thomann Source Mix 18R User manual

Source Mix 18R
mixer
user manual

Musikhaus Thomann
Thomann GmbH
Hans-Thomann-Straße 1
96138 Burgebrach
Germany
Telephone: [phone]
E-mail: [email protected]
Internet: www.thomann.de
09.07.2018, ID: 427376

Table of contents
1 General information................................................................................................................................. 4
1.1 Further information........................................................................................................................... 5
1.2 Notational conventions.................................................................................................................... 6
1.3 Symbols and signal words............................................................................................................... 6
2 Safety instructions..................................................................................................................................... 8
3 Features....................................................................................................................................................... 12
4 Installation.................................................................................................................................................. 13
5 Connections and controls................................................................................................................... 15
6 Technical specifications....................................................................................................................... 20
7 Plug and connection assignment.................................................................................................... 22
8 Protecting the environment.............................................................................................................. 25
Table of contents
Source Mix 18R
3

1 General information
This manual contains important instructions for the safe operation of the unit. Read and follow
the safety instructions and all other instructions. Keep the manual for future reference. Make
sure that it is available to all those using the device. If you sell the unit please make sure that
the buyer also receives this manual.
Our products are subject to a process of continuous development. Thus, they are subject to
change.
General information
mixer
4

1.1 Further information
On our website (www.thomann.de) you will find lots of further information and details on the
following points:
Download This manual is also available as PDF file for you to download.
Keyword search Use the search function in the electronic version to find the topics of
interest for you quickly.
Online guides Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service If you have any problems with the device the customer service will
gladly assist you.
General information
Source Mix 18R
5

1.2 Notational conventions
This manual uses the following notational conventions:
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
1.3 Symbols and signal words
In this section you will find an overview of the meaning of symbols and signal words that are
used in this manual.
Letterings
General information
mixer
6

Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos-
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – high-voltage.
Warning – danger zone.
General information
Source Mix 18R
7

2 Safety instructions
This device is intended to be used for amplification, mixing and playback of signals from
musical instruments and microphones. Use the device only as described in this user manual.
Any other use or use under other operating conditions is considered to be improper and may
result in personal injury or property damage. No liability will be assumed for damages resulting
from improper use.
This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Intended use
Safety instructions
mixer
8

DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never
remove any covers.
There are no user-serviceable parts inside.
Do not use the device if covers, protectors or optical components are missing or
damaged.
Safety
Safety instructions
Source Mix 18R
9

DANGER!
Electric shock caused by short-circuit
Always use proper ready-made insulated mains cabling (power cord) with a pro-
tective contact plug. Do not modify the mains cable or the plug. Failure to do so
could result in electric shock/death or fire. If in doubt, seek advice from a regis-
tered electrician.
NOTICE!
Risk of fire
Do not block areas of ventilation. Do not install the device near any direct heat
source. Keep the device away from naked flames.
Safety instructions
mixer
10

NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
NOTICE!
Power supply
Before connecting the device, ensure that the input voltage (AC outlet) matches
the voltage rating of the device and that the AC outlet is protected by a residual
current circuit breaker. Failure to do so could result in damage to the device and
possibly injure the user.
Unplug the device before electrical storms occur and when it is unused for long
periods of time to reduce the risk of electric shock or fire.
Safety instructions
Source Mix 18R
11

3 Features
n8 microphone / line inputs with separate volume and tone controls, each with XLR and
1/4" phone sockets
nLine output
nPre-fader output and AUX input allow multiple devices to be connected in series
nPhantom power switchable per channel
nsolid metal housing, 19" rack mountable (1 RU)
Features
mixer
12

4 Installation
NOTICE!
Danger of short circuit
Switching on phantom power will damage the device if unbalanced XLR cables
are connected.
Only turn on phantom power when exclusively balanced XLR cables are con-
nected.
Unpack and carefully check that there is no transportation damage before using the unit. Keep
the equipment packaging. To fully protect the device against vibration, dust and moisture
during transportation or storage use the original packaging or your own packaging material
suitable for transport or storage, respectively.
Create all connections while the device is off. Use the shortest possible high-quality cables for
all connections. Take care when running the cables to prevent tripping hazards.
Installation
Source Mix 18R
13

The unit has been designed for rack mounting in a standard 19-inch rack; it occupies one rack
unit.
Rack mounting
Installation
mixer
14

5 Connections and controls
Front panel
Connections and controls
Source Mix 18R
15

1[POWER]
Mains switch to turn the device on and off.
The corresponding LED indicates that the device is switched on.
2[MASTER VOL]
Overall volume control
3[8]…[1]
Controls for the eight input channels
n[TONE]: Tone control for the respective channel. The "0" position corresponds to the neutral position.
n[VOLUME]: Level control for the respective channel
nThe LED indicates that a signal is present at the respective input.
Connections and controls
mixer
16

Rear panel
Connections and controls
Source Mix 18R
17

4[CHANNEL 1]…[CHANNEL 8]
Signal inputs 1 to 8, each designed as lockable, balanced XLR chassis plugs and as unbalanced 1/4" phone socket.
5[PHANTOM POWER]
DIP switch for switching on phantom power for the supply of condenser microphones connected to the signal
inputs.
The phantom power leads to damage to the device if unbalanced cables are connected. Only switch on phantom
power while exclusively balanced cables are connected.
6[AUX BUS IN]
Signal input for the series connection of several mixers, designed as RCA socket.
7[POWER INPUT]
IEC chassis plug for operating voltage supply with fuse holder.
Should the fuse have blown, disconnect the unit from the power supply and replace the fuse with a new fuse of the
same type.
Connections and controls
mixer
18

8[PREFADE OUT]
Signal output to connect another mixer, designed as RCA socket. The level of this output is not affected by the overall
volume control.
9[MAIN OUT]
Signal output for connecting an amplifier or powered speaker box, designed as 1/4" phone socket.
Connections and controls
Source Mix 18R
19

6 Technical specifications
Input level (Mic / Line) XLR connectors (balanced): max. –15 dBv
1/4" phone socket (unbalanced): max. +22 dBv
Input impedance (Mic / Line) XLR connectors (balanced): 600 Ω
1/4" phone socket (unbalanced): 50 kΩ
Input impedance (Aux / Bus) RCA socket: 10 kΩ
Total harmonic distortion (THD) < 0.003 %
Signal-to-noise ratio 106 dB
Common mode rejection Mic: 52 dB
Gain Mic: 55 dB
Line: 26 dB
Tone control. ±20 dB
Output level max. +17 dBV
