 EVO5
Page 18
ENG
- BOILER WITH PUFFER TANK AND AUXILIARY GENERATOR CONNECTED WITH A PLATE HEAT EXCHANGER
Legenda
Key
RISCALDAMENTO A PAVIMENTO
UNDERFLOOR HEATING
RADIATORI
RADIATORS
Generatore liquido o gassoso
Liquid or gas generator
Sonda PUFFER BASSO JP12 pin 9 e 10
Sensor LOWER PUFFER JP12 pin 9 and 10
Sonda PUFFER ALTO JP12 pin 7 e 8
Sensor UPPER PUFFER JP12 pin 7 and 8
Consenso accensione morsettiera JP4 pin 1 e 3
Terminal block ON consent JP4 pin 1 and 3
DALL'ACQUEDOTTO
FROM WATER MAINS
BULBO VST
BULB VST
CALDAIA
BOILER
SCARICO
OUTLET
THERMOPUFFER 1500
THERMOPUFFER 1500
Morsettiera JP2 pin 1 e 2
Terminal block JP2 pin 1 and 2
Morsettiera JP2 pin 5 (marrone), 6 (blu), 7 (nero)
VNR
Nonreturn valve
VST
Thermal relief valve
CG
Additional liquid or gas fuelled boiler circulating pump
S
Gate valve
VR
Pressure reducing valve
CC
Boiler circulating pump
VEC
Closed expansion tank
VS
Overpressure safety valve
V3V
Three-way valve
SCA
Safety heat exchanger
VSP
Gate valve (throttle according to pressure drop in the
system)
V3VM
Manual three-way valve
CIB
System circulator pump, low
temperature
GAM
Motor-operated anticondensation unit
CIA
System circulating pump, high
temperature
CS
Heat exchanger circulating pump
PUFFER TANK 1500 l + BOILER + ADDIT. BOILER ON SYSTEM + HIGH TEMPERATURE SYSTEM + LOW TEMPERATURE SYSTEM
ATTENTION: Before loading the system, it is mandatory to verify that the preload pressure of the expansion tank or expansion
tanks is 1.5 bar. Next load the system until it reaches a pressure of 1 bar.
CIB
PUFFER 1500 l + CALDAIA + CALDAIA AGG SU IMPIANTO + IMPIANTO ALTA TEMPERATURA + IMPIANTO BASSA TEMPERATURA
CIA
VNR - Valvola di non ritorno
S - Saracinesca
VEC - Vaso di espansione chiuso
V3V - Valvola 3 vie
V3VM - Valvola 3 vie manuale
CIA - Circolatore impianto alta temperatura
VNR VSP
VEC
VST
BULBO VST
VR
SCA
VS
CC
DALL'
ACQUEDOTTO
CG - Circolatore caldaia aggiuntiva combustibile liquido o gassoso
CC - Circolatore caldaia
VSP - Valvola saracinesca (da parzializ. in funzione delle perdite
di carico dell'impianto).
GAM - Gruppo anticondensa motorizzato
CALDAIA
SCARICO
S
VST - Valvola di scarico termico
VR - Valvola riduttrice di pressione.
VS - Valvola di sicurezza di sovrapressione.
SCA - Scambiatore termico di sicurezza
CIB - Circolatore impianto bassa temperatura
CS - Circolatore scambiatore
morsettiera JP2 pin 1 e 2
S
S
S
VNR S
Consenso accensione
morsettiera JP4 pin 1 e 3
liquido
CG
V3VM
Sonda PUFFER BASSO JP12 pin 9 e 10
Sonda PUFFER ALTO JP12 pin 7 e 8
VNR
S
V3V
RISCALDAMENTO
A PAVIMENTO
RADIATORI
VNR
VEC
SSS
VNR
V3V
SS
o gassoso
Generatore
S
GAM
THERMOPUFFER 1500
morsettiera JP2 pin 5 (marrone), 6 (blu), 7 (nero)
CS
S

Installation, use and maintenance guide
LAMBDA S29 –S35 –S46 EVO5
Page 19
ENG
ATTENTION: The following genuine Thermorossi accessories are required to control this system:
2 thermocouples (code no. 60013656) to connect to the terminal block JP12 on pins 7 - 8 (upper puffer sensor) and on pins 9 - 10
(lower puffer sensor).
1 motor-operated anticondensation unit 70030783
1 safety heat exchanger Code 60013727
1 thermal relief valve Code 60012922
When any alarm intervenes - except the ‘door open’ or ‘boiler temperature too high’ alarms - the generator enables the start
consent for an auxiliary generator.
The auxiliary generator receives the signal to start when contacts 1 and 3 on terminal block JP4 close. These contacts are not
powered and therefore are defined as voltage-free contacts.
With this type of system, you must activate the BOILER + PUFFER TANK configuration in the generator’s System Menu. (See the
paragraph dedicated to software operation).
ATTENTION: it is mandatory to earth the generator. If this instruction is not observed serious damage, which
is not covered by warranty, will result to the body of the generator. Have an electrician check the earthing.
There must be no electric potential (Volt) between the earth of the generator and the actual earth of the
system. To prevent electrochemical corrosion of the boiler body do not use galvanised pipes and fittings.
Dedicated ground wires must be used to ground all other materials.
