THERMOROSSI aspiromec le Installation and operating instructions

HEATING TECHNOLOGY AND INNOVATION
INSTALLATION, USE AND MAINTENANCE GUIDE

CONTENTS
page 3
DECLARATION OF CONFORMITY.................................................................................................................................................................................................................... 4
1. INTRODUCTION ................................................................................................................................................................................................................................................ 5
1.1 General guidelines .............................................................................................................................................................................................................................. 5
1.2 Safety guidelines .................................................................................................................................................................................................................................. 5
1.3 Standards and recommendations..........................................................................................................................................................................................6
1.4 Transportation ........................................................................................................................................................................................................................................ 6
2. TECHNICAL CHARACTERISTICS.................................................................................................................................................................................................... 7
2.1 Technical data.......................................................................................................................................................................................................................................... 7
3. GENERAL DESCRIPTION ........................................................................................................................................................................................................................ 9
3.1 ASPIROTRONIC LE / ASPIROMEC LE wood fired boilers .......................................................................................................................... 9
4. INSTALLATION................................................................................................................................................................................................................................................ 10
4.1 Mounting the outer casing on ASPIROTRONIC LE ASPIROMEC LE .............................................................................................. 10
4.2 Mounting the outer casing on ASPIROTRONIC COMBI LE ...................................................................................................................... 11
4.3 Mounting the electronic panel on ASPIROTRONIC LE ................................................................................................................................ 12
4.4 Functions of panel on ASPIROTRONIC LE .............................................................................................................................................................. 13
4.5 Display panel of ASPIROTRONIC .................................................................................................................................................................................... 14
4.6 Programs of the ASPIROTRONIC LE panel .............................................................................................................................................................. 14
4.7 Electrical connections diagram for ASPIROTRONIC LE .............................................................................................................................. 15
4.7.1 Diagram of ASPIROTRONIC LE electronic panel .......................................................................................................................................... 16
4.7.2 REMOTE BOARD CONTROL.............................................................................................................................................................................................. 17
4.7.3 Installation of the antenna.................................................................................................................................................................................................. 17
4.7.4 Diagram of ASPIROTRONIC LE panel operation .......................................................................................................................................... 18
4.8 Installation of ASPIROMEC LE electromechanical panel .......................................................................................................................... 18
4.9 ASPIROMEC LE electromechanical panel functions ...................................................................................................................................... 19
4.9.1 Wiring diagram for ASPIROMEC LE .......................................................................................................................................................................... 20
4.10 Electrical connections diagram for ASPIROMEC LE.................................................................................................................................... 21
4.11 Installation of smoke suction unit on ASPIROMEC LE / ASPIROTRONIC LE .................................................................. 21
4.12 Installation of safety exchanger/heat exchanger on ASPIROMEC LE/ASPIROTRONIC LE (Optional).... 22
4.13 Guidelines for the hydraulic connections of the LE series boilers ................................................................................................ 22
4.14 Guidelines for the hydraulic connections of the ASPIROTRONIC COMBI LE boiler (Optional)
...................... 23
4.15 Guidelines for the hydraulic connections of the ASPIROTRONIC LE / ASPIROMEC LE
boiler with the boiler tube (optional) .................................................................................................................................................................... 23
4.16 Example of hydraulic diagram for ASPIROTRONIC LE with DUO-TEC settings ...................................................... 24
4.17 Example of hydraulic diagram for ASPIROTRONIC LE with PUFFER-TEC settings ................................................ 24
4.18 Approximate hydraulic diagram of ASPIROTRONIC LE with puffer with first priority to heating system ........ 25
5. USE OF THE BOILERS ................................................................................................................................................................................................................ 25
5.1 Starting the ASPIROMEC LE boiler ........................................................................................................................................................................ 25
5.2 Starting the ASPIROTRONIC LE boiler ................................................................................................................................................................ 25
5.3 Regulation of the combustion air in ASPIROMEC LE and ASPIROTRONIC LE ................................................................ 26
5.4 Refuelling with wood .......................................................................................................................................................................................................... 26
5.5 Adjustment of the combustion air damper opening ................................................................................................................................ 26
5.6 Practical advice and guidelines ................................................................................................................................................................................ 27
5.7 Wood fuel ...................................................................................................................................................................................................................................... 27
6. TROUBLESHOOTING .................................................................................................................................................................................................................... 28
6.1 Troubleshooting for ASPIROMEC LE and ASPIROTRONIC LE boilers
.................................................................................... 28
7. CLEANING AND MAINTENANCE
........................................................................................................................................................................................ 29
7.1 Cleaning and maintaining ASPIROMEC LE and ASPIROTRONIC LE boilers
.................................................................... 29
7.2 Cleaning and maintaining EURA boilers ............................................................................................................................................................ 29
CONTENTS

page 4
THERMOROSSI S.p.A.
Via Grumolo. 4
36011 ARSIERO
tel: [phone]
fax:[phone]
CE DECLARATION OF CONFORMITY
In accordance with the following directives:
European Directive 73/23/EEC and its amending directive 93/68
89/336/EEC and its amending directives 93/68/EEC
92/31/EEC
93/97/EEC
Thermorossi S.p.A., Via Grumolo 4 - ARSIERO (VI), declares that the the boilers
belonging to the series ASPIROMEC LE, ASPIROTRONIC LE, ASPIROTRONIC
COMBI LE have been designed and manufactured in compliance with the safety
requirements of the standards for EC marking.
This declaration refers to the entire range of the specified series.
ARSIERO, 1 March 2003 THERMOROSSI S.p.A.

INTRODUCTION
page 5
1.1 GENERAL GUIDELINES
• This installation, use and maintenance guide is an integral and essential part of the product and must be
kept by the user.
• Before commencing with the installation, use and maintenance of the product, carefully read all the
instructions contained in this booklet.
• This appliance must only be used as intended by the manufacturer. Any other use is considered incorrect
and therefore hazardous; consequently, the user shall be totally liable for the product if used improperly.
• Installation, maintenance and repairs must be carried out by personnel with professional qualifications
and in compliance with current regulatory standards and in accordance with the instructions of the
manufacturer of the appliance.
Use only original spare parts.
• Incorrect installation or poor maintenance could injure or damage people, animals or things; in this case
the manufacturer shall be relieved of all responsibility.
• Before commencing any cleaning or maintenance operation ensure that the appliance has been discon-
nected from the mains power supply by means of the main system switch or some other disconnecting
device installed upstream from the appliance.
• The product must be installed in locations suitable for fire-fighting and furnished with all the services
(power and outlets) which the appliance requires for a correct and safe operation.
• If the appliance is sold or transferred to another user ensure that the guide is handed over with it.
Thermorossi S.p.A. maintains the author’s rights on these service instructions.
The information in this booklet may not be reproduced or given to third parties or used for competitive
purposes without the appropriate authorization.
1.2 SAFETY GUIDELINES
Personal injury
This safety symbol identifies important messages throughout the manual. Read the information
marked by this symbol carefully as non-observance of this message can cause serious injury to
persons using the boiler.
Damage to property
This safety symbol identifies messages or instructions that are fundamental for the boiler and
system to function well. To avoid serious damage to the boiler and/or heating system adhere
strictly to these instructions.
Information
This symbol indicates important instructions for good functioning of the boiler or system.
If this information is not correctly observed, the performance of the boiler and/or system will not
be satisfactory.
1. INTRODUCTION

INTRODUCTION
page 6
1.3 STANDARDS AND RECOMMENDATIONS
Normative references: national and international standards used for the design, industrialization and
manufacture of the products described in this manual:
–European Directive 73/23/EEC – CEI 61/50
–European Directive 93/68/EEC – CEI EN 60204
–European Directive 89/336/EEC – CEI 64-8 (IEC 364)
RECOMMENDATIONS:
• Before using the appliance, carefully read every section of this instruction manual as
knowledge of the information and the regulations contained in it are essential for a correct use
of the appliance.
• The connection of the electric panel must be made by skilled personnel; the manufacturer
denies all responsibility for damage, even to third parties, if the instructions for the installation,
use and maintenance of the appliance are not strictly observed.
• The user is entirely liable for any changes made to the appliance by the user or by third
parties on his behalf.
• All the operations required for the installation and maintenance of the appliance before and
during its use are the responsibility of the user.
GENERAL WARNINGS
• Caution: the appliance must be connected to a system provided with a PE conductor (in
compliance with the specifications of 73/23/EEC, 93/98/EEC, concerning low voltage
equipment). Before installing the equipment check the efficiency of the earth circuit of the power
supply system.
•Caution: the power supply line must have a section which is suitable for the power of the
equipment. In any case, the section of the cables must not be less than 1.5 mm2. The boiler
must be powered with a voltage of 230 V and 50 Hz. Voltage variations which exceed 10% of
the nominal value can cause poor functioning or damage the electrical device. Ensurethat a
suitable differential switch is installed upstream from the appliance.
1.4 TRANSPORTATION
TRANSPORTATION AND HANDLING
The boiler body must always be in a vertical position when handled and exclusively by means of trolleys.
Take special care to protect the electric panel from mechanical impact which could damage it and its
correct functioning.
STORAGE
The boiler must be stored in dry, sheltered areas; it is inadvisable to store the boiler directly on the floor.
The electric panel must be stored in a clean, dry place. It is inadvisable to store the electricl panel for long
periods of time.

TECHNICAL CHARACTERISTICS
page 7
10
D
C
A
4
3
2
1
5
E
F
G
M
ILR7
R1
N
R5
X
T
RR2
C
11
ZA
5
1
6
2
3
4
X
T
FG
E
R
R7
R2
L
M
IR5
R1
N
R6
8
N1
O
Q
N2
B
A
W
L
U
IL
IL
Q
O
2.1 TECHNICAL DATA
2. TECHNICAL CHARACTERISTICS
ASPIROTRONIC LE
ASPIROTRONIC COMBI LE
A
F
E
G
C
M
I
N
L
Z
T
X
R
3
5
1
2
R2
R7
R5
R1
ASPIROMEC LE

TECHNICAL CHARACTERISTICS
page 8
MODEL
DIMENSIONS IN MM
DOOR
DIMENSIONS mm
FLUE OUTLET
CONNECTION
WEIGHT KG
MODEL CONNECTORS
Delivery Ø Return Ø
FLUIDSSOLIDS
SOLIDS FLUIDS FLUIDSSOLIDS
MODEL COMBUSTION CHAMBER POWER
Kw(Kcal/h)
MAXIMUM USEFUL HEATING
CAPACITY Kw (Kcal/h)
MANIMUM USEFUL HEATING
CAPACITY Kw (Kcal/h)
TECHNICAL CHARACTERISTICS
DIMENSIONAL TECHNICAL DATA
   
   
   
  4 
   
   
   
   

            !    
            !    
            !    
            !    
            !    
 !
 !
 !
 !
 !
 !












 !
 !








 
 
 
 

113 
 
 





FUEL BOX
VOLUME
(dm2)
WATER
CONTENT (l.)
WORKING
PRESSURE
(bar)
MAX. FUEL
LENGTH
(mm)
FLUE OUTLET
DRAFT LOSS
(mbar)
HEAT
EXCHANGER
CONNECTIONS
Ø
WATERSIDE HEAD
LOSS
(mbar)
WEIGHT
(kg)
COLD WATER
PRESSURE
REQUIRED
BY THE HEAT
EXCHANGER
MODEL
623 / 1303 820 37 909 1140 1080 140 112 311 \ 1048 1108 90 860 156 775 \ 490 180 324x234
713 / 1435 820 37 909 1270 1210 145 122 304 \ 1176 1236 90 980 156 865 \ 605 180 354x264
713 / 1435 984 37 1107 1270 1210 145 122 305 445 1176 1236 90 945 185 865 \ 715 180 354x264
623 / 1303 696 37 827 1140 1080 140 112 230 \ 1048 1108 90 600 156 775 \ 430 180 324x234
623 / 1303 820 37 909 1140 1080 140 112 311 \ 1048 1108 90 860 156 775 \ 500 180 324x234
713 / 1435 820 37 909 1270 1210 145 122 304 \ 1176 1236 90 980 156 865 \ 615 180 354x264
713 / 1435 984 37 1107 1270 1210 145 122 305 445 1176 1236 90 945 185 865 \ 725 180 354x264
713 / 1435 1354 37 1479 1270 1210 145 122 375 515 1176 1236 90 925 221 865 \ 915 200 354x264
623 1970 / 696 37 827 980 1080 140 112 230 \ 1048 1108 90 600 156 775 941 540 180/130 340x260
623 1970 / 820 37 909 1140 1080 140 112 311 \ 1048 1108 90 860 156 775 860 610 180/130 324x234
713 2180 / 820 37 909 1270 1210 145 122 304 \ 1176 1236 90 980 150 865 791 725 180/200 354x264
713 2180 / 984 37 1107 1270 1210 145 122 305 445 1176 1236 90 945 185 865 826 885 180/200 354x264
713 2180 / 1354 37 1479 1270 1210 145 122 375 515 1176 1236 90 925 221 865 847 1075 200/200 354x264

GENERAL DESCRIPTION
page 9
3
4
2
1
7
1
6
5
7
4
2
3
5
6
3. GENERAL DESCRIPTION
3.1 ASPIROTRONIC LE / ASPIROMEC LE WOOD FIRED BOILERS
FOREWORD
ASPIROTRONIC LE, ASPIROMEC LE,arewood fired boilers which operate on the reverse flame principle.
The flame is conveyed to the lower part of the boiler by the action of a suction device.
The flame develops in the burner referred to as LE. The configuration determines low emissions and an
exceptionally regular functioning. The LE burner satisfies the emission limit regulations in major European
countries, including Austria which has the strictest regulations concerning polluting emissions (art. 15a
B.V.G.).
THE BOILER CONSISTS OF :
1-FUEL BOX.This is where the gasification process (Pyrolysis) takes places, that is the reduction of the
wood moisture in simultaneous precombustion with the substances that take part in combustion. It is
normal for a layer of tar to be produced in proportion with the quantity of moisture content of the fuel.
2-LE BURNER.The shape of the burner and the materials used in its construction guarantee the creation
of a strong turbulence in the compartment under the burner. Veryhigh temperatures are developed in the
LE burner.The symbiosis between temperatureand turbulence guarantee low emissions.
3-COMBUSTION CHAMBER.The combustion chamber is located in the lowest part of the boiler and it
is the area on which the ash pan sits.
4-ASH PAN.The ash is deposited here.
5-SAFETY HEAT EXCHANGER.ASPIROMEC LE and ASPIROTRONIC LE can be fitted with a safety heat
exchanger.If a thermal relief valve is installed it absorbs the excess heat as soon as the boiler,due to
external causes, increases to excessively high temperature values. This function is referred to as the fast
disconnection phase. If necessary the heat exchanger can be used to produce hot water for domestic use.
Limit the duration of this function, as if it is used for a long period of time the boiler will cool down too much.
Furthermore, the removal of water must take place together with the operation of the boiler.
6-INSULATION.The thick layer of mineral wool enveloping the boiler and the insulated outer casing
panels guarantee that thermal dispersion is reduced to a minimum.
7-STARTER.Every time the loading door is opened it activates a direct communication between the fuel
box and the smoke outlet.
1-Fuel box
2-Burner LE
3-Tube bundle
combustion chamber
4-Ash pan
5-Safety heat
exchanger (optional)
6-Insulation
7-Starter
ASPIROTRONIC LE ASPIROMEC LE

INSTALLATION
page 10
5
8
5
1
2
3
6
4
7
4. INSTALLATION
4.1 MOUNTING THE OUTER CASING ON ASPIROTRONIC LE / ASPIROMEC LE.
Key to outer casing material:
2–Top front panel
3–Top rear panel
4 – RH side panel (2 pieces for model 102)
5–Supportprofiles
6-Back
7–Layer of mineral wool
8–LH side panel (2 pieces for model 102)
- Wrap the layer of mineral wool (7) around the heater body and fasten it using the strap and fastener; make
holes in the mineral wool for the feeler pockets, the tube bundle door and the heat exchanger covers
(optional).
-Mount the 2 supportprofiles (5) using M5x16 screws, washers and nuts.
- Make sure that the RH side panel (4) is correctly mounted on the support profiles then fasten it (for the LE
102 mount 2 side panels).
- Fasten the LH side panel ( 8), with the smoke suction unit power plug facing towards the back, to the
supportprofile.
- Fasten the top rear panel (3) to the top front panel using the hinges provided and the 4.8x25 screws.
-Lastly,fasten the back panel.

INSTALLATION
page 11
4.2 MOUNTING THE OUTER CASING ON ASPIROTRONIC COMBI LE.
- Mount the outer casing to the boiler as shown
in the figure on the previous page.
- Do not mount the top front panel (2); in its
place, mount the top rear panel (3) (For LE 102
COMBI use 2 brackets as the Eura boiler,
unlike the Aspirotronic boiler, is positioned
centrally).
- Disconnect the pins from the front panel and
fasten it to the rear panel.
- Fasten the bracket C to the EURA boiler (using
screws and nuts A)
- Position the Eura boiler as illustrated in the
figure and fasten it to the ASPIROTRONIC
boiler (using screws and nuts B).
- Position the EURA boiler and adjust the height
by acting on the screws which fasten the
bracket B.
- Wrap the mineral wool (5) around the boiler,
secure it using the fasteners provided and
make holes for the feeler pockets.
-Mount panels 1 and 3 (the plug must be at the
front); insertthem inside the 4 brackets on the
front panel of the boiler.
-Then mount panel 2 and secure the side panels
1and 3 using the screws provided.
-Lastly,fasten panel 4.
Screws and nuts A, B:M8x25 hexagon head screws and nuts
Screws and nuts C:M10x60 hexagon head screws and nuts
Follow the diagram below to mount the outer casing of the EURA boiler. Two panels to be mounted at the
front and back of the boiler are supplied with boiler LE 102.

INSTALLATION
page 12
4.3 MOUNTING THE ELECTRONIC PANEL ON ASPIROTRONIC LE
1- Cage nuts
2- Screws M5x16
3- Control board
4- Board cover
5- Self-tapping screws
-Fasten the ASPIROTRONIC panel to the left side panel of the boiler. (If mounting it on the right side panel,
fix the control board by rotating it by 180° with respect to the panel. Alternatively, the panel can be affixed
to the wall).
-Fasten the cage nuts (1) provided in the precut holes.
- Unroll the capillaries and the thermocouple, thread them through the precut holes on the side panels.
Thread the end bulbs in the pockets (A) located on the top of the boiler and fill up with lubricating oil to
improve the heat exchange.
-Close the panel with the boardcover (4) using the screws and nuts (5).
- Insert the rear part and secure the front part with the catch.

INSTALLATION
page 13
The electronic panel is managed by a suitably programmed microprocessor.
The microprocessor not only improves the functioning of the boiler,
but it also makes it possible to manage the gas-diesel oil boiler with blown burner
of the EURA series.
The temperature detection system is controlled by one or two thermocouples
(combi version). The large display improves boiler management by making read-outs
and functions promptly available.
The main feature of the panel is its capacity to modulate the boiler power according
to the energy requirements of the plant. The panel allows the suction unit to vary its
speed according to the temperature of the boiler: the modulation of power is obtained
by reducing the speed of the smoke suction unit as the temperature in the boiler
increases.
THE PANEL CONSISTS OF:
• Main illuminated switch located on the back of the panel.
•Manual reset safety thermostat push button (back of panel); if the overtemperature
rises above 100°C the burner and fan are shut off.
Once the causes leading to the overtemperature have been identified and solved
the burner and fan can be reactivated by unscrewing the plastic cover of the
thermostat and pressing the button (the boiler temperature must be below 70° C).
• Signal light (back of panel); the light comes on to signal that the manual reset thermostat has tripped.
• Display.
•START push button (to start the operating cycle).
•MIN / MAX push button . Press the push button to select the MINIMUM CYCLE;the min. indicator light
comes on to signal that the cycle has been activated. The boiler develops a power which is 35% below
the rated power.
•ECONOMY push button. When this function is selected the letter “e” appears on the display.
The ECONOMY function can be selected in both the MAXIMUM CYCLE and the MINIMUM CYCLE.
The maximum speed of the fan is 1800 RPM in this cycle compared to 2700 RPM in the cycles other than
the ECONOMY cycles.
This function must be used in the in-between season periods with a partial load of wood or to produce
hot water for domestic use. The fan operates at maximum working speed until the boiler reaches 60°C.
The modulation phase starts at 61°C: the suction unit reduces its rotating speed until it stops as soon as
the boiler temperature reaches 78°C.
Press the push button to select the MAXIMUM CYCLE;the max. indicator light comes on to signal that
the cycle has been activated. The boiler operates at maximum power until the temperature reaches 68°C.
The fan modulates from 69°C to 82°C which is when it stops.
•H-H selection push button. When this button is pressed the letters H-H appear on the display and the
fan operates at maximum speed for one minute in whatever situation it happens to be (even if it has shut
down due to having reached the temperature).
•WOOD-AUT.-DIESEL selection (only for COMBI version). Press this button to select the operating cycle:
only wood, only diesel oil or automatic. Each time the button is pressed the corresponding light comes on.
The automatic cycle activates the gas-diesel oil burner 30 minutes after the boiler temperaturedrops
below 59°C.
•DIESEL OIL °C.Press this button to select the temperaturefor the burner to shut off. The temperaturecan
be selected from between 65°C-85°C; each time you press the button the temperature increases by 1°C.
4.4 FUNCTIONS OF PANEL ON ASPIROTRONIC LE

INSTALLATION
page 14
4.5 DISPLAY PANEL OF ASPIROTRONIC
4.6 PROGRAMS OF THE ASPIROTRONIC LE PANEL
OPERATION OF ASPIROTRONIC LE
Symbols appearing on the display:
-Boiler temperature
-Wood fuel operation
-Smoke suction unit
OPERATION OF ASPIROTRONIC COMBI LE
Symbols appearing on the display:
-Boiler temperature
-Wood fuel operation
-Diesel oil fuel operation
-Smoke suction unit
OPERATION OF ASPIROTRONIC COMBI LE PUFFER TEC
Symbols appearing on the display:
-Boiler temperature + storage temperature
- Wood fuel operation
-Diesel oil fuel operation
-Smoke suction unit
The operating program for the panel can be selected according to the plant type. The
settings for the dipswitches located on the front panel are shown below (figure below).
Prog. Boiler
ASPIROTRONIC LE
Prog. Boiler
ASPIROMEC LE
BOILER TUBE
DIESEL OIL
WOOD
DISPLAY
CONNECTION 2 WIRES BOILER TUBE THERMOCOUPLE
CONNECTION 2 WIRES DIESEL OIL THERMOCOUPLE
CONNECTION 2 WIRES WOOD THERMOCOUPLE
Prog. Boiler
ASPIROTRONIC LE
COMBI DUOTEC
Prog. Boiler
ASPIROTRONIC LE
COMBI

INSTALLATION
page 15
4.7 ELECTRICAL CONNECTIONS DIAGRAM FOR ASPIROTRONIC LE
The circuitry consists of 3 terminal boards called M1 M2 M3. The individual contacts are called "pins".
TERMINAL BOARD M1
Pins 1-2-3 are used in the combi version with
the installation of a 3-way motorised valve
which can cut out and isolate the wood fuel
boiler when the gas-diesel oil boiler is
operating. The switch-over is done by means of
the special push button on the panel.
Pins 4 and 5 are used for the room temperature
thermostat of the plant circulating pump (pins 6
and 7).
The plant circulating pump will only be
activated under the following conditions:
-Room temperature thermostat with closed
contact.
- Temperature of the boiler above 61°C.
The power supply (220 V) for the plant
circulating pump is delivered from pins 6, 7.
The plant circulating pump also functions as a
thermal safety device: if the temperature in the
boiler rises above 90°Cthe plant circulating
pump is activated automatically.
TERMINAL BOARD M2
The M2 terminal board is used when a boiler
tube is installed for the production of hot water
for domestic use.
For priority to domestic hot water install a
thermostat connected to pins 1,2,4.
It is mandatory to connect all the contacts:
common, N.C., N.O.. Pins 3 and 5 are dedicated
to energising the boiler tube pump (220 V).
TERMINAL BOARD M3
Pins 1, 2 (220 V) are used for additional
circulating pumps.
The circulating pumps areonly activated if the
boiler temperature reaches or exceeds 61°C.
Pins 3 and 4 are used for the recycling pump
connected between the delivery and the return
(to prevent heat stratification of the water in the
boiler). This pump operates when the wood
fired boiler is active. Pins 5 and 6 (220V) are
used to power the gas-diesel oil burner.
Pins 7 and 8 are dedicated to powering the
suction unit.
Pins 9, 10, 11 are dedicated to an exchange
valve when the thermal safety device is
activated.
3WAY VALVE DIESEL OIL POSITION
3WAY VALVE WOOD POSITION
COMMON 3 WAY VALVE
ROOM TEMPERATURE THERMOSTAT
PLANT CIRCULATING PUMP
COMMON BOILER TUBE THERMOSTAT
N.C. BOILER TUBE THERMOSTAT
N.O. BOILER TUBE THERMOSTAT
BOILER TUBE CIRCULATING PUMP
ADDITIONAL CIRCULATING PUMPS
RECYCLING PUMP
GAS-DIESEL OIL BURNER
FAN
N.O.
BY PASS EXCHANGE COM.
N.C.

INSTALLATION
page 16
4.7.1 DIAGRAM OF ASPIROTRONIC LE ELECTRONIC PANEL
11
11
33
33
22
22
44
44
55
55
77
77
88
88
66
66
99
99
3 WAY VALVE DIESEL OIL POSITION
3 WAY VALVE WOOD POSITION
COMMON 3 WAY VALVE
ROOM TEMPERATURE THERMOSTAT
PLANT CIRCULATING PUMP
ADDITIONAL CIRCULATING PUMPS
RECYCLING PUMP
GAS-DIESEL OIL BURNER
FAN
N.O.
BY PASS EXCHANGE COM.
N.C.
COMMON BOILER TUBE THERMOSTAT
N.C. BOILER TUBE THERMOSTAT
N.O. BOILER TUBE THERMOSTAT
BOILER TUBE CIRCULATING PUMP
The fuses on the power board are shown in the diagram: 1) 220 V safety fuse
2) General safety fuse
3) 3 way valve fuse
4) By pass fuse
5) Circulating pump fuse
6) Low voltage fuse
7) Recycling pump fuse
8) Burner fuse
9) Smoke suction unit fuse
N.B.: If the room temperature thermostat is not
used install a jumper between terminals 4 and 5
on terminal board M1.
N.B.: If the boiler tube is not used install a
jumper between terminals 1 and 4 on terminal
board M2.

INSTALLATION
page 17
4.7.2 REMOTE BOARD CONTROL
Allows you to view the main parameters of the generator on a separate unit (Remote Board Control).
The data is transmitted on radio waves.
The unit is powered with the help of a transformer 220 – 7.5 V (supplied).
4.7.3 INSTALLATION OF THE ANTENNA
Installation of the antenna on the control board for the "Remote Board Control" (only on ASPIROTRONIC
version). The transmitting antenna must be installed in order to be able to transmit the main parameters
from the control panel to the "Remote Board Control".
Fasten the antenna to the top part of the panel, as shown in the photos.
Insert the transmitting module on the connection board.
At this point the antenna is connected to the control board.
PIN 1
PIN 1
ANTENNA
ANTENNA EARTH BRAID

INSTALLATION
page 18
4.7.4 INSTALLATION OF THE ANTENNA
4.8 INSTALLATION OF ASPIROMEC LE ELECTROMECHANICAL PANEL
Illuminated bipolar switch
Plant circulating pump
Additional circulating pump
Boiler tube circulating pump
Room temperature thermostat
Boiler tube thermostat
Gas-diesel oil burner
Fan
Board
Circulating pump
Burner
3 way motorised valve
Microprocessor enables contact when the thermocouple exceeds T=61°C
Microprocessor enables contact when the thermocouple exceeds T=89°C
Microprocessor enables BR a) always in diesel oil position
b) 3 min after the temperature has dropped below 59° C in automatic position
Microprocessor enables exchange each time the BR is powered
When T.B. closes the contact the microprocessor enables C.B. and C.A. (priority to domestic hot water)
Microprocessor enables contact when the temperature of the thermocouple exceeds T=61° C
Microprocessor adjusts the rpm of the suction unit
1 – Retainer nuts
2 - Screws M5 x16
3 – Control board
4 – Board cover
5 – Self-tapping screws
Fasten the ASPIROMEC LE panel to the front cover of the boiler.
Use the supplied screws and nuts (3) to fasten the panel with cover after having made all the necessary
connections: unwind the capillaries, thread them through the precut holes in the side right or left, insert the
end bulbs in the pockets (A) located on the top of the boiler and fill up with lubricating oil to improve the
exchange.
1
3
4
2
5

INSTALLATION
page 19
4.9 ASPIROMEC LE ELECTROMECHANICAL PANEL FUNCTIONS
The control panel consists of the following parts:
1 – Main and cycle start switch (illuminated).
2 – Boiler fan control switch.
3 – Heating plant circulating pump control switch.
4 – Wood cycle start and fuel finished signal light. This light comes on when the
fuel finished thermostat signals a drop in the water temperature caused by
a lack of firewood. The thermostat is located inside the electric panel and it
is calibrated at 45° C. Once the wood load finishes the light comes on and
the fan shuts off.
5 – Manual reset safety thermostat; when the overtemperature goes above 100°
C the fan shuts off. Once the reasons for this overtemperature have been
identified and resolved the fan can be reactivated by unscrewing the plastic
cover on the thermostat and pressing the button (the temperature of the
boiler must be below 70° C).
6 – Thermostat for regulating the boiler water temperature (from 70 to 90° C).
The manufacturer recommends keeping the boiler water temperature on
high values (75° C /80° C) in order to prevent the formation of condensation.
7 – Thermometer.
The following devices are located inside the electric panel:
- Forced circulation (bypass) thermostat calibrated at 90°C. This is a safety
device which prevents the boiler water from boiling by activating the
circulating pump for a few seconds, even without the signal from the room
temperature thermostat.
- Anticondensation thermostat (Calibrated at 60°C)
- Fuel finished thermostat (Calibrated at 45°C)
- Relay.
Operation:
The operation of the fan is indispensable for intaking air required for the combustion in the boiler. The fan
functions if switch 2 is positioned on "1".
The air intake is always the maximum and it only stops when the set point temperature of the boiler
thermostat is reached. The pumps must always be connected to the panel as they are activated above
60°C. When the wood fuel is about to finish, the water temperature tends to drop and eventually shuts down
the pump as the anticondensation thermostat is tripped. The fan continues to operate without producing
any further heat and cools the boiler body. When, as a result of this cooling process the temperature drops
to roughly 45°C, the fuel finished thermostat is tripped, which in turn shuts down the fan. In the initial
starting phase when the boiler is cold the fuel finished device could be activated even if the boiler is lit and
running on a full load of wood.
This occurs when:
- The circulators are not connected to the electric board but by means of external collar thermostats. The
poor sensitivity of these thermostats can allow the pumps to operate to the point where the water
temperature in the boiler drops below 45°C which trips the fuel finished thermostat.
- The overall capacity of the pumps is so high that when they start at 60°C for the first time, the water refill
is so fast that the cold water return from the plant is not signalled in time by the anticondensation
thermostat, consequently the temperature drops below 45°C, which in this case as well, trips the fuel
finished thermostat.
To remedy this situation in this case simply reduce the pump speed, or throttle its flow capacity.
1
0
70 9080
0
1

INSTALLATION
page 20
4.9.1 WIRING DIAGRAM FOR ASPIROMEC LE
KEY
S1A MAIN SWITCH S2A CIRCULATING PUMP SWITCH B2T ANTICONDESATION THERM. 60°C B3T SAFETY BY-PASS THERMOSTAT 90°C B4T FUEL FINISHED THERMOSTAT 45°C K0A THERMOSTATAUX K1A FUEL FINISHED AUX B1T
SAFETY THERMOSTAT WITH MANUAL RESET 96°C
B5T FAN THERMOSTAT 60°-90°C S3A FAN SWITCH
THE PERSON WHO MAKES THE BOILER
CONNECTIONS MUST ALSO INSTALL A
MAGNETOTHERMAL SWITCH SUITABLE FOR THE
PROTECTION OF THE PUMPS
POWER SUPPLY
230V-50Hz WITH 6A
MAXIMUM CURRENT
PROTECTION
ROOM TEMPERATURE
THERMOSTAT
EXTRA CIRCULATING PUMPS FOR INDEPENDENT
CIRCUITS MAY BE CONNECTED BETWEEN TERMINALS 11
AND 12 AND CONTROLLED LOCALLY BY ROOM
TEMPERATURE THERMOSTATS. THE CURRENT DEMANDED
BY THESE ADDITIONAL APPLIANCES MUST NOT INVOLVE A
GLOBAL ABSORPTION FROM THE POWER SUPPLY MAINS
OF THE BOILER GREATER THAN 6A . IN THIS CASE IT WILL
BE NECESSARY TO INSTALL A SUITABLE AUXILIARY RELAY
AND NECESSARY PROTECTIVE DEVICES FOR THE
CONTROL OF THE PUMPS.
WIRING TO BE MADE WITH: WIRE TYPE : NO7V-K
MINIMUM SECTION : 1 mmq
TERMINAL BOARDS : INDIRECT CLAMPING Avail. Wire ----> F 17
CIRCULATING PUMP
CIRCULATING PUMP FAN
FUEL FINISHED
AUXILIARY
FUEL FINISHED LED
FOR THE MAIN ROOM TEMPERATURE
THERMOSTATCONNECTION IT IS
NECESSARY TO REMOVE THE JUMPER
BETWEEN TERMINALS 4 AND 5 ON THE
TERMINAL BOARD
THERMOSTAT
AUXILIARY
INTERNAL CONNECTIONS EXTERNAL CONNECTIONS
PHASE
NEUTRAL
FAN
ADDITIONAL EXTERNAL
CIRCULATING PUMPS BEYOND 1°
APPL. GROUND
CIRCULATING
PUMP
ROOM TEMP. THERMOSTAT
GROUND (PE)
TERMINAL BOARD X1
